Bluetooth Micro Dongle
User’s Guide
Rating: 5V DC 80mA
Made in China
Package Contents
· USB Bluetooth adapter x 1
· Installation CD x 1 (includes Bluetooth software and User’ s Guide)
· User’ s Guide x 1
PC Requirements
· Pentium processor or equivalent
· At least one USB port (USB 2.0 or 1.1)
· CD-ROM drive
· Operating System: Windows® 2000, Windows® XP with Service Pack 1 or higher, Windows® Vista.
Introduction
Installing the Bluetooth Software (Vista)
Before installing the Bluetooth software, plug the USB Bluetooth adapter into a USB port of your computer. If not, a warning message will
appear and prompt you to plug the USB Bluetooth adapter into a USB port during the installation.
The following procedures are based on Windows Vista operating system.
1. Insert the provided Installation CD in the CD ROM drive.
2. The Bluetooth software loads automatically. If not, click the Setup.exe in the CD ROM.
3. The welcome screen appears. Click Next to begin installation.
4. Read the agreement and select I accept the terms in the license agreement. Click Next to continue.
5. The program will be installed in the folder as shown. Click Change to install in a different directory. Click Next to continue.
6. Click Install to start the installation. The installation may take some time to complete.
Note: If the “Bluetooth device not found” message appears, plug the USB Bluetooth adapter into a USB port of your computer and click OK.
The Found New Hardware Wizard starts installing the components for the USB Bluetooth adapter.
7. The following screen appears to indicate installation is complete.
8. Click Yes to restart your computer and for the new settings to take effect.
Using the Bluetooth Software (Vista)
After you have completed the driver and software installation and reboot your computer, a Bluetooth icon will appear on your desktop and in
the bottom right hand corner of your desktop screen (systray). The Bluetooth icon gives you access to the Bluetooth shortcut menu, and
Bluetooth Devices, for configuring your Bluetooth settings.
Right click the Bluetooth icon for to display the shortcut menu.
· Add a Bluetooth Device: Click to add a new Bluetooth device.
· Show Bluetooth Devices: Click to show all detected Bluetooth devices.
· Send a File: Click to send a file using Bluetooth File Sharing.
· Receive a File: Click to receive a file using Bluetooth File Sharing.
· Join a Personal Area Network: Click to join a private Bluetooth network.
· Open Bluetooth Settings: Click to open the Bluetooth Devices screen.
· Remove Bluetooth Icon: Click to remove the Bluetooth icon from the system tray.
Double click the Bluetooth icon for access to Bluetooth Devices.
You can manage all your Bluetooth connections and settings from the Bluetooth Devices screen.
Use the tabs at the top of the screen to navigate the Bluetooth Devices screen.
Click OK to confirm a setting, and close the screen, click Cancel to cancel any changes, and click Apply to confirm a setting without closing
the screen.
Devices Tab
Click the Devices tab to view all detected Bluetooth devices. Click Add to configure a new device, click Properties to view the properties for a
selected device, or Remove to remove a device from the list.
Options Tab
Click the Options tab to set discovery and connection permissions. You can also select to how the Bluetooth icon in the system taskbar from
here.
Click Restore Defaults to restore all settings to their original defaults.
