Prestige APS 800a, Platinum APS 800a Installation Manual

Model APS 800a

Installation Manual

SELECT ABLE FEA TURES

Note : The method of manual override can either be selected to operate from the valet switch or operate as custom code. Be

certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.

RF Programmable Features :

Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps Default
1st Door L/UL 1 Sec. 3.5 Sec. 1 Sec L, Dbl. U/L 1 Sec.
2nd Accy Lock Auto Lock On Auto Lock Off Auto Lock Off
3rd Accy. UL Auto UL Dr. Auto UL All Auto UL Off Auto UL Off
4th Headlights On Arm On Disarm On Both Off Both
5th Passive Locks Passive Active Active
6th Passive/Active Arm Passive Arm Active Arm Active Arm
7th Voltage Sense Voltage Sense Hardwire Hardwire
8th Siren/Horn Siren/Horn Siren Only Horn Only Siren/Horn
9th Horn Chirp 10mS 16mS 30mS 16mS
10th Override Method Custom Code Valet Valet
11th Two Step Unlock On O ff O ff
12th Chirp Delete From Tx On Off Off

T o program these selectable features;

Action System Response
Turn ignition on No response
Press and release the valet switch 3 times 1 Chirp - LED 1 flash
Within 3 seconds, turn ignition Off Short chirp, then long chirp

First Then On 1 chirp = 1 second door locks

Second Press and release the valet switch 2 chirps = auto locks off

Third Press and release the valet switch 3 chirps = auto unlock off

Fourth Press and release the valet switch 3 chirps = headlight output when arming and disarming

Fifth Press and release the valet switch 2 chirps = active locks

Sixth Press and release the valet switch 2 chirps = active arming

Seventh Press and release the valet switch 2 chirps = hardwire

Press transmitter Lock button to change 2 chirps = 3.5 second door locks
Press transmitter Lock button to change 3 chirps = 1 sec. lock, dbl 1 sec. unlock

or

Press transmitter Lock button to change 1 chirp = auto locks on

or

Press transmitter Lock button to change 1 chirp = auto unlock drivers door only
Press transmitter Lock button to change 2 chirps = auto unlock all doors

or

Press transmitter Lock button to change 4 chirps = headlight output off
Press transmitter Lock button to change 1 chirp = headlight output when arming
Press transmitter Lock button to change 2 chirps = headlight output when disarming

or

Press transmitter Lock button to change 1 chirp = passive locks

or

Press transmitter Lock button to change 1 chirp = passive arming

or

Press transmitter Lock button to change 1 chirp = voltage sense

128-6199

1 of 8

Eighth Press and release the valet switch 1 chirp = siren and horn output

Press transmitter Lock button to change 2 chirps = siren output only
Press transmitter lock button to change 3 chirps = horn output only

Ninth Press and release the valet switch 2 chirps = horn chirp output 16mS

Press transmitter Lock button to change 3 chirps = horn chirp output 30mS
Press transmitter Lock button to change 1 chirp = horn chirp output 10 mS

Tenth Press and release the valet switch 2 chirps = valet switch override operation

Press transmitter Lock button to change 1 chirp = custom code override operation

Eleventh Press and release the valet switch 2 chirps = 2 step unlock off

Press transmitter Lock button to change 1 chirp = 2 step unlock on

Twelfth Press and release the valet switch 2 chirps = chirp delete from transmitter inactive

Press transmitter Lock button to change 1 chirp = chirp delete from transmitter active
Press and release the valet switch Exit program mode

Turn ignition key off Exit program mode

Note : Once you enter the feature programming mode, do not allow more than 15 seconds to pass between steps, or the

programming will be terminated.

or

or

or

or

or

or

INST ALLATION OF MAJOR COMPONENTS

Control Module :

Select a mounting location inside the passenger compartment ( up behind the dash ) and secure using the two screws provided. The
control module can also be secured in place using cable ties.

Do not

mount the control module in the engine compartment, as it is not waterproof. You should also avoid mounting the unit
directly onto factory installed electronic components. These components may cause RF interference, which can result in poor
transmitter range or intermittent operation.

Siren :

Select a mounting location in the engine compartment that is well protected from access below the vehicle. Avoid areas near
high heat components or moving parts within the engine compartment. To prevent water retention, the flared end of the siren
must be pointed downward when mounted. Mount the siren to the selected location using the screws and bracket provided.

Hood or Trunk Pin Switch :

A pin switch is included for use in protecting the hood or trunk ( or hatchback ) of the vehicle. The switch must always be
mounted to a grounded, metal surface of the vehicle. It is important to select a location where water cannot flow or collect, and
to avoid all drip gutters on hood and trunk fender walls. Choose locations that are protected by rubber gaskets when the hood
or trunk lid is closed.
The pin switch can be mounted using the bracket provided, or direct mounted by drilling a ¼ " diameter mounting hole. Keep in mind
that when properly mounted, the plunger of the pin switch should depress at least ¼ " when the hood or trunk lid is closed.

Dash Mounted LED :

A small LED is included that will serve as a visual indicator of the alarm status. It should be installed in the dash, located where
it can be easily seen from outside the vehicle, yet not be distracting to the driver.
Once a location has been selected, check behind the panel for wire routing access, and to confirm the drill will not damage any
existing components as it passes through the panel.
Drill a ¼ " diameter hole, and pass the red and blue wires from the LED through the hole, from the front of the panel. Firmly press the
body of the LED into the hole until fully seated.

Valet Switch :

Select a mounting location for the switch that is easily accessible to the driver of the vehicle. The switch does not have to be
concealed, however, concealing the switch is always recommended, as this provides an even higher level of security to the
vehicle.

Page 2

128-6199

2 of 8

The valet switch can be mounted to the lower side of the dash by drilling a ¼ " diameter hole in the selected location.
Be sure to check behind the dash for adequate clearance for the body of the switch, and to confirm that the drill will not damage
any existing components as it passes through the dash. You should also make certain that the back of the switch is accessible
for wiring later in the installation.

Shock Sensor :

Select a solid mounting surface for the shock sensor on the firewall inside the passenger compartment, and mount the
sensor using the two screws provided. The shock sensor can also be secured to any fixed brace behind the dash using tie straps.
Whichever mounting method is selected, make certain that the sensitivity adjustment is accessible for use later in the installation.

THE RECEIVER/ANTENNA ASSEMBL Y :

The Superheterodyne Receiver Antenna Assembly provided with this unit allows routing from below the dash board for
maximum operating range. Choose a location above the belt line (dashboard) of the vehicle for best reception. Special
considerations must be made for windshield glass as some newer vehicles utilize a metallic shielded window glass that will
inhibit or restrict RF reception. In these vehicles, route the antenna toward a rear window location for best reception. Secure
the antenna with double stick tape provided. After securing the antenna with tape, we advise also securing a section of the
antenna cable to a fixed support. This will prevent the antenna from dropping down in case the double stick tape is exposed
to extreme heat which may loosen it's gummed surface. Route the 3 pin connector toward the control module using caution not
to pinch the cable as this will cause poor or no RF reception to the control module.

WIRING THE SYSTEM

Large 9 Pin Edge Connector :
Red Fused Wire : + 12 VDC CONST ANT BATTERY SOURCE

This wire controls the sensitivity of the voltage sensing circuit, which detects the turning on of an interior light when a door is
opened. It will also detect the switching on of parking or headlamps, and in many cases will trigger the alarm when a
thermostatically controlled electronic radiator cooling fan switches on.
When installing this system into vehicles with electronic “ after fans “, it is recommended you disable the voltage sense circuit.
In voltage sensing applications, the closer to the battery that the red wire is connected, the less sensitive the voltage sense
circuitry will be. Moving this connection point to the fuse panel will increase the sensitivity, and connecting to the courtesy lamp
fuse in the vehicle will provide maximum sensitivity of the voltage sense circuit.
When hardwiring the control module to pin switches at all entry points, the voltage sense circuit must be disabled. Set
programmable feature # 6 to the voltage sense "OFF" position, 2 chirps, then connect the red wire to a + 12 VDC constant battery
source.

White Wire : + 12 VDC PULSED PARKING LIGHT OUTPUT ( 15 AMP MAX )
This wire is provided to flash the vehicle’s parking lights. Connect the white wire to the positive side of one of the vehicle’s
parking lights.

Yellow Wire : + 12 VDC IGNITION SOURCE
Connect this wire to a source that is live when the key is in the on and crank positions. Be sure that this source is off when the
key is in the off position.

White w/ Black Trace Wire : POSITIVE OUTPUT T O SIREN
Route this wire through a rubber grommet in the firewall, and to the siren location. Connect the white / black wire to the positive wire
of the siren. Secure the black ground wire of the siren to chassis ground.

Black Wire : CHASSIS GROUND
Connect this wire to a solid, clean, metal part of the vehicle’s chassis.

Dark Blue w/Black Trace Wire: Alternate Channel 3 Output (Dbl. Push Required)
This wire is controlled from the transmitter button programmed to the receiver's channel 3. By double pressing this the
transmitter button, this output will become active for 1 second. This is a transistorized, low current ( 300 mA ) output, designed
to provide an output only when the transmitter is intentionally operated, such as is the case with remote start add on modules.
If you require more than 300mA drive from this output, you must drive an external relay coil, and arrange the relays contacts
to preform the specified function.
