Operating instructions NJ1 e-assistant
0
MOBILITY MADE SIMPLE!
Operating instructions
Service booklet
NJ1 e-assistant
Operating instructions NJ1 e-assistant
1
Contents
1Preface ............................................................................................................................................... 3
2Legend ................................................................................................................................................ 3
3CE Declaration of Conformity / other information ............................................................................... 3
3.1Classification ............................................................................................................................... 3
3.2Declaration of Conformity ........................................................................................................... 3
3.3Manufacturer ............................................................................................................................... 3
4Scope of delivery ................................................................................................................................ 3
5Introduction ......................................................................................................................................... 4
6Product description / purpose ............................................................................................................. 4
7Acceptable usage and operating conditions / places of use .............................................................. 4
8Technical specifications ..................................................................................................................... 5
8.1Drive system ............................................................................................................................... 5
8.2Climbing power ........................................................................................................................... 5
8.3Product weight ............................................................................................................................ 5
8.4Load weight ................................................................................................................................ 5
8.5Obstacle height and turning circle .............................................................................................. 5
8.6Service life .................................................................................................................................. 5
9Commissioning ................................................................................................................................... 6
10Hand-over ........................................................................................................................................... 6
11Safety instructions - prior to driving / use ........................................................................................... 6
12Safety instructions - while driving / using ........................................................................................... 7
13Safety instructions regarding obstacles ............................................................................................. 8
14Safety instructions regarding dangerous locations and dangerous situations ................................... 9
15Ending the driving operation ............................................................................................................... 9
16Safety instructions - after driving / use ............................................................................................... 9
17Adapter & adaptation .......................................................................................................................... 9
18Functional elements ......................................................................................................................... 10
18.1Parking stand ............................................................................................................................ 10
18.1.1Active and passive positions ........................................................................................ 10
18.1.2
Parking stand height adjustment ......................................................................... 10
18.2
Pedal bearing support & crank ......................................................................................... 11
18.2.1Seating position ........................................................................................................... 11
18.2.2Pedal bearing position ................................................................................................. 11
18.2.3Crank length and grip width ......................................................................................... 12
18.3Grips ......................................................................................................................................... 13
Operating instructions NJ1 e-assistant
2
18.4 Gear shift .................................................................................................................................. 13
18.4.1 Chain shift .................................................................................................................... 13
18.4.2 Hub gears .................................................................................................................... 14
18.4.3 Pedal bearing gearshift ................................................................................................ 15
18.5 Disc and rim brakes .................................................................................................................. 15
18.6 Back-pedal brake & crank release function .............................................................................. 16
18.6.1 Operation ..................................................................................................................... 16
18.6.2 Operation ..................................................................................................................... 16
18.6.3 Safety instructions ........................................................................................................ 16
18.7 Parking brake ............................................................................................................................ 17
18.8 Battery pack .............................................................................................................................. 17
18.9 Components & drive system ..................................................................................................... 17
19Storage ............................................................................................................................................. 17
20Transport .......................................................................................................................................... 18
21Malfunctions ..................................................................................................................................... 18
22Cleaning and care ............................................................................................................................ 18
23Maintenance ..................................................................................................................................... 19
23.1 General instructions .................................................................................................................. 19
23.2 Service schedules ..................................................................................................................... 19
23.3 Proof of maintenance ................................................................................................................ 20
24Disposal ............................................................................................................................................ 20
25Re-use .............................................................................................................................................. 20
26Warranty ........................................................................................................................................... 20
27Liability .............................................................................................................................................. 20
28Appendix: Avoiding crossed gears with the chain shift .................................................................... 21
29Appendix: Tightening torques and securing details ......................................................................... 22
30Appendix: Medical product passport / record of training .................................................................. 23
31Appendix: Hand-over certificate ....................................................................................................... 24
31.1 Required compliance criteria to authorise use ......................................................................... 24
31.2 Check list for training the user .................................................................................................. 25
32Appendix: Inspection lists ................................................................................................................. 26
Operating instructions NJ1 e-assistant
3
1 Preface
Dear customer,
Congratulations on purchasing your new PRO
ACTIV product. You have bought a quality
product which has been especially customised
to meet your requirements.
We have put together some instructions about
its proper and safe use in the following document. Please read these instructions before
using the product.
Throughout these operating instructions, the
operation of standard components is explained. If you have individual solutions or nonstandard components on your drive unit, we
would be happy to deal with any questions
about handling it at PRO ACTIV.
If you have additional questions about this or
any other product that we supply, we are
happy to answer them.
Enjoy your trips and the best possible mobility.
Your PRO ACTIV team
2 Legend
The symbols used in these operating instructions have the following meanings:
Manufacturer
Warnings and safety instructions
Serial number
Additional information
Assembly instructions for the dealer (see
table of contents)
3 CE Declaration of Conformity /
other information
3.1 Classification
The NJ1 e-assistant (referred to as a "product"
below) is classified as a class I product.
3.2 Declaration of Conformity
PRO ACTIV Reha-Technik GmbH declares in
the context of an individual declaration of conformity that the respective product has been
developed and manufactured according to the
relevant provisions of EC Directive 93/42/EEC
2007.
If the product is adapted in a manner which
has not been agreed by PRO ACTIV RehaTechnik GmbH, this declaration becomes void.
3.3 Manufacturer
PRO ACTIV Reha-Technik GmbH
Im Hofstätt 11
D-72359 Dotternhausen
Tel. +49 7427 9480-0
Fax +49 7427 9480-7025
E-Mail: info@proactiv-gmbh.de
Web: http://www.proactiv-gmbh.com
4 Scope of delivery
The product may only be operated with an
adapter supplied by PRO ACTIV which is suitable for the wheelchair.
The delivery includes the product configured in
accordance with the order, battery pack, console / display, mains power charger, reflectors,
operating instructions, record of training /
hand-over certificate, inspection lists.
Please check that the delivery is complete after
you have received your product.
The product is tested to ensure it is completely
functional prior to shipping. If your product has
been damaged during transit, please contact
your dealer or PRO ACTIV immediately.
Operating instructions NJ1 e-assistant
4
5 Introduction
Before starting your journey, familiarise
yourself with these operating instructions paying particular attention to the safety information
and hazard warnings contained within them.
If you are not sure how to handle the
product or if technical faults occur, please contact your dealer or PRO ACTIV before using it.
When operating the product, the wheelchair operating instructions must also be observed. Information on limit values must not be
exceeded. If the values contained in the two
operating instructions differ, the lower limit is
the one which applies.
The control software is programmed at the
factory to ensure that the legal requirements
for a pedelec drive are met. If changing the
software, it must be ensured that these requirements are still met.
Never leave the product unattended, either when it is switched on or switched off. If
this cannot be avoided, removing the battery
and the display can help prevent unauthorised
use.
6 Product description / purpose
The product is attached to a manual wheelchair as an electrically propelled drive unit
which helps to assist the wheelchair user when
moving the wheelchair. This means that long
distances can be covered largely without tiring
the user. On flat roads and uphill, the electrical
drive of the product provides the force to pull
the wheelchair. Downhill, the speed can be
controlled using the product's braking system
and, possibly, through the recuperation. This
allows for safe driving down slopes.
For safety reasons, the product may only be
operated by persons who
• have been trained in its use by the dealer
or PRO ACTIV.
• can move and control their hands and
arms so that they are able to operate the
controls and perform the full steering
movement without restrictions while driving.
• are physically and mentally capable of
safely operating the device in all operating
situations and can meet the legal requirements for use on public roads.
7 Acceptable usage and operating
conditions / places of use
Observe the instructions on permitted operating conditions in the operating instructions of
your wheelchair on which the product has been
installed.
Use the product on paved surfaces. Avoid
driving on unpaved or loose surfaces (e.g. on
loose gravel, in sand, mud, snow, ice or
through deep puddles of water), as this may
result in incalculable risks.
The wheelchair with the adapted product must
be equipped in accordance with road traffic
regulations when operated on public roads and
spaces.
When driving downhill the maximum permitted
speed must not be exceeded; if necessary
operate the hydraulic service brake. The appropriate value for your product can be found
in the operating instructions from the drive
manufacturer.
The driving characteristics and speed parameters can be programmed using the display. The
programming has been done at the factory and
does not normally need to be adjusted.
Changes to the programming may only be
carried out by your dealer or PRO ACTIV.
The maximum permitted load of the product in
its standard design is 120 kg towed capacity
and 10 kg payload. Individual customisation
can be made to accommodate a higher load;
this will be indicated on the ratings plate.
Please ensure that the load limit indicated on
the ratings plate is not exceeded when transporting objects.
Operating instructions NJ1 e-assistant
5
It is recommended that you fit the wheelchair with an anti-roll back device and to activate this before driving on slopes. The anti-roll
back device can also be used if a wheelbase
extension is used on the wheelchair.
Figure 1: Anti-roll back device
8 Technical specifications
8.1 Drive system
The technical specifications, information and
instructions about the drive system can be
found in the operating instructions from the
drive's manufacturer which are included.
The range of the drive system varies depending on the terrain driven across and the prevailing driving conditions. With optimum driving
conditions (including maximum power transfer
of the user via the pedal crank, level ground,
fully charged batteries, ambient temperature of
20 °C, smooth driving, maximum tyre pressure,
no headwind), the range indicated in the drive
manufacturer's operating instructions can be
achieved.
A continuously adjustable speed of up to 6
km/h can be achieved using the pushing aid
without moving the crank. Motor support above
this speed is only done with manual rotation of
the pedal crank. Motor support is provided up
to a maximum speed of 24.9 km/h.
8.2 Climbing power
The climbing power refers to the ability of the
wheelchair-product combination to climb a
slope. This is very much dependent on the
weight distribution between the wheelchair
wheels and the product's drive wheel and on
the friction coefficient of the ground. Under
sub-optimal conditions, the drive wheel may
start to spin before the maximum climbing
power has been reached.
Maximum climbing power:
10° or 22%
The slope which can be driven up using the
product-wheelchair combination is also dependent on the manual driving force which the
driver can apply as well as the maximum
climbing power.
8.3 Product weight
The total weight depends on the drive system
and accessories and starts from 12.9 kg.
8.4 Load weight
Maximum load weight:
120 kg towing capacity and 10 kg payload
8.5 Obstacle height and turning circle
Maximum drive-over / negotiable obstacle
height: 10 cm (must be ensured through an
appropriate adapter assembly / setting, steering wheels must be removed ( recommended equipment of the wheelchair: steering
forks with quick-release axle))
Turning circle: approx. 2.3 m
8.6 Service life
The service life of the product is 6 years in
accordance with the medical products law.
Operating instructions NJ1 e-assistant
6
9 Commissioning
The product is handed over to you ready to
use by a PRO ACTIV dealer. They will fit, if not
already done, the required fastening elements
to your wheelchair to hold the adapter and, if
required, any other accessories. In addition,
the batteries and the display included in delivery will be installed and the parking stands will
be adjusted to the correct height.
Finally, you will be fully instructed in the use of
the product based on the operating instructions
included in delivery. If you wish (recommended
by PRO ACTIV), you will be presented with a
record of training and a hand-over certificate
as written evidence and in addition the operating instructions and any other accessories for
your own use. The form for the record of training and the hand-over certificate can be found
in chapters 30 and 31.
It is recommended that you take along an assistant to the training so that, if required, they
can assist you later when handling the product.
During the initial commissioning of the product,
drive at minimum speed and become accustomed to the driving characteristics of the
product. Always adapt the speed and driving
manoeuvres to match your own abilities, the
external circumstances and the legal regulations. You will get a feel for how to use the
product safely after a short time.
10 Hand-over
The hand-over must be done by your dealer or
a field representative from PRO ACTIV. During
the hand-over, the record of training (chapter
30) and the hand-over certificate including the
associated check list (chapter 31) must be
filled in. The dealer should send a copy of the
completed documents to PRO ACTIV for filing
either as a scanned file via e-mail, by fax or in
the post. These documents are available as
pdf files which can be completed in the
download area at www.proactiv-gmbh.com
.
11 Safety instructions - prior to
driving / use
The operating instructions of the connected wheelchair must be strictly observed
when using the product.
If your wheelchair is operated in combination with the product, any existing anti-tipping
supports must be put into their passive position
or removed (see the wheelchair's operating
instructions). If the wheelchair is then used
without the product, the anti-tipping supports
must be brought back into their operating position again to ensure tipping stability.
Before every trip, check the condition of
the wheels (e.g. visual inspection of the spokes
and rims, check the tyres for damage, foreign
bodies and crack formation). If you have any
doubts, the wheelchair-product combination
must not be operated any further.
Before starting your trip check that the
product's brake functions. If all existing brakes
are not fully functional, no trips may be taken.
Before every trip, check that the product is
firmly attached to the adapter and that the
adapter is firmly attached to the wheelchair.
The product may not be operated on the
wheelchair if any of the connections are not
tight and secure. In this case, contact your
dealer or PRO ACTIV.
Always ensure that your feet cannot slip
off the feet plate of the wheelchair when using
the product, if necessary by using a special
fixation device.
If present, check the function of the front
and rear lights as well as the effectiveness of
the side and rear reflectors before every trip.
Lights and reflectors must be clearly visible
during the journey and must not be covered by
other objects.
Operating instructions NJ1 e-assistant
7
Check tyre pressures at regular intervals.
Ensure that you comply with the manufacturer's specifications which are fitted to the
tyres. Tyre pressure which is too low has a
detrimental effect on the driving behaviour, the
range of the product and the braking action.
It is recommended that you only take a
trip with completely charged batteries. If this
recommendation is not followed, you must take
into account that the range will be restricted
when planning your route.
To minimise the risk of suffering serious
head injuries in the event of a fall, a helmet
should always be worn when driving with the
product.
12 Safety instructions - while driv-
ing / using
Always hold onto the crank handles with
both hands while driving. If the driving situation
requires you to take one hand off the crank
handles, this is only permitted when the speed
has been reduced to the minimum possible
beforehand.
Before driving up or down slopes or hills
with the product, you should be proficient in the
safe handling of the product on the flat.
Increase the speed slowly up to the desired speed.
Use particular caution when approaching
stairs, edges, drops or other hazard areas.
When driving round a bend, reduce your
speed to a minimum.
When the product is switched on, the
smallest movement on the crank handle is
converted into a drive command. When waiting
at potential hazard areas (e.g. while waiting at
a pedestrian crossing, on hills or slopes or at
ramps of any type), always hold down the service brakes and keep the crank handles in a
vertical position downwards.
In rooms, tight or dangerous areas or
when manoeuvring, the product may only be
used with the drive inactive and turned off to
prevent unintentional drive signals. Due to the
increased turning circle, it can be difficult to
turn in buildings, in front of or in lifts or other
buildings, as the standard in such buildings
assumes a maximum turning circle of 1.5 m.
During long trips the drive and the brakes
of the product may heat up. Therefore, do not
touch the drive or the brakes during or immediately after the trip (e.g. when detaching or
loading the product).
Do not attach objects (carrier bags, etc.)
to the product. These could cause an unwanted drive impulse when stationary and
prevent safe operation of the product while
driving.
When driving on areas which are used for
pedestrians, observe the maximum permitted
speed (walking speed 6 km/h) and keep a
sufficient distance (at least the width of a
wheelchair) from the kerbs or other obstacles
and other road users.
When driving on public roads and footpaths, the provisions of the road traffic regulations must be observed.
Avoid driving on unpaved or loose surfaces (e.g. on loose gravel, in sand, mud,
snow, ice or through deep puddles of water).
If you encounter new driving situations
which are unknown to you, approach them with
great care. If you consider that the risk is too
high, you must immediately abort the driving
manoeuvre and, if required, call for help to
assist you in extracting yourself from this situation.
You must not make telephone calls while
driving. You should also avoid driving near to
strong electrical interference fields.
Operating instructions NJ1 e-assistant
8
The driving characteristics of the product
can be influenced by electromagnetic fields
which can be produced by mobile phones or
other radiating devices. The power supply to
the product should be switched off when operating such devices.
Operating the product can affect other
devices, for example theft protection barriers in
department stores.
By performing regular checks, ensure that
the safety bolts of the adapter are always in
the correct position while driving (see operating
instructions "Adapter & Adaptation").
During a trip never jerk the handlebars to
the left or the right, as this may cause the
wheelchair-product combination to tip over
sideways in certain circumstances.
Never turn the product off on upwards or
downwards slopes. This could result in dangerous situations to which you can only react
with a delay in terms of electrical assistance or
virtually not at all by manual means.
Never drive parallel to slopes.
While driving, never grab onto the wheelchair wheels, in the area of the product wheel
or into other rotating parts; if you do you may
cause injuries.
Only brake the product using the service
brakes.
The product is only designed to be used
to transport persons with limited mobility and
must not be used for any other purpose, e.g.
by playing children or to transport goods.
You may only drive on slopes where the
wheelchair-product combination can be safely
controlled by steering and braking of the product.
If the weight load on the drive wheel falls
(e.g. when driving on slopes) or when driving
on loose / slippery surfaces, the braking action
of the wheel may be considerably reduced.
The driving style and speed should be adjusted
so that the product can be safely stopped at all
times using the brakes.
Towing or using a trailer is not permitted.
If the situation allows it, the speed should
be reduced by carefully applying the service
brake. Abrupt braking can cause the upper
body to fall forwards which can thereby result
in injuries or loss of vehicle control.
13 Safety instructions regarding
obstacles
Obstacles like curbs, for example, should
always be negotiated driving forwards and
always using the minimum speed required.
The maximum obstacle height which can
be negotiated is 10 cm. This value can, however, be reduced due to the specifications of
the type of wheelchair or its settings. Therefore, you should observe the values given in
the wheelchair's operating instructions or the
restrictions dependent on the settings.
When driving over or passing obstacles,
you must absolutely avoid any wheelchair or
body parts becoming trapped on the obstacle.
This could result in falls, serious injuries to the
user or third-parties as well as damage to the
product and the wheelchair.
Always drive over curbs or other obstacles
so that you cross them to the front or at right
angles. If you drive at them on an angle, or
only have one rear wheel on the obstacle,
there is an increased risk of tipping over to the
side which can result in serious injuries to the
user and third-parties as well as damage to the
product and the wheelchair.
Operating instructions NJ1 e-assistant
9
14 Safety instructions regarding
dangerous locations and dangerous situations
The operator of the product determines the
route to be driven taking the operating instructions, their driving knowledge and physical
abilities into consideration.
The personal driving skills are particularly important in the following dangerous locations
which are provided as examples; the product's
user must use their judgement before driving in
such locations:
quay walls, landing and berthing locations,
paths and locations close to water, unsecured bridges and dykes.
narrow paths, slopes (e.g. ramps and
driveways), narrow paths on a slope,
mountainous routes.
narrow and / or steeply sloping paths along
main roads or near cliffs.
routes which are covered in leaves, snow
or ice.
ramps and lifting equipment on vehicles.
When driving in a circle or turning on hills
or downward slopes, there may be an increased tendency to tip over to the side due to
the changes in the centre of gravity. Always
perform these driving manoeuvres with increased caution and only at slow speed. If
required, the driving manoeuvre must not be
performed or only with the help of an assistant.
When crossing main roads, intersections
and level crossings, extreme caution is
needed. Crossing rails in the road or at level
crossings must never be undertaken while
driving parallel, otherwise the wheels could
become caught which would result in the
wheelchair and the product being unable to
manoeuvre.
When driving on ramps and lifting equipment on vehicles, extreme caution is needed.
During the lifting or lowering operation of the
ramp or the lifting equipment, the product
should be switched off and the service brake
operated. In this way rolling away due to unintentional drive commands, for example, can be
prevented.
The grip of the tyres on the ground is reduced in the wet. There is an increased risk of
slipping. Adjust your driving, braking and steering behaviour accordingly.
15 Ending the driving operation
Turn off the drive unit. To make getting out of
the wheelchair more simple, the product can
be disconnected from the wheelchair (see
operating instructions "Adapter & Adaptation").
The product may only be disconnected with the
drive turned off to prevent any unintended
drive signals.
16 Safety instructions - after driv-
ing / use
Always turn off the product immediately
when it is not in use to prevent accidental triggering of a drive signal by touching the crank
handle and to prevent the batteries being discharged.
Always observe the instructions and recommendations in the drive manufacturer's
operating instructions concerning charging the
batteries.
17 Adapter & adaptation
Where necessary and ordered, a suitable
adapter for your wheelchair is included with the
delivery.
Please read the operating instructions and
assembly instructions for the "Adapter & Adaptation" before using the product.
The drive's controller must only be
switched on after completing the adaptation
process. The adaptation and disconnection of
the product may only be performed when the
driving signal sensor is inactive to prevent
unintended drive signals.
Operating instructions NJ1 e-assistant
10
The product may only be adapted and
detached on dry, stable and flat surfaces.
18 Functional elements
18.1 Parking stand
18.1.1 Active and passive positions
By pressing down and turning the operating
lever, the parking stand positions can be
changed from the active to the passive position, or vice versa.
Figure 2: Press down and turn the operating lever
Figure 3: Parking stand in the active position
Figure 4: Parking stand in the passive position
18.1.2 Parking stand height adjustment
It is important to adjust the height of the parking stand to bring the adapter into the right
position in relation to the product's docking
plate. Height adjustment is made by loosening
the M6 oval head screw (SW 4 mm) and adjusting the position of the adjustment inlet.
Finally, tighten the oval head screw up to 7 Nm
of torque.
Figure 5: M6 oval head screw and adjustment inlet
to adjust the height of the parking stand
M6 oval
head screw
Adjustment
inlet
Operating instructions NJ1 e-assistant
11
18.2 Pedal bearing support & crank
18.2.1 Seating position
The seating position and therefore the pedal
position and the pedal crank length depend on
the upper-body stability or the core musculature. A suitable adjustment to the arm length
will have been made during the consultation /
measurement procedure.
With weak core musculature, the seating
position should normally be chosen so that the
upper body remains still in an upright position
when operating the crank while driving. This is
particularly important if you have low seating
stability due to missing or weak core musculature. A rocking motion (forwards and backwards) of the upper body or the head should
be avoided where possible. The height of the
pedal bearing in this case is selected to be
slightly higher (chest height or higher).
Sporty drivers with the appropriate trunk
stability relieve their arm musculature by mov-
ing their trunk at the same time. The height of
the pedal bearing in this case can be selected
to be slightly lower (chest height or lower).
Figure 6: Elbows are not completely straight, upper
body is in an upright position
Figure 7: Distance between the crank and the thigh /
knee
The cranks must not touch the knee or
thigh when they are being turned.
The elbows must not be completely extended when the crank handles point completely forward away from the body.
A suitable restraint system must be used if
you have poor seating stability due to a lack of
or weak core musculature. The selection of the
suitable system must be made in conjunction
with your doctor or therapist and / or defined
and implemented by your dealer. There are
various systems available such as chest straps
or four-point safety belts. Also, the dealer can
frequently individually make a system or adapt
one that has been purchased.
18.2.2 Pedal bearing position
In a product equipped with a non-adjustable
pedal bearing support, a subsequent adjust-
ment of the pedal bearing position can only be
achieved by exchanging the pedal bearing
support, the angle adjustment possible on the
steering head as well as the length adjustment
and the spacing of the adapter tube on the
adaptation points on the wheelchair frame (see
operating instructions "Adapter & Adaptation").
The pedal bearing support can be exchanged
by loosening the four M6 fastening screws (SW
5 mm) on the tip fork bridge and the four M6
fastening screws (SW 4 mm) on the pedal
bearing housing. Then the new pedal bearing
support with another length can be inserted
and the 8 fastening screws tightened up to 7
Nm and secured with thread lock fluid. Finally,
Distance crank
to knee
Operating instructions NJ1 e-assistant
12
check the chain length and the cable lengths
and adjust them if necessary.
Figure 8: Fastening screws on the top fork bridge
Figure 9: Fastening screws on the pedal bearing
housing
If your product is fitted with an adjustable
pedal bearing support (optional), the pedal
bearing position can be adjusted in angle and
height:
The angle adjustment is done at the top
fork bridge. To do this, loosen the four M6
fastening screws (SW 5 mm), on the clamp
slightly so that the pedal bearing support's
angle can be adjusted using minimal force.
The angle adjustment is continuous (as a
guide, there is a 12° scale fitted). When
you have finished adjusting the angle,
tighten up the four fastening screws to 7
Nm torque and secure them with thread
lock fluid.
To adjust the height, two M6 clamp screws
(SW 5 mm) must be loosened on the pedal
bearing housing. Then the pedal bearing
housing can be moved along the pedal
bearing support to the correct position. Af-
ter this, tighten up the clamp screws to 7
Nm torque and secure them with thread
lock fluid.
Finally, check the chain length and the cable
lengths and adjust them if necessary.
Figure 10: Fastening screws for angle and height
adjustment of the pedal bearing position
If you want to make a change to the pedal
bearing position, please contact your dealer or
PRO ACTIV.
Please note that, after a large adjustment
to the pedal bearing position, the chain length
and the cable lengths must be adjusted.
18.2.3 Crank length and grip width
The crank length can be chosen from different
lengths individually to suit the length of the
arms and mobility of the user. Different widths
of pedal bearing shafts and spacers between
the crank handles and the rotary axles of the
hand grips are available to adjust the grip
width.
If you want to make a change to the crank
length or grip width, please contact your dealer
or PRO ACTIV.
M6 fastening
screws on the
pedal bearing housing
Fastening screws
on the clamp
(angle adjustment)
Clamp screws on
the pedal bearing
housing (height
adjustment)
M6 fastening
screws on the
top fork bridge
Operating instructions NJ1 e-assistant
13
Figure 11: Crank length and grip width
18.3 Grips
The grips must be held firmly with both hands
whilst driving and always held so that the cables and brake lines are oriented upwards.
Figure 12: Correct grip hold
Make sure that cables and brake lines are not
kinked or caught up somewhere. This could
cause them to be damaged which could lead to
the brakes and gear shift not working correctly.
18.4 Gear shift
18.4.1 Chain shift
For the chain shift, shifting procedures can
only occur while the crank is moving. Changing
the gear with the cranks stationary is not possible. In general, the torque applied to the
cranks should be reduced briefly while changing the gear so that the gear change can happen more quickly.
The controls for the gear change are normally
designed so that they can be operated using
thumb / index finger switching fittings or
with a chin control (based on the thumb / index
finger switching fittings). With the 9-speed
cassette at the bottom, switching to the next
largest sprocket means a lower or easier gear,
and to the next smallest sprocket to a larger or
more difficult gear. For the 3-speed chain
wheels at the top, the behaviour is exactly the
opposite.
Figure 13: 9-speed cassette and 3-speed chain
wheels
With the thumb / index finger switching fittings,
gear changes are achieved by:
"Thumb switch" – operation by pressing in
the direction of travel with the thumb
"Index finger switch" – operation normally
by pulling in the opposite direction to travel
with the index finger (alternatively can also
be operated with the thumb by pressing
against the direction of travel).
Figure 14: Operation using the thumb / index finger
switching fittings
Grip width
Crank
length
3-speed chain wheels
9-speed
cassette
Pedal bearing
Hand grip
rotary axle
Crank
handles
Thumb
operation
Index finger
operation
Operating instructions NJ1 e-assistant
14
Figure 15: Switching using the thumb / index finger
switching fittings
Operation of the chain shift is also possible
using a twist grip (optional). Here, you can
change between the 3 chain wheels by turning
the left-hand twist grip. On the right-hand grip,
you can change between the sprockets in the
9-speed cassette. You can read the respective
gears on the twist grip.
Figure 16: Switching using the twist grip
When driving up a hill, it should be noted
that it is only possible to change using the 9speed cassette under heavy loads on the
chain. Changing using the top three chain
wheels is no longer possible if there is heavy
tension on the chain.
Try to avoid selecting cross gears, as the
efficiency and service life of the chain will fall
significantly (more information can be found in
chapter 28).
For more information, please see the instructions provided by the gear manufacturer.
18.4.2 Hub gears
The hub gears integrated into the drive can be
changed while driving and also when stationary. No crank movement is needed to change
and only a small reduction in torque is needed.
Normally, the hub gears are operated by turn-
ing the twist grip. The gear selected is shown
in the display on the control panel.
Figure 17: Switching using the twist grip
It is also possible to operate the hub gears
using the operating machine which allows
gear changes to be made using the chin (optional). To change up, the gear lever is turned
through 45° anti-clockwise (upwards). To
change down, the gear lever is turned through
45° clockwise (downwards). After completing
the gear change, the gear lever moves back to
its starting position.
Figure 18: Changing gear using the PRO ACTIV
operating machine
right: operation
9-speed cassette
Thumb:
lower gear
Index finger:
higher gear
left
: operation 3-
speed chain wheels
Thumb:
higher gear
Index finger:
lower gear
Gear display
Gear changes
by twisting
grip to the left
and right
Change
down
Change up
Gear
lever
Gear display
Gear changes
by twisting the
grip to the left
and right
Operating instructions NJ1 e-assistant
15
Please refer to the gear or drive manufacturers' instructions for more information about the
hub gears.
18.4.3 Pedal bearing gearshift
The pedal bearing gearshift is switched on by
pressing the control buttons on the left and
right of the pedal bearing. Here, you can
choose between a 1:1 gear ratio (the left control button in the direction of travel) or a 2.5:1
gear ratio (the right control button in the direction of travel).
Figure 19: Control button on the pedal bearing
gearshift
The pedal bearing gearshift should be lubricated once or twice a year with the supplied
original semi-fluid grease using the syringe.
The semi-fluid grease is filled through the slotted screw.
Figure 20: Slotted screw to lubricate
Figure 21: Original semi-fluid grease in the syringe
For more information, please see the instructions provided by the manufacturer.
18.5 Disc and rim brakes
Normally there is one disc and one rim brake
fitted to the product. Where possible, both
brakes should be operated simultaneously and
the braking requirement reduced by driving in a
way that anticipates the requirement to reduce
speed if necessary.
The brakes are operated using the brake lever.
Figure 22: Brake lever
In the event of abrupt hard braking, there
is a risk that you might fall forward with your
upper body and thereby cause injuries to yourself.
Please make sure that the braking surfaces on the rim and the brake pads on the rim
breaks do not come into contact with oils or
greases which could otherwise impair the braking effect. If rims or brake pads do come into
contact with oils or greases, the brake pads
must be replaced and the brake disc and rim
must be professionally cleaned with brake
cleaner (e.g. Weicon surface cleaner).
Control button
Slotted screw
Press
Left-hand: 1:1
gear ratio
Brake lever
Operating instructions NJ1 e-assistant
16
You can find further information in the brake
manufacturer's instructions.
18.6 Back-pedal brake & crank release
function
18.6.1 Operation
This back-pedal brake is a closed hydraulic
system consisting of a generator unit and a
disc brake calliper. The system has automatic
wear compensation for the brake pads.
To adapt the system to your body weight and
the physical limitations of the driver, the
springs of the system are available in three
strengths. These can also be replaced retrospectively.
The back-pedal brake is delivered with a crank
release function which allows reverse driving
and manoeuvring via the hand rims. For functional reasons, the back-pedal brake always
acts as soon as the product moves backwards.
Therefore, the driver must first unlock the reverse movement by operating the crank release function.
The braking function via the backward movement (crank movement against the direction of
acceleration) is always guaranteed – with the
crank release function activated or deactivated.
Figure 23: Generator unit PRO ACTIV back-pedal
brake
18.6.2 Operation
The brake is operated by moving the cranks
against the acceleration direction (clockwise).
The brake force applied is adjusted by the
strength of the backwards movement of the
cranks.
The crank release function is operated by
pressing the side pressure plate. To activate
the crank release function, the left-hand pressure plate must be operated (seen from the
direction of travel). To return to normal driving
operation with the back-pedal brake, the righthand pressure plate must be operated.
Figure 24: Left- and right-hand pressure plates
18.6.3 Safety instructions
Before every trip, perform a brake test
while stationary by moving the cranks with the
normal operating force rearwards. The drive
wheel must not be able to move when the system is operated.
At regular intervals, check that all of the
connections, lines, bleed screws and the surface of the transmitter unit do not leak and that
all the screw connections on the brake system
are tightened securely.
At regular intervals, check that the brake
pads and discs are free from grease, oil or
other contamination. In addition, check the
thickness of the brake disc. The minimum
thickness is printed on the brake disc. In addition, the brake pad thickness must be checked
with a measuring calliper. The minimum pad
thickness plus support material is 2.5 mm.
Measure the pad thickness at the thinnest
point.
Do not drive if your product is faulty in one of
the previously listed points. Contact your
dealer immediately who will arrange maintenance by PRO ACTIV.
Deactivating the
crank
release function
Activating the
crank
release function
Operating instructions NJ1 e-assistant
17
18.7 Parking brake
Using the aluminium bracket which is attached
to the left-hand side of the pedal bearing support, one of the two brakes can be used as a
parking brake. For this purpose, the aluminium
bracket is clamped over the grip and the brake
lever while the brake lever is depressed.
Figure 25: Aluminium bracket as a parking brake
18.8 Battery pack
Please refer to the accompanying documentation from the drive manufacturer concerning
the handling as well as the insertion and removal of the battery.
Improper handling of the battery can
cause electrolyte fluid to leak. This can cause
skin injuries or damage to clothing. If skin or
eyes come into contact with the electrolyte
fluid, they must be rinsed with pure water and
a doctor consulted immediately.
The batteries may not be exposed to fire
or burned. This could cause them to explode.
The contacts of the batteries must not be
short-circuited. A short-circuit causes very high
currents which could damage the batteries
and / or the product.
The product's batteries may only be
charged using the original charger from the
manufacturer which was supplied. They can be
charged in any position.
After the end of the journey, the batteries
should be fully charged.
18.9 Components & drive system
You will be instructed about the functions and
operation of the drive support, gears, brakes
and other brand components during the handover / training. You can also get information
later from the component manufacturers' operating instructions enclosed, or if needed, by
asking your dealer or PRO ACTIV. The operating instructions from the component manufacturers can also be downloaded online.
The most important documents are grouped
together in the download area at www.proactiv-
gmbh.com. More extensive information can be
found on the manufacturers' websites:
Shimano components:
http://si.shimano.com
Magura components:
http://www.magura.com/en/bicyclecomp/produ
cts/downloads.html
Mountain Drive pedal bearing gear shift:
http://www.haberstockmobility.com/en/products/schlumpfdrive/schlumpf-mountain-drive.html
BionX drive system:
http://www.bionxinternational.com/naen/service/downloads/
neodrives drive system:
http://www.neodrives.com/en/service/download
s.html
Sigma:
http://www.sigmasport.de
Subject to changes to the links provided by the
component manufacturers.
19 Storage
Store the product on an easy to clean surface
in a dry environment, preferably at room temperature (+15 °C to +25 °C).
For storage, please also observe the instructions in the other sections of these operating
instructions and in the component and drive
manufacturers' instructions included with the
delivery, in particular the points about the batteries and the electrical drive.
Aluminium bracket as a parking brake
Operating instructions NJ1 e-assistant
18
If the product should be stored or not used
for a long time, the device should be turned on
briefly once a month and driven a few metres
forwards and backwards to prevent the brakes
seizing up. If necessary, before returning to
service, a general function and safety check by
the dealer is recommended.
When the batteries are stored or taken out
of use, these may only be stored with a charge
status of between 70% and 100%, they must
be fully charged at least every two months.
Before re-use, the batteries must be completely charged.
20 Transport
When transporting in vehicles it must be
noted that the product is not approved for use
as a seat in vehicles or disabled person's vehicles when combined with a manual wheelchair.
All vehicle occupants must only sit on the seats
installed in the vehicle during the journey with
the associated restraint systems. Failing to
observe this leads to increased risk of injury for
the user as well as for third-parties.
To reduce the weight when loading, the
batteries can be removed from the product and
stored separately. The product and all associated components must be secured during
transport so that they are not damaged (e.g. by
falling over) and do not become a hazard to
persons or other products.
When loading make sure that the cables
and brake lines are not caught up, become
kinked or otherwise damaged. The product
may not be used with damaged cables and / or
brake lines.
The lithium batteries used are classified as
hazardous goods for transport by air. It is not
permitted to claim that there is a right to transport them by air. The decision about the transport is the sole responsibility of the airline and
this should be discussed in advance of the
flight or the booking.
21 Malfunctions
In the event of any malfunctions which cannot
be solved by yourself based on the operating
instructions included on delivery, please contact your dealer or PRO ACTIV.
Malfunctions must be solved before any
further use or, if they occur during the journey,
this must be interrupted immediately.
22 Cleaning and care
Regular cleaning of the product is prescribed
to prevent the components becoming clogged
up due to dirt. In particular, the product should
be carefully cleaned after every major use, e.g.
summer or winter holidays.
For all cleaning processes, only use commercially available, household cleaning agents. Do
not use any abrasive cleaning agents or aggressive, acidic cleaners, to prevent scratching
or fading of the coating or the anodised parts.
Drive and grip units, as well as the batteries,
may only be cleaned by rubbing off with a
damp (not wet) cloth. Always work with just a
little water and keep water away from the electrical contacts.
The drive wheel should be regularly cleared of
contamination. It is recommended that you use
a soft sponge or a soft brush.
After cleaning, check to make sure that the
plug connectors are not damp and, if required,
allow them to dry before re-starting the product.
In addition, the plug connectors should be
lubricated with petroleum jelly after cleaning to
protect them against corrosion and moisture.
The product must not be cleaned using
steam or high pressure.
If you need care products for your product,
please contact PRO ACTIV.
Operating instructions NJ1 e-assistant
19
23 Maintenance
23.1 General instructions
The product is not a maintenance-free device.
Therefore, please observe the following instructions about maintenance.
For tyres with tread: As soon as there is
one or more points with less than 1 mm of
tread on the product or the adapted wheelchair, the tyres must be changed since otherwise there is an increased risk of an accident.
For tyres without thread: As soon as there
is one or more points where the tyre carcass or
the accident protection is visible on the product
or the adapted wheelchair, the tyres must be
changed since otherwise there is an increased
risk of an accident.
When maintaining the brakes and the
gear components, it is imperative that the operating instructions of the manufacturer which
were included in delivery are followed.
Only manufacturer's original parts may be
used when ordering spare parts.
Service and repairs to the product may
only be carried out by your dealer or PRO ACTIV.
Tightening torques and securing details for
fastening elements as shown in the table in
chapter 29 must be observed.
23.2 Service schedules
There is some maintenance work or checks
which should be carried out by the user
themselves at regular intervals (approximately
every 4 weeks depending on the frequency of
use):
The chain for the chain shift should be
cleaned and lubricated with chain oil (ob-
serve the manufacturer's instructions).
Check the tyres for damage, foreign bodies
and any cracks that form.
Check the cable housings are seated cor-
rectly and tightly in the gear cable holders.
Gear and brake cables or brake lines
should be checked for any kinks or crushing.
Check the brake pads.
Check the plug contacts of the drive sys-
tem; if required clean with a soft, dry brush
and re-grease (using petroleum jelly).
Check the tyre pressure and correct if
needed (the tyre pressure should always
be as printed on the tyre covers).
If you should discover any problems during these checks, please immediately contact
your dealer or PRO ACTIV. Service and repair
work on the product may only be carried out by
your dealer or PRO ACTIV.
In addition to these maintenance tasks /
checks by the user, PRO ACTIV has prescribed maintenance tasks to be carried out
by the dealer or PRO ACTIV for safe operation of the product and to minimise the risk to
the user or third-parties.
The initial inspection is performed after running
200 kilometres or 5 months after delivery
(whichever comes first). The maintenance
schedule can be found in the inspection lists in
chapter 32.
Subsequent inspections are then always performed after 1,000 kilometres running or after a
period of 1 year (whichever comes first). The
maintenance schedule can be found in the
inspection lists in chapter 32.
After extreme loads, e.g. during holidays where
the product was used on sand, near sea water
or in snow, it is recommended that an additional deep clean and inspection is performed
by your dealer or PRO ACTIV.
To maintain the operating licence and the warranty validity, the performance of the maintenance tasks must be documented. Any faults
identified during maintenance work must be
rectified and documented as such before further use of the product.
Operating instructions NJ1 e-assistant
20
Even if your product does not show any signs
of wear, damage or malfunctions, the regular
safety-related checks on your product must be
carried out in accordance with the maintenance schedule.
23.3 Proof of maintenance
To provide proof of the maintenance, you can
use the inspection lists in chapter 32. The inspection lists are also available as pdf files
which can be filled in within the download area
of www.proactiv-gmbh.com
. In any event, keep
all documents / service reports as a means of
proof, and get any service work which was not
carried out by PRO ACTIV documented.
Please bring these operating instructions /
service booklet to every service.
24 Disposal
At the end of the service life, the product can
be disposed of by PRO ACTIV or your dealer
in a proper, environmentally-friendly manner.
25 Re-use
If your product has been provided to you by
your funding provider and you no longer require it, you should report this fact to your
health insurance company or your dealer. Your
product can then be simply and economically
re-used.
Before any re-use, a safety check must be
carried out on the product by PRO ACTIV. The
system must be checked for corrosion. In addition to the instructions contained in chapter 22
(Cleaning and care), a thorough cleaning of the
grips, all controls and the battery housing must
be carried out. This will also be done by PRO
ACTIV as part of the safety check. This must
be initiated by the funding provider.
26 Warranty
PRO ACTIV guarantees that the product was
free of any defects at the time it was handed
over. This warranty expires 24 months after the
product was delivered. Further information can
be found in PRO ACTIV's general terms and
conditions at www.proactiv-gmbh.com
.
With regard to the warranty and guarantee for
the drive system, please refer to the operating
instructions of the drive manufacturer.
Any modifications to the product which
have not been expressly approved by PRO
ACTIV will invalidate the warranty. Such modifications may cause unforeseeable safety risks
and are therefore not permitted.
27 Liability
As the manufacturer of the product, PRO ACTIV is not responsible for its safety if:
the product is handled improperly
the product is not maintained in accor-
dance with the maintenance schedule laid
down by PRO ACTIV
the product is commissioned and used
contrary to the instructions in these operat-
ing instructions
the product is operated without sufficient
battery charge
repairs or other work are carried out by
non-authorised persons
third-party parts are installed or connected
to the product
changes are made to the software
Further information can be found in PRO ACTIV's general terms and conditions at
www.proactiv-gmbh.com
Operating instructions NJ1 e-assistant
21
28 Appendix: Avoiding crossed gears with the chain shift
from the middle
chain wheel, you
can switch to all 9
sprockets
from the large
chain wheel, you
can switch to the
small sprockets
(1-7)
from the large
chain wheel, you
should
not switch
to the large
sprockets (8+9)
=
crossed gear
from the small
chain wheel, you
can switch to the
larger sprockets
(9-3)
from the small
chain wheel, you
should
not switch
to the smallest
sprockets (1+2)
=
crossed gear
Operating instructions NJ1 e-assistant
22
29 Appendix: Tightening torques and securing details
The following table shows the torques for shaft screws with a metric control thread (valid if the drawing
or assembly instructions do not state different values!):
Dimension
Torque MA in Nm depending on how tight the screws are
Stability 8.8 Stability 10.9
M4 2.1 3.1
M5 4.2 6.1
M6 7.3 11
M8 17 26
M10 34 51
M12 59 87
M10 x 1 36 53
M12 x 1.25 64 93
M27 x 1.5 70 ...
Securing details: All screws on PRO ACTIV products should be secured with thread lock fluid "medium
strength" (e.g. Weicon AN302-42), where there are no securing clamps on the screw connections
present or there is a lubrication requirement with grease or copper paste.
Operating instructions NJ1 e-assistant
23
30 Appendix: Medical product passport / record of training
Product specifications:
Serial number:
Key number:
Customer data:
Surname, forename:
Street:
Postcode, city:
Phone:
Paying organisation:
Training carried out by:
Medical supplies dealer
PRO ACTIV field
representative
Record of training
I was / we were instructed in accordance with the associated hand-over certificate about the operation
of the product listed and informed about possible operator errors. I was / we were also advised about
situations where the assistance of another person is required. The operating instructions were handed
to me / us.
Person being trained
Name, date, signature
1. Person being trained
Name, date, signature
2. Person being trained
Name, date, signature
3. Person being trained
Name, date, signature
For minors, or persons who are not responsible for their actions, legal guardians / supervisors / responsible persons are to be
trained in the use, this is confirmed by their signature. The data is recorded in the feedback system of PRO ACTIV RehaTechnik GmbH, as the manufacturer of the above named product. It will be managed in accordance with Section 16 BDSG
(Federal Data Protection Law).
Stamp / Date / Dealer's signature
Operating instructions NJ1 e-assistant
24
31 Appendix: Hand-over certificate
31.1 Required compliance criteria to authorise use
Topics
completed /
fulfilled
Remarks
The product is suitable for the customer based on
their own judgement and the customer information received regarding the disability-related restrictions.
The use intended by the customer is fully consistent with the intended use as described in the
operating instructions (see the Product description / intended use chapter).
The product's equipment is suitable to allow the
customer safe use with maximum reduction of
risks. (see check list on the following page)
The customer was informed about the current /
applicable regulations in accordance with the
StVO.
The customer's driving ability was checked during
a test drive with difficult driving situations and
found to be appropriate (see the check list on the
following page).
The user, according to their own statements, or
those of the legal representative or guardian and
the assessment of the person providing the training, is able to meet the requirements of public
traffic in full and to act accordingly. This ability to
act, which is the basis for reducing the risk for the
user and other road users to an acceptable level,
is also completely achievable taking current illnesses / disabilities into full account.
The operating instructions, and explicitly all of the
warning and safety instructions contained therein,
were discussed during the training in detail and
understood by the user. The user was then
handed these operating instructions.
Operating instructions NJ1 e-assistant
25
31.2 Check list for training the user
Topics
completed/
fulfilled
Advised of the applicable legal regulations when driving on public roads.
All mechanical and electrical functional controls were explained and their function demonstrated.
Adaptation of the adapter to the wheelchair and removing the adapter from the wheelchair was
demonstrated and then performed by the user themselves and / or their assistant.
Adaptation and uncoupling the product to / from the wheelchair was demonstrated and then per-
formed by the user themselves and / or their assistant.
Adaptation of the wheelbase extension on the wheelchair was demonstrated and then performed
by the user themselves and / or their assistant.
Repositioning the wheelchair drive wheels from the standard position in the wheelbase extension
sockets – if fitted – was demonstrated and then performed by the user themselves and / or their
assistant.
How the parking stand works was demonstrated and then performed by the user themselves and /
or their assistant.
Operation and basic settings on the display / operating console were demonstrated and t hen performed by the user themselves and / or their assistant.
The drive assistance / pushing aid was demonstrated and then performed by the user themselves
and / or their assistant.
Operation of the drive system and the reaction of the drive system to the various settings was
demonstrated and then performed by the user themselves and / or their assistant.
Removal and insertion of the operating console and the batteries was demonstrated a nd then
performed by the user themselves and / or their assistant.
Handling and charging the batteries as well as the charger functions were demonstrated and then
performed by the user themselves and / or their assistant. The instructions about charging the
batteries during a prolonged period of non-use / storage of the product are important here.
Operating the parking brake was demonstrated and then performed by the user themselves and /
or their assistant.
Use of the service brakes was demonstrated and then performed by the user themselves and / or
their assistant.
How the gears work was demonstrated and then performed by the user themselves and / or their
assistant.
How the lights work – if fitted – was demonstrated and then performed by the user themselves
and / or their assistant.
Test drive: Forwards and, if required, backwards travel through 4 cones spaced at 1.5 m or 2 m
Test drive: Driving on the level, uphill and downhill in the direction of travel
Test drive: Emergency stop from maximum speed
Instructions about care, cleaning and maintenance of the product were given.
The contents of the operating instructions from PRO ACTIV, the drive manufacturer and the other
component manufacturers were completely worked through and understood by the customer
based on the product training.
The use of the product is only permitted when all topics listed in "Required compliance criteria for
those permitted to use" have been met by the user and all the points have been ticked off in the
"Check list for training the user".
Operating instructions NJ1 e-assistant
26
32 Appendix: Inspection lists
Initial inspection: After 200 km or 5 months
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights, steering, adaptation
to the product and the adapted wheelchair / wheelchairs
Check the electrical connections
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
27
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
28
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
29
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
30
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
31
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
32
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
33
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
34
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
35
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
36
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
37
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
38
Subsequent inspection: After a further 1000 km or 1 year after the last inspection or after
heavy use
Kilometre reading:___________________
OK /
carried out
not OK resolved
Check all screws / fastening elements are firmly seated
Functional / safety check of all lights (if fitted), adaptation to
the product and the adapted wheelchair / wheelchairs
Oil / grease all pivot points and bearings
Visual inspection of the frame and attachments for crack
formation, deformation, etc.
Replace the brake fluid, brake pads, brake cables and tyres
on the product and the wheelchair
Geometrical check of the wheelchair and product frame
Check the capacity of the battery
Check the electrical connections
Check the control parameters
Grease the pedal bearing gears (if fitted)
Check and oil the gear components
Check the spoke tension of the drive wheel and, if required,
correct the tension / re-centring
OK / carried out = OK | not OK = not OK | resolved = the fault was corrected
Comments:
Stamp:
Date / Signature
Operating instructions NJ1 e-assistant
39
Your dealer:
PRO ACTIV Reha-Technik GmbH
Im Hofstätt 11
72359 Dotternhausen - Germany
Tel. +49 7427 9480-0
Fax +49 7427 9480-7025
E-Mail: info@proactiv-gmbh.de
www.proactiv-gmbh.com
No. 000 000 1401
© 11/2013 PRO ACTIV Reha-Technik GmbH. All rights reserved.
in accordance with Directive 93/42/EEC for medical products
Loading...
