Premier Mounts P4263F Users Guide

Installation Guide

P4263F

Low-Prole Mount for Flat-Panels

Weight Limit

Maximum Flat Panel Weight:

Warning Statements

PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS MUST BE READ AND COMPLETELY

UNDERSTOOD. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE REFERENCE.

PROPER INSTALLATION PROCEDURE BY A QUALIFIED SERVICE TECHNICIAN MUST BE FOLLOWED, AS OUTLINED IN THESE

INSTALLATION INSTRUCTIONS. FAILURE TO DO SO COULD RESULT IN PROPERTY DAMAGE, SERIOUS PERSONAL INJURY, OR
EVEN DEATH.

SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE ASSEMBLY OF THIS PRODUCT. USE PROPER SAFETY

EQUIPMENT AND TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY.

PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT FOR

PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED ATTACHMENTS OR
MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION
OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR
MODIFICATIONS.

At least two qualied people should perform the assembly procedure. Personal injury and/or property damage can result from dropping or

mishandling the at panel.

If mounting to wall studs or ceiling studs, make sure that the mounting screws are anchored into the center of the wall studs or ceiling studs.

Use of an edge-to-edge stud nder is recommended.

It is recommended that a maximum of ⅝˝ plaster board be used when mounting to wooden studs.

Be aware of the mounting environment. If drilling and/or cutting into the mounting surface, always make sure that there

are no electrical wires in wall. Cutting or drilling into an electrical line may cause serious personal injury.

Make sure there are no water or natural gas lines inside the wall where the mount is to be located. Cutting or drilling into a water or gas line

may cause severe property damage or personal injury.

This product is intended for indoor use only. Use of this product outdoors could lead to product failure and/or serious personal injury.

Do not install near sources of high heat. Do not install on a structure that is prone to vibration, movement or chance of impact.

175 lb.

THE WALL STRUCTURE MUST BE CAPABLE OF SUPPORTING AT
LEAST FOUR TIMES THE WEIGHT OF THE FLAT PANEL. IF NOT, THE
WALL STRUCTURE MUST BE REINFORCED.

AVERTISSEMENT

AVANT L’INSTALLATION DE CE PRODUIT, LES CONSIGNES D’INSTALLATION DOIVENT ÊTRE LUES ET PLEINEMENT COMPRISES.

CONSERVER CES CONSIGNES D’INSTALLATION DANS UN ENDROIT FACILEMENT ACCESSIBLE POUR RÉFÉRENCE FUTURE.

LA PROCÉDURE D’INSTALLATION CORRECTE PAR UN TECHNICIEN QUALIFIÉ DOIT ÊTRE OBSERVÉE, COMME DÉCRIT DANS

CES CONSIGNES D’INSTALLATION. FAUTE DE QUOI DES DOMMAGES MATÉRIELS, BLESSURES GRAVES, VOIRE MÊME LA MORT
PEUT SUBVENIR.

DES MESURES DE SÉCURITÉ DOIVENT ÊTRE PRATIQUÉES À TOUT MOMENT DURANT L’ASSEMBLAGE DE CE PRODUIT.

UTILISER L’ÉQUIPEMENT ET OUTILS DE SÉCURITÉ APPROPRIÉ POUR LA PROCÉDURE D’ASSEMBLAGE AFIN D’ÉVITER DES
BLESSURES.

LES SUPPORTS PREMIER MOUNTS NE GARANTISSENT PAS CONTRE LES DOMMAGES CAUSÉS PAR L’USAGE DU PRODUIT

DE MONTAGE PREMIER MOUNTS À D’AUTRES FINS QUE CELLES POUR LESQUELLES IL A ÉTÉ CONÇU OU DES DOMMAGES
CAUSÉS PAR DES ACCESSOIRES OU DES MODIFICATIONS NON AUTORISÉS, ET NOUS NE POUVONS PAS ÊTRE TENUS
RESPONSABLES DES DOMMAGES, PLAINTES, RÉCLAMATIONS, POURSUITES, ACTIONS OU CAUSES D’ACTION DE N’IMPORTE
QUELLE MANIÈRE RÉSULTANT DE, DÉCOULANT DE OU TOUCHANT DE N’IMPORTE QUELLE MANIÈRE UN TEL USAGE,
ACCESSOIRE OU MODIFICATION

Au moins deux personnes qualiées devraient exécuter la procédure d’assemblage. Il pourrait subvenir des blessures et/ou des dommages

matériels dû à la chute ou à la manipulation incorrecte de l’écran plat.

Si le montage s’effectue sur des rivets, assurez-vous que les vis de montage sont ancrées au centre des rivets. L’usage d’un détecteur de

rivet bord-à-bord est recommandé.

Il est recommandé qu’un maximum de plaque-plâtre de 5/8" soit utilisé lors d’un montage sur des rivets à bois.

Familiarisez-vous avec l’environnement de montage. Si un perçage et/ou une coupe est opéré sur la surface de montage, assurez-vous

toujours qu’il n’y a pas de ls électriques dans le mur. Couper/percer dans une installation électrique peut causer des blessures graves.

S’assurer qu’il n’y a pas de canalisation d’eau ou de gaz naturel dans le mur où le montage doit être localisé. Une coupe ou un perçage

dans une canalisation d’eau ou de gaz naturel peut causer des dommages matériels ou des blessures graves.

Ce produit n’est destiné qu’à être utilisé à l’intérieur. L’utilisation de ce produit à l’extérieur pourrait entraîner des défauts matériels et/ou des

blessures graves.

Ne pas installer près de sources de forte chaleur. Ne pas installer sur une structure soumise aux vibrations, aux mouvements ou aux chocs.

Page 2

Installation Guide

P4263F

Included Components

5/16” Flat Washers

(Qty 4)

5/16” x 3” Lag Bolts

(Qty 4)

M4 x 12mm (Qty 4)

M4 x 16mm (Qty 4)

M4 x 25mm (Qty 4)

Wall Mount

(Qty 1)

Universal Spacers

(Qty 8)

Finned Anchor

(Qty 4)

Bracket

(Qty 2)

Lock-it Barrel

(Qty 1)

M6 x 12mm (Qty 4)

M6 x 16mm (Qty 4)

Thread Depth Indicator

(Qty 1)

M8 x 12mm (Qty 4)

M8 x 16mm (Qty 4)

M6 x 120 mm

(Qty 4)

Universal Washers

(Qty 4)

M6 x 25mm (Qty 4)

Required for installation

Electronic Stud Finder M6 or 1/4” Drill Bit

Pencil Protective Eyewear

13mm or 1/2” SocketLevel

Socket Wrench

M8 x 25mm (Qty 4)

3/8” Masonry Drill Bit

Portable DrillPhillips Head Screwdriver

Page 3

Installation Guide

P4263F

Introduction

Directional Mounting Arrow

The Directional Mounting Arrow stamped into the top of the P4263F wall
mount indicates which edge is the top.

Wood Stud Installation

1

Minimum of 2 by 4 wood stud to be used

Minimum de 2 par 4 bois goujon pour être utilisé

You must secure the wall plate to two (2) wall studs with a minimum of four (4) lag bolts

(2 lag bolts for each stud found).

Vous devez assembler la sablière sur deux (2) rivets de mur avec un minimum
de quatre (4) tirefonds (2 tirefonds pour chaque rivet trouvé).

1) Use a stud nder to determine the center of wall studs in the vicinity of the wall plate.

2) Use a pencil to mark the center of each of the wall studs.

2

1) Place the wall plate against the wall in the desired viewing location.

2) Use a pencil to mark the upper right mounting location along the center of
the wall stud.

X

X

3

Page 4

Drill a “pilot hole” in the center of the upper right mark using a 1/4” drill bit and
power drill.

Only use a 1/4″ drill bit when drilling the pilot holes.

N’utiliser qu’un foret de 1/4˝ lors du forage de guidage.

Installation Guide

P4263F

4

5

1) Place the wall plate against the wall and align it with the pilot hole.

2) Insert one (1) 5/16″ x 3″ lag bolt and one (1) 5/16″ washer into the
up per right mounting hole and tighten using a socket wrench and 1/2” socket.

Do not overtighten the lag bolt.

Éviter de trop serrer le tirefond.

1) Level the wall plate.

2) Use a pencil to mark the remaining three (3) mounting locations along the
Center of each wall stud.

6

7

Two people are recommended for this step; one person to level the wall

plate and another person to drill the pilot holes.

Il est recommandé deux personnes pour cette étape : une per­sonne pour niveler la sablière et une autre personne pour percer
le forage de guidage.

Drill a “pilot hole” in the center of each of the marks with a power drill and a 1/4″
drill bit.

Only use 1/4″ drill bit when drilling the pilot holes.

N’utiliser qu’un foret de 1/4” lors du forage de guidage.

1) Insert one (1) 5/16” x 3” lag bolt and one (1) 5/16” washer into each pilot hole.

2) Tighten all lag bolts using a socket wrench and 1/2” socket.

Do not overtighten the lag bolts when attaching the mount to the wall. Improper
Installation may result in personal injury or property damage.

Éviter de trop serrer les tirefonds lors de la xation du support au
mur. Une installation incorrecte peut entraîner des blessures ou
des dommages matériels.

Page 5

Installation Guide

P4263F

Concrete Installation

8

Two people are recommended for this step: one person to level the wall

plate and another person to mark the mounting locations.

Il est recommandé deux personnes pour cette étape : une personne pour
niveler la sablière et une autre personne pour marquer les emplacements
de montage.

9

10

Drill four (4) pilot holes of each mark using a drill and 3/8” masonry drill bit.

Drill 3 inches deep.

Only use a 3/8" masonry drill bit when drilling pilot holes.

N’utiliser qu’un foret de 3/8” lors du forage de guidage.

Insert the Finned Anchors into each pilot hole.

Lightly tap each Finned Anchors into place with a hammer.

11

Page 6

1) Insert one (1) 5/16” x 3” Lag Bolt and one (1) 5/16” washer into each
pilot hole.

2) Tighten all lag bolts using a socket wrench and 1/2” socket.

Do not overtighten the lag bolts when attaching the mount to the
wall. Improper installation may result in personal injury or property
damage.

Éviter de trop serrer les tirefonds lors de la xation du support au
mur. Une installation incorrecte peut entraîner des blessures ou des
dommages matériels.

Installation Guide

P4263F

Selecting the Mounting Hardware

Small Straw or Toothpick

1) Insert a small straw or toothpick into the threaded inserts found on the

2) Use a pencil to mark the depth of the threaded insert on the small straw

3) Mark the straw or toothpick 1/8” above the depth of the threaded insert,

4) Insert the small straw or toothpick into the remaining threaded inserts

5) Locate the correct diameter screw for the threaded insert.

Marking the 1/8”
Allowance

6) Test each size of the screws provided.

back of the at-panel.

or toothpick.

as shown in Figure 1.

to compare and verify their depth using the straw or toothpick’s 1/8”
allowance mark.

If the screw you selected is longer than the 1/8” allowance mark on

the small straw or toothpick, as shown in Figure 2 and Figure 3, do
not use this screw. The screw length must not bypass the mark.

Si la vis que vous sélectionnez est plus longue que la marque du
jeu maximal de 1/8” sur le paillon ou le cure-dents, comme illustré
sur le schéma 2 et le schéma 3, veuillez ne pas utiliser cette vis. La
longueur de la vis doit dévier la marque.

The correct screws should thread easily into themounting point and
not pull out when tension is applied.

Small Straw
or Toothpick

Depth Plus 1/8” Allowance
Mark

Small Straw
or Toothpick

Depth Plus 1/8” Allowance
Mark

Page 7

Installation Guide

P4263F

Universal Washer Installation

Premier Mounts’ Universal Washers are designed to accommodate the various
M4, M5, M6 and M8 hole sizes required by at panels.

Do not place excessive pressure on the back of the at panel, as this

may damage your at panel.

The Universal Washer must be installed between the head of the

mounting screw and the mounting bracket as shown.

Does your at panel have:

● Recessed mount points?

● Uneven mount points?

● A curved back?

● Any obstruction near the mount point?

If Yes, you must install Universal Spacers. Remove the mounting brackets,
Universal Washers, and mounting screws from the back of the at panel.
Proceed to the “Universal Spacer Installation” section.

If No, skip to the “Leveling and Locking Screw Installation” section.

Universal Spacer Installation

Premier Mounts’ Universal Spacers allow you to attach the mounting bracket
to at panels which have recessed or uneven mount points. Each Universal
Spacer adds ¼˝ to the distance between the mounting bracket and your at
panel.

Éviter de placer une pression excessive à l’arrière de l’écran plat, car

cela risque d’endommager votre écran plat.

La rondelle tous usages doit être installée entre le chapeau de la vis de

xation et le support de montage comme illustré.

Votre écran plat est-il muni de :

● Points de montage encastrés ?

● Points de montage inégaux ?

● Un plan arrière arrondi ?

● Une obstruction à l’emplacement du point d’assemblage ?

Si Oui, il vous faut installer des entretoises tous usages. Aller à la section
« Installation d’entretoise tous usages ».

Si non, aller à la section « Verrouillage et mise à niveau de l’installation de
la vis ».

M8
M5, M6
M4

The Universal Spacers must be stacked and oriented as shown.

Les entretoises tous usages doivent être empilées et orientées
comme illustré.

The Universal Spacers must only be installed between the mounting

bracket and your at panel.

Les entretoises tous usages ne doivent être installées qu’entre le
support de montage et votre écran plat.

The Universal Spacers will t M4, M5, M6 and M8 screw sizes.

Proceed to the “Locking and Leveling Screw Installation” section.

1˝ ¼˝

Mounting Screw

Universal Washer

Mounting Bracket

Flat Panel

Universal Spacer

Mount Point

Page 8

Installation Guide

P4263F

Locking and Leveling Screw Installation

Leveling Screw Installation

You must install the leveling screws before you attach the mounting bracket to

the back of the at panel. The leveling screws consists of two (2)
M6 x 120mm screws.

Vous devez installer les vis de réglage aven de xer le support de
montage à l’arrière de l’écran plat. Les vis de réglage se composent de
deux (2) vis de M6 x 120 mm.

Thread one (1) leveling screw into the top mounting hole on each of the mounting
brackets. Make sure the leveling screw is securely threaded into the mounting tab
before proceeding.

Do not thread the leveling screw any further once it is even with the mounting

tab. Threading the leveling screw any further will prevent you from safely
attaching the at panel to the wall plate.

Éviter d’enler davantage la vis de réglage une fois qu’elle parvient au niveau
de la patte de xation. Le letage excessif de la vis de réglage au-delà de ce
point gênera le xage correct de l’écran plat sur la sablière.

Locking Screw Installation

Leveling Screw

Correctly Threaded

Leveling Screw

Threaded Too Far

You must install the locking screws before you attach the mounting bracket to

the back of the at panel. The locking screws consists of two (2)
M6 x 120mm screws.

Vous devez installer les vis de réglage aven de xer le support de mon­tage à l’arrière de l’écran plat. Les vis de réglage se composent de deux
(2) vis de M6 x 120 mm.

Thread one (1) locking screw into the bottom mounting hole on each of the mounting
brackets. Make sure the locking screw is securely threaded into the mounting tab
before proceeding.

Do not thread the locking screw any further once it is even with the mounting

tab. Threading the locking screw any further will prevent you from safely
attaching the at panel to the wall plate.

Éviter d’enler davantage la vis de réglage une fois qu’elle parvient au niveau
de la patte de xation. Le letage excessif de la vis de réglage au-delà de ce
point gênera le xage correct de l’écran plat sur la sablière.

Proceed to the “Attaching the Mounting Bracket to the Flat Panel” section.

Locking Screw

Correctly Threaded

Locking Screw

Threaded Too Far

Page 9

P4263F

Installation Guide

Lock-it™ Security Barrel Installation (Optional)

Optional security congurations include:

- PCB-CSL1 (sold separately)

- Padlock (Combination or Keyed; commercially
available)

Please read the following directions to install the security barrel:

1) Remove the locking screw from the mounting bracket.

2) Place the locking screw into and through the security barrel (see illustration below).

3) Re-insert the locking screw and security barrel into the mounting bracket.

4) Tighten the locking screw and security barrel until seated in the mounting tab.

Do not thread the locking screw any further once it is even with the

mounting tab (see illustration to the right). Threading the locking screw
any further will prevent you from safely attaching the at panel to the
wall plate.

Éviter d’enler davantage la vis de réglage une fois qu’elle parvient au niveau
de la patte de xation (voir illustration à droite). Le letage excessif de la vis
de réglage au-delà de ce point gênera le xage correct de l’écran plat sur la
sablière.

Do not overtighten the locking screw.

Mounting Tab

Éviter de trop serrer la vis de blocage.

Proceed to the “Attaching the Mounting Bracket to the Flat Panel”
section.

Locking Screw

Lock-It™ Security
Barrel

Attaching the Mounting Bracket to the Flat Panel

This section presumes that you have read and understood these sections:

● Selecting the Proper Mounting Hardware

● Universal Washer Installation

● Universal Spacer Installation

1) Place your at panel screen-side down on a soft, at surface.

2) Identify the number and location of the thread inserts on the back of your
at panel.

3) Aligning the holes on each mounting bracket with the thread inserts on the
back of our at panel.

4) Secure each mounting bracket to your at panel by inserting a minimum of
two (2) screw per bracket.

Do not overtighten the mounting hardware.

Éviter de trop serrer le dispositif de montage.

Proceed to the “Attaching the Flat Panel to the Wall Plate” section.

Page 10

Attaching the Flat Panel to the Wall Plate

This section requires two people.

Cette section exige deux personnes.

Do not release your at panel until you are certain that top and bottom hooks of both mounting

brackets are securely seated on the upper and lower mounting rails of the wall panel.

Éviter de relâcher votre écran plat jusqu’à ce que vous vous assuriez que les crochets

de haut et de bas de tous les deux supports de montage sont bien posés sur les rails
de montage hauts et bas de la sablière.

1) Raise the at panel past the top and bottom mounting rails on the wall panel.

2) Slide the at panel down slowly, keeping it close to the wall.

3) Engage the top and bottom mounting brackets to the rails of the wall plate.

Proceed to the “Mounting Bracket Adjustments” section.

P4263F

Installation Guide

Mounting Bracket Adjustment

Leveling Screw Adjustment

If your at panel is tilted too far to one side, the leveling screws will allow you
compensate for this tilt by simply adjusting the screws with a screwdriver.

1) Loosen both locking screws.

2) Adjust the tilt of your at panel.

3) Tighten both locking screws.

Caution!

It is possible to dislodge your at panel while you level your at panel.
Use extreme caution until you tighten the locking screws.

Attention !

C’est possible de retirer votre écran plat pendant son réglage. User d’une
extrême prudence jusqu’au moment du serrage des vis de blocage.

Locking Screw Adjustment

After you have nished leveling your at panel, be sure to tighten the two (2) M6 x 120mm
locking screws.

Do not overtighten the locking screws.

Éviter de trop serrer les vis de blocage.

M6 x 120mm

Leveling Screw

(1 per Bracket)

M6 x 120mm
Locking Screw
(1 per Bracket)

Page 11

P4263F

Installation Guide

Utilizing the Security Barrel

Your P4263F Mount includes one (1) Security Barrel which can provide
additional theft deterrence for your at panel.

PCB-CSL1 Security Cable

1) Thread the cable through the hole on the security barrel.

2) Attach the PCB-CSL1 locking mechanism and secure it using the

supplied key.

Padlock

1) Place the locking hook through the hole of the security barrel.

2) Snap lock and locking hook together.

PCB-CSL1

Padlock

(Combination or Keyed)

Page 12
