Pro Boat PRB08011 User Manual

PRB08011

29-INCH BRUSHLESS RTR CATAMARAN

BlackjackTM 29

Owners Manual • Bedienungsanleitung
Manuel de l'utilisateur • Manuale dell'utente

EN

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date
product literature, visit http://www.horizonhobby.com and click on the support tab for this product.

Meaning of Special Language

NOTICE

The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility

of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious
injury OR create a high probability of superficial injury.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate
the product correctly can result in damage to the product, personal property and cause serious injury.

This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and requires some basic mechanical
ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This
product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in
any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It
is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and
avoid damage or serious injury.

WARNING AGAINST COUNTERFEIT PRODUCTS

Thank you for purchasing a genuine Spektrum product. Always purchase from a Horizon Hobby, LLC authorized
dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with
regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility
with DSM or Spektrum.

Age Recommendation: Not for children under 14 years. This is not a toy.

Safety Precautions and Warnings

As the user of this product, you are solely responsible for
operating in a manner that does not endanger yourself and
others or result in damage to the product or the property of
others.

• When handling and/or transporting your boat, always
pick up the boat from the front, keeping all moving parts
pointed away from you.

• Always keep a safe distance in all directions around
your model to avoid collisions or injury. This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.

• Always operate your model in open spaces away from
full-size vehicles, traffic and people.

• Always carefully follow the directions and warnings
for this and any optional support equipment (chargers,
rechargeable battery packs, etc.).

• Always keep all chemicals, small parts and anything
electrical out of the reach of children.

• Always avoid water exposure to all equipment not
specifically designed and protected for this purpose.
Moisture causes damage to unprotected electronics.

• Never place any portion of the model in your mouth
as it could cause serious injury or even death.

• Never operate your model with low transmitter batteries.

Table of Contents

Water-resistant Boat with Waterproof Electronics .......... 3

General Precautions ........................................................ 3

Wet Conditions Maintenance .......................................... 3

Introduction ..................................................................... 4

Specifications .................................................................. 4

Recommended Tools and Materials ................................ 4

Product Inspection........................................................... 4

Boat Stand Assembly ...................................................... 5

Antenna Tube Installation................................................. 5

Canopy Removal .............................................................. 5

Battery Charger ............................................................... 6

Low Voltage Cutoff (LVC) ................................................. 6

Installing the Battery Packs ............................................. 6

Spektrum DX2E Radio System ........................................ 7

Binding ........................................................................... 8

Getting Started ................................................................ 8

Range Check ................................................................... 9

2

Testing Your Boat in the Water ........................................ 9

Motor Care .....................................................................10

When you are Finished...................................................10

After Boating and Maintenance ......................................11

Rudder Service ...............................................................11

Water Cooling System ....................................................11

Rudder Service ...............................................................11

Prop Angle Adjustment ................................................. 12

Drivetrain Lubrication..................................................... 12

Troubleshooting Guide ................................................... 13

LIMITED WARRANTY .................................................... 14

Warranty and Service Contact Information ................... 15

Compliance Information for the European Union .......... 16

Instructions for Disposal of WEEE ................................ 16

Replacement Parts ........................................................ 62

Optional Parts ................................................................ 62

Blackjack 29

Water-resistant Boat with Waterproof Electronics

Your new Horizon Hobby boat has been designed and built with a combination of waterproof and water-resistant
components to allow you to operate the product in calm, fresh water conditions.

While the entire boat is highly water-resistant, it is not completely waterproof and your boat should NOT be treated like
a submarine. The various electronic components used in the boat, such as the Electronic Speed Control (ESC), servo(s)
and receiver are waterproof, however, most of the mechanical components are water-resistant and require additional
maintenance after use.

Metal parts, including the bearings, pins, screws and nuts, propeller, rudder, rudder mounts, prop struts, as well as
the contacts in the electrical cables, will be susceptible to corrosion if additional maintenance is not performed after
running in wet conditions. To maximize the long-term performance of your boat and to keep the warranty intact, the
procedures described in the “Wet Conditions Maintenance” section below must be performed regularly.

CAUTION: Failure to exercise caution while using this product and complying with the following precautions could
result in product malfunction and/or void the warranty.

EN

General Precautions

• Read through the wet conditions maintenance
procedures and make sure that you have all the tools
you will need to properly maintain your boat.

• Not all batteries can be used in wet conditions.
Consult the battery manufacturer before use. Caution
should be taken when using Li-Po batteries in wet
conditions.

• Most transmitters are not water-resistant. Consult
your transmitter’s manual or the manufacturer before
operation.

• Never operate your transmitter or boat where
lightning may be present.

• Salt water is very conductive and highly corrosive.
If you choose to run your boat in salt water,
immediately rinse the boat in fresh water after every
use. Operating your boat in salt water is at the sole
discretion of the modeler.

• Even minimal water contact can reduce the life of
your motor if it has not been certified as water­resistant or waterproof. If the motor becomes
excessively wet, apply very light throttle until the
water is mostly removed from the motor. Running a
wet motor at high speeds may rapidly damage the
motor.

• Driving in wet conditions can reduce the life of the
motor. The additional resistance of operating in water
causes excess strain.

Wet Conditions Maintenance

• Drain any water that has collected in the hull by
removing the drain plug or canopy and tilting the boat
in the appropriate direction to drain the water.

CAUTION: Always keep hands, fingers, tools and any
loose or hanging objects away from rotating parts.

• Remove the battery pack(s) and disconnect the
ESC and motor. Dry the contacts. If you have an air
compressor or a can of compressed air, blow out
any water that may be inside the recessed connector
housings.

• Remove the flex shaft and all moving parts. Dry and
lubricate parts after every 30 minutes of operation or
if the boat becomes submerged.

NOTICE: Never use a pressure washer to clean your
boat.

• Use an air compressor or a can of compressed air
to dry the boat and help remove any water that may
have gotten into small crevices or corners.

• Spray the bearings, fasteners and other metal parts
with a water-displacing light oil or lubricant. Do not
spray the motor.

• Let the boat air dry before you store it. Water (and oil)
may continue to drip for a few hours.

Blackjack 29 3

EN

Introduction

Pro Boat® RC models look as good as they perform. Our boats, which include everything from scale sailboats to
fully licensed powerboats, exceed expectations and provide years of radio control fun and excitement. Whether your
passion leads you towards the pure serenity of sailing or the all-out speed of a Deep-V, Pro Boat models fit your taste,
budget and lifestyle. You can count on us to be available any time you need help—the brand is backed by Horizon
Hobby, one of the world’s largest distributors of hobby-grade RC products. The Pro Boat brand will help you turn your
boating passion into a reality, whether you’re new to the hobby or an old pro.

Please read this manual for operation and maintenance instructions.

Register your boat online at www.proboatmodels.com.

Specifications

Length 29 in (736mm)
Beam (width) 10.75 in (273mm)
Hull Material Fiberglass Composite

®

Motor Dynamite
6-pole, Marine

ESC Dynamite 120-amp brushless,
water-cooled

Transmitter Spektrum™ DX2E V3 2.4GHz
Pistol Grip Transmitter

Receiver Spektrum SR410
Batteries 4 AA batteries (sold

separately) are required to
operate the transmitter.

(2) Reaction® 7.4V 5000mAh
2S 50C Li-Po batteries
(sold separately)

2000Kv,

10.75 in

(273mm)

29 in (736mm)

Recommended Tools and Materials

• Needle nose pliers

• Paper towel

• Rubbing alcohol

• Open-end wrench: 10mm (2)

• Nut driver: 4mm, 5.5mm, 8mm

• Phillips screwdriver: #1

• Hex wrench: 1.5mm, 2mm, 2.5mm, 3mm

• Clear tape (DYNM0102)

• Pro Boat® Marine Grease and Gun

• Hook and Loop Tape Set, WP 4pcs

Product Inspection

Carefully remove the boat and radio transmitter from the
box. Inspect the boat for damage.
If you find damage is present, please contact the retailer
where you purchased your boat.

Blackjack 294

Boat Stand Assembly

1. Attach the side stand pieces to the end pieces as
shown.

2. Use medium CA or epoxy adhesive to secure the side
stand to the ends.

3. Allow the adhesive to dry before placing your boat on
the stand.

Antenna Tube Installation

1. Carefully feed the end of the receiver antenna through
the grommet inside the hull.

2. Pull the antenna wire out of the grommet
towards the outside of the boat, then slide the
antenna through the antenna tube.

3. Insert the tube into the grommet, then
fit the cap onto the tube.

4. Apply clear tape to the antenna, grommet
and hull in the boat to keep the antenna
from moving.

The antenna must be installed above the boat's waterline
to get the best reception of your transmitter's signal.

NOTICE: Do not cut or kink the receiver antenna
or damage may result.

EN

Canopy Removal

1. Push down and turn the latch button one quarter of a
turn to disengage the pin from the hull.

2. Carefully lift the rear of the canopy and pull back to
disengage the front pin from the hull.

Blackjack 29

5

Battery Charger

Choose a charger designed to charge the recomended
Dynamite
We recommend either the Dynamite Prophet™ Sport
Plus 50W AC/DC Charger or the Dynamite Prophet Sport
Duo 2 X 50W charger. Refer to your charger manual for
charging instructions and safety information.

®

Reaction 7.4V 5000mAh 2S 50C Li-Po battery.

Low Voltage Cutoff (LVC)

Discharging a Li-Po battery below 3V per cell may
damage your battery.The included ESC protects the boat
battery from over-discharge using Low Voltage Cutoff
(LVC). Before the battery charge decreases too much,
LVC removes power supplied to the motor. Power to
the motor pulses, showing that some battery power is
reserved for boat control and safe landing.

Disconnect and remove the Li-Po battery from the boat
after use to prevent trickle discharge. Charge your Li-Po
battery to about half capacity before storage. During
storage, make sure the battery charge does not fall below
3V per cell. LVC does not prevent the battery from over­discharge during storage.

NOTICE: Never charge a battery in the boat or damage
may result.

NOTICE: Repeated operation to LVC will damage the
battery.

Tip: Monitor your boat battery's voltage before and
after boating by using a Li-Po Cell Voltage Checker
(DYN4071, sold separately).

Installing the Battery Packs

1. Install the 2 battery packs opposite each other in the
compartment. Secure with the hook and loop straps.
If running your boat in rougher water conditions, the
use of Waterproof Hook and Loop Tape (DYNK0300)
may also be needed to fully secure your batteries'
positions.

Tip: Move the packs forward or back to adjust the
center of gravity for your boat. Move the packs toward
the bow so the bow rides lower in the water. Move
the packs away from the bow so that the bow rides
higher in the water.

2. Connect each battery pack to the ESC power
connectors.

X2

6ENBlackjack 29

Blackjack 29
