Pride Mobility PMV5000 User Manual
Owner’s Manual
®
The Ultimate In Style & Performance
Exeter, PA
St. Catharines, ON 1-800-800-8586
www.pridemobility.com
SAFETY GUIDELINES
Please read and follow all instructions in this owners manual before attempting to operate your Hurricane PMV
for the first time. If there is anything in this manual you do not understand, or if you require additional assistance for
setup, contact your authorized Pride provider.
Using your Pride product safely depends upon your diligence in following the warnings, cautions, and instructions
in this owners manual. Using your Pride product safely also depends upon your own good judgement and/or
common sense, as well as that of your provider, caregiver, and/or healthcare professional. Pride is not responsible
for injuries and/or damage resulting from any persons failure to follow the warnings, cautions, and instructions in
this owners manual. Pride is not responsible for injuries and/or damage resulting from any persons failure to
exercise good judgement and/or common sense.
The symbols below are used throughout this owners manual to identify warnings and cautions. It is very important
for you to read and understand them completely.
WARNING! Failure to heed the warnings in this owners manual may result in personal injury.
CAUTION! Failure to heed the cautions in this owners manual may result in damage to your
Hurricane PMV.
Copyright ©2003
Pride Mobility Products Corp.
INFMANU1035
CONTENTS
I. INTRODUCTION ......................................................................................................................... 4
II. SAFETY ......................................................................................................................................... 6
III. EMI/RFI ........................................................................................................................................ 15
IV. SPECIFICATIONS ................................................................................................................... 17
V. YOUR HURRICANE PMV ...................................................................................................... 19
VI. BATTERIES AND CHARGING ............................................................................................ 25
VII. OPERATION ............................................................................................................................... 29
VIII. COMFORT ADJUSTMENTS................................................................................................ 31
IX. DISASSEMBLY AND ASSEMBLY ..................................................................................... 34
X. OPTIONAL ACCESSORIES ................................................................................................. 37
XI. BASIC TROUBLESHOOTING ............................................................................................. 38
XII. CARE AND MAINTENANCE ................................................................................................ 40
XIII. WARRANTY ............................................................................................................................... 42
Hurricane PMV/RevK/Mar03 www.pridemobility.com
3
I. INTRODUCTION
Welcome to Pride Mobility Products Corporation (Pride). Congratulations on the purchase of your new Pride
Personal Mobility Vehicle (PMV). Your Hurricane PMV design combines the most advanced state-of-the-art
components with modern, attractive styling. We are certain that the design features and trouble-free operation will
add convenience to your daily living and ensure complete satisfaction.
At Pride, your safety is important to us. Please read and follow all of the instructions in this manual before
you attempt to operate your Hurricane PMV for the first time. These instructions were produced for your
benefit. Your understanding of these instructions is essential for the safe operation of your new Pride Hurricane
PMV.
The PMV is not an FDA approved medical device. As such, it is untended to be used as a luxury personal
transportation device. It is recommended that you consult your physician before using this or any personal mobility/transportation device. The manufacturer and distributor of this PMV is also not liable for any property damage
or personal injury arising out of the failure of any person and/or user to follow the instructions and recommendations set forth in this manual or any other instructions or recommendations contained in other PMV related literature issued by Pride or contained on the Pride PMV itself. The failure to follow these instructions will also void
your warranty.
This owners manual is compiled from the latest specifications and product information available at the time of
publication. We reserve the right to make changes as they become necessary. Any changes to our products may
cause slight variations between the illustrations and explanations in this manual and the product you had purchased.
If you experience any problems with your Hurricane PMV that you are unable to solve, or if you do not feel capable of
safely following any of the instructions and/or recommendations as contained in this manual, please contact your
authorized Pride Provider for assistance.
Once you understand how to operate and take care of your Hurricane PMV, we are certain that it will give you years of
trouble-free service and enjoyment.
Information Exchange
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about the
safety and reliability of your new Pride Hurricane PMV and the service you received from your authorized Pride Provider.
Please notify us of any change of address so we can keep you apprised of important information about safety, new
products, and new options that can increase your ability to use and enjoy your Pride Hurricane PMV. Please feel free to
write us at the address below:
Pride Mobility Products Corporation
Attn: Technical Service Department
182 Susquehanna Avenue
Exeter, PA 18643-2694
customercare@pridemobility.com
1-800-424-8205
4
www.pridemobility.com Hurricane PMV/RevK/Mar03
I. INTRODUCTION
Pride Owners Club
As an owner of a Pride product, you are invited to register your products warranty and enroll in the Pride Owners
Club. You may do so by filling out and returning your enclosed registration card or by visiting Prides web site at
www.pridemobility.com. As a registered member, each time you visit our site, you will have access to the most
interactive and honest educational venue available today for people with mobility needs, their families, and friends.
From our home page, click on the button that reads Owners Club to enter a page dedicated to current and
potential Pride product owners. You will gain access to interviews, stories, recreation ideas, daily living tips,
product and funding information, and interactive message boards. On these message boards you are invited to
speak with other Pride customers as well as Pride representatives who are available to assist you with any questions or concerns you may have.
My Authorized Pride Provider Is:
Name:_______________________________________________________________________________
Address:_____________________________________________________________________________
Phone Number:________________________________________________________________________
Quick Reference Information:
Model:______________________________________________________________________________
Serial Number:__________________________________________________________________________
Purchase Date:_________________________________________________________________________
NOTE: If you ever lose or misplace your product registration card or this owners manual, contact us and
we will be glad to send you a new one immediately.
Hurricane PMV/RevK/Mar03 www.pridemobility.com
5
II. SAFETY
GENERAL
WARNING! Do not operate your new Hurricane PMV for the first time without completely
reading and understanding this owners manual.
Your Hurricane PMV is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides
an extensive variety of products to best fit the individual needs of the Hurricane PMV user. Please be aware that
the final selection and purchasing decision regarding the type of Hurricane PMV to be used is the responsibility of
the Hurricane PMV user who is capable of making such a decision and his/her healthcare professional (i.e.,
medical doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted the
Hurricane PMV to the user and has assisted the prescribing healthcare professional and/or the authorized Pride
Provider in the instruction process for the use of the product.
There are certain situations, including some medical conditions, where the Hurricane PMV user will need to practice
operating the Hurricane PMV in the presence of a trained attendant. A trained attendant can be defined as a family
member or care professional specially trained in assisting a Hurricane PMV user in various daily living activities.
As you begin using your Hurricane PMV during daily activities, you will probably encounter situations in which you
will need some practice. Simply take your time and you will soon be in full and confident control as you maneuver
through doorways, on and off elevators, up and down ramps, and over moderate terrain.
Below are some precautions, tips, and other safety considerations that will help the user become accustomed to
operating the Hurricane PMV safely.
MODIFICATIONS
Pride has designed and engineered your Hurricane PMV to provide maximum mobility and utility. A wide range of
accessories is available from your Pride Provider to further customize your Hurricane PMV to better suit your
needs and/or preferences. However, under no circumstances should you modify, add, remove, or disable any
feature, part, or function of your Hurricane PMV.
WARNING! Do not modify your Hurricane PMV in any way not authorized by Pride.
Unauthorized modifications may result in personal injury and/or damage to your Hurricane
PMV.
REMOVABLE PARTS
WARNING! Do not attempt to lift or move a Hur ricane PMV by any of its removable parts.
Personal injury and damage to the Hurricane PMV may result.
ELECTROMAGNETIC FIELDS
Your PMVs road performance features may be influenced by electromagnetic fields caused by cellular telephones
or other radiating devices, such as hand-held radios, radio and television stations, wireless computer links, microwave sources, and paging transmitters. Learn more about this topic in III. EMI/RFI.
6
www.pridemobility.com Hurricane PMV/RevK/Mar03
II. SAFETY
PRE-RIDE SAFETY CHECK
Get to know the feel of your Hurricane PMV and its capabilities. Pride recommends that you perform a safety
check before each use to make sure your Hurricane PMV operates smoothly and safely. For details on how to
perform these necessary inspections, see XII. Care and Maintenance.
Perform the following inspections prior to using your Hurricane PMV:
n Check for proper tire inflation. Maintain 30-35 psi in each tire (if equipped with pneumatic tires).
n Check all electrical connections. Make sure they are tight and not corroded.
n Check all controller connections to the electronics module. Make sure they are secured properly.
n Check the brakes.
n Check battery charge.
TIRE INFLATION
If your PMV is equipped with pneumatic tires, you should check or have the air pressure checked at least once a
week. Proper inflation pressures will prolong the life of your tires and help ensure the smooth operation of your PMV.
WARNING! It is critically important that 30-35 psi tire pressure be maintained in pneumatic
tires at all times. Do not underinflate or overinflate your tires. Low pressure may result in
loss of control, and overinflated tires may burst. Failure to maintain 30-35 psi tire pressure
in pneumatic tires at all times may result in tire and/or wheel failure, causing serious
personal injury and/or damage to your PMV.
WARNING! Inflate your PMV drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting
in a burst tire and/or personal injury.
If you discover a problem, contact your authorized Pride Provider for assistance.
WEIGHT LIMITATIONS
Your PMV is rated for a maximum weight capacity. Refer to the specifications table for information.
WARNING! Exceeding the weight limit voids your warranty and may result in personal
injury and damage to your Hurricane PMV. Pride will not be held responsible for injuries
and/or property damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your PMV. Carrying passengers may result in personal
injury and/or property damage.
INCLINE INFORMATION
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe access.
Some ramps may have turning switchbacks (180-degree turns) that require you to have good cornering skills on
your Hurricane PMV.
n Proceed with extreme caution as you approach the downgrade of a ramp or other incline.
n Take wide swings with your Hurricane PMVs front wheels around any tight corners. If you do that, the
Hurricane PMVs rear wheels will follow a wide arc, not cut the corner short, and not bump into or get hung up
on any railing corners.
n When driving down a ramp, keep the Hurricane PMVs speed adjustment set to the slowest speed setting to
ensure a safely controlled descent. See V. Your Hurricane PMV.
n Avoid sudden stops and starts.
Hurricane PMV/RevK/Mar03 www.pridemobility.com
7
II. SAFETY
When climbing an incline, try to keep your Hurricane PMV moving. If you must stop, start up again slowly, and
then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment button to the
slowest setting and driving in the forward direction only. If your Hurricane PMV starts to move down the incline
faster than you anticipated or desired, allow it to come to a complete stop by releasing the throttle control lever.
Then push the throttle control lever forward slightly to ensure a safely controlled descent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the
incline. Drive your PMV straight up the incline. This greatly reduces the possibility of a tip
or a fall. Always exercise extreme caution when negotiating an incline.
WARNING! Do not drive your PMV across the side of a hill or diagonally up or down a hill;
do not stop, if possible, while driving up or down an incline.
WARNING! You should not travel up or down a potentiall y hazardous incline (i.e., areas
covered with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the PMV in freewheel
mode while seated on it or standing next to it.
WARNING! Even though your PMV is capable of climbing slopes greater than those
illustrated in figure 1, do not, under any circumstances, exceed the incline guidelines or
any other specifications presented in this manual. Doing so could cause instability in your
PMV, resulting in personal injury and/or damage to your PMV.
Other inclines may be natural or, if man-made, not designed specifically for PMVs. Figure 1 illustrates your Hurricane
PMVs stability and its ability to climb grades under various weight loads and under controlled testing conditions.
These tests were conducted with the Hurricanes seat in the highest position and adjusted backward on the seat
base to its farthest rearward position. Use this information as a guideline. Your Hurricanes ability to travel up
inclines is affected by your weight, your Hurricane PMVs speed, your angle of approach to the incline, and your
Hurricane PMV setup.
150-300 lbs.
7˚
Figure 1. Maximum Recommended Incline Angles
WARNING! Any attempt to climb or descend a slope steeper than what is shown in figure
1 may put your PMV in an unstable position and cause it to tip, resulting in personal injury.
WARNING! Never carry an oxygen tank weighing more than 15 lbs. Never fill the rear
basket with contents exceeding 15 lbs.
350-400 lbs.
6˚
8
www.pridemobility.com Hurricane PMV/RevK/Mar03
II. SAFETY
When you approach an incline, it is best to lean forward. See figures 2 and 2A. This shifts the center of gravity of
you and your Hurricane PMV toward the front of the Hurricane PMV for improved stability.
Figure 2. Normal Driving Position
Figure 2A. Increased Stability Driving Position
CORNERING INFORMATION
Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility of
tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning), uneven road
surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction (such as passing
from a grassy area to a paved area especially at high speed while turning), and abrupt directional changes. High
cornering speeds are not recommended. If you feel that you may tip over in a corner, reduce your speed and
steering angle (i.e., lessen the sharpness of the turn) to prevent your Hurricane PMV from tipping.
WARNING! When cornering sharply, reduce your speed. When using your Hurricane PMV
at higher speeds, do not corner sharply. This greatly reduces the possibility of a tip or
fall. To avoid personal injury or property damage, always exercise common sense when
cornering.
BRAKING INFORMATION
Your Hurricane PMV is equipped with two powerful brake systems:
1. Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the center/
stop position; and
2. Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or when
power is removed from the system for any reason.
Hurricane PMV/RevK/Mar03 www.pridemobility.com
9
II. SAFETY
OUTDOOR DRIVING SURFACES
Your Hurricane PMV is designed to provide optimum stability under normal driving conditionsdry, level surfaces
composed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you will
encounter other surface types. For this reason, your Hurricane PMV is designed to perform admirably on packed
soil, grass, and gravel. Feel free to use your Hurricane PMV safely on lawns and in park areas.
n Reduce your Hurricane PMVs speed when driving on uneven terrain and/or soft surfaces.
n Avoid tall grass that can become tangled in the running gear.
n Avoid loosely packed gravel and sand.
n If you feel unsure about a driving surface, avoid that surface.
STATIONARY OBSTACLES (STEPS, CURBS, ETC.)
WARNING! Do not drive near raised surfaces, unprotected ledges, and/or drop-offs (curbs,
porches, stairs, etc.).
WARNING! Do not attempt to have your PMV climb or descend an obstacle that is
inordinately high. Serious personal injury and/or damage may result.
WARNING! Do not attempt to have your PMV proceed backward down any step, curb, or
other obstacle. This may cause the PMV to tip and cause personal injury.
WARNING! Be sure your PMV is traveling perpendicular to any curb you may be required to
ascend or descend. See figures 3 and 3A.
WARNING! Do not attempt to negotiate a curb that has a height greater than 2 in.
Figure 3. Correct Curb Approach Figure 3A. Incorrect Curb Approach
PUBLIC ROADS AND PARKING LOTS
WARNING! You should not operate your Hurricane PMV on public streets and roadways.
Be aware that it may be difficult for traffic to see you when you are seated on your Hurricane
PMV. Obey all local pedestrian traffic rules. Wait until your path is clear of traffic, and then
proceed with extreme caution.
NOTE: Safety accessories like fluorescent flags are available to order from your authorized Pride Provider.
10
www.pridemobility.com Hurricane PMV/RevK/Mar03
II. SAFETY
INCLEMENT WEATHER PRECAUTIONS
WARNING! Pride recommends that you do not operate your Hurricane PMV in icy or slippery
conditions or on salted surfaces (i.e., walks or roads). Such use may result in an accident,
personal injury, or adversely affect the performance and safety of your Hur ricane PMV.
WARNING! Pride recommends that you do not expose your Hurricane PMV to any type of
moisture at any time (rain, snow, mist, or wash). Such exposure can damage your Hurricane
PMV. Never operate your Hurricane PMV if it has been exposed to moisture until it has
dried thoroughly.
FREEWHEEL MODE
Your Hurricane PMV is equipped with a manual freewheel lever that when pulled up allows the Hurricane PMV to
be pushed. For more information about how to place your Hurricane PMV into and out of freewheel mode, see V.
Your Hurricane PMV.
WARNING! When your PMV is in freewheel mode, the braking system is disengaged.
n Disengage the drive motors only on a level surface.
n Ensure the key is removed from the key switch.
n Stand behind the PMV to engage or disengage freewheel mode. Never sit on a
PMV to do this.
n After you have finished pushing your PMV, always return it to the drive mode to lock
the brakes.
Failure to heed the above could result in personal injury and/or damage to your PMV.
STAIRS AND ESCALATORS
Hurricane PMVs are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! Do not use your PMV to negotiate steps or escalators. You may cause injury to
yourself and/or to others and damage your PMV.
DOORS
n Determine if the door opens toward or away from you.
n Use your hand to turn the knob or push the handle or push-bar.
n Drive your Hurricane PMV gently and slowly forward to push the door open. Or drive your Hurricane PMV
gently and slowly backwards to pull the door open.
ELEVATORS
Modern elevators have a door edge safety mechanism that, when pushed, reopens the elevator door(s).
n If you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or
allow the rubber door edge to contact the Hurricane PMV and the door will reopen.
n Use care that pocketbooks, packages, or Hurricane PMV accessories do not become caught in elevator doors.
LIFT/ELEVATION PRODUCTS
If you will be traveling with your Hurricane PMV, you may find it necessary to use a lift/elevation product to aid in
transportation. Pride recommends that you closely review the instructions, specifications, and safety information
set forth by the manufacturer of the lift/elevation product before using that product.
Hurricane PMV/RevK/Mar03 www.pridemobility.com
11
II. SAFETY
BATTERIES
In addition to following the warnings below, be sure to comply with all other battery handling information.
WARNING! PMV batteries are heavy (refer to specifications table). Lifting weight beyond
your capacity could result in personal injury. If necessary, get someone physically able
to lift the PMV batteries for you.
WARNING! Battery posts, terminals, and related accessories contain lead and lead
compounds. Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery.
Charging a frozen battery may result in personal injury and/or damage to the battery.
WARNING! RED (+) cables must be connected to positive (+) battery terminals/posts. BLACK
(-) cables must be connected to negative (-) battery terminals/posts. Failure to connect
your battery harnesses in the proper manner may result in personal injury and/or damage
to your power chair. REPLACE cables immediately if damaged.
BATTERY DISPOSAL AND RECYCLING
If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag and call your authorized
Pride Provider for instructions on disposal. Your authorized Pride Provider will also have the necessary information on battery recycling, which is our recommended course of action.
MOTOR VEHICLE TRANSPORT
Currently, there are no standards approved for tie-down systems in a moving vehicle of any type to transport a
person while seated in a Hurricane PMV.
Although your Hurricane PMV may be equipped with a positioning belt, this belt is not designed to provide proper
restraint during motor vehicle transport. Anyone traveling in a motor vehicle should be properly secured in the
motor vehicle seat with safety belts fastened securely.
WARNING! Do not sit on your Hurricane PMV while it is in a moving vehicle. Personal
injury and/or property damage may result.
WARNING! Always be sure your Hurricane PMV and its batteries are properly secured
when it is being transpor ted. Failure to do so may result in personal injury and/or damage
to your Hurricane PMV.
PREVENTING UNINTENDED MOVEMENT
WARNING! If you anticipate being seated in a stationary position for an extended period
of time, turn off the power. This will prevent unexpected motion from inadvertent throttle
control lever contact. Failure to do so may result in personal injury.
12
www.pridemobility.com Hurricane PMV/RevK/Mar03
II. SAFETY
GETTING ONTO AND OFF OF YOUR HURRICANE PMV
Getting onto and off of your Hurricane PMV requires a good sense of balance. Please observe the following safety
tips when getting onto and off of your Hurricane PMV:
n Power down your Hurricane PMV.
n Ensure that your Hurricane PMV is not in freewheel mode. See V. Your Hurricane PMV.
n Make certain that the seat is locked into place and the key is removed from the key switch.
n The seat armrests can be flipped up to make getting onto and off the Hurricane PMV easier.
WARNING! Position yourself as far back as possible in the Hurricane PMV seat to prevent
the Hurricane PMV from tipping and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause
the Hurricane PMV to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the
Hurricane PMV to tip and cause personal injury.
POSITIONING BELTS
Your authorized Pride Provider, therapist(s), and other healthcare professionals are responsible for determining
your requirement for a positioning belt in order to operate your Hurricane PMV safely.
WARNING! If you require a positioning belt to safely operate your Hurricane PMV, make
sure it is fastened securely. Serious personal injur y may result if you fall from the Hurricane
PMV.
REACHING AND BENDING
Avoid reaching or bending while driving your Hurricane PMV. When reaching, bending, or leaning while seated on
your Hurricane PMV, it is important to maintain a stable center of gravity and keep the Hurricane PMV from
tipping. Pride recommends that the Hurricane PMV user determine his/her personal limitations and practice bending and reaching in the presence of a qualified healthcare professional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the
floor by reaching down between your knees. Movements such as these may change your
center of gravity and the weight distribution of the Hurricane PMV and cause your Hurricane
PMV to tip, possibly resulting in personal injury. Keep your hands away from the tires when
driving.
Hurricane PMV/RevK/Mar03 www.pridemobility.com
13
Loading...
