Pride Mobility SC2000PS User Manual
Owner’s Manual
ATTENTION:
Please read the content
of your owners manual
before operating your
scooter.
®
The Ultimate In Style & Performance
Exeter, PA
St. Catharines, ON 1-800-800-8586
www.pridemobility.com
SAFETY GUIDELINES
The symbols below are used throughout this owner's manual and on the scooter to identify warnings and important
information. It is very important for you to read them and understand them completely.
WARNING! Indicates a potentially hazardous condition/situation that can cause personal
injury, equipment, and/or property damage (black symbol on yellow triangle with black
border).
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause injury to personnel and/or damage to equipment (white
symbol on blue dot).
PROHIBITED! These actions are prohibited; do not perform at any time or in any situation.
Performing a prohibited action can cause personal injury and/or equipment damage (black
symbol with red circle and red slash).
Please fill out the following information for quick reference:
Pride Provider:_______________________________________________________________________
Purchase Date:_______________________________________________________________________
Address:____________________________________________________________________________
Phone Number:_______________________________________________________________________
Serial Number:________________________________________________________________________
NOTE: This owners manual is compiled from the latest specifications and product information available at the time of publication. We reserve the right to make changes as they become necessary. Any
changes to our products may cause slight variations between the illustrations and explanations in this
manual and the product you have purchased.
Copyright ©2005
Pride Mobility Products Corp.
INFMANU2915/Rev A/May 2005
CONTENTS
I. INTRODUCTION ......................................................................................................................... 4
II. SAFETY ......................................................................................................................................... 5
III. EMI/RFI ........................................................................................................................................ 14
IV. SPECIFICATIONS ................................................................................................................... 15
V. YOUR SCOOTER ...................................................................................................................... 17
VI. BATTERIES AND CHARGING ............................................................................................ 21
VII. OPERATION ............................................................................................................................... 25
VIII. COMFORT ADJUSTMENTS................................................................................................ 27
IX. DISASSEMBLY AND ASSEMBLY ..................................................................................... 30
X. BASIC TROUBLESHOOTING ............................................................................................. 33
XI. CARE AND MAINTENANCE ................................................................................................ 35
XII. WARRANTY ............................................................................................................................... 37
Sundancer www.pridemobility.com 3
I. INTRODUCTION
SAFETY
WELCOME to Pride Mobility Products Corporation (Pride). The product you have purchased combines stateof-the art components with safety, comfort, and styling in mind. We are confident the design features will provide
you with the conveniences you expect during your daily activities. Understanding how to safely operate and care
for this product should bring you years of trouble free operations and service.
Read and follow all instructions, warnings, and notes in this manual and all other accompanying literature before
attempting to operate this product for the first time. In addition, your safety depends upon you, as well as your
provider, caretaker, or healthcare professional in using good judgement.
If there is any information in this manual which you do not understand, or if you require additional assistance for
setup or operation, please contact your authorized Pride Provider. Failure to follow the instructions, warnings,
and notes in this manual and those located on your Pride product can result in personal injury or product
damage and will void Prides product warranty.
PURCHASER’S AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter, or modify this product or remove
or render inoperable or unsafe any guards, shields, or other safety features of this product; fail, refuse, or neglect to
install any retrofit kits from time to time provided by Pride to enhance or preserve the safe use of this product.
INFORMATION EXCHANGE
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about
the safety and reliability of your new scooter, and about the service you received from your authorized Pride
Provider. Please notify us of any change of address, so we can keep you apprised of important information about
safety, new products, and new options that can increase your ability to use and enjoy your scooter. Please feel free
to contact us at the address below:
Pride Mobility Products Corporation
Attn: Customer Care Department
182 Susquehanna Ave.
Exeter, PA 18643-2694
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact
us and we will be glad to send you a new one immediately.
PRIDE OWNERS CLUB
As an owner of a Pride product, you are encouraged to enroll in the Pride Owners Club. Complete and return your
enclosed product registration card or visit Pride's web site at www.pridemobility.com.
From our home page, select Owners Club to enter a page dedicated to current and potential Pride product
owners. You will gain access to interviews, stories, recreation ideas, daily living tips, product and funding information, and interactive message boards. These message boards invite you to communicate with other Pride customers as well as Pride representatives who are available to assist you with any questions or concerns.
4 www.pridemobility.com Sundancer
II. SAFETY
GENERAL
MANDATORY! Do not operate your new scooter for the first time without completely reading
and understanding this owners manual.
Your scooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an extensive variety of products to best fit the individual needs of the scooter user. Please be aware that the final selection
and purchasing decision regarding the type of scooter to be used is the responsibility of the scooter user who is
capable of making such a decision and his/her healthcare professional (i.e., medical doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted the
scooter to the user and has assisted the prescribing healthcare professional and/or the authorized Pride Provider in
the instruction process for the use of the product.
There are certain situations, including some medical conditions, where the scooter user will need to practice
operating the scooter in the presence of a trained attendant. A trained attendant can be defined as a family member
or care professional specially trained in assisting a scooter user in various daily living activities.
As you begin using your scooter during daily activities, you will probably encounter situations in which you will
need some practice. Simply take your time and you will soon be in full and confident control as you maneuver
through doorways, on and off elevators, up and down ramps, and over moderate terrain.
Below are some precautions, tips, and other safety considerations that will help the user become accustomed to
operating the scooter safely.
MODIFICATIONS
Pride has designed and engineered your scooter to provide maximum mobility and utility. However, under no
circumstances should you modify, add, remove, or disable any feature, part, or function of your scooter.
WARNING! Do not modify your scooter in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your scooter.
REMOVABLE PARTS
WARNING! Do not attempt to lift or move your scooter by any of its removable parts.
Personal injury and damage to the scooter may result.
Sundancer www.pridemobility.com 5
II. SAFETY
PRE-RIDE SAFETY CHECK
Get to know the feel of your scooter and its capabilities. Pride recommends that you perform a safety check before
each use to make sure your scooter operates smoothly and safely.
Perform the following inspections prior to using your scooter:
n Check for proper tire inflation (if equipped with pneumatic tires).
n Check all electrical connections. Make sure they are tight and not corroded.
n Check all harness connections. Make sure they are secured properly.
n Check the brakes (freewheel lever in drive mode).
n Check battery charge.
If you discover a problem, contact your authorized Pride Provider for assistance.
TIRE INFLATION
If your scooter is equipped with pneumatic tires, you should check or have the air pressure checked at least once
a week. Proper inflation pressures will prolong the life of your tires and help ensure the smooth operation of your
scooter.
WARNING! It is critically important that 30-35 psi tire pressure be maintained in pneumatic
tires at all times. Do not underinflate or overinflate your tires. Low pressure may result in
loss of control, and overinflated tires may burst. Failure to maintain 30-35 psi tire pressure
in pneumatic tires at all times may result in tire and/or wheel failure, causing serious
personal injury and/or damage to your scooter.
WARNING! Inflate your scooter tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting
in a burst tire and/or personal injury.
WEIGHT LIMITATIONS
Your scooter is rated for a maximum weight capacity. Refer to the specifications table for information.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal
injury and damage to your scooter. Pride will not be held responsible for injuries and/or
property damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your scooter. Carrying passengers may result in
personal injury and/or proper ty damage.
INCLINE INFORMATION
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe access.
Some ramps may have turning switchbacks (180-degree turns) that require you to have good cornering skills on
your scooter.
n Proceed with extreme caution as you approach the downgrade of a ramp or other incline.
n Take wide swings with your scooter around any tight corners. If you do that, the scooters rear wheels will
follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing corners.
n When driving down a ramp, keep the scooters speed adjustment set to the slowest speed setting to ensure a
safely controlled descent.
n Avoid sudden stops and starts.
6 www.pridemobility.com Sundancer
II. SAFETY
When climbing an incline, try to keep your scooter moving. If you must stop, start up again slowly, and then
accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the slowest
setting and driving in the forward direction only. If your scooter starts to move down the incline faster than you
anticipated or desired, allow it to come to a complete stop by releasing the throttle control lever. Then push the
throttle control lever forward slightly to ensure a safely controlled descent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the
incline. Drive your scooter straight up the incline. This greatly reduces the possibility of a
tip or a fall. Always exercise extreme caution when negotiating an incline.
WARNING! Do not drive your scooter across the side of an incline or diagonally up or down
an incline; do not stop, if possible, while driving up or down an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas
covered with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the scooter in freewheel
mode while seated on it or standing next to it.
WARNING! Even though your scooter is capable of climbing slopes greater than those
illustrated in figure 1, do not, under any circumstances, exceed the incline guidelines or
any other specifications presented in this manual. Doing so could cause instability in your
scooter, resulting in personal injury and/or damage to your scooter.
Handicap public access ramps are not subject to government regulation in all countries, and therefore do not
necessarily share the same standard percent of slope. Other inclines may be natural or, if man-made, not designed
specifically for scooters. Figures 1 illustrates your scooters stability and its ability to climb grades under various
weight loads and under controlled testing conditions.
These tests were conducted with the scooters seat in the highest position and adjusted rearward on the seat base
to its farthest rearward position. Use this information as a guideline. Your scooters ability to travel up inclines is
affected by your weight, your scooters speed, your angle of approach to the incline, and your scooter setup.
150-200 lbs
9˚ (15.8%)
Figure 1. Maximum Recommended Incline Angles
WARNING! Any attempt to climb or descend a slope steeper than that shown in figure1
may put your scooter in an unstable position and cause it to tip, resulting in personal
injury.
250-300 lbs
8˚ (14.1%)
WARNING! Never carry an oxygen tank weighing more than 15 lbs. Never fill the rear
basket with contents exceeding 15 lbs.
Sundancer www.pridemobility.com 7
II. SAFETY
When you approach an incline, it is best to lean forward. See figures 2 and 2A. This shifts the center of gravity of
you and your scooter toward the front of the scooter for improved stability.
NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the
powered scooter may "rollback" approximately 1 foot before the brake engages. If the throttle control
lever is released while moving in reverse, the powered scooter may "rollback" approximately 3 feet
before the brake engages.
Figure 2. Normal Driving Position
Figure 2A. Increased Stability Driving Position
CORNERING INFORMATION
Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility of
tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning), uneven road
surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction (such as passing from
a grassy area to a paved area especially at high speed while turning), and abrupt directional changes. High
cornering speeds are not recommended. If you feel that you may tip over in a corner, reduce your speed and
steering angle (i.e., lessen the sharpness of the turn) to prevent your scooter from tipping.
WARNING! When cor nering sharply, reduce your speed. When using your scooter at higher
speeds, do not corner sharply. This greatly reduces the possibility of a tip or fall. To avoid
personal injury or property damage, always exercise common sense when cornering.
BRAKING INFORMATION
Your scooter is equipped with these powerful brake systems:
n Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the center/
stop position.
n Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or when
power is removed from the system for any reason.
8 www.pridemobility.com Sundancer
II. SAFETY
OUTDOOR DRIVING SURFACES
Your scooter is designed to provide optimum stability under normal driving conditionsdry, level surfaces composed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you will encounter other surface types. For this reason, your scooter is designed to perform admirably on packed soil, grass, and
gravel. Feel free to use your scooter safely on lawns and in park areas.
n Reduce your scooters speed when driving on uneven terrain and/or soft surfaces.
n Avoid tall grass that can become tangled in the running gear and wrapped around the axle.
n Avoid loosely packed gravel and sand.
n If you feel unsure about a driving surface, avoid that surface.
PUBLIC STREETS AND ROADWAYS
WARNING! You should not operate your scooter on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your scooter. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with
extreme caution.
STATIONARY OBSTACLES (STEPS, CURBS, ETC.)
WARNING! Do not drive near raised surfaces, unprotected ledges, and/or drop-offs (curbs,
porches, stairs, etc.).
WARNING! Do not attempt to have your scooter climb or descend an obstacle that is
inordinately high. Serious personal injury and/or damage may result.
WARNING! Do not attempt to have your scooter proceed backward down any step, curb, or
other obstacle. This may cause the scooter to tip and cause personal injury.
WARNING! Be sure your scooter is traveling perpendicular to any curb you may be required
to ascend or descend. See figures 3 and 3A.
WARNING! Do not attempt to negotiate a curb that has a height greater than 2 in.
Figure 3. Correct Curb Approach Figure 3A. Incorrect Curb Approach
Sundancer www.pridemobility.com 9
II. SAFETY
INCLEMENT WEATHER PRECAUTIONS
Exposure of your scooter to inclement weather conditions should be avoided whenever possible. If suddenly
caught up in rain, snow, severe cold or heat while operating your scooter proceed to shelter at the earliest opportunity. Thoroughly dry your scooter before storing, charging, or operating your scooter.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces
can cause personal injury and/or damage to the scooter and electrical system. Maintain
and store your scooter in a dry and clean condition.
FREEWHEEL MODE
Your scooter is equipped with a manual freewheel lever that, when pushed down, allows the scooter to be pushed.
For more information about how to place your scooter into and out of freewheel mode, see V. Your Scooter.
WARNING! When your scooter is in freewheel mode, the braking system is disengaged.
n Disengage the drive motors only on a level surface.
n Ensure the key is removed from the key switch.
n Stand behind the scooter to engage or disengage freewheel mode. Never sit on a
scooter to do this.
n After you have finished pushing your scooter, always return it to the drive mode to lock
the brakes.
Failure to heed the above could result in personal injur y and/or damage to your scooter.
An added feature built into the scooter is push-too-fast protection which safeguards the scooter against gaining
excessive speed while in freewheel mode.
Push-too-fast operates differently depending on which of two conditions exists:
n If the key is switched off while in freewheel mode, the scooters controller activates regenerative braking
when the scooter is pushed faster than a maximum threshold which has been preprogrammed. In this case, the
controller is acting as a speed governor.
n If the key is switched on while in freewheel mode, you will encounter considerable resistance at any speed.
This prevents the scooter from gaining unwanted momentum should the manual freewheel lever inadvertently
be released while driving the scooter.
STAIRS AND ESCALATORS
Scooters are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! Do not use your scooter to negotiate steps or escalators. You may cause injury
to yourself and to others and/or damage your scooter.
DOORS
n Determine if the door opens toward or away from you.
n Use your hand to turn the knob or push the handle or push-bar.
n Drive your scooter gently and slowly forward to push the door open. Or drive your scooter gently and slowly
backwards to pull the door open.
10 www.pridemobility.com Sundancer
II. SAFETY
DOORS
n Determine if the door opens toward or away from you.
n Use your hand to turn the knob or push the handle or push-bar.
n Drive your scooter gently and slowly forward to push the door open. Or drive your scooter gently and slowly
backwards to pull the door open.
ELEVATORS
Modern elevators have a door edge safety mechanism that, when pushed, reopens the door(s).
n If you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or
allow the rubber door edge to contact the scooter and the door will reopen.
n Use care that pocketbooks, packages, or scooter accessories do not become caught in elevator doors.
LIFT/ELEVATION PRODUCTS
If you will be traveling with your scooter, you may find it necessary to use a lift/elevation product to aid in transportation. Pride recommends that you closely review the instructions, specifications, and safety information set forth
by the manufacturer of the lift/elevation product before using that product.
BATTERIES
In addition to following the warnings below, be sure to comply with all other battery handling information.
WARNING! Scooter batteries are heavy (refer to specifications table). Lifting weight beyond
your capacity could result in personal injury. If necessary, get someone physically able to
lift the scooter batteries for you.
WARNING! Battery posts, terminals, and related accessories contain lead and lead
compounds. Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery.
Charging a frozen battery may result in personal injury and/or damage to the battery.
WARNING! RED (+) cables must be connected to positive (+) battery terminals/posts. BLACK
(-) cables must be connected to negative (-) battery terminals/posts. Failure to connect
your battery harnesses in the proper manner may result in personal injury and/or damage
to your scooter. REPLACE cables immediately if damaged.
BATTERY DISPOSAL AND RECYCLING
If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag and call your authorized
Pride Provider for instructions on disposal. Your authorized Pride Provider will also have the necessary information
on battery recycling, which is our recommended course of action.
PREVENTING UNINTENDED MOVEMENT
WARNING! If you anticipate being seated in a stationary position for an extended period
of time, turn off the power. This will prevent unexpected motion from inadvertent throttle
control lever contact. Failure to do so may result in personal injury.
Sundancer www.pridemobility.com 11
II. SAFETY
MOTOR VEHICLE TRANSPORT
Currently, there are no standards approved for tie-down systems in a moving vehicle of any type to transport a
person while seated in a scooter.
Although your scooter may be equipped with a positioning belt, this belt is not designed to provide proper restraint
during motor vehicle transport. Anyone traveling in a motor vehicle should be properly secured in the motor vehicle
seat with safety belts fastened securely.
WARNING! Do not sit on your scooter while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your scooter and its batteries are properly secured when it is
being transported. Failure to do so may result in personal injury and/or damage to your
scooter.
SECUREMENT POINTS
Steel loops welded to the frame of your scooter provide securement points. These should only be used with an
unoccupied scooter and secured by an approved securement system in accordance with the manufacturers instructions. Pride makes no representation of suitability for use with specific securement systems nor can we anticipate the various situations that might arise in use of public transportation systems. For detailed instructions on the
use of securements refer to the applicable municipal transit authority and/or manufacturer of the system used.
WARNING! DO NOT leave the scooter in freewheel mode when tieing it down for transport.
WARNING! DO NOT use your scooter as a seat in a moving vehicle.
GETTING ONTO AND OFF OF YOUR SCOOTER
Getting onto and off of your scooter requires a good sense of balance. Please observe the following safety tips
when getting onto and off of your scooter:
n Remove the key from the key switch.
n Ensure that your scooter is not in freewheel mode. See V. Your Scooter.
n Make certain that the seat is locked into place and the key is removed from the key switch.
n Pivot the armrests up to make getting onto and off of the scooter easier.
WARNING! Position yourself as far back as possible in the scooter seat to prevent the
scooter from tipping and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause
the scooter to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the
scooter to tip and cause personal injury.
12 www.pridemobility.com Sundancer
Loading...
