Prima PJE020 User Manual

Juice Extractor

MODEL PJE020

USER GUIDE WITH RECIPES

Visit our web site at: www.buyprima.com

IMPORTANT SAFEGUARDS

1. Please read through the information and safety advice contained in these operating instructions
carefully and thoroughly before you use the Juicer for the first time.

2. Place Juice Extractor on a flat, stable, cool work surface.

3. Never allow children to operate this appliance.

4. Make sure that the voltage shown on the rating plate corresponds with that of the mains supply. The
rating plate can be found on the bottom of the motor block. The product is only to be connected to an
AC supply (~). The motor must always be switched off before the product is connected to the main
supply. ( ‘0’ setting).

5. This Juicer has a safety switch and only operates when the two black handles are locked into place.

6. Do not use the Juice extractor continually for more than one minute at a time. If the machine
becomes too hot then it will automatically shut down until the motor is cool enough to start up again.
Once it has shut down the machine normally takes about 15 minutes to cool down before it can be
used again.

7. If the supply cord is damaged, its must be replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard. Do not attempt to repair the device yourself.

8. Do not immerse the unit in water or any other liquid. Simply wipe with soft damp cloth.

9. Close adult supervision is necessary when using this or any appliance where children are present.

10. Never leave the appliance connected to the mains and unattended.

11. Avoid contacting moving parts. Always use the Juicer stick to feed fruit into the feeding tube –
NEVER use fingers.

12. Do not use any attachments other than those supplied. To do so would invalidate your warranty.

13. Do not let the cord hang over the edge or counter top.

14. Never interfere with or try to bypass the safety switches.

15. Make sure when removing parts to clean the power is switched off and unplugged from the wall
socket.

16. Do not use out doors.

17. Please note that this appliance is for domestic use only.

Technical Information

Voltage/frequency: 230V~50Hz (600W)
Juice capacity: 1 litre
Pulp capacity: 2 litres

Parts and Assembly

IMPORTANT

THE JUICE EXTRACTOR IS EQUIPPED WITH A SAFETY INTERLOCK SWITCH. THIS IS FITTED TO PREVENT
THE MOTOR FROM BEING ACTIVATED WHILE THE MACHINE IS DISASSEMBLED. THE MOTOR WILL NOT

RUN UNLESS THE REMOVABLE TRANSPARENT COVER IS ON SECURELY AND LOCKED INTO PLACE
WITH THE SAFETY LOCKING HANDLES.

ASSEMBLY

Before first use it is a good idea to familiarise yourself with the assembly/disassembly of the
unit.

ASSEMBLY

1. The appliance should be unplugged from the mains before assembly or disassembly.

2. Place the pulp container under the nozzle on the left of the machine. Place the juice

container under the nozzle on the right of the machine.

3. Attach the residue container onto the main body and clip the filter net into place.

4. Attach the top transparent cover and close and place the juicer stick in the food chute.

5. Make sure the housing unit is locked with the safety lockers in place by hooking them

onto the top cover and pushing them downwards until they clip in place.

6. The juicer will not work for safety reasons if the safety lockers are not locked in place

correctly.
DISASSEMBLY

1. Remove the juicer stick and the pulp and juice containers.

2. To remove the upper body pull both safety lockers outwards from the bottom. Release

and lift off the top cover.

3. Lift the filter net off by gently pulling upwards.

4. Lift of the Residue container.

SETTINGS

There are 2 settings 1 and 2
Setting 1 is low speed and is usually best for soft fruits such as plums and peaches (Please
remove the stone before trying to juice!)
Setting 2 is faster and is usually best for harder fruits such as apples and carrots.

PLEASE NOTE: There is a temperature safety device installed in the machine. If the machine
becomes too warm the machine will automatically shut down until the motor has cooled to the
correct temperature. (This usually takes about 15 minutes). To prevent this from happening
please do not use the machine continually for more than one minute at a time.
