Synergy TRU-Balance
BASIC OPERATION INSTRUCTIONS
TMTM
TM
TMTM
Po
FLIGHT
Controller
ACN# 088 609 661
ACN# 088 609 661
2 Basic Operation Instructions
INFORMATION LABELING
The symbols below are used throughout this owner's manual and on the power
chair to identify warnings and important information. It is very important for you to
read them and understand them completely .
WARNING! Indicates a potentially hazardous condition/
situation. Failure to follow designated procedures can cause
either personal injury, component damage, or malfunction.
On the product, this icon is represented as a black symbol
on yellow triangle with black border .
MANDATORY! These actions should be performed as
specified. Failure to perform mandatory actions can cause
personal injur y and/or equipment damage. On the product,
this icon is represented as a white symbol on a blue dot with
a white border.
PROHIBITED! These actions are prohibited. These actions
should not be performed at any time or in any circumstances.
Performing a prohibited action can cause injury to personnel
and/or damage to equipment. On the product, this icon is
represented as a black symbol with a red circle and a red
slash.
Read and follow the information in the owner’s manual.
Avoid e xposure to rain, snow , ice, salt, or standing wate r
whenever possible. Maintain and store in a clean and dry
condition.
Disposal and recycling - Contact your authorized Pride
Provider for information on proper disposal and recycling of
your Pride product and its packaging.
Copyright © 2006
Pride Mobility Products Corporation
INFMANU2895/Rev A/November 06
FLIGHT Controller www.pridemobility.com
Basic Operation Instructions 3
INTRODUCTION ................................................................................. 4
FLIGHT CONTROLLER ................................................................... 6
PRECAUTIONAR Y GUIDELINES................................................. 6
OPERA TING THE FLIGHT CONTROLLER ........................... 10
CONTROLLER CONNECTOR...................................................... 12
OFF-BOARD CHARGER/PR OGRAMMING SOCKET ............. 13
LOCK MODE....................................................................................... 13
SLEEP MODE .................................................................................... 13
ERROR CODES ................................................................................. 14
CARE AND MAINTENANCE ........................................................ 14
TABLE OF CONTENTS
WARRANTY ........................................................................................ 14
www.pridemobility.com FLIGHT Controller
4 Basic Operation Instructions
INTRODUCTION
WELCOME to Pride Mobility Products Corporation (Pride). The product you
have purchased combines state-of-the-art components with safety, comfort, and
styling in mind. W e are confident that the design features will provide you with the
conveniences you expect during your daily activities. Understanding how to safely
operate and care for this product should bring you years of trouble free operations
and service.
Read and follow all instructions, warnings, and notes in this manual and all other
accompanying literature before attempting to operate this product for the first
time. In addition, your safety depends upon you, as well as your provider , caretaker,
or healthcare professional in using good judgement.
This manual is to be used in addition to the power base owner’s manual that came with
your power chair . If there is any information in this manual which you do not understand,
or if you require additional assistance for setup or operation, please contact your
authorized Pride Provider . Failure to follow the instructions, warnings, and notes
in this manual and those located on your Pride product can result in personal
injury and/or product damage and will void Pride’ s product warranty.
PURCHASER’S AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter ,
or modify this product or remove or render inoperable or unsafe any guards,
shields, or other safety features of this product; fail, refuse, or neglect to install any
retrofit kits from time to time provided by Pride to enhance or preserve the safe
use of this product.
INFORMA TION EXCHANGE
W e want to hear your questions, comments, and suggestions about this manual.
W e would also like to hear about the safety and reliability of your new Pride
product, and about the service you received from your authorized Pride Provider .
Please notify us of any change of address, so we can keep you apprised of important
information about safety , new products, and new options that can increase your
ability to use and enjoy your Pride product.
FLIGHT Controller www.pridemobility.com
Basic Operation Instructions 5
NOTE: If you ever lose or misplace your product registration card or your
copy of this manual, contact us and we will be glad to send you a new one
immediately.
My authorized Pride Provider Is:
Name: _____________________________________________________
Address:____________________________________________________
Phone Number: ______________________________________________
Purchase Date: _______________________________________________
www.pridemobility.com FLIGHT Controller
6 Basic Operation Instructions
FLIGHT CONTROLLER
The FLIGHT Controller is a modular electronic controller system that allows you to
operate your power chair . It is designed to allow the user to have complete control
over chair movement and speed.
The controller has been pre-programmed to meet a typical user’s needs. The
program is set using either a personal computer with software provided by the
controller manufacturer or with a hand-held programmer, also provided by the
controller manufacturer .
WARNING! The controller program can affect speed,
acceleration, deceleration, dynamic stability, and braking.
If it is programmed incorrectly or outside of the safe limits
as determined by your healthcare professional, it can create
a dangerous situation. Only the power chair manufacturer,
an authorized representative of the manufacturer , or a trained
service technician should program the controller.
PRECAUTIONAR Y GUIDELINES
Before operating the FLIGHT Controller, please read the following. These
guidelines are provided for your benefit and will aid you in the safe operation of
the controller system.
! Turn off the power to the controller when transferring to or from your power
chair.
! Follow all of the procedures and heed the warnings as explained in your power
chair owner’s manual.
Failure to heed the above warnings can result in personal injury and/or
equipment damage.
FLIGHT Controller www.pridemobility.com
Basic Operation Instructions 7
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic
and radio frequency waves can have an adverse affect on
the performance of electrically-powered mobility vehicles.
Electromagnetic and Radio Frequency Interference can come from sources such as
cellular phones, mobile two-way radios (such as walkie-talkies), radio stations, TV
stations, amateur radio (HAM) transmitters, wireless computer links, microwave signals, paging transmitters, and medium-range mobile transceivers used by emergency
vehicles. In some cases, these waves can cause unintended movement or damage to
the control system. Every electrically-powered mobility vehicle has an immunity (or
resistance) to EMI. The higher the immunity level, the greater the protection against
EMI. This product has been tested and has passed at an immunity level of 20 V/m.
WARNING! Be aware that cell phones, two-way radios,
laptops, and other types of radio transmitters may cause
unintended movement of your electrically-powered mobility
vehicle due to EMI. Exercise caution when using any of these
items while operating your mobility vehicle and avoid coming
into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to
the electrically-powered mobility vehicle can increase the
susceptibility of the vehicle to EMI. Do not modify your power
chair in any way not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself
can disturb the performance of other electrical devices
located nearby , such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on
www.pridemobility.com. If unintended motion or brake release occurs, turn
your controller off as soon as it is safe to do so. Call Pride or your authorized
Pride Provider to report the incident.
www.pridemobility.com FLIGHT Controller
8 Basic Operation Instructions
FLIGHT Controller Features
Figure 1 provides information on the FLIGHT components and connections. Use
this diagram to familiarize yourself with the function and location of each component
before using the FLIGHT Controller .
The following functions are available with the FLIGHT Controller:
!
Joystick Control
The joystick is used to control the direction and speed of the power chair.
! Speed Adjustment
The user can increase or decrease the maximum speed of the power chair.
! Sleep Mode
This feature is designed to preserve battery charge, and can be disabled through
programming.
FLIGHT Controller www.pridemobility.com
Basic Operation Instructions 9
On/Off Key
Battery Condition Meter
Indicates the approximate amount of
battery life using color-coded LEDs.
Speed Decrease Key
Used to decrease the
speed setting
Press to power on or
off the power chair and
controller.
Speed Increase Key
Used to increase the
speed setting
Horn Key
Activates a warning horn.
Joystick
A multi-functional tool used
to control speed and direction.
Speed Setting
Indicator
Series of five colored
LEDs which display the
speed setting.
Figure 1. FLIGHT Components and Connections
www.pridemobility.com FLIGHT Controller
Off-board Charger/
Programming Socket
Connects to battery
charger plug or
programmer
10 Basic Operation Instructions
OPERA TING THE FLIGHT CONTROLLER
The FLIGHT Controller is used to operate your power chair and all of its components.
The FLIGHT controller consists of (see figure 2):
1. joystick
2. keypad
3. off-board charger/programming socket
4. controller connector
5. power module
2
1
3
4
5
Figure 2. FLIGHT Controller
Joystick Control
The joystick controls the direction and speed of your power chair . When you
move the joystick from the neutral (center) position, the electromagnetic brakes
release and allow your power chair to move. The farther you push the joystick
from its neutral position, the faster your power chair moves. When you release the
joystick and allow it to return to the neutral position, you engage the electromagnetic brakes. This causes your power chair to decelerate and come to a complete
stop.
FLIGHT Controller www.pridemobility.com
Basic Operation Instructions 11
BATTERY CONDITION METER
SPEED DECREASE KEY
SPEED
SETTING INDICATOR
Figure 3. FLIGHT Keypad
ON/OFF KEY
SPEED INCREASE KEY
HORN KEY
Keypad
The keypad is located directly in front of the joystick. It contains keys that you will
use to control your power chair. See figure 2.
On/Off Key
The on/off key turns the system on and off.
WARNING! Unless faced with an emergency situation, do
not use the on/off key to stop the chair. This will cause the
power chair to stop abruptly .
WARNING! Always turn the power off when you are stationary
to prevent unexpected movement.
www.pridemobility.com FLIGHT Controller
12 Basic Operation Instructions
Battery Condition Meter
The battery condition meter consists of ten lights arranged in an arc over the on/off
key . As the battery voltage drops, the number of lights reduces from right to left.
When the battery capacity drops to 10% or below , the left red LED will flash.
! Left Red LED Flashing: Battery charge is low; charge the batteries as soon
as possible.
! Right-to-Left Ripple of LEDs: FLIGHT is in lock mode; unlock the FLIGHT .
! Left-to-Right Ripple of LEDs Alternating with Steady Display: FLIGHT
is in programming, inhibit, or charging mode.
! Right Green LED Flashing: FLIGHT is in speed limit mode.
! All LEDs Flashing Continuously: The joystick was not in the neutral position
when the controller was turned on. If you get “all LEDs flashing continuously ,”
turn off the controller , allow the joystick to return to the neutral position, then
turn on the controller .
! All LEDs Flashing Quickly (Code): The FLIGHT has detected a fault;
refer to the Error Code table.
Speed Keys
There are two keys that control the speed. Press the speed increase key to increase the speed. Press the speed decrease key to decrease the speed. The speed
setting is displayed on the speed setting indicator. If your power chair was programmed with a drive profile, contact your authorized Pride Provider for more
information.
NOTE: We recommend that the first few times you operate your power
chair, you set the speed to the slowest setting until you become familiar
with your new power chair.
Horn Key
The horn key activates a warning horn.
CONTROLLER CONNECT OR
This connects the FLIGHT to the power module located on the power base.
FLIGHT Controller www.pridemobility.com
Basic Operation Instructions 13
OFF-BO ARD CHARGER/PROGRAMMING SOCKET
Y ou may use an off-board char ger to charge the power chair batteries through the
3-pin socket located on the front of the FLIGHT . If you use an off-board charger ,
the charger current should not exceed 8 amps. Contact your authorized Pride
Provider for more information.
WARNING! Only chargers with Neutrik NC3MX plugs should
be connected to the off-board charger/programming socket.
See your authorized Pride Provider for more information.
NOTE: The socket may also be used for reprogramming the FLIGHT.
Contact your authorized Pride Provider for more information.
LOCK MODE
The Flight controller is equipped with a feature that enables you to “lockout”
unauthorized users.
T o lock the FLIGHT controller:
1. While the power is on, press and hold the on/off key for 2 seconds. The
display will turn off immediately . After 2 seconds, all LEDs will flash briefly
and the horn will sound a short beep.
2. The FLIGHT controller is now locked.
T o unlock the FLIGHT contr oller:
1. While the FLIGHT is locked, press the on/off key to turn on the FLIGHT . All
LEDs will flash briefly . The LEDs will then slowly ripple from right to left.
2. Press the horn key twice before the LED ripple has completed, approximately
10 seconds. The FLIGHT is now unlocked.
SLEEP MODE (IF ENABLED)
The power chair controller features a sleep mode. Sleep mode is a built-in circuit
that will automatically shut off the main power if the joystick is not moved in any
direction for a period of time. This time factor is programmed into the controller .
T o restore power and continue, push any key on the keypad.
www.pridemobility.com FLIGHT Controller
14 Basic Operation Instructions
ERROR CODES
The battery condition meter will flash error codes when the FLIGHT controller
detects an abnormal condition in the electrical system. All of the battery condition
meter LEDs will flash a number of times quickly , then pause, then flash again. The
battery condition meter will continue to flash the error codes until the problem is
fixed. The table below identifies the individual error codes. If any of these error
codes persist or if you experience any other problem with your power chair, contact your authorized Pride Provider .
Error Code Probable Cause Possible Solution
1 Possible stall timeout or user error Release the joystick.
2 Battery Fault Check the batteries and cables. Try
3 Left Motor fault Check the left motor, connections,
4 Right Motor Fault Check the right motor, connections,
5 Left Park Brake Fault Check the left park brake, connections,
6 Right Park Brake Fault C heck the right park brake, connections,
7 FLIGHT Controller Module Fault Check the communications connections
8 FLIGHT Power Module Fault Check the communications connections
9 FLIGHT Communications Fault Check the communications connections
10 Unknown Fault Contact your authorized Pride Provider.
11 Incompatible Controller Fault Contact your authorized Pride Provider.
to charge the batteries. The batteries
may need to be replaced.
and cabling.
and cabling.
and cabling.
and cabling.
and wiring.
and wiring.
and wiring.
CARE AND MAINTENANCE
Refer to your power chair owner’s manual for proper cleaning and disposal
instructions.
W ARRANTY
For two (2) years from the date of purchase, Pride will repair or replace at our
option to the original purchaser, free of char ge, the controller or any of its components
found upon examination by an authorized representative of Pride to be defective
in material and/or workmanship.
FLIGHT Controller www.pridemobility.com
Basic Operation Instructions 15
NOTES
www.pridemobility.com FLIGHT Controller
Pride Mobility Products Corporation
182 Susquehanna Avenue
Exeter, PA 18643-2694
USA
Pride Mobility Products Company
380 Vansickle Road Unit 350
St. Catharines, Ontario L2R 6P7
Canada
Pride Mobility Products Ltd.
Unit 106, Heyford Park Camp Road
Upper Heyford, Oxfordshire OX25 5HA
Pride Mobility Products Australia Pty . Ltd.
21 Healey Road
Dandenong, 3175
Victoria, Australia
Pride Mobility Products Italia S.r .l.
Via del Progresso - ang. Via del Lavoro
Loc. Prato della Corte
00065-Fiano Romano (RM)
Pride Mobility Products Europe B.V.
Tijnmuiden 28
1046 AL Amsterdam
The Netherlands
www.pridemobility .com www .prideservice.com www.quantumrehab.com
*INFMANU2895*
Loading...
