Wireless Bluetooth Mouse User’s Guide
PRIMAX ELECTRONICS LTD.
Model：MOBTEJO
Thanks for purchasing Bluetooth Optical Mouse. This creative and easy-to-use Bluetooth Mouse
will bring you a whole new wireless life experience.
Appearance Drawing
System Requirement
z Mouse compatible with standard Microsoft Mode.
z IBM compatible PCs running Windows Operating System which supports USB devices.
z If your computer doesn’t have built in Bluetooth function, please make sure that you have the
Bluetooth Dongle. Bluetooth Dongle is not include d in this pro duc t.
Main Features
z Switchable CPI among 800/1000/1200/1600(some bluetooth mouse have no this function).
z Features comfortable, ergonomic design
z Built-in software solutions with Bluetooth human interface device and comply with the
standard version of the Bluetooth SIG Bluetooth 2.0
z Work with Windows 98, ME, 2000, XP and Vista OS
z AA alkaline battery x2
z Frequency band: 2.402 - 2.480GHz unlicensed ISM band
z Receiving sensitivity: -75bm (standard)
z Operation distance: 10m
z Operating temperature: 0~55°C
z Operation Humidity: 10%-85% RH at 25°C
z Storage Temperature: -20~+60°C
z Storage Humidity: 5%-95% RH at 25°C
Precaution
! The optical mouse cannot work on a glass or mirror surface. Avoid operating this mouse on a
glossy surface. Otherwise, this mouse may not operate normally.
! For consideration of saving battery power, it is strongly recommended to operate an optical
mouse on a bright surface with fine texture to obtain lower power consumption of the Agilest high
illumination LED. A very dark surface will cause higher power consumption.
! For a better transmission distance, avoid to use this device on a metal plate or desktop because a
large surface of iron, aluminum. Operating on a metal may cause the transmission distance shorter.
Installation Guide
Step1. Inserting Batteries
1. Remove the battery cover.
2. Inset 2Pcs AA alkaline batteries. (Please be cautious of the polarity of the batteries).
3. Close the battery cover, Let the Power Switch On, then Press the Connect Button and the mouse
will be in the match state..
Connect
Button
Power Switch
Battery Cover
Step2. Connecting the Mouse to the Dongle.
Before you install the Bluetooth Mouse, please make sure that your computer supports Bluetooth
function, and finished the Bluetooth software installation. Software available like
Wincomm(Recommended), IVT or the Microsoft built-in software
Press and hold the connect button at the bottom .Please note that the connect button is only useful
during the match procedure.
Match Procedure
A: Match on Widcomm (recommended)
1． Double click the Icon again
2． click “Bluetooth Setup---Bluetooth Setup Guide”.
3． In the Setup Guild window, click next button, wait until the system found the mouse, select
“Mouse”, click “Next”. Hint for connection,
4． click “Click here”, now you can use your mouse at ease.
, “My Bluetooth Place” pops up;
