User’s Quick Guide
Congratulations on your purchase of the Primax KBBT53811 Bluetooth® Keyboard! This guide will take you
through all the functions of this keyboard.
Introduction
Primax KBBT53811 Bluetooth® Keyboard is the latest in a wide range of tablet peripherals manufactured by
Primax and is designed to provide you with the highest level of comfort available while also allowing for
maximum functionality.
Safety Guidelines
Physical discomfort and injury can be caused by the incorrect use of your keyboard. Follow these guidelines
to ensure such problems are avoided:
Sit up straight in your chair, with your elbows by your side.
Adjust the height of your chair so your arm bends at a 90-degree angle respective
Position your keyboard in front you, to the side of your keyboard.
Do not slouch or hunch over your workspace. It is important to keep your wrists,
shoulders relaxed.
If necessary, use a wrist rest or a palm rest to alleviate extra stress placed on your
typing or using the keyboard, especially for long periods of time.
to your desk.
arms and
joints when
If you experience any feelings numbness, cramp, swelling or stiffness in your wrist, arms, neck or shoulders,
consult your local doctor or nearest health institution immediately.
Page
3
of 8
BLUETOOTH
®
KEYBOARD
Rev 0.1
Bluetooth® keyboard connection settings
Follow below steps to connect the Bluetooth® keyboard and the tablet system.
1. Turn on the power switch in front of the Bluetooth® keyboard. The keyboard connection indicator light
blinks blue.
Note: If the Bluetooth® indicator lights stop blinking, long press the connect buttons on the keyboard
to restart the connection process.
Note: If the indicator blinks quickly, it means this keyboard has been paired before. Long press the
connection button to clean the paired data and restart the connection.
2. Turn on Bluetooth in Tablet/iPad settings. Tablet/iPad will start discovering the list of available Bluetooth®
devices for pairing.
Note: If AROWANA Bluetooth Keyboard is not found, long press the Keyboard connect button and
manually trigger the device search again in tablet/iPad.
3. Select the AROWANA Bluetooth Keyboard from the list.
4. Using Primax Bluetooth® Keyboard to enter the pairing code and press the Enter key to complete the
Bluetooth connection.
After the pairing process is completed, the last paired data will be stored. Auto connection will be supported in
later operation.
Bluetooth® keyboard Hotkey support
The hotkey function support, position or printing might be various while shipping. Enclosed is iPad2
version.
