LT80
LIFTING TABLE 800 kg
The scissor lift tables with foot-operated hydraulic pump are the ideal tools for a
variety of lifting and loading operations and for use as “work station” to provide
improved ergonomic conditions together with improved productivity. It represents the
best solution for the manual load handling, combining functioning, cost saving, safety
and health of operator during work.
COMPACTNESS
• Sturdy steel machine designed to transport and pick your goods becoming your
reliable partner in the everyday work.
• Easy handling granted by ergonomic handle and the combination of fixed and steering
polyurethane wheels.
EASY OF USE
• Thanks to the efficient hydraulic foot pump the table can be brought to the desired
height to easily pick or raise working materials.
• With the lever on the handle it is possible to lower the table without clicks with the
utmost precision.
Page 2
SAFETY
• The foot brakes on the steering wheels guarantee perfect stability during operations.
• The practical wheel guards on the steering wheels protect the feet while working.
• The objects raised at an individual and ergonomic height greatly reduce the strain on
your back.
• The appropriate inspection supports fix the platform in case of maintenance or
cleaning work.
APPLICATION FIELDS
Lift tables are perfect for order preparation and goods mobilization. They are
commonly used throughout industry and commerce, including factories, warehouses,
retail outlets, printers, schools, colleges, laboratories, banks and offices.
Description
Load capacity Kg 800
Material Steel
Scissor type Single scissor
Push handle type Fixed
Weight Kg 112
Handle height mm 990
Pumping time no load n. 53
Nombre de coups de pompe avec charge n. 61
Lift
Min. height mm 415
Max. height mm 1000
Lifting distance mm 585
Lift function Foot pedal
Table size
Height mm 60
Width mm 510
Depth mm 1016
Wheels
Wheels material Polyurethane
Wheels locking function Yes
Swivel wheels n. 2
Fixed wheels n. 2
Diameter of the wheels mm 150
