Princeton LCD2000 User Manual

LCD2000

REFERENCE MANUAL

FCC Information

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help .

FCC Warning:

To assure continued FCC compliance, the user must use the provided grounded power

supply cord and the provided shielded video interface cable with bonded ferrite cores. Also,

any unauthorized changes or modifications to this TFT LCD would void the user's authority

to operate this device.

E
N
G
L

I
S
H

Canadian Complaince Statement:

This equipment does not exceed Class B limits per radio noise emissions for a digital

apparatus, set forth in the Radio interference regulation of the canadian Department of

Communications. Operation in a residential area may cause unacceptable intereference to

radio and TV reception requiring the owner or operator to take whatever steps necessary to

crrect the intereferece.

1

E
N
G
L

S
H

Important Safety Instructions:

I

Power:

• Use the type of power indicated on the marking label.

Plugs:

• Do not remove any parts of the Display’s three-pronged power plug.

• Disconnect the power plug from the AC outlet when the display will not be used for an indefinite

period of time.

Power and extension cords

• Use the proper power cord with the correct plug type. If the power source is 120VAC, use a power

cord that has UL and CSA approvals. If the power source is 250VAC supply, use the tandem (T

Blade) type attachment plug with a ground conductor power cord that meets the respective

European counties safety regulations, such as VDE for Germany.

We recommend using the power cord supplied with the product. However, if another type of power

cord is required, power cord H05VV-F, or VW-1, 18AWG x 3G should be used.

Do not overload wall outlets or power cords. Be sure that the total of all units plugged into the wall

outlet does not exceed 7 amperes.

Be sure that the total ampere ratings on all units plugged into the extension cord does not exceed the

rating of the cord.

If the display power supply cord requires a connection to the PC instead of the wall outlet, this

equipment is to be used with a UL approved computer which has a receptacle rated of 100~240VAC,

50/60Hz, (minimum)

Environment

• Place the display on a flat and leveled surface.

• Place the display in a well-ventilated area.

• Keep the Display away from water, excessive heat, cold, or humidity.

• Do not place the power cord on a walkway or rest anything heavy on top of it.

• Keep the display stable at all times.

2

Table of Content

FCC Information ----------------------------------------------------------------------------------------- 1

FCC Warning ---------------------------------------------------------------------------------------------- 1

Safety Precautions --------------------------------------------------------------------------------------- 1

Important Safety Instructions ------------------------------------------------------------------------- 2

E
N
G
L

S
H

I

Getting Started

Package Contents -------------------------------------------------------------------------------------- 4

Unique Features ---------------------------------------------------------------------------------------- 4

Precautions ----------------------------------------------------------------------------------------------- 5

Cleaning the TFT LCD Monitor ---------------------------------------------------------------------- 5

Quick Installation --------------------------------------------------------------------------------------- 6

Operation

Front Control Panel ------------------------------------------------------------------------------------- 9

Hot Key --------------------------------------------------------------------------------------------------- 9

OSD Main Menu ---------------------------------------------------------------------------------------- 9

COLOR Sub-Menu ------------------------------------------------------------------------------------ 10

LCD Sub-Menu ---------------------------------------------------------------------------------------- 10

MISC Sub-Menu -------------------------------------------------------------------------------------- 11

Technical Data

Specifications ------------------------------------------------------------------------------------------ 12

Factory Preset Timings ------------------------------------------------------------------------------- 13

3

E
N
G
L

I
S
H

GETTING STARTED

Thank you for choosing Princeton and congratulations on your purchase of a TFT LCD

Color Monitor. This section lists package contents, features, precautions, as well as

cleaning and installation instructions.

Important ! Please keep the original box and all packing

material for future shipping needs.

Package Contents

Your TFT LCD Color Monitor package includes the following:

• TFT LCD Color Monitor

• Video cable (DB15)

• DVI Cable (DVI-D)

• Power Cord

• This Reference Manual

Monitor Features:

• High resolution, High Contrast color Active Matrix TFT-LCD providing sharp, vivid, and

flicker-free images.

• Energy Star® Compliant for Maximized Energy Saving.

• Plug & Play Compatibility with DDC2B.

• True Native Resolution of 1600 x 1200.

• Free run features that will search the right frequency without interface.

• Composite Sync. and Sync-On-Green Compatibilities.

• Five Selectable Languages.

• Smart Out-of-Sync and No Signal Indications.

• Support for Image Smoothing for lower resolutions.

• True Native 1600 x 1200 Resolutions.

4
