7-in-1
BODY FAT MONITORING SCALE
MODEL #7851
value for life™
USERS GUIDE
2 3
BODY FAT MONITORING SCALE
MODEL #7851
Congratulations! You have purchased a precision health monitoring
product that should provide you with years of accurate use. To assure you
obtain the best performance please read the following set-up and use
instructions carefully before using the scale. A few points to remember as
you get started:
• Open the battery compartment on bottom
of scale. Gently pull out the plastic tab
under the battery. Be sure to check that the
battery is seated properly. If display does
not appear when scale is turned on,
check this first.
•Always weigh in bare feet to obtain health readings – body fat,
body water, muscle mass, and bone mass. If only weight is
desired it is not necessary to weigh in bare feet. ERR will appear
after the weight is shown for the other health readings if you
are not in bare feet. Be sure to stand on scale with feet on the
metal plates.
•Always stand reasonably still. If there is too much movement,
the scale cannot provide accurate measurements.
•Place scale on a hard surface. The scale will not weight
accurately on carpet.
•The scale may not provide accurate measurements for children
under age 7, adults over age 99, and body building athletes
or professional athletes.
LDC DISPLAY
The health and fitness materials are to be used for information purposes only. The health and
fitness materials are not intended as a substitute for seeking professional fitness and/or
medical care.
PREGNANT WOMEN, PEOPLE WITH EDEMA, PEOPLE ON DIALYSIS, OR THOSE USING A HEART
PACEMAKER OR OTHER IMPLANTED MEDICAL DEVICE SHOULD NOT USE THIS SCALE.
Gender
Weight Unit
Height Unit
Age
Calorie Unit
Bone%
Muscle%
Fat status indication
Fat %
Hydration%
Activity level
User memory
code
4 5
SETTING UP YOUR SCALE
1. Locate the pound/kilogram (lb/kg) button
under the scale near the top of the scale.
Select lb or kg weight reading as desired.
The scale will now weigh in pounds or
kilograms as indicated. This will show the
display when you push the button.
2. Press and hold SET button once.. The user number will start
flashing. Select user number by pressing the two arrow buttons
to move the number up or down. Press the SET button when
desired user number is shown. (Note: Up to 12 users can
be programmed.)
3. After the SET button is pushed, the gender icon will start flashing.
Press the up or down arrow to move between male and female.
Press the SET button.
4. In similar fashion, the display will prompt you to set your activity
level, heights, age, and target weight. Press the SET button after the
proper information is shown to move to the next flashing display.
USING THE SCALE
1. Press the SET button. The user number and related information
will be shown. Use the two arrow buttons to select the proper
user number.
2. Wait for 0.0 to appear. Step on the scale in bare feet and stand
still. Be sure to stand with your feet covering the metal plates.
The following information will be displayed after about 3 seconds.
• Weight reading will appear first and start flashing, then
stop flashing when reading is confirmed.
• Weight differences from your target weight setting
will appear next.
• Body Fat percentages and overall fitness assessment for
Body Fat will appear next. The fitness assessment is shown
in a series of bars that tells you if your body fat percent is
above or below average relative to your user information
on gender, height, and age.
• Body Water percentage will appear next.
• Muscle Mass percentage will appear next.
• Bone Mass percentage will appear next on the display.
• Recommended daily calorie intake will appear next.
• The information will be displayed three times and then the
scale will turn off automatically.
3. If only weight is desired, tap on scale with your foot, wait for 0.0
to appear and step on scale. It is not necessary to press the SET
button to select your user number.
6 7
GUIDELINES FOR BODY COMPOSITION SCALES
MALE AGE
Low Average High Low Average High Low Average High Low Average High
20-39 < 8% 9-19% > 19% < 54% 55-65% > 65% < 37% 38-44% > 44% < 15% 16-20% > 20%
40-59 < 11% 12- 22% > 22% < 49% 50-60% > 60% < 35% 36-42% > 42% < 15% 16-20% > 20%
60-79 < 13% 14- 25% > 25% < 44% 45-60% > 60% < 33% 34-40% > 40% < 14% 15-19% > 19%
FEMALE AGE
Low Average High Low Average High Low Average High Low Average High
20-39 < 21% 22- 33% > 33% < 49% 50-60% > 60% < 31% 32-38% > 38% < 14% 15-19% > 19%
40-59 < 23% 24- 35% > 35% < 44% 45-55% > 55% < 29% 30-36% > 36% < 14% 15-19% > 19%
60-79
< 24% 25- 36% > 36% < 39% 40-55% > 55% < 28% 29-35% > 35% < 13% 14-18% > 18%
MALE ATHLETE AGE
Low Average High Low Average High Low Average High Low Average High
20-39 < 6% 7-12% > 12% < 57% 58-64% > 64% < 40% 41-48% > 48% < 14% 15-19% > 19%
40-59 < 6% 7-13% > 13% < 51% 52-62% > 62% < 38% 39-46% > 46% < 14% 15-19% > 19%
60-79 < 8% 9-13% > 13% < 49% 50-63% > 63% < 37% 38-45% > 45% < 13% 14-18% > 18%
FEMALE ATHLETE AGE
Low Average High Low Average High Low Average High Low Average High
20-39 < 14% 15- 18% > 18% < 51% 52-60% > 60% < 33% 34-41% > 41% < 15%
16-20% > 20%
40-59 < 16% 17- 20% > 20% < 49% 50-64% > 64% < 31% 32-39% > 39% < 15% 16-20% > 20%
60-79 < 17% 18- 20% > 20% < 49% 50-64% > 64% < 30% 31-38% > 38% < 14% 15-19% > 19%
BODY FAT %
BODY FAT %
BODY FAT %
BODY FAT %
BODY WATER %
BODY WATER %
BODY WATER %
BODY WATER %
BODY MUSCLE %
BODY MUSCLE %
BODY MUSCLE %
BODY MUSCLE %
BONE MASS %
BONE MASS %
BONE MASS %
BONE MASS %
The health and fitness materials provided are to be used for informational
purposes only. The health and fitness materials are not intended as a substitute
for seeking professional fitness and/or medical care. Above reference chart is
available in a full page version on our website www.precisiononescales.com.
INFORMATION ABOUT BODY FAT MEASUREMENT
Body fat scales measure body composition with the Bioelectrical Impedance
Analysis (BIA) technique. The scale offers an estimated body fat percentage
based on how long it takes a small, harmless electrical current to pass through
the body. The more fat the electrical current encounters, the higher the body fat
percentage is, since fat offers higher resistance to electrical currents than muscle.
This is because electrical currents pass easily through the high volume of fluids
that muscle tissue contains. The scale receives the results, which are equal to the
user’s total body density. The scale then plugs the body density figure into an
equation to determine his body fat percentage based on height and weight.
INFORMATION ABOUT BODY FAT
Body fat is an essential part of the body. The fat in your body allows you to absorb the fat-soluble vitamins A, D, E and K. Fat also allows you to absorb substances called carotenoids, which act as antioxidants in your body. Body fat also
aids with body temperature maintenance and insulation. There is a thin layer of
fat directly underneath your skin. This fat layer acts like insulation and helps keep
heat inside the body to maintain body temperature. In addition, a layer of fat also
surrounds your bones, tissues, nerves and major organs, such as your heart and
brain. This layer of fat acts as a protective cushion. If you are exposed to severe
trauma or a sudden impact, the fat absorbs as much shock as possible to protect
these organs from damage.
While some fat is important in keeping your body functioning efficiently, too
much fat can lead to severe medical problems, including heart disease, heart
attack and stroke. The goal of weight loss is to maintain a balanced relationship
between muscle mass and body fat. Please consult your physician for specific
information regarding your health and weight loss plan.
INFORMATION ABOUT BODY WATER
Water is clearly the most important nutrient and the most abundant substance
in the human body. Water comprises more than half of the human mass and is a
major component in every cell. All the cells in the body, including skin, organs,
and muscles can only function if they receive the proper amount of water. Dehydration will degrade a person’s ability to exercise and burn calories, and will reduce protein synthesis which is needed to build or repair muscles. As a guideline,
it is recommended that adults consume 64 ounces of water each day. Our table
on Page 9 should only be used as a reference towards your fitness regime, diet
and fluid intake. As always, please consult your physician.
MORE IMPORTANT INFORMATION
8 9
INFORMATION ABOUT BODY MUSCLE
The muscular system is the body’s network of tissues that controls movement
both of the body structures and organs. Without the muscular system, all other
essential functions of the body would not be able to take place. Muscles are
essential to other body abilities as well, including circulation, digestion, and
energy. Building strong muscles is a very important part of your overall health.
When you strength your muscles, you will be able to see and feel the results. In
addition, your body fat percentage will also decrease. This scale is designed to
give you an accurate percentage of your body’s muscle profile.
INFORMATION ABOUT BONE MASS
The human skeleton consists of 206 bones. The bones which form the skeleton
consist of proteins and mineral substances. Whenever the bones meet in the
human body there is a joint formed which performs a special function in the
body. Without bones, the human body would not have a shape. Regular exercise
is necessary to keep fit and to maintain the abilities of the bones efficiently.
Exercise makes the muscles stronger and gives power to the body, all while
keeping problems of the bones away. The bone mass feature of this scale
measures the weight of the bones, or the amount of mineralized tissue in the
bones in your body. Please consult your physician for specific information
regarding your health.
INFORMATION ABOUT HEALTHY EATING
Healthy eating is not about strict nutrition philosophies, staying unrealistically
thin, or depriving yourself of the foods you love. It’s about feeling great, having
more energy, and keeping yourself as healthy as possible– all of which can be
achieved by learning some nutrition basics and using them in a way that works
for you. Healthy eating starts with learning how to “eat smart”—it’s not just what
you eat, but how you eat. Learning the habits of healthy eating can boost your
energy, sharpen your memory and stabilize your mood. You can expand your
range of healthy food choices and learn how to plan ahead to create and
maintain a satisfying, healthy diet.
1. The glass platform will be slippery when it is wet. Keep dry.
2. Keep standing still during the course of weighing.
3. Treat the scale with care as it is a precise instrument.
4. Clean the scale with a damp cloth and avoid water getting inside the scale.
DO NOT use chemical/abrasive cleaning agents.
5. Keep the scale in cool place with dry air.
6. If scale fails to turn on, check whether battery is installed properly, or battery power
is low. Insert or replace new battery. Do not mix old and new batteries or different
types of batteries (alkaline, carbon zinc, rechargeable).
7. If there is error on display or the scale will not turn off for a long period of time,
please take out the battery for about 3 seconds, then install it again to correct error.
If you cannot resolve the problem, please contact Precision One
Customer Service for consultation.
8. Do not use for commercial purposes.
WARNING INDICATIONS
ADVICE FOR USE & CARE
OVERLOAD INDICATION
Scale overload. (Max. weight
capacity is indicated on the
scale). Please step off to
avoid damage.
LOW BATTERY
INDICATION.
Battery power is low. Please
install new battery.
RE-TEST
Display “C” when you step
off the scale, means an error
has occurred with the weight
reading. Please re-weigh.
LOW FAT%
INDICATION
The Fat% is below
the minimum
capability of scale.
HIGH FAT%
INDICATION
The Fat% exceeds
the maximum
capability of scale.
For additional information regarding this
product or its warranty, please contact us:
Precision One Lifecare
A Division of Lava Lite LLC
1200 Thorndale Avenue
Elk Grove Village, IL 60007
1-800-336-5282
email: service@precisiononescales.com
www.precisiononescales.com
* Precision One Lifecare is a registered trademark of Precision One Lifecare Ltd. in the U.S.A
and other countries around the world and used under license. All rights reserved.
LIMITED LIFETIME WARRANTY
Your Precision One product is warranted to the original consumer only, for the lifetime of the product,
to be free from defects in materials and workmanship under normal use. This product is designed for personal use only. Precision One, a division of Lava Lite LLC reserves the right to nullify the Warranty Agreement should the product be used in a commercial environment. This warranty is void if the
product has been tampered with, misused, abused or modified. Our obligation under this Warranty
is limited solely to the charge of repairing the product, including the cost of parts, or, at our option,
replacing the product with an equivalent model. There are no express or implied warranties except
as listed above. PRECISION ONE, A DIVISION OF LAVA LITE LLC IS NOT LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR FAILURE OR MALFUNCTION OF THE PRODUCT AND ANY
RECOVERY MAY NOT BE GREATER THAN THE PURCHASE PRICE PAID FOR THIS PRODUCT.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED
TO A PERIOD OF ONE (1) YEAR FROM THE PURCHASE DATE. Some states do not allow limitations
on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations may not apply to you. This Warranty gives you specific legal rights
and you may have other rights which vary from state to state.
To obtain warranty service, you must return the product freight pre-paid, in either its original packaging
or packaging affording an equal degree of protection, to Precision One, a division of Lava Lite LLC at
1200 Thorndale Avenue, Elk Grove Village, IL 60007.
Loading...
