PHOTOMULTlPLlER TUBE

R5108

28mm (1-1/8 Inch) Transmission Mode S–1 Photocathode, Side–on Type

FEATURES

Wide Photocathode
High Infrared Sensitivity

Excellent Spatial Uniformity
Fast Time Response

APPLICATIONS

Near Infrared Spectrophotometer
Raman Spectrophotometer

Photo Luminescence Measurement

GENERAL

Figure 1: Electron Trajectories

Parameter Description Unit

Spectral Response
Wavelength of Maximum Response

Photocathode

MateriaI

Minimum Effective Area
Window Material
Dynode

Structure

Number of Stages
Direct Interelectrode Capacitances

Anode to Last Dynode

Anode to All Other Electrodes
Base

SuitabIe Socket
Applicable Socket Assembly

Subject to local technical requirements and regulations, availability of products included in this promotional material may vary. Please consult with our sales office.

Information furnished by HAMAMATSU is believed to be reliable. However, no responsibility is assumed for possible inaccuracies or omissions. Specifications are
subject to change without notice. No patent rights are granted to any of the circuits described herein. © 1994 Hamamatsu Photonics K.K.

400 to 1200 nm

800

Ag–O–Cs

16(H) 18(W)

Borosilicate glass

Circular-cage

9

1.2 pF

3.4 pF

11-pin base

JEDEC No. B11-88

E678–11A (option)

E717–21 (option)

nm

mm

PHOTOELECTRONS

2nd DYNODE

LIGHT

PHOTOCATHODE

1st DYNODE

3rd DYNODE

GLASS
BULB

FOCUSING
ELECTRODES

TPMSC0003EB

PHOTOMULTlPLlER TUBE R5108

MAXIMUM RATINGS (Absolute Maximum Values)

Parameter Value Unit

Supply Voltage

Between Anode and Cathode
Between Anode and Last Dynode

Average Anode Current

A

1500

250

0.1

CHARACTERISTlCS (at 25 )

Parameter Typ.Min. Max. Unit

Cathode Sensitivity

Quantum Efficiency at 1060nm 0.04
Luminous
Radiant at 800nm

Anode Sensitivity

Luminous

Gain
Anode Dark Current

(after 30min. storage in the darkness)
Time Response

Anode Pulse Rise Time
Electron Transit Time

B

10

25

2.2

C

C

D

E

F

3.5 7.5

3.0 10

1.2
18

5

1000350

Vdc
Vdc

mA

%
A/lm
mA/W

A/lm

nA

ns
ns

NOTES

A:

Averaged over any interval of 30 seconds
maximum.

B:

The light source is a tungsten filament lamp
operated at a distribution temperature of 2856K.
Supply voltage is 150 volts between the cathode
and all other electrodes connected together as
anode.

C:

Measured with the same light source as Note B
and with the voltage distribution ratio shown in
Table 1 below.

Table 1:Voltage Distribution Ratio

Electrodes K Dy1 Dy2 Dy3 Dy4 Dy5 Dy6 Dy7 Dy8 Dy9 P
Ratio

SuppIy Voltage : 1250Vdc
K : Cathode, Dy : Dynode, P : Anode

D:

Measured at the voltage which gives anode
luminous sensitivity of 4A/lm.

E:

The rise time is the time for the output pulse to
rise from 10% to 90% of the peak amplitude when
the entire photocathode is illuminated by a delta
function light pulse.

F:

The electron transit time is the interval between
the arrival of delta function light pulse at the
entrance window of the tube and the time when
the anode output reaches the peak amplitude. In
measurement, the whole photocathode is
illuminated.

1111111111

Figure 2: Typical Spatial Uniformity

Y

SPOTSIZE : 1mm DIA
SUPPLY VOLTAGE : 1000V

X

WAVELENGTH : 400nm

100

80

60

40

20

RELATIVE SENSITIVITY (%)

X-Axis

0

84 04

DISTANCE FROM CENTER OF
PHOTOCATHODE (mm)

Y-Axis

9

8

4.5

DISTANCE FROM CENTER OF
PHOTOCATHODE (mm)

0

4.5

9

TPMSB0066EA

100

80

60

40

20
0

RELATIVE SENSITIVITY (%)

Figure 3: Typical Spectral Response Figure 4: Typical Time Response

TPMSB0041EA

100

10

1

0.1

QUANTUM
EFFICIENCY

QUANTUM EFFICIENCY (%)

0.01

CATHODE RADIANT SENSITIVITY (mA/W)

0.001
200 400 600 800 1000 1200

WAVELENGTH (nm)

CATHODE
RADIANT
SENSITIVITY

200

100

80
60

40

20

TIME (ns)

10

8
6

4

2

1

TPMSB0042EA

TRANSIT TIME

RISE TIME

300 500 700 1000 1500

SUPPLY VOLTAGE (V)

Figure 5: Typical Gain and Anode Dark Current Figure 6: Typical Temperature Characteristics

of Anode Dark Current (at 4A/lm)

TPMSB0043EA

7

10

6

10

5

10

GAIN

4

10

3

10

2

10

600 700 800 1000 1200

SUPPLY VOLTAGE (V)

GAIN

DARK CURRENT

1500

10

10

10

10

10

10

–3

–4

–5

–6

ANODE DARK CURRENT (A)

–7

–8

ANODE DARK CURRENT (A)

10

10

10

10

10

10

TPMSB0044EA

–3

–4

–5

–6

–7

–8

–40

–30 –20 –10010203040

TEMPERATURE ( )

PHOTOMULTlPLlER TUBE R5108

Figure 7: Dimensional Outline and Basing Diagram (Unit: mm)

29.0 1.7
18MIN.

PHOTOCATHODE

16MIN.

76MAX.

49.0 2.5

34MAX.

11 PIN BASE

HA COATING

JEDEC No. B11-88

Figure 8: Optional Accessories (Unit: mm)

49
38

3.5
33

5

29

4

18

90MAX.

3.5

33.0 0.3

4.8

41.0 0.5

450 10

DY6

DY4

DY3

DY2

DY5

3

6

5

4

2

1

DY1

DIRECTION OF LIGHT

BOTTOM VIEW

(BASING DIAGRAM)

D Type Socket Assembly E717-21Socket E678-11A

5

38.0 0.3

49.0 0.3

29

31.0 0.5
HOUSING

(INSULATOR)

POTTING
COMPOUND

DY7

7

DY8

8

DY9

9

10

P

11

K

TPMSA0023EA

SOCKET

PMT

PIN No.

10

P

DY9

9

DY8

8

DY7

7

DY6

6

DY5

5

DY4

4

DY3

3

DY2

2

DY1

1

K

11

R10

R9

R8

R7

R6

R5

R4

R3

R2

R1

C3

C2

C1

R to R10
C1 to C3

SIGNAL GND
SIGNAL OUTPUT RG-174/U

(BLACK)
POWER SUPPLY GND

AWG22 (BLACK)

: 330k
: 0.01 F

–HV

AWG22 (VIOLET)

R1 to R10 : 330k
C

1 to C3 : 0.01 F

TACCA0002ED

TACCA0008EB
