AR Repeaters

User’s Manual

VD203 66/EN - English Future on Demand.

Allgon Systems AB AR Repeaters

User’s Manual

AR Repeaters

Channel Selective and Band Selective Repeaters

–

English

VD203 66/EN - User’s Manual Rev. P1A 2000-09 i

AR Repeaters Allgon Systems AB

This document describes installation, commissioning and the design of the Allgon AR Repeaters.

Communication between Allgon AR repeaters and operators is carried out either by using Allgon OMT32 (Operation and Maintenance Terminal), or Allgon OMS (Operation and Maintenance System). OMT32 is described in the OMT32, User’s Manual. OMS is described in the Advanced Repeater OMS, User’s Manual.

Hardware and software mentioned in this document are subjected to continuous development and improvement. Consequently, there may be minor discrepancies between the information in the document and the performance and design of the product. Specifications, dimensions and other statements mentioned in this document are subject to change without notice.

Allgon and its suppliers shall not be liable for any damages related to the software or hardware, or for any other damages whatsoever caused of the use of or inability to use any Allgon product. This is applicable even if Allgon has been advised of the damage risk. Under any circumstances, Allgon’s entire liability

Teflon is a registered trademark of Du Pont. Other trademarks mentioned in this document are trademarks or registered trademarks of their respective

shall be limited to replace such defective software or hardware which was originally purchased from Allgon.

owners.

This document is produced by El, Tele & Maskin Ingenjörsfirma AB, Huddinge, Sweden.

Printed in Sweden.

Allgon Systems AB, SE-187 80 Täby, Sweden

Phone: +46 8 540 822 00 – Fax: +46 8 540 834 80 – Internet: www.allgon.com

This document or parts of it may not be reproduced without the written permission of Allgon Systems AB.

ii Rev. P1A 2000-09 VD203 66/EN - User’s Manual

Allgon Systems AB AR Repeaters

ontents

bbreviations ............................................................................................................... vi

. Safety ....................................................................................................................... 1-1

Warning Signs ..................................................................................................... 1-2

Static Electricity .................................................................................................. 1-2

. Introduction ............................................................................................................. 2-1

Repeater Types .................................................................................................. 2-2

Using Repeaters ................................................................................................. 2-3

Shaded Area ................................................................................................. 2-4

Sports Arena ................................................................................................... 2-5

. Installation ................................................................................................................ 3-1

Siting the Repeater ............................................................................................ 3-1

Sunshine ......................................................................................................... 3-1

Shelter ............................................................................................................. 3-1

Outdoor Installation and Service Limitations .............................................. 3-1

Dimensions and Weights ................................................................................... 3-2

Mounting ............................................................................................................. 3-4

Connection ........................................................................................................ 3-7

Connection Ports and Station Ground ............................................................ 3-10

Station Ground .............................................................................................. 3-10

P27 Auxiliary Port ........................................................................................... 3-11

P31 PC Port .................................................................................................... 3-11

P32 Modem Port ........................................................................................... 3-12

P33 Alarm Port ............................................................................................... 3-12

P34 Repeater to Repeater Link Port ............................................................ 3-14

Mains Breakdown Relay .................................................................................... 3-15

Installing 24 Volt or 48 Volt DC Power Supply Unit ......................................... 3-16

. Commissioning ........................................................................................................ 4-1

Starting the Repeater ........................................................................................ 4-2

Indicators ....................................................................................................... 4-3

Measuring the Output Power Level .................................................................. 4-4

Voltage Supply Testpoints ................................................................................. 4-4

Repeater Configuration .................................................................................... 4-4

. Functional Description ............................................................................................ 5-1

Repeater Design ................................................................................................ 5-2

Channel Selective GSM Repeater ............................................................... 5-4

Channel Selective CDMA Repeater ............................................................ 5-5

Channel Selective High Power CDMA Repeater ........................................ 5-6

Band Selective Repeater ............................................................................. 5-7

Combined Repeater .................................................................................... 5-8

VD203 66/EN - User’s Manual Rev. P1A 2000-09 iii

AR Repeaters Allgon Systems AB

Block Diagram .................................................................................................... 5-9

Downlink Signal Path ..................................................................................... 5-9

Uplink Signal Path .......................................................................................... 5-9

Channel Selective GSM Repeater ............................................................... 5-10

Channel Selective CDMA Repeater ............................................................ 5-12

Band Selective Repeater ............................................................................. 5-14

RCU ................................................................................................................. 5-15

R2R ................................................................................................................. 5-15

Alarm .............................................................................................................. 5-16

Repeater Setup ............................................................................................. 5-16

Board and Unit Descriptions ............................................................................. 5-17

DC - Directional Coupler .............................................................................. 5-17

DPX - Duplex Filter ......................................................................................... 5-18

LNA - Low Noise Amplifier ............................................................................. 5-19

CHA - Channel Amplifier Board for Channel Selective Operation .......... 5-20

CSA and PA Boards for Channel Selective CDMA Operation .................. 5-21

BSA and PA Boards for Band Selective Operation ..................................... 5-22

DIA Board ....................................................................................................... 5-23

CU Control Unit Board ................................................................................... 5-25

Repeater CU Software and Hardware Compatibility ................................. 5-26

Cabling ............................................................................................................... 5-27

Channel Selective GSM Repeater, 2 Channels ......................................... 5-28

Channel Selective GSM Repeater, 4 Channels ......................................... 5-29

Channel Selective CDMA Repeater ............................................................ 5-30

Channel Selective High Power CDMA Repeater ........................................ 5-31

Band Selective Repeater ............................................................................. 5-32

. Optionals .................................................................................................................. 6-1

RCU, Remote Control Unit for GSM 900 .......................................................... 6-2

RCU, Remote Control Unit with PCMCIA Modem ........................................... 6-4

OMS, Operation and Maintenance System .................................................... 6-8

Traffic Statistics ................................................................................................... 6-8

Battery Backup ................................................................................................... 6-8

Fiber Optic Interface ......................................................................................... 6-8

7/16" Antenna Cable Connectors ................................................................... 6-8

R2R, Repeater To Repeater Link ....................................................................... 6-9

Requirements ................................................................................................. 6-9

Installation ...................................................................................................... 6-10

Configuration ................................................................................................. 6-10

. Repeater Alarms ..................................................................................................... 7-1

Alarm Reference List ......................................................................................... 7-2

ndex .............................................................................................................................. I-1

uestionnaire .............................................................................................................. Q-1

iv Rev. P1A 2000-09 VD203 66/EN - User’s Manual

Allgon Systems AB AR Repeaters

igures

Figure 2-1. Allgon AR Repeater ................................................................................. 2-1

Figure 2-2. Repeater coverage of shaded area ..................................................... 2-4

Figure 2-3. Repeater in sports arena ........................................................................ 2-5

Figure 3-1. Repeater dimensions ............................................................................... 3-2

Figure 3-2. High power CDMA repeater ................................................................... 3-2

Figure 3-3. Attaching the bracket to a wall ............................................................. 3-4

Figure 3-4. Attaching the bracket to a pole ............................................................ 3-5

Figure 3-5. Attaching the bracket to a mast ........................................................... 3-5

Figure 3-6. Attaching the repeater to the bracket .................................................. 3-6

Figure 3-7. MS and BS antenna connections ........................................................... 3-7

Figure 3-8. Connection ports and station ground ................................................... 3-10

Figure 3-9. Mains breakdown relay connection ...................................................... 3-15

Figure 3-10. Replacing the PSU ................................................................................. 3-16

Figure 4-1. Indicators and mains switch ................................................................... 4-3

Figure 5-1. Channel selective GSM repeater ........................................................... 5-4

Figure 5-2. Channel selective CDMA repeater ........................................................ 5-5

Figure 5-3. High power CDMA repeater ................................................................... 5-6

Figure 5-4. Band selective repeater .......................................................................... 5-7

Figure 5-5. Combined repeater ................................................................................ 5-8

Figure 5-6. Block diagram, channel selective repeater ......................................... 5-10

Figure 5-7. Block diagram, CDMA repeater ............................................................. 5-12

Figure 5-8. Block diagram, band selective repeater .............................................. 5-14

Figure 5-9. MS and BS directional coupler ............................................................... 5-17

Figure 5-10. BS directional coupler, high power CDMA .......................................... 5-17

Figure 5-11. MS directional coupler, high power CDMA ......................................... 5-17

Figure 5-12. LNA low noise amplifier ......................................................................... 5-19

Figure 5-13. DIA board connectors and testpoints ................................................. 5-23

Figure 5-14. Cabling, GSM repeater - 2 ch. ............................................................ 5-28

Figure 5-15. Cabling, GSM repeater - 4 ch. ............................................................ 5-29

Figure 5-16. Cabling, CDMA repeater - 2 ch. ......................................................... 5-30

Figure 5-17. Cabling, high power CDMA repeater - 2 ch. ..................................... 5-31

Figure 5-18. Cabling, band selective repeater ....................................................... 5-32

Figure 6-1. RCU - GSM 900 type ............................................................................... 6-2

Figure 6-2. RCU - Fixed Wire Line PCMCIA type ....................................................... 6-5

Figure 6-3. RCU - Wireless PCMCIA type ................................................................... 6-6

Figure 6-4. Repeater to Repeater Link ...................................................................... 6-9

VD203 66/EN - User’s Manual Rev. P1A 2000-09 v

bbreviations

AR Repeaters Allgon Systems AB

Abbreviations used in this manual, in the software, and in the repeater:

AGC Automatic Gain Control ALI Alarm Interface board AMPS Advanced Mobile Phone Service BCCH Broadcast Control Channel (GSM broadcast channel time slot) BS Base Station, BS antenna = towards the base station BSA Band Selective Amplifier board for uplink or downlink band with fixed or

adjustable band width BSel Band Selective CDMA Code Division Multiple Access CHA Channel Amplifier board with 2 channel selective uplink or downlink channels CMB Combiner unit CSA CDMA Segment Amplifier board with 2 channel selective uplink or downlink

channels CSel Channel Selective CU Control Unit board CW Continuous Wave DAMPS Digital Advanced Mobile Phone Service DC Directional Coupler DCS Digital Communication System (same as PCN) DIA Distribution board DL Downlink signal direction (from base station via repeater to mobile station) DPX Duplex filter EEPROM Electrical Erasable Programmable Read Only Memory EGSM Extended Global System for Mobile communication ETACS Extended Total Access Communication System ETSI European Telecommunications Standard Institute GSM Global System for Mobile communication HW Hardware LED Light Emitting Diode LNA Low Noise Amplifier, uplink and downlink MS Mobile Station, MS antenna = towards the mobile station MSC Mobile Switching Center NMT Nordic Mobile Telephone system OMS Operation and Maintenance System OMS/PC Desktop or notebook with installed OMS software OMT32 Operation and Maintenance Terminal OMT32/PC Desktop or notebook with installed OMT32 software PA Power Amplifier board for uplink or downlink PCN Personal Communication Network (same as DCS) PCS Personal Communication System PSU Power Supply Unit PTFE Polytetrafluoro Ethylene (Teflon) RCU Remote Control Unit RF Radio Frequency RIA Repeater to Repeater Interface Adapter RSSI Received Signal Strength Indication RTC Real Time Clock SW Software TACS Total Access Communication System TDMA Time Division Multiple Access UL Uplink signal direction (from mobile station via repeater to base station) UPS Uninterruptible Power Supply

vi Rev. P1A 2000-09 VD203 66/EN - User’s Manual

Allgon Systems AB AR Repeaters Safety

. Safety

Any personnel involved in installation, operation or service of Allgon

repeaters must understand and obey the following:

• Allgon repeaters are designed to receive and amplify signals from one or

more base stations and retransmit the signals to one or more mobile stations. Also, the repeaters are designed to receive signals from one or more mobile stations, amplify and retransmit to the base stations. The repeaters must be used exclusively for these purposes and nothing else.

• Repeaters supplied from the mains must be connected to grounded

outlets and in conformity with any local regulations.

• The power supply unit in repeaters supplied from the mains contains

dangerous voltage that can cause electric shock. Disconnect the mains prior to any work in such a repeater. Any local regulations are to be followed when servicing repeaters.

Authorized service personnel only are allowed to service repeaters while the mains is connected.

BERYLLIUM OXIDE

HYDROGEN FLUORIDE

• The repeater cover must be secured in opened position, e.g. by tying it

up, at outdoor repeater work. Otherwise, the cover can be closed by the wind and cause your fingers getting pinched or your head being hit.

• When working on a repeater on high ground, e.g. on a mast or pole, be

careful not to drop parts or the entire repeater. Falling parts can cause serious personal injury.

• Any repeater, including this repeater, will generate radio signals and

thereby give rise to electromagnetic fields that may be hazardous to the health of any person who is extensively exposed to the signals at the immediate proximity of the repeater and the repeater antennas.

• The CHA channel board power transistors, the PA amplifier board

power transistors, and the combiners (CMB) contain beryllium oxide (BeO) that is poisonous if present as dust or smoke which can be inhaled. The power transistors mentioned are mounted with two screws as opposed to other transistors.

Do not file, grind, machine, or treat these parts with acid.

Warning signs are applied on boards and units that contain beryllium oxide. These warning signs are shown in the next section.

• The coaxial cable insulation is made of PTFE, polytetrafluoro ethylene,

that gives off small amounts of hydrogen fluoride when heated. Hydrogen fluoride is poisonous. Do not use heating tools when stripping off coaxial cable insulation.

No particular measures are to be taken in case of fire because the emitted concentration of hydrogen fluoride is very low.

VD203 66/EN - User’s Manual Rev. P1A 2000-09 1 - 1

Safety AR Repeaters Allgon Systems AB

• A lithium battery is permanently mounted on the CU board. Due to

the risk of explosion, this battery must not be removed from the board. In case of battery malfunction, replace the CU board. The old CU board can be sent to Allgon for repair.

• The heat sink element on the CDMA High Power repeater can be very

hot. Do not touch this surface during operation.

Warning Signs

The following warning signs must be observed and be kept clean and

readable.

Beryllium oxide

This warning sign is applied on boards and units which contain beryllium oxide parts.

Beryllium

oxide

hazard

BERYLLIUM OXIDE

(Toxic)

used in equipment

see instruction book

This warning sign is applied at the bottom, inside the cabinet, below the power supply unit.

The previous section details parts containing beryllium oxide and how to avoid dangerous dealing with these parts.

Static Electricity

Static electricity means no risk of personal injury but it can severely damage essential parts of the repeater, if not handled carefully.

Parts on the printed circuit boards as well as other parts in the repeater are sensitive to electrostatic discharge.

Never touch the printed circuit boards or uninsulated conductor surfaces unless absolutely necessary.

If you must handle the printed circuit boards or uninsulated conductor surfaces, use ESD protective equipment, or first touch the repeater chassis with your hand and then do not move your feet on the floor.

Never let your clothes touch printed circuit boards or uninsulated conductor surfaces.

Always store printed circuit boards in ESD-safe bags.

1 - 2 Rev. P1A 2000-09 VD203 66/EN - User’s Manual

Allgon Systems AB AR Repeaters Introduction

. Introduction

Figure 2-1. Allgon AR Repeater

Allgon repeaters are used to fill out uncovered areas in cellular mobile systems, such as base station fringe areas, road tunnels, business and industrial buildings, etc.

A repeater receives signals from a base station, amplifies and retransmits the signals to mobile stations. Also it receives, amplifies and retransmits signals in the opposite direction. Both directions are served simultaneously.

To be able to receive and transmit signals in both directions, the repeater is connected to a donor antenna directed towards the base station and to a service antenna directed towards the area to be covered.

Control of the repeaters is performed using a desktop or notebook loaded with the Allgon OMT32, Operation and Maintenance Terminal, which can communicate with the repeaters, either locally or remotely via modem. Remote operation can be performed either via a traditional telephone line or via a mobile phone that can be installed inside the repeater.

To be able to control many Allgon AR repeaters in common, there is an Allgon OMS, Operation and Maintenance System.

The repeaters and the OMT32 is described in this manual. The OMS is described in the OMT32, User’s Manual.

User’s Manual VD203 66/EN Rev. P1A 2000-09 2 - 1

Introduction AR Repeaters Allgon Systems AB

Repeater Types

The following repeater types are currently available:

• Channel selective GSM repeater

• Channel selective CDMA repeater

• Channel selective high power CDMA repeater

• Band selective repeater with fixed bandwidth

• Band selective repeater with adjustable bandwidth

• Combined repeater

In the OMT32, the channel selective 900, 1800, and 1900 systems are called GSM, DCS and PCS respectively, even though these systems may have different names in other parts of the world.

Channel selective GSM repeater

A channel selective GSM repeater can be equipped with two, four, six or eight channels. This repeater type is used for channel selective systems, such as GSM, DCS, PCN and GSM 1900 (PCS).

Channel selective CDMA repeater

A channel selective CDMA repeater can be equipped with one or two channels. This repeater type is used for digital code division systems in accordance with IS-95 or J-std-008 standard.

Channel selective high power CDMA repeater

A channel selective CDMA repeater like the previous one, but equipped with a 6dB (typically) BA (Booster Amplifier) unit.

Band selective repeater with fixed bandwidth

A band selective repeater with fixed bandwidth has fixed filters for a certain bandwidth. This repeater type is used for analog or digital systems, such as NMT, GSM, TACS, ETACS, AMPS, DAMPS and CDMA.

Band selective repeater with adjustable bandwidth

A band selective repeater with adjustable bandwidth has filters that can be set to various bandwidths. This repeater type is used for analog or digital systems, such as NMT, TACS, ETACS, AMPS, DAMPS and CDMA.

Combined repeater

Some of the above mentioned types can be combined in the same repeater chassis and be in operation in parallel.

2 - 2 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Introduction

Using Repeaters

In areas where the radio signal propagation is poor repeaters can be used to fill out those areas which are not covered by the base station.

The following scenarios are examples on this:

– Sports arenas – Fair halls – Large shopping centres – Road and railway tunnels – Indoors in buildings with metal or concrete walls

Other examples where repeaters can be used to increase the coverage are:

– Shaded areas – Fringe coverage areas

In areas where the traffic intensity is low, it is not cost efficient to install a base station. An Allgon repeater, which can be installed with a minimum of investments, is a much better solution. You save installation costs as well as operational costs.

Examples of using repeaters

Two examples are described in the following sections. An outdoor example in a shaded valley and an indoor example in a sports arena.

User’s Manual VD203 66/EN Rev. P1A 2000-09 2 - 3

Introduction AR Repeaters Allgon Systems AB

Shaded Area

A valley is shaded by hills. There is a base station 5 kilometers away, but

the lowest signal strength in the valley is less than –100dBm. A mast used for other purposes is available for a repeater installation. The mast height is 42 meter and it is located on a hill. The scenario is illustrated in Figure 2-2.

Donor antenn a

Service ante nna

Figure 2-2. Repeater coverage of shaded area

The donor antenna of the repeater was mounted at the top of the mast and the service antenna was mounted at the half mast. The antenna isolation was measured to over 100dB. The repeater was set to 80dB gain.

Measured levels: Received signal level – 60.0 dBm

Donor antenna gain 15.0 dBi Cable loss

–

5.0 dB

Repeater input level – 50.0 dBm

Adjusted repeater gain 70.0 dB Repeater output level 20.0 dBm

Cable loss – 5.0 dB Service antenna gain 8.0 dBi Radiated output level 23.0 dBm

The measured result in the valley was better than –90dBm.

2 - 4 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Introduction

Sports Arena

A 2000 spectators sports arena with metallic roof had an indoor signal

strength too low to provide a fair service in most parts of the arena. The nearest base station was 8 kilometers away and it was equipped with one carrier only.

A donor antenna directed towards the base station was mounted on a mast outside the building and a repeater was installed inside the building with the service antenna on the arch vault. The scenario is illustrated in Figure 2-3.

Donor antenna

Service antenna

Figure 2-3. Repeater in sports arena

The antenna isolation was measured to over 85dB.

Measured levels: Received signal level – 80.0 dBm

Donor antenna gain 15.0 dBi Cable loss

–

5.0 dB

Repeater input level – 70.0 dBm

Adjusted repeater gain 75.0 dB Repeater output level 5.0 dBm

Cable loss – 2.0 dB Service antenna gain 7.0 dBi Radiated output level 10.0 dBm

The signal strength was fair for service in the entire arena.

User’s Manual VD203 66/EN Rev. P1A 2000-09 2 - 5

Allgon Systems AB AR Repeaters Installation

. Installation

Before installation, read carefully Chapter 1, Safety.

Siting the Repeater

Allgon repeaters are designed for outdoor usage. However, humidity and

temperature changes may have affect on the reliability. A preferable site for the repeater is thus indoor, in a tempered and ventilated room.

Sunshine

If a repeater is placed outdoor and can be exposed to direct sunshine, it is

essential that the air can circulate around the repeater with no obstacle.

The operating temperature must not exceed +55°C. A shelter can be used to shade the repeater from direct sunshine.

Shelter

Allgon repeaters are designed with a weather proof outdoor case that can

be mounted without any kind of shelter from rain, snow or hail.

If a repeater is to be opened on the site when raining, snowing, or hailing there must be some kind of permanent or temporary shelter. This is applicable to gentle rainfall, snowfall or hail. Limitations for very bad weather is found in the next section.

Allgon can provide a shelter designed for these repeaters. This shelter is shown in Figure 3-1.

Outdoor Installation and Service Limitations

Sited outdoors, the repeater must not be opened for installation or

service at bad weather, such as:

– Intense rainfall, snowfall or hail – Storm or high wind – Extremely low or high temperature – High humidity of the air

User’s Manual VD203 66/EN Rev. P1A 2000-09 3 - 1

Installation AR Repeaters Allgon Systems AB

Dimensions and Weights

The dimensions of the repeater, including the mounting bracket, is shown

in Figure 3-1. The repeater chassis consists of two main parts, a cabinet in which the circuitry is housed, and a cover, which can be either a thin cover or a large cover (see the figure) depending on the configuration.

110 (4.3")

530 (20.9")

Mounting br acket

520 (20.5"

440 (17.3")

)

ALLGON

Cabinet Shelter Thin cove r Large cover

174 (6.9")

224 (8.8")

Figure 3-1. Repeater dimensions

240 (9.4")

290 (11.4")

The high power CDMA repeater has an external heat sink on a large cover, see Figure 3-2.

180 (7.1")

350 (13.8")

ALLGON

35 (1.4")

Figure 3-2. High power CDMA repeater

3 - 2 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Installation

Approximately repeater weights

Channel selective repeater, four channels, thin cover ............ 21 kg (46 lbs)

Channel selective repeater, four channels, large cover ........... 25 kg (55 lbs)

Band selective repeater, thin cover .......................................... 21 kg (46 lbs)

Band selective repeater, large cover ......................................... 25 kg (55 lbs)

Channel/band selective combi repeater, large cover ............... 30 kg (66 lbs)

Channel selective high power CDMA repeater, large cover ... 30 kg (66 lbs)

It is not recommended to remove the cover from the cabinet at the site.

However, if the cover, for some reason, has to be removed from the cabinet, then disconnect the interconnection cables, close the cover, remove the hinge shafts, and remove the cover.

The cabinet and cover weights are, approximately, as follows:

Empty thin cover .......................................................................... 6 kg (13 lbs)

Empty large cover ...................................................................... 10 kg (22 lbs)

Equipped cabinet or large cover ............................................... 15 kg (33 lbs)

User’s Manual VD203 66/EN Rev. P1A 2000-09 3 - 3

Installation AR Repeaters Allgon Systems AB

Mounting

The AR repeater is easy to mount using the provided mounting bracket,

which has Ø14mm (9/16") holes for 10mm (3/8") or 12mm (1/2") fixing screws. Clamps with c-c measures of 90mm (3.5"), 135mm (5.3"), 144mm (5.7"), 205mm (8.1"), 250mm (9.8"), and 300mm (11.8") can be used as well. The vertical c-c measure for these are 411mm (16.2").

The mounting bracket is shown in the figure.

NOTE! There is a Ø14mm (9/16") single hole in the middle of the mounting bracket, marked ’A’ in the figure, which is intended for a locking screw, i.e. a screw which cannot be removed when the repeater is put in the bracket.

Mount the repeater as follows:

1. Mount the provided bracket.

Normally, the repeater is mounted on a wall, pole, or mast. These mounting cases are shown below.

Figure 3-3. Attaching the bracket to a wall

Figure 3-3 shows a bracket attachment to a wall using four fixing screws and a locking screw.

3 - 4 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Installation

Figure 3-4. Attaching the bracket to a pole

Figure 3-4 shows a bracket attachment to a pole using two 144mm (5.7") U-shaped clamps and a locking screw.

Figure 3-5. Attaching the bracket to a mast

Figure 3-5 shows a bracket attachment to a mast using two 300mm (11.8") bar-shaped clamps and no locking screw.

User’s Manual VD203 66/EN Rev. P1A 2000-09 3 - 5

Installation AR Repeaters Allgon Systems AB

Figure 3-6. Attaching the repeater to the bracket

2. After attaching the bracket, hang the repeater on the upper supports

(see Figure 3-6) and use the screws for the lower ones. Tighten the upper and lower screws.

There are locking cylinders that can be inserted and locked with a key after the lower screws have been tightened (see Figure 3-6). These prevents from unauthorized removal of the repeater.

3. Mount the donor antenna directed towards the base station antenna.

This antenna is marked ’BS’ in the repeater.

4. Mount the service antenna directed towards the area to be covered by

the repeater. This antenna is marked ’MS’ in the repeater.

3 - 6 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Installation

Connection

OUT

IN ATT +7V OUT1 OUT2

LNA

LOW

LNA DL

OUT LOWIN+7V ATTOUT1 OUT2

DPX

TEST

-30 dB MS

-20 dB

ANT

DPX

TEST

-30 dB MS

-20 dB

ANT

PSU

Mains

MS BS

High power CDMA only

BS MS

Figure 3-7. MS and BS antenna connections

1. Connect the service and donor antenna coaxial cables (see

Figure 3-7). N type female connectors are used in the repeater.

The donor antenna (BS) is connected to the right in the cabinet, except for the high power CDMA repeater for which the donor antenna is connected to the left in the cabinet (see Figure 3-7).

The service antenna (MS) is connected to the left in cabinet, except for the high power CDMA repeater for which the service antenna is connected to the right in the cabinet (see Figure 3-7).

2. Mount the mains plug and connect the power supply unit, PSU.

For repeaters supplied from the mains, the mains outlet must be grounded. Both the mains plugs of repeaters equipped with two power supply units must be connected to outlets supplied from the same fuse.

User’s Manual VD203 66/EN Rev. P1A 2000-09 3 - 7

Installation AR Repeaters Allgon Systems AB

3. Connect external alarm sensors (burglary, fire, etc.) and other

external alarm equipment (optical or acoustic signal, etc.), if any.

P33

External alarm is connected to the P33 alarm port located to the left in the cabinet (see Figure 3-8 on page 3-10). Use a 15 pole D-sub male connector.

External alarm

sensors

MS –20dB

P32

P27

RCU

Modem

Power supply

This is a schematic figure.

The various RCU parts can

be integrated or configured

differently.

Battery

The P33 port is described on page 3-12.

Cables for this installation is taken through strain relief bushings or connectors at the bottom of the repeater.

4. Connect the internal phone/modem unit for remote control of the

repeater, if any.

The modem and a power backup unit are integrated in an RCU, Remote Control Unit, which is mounted downmost inside the cabinet, in front of the PSU. The RCU is available in different types for various systems, which is further detailed in the Optionals section in Chapter 6.

The modem is connected to the P32 modem port (RS-232, V.24 interface) on the repeater located to the left in the cabinet (see Figure 3-8 on page 3-10).

The P32 port is described on page 3-12.

The mobile phone antenna is connected to the MS –20dB port on the BS directional coupler (DC) in the cabinet (DC/BS), provided that the phone and the repeater operate in the same system.

If an RCU is used, this is powered by the P27 auxiliary port located to the left in the cabinet (see Figure 3-8 on page 3-10). Pin 2 and 3 of the P27 port are interconnected with a jumper if not used. This jumper must be removed before plugging the RCU connector to P27.

The P27 port is described on page 3-11.

If the RCU is removed, the jumper between pin 2 and 3 on the P27 port must be reconnected. Otherwise, the CU and ALI boards will have no voltage supply. Do not connect the jumper to another position than between pin 2 and 3 on the P27 port.

5. Connect a telephone line for remote control of the repeater, if any.

The telephone line is connected to a modem, which is connected to

P32

the P32 modem port on the repeater.

The P32 port is described on page 3-12.

Use a strain relief bushing or a connector at the bottom of the

Telephone line

Modem

repeater for the external telephone line cable.

3 - 8 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Installation

6. Connect the Repeater to Repeater Link cable, if this optional feature

is to be used. The R2R net cable is connected to the P34 Repeater to

P34

P3 P2

Repeater Link port via the P1 terminal on the R2R connector board to the right in the repeater.

The P34 Repeater to Repeater Link port is described on page 3-14.

Use a strain relief bushing or a connector at the bottom of the repeater for the external telephone line cable.

Required information for a Repeater to Repeater Link installation is found in the VD202 91/EN, R2R, Repeater to Repeater Link Kit, Installation Guide.

7. Connect a PC for controlling the repeater. A COM port on the PC is

P31

connected to the P31 PC port (RS-232) located to the right in the cabinet (see Figure 3-8 on page 3-10). Use the provided serial cable.

Port P31 is described on page 3-11.

Now, you can use OMT32 to set up and control the repeater. The OMT32 program is described in the OMT32, User’s Manual.

But first, check the connections made and commission the repeater as described in Chapter 4.

User’s Manual VD203 66/EN Rev. P1A 2000-09 3 - 9

Installation AR Repeaters Allgon Systems AB

Connection Ports and Station Ground

The DIA distribution board provides most of the internal connection

between the repeater units, and to external ports. Connectors involved in the installation are also located on the DIA board. These connectors are described below. A complete DIA board connector list is found in the Board and Unit Descriptions section in Chapter 5.

Station ground is detailed below as well.

OUT

IN ATT +7V OUT1 OUT2

LNA

LOW

CMB CMB

DL UL

DPX DPX

LNA DL

OUT LOWIN+7V ATTOUT1 OUT2

P28

P34

P32

P33

P27

DPX

TEST

-30 dB MS

-20 dB

ANT

DPX

TEST

-30 dB

-20 dB

ANT

MS BS

Figure 3-8. Connection ports and station ground

P31

-20 dB

Station Ground

There is a ground screw (M8) in the repeater that is intended for station ground (see Figure 3-8). This screw must be used only for station grounding.

3 - 10 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Installation

P27 Auxiliary Port

Auxiliary port P27 is used for powering an RCU mobile phone/modem remote control unit. The connector is found on the DIA board to the left in the cabinet (see Figure 3-8).

P27 is an 8 pole, 1 line male connector.

Pin 2 and 3 of the P27 port MUST ALWAYS be interconnected to provide the CU and ALI boards with voltage supply. If there is no cable connected to the P27 port, pin 2 and 3 MUST be interconnected with a jumper.

P27 auxiliary connector pinning

Pin 1 +7V DC Pin 2 +7V DC Pin 3 CU and ALI power supply from pin 2 Pin 4 GND Pin 5 +26V DC or +10V DC depending on the repeater type Pin 6 Not used Pin 7 Output 200KHz reference Pin 8 GND

P31 PC Port

PC port P31 is a RS-232 port used for local PC communication.

The connector is found on the DIA board to the right in the cabinet (see Figure 3-8).

P31 is a 9 pole D-sub female connector.

P31 PC connector pinning

Pin 1 Not used Pin 2 Data from repeater to OMT32 Pin 3 Data from OMT32 to repeater Pin 4 DTR from OMT32 to repeater Pin 5 GND Pin 6 DSR from repeater to OMT32 Pin 7 RTS from OMT32 to repeater Pin 8 CTS from repeater to OMT32 Pin 9 Not used

User’s Manual VD203 66/EN Rev. P1A 2000-09 3 - 11

Installation AR Repeaters Allgon Systems AB

P32 Modem Port

Modem port P32 is a RS-232 port with V.24 interface used for remote

control of the repeater.

P33 Alarm Port

The connector is found on the DIA board to the left in the cabinet (see Figure 3-8).

P32 is a 9 pole D-sub male connector.

P32 modem connector pinning

Pin 1 DCD Pin 2 RXD Pin 3 TXD Pin 4 DTR Pin 5 GND Pin 6 DSR Pin 7 RTS Pin 8 RFS Pin 9 RI

Alarm port P33 is used for external alarm sensors and alarm equipment.

The connector is found on the DIA board to the left in the cabinet (see Figure 3-8).

P33 is a 15 pole D-sub female connector.

The port has four alarm inputs, EAL1 - EAL4, and two alarm outputs.

Four alarm inputs

The inputs are low-level inputs (signal AI1 - AI4) with common ground (AIC).

Use insulated switch or relay to initiate alarms (open switches in normal operating mode, closed switches cause alarm).

The alarm switch connection can be toggled between being active open or active closed. See the Alarm Configuration section in Chapter 11.

The alarm input voltage ratings, related to ground (AIC), are:

max min

= 5.5V = –0.5V

Vin Vin

The alarm inputs are defined as follows: Pin 14 AI1 External alarm input 1 - EAL1

Pin 15 AI2 External alarm input 2 - EAL2 Pin 7 AI3 External alarm input 3 - EAL3 Pin 8 AI4 External alarm input 4 - EAL4 Pin 6 AIC Ground

3 - 12 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Installation

P28 - AI4 door switch alarm input

3 1

Normally, alarm input AI4 is used for repeater cover opening alarm EAL4, which is arranged using a door switch (optional). Because of that, AI4 and AIC are available also in the P28 connector, to which the door switch is connected. The location of the connector in the cabinet is shown in Figure 3-8.

The EAL4 door switch alarm is activated 10-30 seconds after the cover has been opened.

Two alarm outputs

Both the alarm outputs are 1 pole closing and 1 pole opening relay outputs insulated from each other.

Maximum ratings, related to ground or any other alarm terminal, are 50VAC/60VDC.

The alarm outputs are defined as follows: Pin 9-1 AO1-AO8 Closed when operating, otherwise open

Pin 10-2 AO6-AO7 Open when operating, otherwise closed Pin 11-3 AO2-AO5 Closed at alarm state, otherwise open Pin 12-4 AO3-AO4 Open at alarm state, otherwise closed

P33 alarm connector pinning

Pin 1 AO8

Pin 2 AO7 Pin 3 AO5 Pin 4 AO4 Pin 5 Not used Pin 6 AIC Pin 7 AI3 Pin 8 AI4 Pin 9 AO1 Pin 10 AO6 Pin 11 AO2 Pin 12 AO3 Pin 13 Not used Pin 14 AI1 Pin 15 AI2

User’s Manual VD203 66/EN Rev. P1A 2000-09 3 - 13

Installation AR Repeaters Allgon Systems AB

P34 Repeater to Repeater Link Port

The P34 port is used for Repeater to Repeater Link (R2R net), which is an optional feature for the AR repeaters.

The connector is found on the DIA board to the left in the cabinet (see Figure 3-8).

P34 is an 8 pole RJ45 modular female connector.

P34 Repeater to Repeater Link connector pinning

Pin 1 C/S Pin 2 GND Pin 3 D–

Pin 4 D+ Pin 5 D+ Pin 6 D– Pin 7 GND Pin 8 C/S

For further information about the Repeater to Repeater Link installation, refer to the VD202 91/EN R2R, Repeater to Repeater Link Kit, Installation Guide.

3 - 14 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Installation

Mains Breakdown Relay

To be able to distinguish PSU faults from power failure, a mains

breakdown relay must be used on the repeater mains supply.

The mains breakdown relay is not included in the repeater. So, it has to be mounted outside the repeater chassis. The relay intended for this purpose must fulfil the following specifications:

Relay specification

Closing time: max. 30 milliseconds Insulation coil/contact: min. 4KV Mains connected relay must be in compliance with valid local regulations.

Connection

• Connect a currentless closed relay contact to pin AI1 and AIC on the

P33 alarm connector see Figure 3-9. Alarm is initiated by short circuiting pin AI1 and AIC in the P33 connector. The P33 alarm connector is detailed on page 3-12.

• Connect the relay coil. It must be supplied from the same fuse as the

repeater.

P33

P33:AI1

Figure 3-9. Mains breakdown relay connection

P33:AI

• After commissioning, select the Mains breakdown option in the

Alarm Configuration dialog box described in the Alarm Configuration

section in Chapter 11.

User’s Manual VD203 66/EN Rev. P1A 2000-09 3 - 15

Installation AR Repeaters Allgon Systems AB

Installing 24 Volt or 48 Volt DC Power Supply Unit

You can replace the 220V AC PSU with a 24 Volt or 48 Volt DC PSU as

follows:

DPX

TEST

-30 dB MS

-20 dB

ANT

DPX

TEST

-30 dB MS

-20 dB

ANT

Figure 3-10. Replacing the PSU

1. Switch the repeater off and remove the mains plug from the PSU

(’1’ in Figure 3-10).

2. Disconnect the two connectors (2) on the PSU.

3. Loosen the three fixing screws (3) using a 5mm Allen key.

4. Remove the PSU from the repeater.

5. Mount the 24/48 Volt DC PSU with the three fixing screws (3).

6. Connect the PSU to the DIA board (2).

BROWN BLUE

7. Connect the DC power cable. The supplied cable should have a

radiation limiter. The cable shall be connected as follows:

The + pole shall be connected to one of the left terminals in the PSU connector with the BROWN part of the DC cable.

The – pole shall be connected to one of the right terminals in the

PSU connector with the BLUE part of the DC cable.

8. Switch the repeater on.

9. The yellow LED on the PSU shall now be lit.

The DC Power Supply Unit must be galvanically separated from the mains supply with an equipment fulfilling the IEC65 safety requirements.

3 - 16 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Commissioning

. Commissioning

Read carefully Chapter 1 Safety before commissioning the repeater.

Check all connections made during the installation. Also, ensure that both the mains plugs for repeaters equipped with two power supply units are connected to outlets supplied from the same fuse.

To fulfill the IP65 weather protective requirements, ensure that the cable strain relief bushings are properly tightened. Also, ensure that the gaskets at the cable inlets and on the cabinet are properly fitted and not damaged.

When the installation is checked, commission the repeater as described below.

User’s Manual VD203 66/EN Rev. P1A 2000-09 4 - 1

Commissioning AR Repeaters Allgon Systems AB

Starting the Repeater

1. Turn the mains switch on (marked ’S’ in Figure 4-1).

2. Check the LED on the power supply unit (V). It must be lit with a

steady yellow light.

3. Check the four CU board LEDs (see Figure 4-1). A correct power

up is indicated as follows:

PWR

Yellow LED which is lit with a steady light after the mains is switched on. Indicates present power.

BOOT

Red LED that is lit with a steady light when the system boots, i.e. for 10 - 15 seconds after the mains is switched on. Then, it flashes for the next 5 - 10 seconds. After that, if no error is detected, the LED is off.

ALARM

Red LED that flashes 15 - 20 seconds after the mains is switched on. Then, it flashes for less serious alarms (ERROR) and is lit with a steady light for fatal alarms (CRITICAL).

OPER

Green LED that lights up approx. 15 seconds after the mains is switched on. It shows, with a steady light, that the repeater is ready for operation.

4. Check the three ALI board LEDs (see Figure 4-1). The LEDs follow

the alarm relays. A correct power up is indicated as follows:

OPER

Green LED that has the same indication as the green LED on the CU board (see above).

ALARM

Red LED that is lit with a steady light for ERROR and CRITICAL alarms.

PWR

Yellow LED that has the same indication as the yellow LED on the CU board (see above).

External indicators on the repeater front

Yellow

Operation LED that lights up approx. 15 seconds after the mains is switched on. At steady light the repeater is ready for operation.

Red

Alarm LED that indicates ERROR alarms with flashing light and CRITICAL alarms with steady light.

4 - 2 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Commissioning

When the indicators show operational mode, the repeater can be configured for operation by using a computer running OMT32. This is further detailed in the OMT32, User’s Manual.

Indicators

OUT

IN ATT +7V OUT1 OUT2

LNA

LOW

LNA DL

OUT LOWIN+7V ATTOUT1 OUT2

-30 dB

-20 dB

DPX

TEST

ANT

TEST

-30 dB BS

ALI

DC TEST

-30 dB MS

DPX

TEST

-30 dB MS

-20 dB

ANT

OPER

ALARM

PWR

BOOT

OPER

ALARM

Figure 4-1. Indicators and mains switch

Figure 4-1 shows the repeater indicators and the mains switch. There are also two external indicators on the repeater front cover.

Repeater to Repeater Link

indicators

Additional indicators are found in the repeater, if equipped with the Repeater to Repeater Link feature. For information about these indicators, refer to the VD202 91/EN R2R, Repeater to Repeater Link Kit, Installation Guide.

User’s Manual VD203 66/EN Rev. P1A 2000-09 4 - 3

Commissioning AR Repeaters Allgon Systems AB

Measuring the Output Power Level

Uplink and downlink output power test ports are found on the directional

couplers (DC) at the MS and BS antenna connectors. These test ports are

marked TEST –30dB (see Figure 4-1) and are intended for measuring using e.g. a spectrum analyzer.

The coupling is –30dB approximately. There is no directivity in these test ports, i.e. both uplink and downlink signal can be measured.

Voltage Supply Testpoints

A number of voltage supply testpoints are available in the repeater.

These testpoints are named U7A - U7F for the 7V supply voltages and U26 for 26V, 13V or 10V supply voltage (depending on the repeater type).

A standard multi-meter can be used on these testpoints.

The testpoints are found on the DIA board in the repeater cabinet. The testpoint positions on the DIA board is detailed in the Board and Unit Descriptions section in Chapter 5.

If the repeater is equipped with a second PSU, e.g. for combined channel/band selective operation, the same set of testpoints are also found on the cover DIA board.

Repeater Configuration

The repeater is now ready to be configured in accordance with the site conditions and system performance requirements. Pay especial attention to the antenna isolation described in the OMT32, User’s Manual.

4 - 4 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

. Functional Description

Allgon repeaters work as bi-directional on-frequency amplifiers.

A repeater receives, amplifies, and retransmits signals downlink and uplink simultaneously, i.e. from the base station via the repeater to the mobile stations and from the mobile stations via the repeater to the base station.

The repeater is connected to a BS antenna, directed towards the base station, and to a MS antenna directed towards the area to be covered. These antennas are connected to the repeater with N type male connectors.

To prevent instability due to poor antenna isolation, a built-in antenna isolation supervision feature reduces the gain level automatically when poor antenna isolation is detected.

The Allgon repeaters are controlled by powerful microprocessors.

Alarm and operational LEDs are visible on the repeater front.

The repeater works with convection cooling without fan.

Operational parameters such as gain, channel number, power levels, etc. are set using a desktop or notebook and the Allgon OMT32, which communicate, locally or remotely via modem, with the repeater. Remote operation is performed using a telephone line or a built-in mobile phone equipped with a data interface.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 1

Functional Description AR Repeaters ALLGON Syst em AB

Repeater Design

The repeater is housed in a cast aluminium chassis that is waterproof,

class NEMA4/IP65, for outdoor use. The chassis has a design suited for outdoor use as well as indoor use.

The chassis consists of a cabinet and a cover joined with hinges. The cabinet contains the repeater circuitry. The cover can either be a thin cover or a large cover. The latter consists of another cabinet which can be used as an empty cover or be equipped as an independent repeater unit.

The cover has two external LEDs for operation and alarm indication.

The cabinet as well as a large cover can be equipped for channel selective operation or band selective operation. A combined repeater is normally equipped for channel selective operation in the cabinet and band selective operation in the cover.

Different amplifier boards are used to get the various operations (see below). The amplifier boards are individually shielded and located under metal cover sheets which can be folded out.

CHA, Channel selective GSM amplifier board

Channel selective GSM repeaters can handle up to eight repeater channels (four if the CU part number is K103/1). For every even number of repeater channels, two CHA amplifier boards are required in the repeater, one CHA board for uplink signaling and one board for downlink signaling. Each repeater channel is allocated to a radio channel or switched off. In a GSM type TDMA system (GSM, EGSM, DCS1800 or PCS1900), one repeater channel can handle eight calls (sixteen if half-rate encoding is used).

CSA, Channel selective CDMA amplifier board

Current CDMA repeaters can handle two CDMA repeater channels. For every even number of repeater channels, two CSA amplifier boards and two PA amplifier boards are required in the repeater, one pair of CSA/PA boards for uplink signaling and one pair for downlink signaling. Each repeater channel is allocated to a radio channel or switched off.

BSA, Band selective amplifier board

Band selective repeaters can handle one wide band repeater channel. The band width is either fixed or adjustable (fixed for 900MHz repeaters only). A band selective repeater channel requires two BSA boards and two PA amplifier boards in the repeater. One pair of BSA/PA boards for uplink signaling and one pair for downlink signaling.

BA, High power CDMA booster amplifier board

CDMA repeaters can be equipped with a high power booster amplifier board that boosts the output gain with typically 6dB. A high power CDMA repeater can operate with maximum 2 channels.

5 - 2 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

Other units

In addition to the channel/band selective boards, the repeater contains:

• DIA Distribution board, which is a board on which all other boards and

units are connected to.

On the DIA board, there is a shielded metal frame in which the CU and ALI boards are located.

There is a DIA board in the cabinet, and another board in the cover, if equipped.

• CU Control Unit board, located in the frame on the DIA board.

There is one CU board in the cabinet, which controls the entire repeater.

• ALI Alarm Interface board, located in the frame on the DIA board.

There is one ALI board in the cabinet which handles alarm and alarm communication.

• DC Directional Coupler, located in shielded boxes which are formed as

recesses in the cabinet.

Two DC units in the cabinet are used as antenna signal directional coupler.

• LNA Low Noise Amplifier, located in shielded boxes which are formed

as recesses in the cabinet.

Two LNA units in the cabinet are used as downlink and uplink low noise amplifiers, and additional two LNA are used in the cover, if equipped.

• DPX Duplex filter, located on the cover plate over the channel/band

selective boards.

• CMB Combiner unit, located on the cover plate over the channel/band

selective boards in channel selective repeaters with more than two channels, and in combined repeaters.

• RCU unit (optional), see Chapter 6, Optionals.

• PSU Power Supply Unit, located downmost in the cabinet, and in the

cover, if equipped.

If the repeater is equipped with an optional Repeater to Repeater Link feature, the following board is also included in the repeater (not valid to channel selective CDMA repeaters):

• RIA Repeater to Repeater Interface Adapter, located in the frame on

the DIA board.

For further information about the Repeater to Repeater Link feature, refer to the VD202 91/EN R2R, Repeater to Repeater Link Kit, Installation Guide.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 3

Functional Description AR Repeaters ALLGON Syst em AB

Channel Selective GSM Repeater

LNA UL Uplink

CMB Downlink

DPX MS

RIA CU ALI

DC MS

LNA DL Downlink

123 4

CHA1

(2 ch.)

Mobile station

antenna

CHA2

(2 ch.)

CHA3

(2 ch.)

PSU

Base station

CHA4

(2 ch.)

antenna

567 8

CHA5

(2 ch.)

DC BS

CHA6

(2 ch.)

CMB

Uplink

CHA7

(2 ch.)

DPX

CHA8

(2 ch.)

Figure 5-1. Channel selective GSM repeater

A cabinet (the left part in Figure 5-1) for a channel selective GSM

repeater can be equipped with four CHA channel boards, two downlink boards (DL) with two internal channels each and two uplink boards (UL) with two internal channels each. The described cabinet has a capacity of four bi-directional GSM channels.

The cover (the right part in Figure 5-1) can be equipped as well, which gives up to eight GSM channels. The cover board positions are shown in the figure.

Channel selective GSM repeaters are used for GSM, DCS and PCS types of TDMA systems.

Main units: ALI Alarm Interface board

CHA Channel Selective Amplifier board, GSM type CMB Combiner unit CU Control Unit board DC Directional Coupler DPX Duplex filter LNA Low Noise Amplifier PSU Power Supply Unit RIA Repeater to Repeater Interface Adapter (optional)

5 - 4 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

Channel Selective CDMA Repeater

LNA UL Uplink

DPX MS

ALI

DC MS

LNA DL Downlink

123 4

CSA

(2 carr.)

Mobile station

antenna

PA DL

CSA

(2 carr.)

PSU

Base station

PA UL

antenna

567 8

CSA

(2 carr.)

DC BS

PA DL

DPX

CSA

(2 carr.)

PA UL

Figure 5-2. Channel selective CDMA repeater

A cabinet (the left part in Figure 5-2) for a channel selective CDMA

repeater can be equipped with two pair of CSA and PA boards, one pair for downlink (DL) and one pair for uplink (UL). The described cabinet has a capacity of two bi-directional CDMA carriers.

The cover (the right part in Figure 5-2) can be equipped as well. The cover board positions are shown in the figure.

CSA boards are used for IS-95 or J-STD-008 types of CDMA systems.

Main units: ALI Alarm Interface board

CSA Channel Selective Amplifier board, CDMA type CU Control Unit board DC Directional Coupler DPX Duplex filter LNA Low Noise Amplifier PA Power Amplifier board PSU Power Supply Unit

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 5

Functional Description AR Repeaters ALLGON Syst em AB

Channel Selective High Power CDMA Repeater

LNA UL Uplink

DPX BS

ALI

DC BS

LNA DL Downlink

123 4

CSA

(2 carr.)

Base station

antenna

PA DL

CSA

(2 carr.)

PSU1

Mobile station

antenna

PA UL

5678

BA DL

PSU2

DC MS

DPX

Figure 5-3. High power CDMA repeater

A cabinet (the left part in Figure 5-3) for a channel selective high power

CDMA repeater can be equipped with two pair of CSA and PA boards, one pair for downlink (DL) and one pair for uplink (UL). The described cabinet has a capacity of two bi-directional CDMA carriers.

The cover (the right part in Figure 5-3) is equipped with the BA board. There is also a heat sink element on the outside of the cover, not shown in Figure 5-3.

Note that this repeater type has opposed positions of the BS and MS antenna inputs and DC units compared to all the other repeater types.

CSA boards are used for IS-95 or J-STD-008 types of CDMA systems.

Main units: ALI Alarm Interface board

BA Booster Amplifier board CSA Channel Selective Amplifier board, CDMA type CU Control Unit board DC Directional Coupler DPX Duplex filter LNA Low Noise Amplifier PA Power Amplifier board PSU1,2 Power Supply Unit 1 and 2

5 - 6 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

Band Selective Repeater

LNA UL Uplink

DPX MS

RIA CU ALI

DC MS

LNA DL Downlink

123 4

BSA

Mobile station

antenna

PA DL

BSA

PSU

Base station

PA UL

antenna

567 8

BSA

DC BS

PA DL

DPX

BSA

PA UL

Figure 5-4. Band selective repeater

A cabinet (the left part in Figure 5-4) for a band selective repeater is

equipped with two pair of BSA and PA boards, one pair for downlink (DL) and one pair for uplink (ULS). The described cabinet is equipped for bi-directional band selective operation.

The cover (the right part in Figure 5-4) can be equipped as well. The cover board positions are shown in the figure.

BSA boards are used for band selective systems either with a fixed band width of 900MHz or an adjustable band width.

Main units: ALI Alarm Interface board

BSA Band Selective Amplifier board, fixed or adjustable band width CU Control Unit board DC Directional Coupler DPX Duplex filter LNA Low Noise Amplifier PA Power Amplifier board PSU Power Supply Unit RIA Repeater to Repeater Interface Adapter (optional)

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 7

Functional Description AR Repeaters ALLGON Syst em AB

Combined Repeater

LNA UL Uplink

CMB Downlink

DPX MS

RIA CU

ALI

DC MS

LNA DL Downlink

1234

CHA1

(2 ch.)

Mobile station

antenna

CHA2

(2 ch.)

CHA3

(2 ch.)

PSU1

Base station

CHA4

(2 ch.)

antenna

LNA UL Uplink

LNA DL Downlink

567 8

BSA

PA DL

PSU2

CMB

Uplink

BSA

PA UL

DPX

Figure 5-5. Combined repeater

Figure 5-5 shows an example of a combined channel selective and band

selective repeater. The channel selective part is located in the cabinet and the band selective part in the cover.

This example has four bi-directional GSM channels and band selective operation.

Any combinations of channel selective GSM part (page 5-4), channel selective CDMA part (page 5-5) and band selective part (page 5-7) can be mixed.

Main units: ALI Alarm Interface board

BSA Band Selective Amplifier board, fixed or adjustable band width CHA Channel Selective Amplifier board, GSM type CMB Combiner unit CU Control Unit board DC Directional Coupler DPX Duplex filter LNA Low Noise Amplifier PA Power Amplifier board PSU1,2 Power Supply Unit 1 and 2 RIA Repeater to Repeater Interface Adapter (optional)

5 - 8 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

Block Diagram

The following block diagrams are found in this section:

• Channel selective GSM repeater, Figure 5-6 on page 5-10.

• Channel selective CDMA repeater, Figure 5-7 on page 5-12.

• Band selective repeater, Figure 5-8 on page 5-14.

The main signal paths for the repeater types are described under the block diagrams.

Before the block diagrams are shown, the downlink and uplink signal paths are described below.

Alarm is described on page 5-16.

Repeater setup is described on page 5-16.

Downlink Signal Path

Uplink Signal Path

The downlink signal path, i.e. from the base station through the repeater

to the mobile station, is described for channel selective GSM operation, channel selective CDMA operation, and band selective operation under the block diagrams on the following pages.

The uplink signal path, i.e. from the mobile station through the repeater

to the base station, is identical to the downlink path the other way round. Only some levels and component values differ.

The high power CDMA repeater has, however, a booster amplifier in the downlink path only.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 9

Functional Description AR Repeaters ALLGON Syst em AB

Channel Selective GSM Repeater

TEST -30 dB

BS antenna

Base station

MSC

Telephone line

Modem

CHANNEL SELECTIVE GSM REPEATER

DC BS

ANT OUT

MS -20 dB

DPX

ANT

RCU

Modem

Battery

P27 P32

PSU

P101

CHA1 - DL

CMB

P701

LNA

OUT1

CHA2 - DL

DC MS

TEST -30 dB

MS antenna

OUT2

P101

P701

DPX

CMB

P701

CHA3 - UL

P101

LNA

OUT1

OUT ANT

ANT

CHA4 - UL

P101

OUT2

RIA

P34

ALLGON

ALL

ALI

P701

ALI

P31

P33

ALLGON

R2R net

ALL

External alarm sensors

Figure 5-6. Block diagram, channel selective repeater

Figure 5-6 shows a block diagram of a channel selective repeater with four

bi-directional channels. This diagram is applicable to repeaters for the GSM, DCS, PCN and GSM 1900 (PCS) systems.

Downlink signal path

The signal from the base station is received via the repeater BS antenna and is then forwarded through a directional coupler (DC). The signal passes a duplex filter (DPX), is amplified in a low noise amplifier (LNA), and enters the channel boards (CHA), which have two parallel channels each.

5 - 10 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

The first mixer stage on the CHA amplifier board, which is controlled by a synthesizer, converts the received frequency down to the IF frequency. The signal is then filtered by SAW bandpass filters and, not shown in the figure, amplified before it is fed to the second mixer stage for conversion back to the original frequency.

The output signal from the mixer is then amplified in the power amplifier

and fed to a combiner, which combines the signals from the two channels on the channel board.

The output signal passes a combiner (CMB), a duplex filter (DPX), and a directional coupler (DC), before it is fed to the repeater MS antenna.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 11

Functional Description AR Repeaters ALLGON Syst em AB

Channel Selective CDMA Repeater

TEST -30 dB

BS antenna

Base station

MSC

Telephone line

Modem

CHANNEL SELECTIVE CDMA REPEATER

DC BS

ANT OUT HI

MS -20 dB

DPX

ANT

RCU

Modem

Battery

P27

PSU1

LNA - DL

IN OUT1 P101 P301

PA - DL

P4 P5 P3 P4

PA - UL

CSA - UL

P301

P32

ALI

CSA - DL

P101

P31

P4P5

OUT1

LNA - UL

High power CDMA only

PSU2

DPX

ANT

ALI

P33

DC MS

ANTOUT

TEST -30 dB

MS antenna

External alarm sensors

Figure 5-7. Block diagram, CDMA repeater

Figure 5-7 shows a block diagram of a channel selective CDMA repeater.

This diagram is applicable only to repeaters for the CDMA system.

Downlink signal path

5 - 12 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

The first mixer stage on the CSA amplifier board, which is controlled by a synthesizer, converts the received frequency down to the IF frequency. The signal is then filtered by SAW bandpass filters and, not shown in the figure, amplified before it is fed to the second mixer stage for conversion back to the original frequency.

The following power amplifier is controlled by the CU. The output gain

can be reduced to avoid instability due to poor antenna isolation.

The output signal from the power amplifier is fed to a combiner, which combines the signals from the two channels on the channel board.

A detector on the PA board measures continuously the output level. The signal from this detector is used by the automatic gain control, AGC, to supervise and, if necessary, reduce the output power to keep it under a maximum level. The AGC gain control affects several of the amplification stages.

BA in high power CDMA

repeaters only.

In high power CDMA repeaters, a booster amplifier (BA) boosts the output downlink signal by typically 6dB. The BA amplifier is powered by a high power PSU2. Note that the booster amplifier (BA) is only present in the downlink path, and only in high power CDMA repeaters.

The output signal passes a duplex filter (DPX) and a directional coupler (DC) before it is fed to the repeater MS antenna.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 13

Functional Description AR Repeaters ALLGON Syst em AB

Band Selective Repeater

TEST -30 dB

BS antenna

Base station

MSC

Telephone line

Modem

BAND SELECTIVE REPEATER

DC BS

ANT OUT

MS -20 dB

DPX

ANT

RCU

Modem

Battery

P27

PSU

LNA - DL

IN OUT1 P101 P301

PA - DL

P4 P5

PA - UL

BSA - UL

P301

P32

ALI

P101

P31

BSA - DL

P4P5

LNA - UL

OUT1

TEST -30 dB

MS antenna

DPX

ANT

RIA

DC MS

ANTOUT

P34

ALLGON

ALL

ALI

P33

ALLGON

R2R net

ALL

External alarm sensors

Figure 5-8. Block diagram, band selective repeater

Figure 5-8 shows a block diagram of a band selective repeater. This

diagram is applicable to repeaters for e.g. NMT, TACS, ETACS, AMPS, DAMPS and CDMA systems.

Downlink signal path

5 - 14 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

The first mixer stage on the BSA amplifier board, which is controlled by a synthesizer, converts the received frequency down to the IF frequency. The signal is then filtered by SAW bandpass filters and, not shown in the figure, amplified before it is fed to the second mixer stage for conversion back to the original frequency.

The SAW filter can be either fixed or adjustable depending on the BSA

board used. If the BSA board has fixed band width, this SAW filter is fixed and selected for the current band width. If the BSA board has adjustable band width, the SAW filter combination can be software changed from within OMT32 (or OMS) to cover various band widths.

The following power amplifier is controlled by the CU. The amplifier gain will be reduced to avoid instability due to poor antenna isolation.

The output signal passes duplex filter (DPX) and a directional coupler (DC) before it is fed to the repeater MS antenna.

RCU

R2R

The optional RCU Remote Communication Unit is located inside the

repeater (described in Chapter 6, Optionals).

Communication with the base station is performed by means of a built-in mobile feature that has the antenna connected to the BS directional coupler (DC). Data is transferred between the repeater and the built-in RCU unit via the P32 modem port.

The RCU unit is powered via the P27 auxiliary port and the unit has a battery with capacity to send a number of alarms if a mains power failure occurs.

The Repeater to Repeater Link feature makes it possible to communicate

with a number of repeaters via one RCU unit in one of the repeaters in an R2R net. Several RCU units can also be used in the same net.

The repeaters in the R2R net are connected to the P34 port.

The R2R feature is described in Chapter 6, Optionals.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 15

Functional Description AR Repeaters ALLGON Syst em AB

Alarm

Alarm signals from external sensors are received by the ALI board, which

forwards the alarm signals to the CU board.

The software on the CU board is able to activate acoustic or visual alarm or direct the alarm to the P33 alarm port to be forwarded, via the RCU unit, to OMT32 (or OMS) located in an operation and maintenance central.

Alarms can be configured from OMT32 (or from OMS).

Repeater Setup

The repeater parameters can be set locally by means of a desktop or

notebook loaded with the OMT32 software (or the OMS software). The PC or notebook is connected to the CU via the P31 PC port (see Figure 5-6, Figure 5-7 and Figure 5-8).

The repeater parameters can also be set remotely by means of a phone (mobile or via a telephone line) and a modem connected to the CU board via the P32 modem port (see Figure 5-6, Figure 5-7 and Figure 5-8).

5 - 16 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

Board and Unit Descriptions

Cabling between boards and units is found on page 5-27.

DC - Directional Coupler

The BS and MS directional couplers, see Figure 5-9, are identical for all

repeaters except for the high power CDMA repeaters, which has BS and MS directional couplers depiced in Figure 5-10 (BS) and Figure 5-11 (MS).

DPX

TEST

-30 dB

-20 dB

ANT

Figure 5-9. MS and

BS directional coupler

Figure 5-10. BS

directional coupler,

high power CDMA

DPX

TEST

-30 dB

MRX

-20 dB

ANT

DPX

TEST

-30 dB

MRX

ANT

Figure 5-11. MS directional coupler, high power CDMA

Connection

DC/MS:

Port Connected to

DPX ANT on the DPX/MS duplex filter.

TEST –30dB Test port for the downlink output signal. This port has

no directivity. MS –20dB Not used. MRX DC-BS on the MRX unit (high power CDMA only). ANT MS antenna.

DC/BS:

Port Connected to

DPX ANT on the DPX/BS duplex filter. TEST –30dB Test port for the uplink output signal. This port has no

directivity. MS –20dB Mobile station antenna connection for remote control.

This port has at least 20dB directivity towards the

antenna. MRX DC-MS on the MRX unit (high power CDMA only). ANT BS antenna.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 17

Functional Description AR Repeaters ALLGON Syst em AB

DPX - Duplex Filter

The DPX duplex filters on the BS and MS sides are identical.

Connection

DPX/MS:

Port Connected to

ANT DPX on the DC/MS directional coupler. HI Channel selective GSM repeater:

Output on the CMB/DL combiner (at 4 channels), P701 on the CHA1/DL channel board (at 2 channels).

Channel selective CDMA repeater:

P5 on the PA/DL board.

Channel selective high power CDMA repeater:

P4 on the BA board in the cover.

Band selective repeater:

P5 on the PA/DL board.

LO IN on the LNA/UL low noise amplifier.

DPX/BS:

Port Connected to

ANT DPX on the DC/BS directional coupler. HI IN on the LNA/DL low noise amplifier. LO Channel selective GSM repeater:

Output on the CMB/UL combiner (at 4 channels), P701 on the CHA3/UL channel board (at 2 channels)

Channel selective CDMA repeater:

P5 on the PA/UL board.

Channel selective high power CDMA repeater:

P5 on the PA/UL board.

Band selective repeater:

P5 on the PA/UL board.

5 - 18 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

LNA - Low Noise Amplifier

The LNA low noise amplifiers are located in the outermost boxes at the

top of the cabinet and large cover (see Figure 5-1 to Figure 5-5 on page 5-4 to 5-8). LNA/UL (uplink) is located to the left and LNA/DL (downlink) to the right. All coaxial connectors are SMA type.

OUT

LNA UL

IN ATT +7V OUT1 OUT2

LOW

Figure 5-12. LNA low noise amplifier

Signals from the duplex filter output is fed to the LNA input connector IN. Output OUT1 and OUT2 feed the CHA boards of the same signal direction. The signal level in these connectors are +20dB referred to the antenna input. Another output, OUT LOW, is an expansion output for an additional LNA amplifier, if the repeater is equipped in the cover part of the chassis. The gain to this connector is +2dB.

LNA DL

OUT LOW

IN+7V ATTOUT1 OUT2

The +7V input is used for 7V supply from the DIA board.

ATT is a control signal for a controllable attenuator in the LNA.

Connection

To the left in the cabinet LNA/UL:

Port Connected to

OUT LOW IN on the LNA/UL in the cover if equipped. IN LO on the DPX/MS duplex filter. ATT P23 on the DIA board. +7V P23 on the DIA board. OUT1 P101 on the CHA3/UL or CSA/UL or BSA/UL board. OUT2 P101 on the CHA4/UL channel board.

To the right in the cabinet LNA/DL:

Port Connected to

OUT LOW IN on the LNA/DL in the cover if equipped. IN HI on the DPX/BS duplex filter. ATT P24 on the DIA board. +7V P24 on the DIA board. OUT1 P101 on the CHA1/DL or CSA/DL, or BSA/DL board. OUT2 P101 on the CHA2/DL channel board.

Not used outputs do not need to be terminated.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 19

Functional Description AR Repeaters ALLGON Syst em AB

CHA - Channel Amplifier Board for Channel Selective Operation

The cabinet can be equipped with four CHA Channel Amplifier boards.

These are numbered from left to right: CHA1 - CHA4. The board positions CHA1 - CHA2 are used for downlink and CHA3 - CHA4 for uplink (see Figure 5-1 on page 5-4). If the repeater is equipped with two channels only, the board positions 1 and 3 are used.

The two internal channels on each CHA board are located to the left and to the right on the board.

If a board is to be removed, the RFI filter at the board connector and the two coaxial connectors must be removed prior to the board removal. No heat compound is used on the heat sink body or on the chassis.

Coaxial connector P101 is the input of the CHA board fed from the LNA.

Coaxial connector P701 is the output of the board. The output signal is fed to the duplex filter, either directly or via a CMB combiner, depending on the repeater configuration.

Connection

Board #1 from left CHA1/DL:

Port Connected to

P101 OUT1 on the LNA/DL low noise amplifier. P701 4 channels: Input on the CMB/DL combiner.

Board #2 from left CHA2/DL:

Port Connected to

P101 OUT2 on the LNA/DL low noise amplifier. P701 Input on the CMB/DL combiner.

Board #3 from left CHA3/DL:

Port Connected to

P101 OUT1 on the LNA/UL low noise amplifier. P701 4 channels: Input on the CMB/UL combiner.

Board #4 from left CHA4/DL:

Port Connected to

P101 OUT2 on the LNA/UL low noise amplifier. P701 Input on the CMB/UL combiner.

2 channels: HI on the DPX/MS duplex filter.

2 channels: LO on the DPX/BS duplex filter.

Caution

The CHA Channel Amplifier board power transistors contain beryllium oxide (BeO) that is poisonous. The power transistors are mounted with two screws as opposed to other transistors. See Chapter 1, Safety.

BERYLLIUM OXIDE

5 - 20 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

CSA and PA Boards for Channel Selective CDMA Operation

For channel selective CDMA operation, the cabinet is normally equipped

with two CSA and two PA boards. These are numbered from left to right. Board position 1 is used for CSA downlink board, position 2 for PA downlink board, position 3 for CSA uplink board, and position 4 for PA uplink board (see Figure 5-2 on page 5-5).

If a board is to be removed, the RFI filter at the board connector, the two coaxial connectors, and the flat conductor cable between the CSA board and the PA board must be removed prior to the board removal. No heat compound is used on the heat sink body or on the chassis.

Coaxial connector P101 is the input of the CSA board fed from the LNA.

Coaxial connector P301 is the output of the CSA board. The signal from this output is fed to the PA board input P4. The PA board output P5 is fed to the duplex filter of the same signal direction.

Connection

Board #1 from left CSA/DL:

Port Connected to

P101 OUT1 on the LNA/DL low noise amplifier. P301 P4 on the PA/DL board.

Board #2 from left PA/DL:

Port Connected to

P4 P301 on the CSA/DL board. P5 Channel selective high power CDMA repeater:

Board #3 from left CSA/UL:

Port Connected to

P101 OUT1 on the LNA/UL low noise amplifier. P301 P4 on the PA/UL board.

Board #4 from left PA/UL:

Port Connected to

P4 P301 on the CSA/UL board. P5 LO on the DPX/BS duplex filter.

P3 on the BA board in the cover.

All other repeater types:

HI on the DPX/MS duplex filter.

Caution

The PA Power Amplifier board power transistors contain beryllium oxide (BeO) that is poisonous. The power transistors are mounted with two screws as opposed to other transistors. See Chapter 1, Safety.

BERYLLIUM OXIDE

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 21

Functional Description AR Repeaters ALLGON Syst em AB

BSA and PA Boards for Band Selective Operation

For band selective operation, the cabinet is equipped with two BSA and

two PA boards. These are numbered from left to right. Board position 1 is used for BSA downlink board, position 2 for PA downlink board, position 3 for BSA uplink board, and position 4 for PA downlink board (see Figure 5-4 on page 5-7).

If a board is to be removed, the RFI filter at the board connector, the two coaxial connectors, and the flat conductor cable between the BSA board and the PA board must be removed prior to the board removal. No heat compound is used on the heat sink body or on the chassis.

Coaxial connector P101 is the input of the BSA board fed from the LNA.

Coaxial connector P301 is the output of the BSA board. The signal from this output is fed to the PA board input P4. The PA board output P5 is fed to the duplex filter of the same signal direction.

Connection

Board #1 from left BSA/DL:

Board #2 from left PA/DL:

Board #3 from left BSA/UL:

Board #4 from left PA/UL:

Caution

BERYLLIUM OXIDE

Port Connected to

P101 OUT1 on the LNA/DL low noise amplifier. P301 P4 on the PA/DL board.

Port Connected to

P4 P301 on the BSA/DL board. P5 HI on the DPX/MS duplex filter.

Port Connected to

P101 OUT1 on the LNA/UL low noise amplifier. P301 P4 on the PA/UL board.

Port Connected to

P4 P301 on the BSA/UL board. P5 LO on the DPX/BS duplex filter.

5 - 22 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

DIA Board

DIA is a distribution board for most of the boards, units and ports. The

DIA board is exclusively equipped with connectors. The connector types are chosen to prevent unintentional mixing up.

P11 P12 P13 P14

P26

P34

P23

P32

U7F

P27

U7A U7B U7C U26

P28

P33

P5 P3

P4 P2

U7D P22

P31

U7E

P21

P25

P24

GND

Figure 5-13. DIA board connectors and testpoints

Connection and connector types

Port Connected to Connector type

P2 CU board P3 Not used P4 ALI board

P5 Not used P11 CHA1/DL or CSA/DL or BSA/DL 16 pole 1 line female P12 CHA2/DL or PA/DL 16 pole 1 line female P13 CHA3/UL or CSA/UL or BSA/UL 16 pole 1 line female P14 CHA4/UL or PA/UL 16 pole 1 line female P21 PSU - Power Supply Unit 10 pole 2 line male P22 LED board in the cover 4 pole 1 line male P23 LNA/UL 2 pole 1 line male P24 LNA/DL 2 pole 1 line male P25 Expansion output port to cover

circuitry if any. Only in cabinets.

P26 Expansion input port from the

cabinet. Used in equipped large covers only.

P27 AUX1 auxiliary connector 8 pole 1 line male P28 Door switch (internal alarm) 3 pole 1 line male P31 PC (serial RS-232) 9 pole D-sub female P32 Modem (serial RS-232) 9 pole D-sub male P33 External alarm 15 pole D-sub female P34 Repeater to Repeater Link 8 pole RJ45 modular female

Pin 2 and 3 on the P27 connector must be interconnected with a jumper

if the connector is not used.

16 pole 2 line male

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 23

Functional Description AR Repeaters ALLGON Syst em AB

Testpoints

Testpoint Voltage Purpose

U7A +7V DC CHA1/DL or CSA/DL or BSA/DL downlink

board supply voltage.

U7B +7V DC CHA2/DL or PA/DL downlink board supply

voltage.

U7C +7V DC CHA3/UL or CSA/UL or BSA/UL downlink

board supply voltage.

U7D +7V DC CHA4/UL or PA/UL downlink board supply

voltage.

U7E +7V DC LNA/UL and LNA/DL and P27 auxiliary port

supply voltage.

U7F +7V DC CU board and ALI board and RCU supply

voltage via the P27 auxiliary port jumper.

U26 +26V DC

+13V DC

+10V DC

GND 0 Ground

Power amplifiers and P27 auxiliary port supply voltage (26V, 13V or 10V depending on the repeater type).

DIA board part # and version

The DIA board part # is K105/1. Version R2A or higher (containing the P34 connector) is required to use the optional Repeater to Repeater Link feature.

5 - 24 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

CU Control Unit Board

The CU board is the central board in the repeater, located in the repeater

cabinet. The CU board contains a microprocessor, main memory, flash memory for the CU software, EEPROM memory for parameters, memory for the event log and statistics, a REFO reference oscillator, ports for local and remote communication, battery powered real-time clock, etc.

The CU board is used to supervise and control operational parameters such as gain control, channel handling, etc. The CU takes care of alarms and the event log, password and logon, and many other procedures.

The CU is also a control interface when using an OMT32/PC or OMS/PC, locally or remotely via modem.

The CU software can be downloaded from an OMT32/PC or OMS/PC, either locally or remotely.

The real-time clock on the CU board is used for alarm and for the event log.

There are currently two CU board variants: K103/1 and K103/2.

CU board and CU software part #s

K103/1 CU board (old)

K103/2 CU board (current) CU board K103/2 can be run with either the old SA102 01/2 CU software

CU board K103/1 can be run with the SA102 01/2 CU software. This board can store one version of CU software. The repeater will always boot on this software version.

or the current SA102 02/1 or SA102 02/2 CU software. This board can store two versions of CU software, located in segment 1 and segment 2 of the flash memory as Application 1 and Application 2. The repeater will boot on that software which is set as Primary (description of Primary application is found in the OMT32, User’s Manual).

Compatibility for CU boards and CU software is detailed in the next section.

Connection

The CU board is connected to the DIA board via the P2 port.

Caution

A lithium battery is permanently mounted on the CU board. Due to the risk of explosion, this battery must not be removed from the board. In case of battery malfunction, replace the CU board. The old CU board can be sent to Allgon for repair.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 25

Functional Description AR Repeaters ALLGON Syst em AB

Repeater CU Software and Hardware Compatibility

There are different versions of repeater CU software, which can be

combined with boards of various revisions. These have unique part numbers and revision information. Below, you will find a table of repeater software currently available in combination with CU board revisions.

CU Software Part #

SA102 01/2 R2E K103/1

Latest Software Revision

Compatible with CU board

K103/2

Comments

For GSM channel selective ≤ 4 channels, band selective 800-900MHz fixed band width only, and combi (800/900MHz). No traffic statistics.

SA102 02/1 R3A K103/2 For GSM, EGSM, DCS,

PCS channel selective ≤ 8 channels, band selective 800-900MHz fixed or adjustable band width, band selective 1800MHz or 1900MHz and combi. Supports R2R link.

SA102 02/2 R2A K103/2 For 800/1900MHz CDMA

≤ 4 channels.

This information is updated 2000-10-01. As new versions of hardware and software are released without prior noticing, contact your Allgon sales representative if in doubt about the latest revision status.

For detailed information, refer to the release notes for the CU software to be downloaded (normally found in the readme.txt file, which is supplied with the program files).

5 - 26 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

Cabling

On the following pages, you will find cabling information for the various

repeater types:

• Channel selective GSM repeater, 2 channels (page 5-28).

• Channel selective GSM repeater, 4 channels (page 5-29).

• Channel selective CDMA repeater (page 5-30).

• Channel selective high power CDMA repeater (page 5-31).

• Band selective repeater (page 5-32).

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 27

Functional Description AR Repeaters ALLGON Syst em AB

Channel Selective GSM Repeater, 2 Channels

DPX

ANT

LO HI

ATT +7V OUT1 OUT2

OUT

LNA

LOW

P101 P101

CHA1/DL CHA3/UL

P701 P701

116 116

116

DOOR

P28

P32

MS DC

OUT

TEST 1

IN/OUT

ANT

P33

P26

P23 LNA

MODEM

EXT LARM

1 X U A

161 161 116

1 0

LNA

OUT1 OUT2 +7V ATT

ANT

DPX

OUT

LOW

P22 LED

PC P31

P25

2 1

P24 LNA

PSU P21

OUT

TEST 1

IN/OUT

ANT

Power Supply Unit

Figure 5-14. Cabling, GSM repeater - 2 ch.

Figure 5-14 shows a repeater equipped with the two channel boards CHA1/DL and CHA3/UL for two bi-directional GSM channels.

5 - 28 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

Channel Selective GSM Repeater, 4 Channels

DPX

ANT

CMB

LO HI

ATT +7V OUT1 OUT2

OUT

LNA

LOW

LNA

OUT1 OUT2 +7V ATT

P101 P101 P101 P101

CHA1/DL CHA2/DL CHA3/UL CHA4/UL

P701 P701 P701 P701

116

P26

2 1

P23 LNA

OUT

MODEM

TEST 1

1 X

U A

IN/OUT

ANT

DOOR

P28

3 1

P32

P33

EXT LARM

161 161 116

1 0

ANT

DPX

OUT

LOW

116116116116

P22 LED

PC P31

P25

2 1

P24 LNA DL

PSU P21

OUT

TEST 1

IN/OUT

ANT

Power Supply Unit

BSMS

Figure 5-15. Cabling, GSM repeater - 4 ch.

Figure 5-15 shows a channel selective repeater equipped with the channel boards CHA1/DL, CHA2/DL, CHA3/UL, and CHA4/UL for four bi-directional GSM channels.

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 29

Functional Description AR Repeaters ALLGON Syst em AB

Channel Selective CDMA Repeater

ANT

LNA

CSA/DL

P301

116

P26

P23

LNA

OUT

MODEM

TEST 1

1 X

U A

IN/OUT

ANT

DPX

P101

P32

OUT LOW

DOOR

P28

3 1

P33

EXT LARM

0 1

ATT +7V OUT1 OUT2

DPX

ANT

LNA

OUT1 OUT2 +7V ATT

OUT

LOW

P101

PA/DL

CSA/UL

PA/UL

P301

161 161 116

1 0

P22 LED

PC P31

P25

2 1

P24 LNA

PSU P21

OUT

TEST 1

IN/OUT

ANT

Power Supply Unit

BSMS

Figure 5-16. Cabling, CDMA repeater - 2 ch.

Figure 5-16 shows a channel selective CDMA repeater equipped with two CSA boards and two PA boards.

5 - 30 Rev. P1A 2000-09 User’s Manual VD203 66/EN

ALLGON System AB AR Repeaters Functional Description

Channel Selective High Power CDMA Repeater

ANT

LNA

CSA/DL

P301

116

P26

2 1

P23 LNA

DPX

OUT

TEST

-30 dB

TEST 1

1 X

MRX

U A

IN/OUT

-20 dB

ANT

P32

MODEM

DPX

P101

OUT LOW

DOOR

P28

3 1

EXT LARM

0 1

P33

ATT +7V OUT1 OUT2

DPX

ANT

LNA

OUT1 OUT2+7V ATT

P101

PA/DL

CSA/UL

OUT

LOW

PA/UL

BA/DL

P301

161 161 116

1 0

P22 LED

PC P31

P25

P24 LNA

DPX

OUT

TEST

PSU P21

-30 dB

TEST 1

MRX

IN/OUT

ANT ANT

Power Supply Unit

Figure 5-17. Cabling, high power CDMA repeater - 2 ch.

Figure 5-17 shows a channel selective high power CDMA repeater equipped with two CSA boards, two PA boards and a BA board (in the cover).

User’s Manual VD203 66/EN Rev. P1A 2000-09 5 - 31

Functional Description AR Repeaters ALLGON Syst em AB

Band Selective Repeater

LNA

BSA/DL

P301

116

P26

P23 LNA

OUT

MODEM

TEST 1

1 X

U A

IN/OUT

ANT

DPX

ANT

LO HI

ATT +7V OUT1 OUT2

OUT LOW

P101

PA/DL

BSA/UL

P301

DOOR

P28

P32

P33

EXT LARM

161 161 116

1 0

P101

DPX

ANT

LNA

OUT1 OUT2+7V ATT

OUT

LOW

PA/UL

P22 LED

PC P31

P25

2 1

P24 LNA

PSU P21

OUT

TEST 1

IN/OUT

ANT

Power Supply Unit

BSMS

Figure 5-18. Cabling, band selective repeater

Figure 5-18 shows a band selective repeater equipped with two BSA boards and two PA boards.

5 - 32 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Optionals

. Optionals

This chapter describes the following optional accessories available for the Allgon repeaters:

• RCU, Remote Control Unit for GSM 900, page 6-2.

• RCU, Remote Control Unit with PCMCIA Modem, page 6-4.

• OMS, Operation and Maintenance System, page 6-8.

• Traffic Statistics, page 6-8.

• Battery Backup, page 6-8.

• Fiber Optic Interface, page 6-8.

• 7/16" Antenna Cable Connectors, page 6-8.

• R2R, Repeater To Repeater Link, page 6-9.

User’s Manual VD203 66/EN Rev. P1A 2000-09 6 - 1

Optionals AR Repeaters Allgon Systems AB

RCU, Remote Control Unit for GSM 900

As the mobile phone technology is developing very fast, this RCU may be

modified after issuing this manual. New types may also have been added. For the latest details, please contact your local Allgon representative.

For remote control of Allgon repeaters in the GSM 900 system an RCU Remote Control Unit is available as a kit. This kit contains an integrated mobile phone/modem, power supply and power supply backup. A detailed installation guide is also included in the RCU kit.

The RCU for the GSM system is mounted inside the repeater cabinet, in front of the PSU (see Figure 6-1).

DPX

TEST

-30 dB MS

-20 dB

ANT

12volt 0.7Ah

DPX

TEST

-30 dB MS

-20 dB

ANT

Figure 6-1. RCU - GSM 900 type

The RCU is connected to the P27, P32, and MS -20dB ports as described in the Connection section in Chapter 3.

6 - 2 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Optionals

RCU kit items

The item numbers refer to the numbers in Figure 6-1.

1. The GSM board. Press a pencil or similar object on the small button

adjacent to the SIM board to release it.

2. LED indicator on the M1 phone/modem unit which shows three

operational modes: Out: The unit is off Slow flashing: Stand by Fast flashing: Connection in progress

3. Green LED on the battery charger which is lit with a steady light

when the power supply is OK, either from the mains or from the battery.

4. Yellow LED on the battery charger which is lit with a steady light

during battery charge from the mains.

Do not forget to put a jumper between pin 2 and 3 on the P27 connector if you disconnect the RCU.

GSM subscriber conditions

• Data transmission, 9600 bps (baud)

• Transparent mode

• If the PIN code have to be disabled, use another phone.

If you get problems with the PIN code, please contact Allgon Technical Support.

Power supply backup

If a power failure occurs, the backup battery has capacity to supply the

CU, ALI and phone/modem for 30 minutes at room temperature and a limited number of call attempts.

The battery life is 1 - 2 years at normal indoor temperature. If the operational temperature is higher, the battery life is shortened.

Power supply battery type

12V, 0.7A/20h, lead, sealed, including cable and JST VHR-2N connector.

Part # Allgon: PM291 09/1

Hitachi: HP0.7-12P (VHR-2N) Yuasa: NP0.8-12

User’s Manual VD203 66/EN Rev. P1A 2000-09 6 - 3

Optionals AR Repeaters Allgon Systems AB

RCU, Remote Control Unit with PCMCIA Modem

As the mobile phone technology is developing very fast, this RCU may be

modified after issuing this manual. New types may also have been added. For the latest details, please contact your local Allgon representative.

For remote control of Allgon repeaters in various systems, two PCMCIA modem based RCU Remote Control Units are available as kits.

These are:

• RCU Kit for PCMCIA - Fixed Wire Line Connection

• RCU Kit for PCMCIA - Wireless Connection

These RCUs are basically two similars, but the Fixed Wire Line Connection kit does not include accessories for a mobile phone.

Detailed installation guides are included in the RCU kits.

RCU Kit for PCMCIA - Fixed Wire Line Connection

This kit contains a PCMCIA card host, power supply, and power supply backup.

Most Hayes compatible PCMCIA card modems (not included in the kit) can be used.

RCU Kit for PCMCIA - Wireless Connection

This kit contains a PCMCIA card host, power supply, power supply backup, mobile phone bracket, battery charger, charging cable, and mobile phone antenna cable.

The following mobile phones have been tested together with a DC23 type modem and are thus recommended by Allgon:

– Ericsson PH388 in DCS/PCN 1800MHz system – Ericsson GH388 in GSM 1900MHz system

Power supply backup

If a power failure occurs, the included backup battery has capacity to supply the CU, ALI and the modem. For the Wireless Connection type, this is applicable provided the specified configuration of mobile phone and PCMCIA modem is used.

The battery life is 1 - 2 years at normal indoor temperature. If the operational temperature is higher, the battery life is shortened.

6 - 4 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Optionals

RCU for Fixed Wire Line Connection

The RCU for Fixed Wire Line Connection is mounted inside the repeater

cabinet, in front of the PSU (see Figure 6-2).

DPX

TEST

-30 dB MS

-20 dB

ANT

12volt 0.7Ah

DPX

TEST

-30 dB MS

-20 dB

ANT

Figure 6-2. RCU - Fixed Wire Line PCMCIA type

The RCU is connected to the P27 and P32 ports as described in the Connection section in Chapter 3.

A free strain relief bushing at the bottom of the repeater is used for the external telephone line cable.

RCU kit items - Fixed Wire Line Connection

The item numbers refer to the numbers in Figure 6-2.

1. PCMCIA modem card host.

2. PCMCIA modem card (not included in the kit).

3. Green LED on the battery charger which is lit with a steady light

when the power supply is OK, either from the mains or from the battery.

4. Yellow LED on the battery charger which is lit with a steady light

during battery charge from the mains.

Do not forget to put a jumper between pin 2 and 3 on the P27 connector if you disconnect the RCU.

User’s Manual VD203 66/EN Rev. P1A 2000-09 6 - 5

Optionals AR Repeaters Allgon Systems AB

RCU for Wireless Connection

The RCU base unit for Wireless Connection is mounted inside the

repeater cabinet, in front of the PSU (see Figure 6-3).

OUT

IN ATT +7V OUT1 OUT2

LNA

LOW

LNA DL

OUT LOW

IN+7V ATTOUT1 OUT2

DPX

TEST

-30 dB MS

-20 dB

ANT

12volt 0.7Ah

DPX

TEST

-30 dB MS

-20 dB

ANT

Figure 6-3. RCU - Wireless PCMCIA type

The bracket for the mobile phone is mounted in the upper right corner of the cabinet. The mobile phone is placed in the phone holder.

The RCU is connected to the P27 and P32 ports as described in the Connection section in Chapter 3.

The mobile phone antenna is connected to the MS -20dB port on the BS directional coupler (DC) located to the right in the cabinet.

The mobile battery charger is connected to the mobile phone.

6 - 6 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Optionals

RCU kit items - Wireless Connection

The item numbers refer to the numbers in Figure 6-3.

1. PCMCIA modem card host.

2. PCMCIA modem card (not included in the kit).

3. Green LED on the battery charger which is lit with a steady light

when the power supply is OK, either from the mains or from the battery.

4. Yellow LED on the battery charger which is lit with a steady light

during battery charge from the mains.

5. Mobile phone (not included in the kit) and the phone holder.

6. Battery charger with cable to the mobile phone.

Do not forget to put a jumper between pin 2 and 3 on the P27 connector if you disconnect the RCU.

User’s Manual VD203 66/EN Rev. P1A 2000-09 6 - 7

Optionals AR Repeaters Allgon Systems AB

OMS, Operation and Maintenance System

The OMS, Operation and Maintenance System is an Allgon software

package for controlling a large repeater fleet by using computers with Windows NT in networks with a common database.

The OMS is capable of operating a large number of repeaters. Multiple modems can be used for several incoming and outgoing parallel activities, such as polling, radio parameter configuration, software downloading, etc.

OMS is an improved OMC, Operation and Maintenance Center. The latter is replaced by the OMS and is no longer subject to further development.

Traffic Statistics

Traffic statistics is available for channel selective GSM 900, GSM 1900

and DCS/PCN 1800 repeaters, provided that the repeaters have the latest CU software versions, the latest CU and CHA boards, and that an OMS is used to poll and view the statistics.

Battery Backup

Battery backup can be arranged by completing the repeater with an

Allgon UPS (Uninterruptible Power Supply). The Allgon UPS has an exterior similar to the repeater which means that it can preferably be mounted adjacent to the repeater.

Fiber Optic Interface

A Fiber Optic Interface that includes transmitter, receiver, alarm board

and power supply is available for all the Allgon repeaters. The fiber optic interface can be adapted for separate uplink and downlink fiber as well as for bi-directional one-fiber distribution.

7/16" Antenna Cable Connectors

A 7/16" antenna cable kit is available for all the Allgon repeaters. This kit

includes 7/16" antenna connectors for uplink and downlink antennas mounted on two repeater cable inlet flanges, and cables and connectors for connection to the DC directional couplers inside the repeater.

6 - 8 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Optionals

R2R, Repeater To Repeater Link

Figure 6-4. Repeater to Repeater Link

The Allgon Repeater to Repeater Link can be used in order to establish a repeater network with up to 13 repeaters, one or several of which can contain a phone line for communication with an OMT32 or an OMS.

Requirements

All Allgon repeaters can be included in a R2R net (see Figure 6-4). Channel selective repeaters, band selective repeaters, and Compact repeaters can be mixed in the same net. For Compact repeaters, the R2R Repeater to Repeater Link feature is standard and requires no extra hardware or software.

AR Repeaters can either be equipped with this feature at the delivery from Allgon, or be completed with a Repeater to Repeater Link Kit, provided the repeaters meet the below requirements.

To be able to use the Repeater to Repeater Link feature, the following DIA board, CU board and CU software is required:

DIA board K105/1 version R2A or higher CU board K103/2 version R1A or higher CU software SA102 02/1 version R3A or higher

The version of the RIA board can be detected remotely by means of the OMT32, see the OMT32, User’s Manual.

Further information and requirements are found in the R2R installation document, R2R, Repeater to Repeater Link Kit, Installation Guide (part # VD202 91/EN).

User’s Manual VD203 66/EN Rev. P1A 2000-09 6 - 9

Optionals AR Repeaters Allgon Systems AB

Installation

The R2R, Repeater to Repeater Link is installed as described in the R2R, Repeater to Repeater Link Kit, Installation Guide.

At least one RCU unit (or telephone line with modem) is required for remote communication.

Configuration

Configuration is described in the OMT32, User’s Manual.

6 - 10 Rev. P1A 2000-09 User’s Manual VD203 66/EN

Allgon Systems AB AR Repeaters Repeater Alarms

. Repeater Alarms

This chapter contains a list of those alarms which are initiated in the repeater and generated by the repeater control circuitry.

Critical, Error and Warning alarms can be sent automatically from a repeater to an OMT32 and OMS and then be stored. These alarms can then be viewed.

The alarm handling and facilities are described in the following manuals:

• OMT32, User’s Manual

• Advanced Repeater OMS, User’s Manual

The table starting on the following page contains those alarms that can be generated by a Compact repeater.

VD203 66/EN - User’s Manual Rev. P1A 2000-09 7 - 1

Repeater Alarms AR Repeaters Allgon Systems AB

Alarm Reference List

The following table contains the internal repeater alarms which can occur

and be shown in the OMT32 and OMS alarm window (additional alarms may have been added to the system after issuing this manual).

Alarm Text Alarm Unit Alarm Level Description

Antenna isolation BSA # UL/DL Warning Poor antenna isolation

Error Poor antenna isolation at lowest gain Ceasing The cause of the alarm has ceased

Chan. # UL/DL Warning Poor antenna isolation

Error Poor antenna isolation at lowest gain

Ceasing The cause of the alarm has ceased Alarm reset CU None Manual alarm reset Battery backup fault External Error Battery backup fault

Ceasing The cause of the alarm has ceased CU battery fault CU Warning CU RAM battery fault

Door open alarm

EEPROM error CU Error EEPROM read or write error Ext REFO error CU Warning An external reference is lost (e.g. GPS reference) External alarm 1 External Configurable External alarm input 1 active more than 1 second

External alarm 2 External Configurable External alarm input 2 active more than 1 second

External alarm 3 External Configurable External alarm input 3 active more than 1 second

External alarm 4 External Configurable External alarm input 4 active more than 1 second

Fiber Optical error External Configurable Fiber optic fault

Gain reduction Chan. # UL/DL Warning The gain is reduced below the limit

High temperature BSA #

Local bus error BSA # Error Communication bus error on BSA board

Log cleared CU None Log memory has been cleared Log memory fault CU Error Log memory fault Logon failed CU None Invalid repeater password Low traffic activity RSSI Statistics Warning No signal strength was above the limit set

Mains breakdown

Mains bkd w backup External Error Mains breakdown - power from battery backup

Modem init failed Remote ctrl None Initiation string to modem not OK

External Configurable Door open more than 30 seconds

CHA # CSA #

CU Warning The CU board temperature is higher than 90°C

CHA # Error Communication bus error on CHA board CSA # Error Communication bus error on CSA board

External Critical Power failure

Ceasing The cause of the alarm has ceased

Ceasing Door closed more than 30 seconds or the alarm is disabled

Ceasing External alarm input 1 no longer active

Ceasing External alarm input 2 no longer active

Ceasing External alarm input 3 no longer active

Ceasing External alarm input 4 no longer active

Ceasing The cause of the alarm has ceased

Warning The board temperature is higher than 85°C

Error The board temperature is higher than 95°C

Ceasing The board temperature has fallen below 70°C

Ceasing The CU board temperature has fallen below 90°C

Ceasing The cause of the alarm has ceased

Ceasing Mains power is up again

Ceasing The cause of the alarm has ceased

7 - 2 Rev. P1A 2000-09 VD203 66/EN - User’s Manual

Allgon Systems AB AR Repeaters Repeater Alarms

Alarm Text Alarm Unit Alarm Level Description

No BCCH detected RSSI Statistics Warning Signal strength on the BCCH channel was below the limit set

Ceasing The cause of the alarm has ceased

No connection Remote ctrl None No connection at callback

Warning No connection at alarm calling

No modem found Remote ctrl None No modem found

Ceasing Modem found

No phone detected Remote ctrl Warning When using a PC-card modem together with the MS this

alarm indicates contact with the PC-card modem but not with the MS. The MS may be turned off.

Ceasing The cause of the alarm has ceased

PA fault BSA # Error Low power amplifier gain

CHA # Error Low power amplifier gain CSA # Error Low power amplifier gain

Param. R/W error BSA # Error EEPROM failure on the BSA board

CHA # Error EEPROM failure on the CHA board CSA # Error EEPROM failure on the CSA board

Modem PIN failed Remote ctrl Warning The PIN code sent tp MS is incorrect

Ceasing The cause of the alarm has ceased

Power supply PSU1 Critical Power failure in PSU1 (in the cabinet)

Ceasing PSU1 works properly again

PSU2 Critical Power failure in PSU2 (in the cover)

Ceasing PSU2 works properly again PSU overvoltage BSA # Critical The PA supply voltage is too high REFO error CU Error Significant REFO drift or error detected by CU Remote connection Remote ctrl None Remote connection to OMT32 via modem Remote link timeout Remote ctrl Warning Time limit of 20 min. exceeded without extending timer Repeater restart CU None Powering up by user or after power failure

Warning Software restart error 1

Error Software restart error 8 RF blocking Chan. # UL Error Constant CW signal >27dBm. PA off.

Ceasing The cause of the alarm has ceased RTC restarted CU None The time is changed by the operator

Warning Date set to 1994-01-01 RTC error CU Error RTC does not operate properly Startup error BSA # Error Hardware error on BSA board

CHA # Error Hardware error on CHA board CSA # Error Hardware error on CSA board

SW load error CU Error Software load error Unsupported PA type CSA # Error Mounted PA board ID is not expected by the BSA board Synthesizer fault BSA # Error Synthesizer unlocked on the BSA board

CHA # Error Synthesizer unlocked on the CHA board CSA # Error Synthesizer unlocked on the CSA board

Volt Reg. fault BSA # Error Missing DC voltage on the BSA board

CHA # Error Missing DC voltage on the CHA board CSA # Error Missing DC voltage on the CSA board

- 7th time

- 10th time

Remarks

1) The Door open alarm requires an optional door switch described in the P33 Alarm Port section in Chapter 3.

2) The Mains breakdown alarm requires a relay not included in the repeater (see Mains Breakdown Relay in Chapter 3). Chan. #, UL/DL Repeater channel number (1-4) at channel selective operation, uplink or downlink.

BSEL #, UL/DL Repeater channel number at band selective operation, uplink or downlink. CHA # CHA board number at channel selective operation. CSA # CSA board number at channel selective CDMA operation. BSA # BSA board number at band selective operation.

VD203 66/EN - User’s Manual Rev. P1A 2000-09 7 - 3

Allgon Systems AB AR Repeaters Index

ndex

Abbreviations ............................................................................................................... vi

AGC, Automatic Gain Control ....................................................................... 5-13, 5-15

Alarm ........................................................................................................................ 5-16

Alarm reference list ................................................................................................... 7-2

ALARM, red LED ...................................................................................................... 4-2

ALI, Alarm Interface board ............................... 5-3 - 5-8, 5-16, 5-23 - 5-24, 6-3 - 6-4

AMPS ................................................................................................................. 2-2, 5-14

Antenna cable connectors, 7/16" ............................................................................... 6-8

AUX1 auxiliary connector ....................................................................................... 5-23

BA, Booster Amplifier board ........................................ 5-2, 5-6, 5-13, 5-18, 5-21, 5-31

Battery backup ........................................................................................................... 6-8

Block diagram

band selective repeater ...................................................................................... 5-14

channel selective CDMA repeater ..................................................................... 5-12

channel selective GSM type repeater ............................................................... 5-10

BOOT, red LED ......................................................................................................... 4-2

BSA, Band Selective Amplifier board .............. 5-2, 5-7 - 5-8, 5-14, 5-22 - 5-24, 5-32

Cabling ...................................................................................................................... 5-27

band selective repeater ...................................................................................... 5-32

channel selective CDMA repeater ..................................................................... 5-30

channel selective GSM type repeater, 2 ch. ..................................................... 5-28

channel selective GSM type repeater, 4 ch. ..................................................... 5-29

channel selective high power CDMA repeater ................................................. 5-31

CDMA .................................................................................. 2-2, 5-12, 5-21, 5-30 - 5-31

CHA, Channel Amplifier board .................................. 5-2, 5-4, 5-8, 5-10, 5-18 - 5-20,

5-23 - 5-24, 5-28 - 5-29

CMB, Combiner unit .................................................... 5-3 - 5-4, 5-8, 5-11, 5-18, 5-20

Commissioning ........................................................................................................... 4-1

Connection .................................................................................................................. 3-7

donor antenna ....................................................................................................... 3-7

external alarm ....................................................................................................... 3-8

internal phone/modem unit ................................................................................. 3-8

mains ..................................................................................................................... 3-7

RCU ....................................................................................................................... 3-8

Repeater to Repeater Link .................................................................................. 3-9

service antenna ..................................................................................................... 3-7

telephone line ........................................................................................................ 3-8

Connection ports ...................................................................................................... 3-10

CSA, CDMA Segment Amplifier board ...................... 5-2, 5-5 - 5-6, 5-12, 5-19, 5-21,

5-23 - 5-24, 5-30 - 5-31 CU software

version ...................................................................................................... 5-25 - 5-26

CU software and hardware compatibility .............................................................. 5-26

CU, Control Unit board ......... 5-3 - 5-8, 5-13, 5-15 - 5-16, 5-23 - 5-26, 6-3 - 6-4, 6-8

VD203 66/EN - User’s Manual Rev. P1A 2000-09 I - 1

Index AR Repeaters Allgon Systems AB

DAMPS .............................................................................................................. 2-2, 5-14

DC, Directional Coupler ............. 3-8, 4-4, 5-3 - 5-8, 5-10 - 5-15, 5-17 - 5-18, 6-6, 6-8

DCS ..................................................................................................... 2-2, 5-10, 6-4, 6-8

DIA, Distribution board ....................................................... 3-10, 5-3, 5-19, 5-23, 5-25

Dimensions .................................................................................................................. 3-2

See Downlink

Donor antenna .................................................................................. 2-4 - 2-5, 3-6 - 3-7

Door switch ..................................................................................................... 3-13, 5-23

Downlink ............................................................................. 5-9 - 5-10, 5-12, 5-14, 5-19

DPX, Duplex filter .................................................... 5-3 - 5-8, 5-10 - 5-15, 5-17 - 5-22

EAL1 .......................................................................................................................... 3-12

EAL2 .......................................................................................................................... 3-12

EAL3 .......................................................................................................................... 3-12

EAL4 ............................................................................................................... 3-12 - 3-13

ESD .............................................................................................................................. 1-2

ETACS ............................................................................................................... 2-2, 5-14

External alarm ............................................................................................................ 3-8

External alarm input ............................................................................................... 3-12

Fiber Optic Interface .................................................................................................. 6-8

Functional description ............................................................................................... 5-1

GSM ............................................................... 2-2, 5-10, 5-18, 5-28 - 5-29, 6-2, 6-4, 6-8

Hail .............................................................................................................................. 3-1

Indicators in the cabinet ............................................................................................ 4-3

Indicators on the repeater front ............................................................................... 4-2

Introduction ................................................................................................................ 2-1

LNA, Low Noise Amplifier .............................. 5-3 - 5-8, 5-10, 5-12, 5-14, 5-18 - 5-24

Mains breakdown relay ............................................................................................ 3-15

Mounting ............................................................................................................ 3-4 - 3-6

Mounting bracket .............................................................................................. 3-4 - 3-6

NMT .................................................................................................................. 2-2, 5-14

I - 2 Rev. P1A 2000-09 VD203 66/EN - User’s Manual

Allgon Systems AB AR Repeaters Index

OMS, Operation and Maintenance System ...................................................... 2-1, 6-8

OMT32, Operation and Maintenance Terminal ..................................................... 2-1

OPER, green LED ..................................................................................................... 4-2

Outdoor installation .................................................................................................. 3-1

Output power level .................................................................................................... 4-4

PA, Power Amplifier board . 5-2, 5-5 - 5-8, 5-13, 5-15, 5-18, 5-21 - 5-24, 5-30 - 5-32

PCMCIA ...................................................................................................... 6-4 - 6-5, 6-7

PCN ..................................................................................................... 2-2, 5-10, 6-4, 6-8

PCS .............................................................................................................................. 2-2

Ports

+7V ...................................................................................................................... 5-19

AI ..................................................................................................... 3-12 - 3-13, 3-15

ANT .......................................................................................................... 5-17 - 5-18

AO ........................................................................................................................ 3-13

ATT ...................................................................................................................... 5-19

DPX ........................................................................................................... 5-17 - 5-18

HI ..................................................................................................... 5-18, 5-20 - 5-22

IN .............................................................................................................. 5-18 - 5-19

LO ............................................................................................................. 5-18 - 5-22

MRX ..................................................................................................................... 5-17

MS -20dB ....................................................................................... 3-8, 5-17, 6-2, 6-6

OUT LOW ........................................................................................................... 5-19

OUT1 ........................................................................................................ 5-19 - 5-22

OUT2 ........................................................................................................ 5-19 - 5-20

P101 .......................................................................................................... 5-19 - 5-22

P11 ....................................................................................................................... 5-23

P12 ....................................................................................................................... 5-23

P13 ....................................................................................................................... 5-23

P14 ....................................................................................................................... 5-23

P2 ................................................................................................................ 5-23, 5-25

P21 ....................................................................................................................... 5-23

P22 ....................................................................................................................... 5-23

P23 .............................................................................................................. 5-19, 5-23

P24 .............................................................................................................. 5-19, 5-23

P25 Expansion .................................................................................................... 5-23

P26 Expansion .................................................................................................... 5-23

P27 Auxiliary ......................................... 3-8, 3-11, 5-15, 5-23 - 5-24, 6-2, 6-5 - 6-7

P28 Door switch ........................................................................................ 3-13, 5-23

P3 ................................................................................................................ 5-21, 5-23

P301 .......................................................................................................... 5-21 - 5-22

P31 PC ....................................................................................... 3-9, 3-11, 5-16, 5-23

P32 Modem ............................................ 3-8, 3-12, 5-15 - 5-16, 5-23, 6-2, 6-5 - 6-6

P33 Alarm ............................................................ 3-8, 3-12 - 3-13, 3-15, 5-16, 5-23

P34 Repeater to Repeater Link ...................................................... 3-14, 5-15, 5-23

P4 ..................................................................................................... 5-18, 5-21 - 5-23

P5 ..................................................................................................... 5-18, 5-21 - 5-23

P701 ............................................................................................................ 5-18, 5-20

TEST -30dB ................................................................................................. 4-4, 5-17

Power Supply Unit, 24 or 48 Volt DC ................................................................... 3-16

PSU, Power Supply Unit ........................................................................ 5-3 - 5-8, 5-23

PWR, yellow LED ...................................................................................................... 4-2

VD203 66/EN - User’s Manual Rev. P1A 2000-09 I - 3

Index AR Repeaters Allgon Systems AB

R2R, Repeater to Repeater Link .................................................... 3-14, 4-3, 5-15, 6-9

Rain .............................................................................................................................. 3-1

RCU, Remote Control Unit ............................................................................. 5-3, 5-15

RCU, Remote Control Unit for GSM 900 ................................................................ 6-2

RCU, Remote Control Unit with PCMCIA modem ................................................. 6-4

Repeater CU hardware version ............................................................................... 5-25

Repeater CU software version ................................................................................. 5-25

Repeater design .......................................................................................................... 5-2

Repeater setup .......................................................................................................... 5-16

Repeater to Repeater Link

See R2R, Repeater to Repeater Link

Repeater types

Band selective repeater, adjustable band width ................................................. 2-2

Band selective repeater, fixed band width .......................................................... 2-2

Channel selective CDMA repeater ....................................................................... 2-2

Channel selective GSM repeater .......................................................................... 2-2

Channel selective high power CDMA repeater .................................................. 2-2

Combined repeater ................................................................................................ 2-2

RFI filter ........................................................................................................ 5-20 - 5-22

RIA, Repeater to Repeater Interface adapter .......................................................... 5-3

Safety ........................................................................................................................... 1-1

beryllium oxide ...................................................................................................... 1-1

electric shock ......................................................................................................... 1-1

lithium battery ...................................................................................................... 1-1

polytetrafluoro ethylene ....................................................................................... 1-1

PTFE ...................................................................................................................... 1-1

Service antenna ................................................................................ 2-4 - 2-5, 3-6 - 3-7

Service limitations ...................................................................................................... 3-1

Shelter ......................................................................................................................... 3-1

Siting the repeater ..................................................................................................... 3-1

Snow ............................................................................................................................ 3-1

Static electricity .......................................................................................................... 1-2

Station ground .......................................................................................................... 3-10

Sunshine ...................................................................................................................... 3-1

Supply voltage ............................................................................................................. 4-4

TACS ................................................................................................................. 2-2, 5-14

Testpoints .......................................................................................................... 4-4, 5-24

Traffic statistics .......................................................................................................... 6-8

See Uplink

Uplink ................................................................................................................ 5-9, 5-19

UPS .............................................................................................................................. 6-8

Warning signs ............................................................................................................. 1-2

Weights ........................................................................................................................ 3-2

I - 4 Rev. P1A 2000-09 VD203 66/EN - User’s Manual

Allgon Systems AB AR Repeaters Questionnaire

uestionnaire

The aim of this manual is to guide you when installing and operating the

Allgon repeaters, and to answer questions that may turn up. To ensure that we provide appropriate information for these purposes, we would appreciate your views and suggestions on how to improve the manual in this direction. Please, fill out the following questionnaire and send it to us.

Have you read entire sections or do you use the manual to look up specific information when needed?

q Read entire sections q Look up specific information

1 2

Comments:

Do you think the information is easy to find and understand?

q Yes q No

Comments:

Do you find any function of the Allgon repeater hard to understand, a function which should be subjected to more detailed description?

q Yes q No

If yes, which one:

Do you have any suggestions on how we can improve this manual?

Title (Mr/Ms/Other): Initial:

Surname: Job title:

Company: Address:

City: Country: Phone:

Thanks for your kind help. It’s very valuable to us.

VD203 66/EN - User’s Manual Rev. P1A 2000-09 Q - 1

Questionnaire AR Repeaters Allgon Systems AB

POSTAGE

STAMP

Allgon Systems AB Customer Support Centre

SE-187 80 Täby Sweden

If you prefer to send by mail, fold here and tape.

No envelope requ ired.

If you prefer to send by fax, use this number: +46 8 540 834 80

Q - 2 Rev. P1A 2000-09 VD203 66/EN - User’s Manual

Powerwave Technologies AR3530 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Allgon Systems AB AR Repeaters Safety

Warning Signs

Static Electricity

Allgon Systems AB AR Repeaters Introduction

Repeater Types

Using Repeaters

Shaded Area

Sports Arena

Allgon Systems AB AR Repeaters Installation

Siting the Repeater

Sunshine

Shelter

Outdoor Installation and Service Limitations

Dimensions and Weights

Mounting

Connection

Connection Ports and Station Ground

Station Ground

P27 Auxiliary Port

P31 PC Port

P32 Modem Port

P33 Alarm Port

P34 Repeater to Repeater Link Port

Mains Breakdown Relay

Installing 24 Volt or 48 Volt DC Power Supply Unit

Allgon Systems AB AR Repeaters Commissioning

Starting the Repeater

Indicators

Measuring the Output Power Level

Voltage Supply Testpoints

Repeater Configuration

ALLGON System AB AR Repeaters Functional Description

Repeater Design

Channel Selective GSM Repeater

Channel Selective CDMA Repeater

Channel Selective High Power CDMA Repeater

Band Selective Repeater

Combined Repeater

Block Diagram

Downlink Signal Path

Uplink Signal Path

Channel Selective GSM Repeater

Channel Selective CDMA Repeater

Band Selective Repeater

Alarm

Repeater Setup

Board and Unit Descriptions

DC - Directional Coupler

DPX - Duplex Filter

LNA - Low Noise Amplifier

CHA - Channel Amplifier Board for Channel Selective Operation

CSA and PA Boards for Channel Selective CDMA Operation

BSA and PA Boards for Band Selective Operation

DIA Board

CU Control Unit Board

Repeater CU Software and Hardware Compatibility

Cabling

Channel Selective GSM Repeater, 2 Channels

Channel Selective GSM Repeater, 4 Channels

Channel Selective CDMA Repeater

Channel Selective High Power CDMA Repeater

Band Selective Repeater

Allgon Systems AB AR Repeaters Optionals

RCU, Remote Control Unit for GSM 900

RCU, Remote Control Unit with PCMCIA Modem

OMS, Operation and Maintenance System

Traffic Statistics

Battery Backup

Fiber Optic Interface

R2R, Repeater To Repeater Link

Requirements

Installation

Configuration

Allgon Systems AB AR Repeaters Repeater Alarms

Alarm Reference List

Allgon Systems AB AR Repeaters Index
