Pringle D10024 User Manual

D10024 Analog Fire Alarm Control Panel

Operator’s Guide

D10024

Alarm

Manual

Trouble

Silence

Alarm ENTER

9 10 11 12

29 30 31 32

49 50 51 52

69 7071727374 75 76

13 14 153616

33 34 35

53 54 55 56

Letters

Numbers

17 18

38 39

58 59 60

78 79 80

YES

Keyword

194020

POWER SYSTEM TROUBLE TROUBLE SILENCED ALARM SILENCED POINT BYPASSED ALARM

System

Reset

Trouble

Silenced Silence

System

Reset

Enable Keypad

Alarm

Manual

Alarm

Disable Keypad

ALARM TROUBLE

2 3

21122 23 24

41 42 43 44

61 62 63 64 65 66 67 68

6 7 8

25526 27 28

45 46 47 48

D10024

This page is intentionally blank.

D10024 Operator’s Guide

D10024

Contents

1.0 Notices ................................................................................................................................................................................. 5

1.1 General Notices .................................................................................................................................................................... 5

1.2 FCC Notice ............................................................................................................................................................................ 5

1.2.1 Part 15 ................................................................................................................................................................................... 5

1.3 UL/NFPA Notice .................................................................................................................................................................... 5

2.0 Overview .............................................................................................................................................................................. 7

2.1 System Overview .................................................................................................................................................................. 7

2.2 Control Level Distinction ...................................................................................................................................................... 8

2.3 Passcodes............................................................................................................................................................................. 8

2.4 Controls and Displays .......................................................................................................................................................... 8

3.0 Control Level 1 (Display Functions) .............................................................................................................................. 11

3.1 Power Conditions ................................................................................................................................................................ 11

3.2 Trouble Conditions .............................................................................................................................................................. 11

3.3 Alarm Conditions ................................................................................................................................................................ 11

4.0 Control Level 2 (Controller Functions) .........................................................................................................................13

4.1 Power Conditions ................................................................................................................................................................13

4.1.1 Power Failure Signal .......................................................................................................................................................... 13

4.1.2 Power Failure Signal Response ........................................................................................................................................13

4.2 Trouble Conditions ..............................................................................................................................................................14

4.2.1 Trouble Signals ................................................................................................................................................................... 14

4.2.2 Trouble Signal Response ................................................................................................................................................... 14

4.3 Alarm Conditions ................................................................................................................................................................ 14

4.3.1 Alarm Signals ......................................................................................................................................................................14

4.3.2 Alarm Signal Response ...................................................................................................................................................... 14

4.4 System Operation (Main Menu Options) ...........................................................................................................................15

4.4.1 System Tests ....................................................................................................................................................................... 15

4.4.1.1 LEDs Test ............................................................................................................................................................................ 15

4.4.1.2 LCD Test.............................................................................................................................................................................. 15

4.4.1.3 Zones Test ........................................................................................................................................................................... 15

4.4.2 Time Setting ........................................................................................................................................................................ 17

4.4.3 Enable/Disable Functions .................................................................................................................................................. 17

4.4.3.1 Enable/Disable by Zone .....................................................................................................................................................17

4.4.3.2 Enable/Disable Individual Detection Devices (Inputs) .....................................................................................................17

4.4.3.3 Enable/Disable Panel Keys ................................................................................................................................................ 17

4.4.3.4 Enable/Disable Delayed Day Mode ................................................................................................................................... 18

4.4.3.5 Enable/Disable Relays ....................................................................................................................................................... 18

4.4.4 Print Functions .................................................................................................................................................................... 19

4.4.4.1 Print Devices .......................................................................................................................................................................19

4.4.4.2 Print Events (Event Log) .................................................................................................................................................... 19

4.4.4.3 Print Mode ...........................................................................................................................................................................19

4.4.4.4 Print Direction .....................................................................................................................................................................19

4.4.4.5 Print Disabled ...................................................................................................................................................................... 19

4.4.5 View Functions ....................................................................................................................................................................19

4.4.5.1 View Devices .......................................................................................................................................................................19

4.4.5.2 View Event Log ................................................................................................................................................................... 19

4.4.5.3 View Faults .......................................................................................................................................................................... 19

4.4.5.4 View Outputs ....................................................................................................................................................................... 20

4.4.5.5 View Disablements ............................................................................................................................................................. 20

4.4.5.6 View System Events ...........................................................................................................................................................20

5.0 Control Level 3 (Programmer Functions) ..................................................................................................................... 21

5.1 Enable/Disable Sounders (NAC Devices) ........................................................................................................................ 21

Index ..................................................................................................................................................................................................23

D10024 Operator’s Guide

D10024 Figures and Tables

Figures

Figure 1: D10024 Fire Alarm Control Panel ....................................................................................................................................... 7

Figure 2: D10024 Controls and Displays ...........................................................................................................................................9

Figure 3: Control Level 2, Entry Menu 1 .......................................................................................................................................... 13

Figure 4: Control Level 2, Entry Menu 2 .......................................................................................................................................... 13

Figure 5: Main Menu.......................................................................................................................................................................... 13

Figure 6: Enable Menu ...................................................................................................................................................................... 13

Figure 7: Main Menu.......................................................................................................................................................................... 15

Figure 8: Test Menu ...........................................................................................................................................................................15

Figure 9: Zone Test Menu 1 .............................................................................................................................................................. 15

Figure 10: Zone Test Menu 2 ............................................................................................................................................................16

Figure 11: Zone Test Menu 3 ............................................................................................................................................................ 16

Figure 12: Zone Test Menu 4 ............................................................................................................................................................16

Figure 13: Main Menu........................................................................................................................................................................ 16

Figure 14: Enable/Disable Menus .................................................................................................................................................... 17

Figure 15: Outputs Menu .................................................................................................................................................................. 18

Figure 16: Main Menu........................................................................................................................................................................ 18

Figure 17: Print Menu ........................................................................................................................................................................19

Figure 18: View Menu ........................................................................................................................................................................ 19

Figure 19: Outputs Submenu............................................................................................................................................................ 21

Tables

Table 1: Control Key Functions........................................................................................................................................................... 8

Table 2: Alphanumeric and Program/Interactive Key Functions ...................................................................................................... 9

Table 3: System Event and Status LEDs ......................................................................................................................................... 10

D10024 Operator’s Guide

1.0 Notices

1.1 General Notices

These instructions contain procedures to follow in order to avoid personal injury and/or damage to the equipment.

NFPA 72 requires a complete system-wide functional test be performed following any modifications, repair, upgrades or adjustments made to the system’s components, hardware, wiring, programming and software/ firmware.

The material and instructions covered in this installation guide have been carefully checked for accuracy and are presumed to be reliable. However, the manufacturer assumes no responsibility for inaccuracies and reserves the right to modify and revise this installation guide without notice.

This manual covers the operation of the D10024 Analog Fire Alarm Control Panel (FACP). See the D10024 Installation Guide (P/N: 46482) for instructions on the installation of the D10024.

1.2 FCC Notice

1.2.1 Part 15

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial installation. This equipment generates, uses and can radiate radio frequency energy, and, if not installed in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and the receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

D10024

Notices

1.3 UL/NFPA Notice

Radionics’ D10024 Analog Fire Alarm Control Panel is UL Listed for NFPA 72, Central Station and Remote Station. All references to NFPA and related requirements are based upon compliance with the 1993 edition of NFPA 72, National

Fire Alarm Code. Since installation specifications are nearly always based upon a specific edition of a standard which has been legally adopted by the Authority Having Jurisdiction (AHJ), earlier editions of NFPA standards will generally apply. Consult with the appropriate AHJ for confirmation.

D10024 Operator’s Guide

D10024 Notices

Notes:

D10024 Operator’s Guide

2.0 Overview

2.1 System Overview

Radionics’ D10024 Analog Fire Alarm Control Panel (FACP) is an expandable control panel that provides point identification through addressable analog devices. The D10024 has five expansion slots to accommodate plug-in polling circuit modules. Each of these polling circuit modules can support up to 126 analog addresses, giving the D10024 a potential of 630 addressable points. Flexibility in system design allows the option of grouping device points together and identifying them as one location, or zone, in order to simplify system operation.

The D10024 includes the following features:

• Analog design using advanced communications protocol

• 80 character display

• Custom text annunciation

• Up to 630 addresses supported in a stand-alone system

• Can be networked with Radionics’ D8024 and D9024 Analog FACPs, as well as other D10024 FACPs

• 24 VDC, 3 A power supply and battery charger

• Programmable sensitivity levels by device

• Programmable “day/night” sensitivity levels

• PC programmable

• Service mode polling

• Fire test mode

• Event activity logger (up to 500 events)

• Optional local printer

• Suitable for ADA applications

• Meets NFPA National Fire Code standards

D10024

Overview

Control Keys

LED Display

D10024

System

Trouble

Alarm

Manual

Silence

Reset

Silence

2 3 4

45 46 47 48

6 7 8

26 27 28

ALARM TROUBLE

22 23

41 42 43 44

61 62 63 64 65 66 67 68

Figure 1: D10024 Fire Alarm Control Panel

Alarm ENTER

9 10 11 12

29 30 31 32

49 505152

69 70 71 72 73 74 75 76

13 14 153616

33 34

54 55 56

Alphanumeric Display

YES

Letters

Keyword

Numbers

17 18 194020

38 39

58 59 60

78 79 80

Alphanumeric

Keys

Program/

Interactive Keys

Zone/Area

Display

D10024 Operator’s Guide

D10024

System Reset Cancels all alarm conditions and resets the panel.

Overview

2.2 Control Level Distinction

The D10024 has three available control levels. At all three levels, the LED display indicates condition, the Zone/Area LEDs indicate location and determined alarm/trouble information is displayed alphanumerically.

• Control Level 1 (Display Level): Inhibits the system control keys, limiting the front panel function to annunciation.

• Control Level 2 (Controller Level): Allows system control for Fire Drill, Alarm Silence, Trouble Silence and System Reset. This level also allows Test and Enable/Disable operations, but does not allow access to configuration or programming functions. At Control Level 2, the alphanumeric display becomes interactive and prompts for system checks, log functions and key status. Control Level 2 is reached by entering a passcode from Control Level 1.

• Control Level 3 (Programmer’s Level): Allows full system configuration information and is used to program the system or modify the program. Control Level 3 is reached by passcode from Control Levels 1 or 2. See the Analog Fire Alarm Control Panels Programming Guide (P/N: 38789) for more information on Control Level 3.

2.3 Passcodes

Ten passcodes are available for D10024 Controllers. Passcodes are programmable. The Control Level 2 passcode is assigned or changed from Control Level 3, but will not allow access to Control Level 3. See the Analog Fire Alarm Control Panels Programming Guide (P/N: 38789) for more information on programming and assigning passcodes from Control Level 3.

The default Control Level 2 passcode is 1234. Be sure to change the Control Level 2 passcode in order to provide a higher level of panel security. See Section 7.4 in the Analog Fire Alarm Control Panels Programming

Guide (P/N: 38789) to modify the Control Level 2 passcode.

2.4 Controls and Displays

The D10024 has two rows of control keys and three display areas. The upper row of keys, the alphanumeric keys, normally function as number keys. They can be toggled to letter keys or number keys by pressing the [Letters/Numbers] key in the program/interactive keys row. The [Shift] key at the left end of the alphanumeric keys toggles between the upper and lower rows of letters. Hold the [Shift] key while pressing another key to enter the bottom letter. The control keys row contains four system control keys and three program/interactive keys.

See Tables 1 and 2 for key descriptions and Figure 2 for key locations.

Key Label Function

Fire Drill Turns on all NAC devices.

Alarm Silence

Trouble Silence Acknowledges events and silences the internal buzzer.

Press to silence all NAC devices.

Press again to activate all NAC devices.

Table 1: Control Key Functions

D10024 Operator’s Guide
