PROVU PD7000 Temperature Meter

Instruction Manual

Temperature

USB Install

• Thermocouple: J, K, T, E, R, S, B, N, C

• RTD: 100Ω Pt, 10Ω Cu, 120Ω Ni, 1000Ω Pt inputs

• 1° or 0.1° Resolution

• Displays up to 3300 F

• Averages up to 10 RTD Sensors

• Automatic Cold Junction Compensation

• Dual-Line Display

• NEMA 4X and IP65 Rated Front Panel

• UL Listed & CE Marked

• Display Features 0.6" & 0.46" Digits

• Six Full Digits on Each Line

• Optional Superluminous Sunlight Readable Display

• Free USB Programming Software & Cable

• 2 or 4 Relays + Isolated 4-20 mA Output Options

• USB, RS-232, & RS-485 Serial Communication Options

• External 4-Relay & Digital I/O Expansion Modules

• Input Power Options Include 85-265 VAC or 12-24 VDC

• Isolated 24 VDC @ 200 mA Transmitter Power Supply

• Modbus® RTU Communication Protocol Standard

PRECISION DIGITAL CORPORATION

233 South Street • Hopkinton MA 01748 USA Tel (800) 343-1001 • Fax (508) 655-8990

www.predig.com

PROVU PD7000 Temperature Meter Instruction Manual

CAUTION: Read complete instructions prior to installation and operation of the meter.

WARNING: Risk of electric shock or personal injury.

Warning!

This product is not recommended for life support applications or applications where malfunctioning could result in personal injury or property loss. Anyone using this product for such applications does so at his/her own risk. Precision Digital Corporation shall not be held liable for damages resulting from such improper use.

Disclaimer

The information contained in this document is subject to change without notice. Precision Digital makes no representations or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.

Limited Warranty

Precision Digital Corporation warrants this product against defects in material or workmanship for the specified period under “Specifications” from the date of shipment from the factory. Precision Digital’s liability under this limited warranty shall not exceed the purchase value, repair, or replacement of the defective unit.

Registered Trademarks

PROVU® and MeterView® Pro are registered trademarks of Precision Digital Corporation. Modbus® is a Registered Trademark of Schneider Automation Inc. All other trademarks mentioned in this document are the property of their respective owners.

www.predig.com

PROVU PD7000 Temperature Meter Instruction Manual

Table of Contents

Table of Contents ----------------------------------------- 3 Table of Figures ------------------------------------------- 4 Introduction ------------------------------------------------- 4 Ordering Information ------------------------------------ 5 Specifications ---------------------------------------------- 5

General ------------------------------------------------------------ 5 Temperature Input --------------------------------------------- 6 Relays ------------------------------------------------------------- 6 Isolated 4-20 mA Output ------------------------------------ 7 Modbus® RTU Serial Communications ----------------- 7 PDA1044 Digital Input & Output Expansion Module

----------------------------------------------------------------------- 7 MeterView Pro -------------------------------------------------- 7

Compliance Information -------------------------------- 8

Safety -------------------------------------------------------------- 8 Electromagnetic Compatibility ---------------------------- 8

Safety Information ---------------------------------------- 9 Installation -------------------------------------------------- 9

Unpacking -------------------------------------------------------- 9 Panel Mounting Instructions ----------------------------- 10

Mounting Dimensions ------------------------------------ 10

Connections --------------------------------------------------- 11

Connectors Labeling -------------------------------------- 11 Power Connections --------------------------------------- 11 Signal Connections --------------------------------------- 12 Connections for Averaging RTD Sensors ----------- 13 Modbus RTU Serial Communications ---------------- 13 Relay Connections ---------------------------------------- 13 Switching Inductive Loads ------------------------------- 14 F4 Digital Input Connections ---------------------------- 14 4-20 mA Output Connections --------------------------- 15 Power Supply for Analog Output Loop or Other Uses ---------------------------------------------------------- 15 External Relays & Digital I/O Connections ---------- 15 Interlock Relay Feature ---------------------------------- 16

Setup and Programming ------------------------------ 17

Front Panel Buttons and Status LED Indicators -- 17 MeterView® Pro Software --------------------------------- 18

MeterView Pro Installation ------------------------------ 18

Display Functions & Messages ------------------------- 19 Main Menu ----------------------------------------------------- 21 Setting Numeric Values ----------------------------------- 21 Setting Up the Meter (setup) ----------------------------- 22

Setting the Input Signal (Input) ----------------------- 23 Selecting the Temperature Scale (F or C) --------- 23 Setting the Decimal Point (dEc pt) ------------------- 23 Setting the Display Parameter & Intensity (dsplay)

----------------------------------------------------------------- 23 Setting the Input Units or Custom Tags (units) --- 24 Setting the Relay Operation (relay) ----------------- 24

Setting the Relay Action ---------------------------------- 25

Programming Set and Reset Points ------------------ 25 Setting Fail-Safe Operation ----------------------------- 25 Programming Time Delay ------------------------------- 25

Relay Action for Loss of Input (Input Break) -------- 25

Relay and Alarm Operation Diagrams ---------------- 26

High Alarm Operation (Set > Reset) ------------------ 26 Low Alarm Operation (Set < Reset) ------------------ 26 High Alarm with Fail-Safe Operation (Set > Reset)

----------------------------------------------------------------- 26 Low Alarm with Fail-Safe Operation (Set < Reset) 26 Pump Alternation Control Operation ------------------ 27 Relay Sampling Operation ------------------------------ 27 Signal Loss or Input Break Relay Operation ------- 28 Time Delay Operation ------------------------------------ 28

Relay Operation Details ----------------------------------- 29

Overview ----------------------------------------------------- 29 Relays Auto Initialization -------------------------------- 29 Fail-Safe Operation --------------------------------------- 29 Front Panel LEDs ----------------------------------------- 29 Latching and Non-Latching Relay Operation ------- 30 Non-Latching Relay (Auto) ----------------------------- 30 Non-Latching Relay (A-nman) -------------------------- 30 Latching Relay (LatcH) ---------------------------------- 30 Latching Relay (Lt-Clr) --------------------------------- 30 Acknowledging Relays ----------------------------------- 31 Setting Up the Interlock Relay (Force On) Feature 31

Scaling the 4-20 mA Analog Output (Aout) --------- 32 Reset Menu (reset) ----------------------------------------- 32 Control Menu (Contrl) ------------------------------------- 32 Setting Up the Password (pass) ------------------------ 33

Protecting or Locking the Meter ----------------------- 33 Making Changes to a Password Protected Meter - 33 Disabling Password Protection ------------------------ 33

Advanced Features Menu -------------------------------- 34

Advanced Features Menu & Display Messages --- 34 Offset Adjust (Adjust) ----------------------------------- 35 Recalibration of the Meter (t CAL) -------------------- 36 Noise Filter (filter) ------------------------------------- 37 Noise Filter Bypass (bypass) --------------------------- 37 Rounding Feature (round) ------------------------------ 37 Modbus RTU Serial Communications (serial) --- 37 Select Menu (SElect) ------------------------------------ 38 Analog Output Programming (AoutPr) -------------- 38 Programmable Function Keys User Menu (user) - 39 Internal Temperature Calibration (ICAL) ------------ 40

Meter Operation ------------------------------------------ 42

Front Panel Buttons Operation ------------------------- 42 Function Keys Operation --------------------------------- 42 F4 Operation -------------------------------------------------- 42 Maximum/Minimum Readings --------------------------- 43

Troubleshooting ----------------------------------------- 44

Diagnostics Menu (diag) ---------------------------------- 44

Determining Software Version ------------------------- 44

Reset Meter to Factory Defaults ------------------------ 44

Factory Defaults & User Settings ---------------------- 45

Troubleshooting Tips -------------------------------------- 46

EU Declaration of Conformity ----------------------- 47

PROVU PD7000 Temperature Meter Instruction Manual

Table of Figures

Figure 1. 1/8 DIN Panel Cutout Dimensions .............. 10

Figure 2. Panel Mounting Details ............................... 10

Figure 3. Meter Dimensions - Side View ................... 10

Figure 4. Meter Dimensions - Top View .................... 10

Figure 5. Connector Labeling for Fully Loaded

PD7000 ................................................................. 11

Figure 6. Power Connections ..................................... 11

Figure 7. Thermocouple Input Connections ............. 12

Figure 8. Three-Wire RTD Input Connections ........... 12

Figure 9. Two-Wire RTD Input Connections ............. 12

Figure 10. Four-Wire RTD Input Connections ........... 12

Figure 11. Average Temperature RTD Input

Connections ........................................................ 13

Figure 12. Relay Connections ..................................... 13

Figure 13. AC and DC Loads Protection .................... 14

Figure 14. Low Voltage DC Loads Protection ........... 14

Figure 15. F4 Digital Input Connections .................... 14

Figure 16. 4-20 mA Output Connections .................... 15

Figure 17. Expansion Modules & DIN Rail Mounting

Kit .......................................................................... 15

Figure 18. External Relays Module Connections ...... 15

Figure 19. Digital I/O Module Connections ................ 15

Figure 20. Interlock Connections ............................... 16

Figure 21. Acknowledge Relays w/Function Key or

Digital Input .......................................................... 31

Introduction

The PROVU® PD7000 temperature meter accepts a direct temperature input from a wide range of temperature measurement devices (type J, K, T, E, R, S, B, N, and C thermocouples and 100 or 1000 Ω platinum, 10 Ω copper, 120 Ω nickel RTDs). It displays the measured temperature in either degrees Fahrenheit or degrees Celsius on a dual-line, 6-digit display whose superluminous LED digits make it easily readable in smoke, dust, fog, and, with the optional SunBright® display, even direct sunlight. The PD7000 includes automatic cold junction compensation for thermocouples and the ability to average up to ten (10) RTD sensors.

A fully loaded PD7000 meter has the following: four SPDT relays, 4-20 mA output, and one 24 VDC power supply to power the 4-20 mA output. The PD7000 capabilities may be enhanced by adding the following external expansion modules: four SPST relays (creating an eight-relay temperature meter), two digital I/O modules with four inputs and four outputs each, and USB, RS-232 or RS-485 communication adapters. A digital input is standard.

The eight relays can be used for alarm indication or temperature control applications. The 4-20 mA isolated output, Modbus RTU serial communications, and digital I/O options make the PD7000 an excellent addition to any system.

PROVU PD7000 Temperature Meter Instruction Manual

85-265 VAC Model

12-24 VDC Model

Options Installed

PD7000-6R0

PD7000-7R0

No options

PD7000-6R2

PD7000-7R2

2 relays (PD1102*)

PD7000-6R3

PD7000-7R3

4-20 mA output (PD1103*)

PD7000-6R4

PD7000-7R4

4 relays (PD1104*)

PD7000-6R5

PD7000-7R5

2 relays & 4-20 mA output (PD1105*)

PD7000-6R7

PD7000-7R7

4 relays & 4-20 mA output (PD1107*)

*Model number for replacement option card.

85-265 VAC Model

12-24 VDC Model

Options Installed

PD7000-6H0

PD7000-7H0

No options

PD7000-6H2

PD7000-7H2

2 relays (PD1102*)

PD7000-6H3

PD7000-7H3

4-20 mA output (PD1103*)

PD7000-6H4

PD7000-7H4

4 relays (PD1104*)

PD7000-6H5

PD7000-7H5

2 relays & 4-20 mA output (PD1105*)

PD7000-6H7

PD7000-7H7

4 relays & 4-20 mA output (PD1107*)

*Model number for replacement option card.

Model

Description

PDA1002

DIN rail mounting kit for two expansion modules

PDA1004

4 SPST (Form A) relays

PDA1044

4 digital inputs & 4 digital outputs (2 may be connected)

PDA1232

RS-232 serial adapter

PDA1485

RS-485 serial adapter

PDA7485-I

RS-232 to RS-422/485 isolated converter

PDA7485-N

RS-232 to RS-422/485 non-isolated converter

PDA8232-N

USB to RS-232 non-isolated converter

PDA8485-I

USB to RS-422/485 isolated converter

PDA8485-N

USB to RS-422/485 non-isolated converter

PDX6901

Suppressor (snubber): 0.01 µF/470 , 250 VAC

Display

Line 1: 0.60" (15 mm) high red LEDs; Line 2: 0.46" (12 mm) high red LEDs. Both displays have six characters with leading zero blanking. Temperature value is four or five-digit F/C, based on configuration.

Resolution

1 or 0.1 for all thermocouples and RTD inputs

Display Intensity

Eight user selectable intensity levels

Display Update Rate

5/second (200 ms)

Overrange

Display flashes 99999

Underrange

Display flashes -9999

Programming Methods

Four front panel buttons, digital inputs, PC and MeterView® Pro software, or Modbus registers.

Noise Filter

Programmable from 2 to 199 (0 will disable filter)

Filter Bypass

Programmable from 0.1 to 99.9% of calibrated span

Recalibration

All ranges are calibrated at the factory. Recalibration is recommended at least every 12 months.

Max/Min Display

Max/min readings reached by the process are stored until reset by the user or until power to the meter is cycled.

Ordering Information

Standard Models

SunBright Display Models

Accessories

Specifications

Except where noted all specifications apply to operation at +25°C.

General

PROVU PD7000 Temperature Meter Instruction Manual

Password

Three programmable passwords restrict modification of programmed settings.

Pass 1: Allows use of function keys and digital inputs Pass 2: Allows use of function keys, digital inputs and editing set/reset points Pass 3: Restricts all programming, function keys, and digital inputs.

Non-Volatile Memory

All programmed settings are stored in nonvolatile memory for a minimum of ten years if power is lost.

Power Options

85-265 VAC 50/60 Hz, 90-265 VDC, 20 W max or 12-24 VDC  10%, 15 W max

Powered over USB for configuration only

Fuse

Required external fuse: UL Recognized, 5 A max, slow blow; up to 6 meters may share one 5 A fuse

Normal Mode Rejection

Greater than 60 dB at 50/60 Hz

Isolation

4 kV input/output-to-power line 500 V input-to-output

Overvoltage Category

Installation Overvoltage Category II: Local level with smaller transient overvoltages than Installation Overvoltage Category III.

Environmental

Operating temperature range: -20 to 65°C Storage temperature range: -40 to 85°C Relative humidity: 0 to 90% non-condensing

Connections

Removable screw terminal blocks accept 12 to 22 AWG wire, RJ45 for external relays, digital I/O, and serial communication adapters.

Enclosure

1/8 DIN, high impact plastic, UL 94V-0, color: black

Mounting

1/8 DIN panel cutout required:

3.622" x 1.772" (92 mm x 45 mm) Two panel mounting bracket assemblies are provided.

Tightening Torque

Screw terminal connectors: 5 lb-in (0.56 Nm)

Overall Dimensions

4.68" x 2.45" x 5.64" (119 mm x 62 mm x 143 mm) (W x H x D)

Weight

9.5 oz (269 g)

Warranty

3 years parts & labor

F4 Digital Input Contacts

3.3 VDC on contact. Connect normally open contacts across F4 to COM.

F4 Digital Input Logic Levels

Logic High: 3 to 5 VDC Logic Low: 0 to 1.25 VDC

Inputs

Thermocouple: J, K, T, E, R, S, B, N, C; RTD: 100 Ω platinum (0.00385 & 0.00392 coefficients), 10 Ω copper, 120 Ω nickel, 1000 Ω platinum (0.00385 & 0.00392 coefficients)

Cold Junction Reference

Automatic, fixed, no user calibration needed

Temperature Drift

2C maximum from 0 to 65C ambient temperature 4C maximum from -20 to 0C ambient temperature

Offset Adjustment

User programmable offset adjust ±50.0 degrees. This parameter allows the user to apply an offset value to the temperature being displayed.

Input Impedance

Greater than 100 k

Sensor Break Detection

Open TC or RTD sensor indicated by display flashing oPEn, relays can be programmed to go “On”, “Off”, or to “Ignore” (Note: Ignore is detected as an upscale condition). Analog output goes to the programmed sensor break value.

Rtd Averaging

Up to 10 RTDs connected in parallel can be averaged.

Accuracy & Ranges

Type

Range (°F)

Accuracy

Range (°C)

Accuracy

-200 to 2000

±1.8°F

-129 to 1093

±1°C

-200 to 2400

±1.8°F

-129 to 1316

±1°C

-200 to 752

±1.8°F

-129 to 400

±1°C

-200 to 1800

±1.8°F

-129 to 982

±1°C

-50 to 3000

±3.6°F

-46 to 1649

±2°C

-50 to 3000

±3.6°F

-46 to 1649

±2°C

752 to 3300

±3.6°F

400 to 1816

±2°C

-100 to 2300

±3.6°F

-73 to 1260

±2°C

32 to 4100

±3.6°F

0 to 2260

±2°C

10

-328 to 500

±0.2°F

-200 to 260

±0.1°C

100

-328 to 1562

±0.7°F

-200 to 850

±0.4°C

120

-110 to 500

±0.2°F

-79 to 260

±0.1°C

1000

-328 to 900

±0.7°F

-200 to 482

±0.4°C

Rating

2 or 4 SPDT (Form C) internal and/or 4 SPST (Form A) external; rated 3 A @ 30 VDC and 125/250 VAC resistive load; 1/14 HP (≈ 50 W) @ 125/250 VAC for inductive loads

Noise Suppression

Noise suppression is recommended for each relay contact switching inductive loads; see page 14 for details.

Deadband

0-100% of span, user programmable

High Or Low Alarm

User may program any alarm for high or low trip point. Unused alarm LEDs and relays may be disabled (turn off).

Relay Operation

Automatic (non-latching) Latching (requires manual acknowledge) Sampling (based on time) Relay alternation control (2 to 8 relays) Off (disable unused relays and enable Interlock feature) Manual on/off control mode

Temperature Input

Relays

PROVU PD7000 Temperature Meter Instruction Manual

Relay Reset

User selectable via front panel buttons or digital inputs

1. Automatic reset only (non-latching), when the input passes the reset point.

2. Automatic + manual reset at any time (non-latching)

3. Manual reset only, at any time (latching)

4. Manual reset only after alarm condition has cleared (L)

Note: Front panel button or digital input may be assigned to acknowledge relays programmed for manual reset.

Time Delay

0 to 999.9 seconds, on & off relay time delays Programmable and independent for each relay

Fail-Safe Operation

Programmable and independent for each relay.

Note: Relay coil is energized in non-alarm condition. In case of power failure, relay will go to alarm state.

Auto Initialization

When power is applied to the meter, relays will reflect the state of the input to the meter.

Output Source

PV (temperature), max, min, set points 1-8, Modbus PV input, or manual control mode

Scaling Range

1.000 to 23.000 mA for any display range

Calibration

Factory calibrated 0.0 to 2000.0 = 4-20 mA output

Analog Out Programming

23.000 mA maximum for all parameters:

Overrange, underrange, max, min, and break

Accuracy

± 0.1% of span ± 0.004 mA

Temperature Drift

0.4 µA/C max from 0 to 65C ambient,

0.8 µA/C max from -20 to 0C ambient

Note: Analog output drift is separate from input drift.

Power Supply For Analog Output Loop Or Other Uses

Terminals I+ & R: 24 VDC  10%. May be used to power the 4-20 mA output or other devices.Refer to Figure 6 on page 11 and Figure 17 on page 15.

ProVu Series (PD7000): All models rated @ 40 mA max. ProtEX-MAX (PD8 Series): All models @ 25 mA max.

External Loop Power Supply

35 VDC maximum

Output Loop Resistance

Power supply

Minimum

Maximum

24 VDC

10 

700 

35 VDC (external)

100 

1200 

Slave Id

1 – 247 (Meter address)

Baud Rate

300 – 19,200 bps

Transmit Time Delay

Programmable between 0 and 199 ms

Data

8 bit (1 start bit, 1 or 2 stop bits)

Parity

Even, Odd, or None with 1 or 2 stop bits

Byte-To-Byte Timeout

0.01 to 2.54 sec

Turn Around Delay

Less than 2 ms (fixed)

Note: Refer to the PROVU® Modbus Register Tables located at www.predig.com for details.

Channels

4 digital inputs & 4 digital outputs per module

System

Up to 2 modules for a total of 8 inputs & 8 outputs

Digital Input Logic High

3 to 5 VDC

Digital Input Logic Low

0 to 1.25 VDC

Digital Output Logic High

3.1 to 3.3 VDC

Digital Output Logic Low

0 to 0.4 VDC

Source Current

10 mA maximum output current

Sink Current

1.5 mA minimum input current

+5 V Terminal

To be used as pull-up for digital inputs only. Connect normally open contacts across +5 V & DI 1-4

System Requirements

Microsoft® Windows® XP/Vista/7/8/10

Communications

USB 2.0 (Standard USB A to Micro USB B)

Configuration

Configure meters one at a time

Modbus® RTU Serial Communications

PDA1044 Digital Input & Output Expansion Module

Isolated 4-20 mA Output

MeterView Pro

PROVU PD7000 Temperature Meter Instruction Manual

UL & c-UL Listed

USA & Canada UL 508 Industrial Control Equipment

UL File Number

E160849

Front Panel

UL Type 4X, NEMA 4X, IP65; panel gasket provided

Low Voltage Directive

EN 61010-1:2010 Safety requirements for measurement, control, and laboratory use

Emissions

EN 55022:2010 Class A ITE emissions requirements

Radiated Emissions

Class A

AC Mains Conducted Emissions

Class A

Immunity

EN 61326-1:2013 Measurement, control, and laboratory equipment EN 61000-6-2:2005 EMC heavy industrial generic immunity standard

RFI - Amplitude Modulated

80 -1000 MHz 10 V/m 80% AM (1 kHz)

1.4 - 2.0 GHz 3 V/m 80% AM (1 kHz)

2.0 - 2.7 GHz 1 V/m 80% AM (1 kHz)

Electrical Fast Transients

±2kV AC mains, ±1kV other

Electrostatic Discharge

±4kV contact, ±8kV air

RFI - Conducted

10V, 0.15-80 MHz, 1kHz 80% AM

AC Surge

±2kV Common, ±1kV Differential

Surge

1KV (CM)

Power-Frequency Magnetic Field

30 A/m 70%V for 0.5 period

Voltage Dips

40%V for 5 & 50 periods 70%V for 25 periods

Voltage Interruptions

<5%V for 250 periods

Compliance Information

Safety

Electromagnetic Compatibility

Note:

Testing was conducted on PD7000 meters installed through the covers of grounded metal enclosures with cable shields grounded at the point of entry representing installations designed to optimize EMC performance.

Declaration of Conformity available at www.predig.com

PROVU PD7000 Temperature Meter Instruction Manual

CAUTION: Read complete instructions prior to installation and operation of the meter.

WARNING: Risk of electric shock or personal injury.

WARNING!

Hazardous voltages exist within enclosure. Installation and service should be performed only by trained service personnel.

Safety Information

Installation

There is no need to remove the meter from its case to complete the installation, wiring, and setup.

Unpacking

Remove the meter from box. Inspect the packaging and contents for damage. Report damages, if any, to the carrier. If any part is missing or the meter malfunctions, please contact your supplier or the factory for assistance.

PROVU PD7000 Temperature Meter Instruction Manual

Figure 1. 1/8 DIN Panel Cutout Dimensions

Figure 2. Panel Mounting Details

Figure 3. Meter Dimensions - Side View

Figure 4. Meter Dimensions - Top View

3.622" (92mm)

1.772"

(45mm)

Panel Cutout

to DIN 43700

Square Corners to 0.060"

(1.5mm) Max Radius

Tolerances:

A: +0.032 (+0.8mm)

-0.000 (-0.0mm)

B: +0.024 (+0.6mm)

-0.000 (-0.0mm)

Panel Mounting Instructions

• Prepare a standard 1/8 DIN panel cutout – 3.622" x 1.772" (92 mm x 45 mm). Refer to Figure 1 below, for more details.

• Clearance: allow at least 6.0" (152 mm) behind the panel for wiring.

• Panel thickness: 0.04" - 0.25" (1.0 mm - 6.4 mm).

Recommended minimum panel thickness to maintain Type 4X rating: 0.06" (1.5 mm) steel panel, 0.16" (4.1 mm) plastic panel.

• Remove the two mounting brackets provided with the meter (back-off the two screws so that there is ¼" (6.4 mm) or less through the bracket. Slide the bracket toward the front of the case and remove).

• Insert meter into the panel cutout.

• Install mounting brackets and tighten the screws against the panel. To achieve a proper seal, tighten

the mounting bracket screws evenly until meter is snug to the panel along its short side. DO NOT OVER TIGHTEN, as the rear of the panel may be damaged.

Mounting Dimensions

PROVU PD7000 Temperature Meter Instruction Manual

Caution!

Use copper wire with 60°C or 60/75°C insulation for all line voltage connections. Observe all safety regulations. Electrical wiring should be performed in accordance with all applicable national, state, and local codes to prevent damage to the meter and ensure personnel safety.

Warning!

Do not connect any equipment other than Precision Digital’s expansion modules, cables, or meters to the RJ45 M-LINK connector. Otherwise damage will occur to the equipment and the meter.

AC or DC

POWER

Required External Fuse:

5 A max, 250 V Slow Blow

POWER

Connections

All connections are made to removable screw terminal connectors located at the rear of the meter.

Connectors Labeling

The connectors’ label, affixed to the meter, shows the location of all connectors available with requested configuration.

Figure 5. Connector Labeling for Fully Loaded PD7000

Power Connections

Power connections are made to a two-terminal connector labeled POWER on Figure 5. The meter will operate regardless of DC polarity connection. The + and - symbols are only a suggested wiring convention.

Figure 6. Power Connections

PROVU PD7000 Temperature Meter Instruction Manual

Figure 7. Thermocouple Input

Connections

Figure 8. Three-Wire RTD Input

Connections

Figure 9. Two-Wire RTD Input

Connections

Figure 10. Four-Wire RTD Input

Connections

SIGNAL

EXC T+ COM

1 2 3

RTD

TYPE

100

RANGE

M-LINK

1 2 3 4 5 6 7 8

RTD

Sensor

SIGNAL

EXC T+ COM

1 2 3

RTD

TYPE

100

RANGE

M-LINK

1 2 3 4 5 6 7 8

RTD

Sensor

SIGNAL

EXC T+ COM

1 2 3

RTD

TYPE

100

RANGE

M-LINK

1 2 3 4 5 6 7 8

RTD

Sensor

SIGNAL

EXC T+ COM

1 2 3

RTD

TYPE

100

RANGE

M-LINK

1 2 3 4 5 6 7 8

Signal Connections

Signal connections are made to a three-terminal connector labeled SIGNAL on Figure 5.

Thermocouple and RTD Connections

The following figures show examples for thermocouple and RTD connections. The TYPE selector switch must be set to the proper position for the meter to accept the selected RTD or

TC input. The RANGE selector switch is used to select 100-ohm platinum or 10-ohm copper RTD. The 1000-ohm

platinum RTD input uses the same setting as the 100-ohm RTD. The input type is selected using the Setup menu. The selected thermocouple input must correspond to the thermocouple sensor and wire type used. The meter accepts two, three, or four-wire RTDs. The three-wire RTD connection has built-in lead wire

compensation. Lead wire compensation for two-wire RTDs can be applied using the Adjust menu. See the Advanced Features Menu on page 34. The four-wire RTD connection is similar to the three-wire. One of the leads of a four-wire RTD is not connected, and may be clipped off.

The three-wire connection provides sufficient lead wire compensation to obtain accurate readings even with long leads.

PROVU PD7000 Temperature Meter Instruction Manual

RTD1

SIGNAL

EXC T+ C OM

1 2 3

RTD

TYPE

100

RANGE

M-LINK

1 2 3 4 5 6 7 8

RTD2 RTD3

C NONO NC NC C

RELAY4 RELAY3

4 36 5 2 1

C NONO NC NC C

RELAY2 RELAY1

4 36 5 2 1

Connections for Averaging RTD Sensors

To obtain the average temperature from 2 to 10 RTD sensors, connect all the sensors in parallel and select the number of sensors in the RTD Total (rtdtot) menu. See the Advanced Features Menu on page 34.

Figure 11. Average Temperature RTD Input Connections

Modbus RTU Serial Communications

Serial communications connection is made to an RJ45 connector labeled M-LINK on Figure 5. For interfacing to the PROVU®, use the PDA1232 for RS-232 or the PDA1485 for RS-485. The same port is used for interfacing with all expansion modules (i.e. external relays, digital I/O).

Relay Connections

Relay connections are made to two six-terminal connectors labeled RELAY1 – RELAY4 on Figure 5. Each relay’s C terminal is common only to the normally open (NO) and normally closed (NC) contacts of the corresponding relay. The relays’ C terminals should not be confused with the COM (common) terminal of the INPUT SIGNAL connector.

Figure 12. Relay Connections

PROVU PD7000 Temperature Meter Instruction Manual

Use a diode with a reverse breakdown voltage two to three times the circuit voltage and forward current at least as large as the load current.

Switching Inductive Loads

The use of suppressors (snubbers) is strongly recommended when switching inductive loads to prevent disrupting the microprocessor’s operation. The suppressors also prolong the life of the relay contacts. Suppression can be obtained with resistor-capacitor (RC) networks assembled by the user or purchased as complete assemblies. Refer to the following circuits for RC network assembly and installation:

Figure 13. AC and DC Loads Protection

Choose R and C as follows: R: 0.5 to 1 Ω for each volt across the contacts C: 0.5 to 1 µF for each amp through closed contacts

Notes:

1. Use capacitors rated for 250 VAC.

2. RC networks may affect load release time of solenoid loads. Check to confirm proper operation.

3. Install the RC network at the meter's relay screw terminals. An RC network may also be installed across the load. Experiment for best results.

Figure 14. Low Voltage DC Loads Protection

RC Networks Available from Precision Digital

RC networks are available from Precision Digital and should be applied to each relay contact switching an inductive load. Part number: PDX6901.

Note: Relays are de-rated to 1/14th HP (50 watts) with an inductive load.

F4 Digital Input Connections

A digital input, F4, is standard on the meter. This digital input connected with a normally open closure across F4 and COM, or with an active low signal applied to F4.

Figure 15. F4 Digital Input Connections

PROVU PD7000 Temperature Meter Instruction Manual

Warning!

Do not connect or disconnect the expansion modules with the power on! More detailed instructions are provided with each optional expansion module.

Figure 17. Expansion Modules & DIN Rail

Mounting Kit

Figure 18. External Relays Module

Connections

Figure 19. Digital I/O Module Connections

12-35 VDC

Power Supply

4-20 mA

Input Meter

RI- I+

13 2

RELAY1

3 2 1

24 V

4-20 mA Input

Remote Display,

Chart Recorder, Etc.

RI- I+

MA OUT

13 2

RELAY1

3 2 1

24 V

MA OUT

1 2

RLY5 RLY6 RLY7 RLY8

3 4 5 6 7 8

NO C NO C NO C NO C

1 2 3 4 5 6

+5 I1 I2 I3 I4 O1

7 8

O2 O3

9 10

O4 G

DI 1-4 DO 1-4

5 VDC GND

4-20 mA Output Connections

Connections for the 4-20 mA output are made to the connector terminals labeled MA OUT. The 4-20 mA output may be powered internally or from an external power supply.

Figure 16. 4-20 mA Output Connections

Power Supply for Analog Output Loop or Other Uses

The internal 24 VDC power supply powering the analog output may be used to power other devices, if the analog output is not used. The I+ terminal is the +24 V and the R terminal is the return.

External Relays & Digital I/O Connections

The relay and the digital I/O expansion modules PDA1004 & PDA1044 are connected to the meter using a CAT5 cable provided with each module. The two RJ45 connectors on the expansion modules are identical and interchangeable; they are used to connect additional modules to the system.

Note: The jumper located between the RJ45 connectors of the PDA1044 must be removed on the second

digital I/O module in order for the system to recognize it as module #2.

PROVU PD7000 Temperature Meter Instruction Manual

Interlock Relay Feature

As the name implies, the interlock relay feature reassigns one, or more, alarm/control relays for use as interlock relay(s). Interlock contact(s) are wired to digital input(s) and trigger the interlock relay. This feature is enabled by configuring the relay, and relative digital input(s) (see page 31). In one example, dry interlock contacts are connected in series to one digital input which will be used to force on (energize) the assigned interlock power relay when all interlock contacts are closed (safe). The interlock relay front panel LED flashes when locked out. The interlock relay would be wired in-series with the load (N/O contact). See below.

Figure 20. Interlock Connections

PROVU PD7000 Temperature Meter Instruction Manual

The meter is factory calibrated prior to shipment to read temperature in degrees Fahrenheit. The calibration equipment is certified to NIST standards.

Button Symbol

Description

LED

Status

1-8

Alarm 1-8 indicator

Right arrow/F1

1-8-M

Flashing: Relay in manual control mode

Up arrow/F2

Manual control relays &/or analog output

Enter/F3

1-4

Flashing: Relay interlock switch open

Note: F4 is a digital input. Alarms 5-8

are enabled when relay expansion module is installed.

Note: LEDs for relays in manual mode

flash with the “M” LED every 10 seconds.

Setup and Programming

Overview

There are two switches, located at the back of the meter, to set the input selection for TC or RTD and for 100-ohm platinum or 10-ohm copper. The 1000-ohm RTD input uses the same setting as the 100-ohm.

Setup and programming is done through the front panel buttons. After power and input signal connections have been completed and verified, apply power to the meter.

Front Panel Buttons and Status LED Indicators

• Press the Menu button to enter or exit the Programming Mode at any time.

• Press the Right arrow button to move to the next digit during digit or decimal point programming.

• Press or hold the Up arrow button to scroll through the menus,

move the decimal point or to increment the value of a digit.

• Press the Enter button to access a menu or to accept a setting.

• Press and hold the Menu button for three seconds to access the advanced features of the meter.

PROVU PD7000 Temperature Meter Instruction Manual

Note: If you decide to update your MeterView Pro software, once the installation has completed, you will be asked if you want to update the setup files located on the meter itself. This way, you will always have the most current version on the meter for future installs.

Warn-

ing!

Do not unplug the meter while the new installation files are being written to it. The meter will display

uwrite

during the process and you will receive an onscreen noti-

fication once the process is complete.

MeterView® Pro Software

The meter can also be programmed using the PC-based MeterView Pro software included with the meter. This software can be installed on any Microsoft® Windows® (XP/Vista/7/8/10) computer by connecting the meter’s onboard USB. The meter is powered by the USB connection, so there is no need to wire anything prior to programming the meter, though USB is intended only for meter configuration.

MeterView Pro Installation

1. Connect one end of the provided USB cable to the meter and the other end to the computer.

The computer will automatically install the driver software it needs to talk to the meter.

Only one meter may be connected at a time. Attaching multiple meters will cause a conflict with the meter software.

2. Once the driver is installed, an AutoPlay dialog should appear

for the drive “MAINSTAL.” Click “Open folder to view files.” If the computer does not display an AutoPlay dialog for the drive “MAINSTAL,” you should open My Computer and doubleclick on the drive labeled “MAINSTAL.”

3. Double-click on the file named “MAStart.” The program will

open a few windows and install two programs on your computer. Simply follow the onscreen instructions until you see one of the dialogs below. If you receive a “User Account Control” warning, click “Yes.”

4. If there is an update available, click the “Update” button to in-

stall the new version. Otherwise, click “Configure” to begin programming your meter.

Data logging for one meter at a time is available with MeterView Pro software. More advanced data acquisition may be accomplished by using any Modbus RTU compliant software. Additional information regarding configuration and monitoring of the meter using MeterView Pro software is available online. Go to www.predig.com/meterview-pro.

PROVU PD7000 Temperature Meter Instruction Manual

Display

Parameter

Action/Setting Description

setup

Setup

Enter Setup menu

Input

Enter Input selection menu

Set meter for thermocouple input J, K, T, E, R, S, B, N, C

Rtd

RTD

Set meter for RTD input 100Pt, 1000Pt, 10Cu, 120Ni

A385

Set meter for 0.00385 curve

A392

Set meter for 0.00392 curve

F or C

Press Enter to select degrees F or C

unitS

Units

Select the display units/tags

Dec pt

Decimal point

Set decimal point dddd, dddd.d, dddd°F, dddd.dF

dsplay

Display

Enter the Display menu

Line 1

Press Enter to assign the upper display parameter (default: PV - temperature)

Line 2

Press Enter to assign the lower display parameter (default: engineering units)

d-Inty

Display intensity

Set display intensity level from 1 to 8

RELaY

Relay

Enter the Relay menu

RLY 1

Relay 1

Relay 1 setup

Act 1

Action 1

Set relay 1 action

Auto

Automatic

Set relay for automatic reset

A-nman

Automanual

Set relay for automatic & manual reset any time

LatcH

Latching

Set relay for latching operation

Display

Parameter

Action/Setting Description

Lt-CLr

Latchingcleared

Set relay for latching operation with manual reset only after alarm condition has cleared

Altern

Alternate

Set relay for alternation control

Sanmpl

Sampling

Set relay for sampling operation

OFF

Off

Disable relay and front panel status LED (Select Off to enable Interlock feature)

Set 1

Program set point 1

RSt 1

Reset 1

Program reset point 1

RLY 2

Relay 2

Relays 2-8 setup

Note: Relays 5-8 are shown only if expansion relay module is installed

FaiLSF

Fail-safe

Enter Fail-safe menu

FLS 1

Fail-safe 1

Set relay 1 fail-safe operation

Enable fail-safe operation

off

Off

Disable fail-safe operation

FLS 2

Fail-safe 2

Set relays 2-8 failsafe operation

DeLAY

Delay

Enter relay Time Delay menu

DLY 1

Delay 1

Enter relay 1 time delay setup

On 1

Set relay 1 On time delay

OFF 1

Off 1

Set relay 1 Off time delay

DLY 2

Delay 2

Enter relays 2-8 time delay setup

break

Break

Set relay condition if input break detected

ignore

Ignore

Ignore input break condition (Processed as an upscale condition)

Display Functions & Messages

The meter displays various functions and messages during setup, programming, and operation. The following table shows the main menu functions and messages in the order they appear in the menu.

PROVU PD7000 Temperature Meter Instruction Manual

Display

Parameter

Action/Setting Description

Relay goes to alarm condition when input break is detected

Off

Relay goes to nonalarm condition when input break is detected

Aout

Analog output

Enter the Analog output scaling menu

Dis 1

Display 1

Program display 1 value

Out 1

Output 1

Program output 1 value (e.g. 4.000 mA)

Dis 2

Display 2

Program display 2 value

Out 2

Output 2

Program output 2 value (e.g. 20.000 mA)

reset

Reset

Press Enter to access the Reset menu

Rst Hi

Reset high

Press Enter to reset max display

Rst Lo

Reset low

Press Enter to reset min display

Rst HL

Reset hi/low

Press Enter to reset max & min displays

Display

Parameter

Action/Setting Description

Contrl

Control

Enter Control menu

Auto

Automatic

Press Enter to set meter for auto operation

mAn

Manual

Press Enter to manually control relays or analog output operation

pass

Password

Enter the Password menu

Pass 1

Password 1

Set or enter Password 1

Pass 2

Password 2

Set or enter Password 2

Pass 3

Password 3

Set or enter Password 3

unloc

Unlocked

Program password to lock meter

locd

Locked

Enter password to unlock meter

99999

-9999

Flashing display

Overrange condition Underrange condition

Open

Open sensor indication

PROVU PD7000 Temperature Meter Instruction Manual

0 0 1.000

00 1 .000

00 2 .000

set 1

eset 1

Select

Digit

Increment

Digital

alue

Setting

Main Menu

The main menu consists of the most commonly used functions: Setup, Reset, Control, and Password.

• Press Menu button to enter Programming Mode then press the Up arrow button to scroll main menu.

• Press Menu, at any time, to exit and return to Run Mode. Changes made to settings prior to pressing Enter are not saved.

• Changes to the settings are saved to memory only after pressing Enter/F3.

• The display moves to the next menu every time a setting is accepted by pressing Enter/F3.

Setting Numeric Values

The numeric values are set using the Right and Up arrow buttons. Press Right arrow to select next digit and Up arrow to increment digit value.

The digit being changed is displayed brighter than the rest. Press and hold up arrow to auto-increment the display value. Press the Enter button, at any time, to accept a setting or Menu button to exit without saving changes.

PROVU PD7000 Temperature Meter Instruction Manual

Setting Up the Meter (setup)

It is very important to read the following information, before proceeding to program the meter:

• The meter is factory calibrated prior to shipment to read temperature in degrees Fahrenheit. The calibration equipment is certified to NIST standards.

• There is no need to calibrate the meter, simply select the input type, °F or °C, and decimal point.

The Setup menu is used to select:

1. Input type the meter will accept

2. Degrees F or C

3. Select the display units/tags

4. Decimal point position and F or C indication

5. Display parameter and intensity

6. Relay operation

7. 4-20 mA analog output scaling

Press the Enter button to access any menu or press Up arrow button to scroll through choices. Press the Menu button to exit at any time.

PROVU PD7000 Temperature Meter Instruction Manual

Setting the Input Signal (Input)

Enter the Input menu to set up the meter to accept thermocouple (tc) or RTD (rtd) inputs. The Type selector switch, located at the rear of the meter, must be set accordingly.

The thermocouple input is capable of accepting various types of thermocouples. The RTD input is capable of accepting various types of RTD sensors. After selecting 100 Pt or 1000Pt, it is

necessary to select either A385 (0.00385) or A392 (0.00392) coefficient.

Selecting the Temperature Scale (F or C)

The meter can display the temperature in degrees Fahrenheit or Celsius.

Setting the Decimal Point (dEc pt)

The temperature may be displayed with one decimal or with no decimal point. The temperature scale can also be displayed with the reading. The degree symbol is available only with no decimal point selected.

Pressing the Up arrow scrolls the decimal point and temperature format selections.

Setting the Display Parameter & Intensity (dsplay)

Display line 1 (line 1) can be programmed to display:

1. Process value

2. Relay set points

3. Max & min values

4. Modbus input

5. Display reading and units

Display line 2 (line 2) can be programmed to display:

1. Process value

2. Relay set points

3. Max & min values

4. Engineering units or custom legends

5. Modbus input

6. Off (no display)

7. Display reading and units

Display Intensity: The meter has eight display intensity levels to give the best performance under various lighting conditions. Select intensity 8 for outdoor applications. The default intensity is 8.

Press the Up arrow to change selection, press Enter to accept setting, and press Menu to exit programming

After setting up the input and display, press the Menu button to exit programming and skip the rest of the setup menu. Press the Menu button again and the Up arrow to reach the Setup menu again and complete the setup of the meter.

PROVU PD7000 Temperature Meter Instruction Manual

Display

Character

Display

Character

Display

Character

Display

Character

uw w 2

n m

x X 3

y Y 4

z Z 5

- - 6

/ / 7

[ ] 8

] [ 9

Degree(<)

Space

Caution!

During setup, the relays do not follow the input and they will remain in the state found prior to entering the Relay menu.

Setting the Input Units or Custom Tags (units)

Enter the input unit or custom tag that will be displayed if alternating rate, total, or grand total and units is selected in the units menu, or d unit is selected as the Lower display parameter. See the flow chart on page 23 to access the display menu to show the unit or tag on the Lower display. The engineering units or custom legends can be set using the following 7-segment character set:

Notes: Degree symbol represented by (<) if programming with MeterView® Pro. The letters “m” and “w” use two 7-segment LEDs each; when selected the characters to the right are shifted

one position. Press and hold up arrow to auto-scroll the characters in the display.

Setting the Relay Operation (relay)

This menu is used to set up the operation of the relays.

1. Relay action a. Automatic reset only (non-latching) b. Automatic + manual reset at any time (non-

latching) c. Latching (manual reset only) d. Latching with Clear (manual reset only after alarm condition has cleared) e. Relay alternation control (automatic reset only) f. Sampling (the relay is activated for a user-specified time) g. Off (relay disabled and

Interlock feature enabled)

2. Set point

3. Reset point

4. Fail-safe operation a. On (enabled) b. Off (disabled)

5. Time delay a. On delay (0-999.9

seconds)

b. Off delay (0-999.9

seconds)

6. Relay action for loss (break) of input (ignore, on, off)

PROVU PD7000 Temperature Meter Instruction Manual

Setting the Relay Action

Operation of the relays is programmed in the Action menu. The relays may be set up for any of the following modes of operation:

1. Automatic reset (non-latching)

2. Automatic + manual reset at any time (non-latching)

3. Latching (manual reset only, at any time)

4. Latching with Clear (manual reset only after alarm condition has cleared)

5. Relay alternation control (automatic reset only)

6. Sampling (the relay is activated for a user-specified time)

7. Off (relay disabled and Interlock feature enabled)

The following graphic shows relay 1 action setup; relay 2-8 are set up in a similar fashion.

Programming Set and Reset Points

High alarm indication: program set point above reset point. Low alarm indication: program set point below reset point. The deadband is determined by the difference between set

and reset points. Minimum deadband is one display count. If the set and reset points are programmed with the same value, the relay will reset one count below the set point.

Note: Changes are not saved until the reset point has been accepted.

Setting Fail-Safe Operation

In fail-safe mode of operation, the relay coil is energized when the process variable is within safe limits and the relay coil is de-energized when the alarm condition exists. The fail-safe operation is set independently for each relay. Select on to enable or select off to disable fail- safe operation.

Programming Time Delay

The On and Off time delays may be programmed for each relay between 0 and 999.9 seconds. The relays will transfer only after the condition has been maintained for the corresponding time delay.

The On time delay is associated with the set point. The Off time delay is associated with the reset point.

Relay Action for Loss of Input (Input Break)

Each relay may be programmed to go to one of the following conditions when the meter detects the loss of the input signal:

1. Turn On (Go to alarm condition)

2. Turn Off (Go to non-alarm condition)

3. Ignore (Processed as an upscale condition)

PROVU PD7000 Temperature Meter Instruction Manual

High Alarm Operation (Set > Reset)

For Manual reset mode, ACK can be pressed anytime to turn "off" relay. To detect a new alarm condition, the signal must go below the set point, and then go above it.

Low Alarm Operation (Set < Reset)

For Manual reset mode, ACK can be pressed anytime to turn "off" relay. For relay to turn back “on”, signal must go above set point and then go below it.

High Alarm with Fail-Safe Operation (Set > Reset)

Note: Relay coil is energized in non-alarm condi-

tion. In case of power failure, relay will go to alarm state.

Low Alarm with Fail-Safe Operation (Set < Reset)

Note: Relay coil is energized in non-alarm condi-

tion. In case of power failure, relay will go to alarm state.

Relay and Alarm Operation Diagrams

The following graphs illustrate the operation of the relays, status LEDs, and ACK button.

PROVU PD7000 Temperature Meter Instruction Manual

Set

Reset

Relay

LED

Input

Sample

Time

Sample

Time

Sample

Time

Pump Alternation Control Operation

Relay Sampling Operation

When the signal crosses the set point, the relay trips and the sample time starts. After the sample time has elapsed, the relay resets. The cycle repeats every time the set point is crossed, going up for high alarms and going down for low alarms.

The sample time can be programmed between 0.1 and 5999.9 seconds.

PROVU PD7000 Temperature Meter Instruction Manual

Relay

LED

Input

Input Break = Ignore

de-energized energized

off on

Relay

LED

Input Break = Off

Relay

LED

Input Break = On

Set

Reset

INPUT

BREAK

INPUT

BREAK

Signal Loss or Input Break Relay Operation

The following graph shows the input break relay operation for a high alarm relay.

When the meter detects a break in the input, the relay will go to one of the following selected actions:

1. Turn On (Go to alarm condition)

2. Turn Off (Go to non-alarm condition)

3. Ignore (Processed as an upscale condition)

Time Delay Operation

The following graphs show the operation of the time delay function.

When the signal crosses the set point, the On time delay timer starts and the relay trips when the time delay has elapsed. If the signal drops below the set point (high alarm) before the time delay has elapsed, the On time delay timer resets and the relay does not change state. The same principle applies to the Off time delay.

Note: If “Automatic or Manual (

the relay state when the relay is acknowledged.

A-nmAn

)” reset mode is selected, the LED follows the reset point and not

PROVU PD7000 Temperature Meter Instruction Manual

Alarm #

HI or LO

Alarm

Set

Point

Reset

Point

Power-Up

Reading

Relay

& LED

1000

500

499

Off 2 LO

700

900

499

On 3 LO

250

400

499

Off 4 HI

450

200

499

Fail-Safe Selection

Non-Alarm State

Alarm State

Power Failure

Off

Open

Closed

Open

Relays go to non-alarm state

Closed

Open

Closed

Relays go to alarm state

LED

Status

LED

Status

Alarm 1

5 Alarm 5

Alarm 2

6 Alarm 6

Alarm 3

7 Alarm 7

Alarm 4

8 Alarm 8

Relay Operation Details

Overview

The relay capabilities of the meter expand its usefulness beyond simple indication to provide users with alarm and control functions. These capabilities include front panel alarm status LEDs as well as either 2 or 4 optional internal relays and/or 4 external relays expansion module. Typical applications include high or low temperature alarms, control applications such as simple on/off temperature control. There are four basic ways the relays can be used:

1. High or Low Alarms with Latching or Non-Latching Relays

2. Simple On/Off Control with 100% Adjustable Deadband

3. Sampling (Based on Time)

4. Relay Alternation Control

Relays Auto Initialization

When power is applied to the meter, the front panel LEDs and alarm relays will reflect the state of the input to the meter. The following table indicates how the alarm LEDs and relays will react on power-up based on the set and reset points:

Fail-Safe Operation

The following table indicates how the relays behave based on the fail-safe selection for each relay:

Note: NO = Normally Open,

NC = Normally Closed. This refers to the condition of the relay contacts when the power to the meter is off.

Front Panel LEDs

The LEDs on the front panel provide status indication for the following:

The meter is supplied with four alarm points that include front panel LEDs to indicate alarm conditions. This standard feature is particularly useful for alarm applications that require visualonly indication. The LEDs are controlled by the set and reset points programmed by the user. When the display reaches a set point for a high or low alarm, the corresponding alarm LED will turn on. When the display returns to the reset point the LED will go off. The front panel LEDs respond differently for latching and non-latching relays.

For non-latching relays, the LED is always off during normal condition and always on during alarm condition, regardless of the state of the relay (e.g. Relay acknowledged after alarm condition).

For latching relays, the alarm LEDs reflect the status of the relays, regardless of the alarm condition. The following tables illustrate how the alarm LEDs function in relation to the relays and the acknowledge button (Default: F3 key assigned to ACK).

PROVU PD7000 Temperature Meter Instruction Manual

Warning!

In latching relay mode, latched relays will reset (unlatch) when power is cycled.

Relay terminology for following tables

Terminology

Relay Condition

Alarm (Tripped)

Off

Normal (Reset)

Ack

Acknowledged

Automatic reset only

Condition

LED

Relay

Normal

Off

Alarm

Ack (No effect)

Normal

Off

Automatic + manual reset at any time

Condition

LED

Relay

Normal

Off

Alarm

Normal

Off

Next Alarm

Ack

Off

Normal

Off

Manual reset any time

Condition

LED

Relay

Normal

Off

Alarm

Ack

Off

Manual reset only after alarm

condition has cleared

Condition

LED

Relay

Normal

Off

Alarm

Ack (No effect)

Normal

Ack

Off

Latching and Non-Latching Relay Operation

The relays can be set up for latching (manual reset) or non-latching (automatic reset) operation.

The On and Off terminology does not refer to the status of the relay’s coil, which depends on the fail-safe mode selected.

Non-Latching Relay (Auto)

In this application, the meter is set up for automatic reset (non-latching relay). Acknowledging the alarm while it is still present has no effect on either the LED or the relay. When the alarm finally goes away, the relay automatically resets and the LED also goes off.

Non-Latching Relay (A-nman)

In this application, the meter is set up for automatic and manual reset at any time (non-latching relay). The LED and the relay automatically reset when the meter returns to the normal condition. The next time an alarm occurs, the operator acknowledges the alarm manually while the alarm condition still exists. This causes the relay to reset, but the LED stays on until the meter returns to the normal condition.

Latching Relay (LatcH)

In this application, the meter is set up for manual reset at any time. Acknowledging the alarm even if the alarm condition is still present resets the relay and turns off the LED.

Latching Relay (Lt-Clr)

In this application, the meter is set up for manual reset only after the signal passes the reset point (alarm condition has cleared). Acknowledging the alarm while it is still present has no effect on either the LED or the relay. When the alarm is acknowledged after it returns to the normal state, the LED and the relay go off. Notice that the LED remains on, even after the meter returns to the normal condition. This is because, for latching relays, the alarm LED reflects the status of the relay, regardless of the alarm condition.

PROVU PD7000 Temperature Meter Instruction Manual

+5 I1 I2 I3 I4 O1 O2 O3 O4 G

DO 1-4

GND

ACK

PDA1044 Digital I/O Module

1 2 3 4 5 6 7 8 9 10

DI 1-4

1 2 3 4 5 6

+5 I1 I2 I3 I4 O1

7 8

O2 O3

9 10

O4 G

DI 1-4 DO 1-4

5 VDC GND

SW2

SW1

Acknowledging Relays

There are two ways to acknowledge relays programmed for manual reset:

1. Via the programmable front panel function keys F1-F3 (Default: F3 assigned to ACK).

2. Remotely via a normally open pushbutton wired across one of the digital inputs and the +5 V terminals on the digital I/O modules, or using the F4 digital input, which is triggered with a contact closure to COM, or with an active low signal (see page 14).

When the ACK button or the assigned digital input is closed, all relays programmed for manual reset are acknowledged.

Figure 21. Acknowledge Relays w/Function Key or Digital Input

Setting Up the Interlock Relay (Force On) Feature

Relays 1-4 can be set up as interlock relays. To set up the relays for the interlock feature:

1. Access the Setup – Relay – Action menu and set the action to off.

2. In the Advanced features – User menu program any of the digital inputs to Force On any of the internal relays (1-4).

3. Connect a switch or dry contact between the +5V terminal and the corresponding digital input (dI-1 to dI-4) terminal.

Interlock Relay Operation

Relays 1 & 2 are energized when SW1 & SW2 switches are closed and the front panel LEDs are off. If

the contact to the digital input is opened, the corresponding front panel LED flashes indicating this condition. The processes being controlled by the interlock relay stop and will re-start only after the interlock relay is activated by the digital inputs.

PROVU PD7000 Temperature Meter Instruction Manual

For instructions on how to program numeric

values see Setting Numeric Values, page 21.

Scaling the 4-20 mA Analog Output (Aout)

The 4-20 mA analog output can be scaled to provide a 4-20 mA signal for any display range selected. No equipment is needed to scale the analog output; simply program the display values to the

corresponding mA output signal. The Analog Output menu is used to program the 4-20 mA output based on display values.

Note: During the analog output scaling, the display value is always indicated with a decimal point

regardless of the decimal point selection for the temperature display.

Reset Menu (reset)

The Reset menu is used to reset the maximum or minimum reading (peak or valley) reached by the process; both may be reset at the same time by selecting “reset high & low” (rst HL).

Control Menu (Contrl)

The Control menu is used to control the 4-20 mA analog output and the relays manually, ignoring the input. Each relay and analog output can be programmed independently for manual control. Selecting automatic control sets all relays and analog output for automatic operation.

PROVU PD7000 Temperature Meter Instruction Manual

Did you forget the password?

The password may be disabled by entering a master password once. If you are authorized to make changes, enter the master password 508655 to unlock the meter.

Setting Up the Password (pass)

The Password menu is used for programming three levels of security to prevent unauthorized changes to the programmed parameter settings.

Protecting or Locking the Meter

Enter the Password menu and program a six-digit password. For instructions on how to program numeric values see Setting Numeric Values, page 21.

Making Changes to a Password Protected Meter

If the meter is password protected, the meter will display the message Locd (Locked) when the Menu button is pressed. Press the Enter button while the message is being displayed and enter the correct password to gain access to the menu.

Note: After exiting the programming mode, the meter returns to its password protected condition.

Disabling Password Protection

To disable the password protection, access the Password menu and enter the correct password twice, as shown below. The meter is now unprotected until a new password is entered.

If the correct six-digit password is entered, the meter displays the message unLoc (unlocked) and the protection is disabled until a new password is programmed.

If the password entered is incorrect, the meter displays the message Locd (Locked) for about two seconds, and then it returns to Run Mode. To try again, press Enter while the Locked message is displayed.

PROVU PD7000 Temperature Meter Instruction Manual

Display

Parameter

Action/Setting

Adjust

Set adjust value to offset temperature reading

T cal

T Cal

Enter temperature calibration menu

T lo

T Low

Apply the low temperature input (e.g. 32°F)

T Hi

T High

Apply the high temperature input (e.g. 1000°F)

rtdtot

RTD Total

Set the number of RTDs connected in parallel to obtain average temperature

filtEr

Filter

Set noise filter value

Display

Parameter

Action/Setting

bypASs

Bypass

Set filter bypass value

Round

Set the rounding value for display variables

seriAl

Serial

Set serial communication parameters

SlaveId

Slave ID

Set slave ID or meter address

baud

Baud rate

Select baud rate

Tr dLY

Transmit delay

Set transmit delay for serial communication

Parity

Select parity Even, Odd, or None with 1 or 2 stop bits

Advanced Features Menu

To simplify the setup process, functions not needed for most applications are located in the Advanced Features menu.

Press and hold the Menu button for three seconds to access the advanced features of the meter.

Advanced Features Menu & Display Messages

The following table shows the functions and messages of the Advanced Features menu in the order they appear in the menu.

PROVU PD7000 Temperature Meter Instruction Manual

Display

Parameter

Action/Setting

t-byt

Time byte

Set byte-to-byte timeout

SelEct

Select

Enter the Select menu

AoutPr

Analog output programmin g

Program analog output parameters

Source

Select source for the 4-20 mA output

O-rang

Overrange

Program mA output for display overrange

u-rang

Underrange

Program mA output for display underrange

Break

Loop Break

Set relay condition if loop break detected

mAx

Maximum

Program maximum mA output allowed

min

Minimum

Program minimum mA output allowed

Calib

Calibrate

Calibrate 4-20 mA output (internal reference source used for scaling the output)

4 mA

4 mA output

Enter mA output value read by milliamp meter with at least 0.001 mA resolution

20 mA

20 mA output

Enter mA output value read by milliamp meter with at least 0.001 mA resolution

user

User I/O

Assign function keys and digital I/O

Display

Parameter

Action/Setting

F1 function key

Assign F1 function key

F2 function key

Assign F2 function key

F3 function key

Assign F3 function key

F4 function

Assign F4 function (digital input)

dI I

Digital input 1

Assign digital input 18, if expansion modules are connected

dO 1

Digital output 1

Assign digital output 1- 8, if expansion modules are connected

ICal

Internal temp calibration

Enter internal temperature calibration (used for factory calibration only)

mref

Measured temp reference

Enter the measured reference temperature in degrees Celsius (e.g.

25.0)

0nmv

0 mV

Apply 0.000 mV input Internal Calibration

100nmv

100 mV

Apply 100.000 mV input

Diag

Diagnostics

Display parameter settings

LED t

LED test

Test all LEDs

Info

Information

Display software and S/N information

Erase

Erase MeterView Pro software stored in meter’s memory

Offset Adjust (Adjust)

This parameter allows the user to select an offset adjustment to the temperature being displayed. Offset adjustment values can be either positive or negative and can be any number within 50.0F (+27.8C). The offset adjustment value is programmed through the Adjust menu.

The offset adjustment feature can be useful to compensate for errors due to thermocouple junctions or excessive lead wire resistance in RTDs.

Note: The offset adjustment value is not reset to zero when the type of temperature sensor is changed

(i.e. TC type or RTD curve). Celsius/Fahrenheit conversion must be made manually by the user.

PROVU PD7000 Temperature Meter Instruction Manual

• The meter is factory calibrated prior to shipment to read temperature in degrees Fahrenheit. The calibration equipment is certified to NIST standards.

• There is no need to calibrate the meter, simply select the input type, °F or °C, and decimal point.

• Check calibration of the meter at least every 12 months.

Type of input

Input 1 (Low)

Input 2 (High)

Check (Middle)

Type J

32F

1184F

600F

Type K

32F

1895F

960F

Type T

32F

698F

360F

Type E

32F

1652F

800F

Type R

32F

3110F

1500F

Type S

32F

3110F

1500F

Type B

32F

3110F

1500F

Type N

32F

1472F

700F

Type C

500F

3650F

1800F

10  Cu RTD

32F

9.035

450F

18.032

200F

12.639

100  Pt RTD (0.00385)

32F

100

1148F

320.12

590F

215.61

100  Pt RTD (0.00392)

32F

100

1148F

324.49

590F

217.89

120  Ni RTD

32F

120

410F

315.31

221F

205.22

1000  Pt RTD (0.00385)

32F

1000

900F

2750.4

450F

1876.5

1000  Pt RTD (0.00392)

32F

1000

900F

2785.1

450F

1893.7

Recalibration of the Meter (t CAL)

The Calibration (t CAL) menu is used to recalibrate the thermocouple and RTD inputs.

Allow at least 30 minutes warm-up time before performing recalibration procedure to ensure specified accuracy.

Recommended Calibration Points

To recalibrate the meter, it is recommended to use the Fahrenheit scale; this will give a greater degree of accuracy to the calibration. The scale can be changed to the Celsius scale after calibration is completed. The meter will display temperature accurately in any scale. The following table shows the recommended low and high calibration points for all types.

Recalibration Procedure

1. Connect signal to the meter using the appropriate wire (e.g. type J thermocouple wire to recalibrate type J input), see page 12.

2. Set up the meter to accept the selected input (e.g. type J T/C), see page 23.

3. Set up the meter to display temperature in degrees Fahrenheit.

4. Apply signal corresponding to input 1 (32°F) and program the display to read 32.0.

5. Apply signal corresponding to input 2 (1184°F for type J) and program the display accordingly.

6. After the meter accepts input 2, the display returns to reading mode. This completes the recalibration procedure for the selected input.

PROVU PD7000 Temperature Meter Instruction Manual

Warning!

Do not connect any equipment other than Precision Digital’s expansion modules, cables, or meters to the RJ45 M-LINK connector. Otherwise damage will occur to the equipment and the meter.

Noise Filter (filter)

The noise filter is available for unusually noisy signals that cause an unstable process variable display. The noise filter averages the input signal over a certain period. The filter level determines the length of time over which the signal is averaged. The filter level can be set between 2 and 199. The higher the filter level, the longer the averaging time and so the longer it takes the display to settle to its final value. Setting the filter level to zero disables the filter function.

Noise Filter Bypass (bypass)

The noise filter bypass changes the behavior of the meter so that small variations in the signal are filtered out but large abrupt changes in the input signal are displayed immediately. The bypass value determines the minimum amount of signal change to be displayed immediately. All signal changes smaller than the bypass value are filtered or averaged by the meter. The noise filter bypass may be set between 0.1 and

99.9% of full scale.

Rounding Feature (round)

The rounding feature is used to give the user a steadier display with fluctuating signals. Rounding is used in addition to the filter function.

Rounding causes the display to round to the nearest value according to the rounding selected. This setting affects the last two digits, regardless of decimal point position. On this ProVu model, the valid settings are 1, 2, 5, and 10 (only).

Modbus RTU Serial Communications (serial)

The meter is equipped with serial communications capability as a standard feature using the Modbus RTU Serial Communication Protocol.

The meter may be connected to a PC for initial configuration via the onboard micro USB connection. For ongoing digital communications with a computer or other data terminal equipment, an RS-232, or RS-485 option is required; see Ordering Information on page 5 for details.

Note: More detailed instructions are provided with each optional serial communications adapter.

Note: Refer to the ProVu® Modbus Register Tables located at www.predig.com for details.

When using more than one meter in a multi-drop mode, each meter must be have its own unique Slave ID or meter address. The ID or address may be programmed between 1 and 247. The transmit delay may be set between 0 and 199 ms. The parity can be set to even, odd, or none with 1 or 2 stop bits.

PROVU PD7000 Temperature Meter Instruction Manual

Select Menu (SElect)

The Select menu is used to program the analog output parameters. There are no other selections for this model.

Analog Output Programming (AoutPr)

The Analog Output Programming menu is used to program the behavior of the 4-20 mA output. The following parameters and functions are programmed in this menu:

1. Source: Source for generating the 4-20 mA output (e.g. PV - temperature)

2. Overrange: Analog output value with display in overrange condition

3. Underrange: Analog output value with display in underrange condition

4. Break: Analog output value when input break is detected

5. Max: Maximum analog output value allowed regardless of input

6. Min: Minimum analog output value allowed regardless of input

7. Calibrate: Calibrate the internal 4-20 mA source reference used to scale the 4-20 mA output

Analog Output Source

The source for generating the 4-20 mA output may be assigned to the process variable, maximum or minimum value reached by the process, one of the set points, or the Modbus PV input.

Analog Output Calibration

To perform the analog output calibration, it is recommended to use a milliamp meter with a resolution of at least 0.1 µA to measure the output current. The values saved internally during this procedure are used for scaling the 4-20 mA output in the Setup menu.

PROVU PD7000 Temperature Meter Instruction Manual

Display

Description

Rst Hi

Reset the stored maximum display value

Rst Lo

Reset the stored minimum display value

Rst HL

Reset the stored maximum & minimum display values

tare

Capture tare and zero the display

Rst tr

Reset captured tare and resume normal operation

relay

Directly access the relay menu

Set 1*

Directly access the set point menu for relay 1 (*through 8)

Rly d

Disable all relays until a button assigned to enable relays (Rly E) is pressed

Rly E

Enable all relays to function as they have been programmed

O Hold

Hold current relay states as they are until a button assigned to ena-

ble relays (Rly E) is pressed

d Hold

Hold the current display value momentarily while the function key or digital input is active. The process value will continue to be calculated in the background.

Ln1 Hi

Display maximum display value on line 1

Ln1 Lo

Display minimum display value on line 1

Ln1 HL

Display maximum & minimum display values on line 1

Display

Description

Ln2 Hi

Display maximum display value on line 2

Ln2 Lo

Display minimum display value on line 2

Ln2 HL

Display maximum & minimum display values on line 2

F On 1*

Force relay 1 (*through 4) into the on state. This function is used in conjunction with a digital input expansion module to achieve interlock functionality. See page 31 for details about interlock relays.

Contrl

Directly access the control menu

disabl

Disable the selected function key or digital I/O

AcH

Acknowledge all active relays that are in a manual operation mode such as auto-manual or latching

Reset

Directly access the reset menu

nmenu

Mimic the menu button functionality (digital inputs only)

rigHt

Mimic the right arrow/F1 button functionality (digital inputs only)

Mimic the up arrow/F2 button functionality (digital inputs only)

Enter

Mimic the enter/F3 button functionality (digital inputs only)

Alnm 1*

Provide indication when alarm 1 (*through 8) has been triggered (digital outputs only)

*If installed

Programmable Function Keys User Menu (user)

The User menu allows the user to assign the front panel function keys F1, F2, and F3, the digital input F4 (a digital input located on the signal input connector), and up to eight additional digital inputs to access most of the menus or to activate certain functions immediately (e.g. reset max & min, hold relay states, etc.). This allows the meter to be greatly customized for use in specialized applications.

Up to eight digital outputs can be assigned to a number of actions and functions executed by the meter (i.e. alarms, relay acknowledgement, reset max, min, or max & min, tare, and reset tare). The digital outputs can be used to trigger external alarms or lights to indicate these specific events.

Function Keys & Digital I/O Available Settings

Refer to the following table for descriptions of each available function key or digital I/O setting.

PROVU PD7000 Temperature Meter Instruction Manual

The meter is factory calibrated prior to shipment to read temperature in degrees Fahrenheit. The calibration equipment is certified to NIST standards.

Notes:

1. If meter is in operation and it is intended to accept only one input type (e.g. 100 Pt), recalibration of other inputs is not necessary.

2. Allow the meter to warm up for at least 30 minutes before performing the calibration procedure.

3. Use the Recalibration of the Meter (t CAL) procedure found on page 36.

Internal Temperature Calibration (ICAL)

The Internal Calibration (ICAL) is a function used at the factory to calibrate all the thermocouple and RTD ranges. This procedure should only be used by qualified personnel.

To recalibrate the meter for a specific input and range, refer to page 36 Recalibration of the Meter (t CAL).

The Internal calibration menu is part of the Advanced Features menu and is described in the following pages. This procedure should only be used by qualified personnel.

Note: Most users should not require the use of the Internal Calibration procedure. The T CAL procedure

should be used instead of the ICAL procedure.

Thermocouple Input Internal Calibration (ICAL)

1. Set the Type selector switch in the TC position and using copper wire connect a precision mV calibrator to the input.

2. In the Setup menu select the input: TC – Type J.

3. Press and hold the Menu button for three seconds to access the advanced features of the meter.

4. Press the Up arrow button to scroll to the Internal calibration menu (ICAL) and press Enter.

5. The meter displays either current calibration (mref). Press Enter to start the calibration process.

6. Measure the room temperature in degrees Celsius using a reliable reference, enter the room temperature (e.g. 25.0), and press Enter.

7. The meter displays 0mv, apply an input equal to 0.000 mV and press Enter. The display flashes while accepting the 0 mV input; press Enter again when the display stops flashing.

8. The meter displays 100mv, apply an input equal to 100.000 mV and press Enter. The display flashes while accepting the 100 mV input; press Enter again when the display stops flashing.

9. Apply 0 mV, the meter should read room temperature.

10. This completes the calibration of all the thermocouple ranges.

PROVU PD7000 Temperature Meter Instruction Manual

RTD Input Internal Calibration (ICAL)

1. Set the Type selector switch in the RTD position and the Range switch in the 10 position. Using 3 wires connect a precision calibrator resistance output to the meter.

2. In the Setup menu select the input: RTD – 100 Pt – A385.

3. Access the Advanced Features menu and scroll to the ICAL menu and press Enter.

4. The meter displays the message (10 lo). Apply 9.035 ohm and press Enter. The display flashes for a moment while the meter is accepting the low input signal for the 10-ohm RTD. After the display stops flashing, press Enter again.

5. The meter displays the message (10 Hi). Apply 18.032 ohm and press Enter. The display flashes for a moment while the meter is accepting the high input signal for the 10-ohm RTD. After the display stops flashing, press Enter again.

6. The meter displays the message (100 lo). Do NOT press Enter.

7. Move the Range selector switch to the 100 position. Apply 100 ohm and press Enter. The display flashes for a moment while the meter is accepting the low input signal for the 100-ohm RTD.

8. The meter displays the message (100 Hi). Apply 320.12 ohm and press Enter. The display flashes for a moment while the meter is accepting the high input signal for the 100-ohm RTD.

9. At the end of the calibration process the meter should read 1148.0F with the 320.12-ohm input applied.

10. This completes the calibration of all the RTD ranges.

PROVU PD7000 Temperature Meter Instruction Manual

Button Symbol

Description

Press to enter or exit Programming Mode, view settings, or exit max/min readings

Press to reset max readings or other parameter/function assigned through the User menu

Press to display max/min readings or other parameter/function assigned through the User menu

Press to acknowledge relays or other parameters/function assigned through the User menu

Meter Operation

The meter is capable of accepting a variety of thermocouples and RTDs. The dual-line display can be customized by the user to operate in such a way as to satisfy a specific

application. Typically, display line 1 is used for the process variable; while line 2 is used engineering units, custom legend, or set point indication.

Additionally, the meter can be set up to display the thermocouple or RTD input on line 1 and the Modbus input on line 2. The relays and analog output can be programmed to operate from the Modbus PV input.

Front Panel Buttons Operation

Function Keys Operation

During operation, the programmable function keys operate according to the way they have been programmed in the Advanced Features – User menu.

The table above shows the factory default settings for F1, F2, and F3.

F4 Operation

A digital input, F4, is standard on the meter. This digital input is programmed identically to function keys F1, F2, and F3. The input is triggered with a contact closure to COM, or with an active low signal. During operation, F4 operates according to the way it has been programmed in the Advanced Features – User menu.

PROVU PD7000 Temperature Meter Instruction Manual

Maximum/Minimum Readings

The max & min readings (peak & valley) reached by the process can be displayed either continuously or momentary:

1. Display briefly by assigning to the F1-F3 function keys or to the digital inputs in the User menu.

2. Display continuously by assigning either display to max/min through the Display menu.

Any of the F1-F3 function keys (buttons) and the digital inputs can be programmed to reset the max & min readings. The meters are set at the factory to display the max reading by pressing the Up arrow/F2 button and to use the Right arrow/F1 button to access the Reset menu.

To display max reading using function key with factory defaults:

1. Press Up arrow/F2 button to display maximum reading since the last reset/power-up.

2. To reset max/min press Right arrow/F1 button to access the Reset menu. The max & min displays are reset to actual values.

3. Press Menu to exit max/min display reading.

To display max/min readings continuously:

Assign either display to Max (d Hi), Min (d Lo), or toggle between Max and Min (d HL) every 10 seconds.

PROVU PD7000 Temperature Meter Instruction Manual

Troubleshooting

The rugged design and the user-friendly interface of the meter should make it unusual for the installer or operator to refer to this section of the manual. However, due to the many features and functions of the meter, it’s possible that the setup of the meter does not agree with what an operator expects to see.

If the meter is not working as expected, refer to the Diagnostics menu and recommendations below.

Diagnostics Menu (diag)

The Diagnostics menu is located in the Advanced Features menu, to access Diagnostics menu see Advanced Features Menu, page 34.

This menu allows the user to test the functionality of all the meter LEDs, check the meter’s software and version information, and erase the MeterView Pro software installation files from the meter. Press the Enter button to view the settings and the Menu button to exit at any time.

For a description of the diagnostic messages, see Advanced Features Menu & Display Messages, page

34.

Determining Software Version

To determine the software version of a meter:

1. Go to the Diagnostics menu (diAG) and press Enter button.

2. Press Up arrow button and scroll to Information menu (Info).

3. Press Enter to access the software number (SFT) and version (UER) information. Write down the

information as it is displayed. Continue pressing Enter until all the information is displayed.

4. The meter returns to Run Mode after displaying all the settings.

Reset Meter to Factory Defaults

When the parameters have been changed in a way that is difficult to determine what’s happening, it might be better to start the setup process from the factory defaults.

Instructions to load factory defaults:

1. Enter the Advanced Features menu. See Advanced Features Menu, page 34.

2. Press Up arrow to go to Diagnostics menu

3. Press and hold Right arrow for three seconds, press Enter when display flashes reset. Note: If Enter is not pressed within three seconds, the display returns to the Diagnostics menu.

4. The meter goes through an initialization sequence (similar as on power-up), and loads the factory default settings.

PROVU PD7000 Temperature Meter Instruction Manual

Parameter

Display

Default Setting

Input type

Input

Type J TC

Temp scale

F or C

°F

Adjust

0.0

RTD total

rtdtot

Filter

filter

Bypass

bypass

0.2

Round

Decimal point

ddddoF

No decimal

Display line 1

Line 1

PV: Temperature

Display line 2

Line 2

Eng units: Temp

Display intensity

d-Inty

Relay 1 action

Act 1

Automatic

Relay 1 set point

Set 1

100

Relay 1 reset point

RSt 1

Relay 2 action

Act 2

Automatic

Relay 2 set point

Set 2

200

Relay 2 reset point

RSt 2

150

Relay 3 action

Act 3

Automatic

Relay 3 set point

Set 3

300

Relay 3 reset point

RSt 3

250

Relay 4 action

Act 4

Automatic

Relay 4 set point

Set 4

400

Relay 4 reset point

RSt 4

350

Fail-safe relay 1

Fls 1

Off

Fail-safe relay 2

Fls 2

Off

Fail-safe relay 3

Fls 3

Off

Fail-safe relay 4

Fls 4

Off

On delay relay 1

On 1

0.0 sec

Off delay relay 1

Off 1

0.0 sec

On delay relay 2

On 2

0.0 sec

Off delay relay 2

Off 2

0.0 sec

On delay relay 3

On 3

0.0 sec

Off delay relay 3

Off 3

0.0 sec

On delay relay 4

On 4

0.0 sec

Off delay relay 4

Off 4

0.0 sec

Input break relay 1

ignore

Ignore

Parameter

Display

Default Setting

Input break relay 2

ignore

Ignore

Input break relay 3

ignore

Ignore

Input break relay 4

ignore

Ignore

Display 1 analog out

Dis 1

0.0 Output 1 value

Out 1

4.000 mA

Display 2 analog out

Dis 2

2000.0 Output 2 value

Out 2

20.000 mA

Source analog output

Source

Process Variable Overrange output

O-rang

21.000 mA

Underrange output

u-rang

3.000 mA

Input break output

break

1.000 mA

Maximum output

mAx

23.000 mA

Minimum output

min

1.000 mA

Slave ID

SlavId

247

Baud rate

baud

9600

Transmit delay

Tr dly

10 ms

Parity

Even

Byte-to-byte timeout

t-byt

010 (0.1 sec) F1 function key

Reset max & min

F2 function key

Line 1: Max (Hi)

F3 function key

Acknowledge relays

F4 function

Acknowledge relays

Digital input 1

dI 1

Digital input 2

dI 2

Right arrow

Digital input 3

dI 3

Up arrow

Digital input 4

dI 4

Enter

Digital output 1

dO 1

Alarm 1

Digital output 2

dO 2

Alarm 2

Digital output 3

dO 3

Alarm 3

Digital output 4

dO 4

Alarm 4

Password 1

Pass 1

000000 (unlocked)

Password 2

Pass 2

000000 (unlocked)

Password 3

Pass 3

000000 (unlocked)

Factory Defaults & User Settings

The following table shows the factory setting for most of the programmable parameters on the meter.

PROVU PD7000 Temperature Meter Instruction Manual

Symptom

Check/Action

No display at all

Check power at power connector

Not able to change setup or programming, Locd is displayed

Meter is password-protected, enter correct six-digit password to unlock

Meter displays error message during calibration (Error)

Check:

1. Signal connections

2. Type and range selector switches

3. Input selected in Setup menu

Meter displays

1. 99999

2. -9999

Check:

1. Input selected in Setup menu

2. Corresponding signal at Signal connector

Display is unstable

Check:

1. Input signal stability and value

2. Filter and bypass values (increase)

Display response is too slow

Check filter and bypass values

Display reading is not accurate

Check:

1. TC wire type

2. Input selection in Setup menu

Display does not respond to input changes, reading a fixed number

Check:

1. Display assignment, it might be displaying max, min, or set point.

Display alternates between

1. Hi and a number

2. Lo and a number

Press Menu to exit max/min display readings.

Relay operation is reversed

Check:

1. Fail-safe in Setup menu

2. Wiring of relay contacts

Relay and status LED do not respond to signal

Check:

1. Relay action in Setup menu

2. Set and reset points

Flashing relay status LEDs

Relays in manual control mode or relay interlock switches opened.

Meter not communicating with application programs

Check:

1. Serial adapter and cable

2. Serial settings

3. Meter address and baud rate

If the display locks up or the meter does not respond at all

Cycle the power to reboot the microprocessor.

Other symptoms not described above

Call Technical Support for assistance.

Troubleshooting Tips

Note: Certain sequences of events can cause unexpected results. To solve these issues, it is best to start fresh from factory defaults and map changes ahead of time, rather than at random.

EU Declaration of Conformity

Issued in accordance with ISO/IEC 17050-1:2004.

We,

Precision Digital Corporation 233 South Street Hopkinton, MA 01748 USA

as the manufacturer, declare under our sole responsibility that the product(s),

Model PD7000 Series Temperature Panel Meter

to which this declaration relates, is in conformity with the European Union Directives shown below:

2014/35/EU Low Voltage Directive 2014/30/EU EMC Directive 2011/65/EU RoHS Directive

This conformity is based on compliance with the application of harmonized or applicable technical standards and, when applicable or required, a European Union notified body certification.

Standards:

EN 55022:2003 EN 61000-6-2:2001 EN 61010-1:2001 EN 61326:2006

The standards EN 55022:2003, EN 61000-6-2:2001, EN 61010-1:2001, and EN 61326:2006 are no longer harmonized. The requirements of these standards have been checked against the harmonized standards EN 55022:2010, EN 61000-6-2:2005, EN 61010-1:2010, and EN 61326:2013 and there were no major technical changes affecting the latest technical knowledge for the products listed above.

Product Markings:

Signed for and on behalf of Precision Digital Corporation:

Name: Jeffrey Peters Company: Precision Digital Corporation Title: President Date: 04/20/2016 Document No: DoC PD7000 {042016}

PROVU PD7000 Temperature Meter Instruction Manual

How to Contact Precision Digital

• For Technical Support, please

Call: (800) 610-5239 or (508) 655-7300

Fax: (508) 655-8990

Email: support@predig.com

• For Sales Support or to place an order, please contact your local distributor or

Call: (800) 343-1001 or (508) 655-7300

Fax: (508) 655-8990

Email: sales@predig.com

• For the latest version of this manual, please visit

www.predig.com

PRECISION DIGITAL CORPORATION

233 South Street • Hopkinton MA 01748 USA Tel (800) 343-1001 • Fax (508) 655-8990

www.predig.com

SFT063 Ver 4.000 & up

LIM7000_H

03/17

Precision Digital Corporation PROVU PD7000 Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
