Pro Audio WPM-2U User guide

USER GUIDE

WPM-2U

UHF Wireless Podium Microphone

Offering the proven advantage and convenience of wireless operation,
the WPM-2U wireless podium microphone is the most practical option
in many podium, lectern and desktop conferencing applications.

Thank you for choosing the Nady WPM-2U UHF wireless podium microphone, we
know you will be very pleased with its performance and features. The WPM-2U
was developed using the expertise of professional sound engineers. You will find
your new UHF wireless podium microphone has superior performance and greater
flexibility than any other podium microphone in its price range.

Features

• Superior,clearaudioforbestpossiblecommunication

• Upto200’ultrareliablereceptionrangeforutmost

versatility and operating ease in any application—simplifies
setup with no cumbersome cabling required between mic
and amplifier

• Offeringtopperformanceindistinguishablefromthebest

hard-wired podium microphones

• Idealfordesktopconferencing,withnoclutterofcables,

for the cleanest, simplest possible installation

• UptosixWPM-2Usystems(allondifferentfrequencies)
canbeoperatedsimultaneouslyatthesametime(upto
14totalifcombiningtheUHFandWPM-1VVHFsystems)

• ForusewithaUHF-3receiveronthesamefrequency
only(soldseparatelyoracombinedsystemormulti-channel
systems)

Controls

(1) AUTO MUTE (POWER ON/OFF) SWITCH

ThisswitchisusedtoturntheaudioONorOFF.Useasneededforeasycontrolof
themicwhileoperatingwithintermittentaudioONrequirementsduringacontinuous
useapplication.ThisswitchalsoturnsthetransmitterON/OFF,butonlyiftheMAIN
POWERON/OFFSWITCHisON.Forproperoperationandaudioon,boththeMAIN
POWERON/OFFSWITCHandtheAUTOMUTE(POWERON/OFF)SWITCHmustbe
intheONposition.

(2) LED INDICATOR

ThisLEDlightsgreenwhentheunitispoweredONandthebatteriesareuseable.

When it turns orange it indicates the batteries are low and must be replaced.

(3) MICROPHONE

This unidirectional microphone is designed to pick up sound sources directly in

frontofit.ItplugsintothebasethroughtheXLRconnector.Thebaseoftheneckis
adjustableandeasytobendinanydirection.Speakintothemicfromadistanceof6”
to12”foroptimumperformance.Alsofollowtheinstructionsinthemanualforthe

accompanying wireless receiver for proper setup of the audio signal from the receiver.

3

2

1

5

(4) BATTERY COMPARTMENT

TheunitispoweredbytwoalkalineorrechargeableNiCadorNiMHAA(1.5V)
batteries.ReplacewhentheLEDINDICATORlightsorange.

(5) MAIN POWER ON/OFF SWITCH

ThisisthemainpowerswitchwhichturnsthetransmitterON/OFF.Itmustbe
turnedonrsttopowertheunit.AlwaysleavethisintheOFFpositionwhennot

using the unit.

4

2xAA

Operation

• Easyoperation,simpliedsetup—
cord-free, ultra-reliable wireless podium mic

operationforupto200’ftwithhighestqualityaudio

• Choiceofsixstandardfrequenciesbetween
470-510MHz

Public Address System

OR

Desktop Conferencing System

Specifications

MICROPHONE:OptimallymatchedUnidirectionalCondenser

Microphone with adjustable neck

RF FREQUENCY:UHF470-510MHz,usewithaNady
UHF-3receiveronthesamefrequency

FREQUENCY STABILITY:+/-0.005%,crystalcontrolled

MODULATION:FM(F3E),+/-20kHznormal

TONE SQUELCH:38.000KHz

RF OUTPUT:50mW(MaximumallowedbyFCC)

HARMONICS & SPURS:<-60dBc

OPERATION RANGE:Upto250ft,typical(dependingon

sitecondition);andupto500+feetoptimumline-of-sight

CONTROLS:PowerON/OFFandAutoMute

LED INDICATOR:Bi-color,Unit“ON”(green),

LowBatteryAlert(Orange)

BATTERY:3V(twoAA)AlkalineorRechargeable
(NiCadorNiMH)

BATTERY DRAIN:120mA

BATTERY LIFE:8-16Hours,dependingondutycycle

WEIGHT: 1.5lbs(includebatteriesandmicrophone)

Service

(U.S.)ShouldyourNADYWPM-2Uproductrequireservice,pleasecontacttheNadyServiceDepartmentviatelephone
at(510)652-2411ore-mailat[email protected].

(International)Forservice,pleasecontacttheNADYdistributorinyourcountrythroughthedealerfromwhomyou

purchased this product.
