Page 1
USER’S
MANUAL
RCO-6000 Series
Superior Fanless Embedded System
Page 2
RCO-3000 | User’s Manual
Table of Contents
Revision ………………………………………………………..……………………………..……………….……….. 04 Disclaimer ……………………………………………………….…….……………….………………….………….. 04 Copyright Notice …………………………………….…….….………………………………….………………… 04
Trademarks Acknowledgment …………..………….………………………………………................... 04
Environmental Protection Announcement ……………………………………..……..……………….. 04 Safety Precautions ……………………………………………………………………………………….….…….. 05 Technical Support and Assistance ………………………………...……………………..…….…….……. 06
Conventions Used in this Manual …………………………………..……………………......….……….. 06
Package Contents ……………………………………………………………………..…..…………………….… 07 Ordering Information …………………………..……………………………………..………..….….………… 07
Optional Accessory …………...……………………………………................................................. 09
1.1 Overview ………………….………………………………..………….…………..……………….. 11
1.1.1 Key Feature ………….…………………..…………….……….…..…..…………....... 11
1.2 Hardware Specification ….………..………….....…………….……..……..……………… 12
1.3 System I/O ………..……………..……………………..……………………..…………………… 13
1.3.1 RCO-6000 ………………………......................……………………………………… 13
1.3.2 RCO-6000-4L(P) ………………………..……………..……………….………………... 15
1.3.3 RCO-6000-4L(P)-M12 ……………………………..…….……………………..……... 17
1.3.4 RCO-6000-8L(P) ………………………………………………………..………………... 19
1.3.5 RCO-6000-8L(P)-M12 ………………….……………….…..…..….………………... 21
1.3.6 RCO-6011E(P) ………………….……................………………..…………………… 23
1.3.7 RCO-6011E(P)-4L(P) …………………………..……..…………..….………………... 25
1.3.8 RCO-6011E(P)-4L(P)-M12 …………………………..…….…..…….……………... 27
1.3.9 RCO-6011E(P)-8L(P) …………………………..……….…………………….………... 29
1.3.10 RCO-6011E(P)-8L(P)-M12 ……………………………….…………….……….….. 31
1.3.11 RCO-6022EE(PP/PE) ……………................……………………………………… 33
1.3.12 RCO-6022EE(PP/PE)-4L(P) ……………….…………………..……………….…... 35
1.3.13 RCO-6022EE(PP/PE)-4L(P)-M12 ……………………………..…….…………... 37
1.3.14 RCO-6022EE(PP/PE)-8L(P) ………………………………………….……………... 39
1.3.15 RCO-6022EE(PP/PE)-8L(P)-M12 …………………………..…….………….….. 41
1.4 Mechanical Dimension ……………………..………………………..…..………….………. 43
1.4.1 RCO-6000 / RCO-6000-4L(P) / RCO-6000-4L(P)-M12 / RCO-6000-8L(P) / RCO-6000-8L(P)-M12 …………………………………….… 43
1.4.2 RCO-6011E / RCO-6011E-4L(P) / RCO-6011E-4L(P)-M12 / RCO-6011E-8L(P) / RCO-6011E-8L(P)-M12 / RCO-6011P / RCO-6011P-4L(P) / RCO-6011P-4L(P)-M12 / RCO-6011P-8L(P) /
RCO-6011P-8L(P)-M12 …..…………………………………………………..….….... 44
1.4.3 RCO-6022EE / RCO-6022EE-4L(P) / RCO-6022EE-4L(P)-M12 / RCO-6022EE-8L(P) / RCO-6022EE-8L(P)-M12 / RCO-6022PP / RCO-6022PP-4L(P) / RCO-6022PP-4L(P)-M12 / RCO-6022PP-8L(P) / RCO-6022PP-8L(P)-M12 / RCO-6022PE / RCO-6022PE-4L(P) / RCO-6022PE-4L(P)-M12 / RCO-6022PE-8L(P) / RCO-6022PE-8L(P)-M12 ……………………..……….……….….………………….. 45
Chapter 2 Switches and Connectors …………….……………………………………. 46
2.1 Switch and connector Locations ………………………………………..…….….…….... 47
2.1.1 Top View ………………………………………………………………………..…..……… 47
2.1.2 Bottom View ……………………………………………………………..……..……….. 48
2.2 Connector / Switch Definition ……………………………….……….…….……............. 49
2
Page 3
RCO-3000 | User’s Manual
3
2.3 Switch Definitions ………….……………............................................................. 50
2.4 Connector Definitions …………………………..................................................... 50
3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and
unscrewing …………………………………………………………………………………………….. 67
3.2 Removing chassis bottom cover ………………...………………………………………..... 67
3.3 Removing PCIe/PCI expansion module …….……………..….…….…..….…………... 68
3.4 Removing chassis top cover …………….…………………………….….………………...... 69
3.5 Installing SODIMM …………….…………………………..…….…………………………....... 70
3.6 Installing CPU ……………………...…………………………..….……………………………...... 71
3.7 Installing mini PCIe card / mSATA ……………………...…….….……………………...... 76
3.8 Installing antenna ………………...…….………………….……………………..…………...... 77
3.9 Assembly chassis top cover …...…….………………………………………..…………...... 79
3.10 Installing HDD on internal SATA HDD bay …...…….…………………..….………...... 81
3.11 Installing HDD on removable SATA HDD bay ………………..…….……..………...... 83
3.12 Installing PCIe/PCI expansion card ………………..…………………..……..………...... 84
3.13 Assemble PCIe/PCI expansion module ……………….……………..……..………...... 86
3.14 Assemble chassis bottom cover ………………..………………..……..……….……...... 87
3.15 Installing SIM card ………………..…………………..…….………..………….…….……...... 88
3.16 Installing wall mount kit …………..……………....………………..……..……….……...... 90
Chapter 4 BIOS Setup …………………………………………………………..……………..……………… 91
4.1 BIOS Introduction …….……….……………………………………….…….…..….…………... 92
4.2 Main Setup ……..……….………………….…………………………..….….………………...... 93
4.2.1 System Language ……………………………………………..….…………………….... 93
4.2.2 System Date …….…….……………………..……………..……..…………………….... 93
4.2.3 System Time ………..….……………………………………..……….…………………... 93
4.3 Advanced Setup …………………………………………..………………………………………… 94
4.3.1 ACPI Settings ……..………………………………………………………..………………. 94
4.3.2 AMT Configuration …………………………….………..………..……………..……... 95
4.3.3 NCT6106D Super IO Configuration ……………………….………………..….... 96
4.3.4 NCT6106D HW Monitor ………………………………......………………..……..... 98
4.3.5 Serial Port Console Redirection ……………..………….………….….…….….... 99
4.3.6 CPU Configuration ..……………………………………………..…………..………..... 99
4.3.7 SATA Configuration ……..……………………………..…………………………....... 100
4.3.8 Network Stack Configuration ……………..…………………………..………….... 100
4.3.9 CSM Configuration ……………………………..……………..……..…………………. 101
4.3.10 USB Configuration …………………………..………………………….………..…….. 102
4.4 Chipset ………..………………….…..….…..…………………………………………………..….... 103
4.4.1 System Agent (SA) Configuration ………….…………………..………………….. 103
4.4.2 PCH-IO Configuration ………….……………………….………………..…………….. 105
4.5 Security …………...….………………….…..….………………………………………..…………... 108
4.5.1 Administrators Password ……..………………………………..…………………….. 108
4.5.2 Users Password …….……………….…………….………………..…………………….. 108
4.6 Boot …………...……….….………………….…..………………………..…………..……………... 109
4.6.1 Setup Prompt Timeout ……………………..…………..…………………………….. 109
4.6.2 Bootup NumLock State ………….…………………………………..………………… 109
4.6.3 Full Screen Logo Show ……………………….…………………………..…...………. 109
4.6.4 Hard Driver BBS Priorities …………………………..………………………………... 109
4.7 Save & Exit …...……….….………………….…..….…..………………………………………..... 110
4.7.1 Save Changes and Reset ……………..……………………………..……..……...... 110
4.7.2 Discard Changes and Reset ………………………………............………………. 110
4.7.3 Restore Defaults …………………………………………………………..……………... 110
Page 4
RCO-3000 | User’s Manual
4
Revision
Disclaimer
All specifications and information in this User’s Manual are believed to be accurate and up to date. C&T
Solution Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of C&T Solution Inc. C&T Solution Inc. disclaims all warranties, express or implied, including, without limitation, those of
merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users must
take full responsibility for the application of the product.
Copyright Notice
All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or information storage and retrieval systems, without the prior written permission of C&T Solutions Inc. Copyright © 2015 C&T Solutions Inc.
Trademarks Acknowledgment
Intel®, Celeron® and Pentium® are trademarks of Intel Corporation. Windows® is registered trademark of Microsoft Corporation. AMI is trademark of American Megatrend Inc. IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation All other products and trademarks mentioned in this manual are trademarks of their respective owners.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution and ensure environment protection.
Prefaces
Revision
Description
Date
1.0 Manual Released
2016/08/23
1.1 Switches and Connectors Revised
2017/08/03
Page 5
RCO-3000 | User’s Manual
5
Safety Precautions
Before installing and using the equipment, please read the following precautions:
Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
The power outlet shall be installed near the equipment and shall be easily accessible.
Turn off the system power and disconnect the power cord from its source before making any
installation. Be sure both the system and the external devices are turned OFF. Sudden surge
of power could ruin sensitive components. Make sure the equipment is properly grounded.
When the power is connected, never open the equipment. The equipment should be opened
only by qualified service personnel.
Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
Avoid the dusty, humidity and temperature extremes.
Do not place heavy objects on the equipment.
If the equipment is not used for long time, disconnect it from the power to avoid being
damaged by transient over-voltage.
The storage temperature shall be above -30°C and below 85°C.
The computer is provided with a battery-powered real-time clock circuit. There is a danger of
explosion if incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer.
If one of the following situation arises, get the equipment checked be service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment does not work well or it cannot work according the user’s manual.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage.
Preface
Page 6
RCO-3000 | User’s Manual
6
Technical Support and Assistance
1. Visit the C&T Solution Inc website at www.Premioinc.com where you can find the latest information
about the product.
2. Contact your distributor, our technical support team or sales representative for technical support if
you need additional assistance. Please have following information ready before you call:
Model name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Conventions Used in this Manual
Preface
This indication alerts operators to an operation that, if not strictly observed, may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE
Page 7
RCO-3000 | User’s Manual
7
Package Contents
Before installation, please ensure all the items listed in the following table are included in the package.
Preface
Item
Description
Q’ty
1
RCO
-6000 Series Fanless Embedded System 1
2
Utility DVD Driver
1
3
Wall Mount Kit
1
4
Accessory Kit
1
5
DVI to VGA Adapter
1
Ordering Information
Model No. Product Description
RCO-6000
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN
RCO-6000-4L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 6x LAN
RCO-6000-4L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 LAN
RCO-6000-8L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 10x LAN
RCO-6000-8L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 LAN
RCO-6000-4P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x PoE
RCO-6000-4P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 PoE
RCO-6000-8P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x PoE
RCO-6000-8P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 PoE
RCO-6011E
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 1x PCIe x16 Expansion
RCO-6011E-4L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 6x LAN, 1x PCIe x16 Expansion
RCO-6011E-4L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 LAN, 1x PCIe x16 expansion
RCO-6011E-8L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH,
10x LAN, 1x PCIe x16 Expansion
RCO-6011E-8L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 LAN, 1x PCIe x16 Expansion
Page 8
RCO-3000 | User’s Manual
8
Preface
Model No. Product Description
RCO-6011E-4P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x PoE, 1x PCIe x16 Expansion
RCO-6011E-4P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 PoE, 1x PCIe x16 Expansion
RCO-6011E-8P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x PoE, 1x PCIe x16 Expansion
RCO-6011E-8P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 PoE, 1x PCIe x16 Expansion
RCO-6011P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 1x PCI Expansion
RCO-6011P-4L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH,
6x LAN, 1x PCI Expansion
RCO-6011P-4L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 LAN, 1x PCI Expansion
RCO-6011P-8L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 10x LAN, 1x PCI Expansion
RCO-6011P-8L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 LAN, 1x PCI Expansion
RCO-6011P-4P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x PoE, 1x PCI Expansion
RCO-6011P-4P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 PoE, 1x PCI Expansion
RCO-6011P-8P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x PoE, 1x PCI Expansion
RCO-6011P-8P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH,
2x LAN, 8x M12 PoE, 1x PCI Expansion
RCO-6022EE
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 2x PCIe x8 Expansion
RCO-6022EE-4L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 6x LAN, 2x PCIe x8 Expansion
RCO-6022EE-4L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 LAN, 2x PCIe x8 Expansion
RCO-6022EE-8L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 10x LAN, 2x PCIe x8 Expansion
RCO-6022EE-8L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 LAN, 2x PCIe x8 Expansion
RCO-6022EE-4P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x PoE, 2x PCIe x8 Expansion
RCO-6022EE-4P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 PoE, 2x PCIe x8 Expansion
RCO-6022EE-8P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH,
2x LAN, 8x PoE, 2x PCIe x8 Expansion
RCO-6022EE-8P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 PoE, 2x PCIe x8 Expansion
RCO-6022PP
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 2x PCI Expansion
RCO-6022PP-4L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 6x LAN, 2x PCI Expansion
RCO-6022PP-4L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 LAN, 2x PCI Expansion
Page 9
RCO-3000 | User’s Manual
9
Preface
Model No. Product Description
RCO-6022PP-8L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 10x LAN, 2x PCI Expansion
RCO-6022PP-8L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 LAN, 2x PCI Expansion
RCO-6022PP-4P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x PoE, 2x PCI Expansion
RCO-6022PP-4P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 PoE, 2x PCI Expansion
RCO-6022PP-8P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x PoE, 2x PCI Expansion
RCO-6022PP-8P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH,
2x LAN, 8x M12 PoE, 2x PCI Expansion
RCO-6022PE
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 1x PCIe x16, 1x PCI Expansion
RCO-6022PE-4L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 6x LAN, 1x PCIe x16, 1x PCI Expansion
RCO-6022PE-4L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x M12 LAN, 1x PCIe x16, 1x PCI Expansion
RCO-6022PE-8L
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 10x LAN, 1x PCIe x16, 1x PCI Expansion
RCO-6022PE-8L-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 LAN, 1x PCIe x16, 1x PCI Expansion
RCO-6022PE-4P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 4x PoE, 1x PCIe x16, 1x PCI Expansion
RCO-6022PE-4P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH,
2x LAN, 4x M12 PoE, 1x PCIe x16, 1x PCI Expansion
RCO-6022PE-8P
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x PoE, 1x PCIe x16, 1x PCI Expansion
RCO-6022PE-8P-M12
Superior Fanless Embedded System with LGA 1151 for Intel® 6th Gen Processor and Q170 PCH, 2x LAN, 8x M12 PoE, 1x PCIe x16, 1x PCI Expansion
Optional Accessories
Model No. Product Description
1
-E09A12001
Adapter AC/DC 24V 5A 120W with 3pin Terminal Block Plug 5.0mm Pitch, GST120A24
-CT
1
-E09A22101
Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug
5.0mm Pitch, GST220A24
-CT
SFICBL022
Power Cord, 3
-pin US Type, 180cm
1
-TPCD00002
Power Cord, European Type, 180cm
1
-TPCD00001
Power Cord, 3
-pin UK Type, 180cm
1
-TZZZ00001
DVI
-I(M) TO DVI-D(F) + VGA(F) Cable, L=120mm, C129P012H1211
Page 10
Chapter 1
Product Introductions
Page 11
RCO-3000 | User’s Manual
11
1.1 Overview
Based on 6th Gen. Intel® Core™ i7-6700TE (3.4GHz, Quad Core) / i5-6500TE (3.3GHz, Quad Core) / i3­6100TE (2.7GHz, Dual Core) or Pentium® G4400TE (2.4GHz, Dual Core) / Celeron® G3900TE (2.3GHz, Dual Core) Desktop processor, RCO-6000 series is an extreme features integration, outstanding system performance, versatile I/O connections, and rugged reliability fanless embedded systems. It offers dramatically enhanced CPU and graphics performance, wide power and feature scalability, and advanced features, modularize expansion I/O, rich connectivity interfaces, wide range (9~48V) DC power input, and high reliability even operating in temperature extremes (-25°C~+70°C).
Featuring with completely cable-less designed, high functional, one-piece housing design, and anti-
vibration, RCO-6000 series are ruggedized systems that can operate in harsh environments and easy to install and maintain. A build in over voltage protection (OVP), over current protection (OCP), reverse protection, and wide range DC power input makes RCO-6000 series are safety system for all industrial applications.
Chapter 1: Product Introductions
1.1.1 Key Features
LGA 1151 socket for 6th Gen. Intel® Core™ i7/i5/i3 or Pentium® / Celeron® Desktop Processor Intel® Q170 Chipset 2x 260-pin DDR4 SODIMM. Max up to 32GB Triple independent display supported by 1x DVI-I and 2x DisplayPort 2x Intel® GbE supporting Wake-on-LAN and PXE 2x Removable 2.5" SATA HDD Bay, 2x Internal 2.5” SATA SSD/HDD Bay supporting RAID 0, 1, 5, 10 4x Full-size Mini-PCIe Socket with 4x SIM Card Socket for communication or expansion modules 2x mSATA (Shared by 2x Mini-PCIe Socket) 2x External RS-232/422/485, 2x Internal RS-232/422/485
6x USB 3.0, 2x USB 2.0
8x Isolated DI, 8x Isolated DO 1x Mic-in, 1x Speak-out 9 to 48VDC wide range power input supporting AT/ATX mode 1x PCIe x16 Expansion (RCO-6011E Series Only) 1x PCI Expansion (RCO-6011P Series Only) 2x PCIe x8 Expansion (RCO-6022EE Series Only) 2x PCI Expansion (RCO-6022PP Series Only) 1x PCIe x16 and 1x PCI Expansion (RCO-6022PE Series Only) Remote Power On/Off Switch
RCO-6000 Series
RCO-6022 Series RCO-6011 Series
Page 12
RCO-3000 | User’s Manual
12
1.2 Hardware Specification
Chapter 1: Product Introductions
Processor System
• Support 6th Gen Intel® Core™ i3 / i5 / i7 / Pentium® /
Celeron® Desktop Processor (LGA 1151) with AMI
128Mbit SPI BIOS
- 6th Gen Intel® Core™ i7-6700TE, Quad Core, 8MB cache, up to 3.4 GHz
- 6th Gen Intel® Core™ i5-6500TE, Quad Core, 6MB Cache, up to 3.3 GHz
- 6th Gen Intel® Core™ i3-6100TE, Dual Core, 4MB Cache, 2.7 GHz
- Intel® Pentium G4400TE, Dual Core, 3MB Cache, 2.4 GHz
- Intel® Celeron G3900TE, Dual Core, 2MB Cache, 2.3 GHz
Memory
• 2x 260-Pin DDR4 1866/2133MHz SODIMM. Max. up to
32GB
Display
Triple Display
• 1x DVI-I, 1x VGA, and 2x DisplayPort
Expansion
• 4x Full-size Mini PCIe Socket for Wi-Fi / GSM / Expansion Module
• 2x Universal I/O Bracket
Ethernet
• 2x Intel® i210-AT GbE LAN Port, Support Wake-on-LAN and PXE
Audio
• Codec: Realtek ALC888S
• 1x Mic-in and 1x Speak-out
Watchdog Timer
• Software Programmable Supports 1~255 sec. System Reset
Storage
• 2x Removable 2.5" SATA HDD Bay
• 2x Internal 2.5" SATA HDD Bay
• 2x Internal mSATA Slot (Shared by 2x Mini-PCIe Socket)
• 2x External SIM Card Socket
• 2x Internal SIM Card Socket
• Support RAID 0, 1, 5, 10
I/O Ports
• 6x USB 3.0 Port
• 2x USB 2.0 Port
• 8 Isolated DI and 8 Isolated DO Port
• 2x DB9 for COM1~2, Support RS232/422/485 with Auto
Flow Control
• 2x Internal connector for COM3~4, Support RS232/422/485 with Auto Flow Control
• 6x Antenna Hole
• 1x Power Switch
• 1x AT/ATX Switch
• 1x Remote Power on/off Connector
Digital Input & Output
• 8x Digital Input (Source Type)
- Input Voltage (Dry Contact): Logic 0: Close to GND Logic 1: Open
- Input Voltage: Logic 0: 3V max. Logic 1: 5V min. (DI to COM-)
• 8x Digital Output
- Supply Voltage: 5~30VDC
- Sink Current: 200 mA Max. Per Channel
Power
• Support AT, ATX Mode
• 1x 3-pin Terminal Block Connector with Power Input
9~48VDC
• 1x Optional AC/DC 24V/5A, 120W Power Adapter
Environment
• Operating Temperature: Ambient with Air Flow:
-25°C to 70°C (with Industrial Grade Peripherals)
• Storage Temperature: -30°C to 85°C
• Relative humidity: 10%~95% (non-condensing)
Physical
• RCO-6000 Series
Dimension (WxDxH, mm): 240 x 261 x 79 mm
Weight: 4.37 kg ~ 5.41 kg
• RCO-6011 Series
Dimension (WxDxH, mm): 240 x 261 x 107 mm Weight: TBC
• RCO-6022 Series
Dimension (WxDxH, mm): 240 x 261 x 127 mm Weight: 5.54 kg ~ 6.64 kg
• Construction: Extruded Aluminum with Heavy Duty Metal
• Mounting: Wall/ DIN-Rail Mounting
Operating System
• Windows® 7
• WES7
• Windows® 8.1
• WES8.1
• Windows 10
• Linux kernel 3.X
Certifications
• CE
• FCC Class A
Page 13
RCO-3000 | User’s Manual
13
1.3 System I/O
1.3.1 RCO-6000
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
Page 14
RCO-3000 | User’s Manual
14
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
Page 15
RCO-3000 | User’s Manual
15
1.3.2 RCO-6000-4L(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
LAN Port
Used to connect the system to a local area network (RCO-6000-4L Only)
PoE Port
Used to connect the system to a local area network with power over Ethernet (RCO-6000-4P Only)
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 16
RCO-3000 | User’s Manual
16
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
Page 17
RCO-3000 | User’s Manual
17
1.3.3 RCO-6000-4L(P)-M12
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
M12 LAN Port
Used to connect the system to a local area network (RCO-6000-4L-M12 Only)
M12 PoE Port
Used to connect the system to a local area network with power over Ethernet (RCO-6000-4P-M12 Only)
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 18
RCO-3000 | User’s Manual
18
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
Page 19
RCO-3000 | User’s Manual
19
1.3.4 RCO-6000-8L(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
LAN Port
Used to connect the system to a local area network (RCO-6000-8L Only)
PoE Port
Used to connect the system to a local area network with power over Ethernet (RCO-6000-8P Only)
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 20
RCO-3000 | User’s Manual
20
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
Page 21
RCO-3000 | User’s Manual
21
1.3.5 RCO-6000-8L(P)-M12
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
M12 LAN Port
Used to connect the system to a local area network (RCO-6000-8L-M12 Only)
M12 PoE Port
Used to connect the system to a local area network with power over Ethernet (RCO-6000-8P-M12 Only)
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 22
RCO-3000 | User’s Manual
22
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
Page 23
RCO-3000 | User’s Manual
23
1.3.6 RCO-6011E(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
Page 24
RCO-3000 | User’s Manual
24
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6011E Only)
Used to plug PCI Card (RCO-6011P Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 25
RCO-3000 | User’s Manual
25
1.3.7 RCO-6011E(P)-4L(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
LAN Port
Used to connect the system to a local area network (RCO-6011E-4L & RCO-6011P-4L Only)
PoE Port
Used to connect the system to a local area network with power over Ethernet (RCO-6011E-4P & RCO-6011P-4P Only)
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 26
RCO-3000 | User’s Manual
26
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6011E-4L & RCO-
6011E-4P Only)
Used to plug PCI Card (RCO-6011P-4L & RCO­6011P-4P Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 27
RCO-3000 | User’s Manual
27
1.3.8 RCO-6011E(P)-4L(P)-M12
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
M12 LAN Port
Used to connect the system to a local area network (RCO-6011E-4L-M12 & RCO-6011P-4L-M12 Only)
M12 PoE Port
Used to connect the system to a local area network with power over Ethernet (RCO-6011E-4P-M12 & RCO-6011P-4P-M12 Only)
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 28
RCO-3000 | User’s Manual
28
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6011E-4L-M12 &
RCO-6011E-4P-M12 Only)
Used to plug PCI Card (RCO-6011P-4L-M12 & RCO-6011P-4P-M12 Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 29
RCO-3000 | User’s Manual
29
1.3.9 RCO-6011E(P)-8L(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
LAN Port
Used to connect the system to a local area network (RCO-6011E-8L & RCO-6011P-8L Only)
PoE Port
Used to connect the system to a local area network with power over Ethernet (RCO-6011E-8P & RCO-6011P-8P Only)
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 30
RCO-3000 | User’s Manual
30
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6011E-8L & RCO-
6011E-8P Only)
Used to plug PCI Card (RCO-6011P-8L & RCO­6011P-8P Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 31
RCO-3000 | User’s Manual
31
1.3.10 RCO-6011E(P)-8L(P)-M12
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
M12 LAN Port
Used to connect the system to a local area network (RCO-6011E-8L-M12 & RCO-6011P-8L­M12 Only)
M12 PoE Port
Used to connect the system to a local area network with power over Ethernet (RCO-6011E-8P-M12 & RCO-6011P-8P-M12 Only)
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 32
RCO-3000 | User’s Manual
32
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6011E-8L-M12 &
RCO-6011E-8P-M12 Only)
Used to plug PCI Card (RCO-6011P-8L-M12 & RCO-6011P-8P-M12 Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 33
RCO-3000 | User’s Manual
33
1.3.11 RCO-6022EE(PP/PE)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
Page 34
RCO-3000 | User’s Manual
34
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial
device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card
(RCO-6022EE & RCO-6022PE Only)
Used to plug PCI Card (RCO-6022PP & RCO-6022PE Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 35
RCO-3000 | User’s Manual
35
1.3.12 RCO-6022EE(PP/PE)-4L(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
LAN Port
Used to connect the system to a local area
network (RCO-6022EE-4L & RCO-6022PP-4L &
RCO-6022PE-4L Only)
PoE Port
Used to connect the system to a local area
network with power over Ethernet (RCO-6022EE-4P & RCO-6022PP-4P & RCO­6022PE-4P Only)
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 36
RCO-3000 | User’s Manual
36
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6022EE-4L & RCO-6022EE-4P & RCO-6022PE-4L & RCO-6022PE-4P Only) Used to plug PCI Card (RCO-6022PP-4L & RCO-6022PP-4P & RCO-6022PE-4L & RCO-6022PE-4P Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 37
RCO-3000 | User’s Manual
37
1.3.13 RCO-6022EE(PP/PE)-4L(P)-M12
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
M12 LAN Port
Used to connect the system to a local area
network (RCO-6022EE-4L-M12 & RCO-6022PP-
4L-M12 & RCO-6022PE-4L-M12 Only)
M12 PoE Port
Used to connect the system to a local area
network with power over Ethernet (RCO-6022EE-4P-M12 & RCO-6022PP-4P-M12 & RCO-6022PE-4P-M12 Only)
Universal I/O Bracket
Used to customized I/O output
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 38
RCO-3000 | User’s Manual
38
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6022EE-4L-M12 & RCO-6022EE-4P-M12 & RCO-6022PE-4L-M12 & RCO-6022PE-4P-M12 Only) Used to plug PCI Card (RCO-6022PP-4L-M12 & RCO-6022PP-4P-M12 & RCO-6022PE-4L-M12 &
RCO-6022PE-4P-M12 Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 39
RCO-3000 | User’s Manual
39
1.3.14 RCO-6022EE(PP/PE)-8L(P)
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
LAN Port
Used to connect the system to a local area
network (RCO-6022EE-8L & RCO-6022PP-8L &
RCO-6022PE-8L Only)
PoE Port
Used to connect the system to a local area
network with power over Ethernet (RCO-6022EE-8P & RCO-6022PP-8P & RCO-6022PE-8P Only)
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 40
RCO-3000 | User’s Manual
40
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6022EE-8L & RCO-6022EE-8P & RCO-6022PE-8L & RCO-6022PE-8P Only) Used to plug PCI Card (RCO-6022PP-8L & RCO-6022PP-8P &
RCO-6022PE-8L & RCO-6022PE-8P Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 41
RCO-3000 | User’s Manual
41
1.3.15 RCO-6022EE(PP/PE)-8L(P)-M12
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 port
Used to connect USB 2.0/1.1 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM2 support RS232/422/485 serial device
M12 LAN Port
Used to connect the system to a local area
network (RCO-6022EE-8L-M12 & RCO-6022PP-
8L-M12 & RCO-6022PE-8L-M12 Only)
M12 PoE Port
Used to connect the system to a local area
network with power over Ethernet (RCO-6022EE-8P-M12 & RCO-6022PP-8P-M12 & RCO-6022PE-8P-M12 Only)
HDD port
Removable 2.5" SATA HDD Area
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 42
RCO-3000 | User’s Manual
42
Chapter 1: Product Introductions
Rear Panel
DC IN
Used to plug a DC power input with terminal block
Speaker-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input and 4 digital output
COM port
COM1 ~ COM2 support RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.0 port
Used to connect USB 3.0/2.0/1.1 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal block
Expansion Area
Used to plug PCIe Card (RCO-6022EE-8L-M12 & RCO-6022EE-8P-M12 & RCO-6022PE-8L-M12 & RCO-6022PE-8P-M12 Only) Used to plug PCI Card (RCO-6022PP-8L-M12 & RCO-6022PP-8P-M12 & RCO-6022PE-8L-M12 &
RCO-6022PE-8P-M12 Only)
Antenna hole
Used to connect an antenna for optional Mini­PCIe WiFi module
Page 43
RCO-3000 | User’s Manual
43
1.4 Mechanical Dimensions
1.4.1 RCO-6000 / RCO-6000-4L(P) / RCO-6000-4L(P)-M12 / RCO-6000-8L(P) / RCO-6000-8L(P)-M12
Unit: mm
Chapter 1: Product Introductions
Page 44
RCO-3000 | User’s Manual
44
1.4.2 RCO-6011E / RCO-6011E-4L(P) / RCO-6011E-4L(P)-M12 / RCO-6011E-8L(P) / RCO-6011E-8L(P)-M12 / RCO-6011P / RCO-6011P-4L(P) / RCO-6011P-4L(P)-M12 / RCO-6011P-8L(P) / RCO-6011P-8L(P)-M12
Unit: mm
Chapter 1: Product Introductions
Page 45
RCO-3000 | User’s Manual
45
1.4.3 RCO-6022EE / RCO-6022EE-4L(P) / RCO-6022EE-4L(P)-M12 / RCO-6022EE-8L(P) / RCO-6022EE-8L(P)-M12 / RCO-6022PP / RCO-6022PP-4L(P) / RCO-6022PP-4L(P)-M12 / RCO-6022PP-8L(P) / RCO-6022PP-8L(P)-M12 / RCO-6022PE / RCO-6022PE-4L(P) / RCO-6022PE-4L(P)-M12 / RCO-6022PE-8L(P) / RCO-6022PE-8L(P)-M12
Unit: mm
Chapter 1: Product Introductions
Page 46
Chapter 2
Switches and Connectors
Page 47
RCO-3000 | User’s Manual
47
2.1 Switch and Connector Locations
2.1.1 Top View
Chapter 2: Switches and Connectors
Page 48
RCO-3000 | User’s Manual
48
2.1.2 Bottom View
Chapter 2: Switches and Connectors
Page 49
RCO-3000 | User’s Manual
49
2.2 Connector / Switch Definition
List of Connector / Switch
Chapter 2: Switches and Connectors
Connector Location Definition
AT_ATX
1
AT
/ ATX Power Mode Switch
CLR_CMOS
1
Clear
BIOS Switch
PWR_SW
1
Power
Switch
RESET
1
Reset
Switch
USB
3_1,USB3_2
USB 3.0 Port
USB
2_1, USB2_2
USB 2.0 Port
USB
2_CN1
USB 2.0 Port
SIM
1, SIM2, SIM3, SIM4
SIM
Card Socket
COM1_2_1
RS232
/ RS422 / RS485 Connector
COM3_1, COM4_1
RS232
/ RS422 / RS485 Connector
DC_IN
1
3
-pin DC 9~48V Power Input Connector
DVI_I
1
DVI
-I Connector
DP1,DP2
DisplayPort
Connector
SPK_OUT
1
Speaker
-out Jack
MIC_IN
1
Mic
-in Jack
DIO1
8DI
/ 8DO Connector
PWR_SW
2
Remote
Power Switch
CN1 LAN1 and USB3.0 Ports
CN2 LAN2 and USB3.0 Ports
LAN
3, LAN4, LAN5, LAN6, LAN7, LAN8,
LAN
9, LAN10
LAN Port / M12 LAN Port
MINIPCIE
1, MINIPCIE2
Mini PCI
-Express Socket
CN
3, CN4
Mini PCI
-Express / mSATA Socket
SATA
1, SATA2, SATA3, SATA4
SATA
with Power Connector
POWER1, POWER2,
POWER3, POWER4
Power Connector
PCIE1
PCI
-Express X1 Slot
PCIE2
PCI
-Express X16 Slot
PWR_LED
1
Power LED Status
HDD_LED
1
HDD Access LED Status
WDT_LED
1
Watchdog LED Status
GPIO_LED
1
GPIO LED Status
LAN
1_LINK1, LAN2_LINK1
LAN
Link LED
LAN
1_ACT1, LAN2_ACT1
LAN
Active LED
Page 50
RCO-3000 | User’s Manual
50
2.3 Switches Definitions
Switch Definition
1-2 (Left)
AT Power Mode
2-3 (Right)
ATX Power Mode
（Default）
AT_ATX1: AT / ATX Power Mode Switch
CLR_CMOS1: Clear BIOS Switch
Switch Definition
Off Normal Status (Default)
ON Clear BIOS
2.4 Connectors Definitions
PWR_SW1: Power Button
Pin Definition Pin Definition
1 NC 4 GND
2
Power Button
5 NC
3 NC 6 GND
RESET1 : Reset Button
Pin Definition
1 RESET
2 GND
USB3_1: USB3.0 Connector, Type A
Pin
Definition Pin
Definition
1 +5V 6 USB3_RX5+ 2 USB2_D5- 7 GND 3 USB2_D5+ 8 USB3_TX5­4 GND 9 USB3_TX5+ 5 USB3_RX5-
USB3_2: USB3.0 Connector, Type A
Pin
Definition Pin
Definition
1 +5V 6 USB3_RX6+ 2 USB2_D6- 7 GND 3 USB2_D6+ 8 USB3_TX6-
4 GND 9 USB3_TX6+
5 USB3_RX6-
Chapter 2: Switches and Connectors
Page 51
RCO-3000 | User’s Manual
51
USB2_1: USB3.0 Connector, Type A
Pin Definition
1 +5V
2 USB2_D7-
3 USB2_D7+
4 GND
USB2_2: USB3.0 Connector, Type A
Pin Definition
1 +5V
2 USB2_D8-
3 USB2_D8+
4 GND
USB2_CN1: USB2.0 Ports Connector Type: 2X5 10-pin box header, 2.0mm pitch
Pin
Definition Pin
Definition
1 +5V 2 +5V 3 USB2_D9+ 4 USB2_D10+
5 USB2_D9- 6 USB2_D10-
7 GND 8 GND 9 Cable Shield 10 Cable Shield
SIM1：SIM Card Socket
Pin Definition Pin Definition
C1 UIM1_PWR C6 UIM1_VPP
C2 UIM1_RESET C7 UIM1_DATA
C3 UIM1_CLK CD NC
C5 GND COM
GND
SIM2：SIM Card Socket
Pin Definition Pin Definition
C1 UIM2_PWR C6 UIM2_VPP
C2 UIM2_RESET C7 UIM2_DATA
C3 UIM2_CLK CD NC
C5 GND COM
GND
Chapter 2: Switches and Connectors
Page 52
RCO-3000 | User’s Manual
52
SIM3：SIM Card Socket
Pin Definition Pin Definition
C1 UIM3_PWR C5 GND
C2 UIM3_RESET C6 UIM3_VPP
C3 UIM3_CLK C7 UIM3_DATA
SIM4：SIM Card Socket
Pin Definition Pin Definition
C1 UIM4_PWR C5 GND
C2 UIM4_RESET C6 UIM4_VPP
C3 UIM4_CLK C7 UIM4_DATA
COM1_2_1: RS232 / RS422 / RS485 Connector
Connector Type: 9-pin D-Sub
COM1
Pin
RS232 Definition
RS422 / 485 Full
Duplex Definition
RS485 Half Duplex
Definition
1 DCD1 TX1- DATA1­2 RxD1 TX1+ DATA1+ 3 TxD1 RX1+ 4 DTR1 RX1- 5 GND 6 DSR1 7 RTS1 8 CTS1 9 RI1
COM2
Pin
RS232 Definition
RS422 / 485 Full
Duplex Definition
RS485 Half Duplex
Definition
10 DCD2 TX2- DATA2­11 RxD2 TX2+ DATA2+ 12 TxD2 RX2+ 13 DTR2 RX2- 14 GND 15 DSR2 16 RTS2 17 CTS2 18 RI2
Chapter 2: Switches and Connectors
Page 53
RCO-3000 | User’s Manual
53
COM3_1： RS232 / RS422 / RS485 Connector
Connector Type: 2X5 10-pin box header, 2.54mm pitch
COM3_1
Pin
RS232 Definition
RS422 / 485 Full
Duplex Definition
RS485 Half Duplex
Definition
1 DCD3 TX3- DATA3-
2 RxD3 TX3+ DATA3+
3 TxD3 RX3+
4 DTR3 RX3-
5 GND
6 DSR3
7 RTS3
8 CTS3
9 RI3
COM4_1： RS232 / RS422 / RS485 Connector
Connector Type: 2X5 10-pin box header, 2.54mm pitch
COM4_1
Pin
RS232 Definition
RS422 / 485 Full
Duplex Definition
RS485 Half Duplex
Definition
1 DCD4 TX4- DATA4-
2 RxD4 TX4+ DATA4+
3 TxD4 RX4+
4 DTR4 RX4-
5 GND
6 DSR4
7 RTS4
8 CTS4
9 RI4
Chapter 2: Switches and Connectors
Page 54
RCO-3000 | User’s Manual
54
DC_IN1: DC Power Input Connector (+9~48V)
Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch
Pin Definition
1 +9~48VIN 2 Chassis GND 3 GND
DVI_I1: DVI-I Connector
Pin Definition Pin Definition
1 DVI_TX2- 16 DVI Hot Plug Detect 2 DVI_TX2+ 17 DVI_TX0­3 GND 18 DVI_TX0+ 4 NC 19 GND 5 NC 20 VGA_DDC_CLOCK 6 DVI_DDC_CLOCK 21 VGA_DDC_DATA 7 DVI_DDC_DATA 22 GND 8 VGA VSYNC 23 DVI_TXCLK+
9 DVI_TX1- 24 DVI_TXCLK­10 DVI_TX1+ C1 VGA_RED 11 GND C2 VGA_GREEN 12 NC C3 VGA_BLUE 13 NC C4 VGA_HSYNC 14 +5V C5 GND 15 GND
DP1: DisplayPort Connector
Pin Definition Pin Definition
1 DP1_LANE0_P 11 GND 2 GND 12 DP1_LANE3_N 3 DP1_LANE0_N 13 GND 4 DP1_LANE1_P 14 GND 5 GND 15 DP1_AUX_P 6 DP1_LANE1_N 16 GND 7 DP1_LANE2_P 17 DP1_AUX_N 8 GND 18 DP1_HPD 9 DP1_LANE2_N 19 GND
10 DP1_LANE3_P 20 DP1_PWR
Chapter 2: Switches and Connectors
Page 55
RCO-3000 | User’s Manual
55
DP2: DisplayPort Connector
Pin Definition Pin Definition
1 DP2_LANE0_P 11 GND
2 GND 12 DP2_LANE3_N
3 DP2_LANE0_N 13 GND
4 DP2_LANE1_P 14 GND
5 GND 15 DP2_AUX_P
6 DP2_LANE1_N 16 GND
7 DP2_LANE2_P 17 DP2_AUX_N
8 GND 18 DP2_HPD
9 DP2_LANE2_N 19 GND
10 DP2_LANE3_P 20 DP2_PWR
SPK_OUT1 : Speaker-out Jack (Green) Connector Type: 5-pin Phone Jack
Pin Definition
1 GND 2 OUT_R 3 NC 4 GND 5 OUT_L
MIC_IN1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack
Pin Definition
1 GND
2 MIC_R
3 NC
4 GND
5 MIC_L
Chapter 2: Switches and Connectors
Page 56
RCO-3000 | User’s Manual
56
DIO1: Digital Input / Output Connector
Connector Type: Terminal Block 2X9 18-pin, 3.5mm pitch
Pin Definition Pin Definition
1 DI1 2 DO1
3 DI2 4 DO2
5 DI3 6 DO3
7 DI4 8 DO4
9 DI5 10 DO5
11 DI6 12 DO6
13 DI7 14 DO7
15 DI8 16 DO8
17 DC INPUT 18 GND
Chapter 2: Switches and Connectors
Page 57
RCO-3000 | User’s Manual
57
PWR_SW2 : Remote Power Switch Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch
Pin Definition
1 Power Button 2 GND
Digital Input Wurung
Digital Output Wurung
Chapter 2: Switches and Connectors
Page 58
RCO-3000 | User’s Manual
58
CN1: LAN1 and USB3.0 Ports
Connector Type: RJ45 port with LEDs and dual USB3.0 ports
Pin
Definition Pin
Definition Pin Definition
1 +5V 10 +5V 20 LAN1_MDI0P
2 USB2_D1- 11 USB2_D2- 21 LAN1_MDI0N
3 USB2_D1+ 12 USB2_D2+ 22 LAN1_MDI1P
4 GND 13 GND 23 LAN1_MDI2P
5 USB3_RX1- 14 USB3_RX2- 24 LAN1_MDI2N
6 USB3_RX1+ 15 USB3_RX2+ 25 LAN1_MDI1N
7 GND 16 GND 26 LAN1_MDI3P
8 USB3_TX1- 17 USB3_TX2- 27 LAN1_MDI3N
9 USB3_TX1+ 18 USB3_TX2+
CN2: LAN2 and USB3.0 Ports
Connector Type: RJ45 port with LEDs and dual USB3.0 ports
Pin
Definition Pin
Definition Pin Definition
1 +5V 10 +5V 20 LAN2_MDI0P
2 USB2_D3- 11 USB2_D4- 21 LAN2_MDI0N
3 USB2_D3+ 12 USB2_D4+ 22 LAN2_MDI1P
4 GND 13 GND 23 LAN2_MDI2P
5 USB3_RX3- 14 USB3_RX4- 24 LAN2_MDI2N
6 USB3_RX3+ 15 USB3_RX4+ 25 LAN2_MDI1N
7 GND 16 GND 26 LAN2_MDI3P
8 USB3_TX3- 17 USB3_TX4- 27 LAN2_MDI3N
9 USB3_TX3+ 18 USB3_TX4+
Chapter 2: Switches and Connectors
Page 59
RCO-3000 | User’s Manual
59
Chapter 2: Switches and Connectors
LAN3, LAN4, LAN5, LAN6, LAN7, LAN8, LAN9, LAN10 : RJ45 with LEDs Port
Connector Type: RJ45 Connector
Pin
LAN3~LAN10
Definition
Pin
LAN3~LAN10
Definition
1 LAN_MDI0P 5 LAN_MDI2N 2 LAN_MDI0N 6 LAN_MDI1N 3 LAN_MDI1P 7 LAN_MDI3P 4 LAN_MDI2P 8 LAN_MDI3N
Link LED Status LAN3~LAN10 Definition
Act LED Status
LAN3~LAN10 Definition
Steady Orange 1Gbps Network Link Blinking Yellow Data Activity
Steady Green 100Mbps Network Link Off No Activity
Off 10Mbps Network Link
LAN3, LAN4, LAN5, LAN6, LAN7, LAN8, LAN9, LAN10 : M12 Lan Port
Connector Type: M12 X-code Female Connector
Pin
LAN3~LAN10
Definition
Pin
LAN3~LAN10
Definition
1 LAN_MDI0P 5 LAN_MDI3N 2 LAN_MDI0N 6 LAN_MDI3N 3 LAN_MDI1P 7 LAN_MDI2P 4 LAN_MDI1N 8 LAN_MDI2N
Page 60
RCO-3000 | User’s Manual
60
MINIPCIE1: Mini PCI-Express Socket
MINIPCIE2: Mini PCI-Express Socket
Pin
Definition
Pin
Definition
Pin
Definition
1 WAKE# 19
NC 37
GND
2 +3.3V 20
+3.3V 38
USB2_D11+
3 NC 21
GND 39
+3.3V
4 GND 22
MINIPCIE RST# 40
GND
5 NC 23
MINIPCIE_RXN11 41
+3.3V
6 +1.5V 24
+3.3V 42
NC
7 CLKREQ0# 25
MINIPCIE_RXP11 43
GND
8 USIM1_VCC 26
GND 44
NC
9 GND 27
GND 45
NC
10
USIM1_DATA 28
+1.5V 46
NC
11
MINIPCIE_CLKN0 29
GND 47
NC
12
USIM1_CLK 30
SMB_CLK 48
+1.5V
13
MINIPCIE_CLKP0 31
MINIPCIE_TXN11 49
NC
14
USIM1_RST 32
SMB_DATA 50
GND
15
GND 33
MINIPCIE_TXP11 51
NC
16
USIM1_VPP 34
GND 52
+3.3V
17
NC 35
GND
18
GND 36
USB2_D11-
Pin
Definition
Pin
Definition
Pin
Definition
1 WAKE# 19
NC 37
GND
2 +3.3V 20
+3.3V 38
USB2_D12+
3 NC 21
GND 39
+3.3V
4 GND 22
MINIPCIE RST# 40
GND
5 NC 23
MINIPCIE_RXN2 41
+3.3V
6 +1.5V 24
+3.3V 42
NC
7 CLKREQ2# 25
MINIPCIE_RXP2 43
GND
8 USIM2_VCC 26
GND 44
NC
9 GND 27
GND 45
NC
10
USIM2_DATA 28
+1.5V 46
NC
11
MINIPCIE_CLKN2 29
GND 47
NC
12
USIM2_CLK 30
SMB_CLK 48
+1.5V
13
MINIPCIE_CLKP2 31
MINIPCIE_TXN2 49
NC
14
USIM2_RST 32
SMB_DATA 50
GND
15
GND 33
MINIPCIE_TXP2 51
NC
16
USIM2_VPP 34
GND 52
+3.3V
17
NC 35
GND
18
GND 36
USB2_D12-
Chapter 2: Switches and Connectors
Page 61
RCO-3000 | User’s Manual
61
CN3: Mini PCI-Express / mSATA Socket
CN4: Mini PCI-Express / mSATA Socket
Pin
Definition
Pin
Definition
Pin
Definition
1 WAKE# 19
NC 37
GND
2 +3.3V 20
+3.3V 38
USB_D13+
3 NC 21
GND 39
+3.3V
4 GND 22
MINIPCIE RST# 40
GND
5 NC 23
MINIPCIE_RXN4
(SATA_RXN4)
41
+3.3V
6 +1.5V 24
+3.3V 42
NC
7 CLKREQ1# 25
MINIPCIE_RXP4
(SATA_RXP4)
43
GND
8 USIM3_VCC 26
GND 44
NC
9 GND 27
GND 45
NC
10
USIM3_DATA 28
+1.5V 46
NC
11
MINIPCIE_CLKN4 29
GND 47
NC
12
USIM3_CLK 30
SMB_CLK 48
+1.5V
13
MINIPCIE_CLKP4 31
MINIPCIE_TXN4
(SATA_TXN4)
49
NC
14
USIM3_RST 32
SMB_DATA 50
GND
15
GND 33
MINIPCIE_TXP4
(SATA_TXP4)
51
NC
16
USIM3_VPP 34
GND 52
+3.3V
17
NC 35
GND
18
GND 36
USB_D13-
Pin
Definition
Pin
Definition
Pin
Definition
1 WAKE# 19
NC 37
GND
2 +3.3V 20
+3.3V 38
USB_D14+
3 NC 21
GND 39
+3.3V
4 GND 22
MINIPCIE RST# 40
GND
5 NC 23
MINIPCIE_RXN12
(SATA_RXN5)
41
+3.3V
6 +1.5V 24
+3.3V 42
NC
7 CLKREQ3# 25
MINIPCIE_RXP12
(SATA_RXP5)
43
GND
8 USIM4_VCC 26
GND 44
NC
9 GND 27
GND 45
NC
10
USIM4_DATA 28
+1.5V 46
NC
11
MINIPCIE_CLKN3 29
GND 47
NC
12
USIM4_CLK 30
SMB_CLK 48
+1.5V
13
MINIPCIE_CLKP3 31
MINIPCIE_TXN12
(SATA_TXN5)
49
NC
14
USIM4_RST 32
SMB_DATA 50
GND
15
GND 33
MINIPCIE_TXP12
(SATA_TXP5)
51
NC
16
USIM4_VPP 34
GND 52
+3.3V
17
NC 35
GND
18
GND 36
USB_D14-
Chapter 2: Switches and Connectors
Page 62
RCO-3000 | User’s Manual
62
SATA1, SATA2: SATA with Power Connector
Pin
SATA1
Definition
Pin
SATA1
Definition
Pin
SATA2
Definition
Pin
SATA2
Definition
1 GND 12
GND 1 GND 12
GND
2
SATA_TXP0
13
GND 2 SATA_TXP1 13
GND
3
SATA_TXN0
14
+5V 3
SATA_TXN1
14
+5V
4 GND 15
+5V 4 GND 15
+5V
5
SATA_RXN0
16
+5V 5
SATA_RXN1
16
+5V
6
SATA_RXP0
17
GND 6
SATA_RXP1
17
GND
7 GND 18
GND 7 GND 18
GND
8 +3.3V 19
GND 8 +3.3V 19
GND
9 +3.3V 20
+12V 9 +3.3V 20
+12V
10
+3.3V 21
+12V 10
+3.3V 21
+12V
11
GND 22
+12V 11
GND 22
+12V
SATA3, SATA4: SATA with Power Connector
Pin
SATA1
Definition
Pin
SATA1
Definition
Pin
SATA2
Definition
Pin
SATA2
Definition
1 GND 12
GND 1 GND 12
GND
2
SATA_TXP2
13
GND 2 SATA_TXP3 13
GND
3
SATA_TXN2
14
+5V 3
SATA_TXN3
14
+5V
4 GND 15
+5V 4 GND 15
+5V
5
SATA_RXN2
16
+5V 5
SATA_RXN3
16
+5V
6
SATA_RXP2
17
GND 6
SATA_RXP3
17
GND
7 GND 18
GND 7 GND 18
GND
8 +3.3V 19
GND 8 +3.3V 19
GND
9 +3.3V 20
+12V 9 +3.3V 20
+12V
10
+3.3V 21
+12V 10
+3.3V 21
+12V
11
GND 22
+12V 11
GND 22
+12V
Chapter 2: Switches and Connectors
Page 63
RCO-3000 | User’s Manual
63
POWER1, POWER2, POWER3, POWER4: Power Connector
Connector Type: 1X4-pin Wafer, 2.0mm pitch
Pin Definition
1 +5V 2 GND 3 GND 4 +12V
PCIE1: PCI-Express X1 Socket Connector Type: PCI-Express X1 Slot
Pin Definition Pin
Definition
A1 NC B1 +12V
A2 +12V B2 +12V
A3 +12V B3 +12V
A4 GND B4 GND
A5 NC B5 SMB_CLK
A6 NC B6 SMB_DATA
A7 NC B7 GND
A8 NC B8 +3.3V
A9 +3.3V B9 NC
A10 +3.3V B10
+3.3VSB
A11 PCIE_RESET# B11
PCIE_WAKE#
A12 GND B12
+12V
A13 PCIE_CLKP1 B13
GND
A14 PCIE_CLKN1 B14
PCIE_TXP11
A15 GND B15
PCIE_TXN11
A16 PCIE_RXP11 B16
GND
A17 PCIE_RXN11 B17
NC
A18 GND B18
GND
Chapter 2: Switches and Connectors
Page 64
RCO-3000 | User’s Manual
64
PCIE1: PCI-Express X16 Socket Connector Type: PCI-Express X16 Slot
Pin Definition Pin Definition Pin Definition Pin Definition
A1 PCIE_PRSNT1 A42
GND B1 +12V B42
PEG_TXN6
A2 +12V A43
PEG_RXP6 B2 +12V B43
GND
A3 +12V A44
PEG_RXN6 B3 +12V B44
GND
A4 GND A45
GND B4 GND B45
PEG_TXP7
A5 NC A46
GND B5 SMB_CLK B46
PEG_TXN7
A6 NC A47
PEG_RXP7 B6 SMB_DATA B47
GND
A7 NC A48
PEG_RXN7 B7 GND B48
PRSNT2_3
A8 NC A49
GND B8 +3.3V B49
GND
A9 +3.3V A50
NC B9 NC B50
PEG_TXP8
A10
+3.3V A51
GND B10
+3.3VSB B51
PEG_TXN8
A11 PCIE_RESET# A52
PEG_RXP8 B11
PCIE_WAKE# B52
GND
A12
GND A53
PEG_RXN8 B12
NC B53
GND
A13
PEG_CLK_P A54
GND B13
GND B54
PEG_TXP9
A14
PEG_CLK_N A55
GND B14
PEG_TXP0 B55
PEG_TXN9
A15
GND A56
PEG_RXP9 B15
PEG_TXN0 A56
GND
A16
PEG_RXP0 A57
PEG_RXN9 B16
GND B57
GND
A17
PEG_RXN0 A58
GND B17
PRSNT2_1 B58
PEG_TXP10
A18
GND A59
GND B18
GND B59
PEG_TXN10
A19
NC A60
PEG_RXP10 B19
PEG_TXP1 B60
GND
A20
GND A61
PEG_RXN10 B20
PEG_TXN1 B61
GND
A21
PEG_RXP1 A62
GND B21
GND B62
PEG_TXP11
A22
PEG_RXN1 A63
GND B22
GND B63
PEG_TXN11
A23
GND A64
PEG_RXP11 B23
PEG_TXP2 B64
GND
A24
GND A65
PEG_RXN11 B24
PEG_TXN2 B65
GND
A25
PEG_RXP2 A66
GND B25
GND B66
PEG_TXP12
A26
PEG_RXN2 A67
GND B26
GND B67
PEG_TXN12
A27
GND A68
PEG_RXP12 B27
PEG_TXP3 B68
GND
A28
GND A69
PEG_RXN12 B28
PEG_TXN3 B69
GND
A29
PEG_RXP3 A70
GND B29
GND B70
PEG_TXP13
A30
PEG_RXN3 A71
GND B30
NC B71
PEG_TXN13
A31
GND A72
PEG_RXP13 B31
PRSNT2_2 B72
GND
A32
NC A73
PEG_RXN13 B32
GND B73
GND
A33
NC A74
GND B33
PEG_TXP4 B74
PEG_TXP14
A34
GND A75
GND B34
PEG_TXN4 B75
PEG_TXN14
A35
PEG_RXP4 A76
PEG_RXP14 B35
GND B76
GND
A36
PEG_RXN4 A77
PEG_RXN14 B36
GND B77
GND
A37
GND A78
GND B37
PEG_TXP5 B78
PEG_TXP15
A38
GND A79
GND B38
PEG_TXN5 B79
PEG_TXN15
A39
PEG_RXP5 A80
PEG_RXP15 B39
GND B80
GND
A40
PEG_RXN5 A81
PEG_RXN15 B40
GND B81
PRSNT2_4
A41
GND A82
GND B41
PEG_TXP6 B82
NC
Chapter 2: Switches and Connectors
Page 65
RCO-3000 | User’s Manual
65 65
Chapter 2: Switches and Connectors
PWR_LED1: Power LED Status
Pin Definition
1 POWER LED+ 2 POWER LED-
Pin
Definition
1 HDD LED+ 2 HDD LED-
HDD_LED1: HDD Access LED Status
Pin Definition
1 WATCHDOG LED+ 2 WATCHDOG LED-
WDT_LED1: Watchdog LED Status
Pin
Definition
1 GPIO LED+ 2 GPIO LED-
GPIO_LED1: GPIO LED Status
Pin Definition
1 LINK LED+ 2 LINK LED-100Mbps­3 LINK LED 100Mbps-
LAN1_LINK1, LAN2_LINK1 : LAN Link LED Status
Pin
Definition
1 ACTIVE LED+ 2 ACTIVE LED-
LAN1_ACT1, LAN2_ACT1 : LAN Active LED Status
Page 66
Chapter 3
System Setup
Page 67
RCO-3000 | User’s Manual
67
3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing.
3.2 Removing chassis bottom cover
1. Turn the system upside down. Unscrew the 6 screws (M3x5L) on the bottom cover.
2. Now you can remove the bottom cover.
In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
WARNING
Chapter 3: System Setup
Page 68
RCO-3000 | User’s Manual
68
3.3 Removing PCIe/PCI expansion module
1. This step only applies to RCO-6011 and RCO-6022 series, which is equipped with PCIe/PCI
expansion module.
2. Unscrew four screws (M3x5L) circled below.
3. Now you can remove the PCIe/PCI expansion module.
Chapter 3: System Setup
Page 69
RCO-3000 | User’s Manual
69
3.4 Removing chassis top cover
1. Unscrew the four screws (M3x5L) highlighted below.
2. Hold the body of the system and lift it vertically away from the top cover.
3. Top cover separated from the system body.
Chapter 3: System Setup
Page 70
RCO-3000 | User’s Manual
70
3.5 Installing SODIMM
1. Place the system body with SODIMM socket facing upward. Two SODIMM sockets are
available for RCO-6000 Series on the top side.
2. Insert memory module from 45 degree direction.
3. Press the memory module vertically downward until you hear the “click” sound. Make sure
the memory module is firmly in place.
Chapter 3: System Setup
Page 71
RCO-3000 | User’s Manual
71
3.6 Installing CPU
1. CPU socket is located on the top side.
2. Press down the CPU socket lever in order to open the socket cover.
Chapter 3: System Setup
Page 72
RCO-3000 | User’s Manual
72
3. Remove the CPU protective cover.
4. Insert CPU gently.
Chapter 3: System Setup
Page 73
RCO-3000 | User’s Manual
73
5. Press down the lever again to hold the socket cover.
6. Paste thermal pad (1-BR0500040, 29x29x0.5mm) on the CPU.
Chapter 3: System Setup
Page 74
RCO-3000 | User’s Manual
74
7. Place the designated heat block onto the CPU with thermal pad.
8. Lock the heat block with three screws (M3x5L). Screw driver will able to penetrate through
the holes on the top in order to fasten the screws with copper stud.
Chapter 3: System Setup
Page 75
RCO-3000 | User’s Manual
75
9. Paste the thermal pad (1-BR0500041, 76x70x2.0mm) onto the installed heat block.
10. Installation complete.
Chapter 3: System Setup
Page 76
RCO-3000 | User’s Manual
3.7 Installing mini PCIe card / mSATA
1. Four mini PCIe slots are available for RCO-6000 series, three on top side and one on bottom
side. CN3 and CN4 on the top side support mSATA.
2. Insert mini PCIe card from 45 degree direction.
3. Press the mini PCIe card down and lock it with two screws (M2x3.7L).
76
Chapter 3: System Setup
Top Side
Bottom Side
CN3
CN4
Page 77
RCO-3000 | User’s Manual
77
3.8 Installing antenna
1. Four antenna holes are available for RCO-6000 series on the rear panel and two holes are on
the front panel.
2. Remove antenna hole cover on the system panel.
3. Have antenna jack penetrate through the hole.
Chapter 3: System Setup
Page 78
RCO-3000 | User’s Manual
78
4. Put on washer and fasten the nut with antenna jack.
5. Assemble the antenna and antenna jack together.
6. Attach the RF connector at the cable-end onto the communication module.
Chapter 3: System Setup
Page 79
RCO-3000 | User’s Manual
79
3.9 Assembly chassis top cover
1. Place the top cover upside down as shown below.
2. Ensure thermal pad is in place on both the CPU thermal block and PCH thermal block.
3. Hold the system body and slide the front/rear panel into the slide rail on the top cover.
Chapter 3: System Setup
Page 80
RCO-3000 | User’s Manual
80
4. Push the system body down until it is firmly in place.
5. Fasten the four screws (M3x5L) to lock the system body with top cover.
Chapter 3: System Setup
Page 81
RCO-3000 | User’s Manual
81
3.10 Installing HDD on internal SATA HDD bay
1. Two internal SATA HDD bays are available for RCO-6000 series.
2. Unscrew the four screws (M3x5L) to remove the internal SATA HDD bay.
3. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L).
Chapter 3: System Setup
Page 82
RCO-3000 | User’s Manual
82
4. Install the HDD bracket following the direction below.
5. Fasten the four screws to lock the internal HDD bracket.
Chapter 3: System Setup
Page 83
RCO-3000 | User’s Manual
83
3.11 Installing HDD on removable SATA HDD bay
1. Two removable SATA HDD bays are available for RCO-6000 Series.
2. Unscrew the two sun screws circled below to take out the removable SATA HDD bay.
3. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L).
4. Slide the HDD bracket back and then fasten the sun screws.
Chapter 3: System Setup
Page 84
RCO-3000 | User’s Manual
84
3.12 Installing PCIe/PCI expansion card
1. PCIe or PCI card with FHHL dimension is supported by RCO-6000 series.
2. Unscrew the screw (M3x5L) to remove the plane bracket.
3. Loose the sun screw (circled below) on the holder so the pairing arm can be adjustable.
4. Install the PCIe/PCI card according to the below direction and ensure the gold finger is inserted into the slot. Then fasten the screw in the circle.
Chapter 3: System Setup
Page 85
RCO-3000 | User’s Manual
85
5. Adjust the arm until it holds the card firmly in place. Then fasten the sun screw on the holder.
6. For RCO-6022 series, which has two expansion slots, follow the same procedure to install the
second card.
7. For easier installation, install the upper card (Card 1) first and then install the lower card (Card 2).
Card 1
Card 2
Chapter 3: System Setup
Page 86
RCO-3000 | User’s Manual
86
3.13 Assemble PCIe/PCI expansion module
1. Install the expansion module back in place and ensure the golden finger is inserted into the expansion slot.
2. Fasten the four screws (M3x5L) below to lock the expansion module.
Chapter 3: System Setup
Page 87
RCO-3000 | User’s Manual
87
3.14 Assemble chassis bottom cover
1. Place the bottom cover according to the below direction and make sure the rail is facing inside the system.
2. Lock the bottom cover with the six screws (M3x5L).
Chapter 3: System Setup
Page 88
RCO-3000 | User’s Manual
88
3.15 Installing SIM card
1. For RCO-6000 Series, SIM card slot is located inside the control area. Unscrew the two screws below to remove the cover bracket.
2. Now you can insert SIM card into the socket.
Chapter 3: System Setup
Page 89
RCO-3000 | User’s Manual
89
3. Please note that the installation of SIM cards has to match the installation of mini PCIe slots.
4. To uninstall SIM card, simply press the installed SIM card and then the card will be pushed out.
SIM Card Socket Number
Matching Mini
PCIe Slot
SIM 1
MINIPCIE1
SIM 2
MINIPCIE2
SIM 3
CN3
SIM 4
CN4
Chapter 3: System Setup
Top Side
Bottom Side
CN3
CN4
MINIPCIE1
MINIPCIE2
Page 90
RCO-3000 | User’s Manual
90
3.16 Installing wall mount kit
1. Wall mount kit is available for RCO-6000 series included in the standard package.
2. Place the system upside down so you can see the bottom cover. The highlighted eight screw holes below will be used.
3. Lock the wall mount kit with eight screws (M3x5L, Nylok).
Chapter 3: System Setup
Page 91
Chapter 4
BIOS Setup
Page 92
RCO-3000 | User’s Manual
92
Chapter 4: BIOS Setup
4.1 BIOS Introduction
The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset.
BIOS Setup
Power on the embedded system and by pressing <Del> or <F2> immediately allows you to enter
the setup screens. If the message disappears before you respond and you still wish to enter the
Setup, restart the system by turning it OFF and ON or pressing the RESET button. You may also restart the system by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.
Main Setup
The main menu lists the setup functions you can make changes to. You can use the arrow keys ( ↑↓ ) to select the item. The on-line description of the highlighted setup function is displayed at the bottom of the screen.
General Help <F1>
The BIOS setup program provides a General Help screen. You can call up this screen from any menu by simply pressing <F1>. The Help screen lists the appropriate keys to use and the possible selections for the highlighted item. Press <Esc> to exit the Help screen.
Control Keys
<←> <→>
Select Screen
<↑> <↓>
Select Item
<Enter>
Select
<Page Up/+>
Increases the numeric value or makes changes
<Page Down/
->
Decreases the numeric value or makes changes
<F1>
General Help
<F2>
Previous Value
<F3>
Load Optimized Defaults
<F4>
Save Configuration and Exit
<Tab>
Select Setup Fields
<Esc>
Exit BIOS Setup
Page 93
RCO-3000 | User’s Manual
93
Chapter 4: BIOS Setup
4.2 Main Setup
Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu.
4.2.1 System Language
Language setup allows the user to configure the language. Please use <Tab> to switch between language elements.
4.2.2 System Date
Set the date. Please use <Tab> to switch between date elements.
4.2.3 System Time
Set the time. Please use <Tab> to switch between time elements.
Page 94
RCO-3000 | User’s Manual
4.3 Advanced Setup
This section allows you to configure and improve your system and allows you to set up some system features according to your preference.
4.3.1 ACPI Settings
■ Enable ACPI Auto Configuration
Enable or disable BIOS ACPI auto configuration.
94
Chapter 4: BIOS Setup
Page 95
RCO-3000 | User’s Manual
95
4.3.2 AMT Configuration
Intel Active Management Technology (AMT) is hardware-based technology for remotely managing and securing PCs out-of-band.
■ Intel AMT
This item allows users to enable or disable Intel AMT BIOS extension.
■ Un-Configure ME
Use this function to enable or disable Un-Configure ME without password function.
Chapter 4: BIOS Setup
Page 96
RCO-3000 | User’s Manual
96
4.3.3 NCT6106D Super IO Configuration
■ Serial Port 1 Configuration
Serial Port
This item will allow users to enable or disable serial port.
Change Settings
This setting is used to change the address & IRQ settings of the specified serial port.
Device Type Select
Change the Serial interface. Select <RS232> ,<RS422> or <RS485> interface.
Chapter 4: BIOS Setup
Page 97
RCO-3000 | User’s Manual
■ Serial Port 2 Configuration
Serial Port
This item will allow users to enable or disable serial port.
Change Settings
This setting is used to change the address & IRQ settings of the specified serial port.
Device Type Select
Change the Serial interface. Select <RS232> ,<RS422> or <RS485> interface
■ Serial Port 3 Configuration
Serial Port
This item will allow users to enable or disable serial port.
Change Settings
This setting is used to change the address & IRQ settings of the specified serial port.
Device Type Select
Change the Serial interface. Select <RS232> ,<RS422> or <RS485> interface.
97
Chapter 4: BIOS Setup
Page 98
RCO-3000 | User’s Manual
■ Serial Port 4 Configuration
Serial Port
This item will allow users to enable or disable serial port.
Change Settings
This setting is used to change the address & IRQ settings of the specified serial port.
Device Type Select
Change the Serial interface. Select <RS232> ,<RS422> or <RS485> interface.
■ Watch dog Timer
Watch Dog Timer Count Mode
Change the Watch dog mode. Select <Second Mode> or <Minute Mode> mode.
Watch Dog Timer Time Out Value
User can set a value in the range of 0 to 255.
4.3.4 NCT6106D HW Monitor
These items display the current status of all monitored hardware devices/components such as
voltages, temperatures and all fans’ speeds.
98
Chapter 4: BIOS Setup
Page 99
RCO-3000 | User’s Manual
99
4.3.5 Serial Port Console Redirection
■ Console Redirection
This item allows users to enable or disable console redirection.
4.3.6 CPU Configuration
■ Hyper-Threading
This item allows you to enable or disable the Intel Hyper-Threading Technology.
■ Active Processor Cores
Set number of cores to be enabled. Select <All> or <1> mode.
■ Intel Virtualization Technology
When enabled, a VMM can utilize the integrated hardware virtualization support.
■ Intel(R) Speedstep(tm)
Allows more than two frequency ranges to be supported.
■ CPU C states
This item allows you to set the power saving of the CPU states.
Chapter 4: BIOS Setup
Page 100
RCO-3000 | User’s Manual
■ CPU C states
This item allows you to set the power saving of the CPU states.
Enhanced C State
This item allows your CPU reduce power consumption
■ Package C State limit
Select Auto for the AMI BIOS to automatically set the limit on the C-State package register. The options are C0/ C1, C2, C3, C6, C7, C7s, C8 and No Limit.
4.3.7 SATA Configuration
■ SATA Controller(s)
Enable or disable Serial ATA controller.
■ SATA Mode Selection
This item allows users to select mode of SATA controller.
■ Serial ATA Port 0 / 1 / 2 / 3 / 4 / 5
This item allows users to enable or disable Serial ATA Port 0 / 1 / 2 / 3 / 4 / 5.
4.3.8 Network Stack Configuration
■ Network Stack
Use this item to enable or disable UEFI Network Stack.
100
Chapter 4: BIOS Setup
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
