Prime Security AMX98 Installation Manual

AMX98 (2) Rev. A - Installation Manual - Front Cover

Table of Contents

Important Information ........................... 2

Required Installation Tools ........................ 2

Recommended Procedures .......................2

Wiring Diagram ............................. 3

20 Pin Connector............................4

Installation Procedures...........................5

Control Unit............................... 5

Antenna................................. 5

Wireloom ................................5

Zone2™ Impact Sensor..........................5

Valet Switch...............................6

LED Indicator..............................6

Ignition Input ..............................6

Channel 2 Accessory (-) Output..................... 6

Channel 4 Accessory (-) Output..................... 6

Channel 6 Accessory (-) Output..................... 7

Parking Lights..............................7

Interior Light Trigger/Illumination .................... 7

Starter Disable.............................. 7

Door Lock/Unlock............................8

Door Lock Diagrams ..........................9

Hood/Trunk Pin Switch.........................13

Siren ..................................13

Power and Ground Connections.................... 13

Programmable Features.......................... 14

Programming Table for Alarm Features................. 15

Programming Table for Remote Controls ................ 16

1

AMX98(3) Rev. A - Installation Manual 12/98

Important Information

Required Installation Tools

Voltmeter

Voltmeter Wire Strippers

Wire Strippers Electric Drill & Bits

Electric Drill & Bits Phillips Screw Driver

Phillips Screw Driver Convoluted Tubing *

Convoluted Tubing * Solder Gun *

Solder Gun * Wire Crimpers

Wire Crimpers Shrink Tube or Electrical Tape

Shrink Tube or Electrical Tape

* Optional

Recommended Procedures

1. Test all circuits with a voltmeter.

2. Make all wiring connections with the supplied solderless crimp

2. Make all wiring connections with the supplied solderless crimp connectors. DO NOT twist wires or use “scotch-lok” connectors.

connectors. DO NOT twist wires or use “scotch-lok” connectors.

3.

Route RED , RED/WHITE and BLACK wires from the control unit directly

Route RED , RED/WHITE and BLACK wires from the control unit directly to the battery.

to the battery.

4. Keep extensions as short as possible. Use same gauge wires for short

4. Keep extensions as short as possible. Use same gauge wires for short extensions and larger gauge wires for longer extensions.

extensions and larger gauge wires for longer extensions.

5. Before installing, discuss the placement of the LED indicator and valet

5. Before installing, discuss the placement of the LED indicator and valet switch with the vehicle owner.

switch with the vehicle owner.

6. Make all battery connections by removing the bolts from the cable

6. Make all battery connections by removing the bolts from the cable clamps. DO NOT disconnect the battery cables.

clamps. DO NOT disconnect the battery cables.

7. Turn off dome light(s) or remove dome light fuse to prevent battery drain.

8. Making secure connections is a very important part of your installation.

8. Making secure connections is a very important part of your installation. Solderless crimp connectors are supplied in your hardware accessory

Solderless crimp connectors are supplied in your hardware accessory package. This type of connection is sufficient for most of your installation.

package. This type of connection is sufficient for most of your installation. However, soldering of the starter disable wires is recommended whenever

However, soldering of the starter disable wires is recommended whenever possible. For a more secure installation, solder all of your connections and

possible. For a more secure installation, solder all of your connections and insulate with heat shrink tubing.

insulate with heat shrink tubing.

This device complies with Part 15 of the FCC rules. Any changes or modifications

This device complies with Part 15 of the FCC rules. Any changes or modifications made to the system without the express approval of Prime Security could void the

made to the system without the express approval of Prime Security could void the user’s authority to operate this equipment.

user’s authority to operate this equipment.

2

AMX98(3) Rev. A - Installation Manual 12/98

Wiring Diagram

3

AMX98(3) Rev. A - Installation Manual 12/98

20 Pin Connector

Pin Number Wire Color Description

1 2 VIOLET Siren (-) Output 3 DARK BLUE Channel 2 (-) Output (Trunk Release) 4 5 BLUE / YELLOW Channel 6 (-) Output 6 GRAY Armed (-) Output Prewired to Starter Disable Relay 7 8 PINK Ignition Output

9 LIGHT GREEN Second Stage Unlock (-) Output 10 11 12 RED / BLACK Parking Light Output 13 14 15 GREEN / BLACK Unlock Switch Side 16 17 18 BLUE / BLACK Lock Switch Side 19 20

RED

LIGHT BLUE

TAN

BLACK

RED / WHITE

WHITE

WHITE / BLACK

GREEN / WHITE

GREEN / RED

BLUE / WHITE

BLUE / RED

Hood / Trunk Switch (-) Input

Parking Light Polarity Input, (+) or (-) Input Select

Door Trigger Polarity Select Input

Unlock Polarity (+) or (-) Input Select

Lock Polarity (+) or (-) Input Select

Battery (+)

Channel 4 (-) Output

Battery (-)

Interior Light Input

Unlock Motor Side

Lock Motor Side

4

AMX98(3) Rev. A - Installation Manual 12/98

Installation Procedures

Control Unit

1. Select a location under the dash that will allow you to use the tie wraps to

1. Select a location under the dash that will allow you to use the tie wraps to securely fasten the control unit.

securely fasten the control unit.

2. Mount the control unit as high as possible to ensure maximum range.

3. Do not mount the control unit near moving parts.

4. Avoid areas that are in the direct path of air blowing from the vents.

5. Route wires from this point, leaving slack for ease of service.

Antenna

1. Do not shorten or lengthen the antenna.

2. Route the antenna away from the control unit.

3. Keep the antenna as far away from metal and wire harnesses as possible

3. Keep the antenna as far away from metal and wire harnesses as possible to optimize range.

to optimize range.

Wireloom

1. Plug the wireloom securely into the control unit.

2. Route wires from the control unit directly to each connection point.

3.

Separate the RED, RED/WHITE, BLACK, VIOLET and TAN wires.

4. Sleeve the wires with vinyl tubing or electrical tape and route them

4. Sleeve the wires with vinyl tubing or electrical tape and route them through an existing rubber grommet into the engine compartment.

through an existing rubber grommet into the engine compartment.

5. If an existing grommet is not available, drill a hole and install a snap

5. If an existing grommet is not available, drill a hole and install a snap grommet.

grommet.

Zone2™ Impact Sensor

The sensor must be firmly mounted on a solid metal surface inside the vehicle.

The sensor must be firmly mounted on a solid metal surface inside the vehicle. We recommend tie wrapping the sensor to the steering column housing or

We recommend tie wrapping the sensor to the steering column housing or steering column support bracket. DO NOT mount the sensor near moving

steering column support bracket. DO NOT mount the sensor near moving parts or in the direct path of an air duct opening.

parts or in the direct path of an air duct opening.

1.

Plug the impact sensor BLUE 4-pin connector into the control unit BLUE

Plug the impact sensor BLUE 4-pin connector into the control unit BLUE 4-pin connector.

4-pin connector.

2. Route the impact sensor harness to the chosen mounting location.

3. Using the long tie wraps supplied, securely fasten the impact sensor

3. Using the long tie wraps supplied, securely fasten the impact sensor allowing access to the adjustment screws.

allowing access to the adjustment screws.

5

AMX98(3) Rev. A - Installation Manual 12/98

Valet Switch

1. Discuss placement with the vehicle owner.

2. Choose a location for the valet switch that is hidden, but convenient for the owner to access.

3. Drill a ¼" hole and mount the switch.

4. Route the valet switch wires to the control unit.

5.

Plug the valet switch WHITE connector into the control unit WHITE plug.

LED Indicator

1. Discuss placement with the owner.

2. Choose a location that is visible from both sides of the vehicle.

3. Drill a ¼" hole.

4. Route the LED wires through the hole and press LED into place.

5. Route the LED wires to the control unit.

6.

Plug the RED LED connector into the control unit RED plug.

Ignition Input

1. Use a voltmeter to locate the one wire that shows +12 volts when the ignition key is in the "ON," "CRANK" and "RUN" positions, and 0 volts when the ignition key is in the "OFF" position.

2.

Connect the PINK wire to the vehicle ignition wire.

Channel 2 Accessory (-) Output

The DARK BLUE wire provides a 0.75 second ground (-) output when the alarm is disarmed only. This is ideal for trunk release. If the remote control button is continuously pressed, the signal will stay at ground as long as the button is held.

NOTE: Most trunk releases are positive and require an optional relay.

Channel 4 Accessory (-) Output

The LIGHT BLUE wire provides a 0.75 second (-) output when activated whether the alarm is armed or disarmed. If the remote control button is continually pressed, the signal will stay at ground as long as the button is held.

6

AMX98(3) Rev. A - Installation Manual 12/98

Channel 6 Accessory (-) Output (Arm/Disarm + Option Buttons)

The LIGHT BLUE/YELLOW wire provides a 0.75 second (-) output when activated whether the alarm is armed or disarmed. If the remote control button(s) is continually pressed, the signal will stay at ground as long as the button is held.

Parking Lights

1.

If the parking lights are positive trigger, connect the RED/WHITE wire to the battery positive (+) terminal through the 20 amp fuse.

NOTE: Do not connect the RED/WHITE wire to the control unit RED wire.

2.

If the parking lights are negative (-) trigger, connect the RED/WHITE wire to control unit BLACK wire.

3.

Connect the RED/BLACK wire to the vehicle parking light wire.

Interior Light Trigger/Illumination

The system door trigger will accept a positive or negative door trigger input. When the alarm is remotely disarmed, the interior lights will turn on for 30 seconds or until the ignition key is turned "ON." The WHITE/BLACK interior light supply wire serves two purposes. It informs the alarm whether the door trigger polarity is positive or negative switching and provides a positive or negative supply for interior light illumination.

1.

Connect the WHITE wire to the vehicle door trigger wire(s).

2.

If the door trigger is negative switching, connect the WHITE/BLACK wire to ground.

3.

If the door trigger wire is positive switching, connect the WHITE/BLACK wire to a constant fused +12 volt source.

Starter Disable

The alarm can be installed as Normally Open (N.O.) or Normally Closed (N.C.) starter disable. It is factory set for Normally Closed.

NOTE: Make sure the YELLOW relay wires are solidly connected. The starter circuit may draw very high current. We recommend that all starter wire connections be soldered.

7

AMX98(3) Rev. A - Installation Manual 12/98

Normally Closed

1. Locate the ignition switch wireloom under the dashboard.

2. Use a voltmeter to find the one wire that will show +12 volts while the

2. Use a voltmeter to find the one wire that will show +12 volts while the ignition key is in the cranking cycle only. This should be the starter

ignition key is in the cranking cycle only. This should be the starter solenoid wire.

solenoid wire.

3. Cut the starter solenoid wire. Test by trying to crank the starter with the

3. Cut the starter solenoid wire. Test by trying to crank the starter with the ignition key. If it will not crank, you have the correct wire.

ignition key. If it will not crank, you have the correct wire.

4.

Connect one YELLOW wire to the key side.

5.

Connect the other YELLOW wire to the starter side.

Normally Open

1.

Unplug the YELLOW wire from relay terminal 87A and insert the

YELLOW wire into relay terminal 87.

2. Locate the ignition switch wireloom under the dashboard.

3. Use a voltmeter to find the one wire that will show +12 volts while the

3. Use a voltmeter to find the one wire that will show +12 volts while the ignition key is in the cranking cycle only. This should be the starter

ignition key is in the cranking cycle only. This should be the starter solenoid wire.

solenoid wire.

4. Cut the starter solenoid wire. Test by trying to crank the starter with the

4. Cut the starter solenoid wire. Test by trying to crank the starter with the ignition key. If it will not crank, you have the correct wire.

ignition key. If it will not crank, you have the correct wire.

5.

Connect one YELLOW wire to the key side.

6.

Connect the other YELLOW wire to the starter side.

7. Program the alarm module for Normally Open (N.O.) starter disable (see

7. Program the alarm module for Normally Open (N.O.) starter disable (see "Programming Table for Alarm Features").

"Programming Table for Alarm Features").

Door Lock/Unlock

The alarm has on-board relays to lock and unlock the doors. It also has a

The alarm has on-board relays to lock and unlock the doors. It also has a second unlock (-) output wire (GREEN ) that will allow you to do Two-Stage

second unlock (-) output wire (GREEN ) that will allow you to do Two-Stage Unlock. The second stage unlock wire provides a 400 ma, 0.75 second (-)

Unlock. The second stage unlock wire provides a 400 ma, 0.75 second (-) output when activated.

output when activated.

Two-Stage Unlock

CAUTION : Be sure to verify the type of door lock system you are

working with. Carefully follow the door lock/unlock diagrams on

I

pages 9-12.

1. Press the remote arm/disarm button once and the driver door only will

1. Press the remote arm/disarm button once and the driver door only will unlock.

unlock.

2. Press the remote arm/disarm button again within 3 seconds and the

2. Press the remote arm/disarm button again within 3 seconds and the passenger doors will unlock.

passenger doors will unlock.

8

AMX98(3) Rev. A - Installation Manual 12/98

9

AMX98(3) Rev. A - Installation Manual 12/98

10

AMX98(3) Rev. A - Installation Manual 12/98

11

AMX98(3) Rev. A - Installation Manual 12/98

12

AMX98(3) Rev. A - Installation Manual 12/98

Hood/Trunk Pin Switch

1. Locate the vehicle hood or trunk pin switch that shows ground when the hood or trunk is open only.

2.

Connect the TAN wire to the vehicle hood or trunk switch wire.

3. If the vehicle does not have a hood or trunk switch, install a pin switch and connect it to the TAN wire.

Siren

1. Choose a location in the engine compartment away from high heat engine components, moving parts and direct exposure to water.

2. Make sure the siren and siren wires cannot be seen or reached from below the vehicle.

3. Mount the siren with the two self tapping screws to a solid metal surface.

4.

Connect the siren BLACK wire to the alarm module VIOLET wire.

5.

Connect the siren RED wire to the alarm module RED wire.

Power and Ground Connections

CAUTION : Do not plug in the system fuses until the final step

below.

I

1.

Connect the RED wire to one of the supplied fuse assemblies.

2.

Connect the RED/WHITE wire to the other fuse assembly (if the vehicle parking lights are (+) positive).

3. Connect the fuse assembly(s) to one of the supplied 10mm ring terminals.

4.

Connect the BLACK wire to the other 10mm ring terminal.

5. Remove the (+) and (-) battery bolts. Do not disconnect the battery clamps.

6. Connect the empty fuse assembly(s) to the positive battery post.

7.

Connect the BLACK wire to the battery negative post.

8. Inspect all alarm wiring. Make sure all wires are connected.

9.

Install the 5 amp fuse in the RED wire fuse assembly.

10.

Install the 20 amp fuse in the RED/WHITE fuse assembly (if the vehicle parking lights are positive).

13

AMX98(3) Rev. A - Installation Manual 12/98

Programmable Features

All system and remote control programmable features are accomplished by turning the ignition key to the "ON" position or starting the engine and flicking the valet switch on and off a preset number of times. The siren will chirp for audible programming confirmation.

The system also allows you to add new remote controls in one step, delete lost or stolen remote controls or rearrange the factory preset remote control functions.

1. Remove the system from Protected or Remote-Controlled Valet Mode. Programming cannot be accessed while the system is in Valet Mode indicated by the LED on solid red.

2. Select the feature you wish to program from the "Programming Table for System Features" or the "Programming Table for Remote Controls" on pages 15-16. Note the number of chirps associated with that feature.

3. Turn the ignition key to the "ON" position.

4. Within 10 seconds, begin flicking the valet switch on and off. The siren will chirp once each time you flick the switch on then off.

5. Continue flicking the switch on and off, counting the number of chirps.

NOTE: Stop when you reach the number of chirps associated with your chosen feature.

6. Follow the "Secondary Action." You will hear a number of chirps to confirm that you have changed the setting of that feature.

7. Turn the ignition key "OFF."

8. Repeat steps 1-7 for any other feature you wish to program.

14

AMX98(3) Rev. A - Installation Manual 12/98

Programming Table for System Features

Feature

Active / Passive Arming Passive 4

Passive Door Lock OFF 5

Passive Armed Confirmation ON 6

2 Pulse Unlock 1 Pulse 7

Door Lock/Unlock Output Duration

(1 or 3 Seconds)

Ignition-Controlled Door

Lock/Unlock

Programmable 0 or 3 Second Delay

for Ignition-Controlled Door Lock0Seconds

Normally Open / Normally Closed

Starter Disable

Door Ajar Indication ON 12

Siren Duration

30 or 60 seconds

Long-Term Silent Arm/Disarm ON 14

Factory

Setting

1 Second 8

ON 9

Normally

Closed

30

Seconds

No. of

Chirps

10

11

13

Secondary Action

Wait 3 seconds, the siren will chirp

once for active, twice passive.

Wait 3 seconds, the siren will chirp

once for Off, twice for On.

Wait 3 seconds, the siren will chirp

once for Off, twice for On.

Wait 3 seconds, the siren will chirp

once for 2 pulse, twice for 1.

Wait 3 seconds, the siren will chirp

once for 3 seconds, twice for

1 second.

Wait 3 seconds, the siren will chirp

once for Off, twice for On.

Wait 3 seconds, the siren will chirp

once for 3 seconds, twice for

0 seconds.

Wait 3 seconds, the siren will chirp

once for normally open, twice for

normally closed.

Wait 3 seconds, the siren will chirp

once for Off, twice for On.

Wait 3 seconds, the siren will chirp

once for 60 seconds, twice for 30.

Wait 3 seconds, the siren will chirp

once for Off, twice for On.

15

AMX98(3) Rev. A - Installation Manual 12/98

Programming Table for Remote Controls

Feature Factory Setting

Arm/Disarm

Remote-Controlled

Trunk Release Output

Remote-Controlled

Silent Arm/Disarm

Channel 4

Remote-Controlled

Accessory Output

Remote-Controlled Valet

Channel 6

Remote-Controlled

Accessory Output

Remote-Controlled

Sensor Bypass

One Step Remote

Control Code Learning

Instant Remote Control

Code Deletion

No. of Chirps

ARM/DISARM

Button

TRUNK Button 16

SILENT Button 17

OPTION Button 18

ARM/DISARM + SILENT Buttsons

ARM/DISARM +

OPTION Buttons

TRUNK +

OPTION Buttons

ARM/DISARM

Button

— 23

Secondary Action

15

19

20

21

22

Press the ARM/DISARM button, the

siren will chirp 1 time.

Press the TRUNK button, the siren

will chirp 2 times.

Press the SILENT button, the siren will

chirp 3 times.

Press the OPTION button, the siren

will chirp 4 times.

Press the ARM/DISARM + SILENT

buttons, the siren will chirp 5 times.

Press the ARM/DISARM + OPTION

buttons, the siren will chirp 6 times.

Press the TRUNK + OPTION buttons,

the siren will chirp 7 times.

Press ARM/DISARM button, the siren

will chirp 1 time.

Wait 3 seconds, the siren will chirp

twice, all codes are erased out of

memory.

16

AMX98(3) Rev. A - Installation Manual 12/98

AMX98 (2) Rev. A - Installation Manual - Back Cover

Prime Security AMX98 Installation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
