Precaster LB11310CA01 User Manual

. Service Support

Please contact your local dealer or contact us through servise email : [ [e-mail] ] for

further assistance.

. FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

PRECASTER ENTERPRISES CO., LTD.

Add: No. 204, Sec. 2, Fu-Hsing Rd., Taichung, Taiwan

Tel: [phone]. Fax: [phone]

Http://www.precaster.com.tw

Email: [e-mail]

LASER DISTANCE METER

LASER DISTANCE METER
OPERATION MANUAL

HANS HT60

(shadow target)
Measure in a darker place

temperature
within specified working
Measure in an environment

Install a new battery

steps are correct
Check and verify values and

intermediate steps
Divide caculation into

Select a better surface

Ambient light is too strong

Out of working temperature

Low Battery

Pythagorean calculation error

dimension is out of display range.

99999), e.g: result of area or
Out of display range (Max Value:

Reflected signal is too weak

Out of measuring range Measuring in a proper range

Err07

Err06

Err05

Err04

Err03

Err02

Err01

Code Description Solution

. Error Code

-Laser 30 Seconds -Device 180 Seconds

-20°C~60°C

-5°C~40°C

105x48x21mm

AAA Battery x2, Up to 10,000 measures

25mm@15m

650nm, Class II, <1mW

0.5sec

±1.5mm

0.001m

0.05m- 60m

· Automatic Power-Off

· Storage Temperature

· Operation Temperature

· Dimension

· Battery

· Beam Size

· Laser Type

· Measuring Speed

· Accuracy

· Resolution

· Measuring Range

. Specification

· Carrying Case x1 · Safety Strap x1

· HT60 Laser Distance Meter x1 · AAA Battery x2 · Operation Manual x1

. Inside The Box

1 2

radioelectrique subi, meme si le brouillage est susceptible d'en compromettre le fonctionnement.
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
exempts de licence. L'exploitation est autorisee aux deux conditions suivantes : (1) l'appareil ne
Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
operation of the device.
and (2) this device must accept any interference, including interference that may cause undesired
Operation is subject to the following two conditions: (1) this device may not cause interference,

8. This device complies with Industry Canada license-exempt RSS standard(s).
void the user’s authority to operate the equipment.
Changes or modifications not expressly approved by the party responsible for compliance could
—Consult the dealer or an experienced radio/TV technician for help.
connected.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
—Increase the separation between the equipment and receiver.
—Reorient or relocate the receiving antenna.
interference by one or more of the following measures:
determined by turning the equipment off and on, the user is encouraged to try to correct the
If this equipment does cause harmful interference to radio or television reception, which can be
installation.
communications. However, there is no guarantee that interference will not occur in a particular
used in accordance with the instructions, may cause harmful interference to radio
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
against harmful interference in a residential installation.
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

7. This equipment has been tested and found to comply with the limits for a Class B digital device,
EN61000-6-1:2001, EN61326-1:2013, IEC 61326:2012 and FCC Test according to PART 15.

6. Product complies with EMC Test according to EN61000-6-3:2001+A11:2004,

5. The total continuous output of the beams never exceeds 1.0 milli-watts.

4. Product contains semiconductor laser diodes with wavelengths of 650 nanometers.

3. Never stare directly into beam or aim the laser beams at others.
radiation exposure.

2. Use of controls, adjustment procedures other than those specified herein may result in laser

1040.11.
comply IEC 60825-1: 2007, EN 60825-1:2007, EN 61326-1:2013 and CRF21, parts 1040.10 and

1. This is a Class 2 laser tool, laser radiation is emitted from this product and is manufactured to

. Safety Information

. Overview for HT60

· Laser Receiving Window

· LCD

· Laser Emitted Window

· Measure

· Addition /
Subtraction

· Clear / Power

· Functions / Units

-Area

-Volume

-Indirect Measure
I, II, III

-Stake Out Setup

HT-60

· Measurement Records

· Reference / Bluetooth

. Overview for Screen

2 3 11

1

4

5
6
7
8

9

10

1. Measuring Reference

12

2. Measuring Function

13

3. Memories

4. Laser Indicator

14

5. Add and Subtract

6. Maxmum Display

7. Indirect Measuring

8. Minimum Display

9. Stakes Direction Indicator

10. Main Screen and Units

11. Countdown Measuring

12. Bluetooth Indicator

13. Battery Status

14. Sub-Screen and Units

. Battery Installation & Power Status

1. This unit is powered by 2 x AAA Batteries.

2. Remove battery lid and observing correct polarity before install batteries.

3. Battery level is showed on screen with batty icon on screen .

4. When the icon appears, there are approximately 1000 times to measure.

5. Replace batteries when low battery icon flash on screen.

6. To change new batteries, when install new batteries, then close back lid.

. Switch On and Off

1. Be sure to check battery status before start.

2. Click the or to turn on the device.

3. Device will process the initial procedure and get ready to measure by turn on the laser dot.

4. Tap and hold for 2 seconds to turn off.

5. The device will turn off automatically after 180 seconds.

. Distance Measurement

Single Measurement Mode

1. Move the laser dot onto the target.

2. Keep your position stable and click .

3. The measurement will be displayed on LCD Screen and laser will be turn off.

4. Click again to enable the laser dot for next measurement.

Continuous Measurement Mode

1. Continuous Measurement is also called tracking measurement and is recommend to use for seeking

proper distance.

2. Move the laser dot onto the target.

3. Keep your position stable and tap and hold , the laser distance meter will enter continuous

measurement mode.

4. Move the device back and forward to proper distance.

5. Click to pause the measurement.

6. Click again to leave the continuously measurement mode.

. Measurement Reference

1. There are two reference positions for measurement .

They are back of the unit, front of the unit, tripod thread and the spike

2. Click to select the proper position.

4

. Measurement Addition & Subtraction

1. To make summary or difference between two measurements is easy

2. Finish your first measure, than click to save as addend or hold to save as Minuend.

3. Take the second measurement, than click to add from addend or hold to subtract minuend.

. Unit Setting

1. There are 8 units inside the laser distance meter.

2. Click and hold to select preferred unit.

3. Unit Switch Reference

meter

Length

Area

Volume

feet inch inch inch inch 尺0’0”1/32

m

ft

in

m²

ft²

ft²

m³

ft³

ft³

0’0”1/32

ft²

ft³

1/32in

ft²

ft³

1/16in

ft²

ft³

1/8in

ft²

ft³

10/33

P

m³

. Measuring Functions

Area Measurement

1. Click to enable Area measurement.

2. Laser will be activated when entering area measurement mode.

3. Follow the instructions on main screen to measure WIDTH and LENGTH.

4. After finish all the instructions, the result [AREA] will be showed on screen.

2. Volume Measurement

1. Click twice to enable Volume measurement.

2. Laser will be activated when entering volume measurement mode.

3. Follow the instructions on main screen to measure WIDTH, LENGTH and HEIGHT.

4. After finish all the instructions, the result [VOLUME] will be showed on screen.

3. Indirectly Height I, II & III Measurement (base on Pythagorean)

1. Click thrice, four and five times to enable Indirectly Measurement.

2. Laser will be activated when entering indirectly measurement mode.

3. Follow the instructions on main screen to measure the LENGTH OF HYPOTENUSE(S) and BASE.

4. After finish all the instructions, the result [HEIGHT] will be showed on screen.

Indirect

Measure I

Indirect

Measure II

Indirect

Measure III

. Store Measurement to Memory and Lookup

1. When you want to add the measurements on the screen, press to add to memory.

You could find the location in memory on the top of screen.

2. To lookup stored measurements, press and hold to enter the lookup mode.

3. Press to move the index up and hold to move index down.

4. To clear all stored measurements, press and hold again in lookup mode to clear all memory.

. iM² app & Bluetooth Setup

For the model supported Bluetooth could connected with phones support BLE4.0,

For Bluetooth version on your phone, please contact with your phone manufacturer.

We currently offer Measurement Kit on iTune and Play Store.

1. To turn on Bluetooth in pairing mode, press and hold .

2. The Bluetooth icon will keep flashing during paring.

3. Select proper device in the Connection Manager of APP

4. After connected with a beep sound the icon will stop flashing.

Pairing Connected

5
