Pride Mobility R4 fo etad eht morf shtnom 42 rof detnarraw era sriahcrewoP
purchase on side frames and crossbars.
(NB Batteries are warranted for 12 months.)
•
During the warranty period any parts that have become defective due to faulty
workmanship or material will be repaired or replaced without charge by Pride
Mobility supplier/dealer
•
The warranty excludes tyres, punctures and items that become worn due to normal
wear and tear such as upholstery and armrest pads
•
The warranty excludes all items that have been subject to undue wear and tear and
misuse
•
Unauthorised changes or modifications will forfeit your warranty
•
If a defect or fault is discovered, the Pride Mobility supplier/dealer from whom the
Wheelchair was purchased should be notified immediately
The warranty does not extend to the consequenti
al costs resulting from fault clearance,
in particular freight and travel costs, loss of earnings, expenses, etc.
The manufacturer will not accept responsibility for any damage or injury caused by
misuse or non-observance of the instructions set out in this user manual.
Pride Mobility Products Australia Pty. Ltd.
21 Healey Road Dandenong Victoria, 3175 Australia
Tel: (03)9706 4611．Fax: (03)9706 4622
E-mail: prideaustralia@pride-mobility.com.au
www.pridemobility.com
Pride Mobility Products Australia Pty. Ltd. reserves the right to change the specifications without prior notice.
Dealer Stamp
R4
Folding Powerchair
R4
USER MANUAL
R4(C650PW)
User Manual
- 2 -
- 25 -
Pride Mobility R4 Power Chair
Manufactured by Taiwan Armada Enterprise Co., Ltd.
Address: No. 140, Kung-Yeh 11th Road, Da-Li Industrial Zone, Da Li City, Taichung Hsien, Taiwan R.O.C.
- 24 -
Notes:
- 3 -
User Manual
Pride Mobility R4 Power Chair
Kerb Climber
- 4 -
Welcome to the Pride Mobility R4 Powerchair and thank you for choosing
our product. This latest model has been designed with specific practical user
needs in mind. It combines solid, rugged construction and high-tech electronics,
safety and performance.
This manual contains some useful tips and information on safet
y, operation and
maintenance. Please read it carefully to ensure that you get maximum enjoyment
and benefit from your new independence and mobility.
Whenever you require special advice and attention do not hesitate to contact your
local Pride Mobility dealer. equipment and know-how to provi
de eht lla
an expert service and assistance on
The R4 Powerchairs are intended to assist and improve mobility for those
individuals who are less able or have walking difficulties who wish to maintain
their independence and freedom.
Your day to day activities will depend on your physical capabilities and your own
specific circumstances. If in doubt seek medical advice first.
The information is this booklet provides a general guide on how to use
your chair
safely and correctly. Do not use the chair without reading this manual first.
As a Powerchair use
r you must be aware of the risks involved to both yourself
and others. We recommend that you take out ‘Third Party Liability’ insurance to
cover you against any possible claims. Advice and policies are available from
general insurance companies or alternatively ask Pride Mobility dealer/supplier
for details.
Although by law you are not required to hold a driving licence you are responsible and fully liable for proper operation and use of your Powerchair. You must
ensure that
your chair is
maintained and is in a good condition at all times.
- 23 -
INSTRUCTIONS FOR DISPOSAL
TO FUNCTION ECONOMICALLY.
THE EQUIPMENT MUST BE DISPOSED OF IN A PROPER MANNER.
•
THE PRODUCT AND /OR ITS COMPONENTS ARE NOT TO ENTER THE SYSTEM OF LANDFILL SITES.
•
THE PRODUCT AND/OR ITS COMPONENTS ARE NOT TO BE DISPOSED OF IN DOMESTIC HOUSEHOLD WASTE.
•
THE ELECTRICAL AND MATERIAL PARTS ARE TO BE DISPOSED
OF AS SCRAP OR RECYCLING MATERIALS.
•
LOCAL WASTE COLLECTION DEPOTS ARE AVAILABLE TO
ADVISE AND DISPOSE OF ELECTRICAL PRODUCTS.
•
BATTERIES WHICH CONTAIN LIQUID ACID MUST BE STORED
AND DISPOSED OF SEPERATELY AT THESE DEPOTS.
•
PLEASE ENQUIRE ABOUT DISPOSAL DEPOTS WITH YOUR
LOCAL AUTHORITY.
•
SHOULD YOU REQUIRE FURTHER ADVICE, PLEASE CONTACT
YOUR SUPPLIER OR NEAREST DEALER.
User Manual
Pride Mobility R4 Power Chair
They have
technical and clinical applications to suit
particular need. your
INSTRUCTIONS ARE GUIDELINES FOR THE DISPOSAL THE FOLLOWING
OF YOUR PRODUCT AT THE END OF ITS LIFE OR WHEN IT CEASES
- 5 -
User Manual
Pride Mobility R4 Power Chair
The Powerchair is a type ‘B’ indoor/outdoor vehicle with a
.dedeecxe eb reven tsum hcihw ) 352( gk 511 fo yticapac gniyrrac mumixam
It has a maximum speed of 6.5 km/h (4 mph) and is classified as an
‘Invalid
Carriage’ eerf saera dna senoz nairtsedep ,shtaptoof ,stnemevap no ,sroodni esu rof
from motor traffic. Use on the road or highway is not allow
ed except for the
purp
ose of crossing .
Folding Backrest
Battery Box
Rear Wheel
Front Castor
K
(optional)
erb Climber
Footrest
Adjustable Height
Armrest
Joystick Control
Pride Mobility R4
lbs
Obstacle Ability (optional)
17km (10 miles)
- 6 -
Do not use on the road, except when crossing between pavements. When
crossing the carriageway of a public road always take extra care and observe
the Highway code
Do not turn off the controls by switching the ON/OFF button when moving at
speed. This will bring the brakes on immediately and could cause damage to
the controls
Do not ride over deep, soft terrain (soft dirt, loose gravel, deep g
rass)
Do not attempt to mount a kerb higher than specified
Do not carry passengers
Do not sit in your Powerchair if the unit is in freewheel mode
We recommend that y
ou do not sit on your Powerchair when in a vehicle, but
transfer to a vehicle seat
Always stop before making a sharp change of direction
Always engage a slow speed when going down gradients
Do not use the joystick in an erratic manner
when going up or down an incline
Do not drive in reverse down a slope or kerb
Always keep your feet on the footplate when moving
Do not stand on the footplate when getting in or out of the chair
Do not expose the Powerchair to direct rain or high humidity (i.e. in the bath-
room) as it may c
ause it to malfunction (electrically or mechanically)
We recommend the use of safety belt
Always keep your pn
eumatic tyres to the correct pressures
Always make sure that the batteries are sufficiently charged before setting out
on a journey
Do not use parts, accessories or adapters other then those authorised by Pride
Mobility Products Australia Pty. Ltd.
Keep the Powerchair away from children. It is not intended to be used as a toy
The manual parking brakes are not designed for slowing-down
- 21 -
The following information is intended to assist in the location of a fault that may
occur in a certain part of your Powerchair’s electronics. Go to the number in the
list which matches the number of flashing bars and follow the instructions.
If the problem persists after you made the checks described below contact your
dealer. Do not use the Powerchair and turn-off the power.
1 Bar The battery needs charging or there is a bad connection to the battery.
Check the connections to the battery. If the connections are good, try
charging the battery
2 Bar The left hand motor has a bad connection. Check the connections to the
left hand motor
3 Bar T
he left hand motor has a short circuit to a battery connection. Contact
your service agent
4 Bar The right hand motor has a bad connection. Check the connections to the
right hand module
5 Bar The right hand motor has a short circuit to a battery connection. Contact
your dealer
6 Bar The Powerchair is being prevented form driving by an external signal.
The exact cause will depend on the type of Powerchair you have, one
possibility is the battery charger is connected
7 Bar A joystick fault is indicated. Make sure th
at the joystick is in th
e center
position before switching on the control system
8 Bar A control system fault is indicated. Make sure that all connections are
secure
9 Bar The parking brakes have a bad connection. Check the parking brake and
motor connections. Make sure the control system connections are secure.
10 Bar An excessive voltage has been applied to the control system. This is
usuall
y caused by a poor battery connection. Check the battery connec-
tions
User Manual
Pride Mobility R4 Power Chair
- 20 -
We recommend that your Powerchair is serviced by your local dealer every six
months. It is in your best interests, not only to ensure your personal safety but
also to ensure long life and reliability. Regular service will identify early damage
and worn components avoiding unnecessary faults occurring.
•
Check all connectors are secure properly, properly mated and free from damage
•
Castor bolts are tight and all fasteners are secure
•
Adjustable height arms operate and lock securely
•
The drive wheels mounting bolts are secure and there is no excessive side
movement or binding when spun
•
Tyres do not show excessive wear or damage
•
Castors for proper tension, i.e. spinning castors should come to gradual stop
•
Check joystick gator around the base of the joystick for damage or splitting
•
Motor parking brakes function correctly
•
The chair rolls straight (no excessive drag or pull to one side)
•
Pivot points are free of wear or looseness
•
Seat and backrest upholstery is not for ripped or sagging
•
Frames are not worn or bent
Paintwork and plastic mouldings can be cleaned with a damp soft cloth of warm
soapy water. Do not use any ha
rsh abrasive cleaners, bleach base fluids or
solvents.
Seat and back upholstery can be cleaned with a general purpose upholstery
cleaner or sponged with warm soapy water.
- 7 -
When using indoors beware of narrow doors, steps, high surfaces, protruding
wall fittings and everyday household items such as children’s toys, electrical
appliances etc. Take extra care in kitchen environments.
To ensure stability and safe control you must maintain proper balance at all
times. The Powerchair is designed to remain stable during normal use as long as
When reaching/bending forward do not lean your body out of the Powerchair further
than the length of the armrests. Do not attempt to reach objects by sliding forwards to
the edge of th
e seat.
When reaching/bending backwards do not reach any further than your arm will
extend without changing your seating position.
Never attempt to use an escalator or stairway, always use a lift.
Occasionally check that the adjustments of the footrests, armrests and controller
are secure and are set in the most comfortable position for use.
void use in rain, to avoid the possibility of water penetration into the
electrically operated equipment.
Powerchairs may be susceptible to ele
ctromagnetic interference (EMI) which is
energy emitted from s
ources such as radio stations, TV stations, two-way radio,
and cellular phones.
Avoid coming into close contact to them whilst the Powerchair is turned-on.
Switch off immediately to avoid possible abnormal, erratic movement and control
of your Powerchair.
User Manual
Pride Mobility R4 Power Chair
A
.noitisop gnitaes lamron eht edistuo ytivarg fo ertnec ruoy evom ton od uoy
User Manual
- 8 -
Using the hexagon key provided, remove the screw, nut
and bush on the footrest outer tube.
Slide the footrest inner tube up or down to the required
height and secure in place with the screw and nut,
ensuring the bush is in the larger hole in tube work and
clamped in place underneath the nut.
Note - The height adjustment screw must always be fitted through one of the
holes in the body of plastic support moulding.
Under the armrest pad is a plastic hand knob. Unscrew to remove and set armrest
to the required height. To secure, screw in hand knob into the nearest hole and
tighten.
The backr
est tubes slide into the rear tube of each side frame through which 4
screws pass holding the armrest and battery box support brackets.
To adjust the backrest, remove these 4 screws and adjust to the required height
and refit screws to secure.
Hold the bayonet end in one hand, and pull on the webbing to increase or
decrease belt length with the other. When length is correct, adjust slide buckle to
suit.
- 19 -
CAUTION! -
•
The charger is for indoor use only
•
Do not use an open flame whilst batteries are being charged
•
Do not use the battery charger if it has been dropped or misused as damage to
the electronics could occur
•
Do not leave the charger plugged in the mains supply and switched-off. Always remove the plug
The battery gauge works in the following way:
Located on the control box, the battery gauge has three colour bars:
When you switch on the control system, the battery gauge shows an estimate of
the remaining battery charge.
If the battery shows red, yellow and green, the batteries are charged.
If the battery shows just red and yellow, then you should charge the batteries as
soon as you can.
If the bat
tery gauge shows just red, either steady or flashing slowly, then you
should charge the batteries immediately.
At ful
l charge all ten lights will be on. As the battery charge drops during
Powerchair operation successive bars will extinguish. Except in emergency, do
not drive on discharged batteries. If you ignore the warning (the bottom bars
flashing) and the battery charge drops further to a level where there is no longer
sufficient charge to allow safe driving, the controller will automatically cut the
po
wer supply to the mot
ors and the power chair will come to abrupt stop.
(optional)
Pride Mobility R4 Power Chair
- 18 -
The Powerchair is supplied with two sealed deep cycle, maintenance free
batteries. These are fitted under the seat in the centre of the Powerchair. For easy
handling, Velcro carrying straps are provided to assist in fitting or removal.
These batteries are different from ordinary car batteries and should be charged
with the charger specifically for this type and make of battery.
CAUTION! - Using incorrect battery size and/or voltage may cause damage to
the Powerchair and have an adverse effect on the performance
specifications.
To ensure long battery
life, do not allow the batteries to become totally
discharged. If the Powerchair is not used for a length of time the batteries must
receive a full charge once a month and remain fully charged during storage.
The battery charger supplied with your Powerchair is fitted with an automatic
electronic switch that terminates the charge when the batteries are fully charged.
To avoid reducing battery life always fully charge new batteries before initial
use. Please note that the batteries will not perform to their peak until first six to
ten charging cycles have be
en completed.
The front panel of the battery charger has two lights - red and green. Steady red
light indicates that charger is on from the mains and is ready to charge. Flickering
red light signifies incorrect or bad connection. The other light is yellow/orange
when charging, which turns to green when charging is complete.
To re-charge the batteries, connect one end of the battery charger power cord to
the c
harging socket and the other end to a 3-pin grounded wall outlet and switch
on at the mains.
Do not sw
itch off or interrupt the charging cycle before charging is complete
(typically from 8 to 12 hours depending on depth of discharge).
When charging is complete always disconnect from the main supply first fol-
lowed by unplugging the charger from the chair.
The charger also has its own ON/OFF switch located in the opposite end to the
two-way display lights. Ensure this is switched on to charge your batteries.
- 9 -
The control box can be adjusted so that it is in a convenient position for use. To
adjust the unit forward and backwards immediate underneath the armrest pad
there is a hand knob which when loosened allows the horizontal tube to be adjusted to the required position.
To adjust the unit vertically, there is a hexagon key screw in a hexagon nut attached to the tubular construction supporting the control box. Using the hexagon
key provided loosen the screw, adjust unit to the required height and re-tighten
screw to secure.
Control box conversions to left hand
1) Remove control box and horizontal tube from right hand arm by releasing
hand knob and hexagon screw
2) R
emove the two screws holding the support tube to the control box and ro-
tate the tube through 180° to th
e opposite side and secure to the control box
with the screws
3) Remove both armrest pads by removing the securing hand knobs. Both pads
are right and left handed
4) To convert to opposite hands remove support brackets from pads and rotate
through 180° and align with opposite screw holes and re-secure with screws
5) Secure the original right hand armrest to the left hand arm and repeat for the
oth
er hand
6) Re-position control box unit to left hand side of chair and assemble and
secure to left hand arm
7)
Adjust heights and position as previous paragraphs
User Manual
Pride Mobility R4 Power Chair
- 10 -
Your Powerchair is fitted with the latest up to date electronic controls. The
control box is normally fitted to the right side of the chair.
Switch on your power chair with the ON/OFF Button. When the chair is turned
on the battery level indicator lamp lights up. This also can be used as a fault finding guide.
The Powerchair is ready for use if the green or orange battery level indicat
or bars
are illuminated. The range of the chair is relative to the number of bars lit, as they
show how much charge is left in the batteries. A true reading will only be taken
when the power chai
r is stationary. When only the red bars are illuminated, do
not use the Powerchair and charge the batteries.
The joystick controls the speed and direction of the Powerchair. The further the
joystick is mov
ed from its central location the faster the Powerchair will move in
the direction the joystick is pushed. To slow down, guide the joystick towards its
central position.
For your first drive choose an area with plenty of space to drive your Powerchair
and select the low
speed setting until you are familiar with the controls. In a short
time you will be in total control and can then increase the spe
ed.
M
ove the joystick gently forward. The more you push the joystick forward the
faster you will travel, but you will not exceed the speed limit imposed by the
speed control knob, regardless of the joystick position.
To reverse, pull the joy-stick to the rear, beyond its centre (neutral) position. The
joystick is also your steeri
ng lever. Move it to the left and you will turn left.
Move it to the
right a
nd you will turn right.
When you want to stop or have to make an emergency brake application, simply
release the joy- stick. It will automatically return to the centre (neutral) position.
At this moment the brakes of the electric motors will cut in and bring the Powerchair smoothly to a standstill.
Once the Powerchair is at a standstill, it is automatically locked in its parking
positio
n by the electromagnetic safety brake system. If you intend to remain
parked for any l
ength of time, or you are leaving the Powerchair switch off the
controller to avoid accidentally moving the joystick, which would release the
braking system.
- 17 -
We recommend that you do not sit on your Powerchair when in a vehicle, but
transfer to a vehicle seat. A Powerchair secured in a vehicle will not provide the
equivalent safety level and security as the vehicle’s seating systems.
However, when transfer is not practical or impossible, ensure the following:
1) Check that the vehicle is suitably designed, insured and equipped to transport
a passenger
seated in a Wheelchair
2)
Remove any part of the Wheelchair (accessories, etc.) that can be easily detached
and store it in the v
ehicle’s luggage hold
3) Make
sure the Wheelchair is transported in a forward facing direction. Rearward
facing is only acceptable if the passenger’s head and back can be supported by a
suitable bulkhead
4) Use the buckle seat belt (if fitted) with your chair as addition
al restraint
We recommend that the powerchair is secured within the vehicle using the 4point webbing tie-down system with Karibiner, model no WWR/ATF/K/R
(available from Unwin Safety Systems based in Yeovil, U.K.)
Note: Although safety dur
ing transportation largely depends upon the diligence
of the person securing the tie-downs and passenger restraints it is the user’s re-
sponsibility
to ensure that the powerchair has been safely secured.
User Manual
Pride Mobility R4 Power Chair
- 16 -
To push the Powerchair by hand or in the event of a fault or
battery failure the motors/gear boxes can be released allowing
the Powerchair to be pushed.
The levers should be switched to the freewheel position. On
the gearbox by rotating them through 90° . Use the manual
brakes to park the chair.
CAUTION! - Always re-engage the freewheeling device after
use. Failure to do so may result in injury
Regularly check the condition of front and rear tyres for wear and tear. Contact
your supplier for replacements. Your Powerchair may have split rim wheels
which are held toge
ther by screws or bolts. When these are removed the wheel
rim separates
for easy access to carry out puncture repairs or tyre replacements.
If you have pneumatic tyres fitted, the pressure indicated on the side of the tyre
wall should not be exceeded.
Your Powerchair can be disassembled and folded for storage:
1) Fold the two footrest plates upwards
2) Remove kerb climber unit (if fitted)
3) Disconnect plug and socket between battery boxes and remove rear box
4) Pull to slide front box and disconnect main loom plug and socket. Remove
second battery box
5) Pull the rings of the four release pins holding th
e battery suppor
t basket in
place. Remove basket.
6) Using both hands, grip front and rear of the seat upholstery and pull up to
fold the chair
7) To unfold the chair, place each hand on both seat tubes and push down-
ward firmly. Lock the front and rear release pins to secure battery basket in
place. Slide batteries into position and reconnect
Drive mode
Freewheel mode
- 11 -
This is a 10 segment display which indicates control unit in ON/OFF
mode and also displays state of charge of the battery.
Additionally, any faults in Powerchair electric system are indicated.
See Troubleshooting Guide for details.
This button turns the unit on and off
Do not use this button to stop the Powerchair, except in an extreme
emergency
This button operates the warning horn
This button decreases the chairs speed setting or a lower drive profile
This button increases the chairs speed setting or a higher drive profile
This is a 1 to 5 light display which indicates your speed setting. 1 light
indicates minimum, up to 5 lights indicating maximum.
User Manual
Pride Mobility R4 Power Chair
Battery Gauge
Speed Profile Indicator
Speed Increase Button
Speed Decrease Button
Horn Button
ON/OFF Button
Joystick rol Unit
Cont Panel Unit
Control
- 12 -
The battery gauge and maximum speed /profile indicator show the status of the
control system.
Battery Gauge is Steady
This indicates that all is well.
Battery Gauge Flashes Slowly
The control system is functioning correctly, but you should charge the battery
as soon as possible.
Battery Gauge Steps Up
The Powerchair batteries are being charged. You will not be able to drive
t
he Powerchair until the charger is disconnected and you have switched the
control system off and on again.
Battery Gauge Blinks Once Every 2.5 Seconds
The control system has “gone to sleep” because the Powerchair has not
been driven for a period of ti
me. To re-start, switch the system off and on
again.
Battery Gauge Flashes Rapidly (even with the joystick released)
The control system
safety circuits have operated and the control system
has been prevented from moving the Powerchair.
This indicates a problem somewhere in the Powerchair’s electrical system.
Please follow this procedure:
• Switch off the control system.
• Make sure that all connectors on the Powerchair and the control system
are mated securely.
• Check the condition of the battery.
• If you can’t find the problem, try using the Troubleshooting Guide
• Switch on the control sys
tem again and try to drive the Powerchair. If the
safety circuits operate again, switch off and do not try to use the Power chair. Contact your dealer.
- 15 -
You can stop at any time while you are climbing or descending. Simply release the
joy-stick as on the flat. The electromagnetic safety brake will ensure that the
Powerchair is positively locked and secured in parking position until you are ready
to continue your journey.
These are fitted at the rear of the chair, adjacent to the rear drive wheels and must
be fitted at all times when driving outd
oors. Especially when climbing kerbs and
gradients.
This is attached at the front of the chair from one side frame to the other. The centre
climbing shoe is set at 40 mm clearance and is designed to lift the front of the chair
over a kerb higher than this as you drive forward, returning to its original position
due to its spring action.
Approach the kerb head-on slowly. Shortly before the front
wheels make
contact
with the kerb push the joystick fully forward for maximum power.
Do not allow the power chair to come to a halt midway through manoeuvre. If pos-
sible, use gentle upper body movement to assist motion.
CAUTION! - Ensure all wheels have mounted the kerb before changing direction.
When climbing kerbs you will find that your Powerchair will smoothly overcome
the kerb without the need for drastic speed variations.
Circumstances and individual needs will vary from person to person, but if there
are difficulties we advi
se you to consult your therapeutic adviser who will help to
develop your skill for appropriate transfer method that
ments.
During transfer always make sure that the brakes are in a locked position and the
Powerchair is manoeuvred as close as possible to the transfer seat.
If your chair stops for no apparent reason, it is probably due to the circuit breaker.
The circuit breaker can be located on the top of each battery box. On rare occasions, it happens that there is a temporary overload on the electric circuit. If this
occurs, the circuit breaker but
ton will pop out. To reset, turn the key to the OFF
position, press circuit breaker button and then turn the key to the ON position.
User Manual
Pride Mobility R4 Power Chair
1.
2.
3.
4.
5.
-eriuqer laudividni ruoy stius
- 14 -
Your footrests are capable of being rotating inwards and outwards. To achieve this pull the release lever towards you and
rotate footrest in the required direction. Lift-off from upper
pivot point to remove.
Both armrests are swing-back detachable. To operate, push
the release lever forwards to unclip, and lift arm out of front
socket
This is an additional brake which is applied manually to the tyres when the chair
is parked in free wheel or in storage. To apply the brake, push the lever forwards
until the shoe is locked in place. Pull backwards to release.
This is available to reduce the overall height of the chair.
Whilst at
the rear of the chair, grip the small lever and push
down to release pin allowing the handle section to be folded.
The Powerchair has climbing power that
enables you to
overcome gradients of up to 12° (1:5).
Always approach an incline directly, not at an angle, and follow it
up or down directly avoiding zigzag movement.
CAUTION! - Never attempt to climb or descend an incline
which has a slippery or icy surface.
While going uphill or downhill there is no need for drastic corrective joystick movements. The electronic controller ensures
th
at the extra power required for climbing is automatically ap-
plied to the m
otors, so that the selected speed is maintained. This
is achieved by the micro-computer of the electronic controller compensating
automatically for any extra power required.
The same applies when you travel downhill. The electromagnetic safety brake
gives you full control over your Powerchair at all times. This unique brak
e sys-
tem enables you to descend at a constant slow speed.
BE CAREFUL
- 13 -
The VR2 control system can be locked to prevent unauthorised use. The locking
method is via a sequence of key presses and joystick movements, as detailed
below: -
1) While the control system is switched on, depress and hold the on/off button
2) After 1 second the control system will bleep. Now release the on/off button
3) Deflect the joystick forwards until the control system bleeps
4) Deflect t
he joystick in reverse until the control system bleeps
5) Release the joystick, there will be a long bleep
6) The wheelchair is now locked
1) Use the on/off button to switch the control system on. The maximum speed /
profile i
ndicator will be rippling up and down
2) Deflect the joystick forwards until the control system bleeps
3) Deflect the joystick in reverse until the control system bleeps
4)
Release the joystick, there will be a long bleep
5) The wheelchair is now unlocked
User Manual
Pride Mobility R4 Power Chair
Loading...
