Introduction
The Pregis Coiler produces large quantities of paper coil cushions when used in
conjunction with the Pregis Packmaster™ pro . Paper coil cushions provide light, strong
packaging options which mould to the shape of the items to be protected and are manufactured using 100% recycled materials.
Paper coils can be made using 52/90gsm and 70gsm white or brown paper. The coils can
be produced at sizes ranging from 30cm to 70cm diameter. All of our paper is 100%
recycled, 100% recyclable and 100% biodegradable.
These coils can be produced quickly either for immediate use or to store for later use. The Coiler is simple to use providing a hands-free repeat option which allows production to continue. Advanced safety features ensure safe operation at all times.
A brand of
16-OM205-1
3
General Safety
Operator safety and the safety of others in the work area are reliant upon the operator using good judgment and reasonable care while operating the machine. This operating manual and any warning labels affixed to the machine provide notification of specific hazards.
The following instructions are only a guideline and should be considered a supplement to
your plant’s comprehensive safety program. Your business’ policy supersedes these
guidelines if at any time the two contradict each other. Please read and understand the manual including all of the dangers, warnings, and cautionary statements.
If after reading the manual you have any questions, contact your supervisor or your Pregis service technician to get answers before operating the machine.
A brand of
16-OM205-1
4
Safety Instructions
1. Only authorised personnel may use the equipment.
2. Only trained authorised personnel may carry out any adjustments or repairs.
3. Never damage or remove factory installed safety stickers. If a safety sticker is lost,
damaged, or becomes illegible, report this condition to a supervisor and obtain a
replacement sticker from Pregis.
4. Check that the Coiler is disconnected from the power supply before cleaning the machine.
5. When moving the Coiler ensure that the power lead and the flying lead connecting the Coiler to the Packmaster™ pro are disconnected.
6. Keep the work area clean and uncluttered. Walkways and access/egress routes should always be free of packing material and debris to prevent a slipping or tripping hazard.
7. Ensure that all covers, guards and other safety devices are in place. NEVER disable a safety device for any reason.
8. Follow the recommended procedures in this manual.
9. Never leave the equipment unattended while operating. Turn the machine off if you must leave the work area.
10. Keep body parts and clothing away from moving components.
11. DO NOT operate equipment if you are under the influence of alcohol, drugs or
medications that can make you less alert or affect your judgment.
A brand of
16-OM205-1
5
Setting up the Coiler after transit
When the Coiler is unloaded after transit some items will need to be attached or re-sited before connecting to the Packmaster™ pro.
Remove the bolts attaching the Control Console and Remote Start Switch (Hands-free switch) in their transit positions.
The retaining bolts for the Remote Start Switch are located inside the switch box.
Install the Control Console and the Remote Start Switch on the front of the Coiler frame using the bolts previously removed. Position both in the optimum positions for the Coiler operative.
Control Console in transit position
Remote Start Switch in transit position
Control Console
in operational position
A brand of
Optional positions for Control Console and remote Start Switch
Remote Start in operational position
www.pregiseu.com 16-OM205-1
6
Attaching the Coiler to the Packmaster™ Pro
Bolt the lower guide plate to the bottom right hand side of the frame (when looking at the front of the Coiler) with the flange pointing downwards,
Place the upper guide plate in position and locate with the 3 threaded black knobs, loosely assembled to allow the plate to be lifted over the Packmaster™ pro frame.
Lower Guide Plate
A brand of
Upper Guide Plate
www.pregiseu.com 16-OM205-1
7
Attaching the Coiler to the Packmaster™ Pro
Remove two screws located below the outlet aperture of the Packmaster™ pro.
Outlet
aperture
Remove screws
Using the two screws previously removed, attach the Shelf Plate to the Packmaster™ pro
below the outlet aperture as shown below.
Shelf Plate
A brand of
Install screws
www.pregiseu.com 16-OM205-1
8
Attaching the Coiler to the Packmaster™ Pro
Push the Packmaster™ pro gently towards the Coiler. Try to keep the Upper Guide Plate positioned in the middle of the Packmaster™ pro frame.
When the frames are close lift the Upper Guide Plate until the Guide Plate drops over the Packmaster™ pro frame.
Use the lugs on
either side of
the Upper Guide Plate to locate the plate inside the
Packmaster™
pro frame
A brand of
Use your foot to lift the Upper Guide Plate over the Packmaster™ pro frame.
www.pregiseu.com 16-OM205-1
9
Attaching the Coiler to the Packmaster™ Pro
When the plate is resting over the Packmaster™ pro frame hand tighten the three black knobs to secure the Coiler to the Packmaster™ pro.
Plug in the lead which connects the coiler to the accessory socket on the side of the Packmaster™ pro. Make certain the lead is routed clear of the safety curtain.
A brand of
www.pregiseu.com 16-OM205-1
10
Location of the controls
The main controls for the Coiler are located on the control box which is height adjustable to allow it to be tailored to the operator. A supplementary Remote Start Switch (Hands free) control is located below the controller and is also height adjustable.
The Coiler mains power On/Off button is located on the back of the machine.
Control Console
Power switch on reverse side of Coiler
Remote Start Button
Mains Power Switch Switch illuminates when switched on.
Control box Refer to the next page for an explanation of the Control Console functions
Remote Start Switch
A brand of
Press the Remote Start Button (Hands-free button) to activate the Coiler.
16-OM205-1
11
Control Console functions
Power
Indicator
‘Start’
Button
‘Stop’
Button
‘Home’
Button
Coil
Indicator
Coil Size
Control
Power Indicator Illuminates when the Coiler is switched on
Start Button Press the green ‘Start’ button to start the Coiler.
Stop Button Press the red ‘Stop button to prematurely stop the Coiler mid-cycle.
Home Button Resets the Coiler, if an error has occurred.
Coil Indicator Illuminates whilst making a coil and flashes when the coil is completed and requires
removal.
Coil Size Control Selects the required coil size. The coil size will vary with different grades of paper.
Tail Position Switch This selects the position of the ‘tail’ of the coil.
Switch to left (normal position) - coil is completed with the tail in the bottom position which keeps the tail in position until the coil is removed. Switch to the right - coil is completed with the tail in the top position allowing access for manual taping of the coil end.
Tail Position
Switch
A brand of
www.pregiseu.com 16-OM205-1
12
Safety Curtain operation
The Coiler operator is protected by a Safety Curtain. If the light beam is broken all
power to the motor is cut immediately stopping the Coiler. The Packmaster™ pro will stop producing and cut the pack. This will place the Coiler into ‘fault’ mode requiring the ‘Home’ button to be pressed before the Coiler will run another pack.
To retrieve a completed coil the operative breaks the Safety Curtain beam. Because the coil has formed completely the Coiler will automatically reset once the coil has been retrieved allowing the next coil to be processed.
When functioning correctly the Safety Curtain on the left hand side of the Coiler should display three green lights and one blue light
When the beam is broken, or the curtain misaligned, (see the Safety Curtain Adjustment section ) then a red indicator is displayed and the Coiler cannot operate.
A brand of
www.pregiseu.com 16-OM205-1
13
Connecting the power supply
Connect the power leads of the Coiler and the Packmaster™ pro to the power source
Switch on both the Coiler and the Packmaster™ pro mains supply. The mains power supply switch is illuminated. Wait 10 seconds then load paper into the Packmaster™ pro in accordance with the Packmaster™ pro manual. A short ‘loading’ pack will be generated
automatically; remove this from the Coiler.
A brand of
16-OM205-1
14
Pre-Start checks
Check that the Safety Curtain on the left hand side of the Coiler displays three green lights and one blue light
Check that the Coiler Paper Support Plate is free to move and will return to the horizontal position when released.
A brand of
www.pregiseu.com 16-OM205-1
15
Operation
Select the required coil size using the Coil Size Selection Knob.
The coil size will vary with different grades of paper.
Select the tail position using Tail Position Switch.
Switch to left (normal position) - coil is completed with the tail in the bottom position which keeps the tail in position until the coil is removed.
Switch to the right - coil is completed with the tail in the top position allowing access for manual taping of the coil end.
Tail in bottom position
A brand of
Tail in top position
16-OM205-1
16
Operation
The red Power Indicator will be illuminated.
Press the Start Button . The Packmaster™ pro feeds the pack on to the Coiler load ramp
and the Coiler automatically produces a coil of the required length.
During the production of the coil the blue Coil Indicator will be illuminated.
Coil production can be stopped at any point during the winding process by pressing the
Stop button. This will immediately stop the pack being produced by the Packmaster™ pro
and will result in a smaller incomplete coil.
This may place the Coiler into a temporary ‘fault’ mode and the Coil Indicator will start to flash denoting operator action is required to remove the coil. To exit the ‘fault’ mode remove
the coil and press the Home Button once. The Coil Indicator extinguishes and the machine is ready to run again).
A brand of
16-OM205-1
17
Operation
When the coil is complete and wound to the selected tail position, the Coil Indicator will start to flash denoting operator action is required to remove the coil.
Once the coil is removed, the Coil Indicator will extinguish, and the Coiler is ready for the next coil to be produced.
The Remote Start switch can be used instead of the Control Console Start Button and is intended to enable hands-free repeat operation whilst holding the previous coil.
A brand of
To prevent the end of the coil from unwinding wrap the tail around the layer
beneath to provide a ‘handle’, see below. This does not detract from the protective
performance of the coil.
16-OM205-1
18
Safety Curtain Adjustment
If the Safety Curtain displays a red light when the beam is not broken the curtain requires adjustment.
Red Light indicates curtain requires adjustment
Loosen the socket screws
To adjust the Safety Curtain:
1. Loosen the M3 socket head screw on top/bottom of the upper and lower safety curtain brackets on either or both sides of the Coiler cage.
2. Adjust the Safety Curtain angle by rotating the loosened Safety Curtain until the left hand Safety curtain displays three green lights and one blue light indicating that the safety curtain is working properly.
3. Re-tighten the M3 screws and check that the three green lights and one blue light are illuminated, with the red light coming on only when the beam is broken.
3 green lights and 1 blue light indicates curtain is
working correctly
A brand of
Tighten the socket screws
www.pregiseu.com 16-OM205-1
19
Maintenance
The Coiler is designed to require little or no maintenance. The following recommended maintenance items will help keep the Coiler operating correctly and minimize any downtime on your packaging line. If there are any questions regarding the maintenance of the Coiler, please contact your local Pregis Service Technician for
assistance.
Electrical shock or unexpected machine movement can cause injury. Unplug the machine before performing maintenance tasks.
Disconnect the power lead before performing ANY maintenance to the machine other than inspections.
Monthly Maintenance:
1. Clean the Coiler using a lint free cloth.
2. Ensure the two sensors (just to the left of the winding head) and the glass surfaces of the safety curtain are free of dust (TAKE CARE - THESE ARE FRAGILE)
3. Verify all components are working properly. If there are any issues, please contact
your Pregis Service Technician.
A brand of
16-OM205-1
20
Troubleshooting
Problem Cause Solution
Machine will not produce a
coil even though the Blue
Indicator Light is not flashing
Safety Curtain displays a red light
Machine needs
to be reset
Safety Curtain requires Adjustment or the beam has been interrupted
Press the Home button
Remove the object interrupting the beam or adjust the Safety Curtain so that the three green
lights and one blue light are displayed
A brand of
16-OM205-1
21
Specifications
Weight (Coiler only): 110kg
Machine dimensions (mm) Without/with
Packmaster™ Pro
(L) 1350 /(L) 2360
(H) 1820 /(H) 1820 (D) 1100 /(D) 1100
Coil diameter From 300mm – 700mm (approx.)
Coil depth 200mm Nominal
Supply: 120/230V AC, 50/60 Hz
Max Power: 350VA (W)
Production Speed:
Automatically matched to Packmaster™ Pro
26m per minute
Compatible with all Packmaster™ pro paper grades. Single ply or twin-ply grades from 70gsm to 52/90gsm. White and brown paper options available
A brand of
16-OM205-1
22
EC Declaration of Conformity
We declare that the following machinery complies with the essential health and safety requirements of the Machinery Directive 2006/42/EC, the Low Voltage Directive (LVD) 2014/35/EC and the Electromagnetic Compatibility Directive 2014/30/EC.
Manufacturer: Pregis Ltd.
Address: Unit 1,The io Centre, Whittle Way,
Arlington Business Park, Stevenage, Hertfordshire, SG1 2BD, England
Description of Product: Coiler
Model No. : 162
The following transposed harmonised European Standards have been used:
EN 12100: 2010 Safety of Machinery - Basic concepts,
general principles for design
EN 13857: 2008 Safety of Machinery - Safety distances to
prevent hazard zones being reached by upper and lower limbs
EN 60204-1: 2006 Safety of Machinery - Electrical equipment
of machines - General requirements
EN 61000: 2007 (part 6-1) Generic standards - Immunity for
light-industrial environments
EN 61000: 2007 (part 6-3) Generic standards -Emission standard for
light-industrial environments
Jason Cox
Operations Director
Signed on behalf of the manufacturer
A brand of
28/01/2019
16-OM205-1
23
Loading...
