Precision ANALOGUE CALENDAR SERIES User Manual

ANALOGUE CALENDAR SERIES

CONTENTS

1 :

2 - 17 :

18 - 19 :

INTRODUCTION

PERPETUAL ANALOGUE CALENDAR
WATCH INSTRUCTIONS

PRECISION GUARANTEE AND WARRANTY

01

INTRODUCTION

Congratulations on the purchase of your Precision Solar
Powered Radio Controlled Watch.

Be sure to read this instruction manual before using the watch

for the rst time. After reading the manual please keep it in a safe
place for future reference.

Your Precision watch is a world band (multi frequency) watch.
It incorporates a highly sensitive radio receiver that receives time
signals from the UK, Europe, US and Japan according to the time
zone setting on the watch. Your Precision watch even adjusts
automatically for daylight saving time.

Automatic Time Setting

Your Precision watch receives the available atomic clock sig-
nal automatically at 3:00am every night according to the time
zone setting (go to time zone setting for details).

Everything is done automatically.

OPERATION DIAGRAM

S1

S3

S2

A B C

02

PERPETUAL ANALOGUE CALENDAR WATCH
INSTRUCTIONS

MAIN FEATURES

• Solar Powered

• Automatic Radio Controlled time setting for UK (MSF), USA (WWVB),

Germany (DCF) and Japan (JJY 60Khz only)

• Perpetual analogue calender

• Day of the week indication by second hand

• Time zone setting

• Reception indicator

• 3 level battery indication

• Watch hand reset

• Rechargeable 20 year (approximate) Battery

• Estimated 12 month battery life from one full charge

• 50m water resistant

• All stainless steel

03

QUICK SET UP GUIDE

Step 1:
Check the Second Hand Position

Make sure the second hand position is correct before use.
During transit the second hand may move or lose time. Press S3 (bottom button) once to check if the
second hand stops at either the 6 or 12 O’clock position (half second deviation is acceptable). If the
second hand does not stop at 6 or 12 O’clock position, please refer to, “Time and Calendar Synchroni­zation” which can be found in the “Troubleshooting” section of this manual.

Step 2:
Check Time Zone

Once the second hand is moving again press and hold S3 (bottom button) for 3 seconds. The second
hand will move and pause at 12 O’clock for 2 seconds and will then spin to its preset time zone. The
Time Zone is represented by the position of the second hand as per the below table.

UK Time Zone

Second hand points at 12 o’clock

Germany Time Zone

Second hand points at 1 o’clock

Japan Time Zone

Second hand points at 4 o’clock

USA Time Zone

Second hand points at 7 o’clock
(Preset to Pacic)

Wait until the second hand starts to move
again before proceeding (may take up to 60
seconds).

04

Time Zone Settings (USA USERS ONLY)

If you nd your preset USA time zone is dierent from your local US time zone, follow the below steps:

Time Zone

Eastern

Central
Mountain
Pacic

Seconds Hand Position

11 o’clock
10 o’clock
8 o’clock

7 o’clock

• Make sure the watch is running normally

• Pull button S2 to the C position.

• Press and hold S3 (bottom button) for 3 seconds. The second hand will move and pause at 12

o’clock for 2 seconds and will then spin to its preset time zone.

• Next, keep pressing S1 (upper button) to move the second hand to point at the Time Zone you want.
(If your watch has been set to the right Time Zone when you check it, leave the watch for around one
minute until the second hand starts moving regularly.

• Press S3 (bottom button) once to conrm the new USA time zone setting.

• Return S2 to the A position.

Remarks:

1. This procedure is used to set USA P/M/C/E only when the time zone of the watch is within the 4
American time zones; Eastern, Central, Mountain and Pacic (7, 8, 9 and 11 o’clock). The watch
cannot be set to another time zone using this USA time zone setting. If you want to change the watch
to the time zone of another country then you need to follow the “Change Time Zone” procedure.

2. If your watch is not within a USA time zone, holding S3 will show the current time zone but no time
zone setting will be allowed.

3. Your watch hands will spin to set the time according to your new time zone setting if it is an advance
hour setting, for instance, were you set your watch from Pacic to Mountain, it may take up to 30
minutes for the watch to be set.

4. If the time zone you require is an anti-clockwise setting from Mountain to Pacic, then the watch will
stop until the new time zone is matched. Please leave the watch until it resumes running again, it

may take up to 4 hours.

05

Step 3:
First Time Use

Please leave your watch near to a window for between 24 to 48 hours to receive radio signal. For the
best possible reception leave your watch at, face down near a window for 24 to 48 hours.
There are other functions available with your Precision Watch. You may go through them as you wish
but as long as you have gone through the “Quick Setup”, your watch is ready to use!

CAUTION!

DO NOT push any button while the second hand is stationary or is fast spinning.

Wait until the seconds hand moves regularly.

Battery Level

High

Medium

Low

Seconds Hand Position

8 o’clock
7 o’clock

6 o’clock

BATTERY MANAGEMENT

When the battery level is low, the second hand runs 2 steps every 2 seconds. When this happens, all
button functions and signal reception will be prohibited. If the battery is not charged up in time, the
hands will stop at 12 o’clock to save battery power. You will need to charge up the watch. It may take
a few days if the battery is too low. The watch will automatically set itself once the battery level returns
to normal.

Battery Level Check

Push S1 twice to show the battery level. Wait until the watch is running normally after reading the
battery level.
