WIDEBAND RADIO HEAD

INSTALLA TION AND SERVICE MANUAL

WRH

NEXUS FT

044-05251 Rev C October 2009

© 2009 Powerwave Technologies Incorporated. All rights reserved. Powerwave Technologies and the Powerwave logo are registered trademarks. Powerwave Technologies Inc. reserves the right to make changes to documentation and equipment, including but not

limited to component substitution and circuitry changes. Changes that impact th is document may be subsequently incorporated in a later revision of this document.

This Powerwave product is designed to operate within the Normal Operating (typical operating) ranges or conditions specified in this document. Operation of this equipment beyond the specified ranges in this document may cause (1) spurious emissions that violate regulatory requirements; (2) the equipment to be automatically removed from service when maximum thresholds are exceeded; or (3) the equipment to not perform in accordance with its specifications. It is the Operator's responsibility to ensure this eq u ipm e nt is properly installed and operated within Powerwave operating specifications to obtain proper performance from the equipment and to comply with regulatory requirements.

The rated output power of a Nexus FT is for multiple carriers. As long as the composite power does not exceed the rated power (20W for North America), derating is not required for multiple carriers. For situations where regulatory requirements require reduced interference to adjacent band users, the rating would have to be reduced by 3 dB. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. Input power is rated at 115/230VAC, 50/60Hz, and should be protected based on the power and fuse specifications in Chapter 5 of this manual. Power strips should, at a minimum, conform to this requirement to prevent equipment damage and possible overload.

Federal Communications Commission (FCC) This device complies with the technical standards gove rning mo bile radio devices in accordance with FCC Rules. This

device is intended to facilitate the reception and transmission of mobile radio devices in the cellular, PCS or other mobile services, and its operation by end users or others requ ires carrier consent under FCC rules. T his equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CRF47 part 15 of the FCC rules. This equipment is also certified to CRF47 part 22 (cellular), part 24 (PCS), part 27, and part 90 (iDEN800 and iDEN900) of the FCC Rules depending on the band of operation. Changes or modifications not exp ressly approved by Powerwave Technologies, Inc. for compliance could void the user’s authority to operate this equipment. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Industry Canadian Requirements All Powerwave apparatus introduced in the Canadian mar ket meet all requirements of the Canadian Interfere nce-Caus-

ing Equipment Regulations. The -20dB bandwidth at 190 0 MHz band is 80 MHz. The -20d B bandwidth at 1 900+G MHz band is 77.4 MHz. The -20dB bandwidth at the 700 MHz is 23.5 MHz. The -20dB bandwidth at the 700 MHz is 23.5 MHz. The output impedance of the unit referenced in this document is 50 Ohms. The -20dB bandwidth at IDEN 800MHz band is 26 MHz. The Manufacturer's rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present, the rating would have to be reduced. For example, at IDEN 800MHz band, the rating would have to be reduced by 3.5 dB, e specially where the output signal is re- radiated and can cause interference to adjacent band users. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. The input signal is optical so input impedance requirements are not applicable.

European Requirements The Powerwave Nexus FT apparatus introduced in EU markets are certified to ESTI EN 300 609-4 (GSM900 and

DCS1800) and ESTI EN 301 908-11 (WCDMA). Powerwave Technologies Inc., 1801 East St. Andrew Place, CA 92705 Santa Ana, USA.

Phone +1 714 466 1000 – Fax +1 714 466 5800 – Internet www.powerwave.com

Warnings, Cautions, and Notes

Warnings, Cautions, and Notes are found throughout this manual where applicable. The associated icons in warnings and cautions are used to quickly identify a potential condition that could re sult in the consequences described below if precautions are not taken. Notes clarify and provide additional information to assist the user.

WARNING: The warning sy cause bodily injury or death. Before you work on any equipment, be aware of the hazards involved with electrical and RF circuitry and be familiar with standard practices for preventing accidents.

CAUTION: The caution symbol means the potential exists for equipment d amage or loss of

data.

mbol means danger. You are in a situation that could

NOTE: No

tes contain helpful suggestions or references to material not covered in the document.

044-05251 Rev C i

Revision Record Nexus FT

Revision Record

Revision Letter Date of Change Reason for Change

Rev A November 2007 Initial Release Rev B February 2008 Renamed product to Nexus FT, added new

Chapter 1 - Product Safety, added text regarding FON maintenance to pages 3-8

and 4-6.

Rev C November 2009 Upated content to include WMATA ad

(PCS+G, CS700MHz)

ditional bands

ii 044-05251 Rev C

Preface

Safety

Any personnel involved in installation, operation, or service of units included in a Powerwave Distributed Antenna System (DAS) must understand and follow the points below.

❑ Powerwave Nexus FTs are designed to receive and amplify signals from one or more

base stations and retr act the other way round, that is to receive signals from one or more mobile stations, amplify and retransmit the signals to the base stations. Powerwave Nexus FT systems must be used exclusively for this purpose and nothing else.

❑ Units supplied from the mains must be connected to grounded outlets and in conformity

with the loc

❑ For outdoor use, the power cord shou ld meet at least IP6

Do not turn the main power on until you are ready to commission the Nexus FT.

❑ Power supply units supplied from the mains contain dangerous voltag e that can cause

electric shock. Disconnect are to be followed when servicing such units. Only authorized service person n el ar e allowed to service units while the mains are connected.

❑ When opened, the Nexus FT cover must be secured. Otherwise, the cover can be

❑ When working on a Nexus FT on high gr ound, for instance on a mast or pole, be careful

not to drop parts or the

❑ All RF transmitting units, including Nexus FTs, will

give rise to electromagnetic fields that may be hazardous to the health of any person who is extensively exposed close to an antenna.

❑ A lithium battery is permanently mounted on the CU and FON PCBAs. Due to the risk

of explosion, authorized service technician.

❑ NiCd batteries are mounted on the FON PCBA. These batteries contain environmental

poison the local prescriptions.

❑ The FON unit contains a Class 1M laser transmitter that em

radiation at 1550 nm during operation and is intended for a restricted location. Avoid direct exposure from a disconnected laser transmitter or fiber cord. For example, do not view directly with optical instruments (magnifiers) and do not view directly with non-attenuating optical instruments.

❑ The FON Unit has this label attached:

al prescriptions.

d by the wind and cause your fingers getting pinched or your head being hit.

this battery must only be removed from the board by a Powerwave

ous substances. If replaced, the old batteries should be d isposed of as stated in

ansmit the signals to one or more mobile stations. And, also to

5 encapsulation requirements.

the mains prior to any work in such a unit. Local regulations

entire Nexus FT. Falling parts can cause serious personal injury.

generate radio signals and thereby

its 2—4 mW invisible laser

❑ Do not power up the FON unit if a fiber cable is not connected to the fiber output UL

port, or if a fibe

❑ Never look at the end of a fiber cable. The 1310n

visible. Always use an instrument, such as a power meter, to detect signaling.

044-05251 Rev C iii

r cable is connected to the port but disconnected at the other end.

m and 1550nm laser light is not

Electrostatic Discharge (ESD) Nexus FT

Human Exposure to RF Radiation

Safe distances must be kept when working around antennas. The follo wing parag raphs describe the cautions to be aware of during the installation and maintenance of antenna systems and how to calculate safety distances needed for RF radiation at different antenna power and frequencies.

Antennas

To be able to receive and transmit signals, a Nexus FT is connected base station and a service antenna directed towards the coverage area. A fiber optic cable from the base station might, however, be substituted for the donor antenna.

Installation and Maintenance of Antenna Systems

Installation and maintenance of all antenna systems must be performed with respect to the radiation exposure limits for p transmission devices such as cables, connectors, splitters and feeders. Also have in mind the system minimum coupling loss, typically between 25dB and 35dB, is determined by a standar d with the purpose to protect ba se stations from noise and other performance dropping effects.

Radiation Exposure

The World Health Organization (WHO) an d In te rn at ion al Comm ission on Non-Ionising Radiation Protecti on (ICNIRP) ha following radiation power for public exposure:

Frequency Radiation power

800/900 MHz 4.5W/m² 1800/1900 MHz 9.0W/m² 2100 MHz 10.0W/m²

For antennas larger than 20cm the maximum radiation po

ublic areas. The antenna radiation level is affected by Nexus FT output power, antenna gain, and

ve determin

S= P/(4

πr

ed recommendations for radiation exposure. ICNIRP recommends not to exceed the

wer ca

)

S = Radiation power in W/m² P = Output power in W r = Distance between antenna and human in meters

to a donor antenna directed towards the

n be calculated by using the following formula:

Electrostatic Discharge (ESD)

ESD can severly damage essential parts of the equipment if not handled carefully. Parts on printed circuit board assemblies (PCBA) as well as other parts in the equipment are sensitive to ESD. Never touch the PCBA or uninsulated conductor surfaces unless absolutely necessary.

If you must handle the PCBAs or uninsulated conductor equipment or first touch the chassis with your hand. Never let your clothes touch PCBAs or uninsulated conductor surfaces and always store PCBAs in ESD-safe bags.

surfaces, use ESD protective

iv 044-05251 Rev C

Table of Contents

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Human Exposure to RF Radiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Installation and Maintenance of Antenna Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Radiation Exposure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Electrostatic Discharge (ESD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Product Description

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Scope of Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Chassis Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Wideband Amplifier PCBA (WBA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Multi-Carrier Power Amplifier PCBA (MCPA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Distribution PCBA (DIA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Control Unit PCBA (CU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Low Noise Amplifier (LNA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Duplex Filter (DPX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Fiber Optic Unit (FOU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Fiber Optic Node (FON) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Power Supply Unit (PSU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Remote Control Unit (RCU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Alarm Interface PCBA (ALI) and Remote Control Interface PCBA (RCI) . . . . . . . . . . . . 1-5

Controls, Indicators and Connectors

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Front Cover Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Cabinet Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

PCBA Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

PCBA Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

Software and Hardware Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8

Installation

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Unpacking and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

WRH Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Main Power and Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Fiber Optic and RF Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

WRH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Optional Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

External Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Door Open Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Main Power Breakdown Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

21-60 Volt DC PSU Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

Initial Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9

Passive Intermodulation (PIM) Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

044-05311 Rev C v

Maintenance

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Periodic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Clearing Alarm Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Field Replaceable Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

FON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

PSU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

WRH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

Remote Control Unit (RCU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

RCU for Radio Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

RCU for Telephone Line Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

Return For Service Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

Obtaining an RMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

Repackaging for Shipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

Specifications

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Appendix A, Block Diagrams

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Non-Diversity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Diversity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

vi 044-05311 Rev C

List of Figures

1-1 PowerwaveWRH Radio Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

1-2 DIA PCBA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

1-3 CU PCBA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

1-4 LNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4

1-5 FOU in Nexus FT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4

1-6 Nexus FT Sub Unit Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5

1-7 700 MHz (CS, PCS) Sub Unit Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5

1-8 Fiber Optic Star Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6

1-9 Multi-operator System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6

2-1 External Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

2-2 Cabinet Internal Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

2-3 CU PCBA Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

2-4 FON LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

2-5 DIA PCBA Connectors and Testpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4

2-6 FON Connector Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6

2-7 PSU Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7

3-1 Mounting Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

3-2 Mounting Bracket Installation on Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

3-3 Attaching the Bracket to a Pole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3

3-4 Attaching the Bracket to a Mast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3

3-5 Attaching the WRH to the Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

3-6 WRH Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

3-7 WRH Cable Connections for 700 MHz unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

3-8 External Alarm Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

3-9 Main Power Breakdown Relay Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

3-10 Connecting a PC for Local Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9

3-11 PIM testing two carriers and one WRH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

3-12 PIM testing one carrier over each of two WRHs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

4-1 PSU Cable, Switch and Lable locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

4-2 RCU in the WRH cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

A-1 WRH Block Diagram - Non-Diversity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

A-2 WRH Block Diagram - Diversity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

044-05311 Rev C vii

List of Tables

2-1 CU PCBA LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

2-2 FON LED Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

2-3 WRH Base Unit Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4

2-4 WRH Cover Unit Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4

2-5 DIA PCBA Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5

2-6 LNALNA Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6

2-7 FON Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6

2-8 Hardware / Software Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8

3-1 Main Power Breakdown Relay Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

3-2 Initial Statup Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9

3-3 PIM Testing Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11

4-1 Recommended Periodic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

4-2 Alarm Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

4-3 FON Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

4-4 PSU Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

4-5 WRH Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

vii 044-05251 Rev C

Chapter 1

Product Description

Introduction

This manual contains information and procedures for installation , operation, and maintenance of The Nexus FT High Power Wideband Radio Head - in this manual, referred to as WRH. The manual is organized into chapters as follows:

❑

Chapter 1- Product Description

❑

Chapter 2- Controls and Indicators

❑

Chapter 3- Installation

❑

Chapter 4- Maintenance

❑

Chapter 5- Specifications

Scope of Manual

This manual is intended for use by service technicians familiar with similar types of equipment. It contains service information required for the equipment described and is current as of the printing date. Changes wh ich occur after the printing date may be incorporated by a complete manual revision or alterna tively as add itions.

Overview

Figure 1-1 PowerwaveWRH Radio Head

Powerwave Nexus FTs work as bi-directional on-frequency amplifiers areas in wireless mobile systems such as base station fringe areas, tunnels, convention centers, airports and buildings. It receives, amplifies, and transmits signals to/from a base transceiver station (BTS) to/from mobile stations (MS) with both directions being served simultaneously. Conn ections to theWRHare made with N-type or 7/16" male connectors.

used to extend coverage into uncovered

044-05251 Rev C 1-1

Overview Nexus FT

Nexus FTs are microprocessor controlled with alarm and operational status LEDs visible on the front cover. Cooling is provided through convection heat dissipation. Operational parameters, such as gain and power levels are set using a PC running Powerwave OM-Online software which communicates with the Nexus FTs either locally or remotely via modem. Remote operation can be performed via PSTN or a GSM net. The Operation and Maintenance System (OMS) provides for Network Operations Cen ter (NOC) configuration an d alarm monitoring.

Nexus FTs can be configured in many combinat ions dep system operation, and output power. The following paragraphs provide a descr iption of the different models of Nexus FTs available.

TheWRHis a fiber fed system designed to provide a high ou in the downlink path. The MCPA restricts the number of bands to o ne in the cabine t and one additional band if a high cover is used. The MCPA is located in the cabinet and is supplied from the existing PSU.

ending

on the wireless system, single or double

tput power level and comes equipped with a MCPA

Chassis Design

TheWRH is housed in a cast aluminium waterproof chassis, class NEMA4 / IP65, approved for outdoor use but is also suited for indoor installations. The chassis consists of a cabinet and a cover attached with hinges. The cabinet contains theWRH circuitry. The cover comes as either a low or high version. The high cover can be used as an empty cover or be equipped as a part of the WRH or an ind ependentWRH unit. AWRH with a high cover that is equipped as two independent units can, for example, be eq uipped for channel selective ope ration in the cabinet and band selective operation in the cover.

Inside the Nexus FT, a number of amplifier PCBAs are individu that can be opened outward. These PCBAs are of different types depending on the supported system.

ally shielded an

d located under a metal cover

Sub Unit Overview

A number of amplifier PCBAs are individually shielded and located under a metal cover inside the Nexus FT. This cover can be opened outward for access. These amplifier PCBAs are of different types depending on the supported system. All of the Nexus FTs are built up with a number of sub units which are described in the following sections.

Wideband Amplifier PCBA (WBA)

Nexus FTs can handle multiple carriers over a wide ban d. Each ba n d re qu ire s on e WBA for the uplin k an d downlink, and on along with two PAs supporting two bands or one MCPA supporting one band. Positions 1 and 3, shown in Figure 1-6, are assigned for a WBA.

Multi-Carrier Power Amplifier PCBA (MCPA)

The MCPA is used to amplify the output signal from the WBA. Each MCPA can direction. It requires an extra heat sink element on the ou tside of the cabinet or h igh cover to dissipate the heat generated. The MCPA occupies positions 2 through 4 in the cabinet and 6 through 8 in a high cover, as shown in Figure 1-6.

e associated PA or MCPA for the downlink. The cabinet can be equipped with up to two WBAs

handle one band in the downlink

1-2 044-05251 Rev C

Nexus FT Overview

ALLGON INNOVATION SWEDEN M105 R6

PARKING FOR W5

P27

W6B 10

P33

ALARM

P23 LNA

UP-LINK

P32

MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31 PC

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

V6B

P27

P26

P23

XOA

XOB

P28

P4 P5 P6 P2 P3 P31 P21 P35 P33

P32

P11 P12 P13 V1P14 P22P29P34 V2P36

V6 GND

P25 P24

Distribution PCBA (DIA)

The DIA is the core distribution PCBA to which all othe

r PCBAs and units connect in the cabinet with the exception of the PA. Figure 1-2 shows a DIA PCBA. A shielded metal frame on the DIA provides the mounti ng location for the CU, ALI and RCIs, if used.

Figure 1-2 DIA PCBA

Control Unit PCBA (CU)

Figure 1-3 shows the CU, which is the core microprocessor controller in the WRH and is connected to P2 on the DIA. The CU contains a microprocessor, main memory, flash memory for the CU software, EEPROM memory for parameters, memory for the event log and statistics, a REFO reference oscillator, ports for local and remote communication, a battery powered real-time clock, and a MAC identity circuit. It supervises and controls operational parameters suc h as gain con t rol and channel handling, alarms, the event log, the password and the logon. The CU is also a control interface for OM-Online and OMS. Software for the CU can be downloaded from OM-Online, either locally or remotely. It is located in the lower right part of the shielded DIA frame.

Figure 1-3 CU PCBA

Low Noise Amplifier (LNA)

LNAs are used on the uplink and are located at the top of

the cabine

t and the high cover, if equipped. An example of an LNA is illustrated in Figure 1-4. All of the coaxial connectors are SMA-type. Signals from the DPX output are fed to the LNA input connector (IN). The OUT1 and OUT2 outpu ts feed the WBAs in the UL direction. The signal level at these connectors is +20dB referenced to the antenna input. The other output, OUT LOW, is an expansion output for an additional LNA if the WRH is equipped with a unit in the cover part of the chassis.

044-05251 Rev C 1-3

Overview Nexus FT

FON

DPX

The gain to this connector is +2dB. The +7V input is used for +7V supply from the DIA PCBA and the ATT connection is for the control signal for a controllable attenuator in the LNA.

Figure 1-4 LNA

Duplex Filter (DPX)

DPXs are located on the metal cover sheet in the upper part of the cabinet.

Fiber Optic Unit (FOU)

The FOU is a metal plate mounted on top of the cover p fiber optic connectors are mounted on the FOU. Figure 1-5 illustrates an FOU with the FON and fiber optic connectors mounted on the plate. It can also be configured with combiners, splitters, and Wave Division Multiplexers (WDMs) to obtain a desired combination of several branches with double or single fiber.

late in the uppe

r part of the Nexus FT. The FON and

Figure 1-5 FOU in Nexus FT

Fiber Optic Node (FON)

The FON is the main part of the FOU. It is a bi-directional electrical/optical signal converter and a node in a fiber network. In addition, th It has also functionality for:

There are two versions of the FON; one with three SMA por ports (UL, DL, RX Mon and TX Mon). The FON also has two optical ports for DL and UL fiber connections.

Power Supply Unit (PSU)

The PSU supplies DC power to all of the compon

Remote Control Unit (RCU)

The RCU is an optional communication unit for remote control of Nexu types and details are described in Chapter 4.

1-4 044-05251 Rev C

e FON has all the functionality included in the CU PCBA and contains battery backup.

• Electrical and optical signal supervisio

• Internal and external alarm handling

• RS232 interface for local PC control via an O&M software (OM-Online)

• Remote control via an O&M software (OM-Online or OMS)

• Interfaces for RCU and FLI

• Battery backup with charger

ents in the Nexus FT.

ts (UL, DL

and RX Mon) and the other with four SMA

s FTs via PSTN or RF modems. RCU

Nexus FT Overview

1550

1310

MCPAs

Alarm Interface PCBA (ALI) and Remote Control Interface PCBA (RCI)

The ALI handles alarms and alarm communication. It is rep

laced with an RCI if an RCU is used and provides an interface between the CU and an RCU for remote communication via modem. The RCI also handles alar ms and alarm communication. Either unit is located in the lower left part of the shielded DIA frame.

Sub Unit Locations

The MCPA is located in the cabinet at the positions indicated in Figure 1-6. A WRH is equipped for one band in the cabinet and, if required, an additional band in a high cove

r. A block diagram is located in Appendix A.

Figure 1-6 Nexus FT Sub Unit Locations

Figure 1-7 700 MHz (CS, PCS) Sub Unit Locations

044-05251 Rev C 1-5

Overview Nexus FT

BMU WRH

WRH

BTS

Fiber Optic Distribution Networks

Fiber optic networks are setup identically to da ta networks. Nexus FTs are connected in a sta r configuration as illustrated in Figure 1-7. In this example, a Base Station Master Unit (BMU) is fed by a BTS via an RF cable. An Optical Converter Module (OCM) could also be used depending on the system configuration. The BMU or OCM contain three FONs and provide continuity to the FONs in the four Nexus FTs. By using WDMs and Optical Splitters (OSPs) in the Nexus FTs, the distribution net can be built up with a combination of star and daisy-chain connections using double or single fiber.

Multi-Operator Configurations

Multi-operator systems require the use of Point of Interconnect (POI) units and OCMs as illustrated in Figure 1-8. In this simple example, two operators have t wo sectors each. Each s ector is connected to a POI and then to a RCM. The RCM is interconnected with an OCM via co axial cab les. Th e com bined DL an d UL signals a re converted to optical signals in the OCM and then distributed to the Nexus FTs-V.

Operator 1

Operator 2

Figure 1-8 Fiber Optic Star Configuration

OCM

Sector 1

Sector 2

Sector 1

BTS-POI

OCM-POI

Sector 2

Figure 1-9 Multi-operator System

1-6 044-05251 Rev C

Controls, Indicators and Connectors

Red

Amber

DPX

ANT

TEST

-30 dB

-20 dB

DPX

ANT

TEST

-30 dB

-20 dB

ALLGON INNOVATION SWEDEN M105 R6

PARKING FOR W5

P27

W6B 10

P33 ALARM

P23 LNA

UP-LINK

P32 MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

P6 c b a

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

POWER SUPPLY UNIT

ALI

RCI

OPER

FAULT

POWER

10V

ALARM

POWER

BOOT

FAULT

OPER

WLI / R2R

DATA

Introduction

This chapter contains descriptions of the controls, indicators and connectors for the WRH.

Front Cover Indicators

Chapter 2

Figure 2-1 External Indicators

Two LEDs, shown in Figure 2-1, are located on the front cover to prov

ide easy identification of a fault in the system. The amber operation LED lights up approximately 15 seconds after the main power is switched on. When the LED is steady, the WRH is ready for operation. The red alarm LED indicates a system error alarm when flashing and a critical alarm when steady.

Cabinet Indicators

Figure 2-2 Cabinet Internal Indicators

044-05251 Rev C 2-1

PCBA Indicators Nexus FT

WLI DATA POWER BOOT FAULT OPER

Figure 2-2 shows the LED indicators located on the ALI or RCI, the CU PCBAs, the 115/220V main power switch (S) in the cabinet, and the voltage indicator (V). These indicators are described in further detail in the following sections.

PCBA Indicators

This following paragraphs describe the LED indicators on the main PCBAs inside the WRH.

CU PCBA

Figure 2-3 shows the location of the LEDs on the CU and Table 2-1 lists their indications.

Figure 2-3 CU PCBA Indicators

Table 2-1 CU PCBA LED Indicators

LED Description

WLI Wire Link Interface. A flashing green LED indicates the unit is receiving

ata over the subcarrier. A steady green LED indicates: the unit is currently not receiving any data, is currently not a control station or there is no other node in the network

DATA Blue LED indicating data transmission in the W-net

POWER Yellow LED indicating present power and remains steady after power is

switched on

BOOT Steady red LED wh

switched detected. If an error is detected LED will stay on

FAULT Flashing red LED for 15 – 20 seconds after main power is switched on.

Flashes for less ser (Critical)

OPER Steady green LED indicates WRH is ready for operation

WARNING: A lithium battery is permanently mounted on the CU PCBA. Due to risk of explosion, this battery must not be removed. In case of battery ma lfunction , re place the CU PCB.

on), then flashing red (5 – 10 seconds), then off if no error is

en the CU boots (10 – 15 seconds after main power is

ious alarms (Error) and is on solid for fatal alarms

2-2 044-05251 Rev C

Nexus FT PCBA Connections

P117

FON PCBA

The FON is shown in Figure 2-4 and the LED indicators are listed in Table 2-2.

Figure 2-4 FON LED Indicators

Table 2-2 FON LED Indications

LED Description

FLI or

F2F

OPER Green LED. Lights up for approximately 5 seconds af

FAULT Red LED. Flashes for 15 – 20 seconds after the mains is switched on. W

POWER Yellow LED. Indicates power is present

BOOT Red LED. Steady LED when the control unit bo

WLI Green LED. Wire Link Interface. Flashing LED indicates un

DATA Blue LED. Indicates data transmission in the W-net BATT Green LED. Steady LED indicates battery pack is currently used as power source

CHARGE Yellow LED. Steady LED indicates battery charging

Green LED. Fib data over the sub carrier. A steady LED indicates the unit has detected an FLI subcarrier, but is not carrying any data

The LED is dark during the boot process and when it is steadily lit again, it indicates the unit is ready for operation

less serious alarms and be steady for fatal alarms

mains is switched on). Next enters a flashing state for 5 – 10 seconds. If no error is detected, the LED turns off. If an error occurs, the LED remains on

the subcarrier. A steady LED indicates one of the following: The unit is not currently receiving any data, the unit is not currently a control statio n or the re is n o oth er no de in the network

er Line Interface (FLI). Flashing LED indicates the unit is receiving

ter the power is switched on.

ill flash for

ots up (

10 – 15 seconds after the

it is receiving data over

PCBA Connections

The following tables list the connections from the main PCBAs to replaceable units inside the WRH. Table 2-3 lists the connections for a WRH configured for PCS both with and without diversity and Table 2-4 lists the connections for Cellular with and without diversity.

044-05251 Rev C 2-3

PCBA Connections Nexus FT

Table 2-3 WRH Base Unit Connections

From To Cable Number Non-Diversity Diversity

WBA P2401 M FON P101 VE007 06/3 Used Used WBA P3401 D FON P101 700-16639-001 Not Used Used WBA P1101 M FON P102 VE007 20/2 Used Used

PSU DIA P21, P35 VE007 98/1 Used Used M FON P108 DIA P29 VE007 66/1 Used Used D FON P108 M FON P116 VE007 66/1 Not Used Used M FON P111 DIA P36 VE008 05/1 Used Used D FON P111 DIA P112 VE008 05/1 Not Used Used

Table 2-3 applies to cables connected to FRUs (PSU and 2 FON) labeled Main FON and Div

ersity FON.

Table 2-4 WRH Cover Unit Connections

From To Cable Number Non-Diversity Diversity

Cover DIA P36 M FON P112 VE008 05/1 Used Not Used Cover DIA P36 D FON P112 VE008 05/1 Not Used Used

PSU DIA P21, P35 VE007 98/1 Used Used

DX DL C M FON P102 700-14508-401 Used Used DX UL1 C (M) M FON P101 700-14508-401 Used Used DX UL2 C (D) M FO N P10 1 VE007 52/2 Not Used Used

DIA PCBA

Figure 2-5 shows and Table 2-5 lists the connections on the DIA PCBA. Th e DIA provides most of the in ternal connection between the sub units and external ports. Connectors involved are also located on the DIA.

P11 P12 P13 V1P14 P22P29P34 V2P36

XOB

XOB XOA

XOA P26

P26 P28

P28

P23

P23 P37

P37

P27

15 16

P23

UL LNA ATTN

P11

P36

P34

X0A

X0B

P28

P28 DOOR

DOOR

8 15

P26

2 1

DIV

P32

P33

MODEM

ALARM

P27

W6B 10

AUX1

ALLGON INNOVATION

ALLGON INNOVATION SWEDEN M105 R6

SWEDEN M105 R6 1

PARKING

PARKING FOR W5

FOR W5

c b

b a

c b

b a

c b

b a

P12 P13

b a

1P232

c b

b a

16P3

P14

LED

LED P22

P22

P25

P29

P31

P31 PC

P21

P21 PSU

PSU

P35

P24

UL LNA ATTN

6V6

P38

DIV

P38

GND

P32

P4 P5 P6 P2 P3 P31 P21 P35 P33

Figure 2-5 DIA PCBA Connectors and Testpoints

The External Alarm Port P33 is used for external ala

rm senso

rs and alarm equipment. The four alarm inputs are low-level inputs with common ground (AIC). Use an insulated switch or relay to initiate alarms (open switches in normal operating mode, closed switches cause alarm). The alarm switch connection can be toggled between active open and active closed. The alarm input voltage ratings, related to ground (AIC), are: Vinmax= 5.5V, Vinmin= –0.5V.

The four alarm inputs are connected to the following pins: Pin 14 AI1 External alarm input 1 - EAL1 Pin 15 AI2 External alarm input 2 - EAL2 Pin 7 AI3 External alarm input 3 - EAL3 Pin 8 AI4 External alarm input 4 - EAL4

2-4 044-05251 Rev C

Nexus FT PCBA Connections

Pin 6 AIC Ground. Two alarm outputs are 1 pole closing and 1 pole opening relay outputs insolated from each other. Maximum

ratings, re follows:

Pin 9 and 1 AO1 and AO8 Closed when operating, otherwise open. Pin 10 and 2 AO6 and AO7 Open when operating, otherwise closed. Pin 11 and 3 AO2 and AO5 Closed at alarm state, otherwise open. Pin 12 and 4 AO3 and AO4 Open at

lated to ground or any other alarm terminal, ar e 50 VAC / 60 VDC. The alarm outputs are defined as

alarm

state, otherwise closed.

Table 2-5 DIA PCBA Connections

Port Connected to

P2 CU PCBA

P3, 5, 6 Not Used

P4 ALI or RCI PCBA

P11 - 14 Channel PCBA positions 1 through 4

P21 PSU, connector 1 P22 LED PCBA in cover P23 LNA/UL (for RH770020/101 ONLY, P24 LNA/DL P25 Expansion output port to cover circuitry. Only in cabinets P26 Expansion input port to cover circuitry. Used in equipped high covers P27 Auxiliary Port (8-pin male) - Pins 2 and 3 must

provide the CU and ALI/RCI PCBAs with voltage. If there is no cable connected, pins 2 and 3 must be interconnected with a jumper

P28 Door switch port - Normally, alarm input AI4 is used for door opening alarm

EAL4 which is arra are thus available also in the P28 connector, to which the door switch is connected. The EAL4 door switch alarm is activated 10 – 30 seconds after

the cover has been opened P29 Power to FON P31 RS-232 PC Port (9-pin D-sub female) - Used P32 RS-232 Modem port (9-pin D-sub male) P33 External

and alarm equip

outputs P34 Not used P35 PSU, connector 2 P36 IP or R2R connection between CU and FON P37 LNA Diversity DL P38 LNA Diversity UL (for RH770020/101 ONLY, P3

Alarm Port (15-pin D-sub female) - Used for external alarm sensors

nged using an optional door switch. Signal AI4 and AIC

ment. Four alarm inputs, EAL1 – EAL4, and two alarm

P23 conn

ects to LNA/UL1)

always

for local PC communication

be interconnected to

8 connects to LNA/UL2)

044-05251 Rev C 2-5

PCBA Connections Nexus FT

P117

LNA

Figure 2-6 shows the front of the LNA and Table 2-6 lists the connections.

Table 2-6 LNALNA Connections

LNA Port Connected to

OUT LOW IN on the LNA/UL in the cover, if equipped

IN LO on the service DPX duplex filter

ATT +7V P23 on the DIA PCBA

OUT1 P2101 on the WBA PCBA OUT2 Diversity LNA connected to P3101 on WBA PCBA

Figure 2-6

NOTE: F UL 2 co

or RH770020/101 only, the OUT 1 on the LNA for UL 1 connects to P2101 and Out 1 for LNA on

nnects to P3101.

FON

Figure 2-7 shows the locations of the connectors on the FON and Table 2-7 lists the po rt numbers, co nnecto r types, and port usage.

Figure 2-7 FON Connector Locations

Table 2-7 FON Connectors

Port Description

P101 SMA, electrical RF input port (to the optical TX port) P102 SMA, electrical RF output port (from the optical RX port) P103 SMA, electrical RF output port (15dB below the P102 port)

RX DIN/APC, optical input port (to the P10

TX DIN/APC, optical output port (from the P101 P104 Used only for development and debugging P105 4-pin male, door LED indicators. Used for the yellow and red L ED indicators located

on the fro

nt ca

binet door

P106 9-pin D-sub female, RS-232 used for local PC communication

08/116 6-pin male, parallel connected power ports for the FON

P109 7-pin male, used for external alarm sensors

2-6 044-05251 Rev C

2 and P103

RF port)

RF ports)

Nexus FT PCBA Connections

DPX

ANT

TEST

-30 dB

-20 dB

POWER SUPPLY UNIT

ALLGON INNOVATION SWEDEN M 105 R6

PARKING FOR W5

P27

W6B 10

P33

ALARM

P23 LNA

UP-LINK

P32

MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31 PC

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

P21 P35

V1V2

Power

DPX

ANT

TEST

-30 dB

-20 dB

DPX

ANT

TEST

-30 dB

-20 dB

POWER SUPPLY UNITPOWER SUPPLY UNIT

ALLGON INNOVATION SWEDEN M 105 R6

PARKING FOR W5

P27

W6B 10

P33

ALARM

P23 LNA

UP-LINK

P32

MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31 PC

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

ALLGON INNOVATION SWEDEN M 105 R6

PARKING FOR W5

P27

W6B 10

P33

ALARM

P23 LNA

UP-LINK

P32

MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31 PC

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

P21 P35

V1V2

Power

Table 2-7 FON Connectors (Continued)

Port Description

P110 W-link jumper, used to terminate units in a W-link. It has to be set in th

e parking state for all units except for the first and last units in a W-link. The Parking state (P) has the jumper between the center and bottom pins. The opposite state, with the jumper between the tip and center pins, terminates(T) the W-link

P111/112 5-pin male, WLI ports used for interconnecting nodes in WLI-nets (IP or R2R

networks).

They are identical and connected in parallel. One of the connectors is intended to be used from the previous node and the ot he r co nn ec to r to th e ne xt node in the network. Either can be used for the first and the last unit in the net chain

P113 2-pin male, used for the on-PCBA backup batteries P114 Backup power output jumper, sets the backup powe

r output state. The OFF state has jumper between the center and left pins. This jumper has to be in the OFF state when used in an OCM. Otherwise, it shall be in the ON state

P115 3-pin male, intended for future use P117 SMA, electrical RF output port (15dB below the P101 port) P130 34-pin, 2-line male, RCU port used for connecting an RCU. The connector contains

modem connection and RCU power supply

th the

PSU

The PSU is located in the bottom middle of the cabinet or in an equipped high cover. The PSU has all the voltages required for the WRH. It has capacity for the radio circu i tr y, fibe r optic s, an d mo d em . Mu lti- ba nd WRHs always require a second PSU. There are two PSU types with different input voltages:

1. 115/230V 50/60Hz, 300W input max.

2. 21- 60V DC, 300W input max.

The PSU is connected to the DIA at P21 and P35, and volta point for P21).

ge is tested

at V1 (test point for P35) and V2 (test

Figure 2-8 PSU Location

044-05251 Rev C 2-7

Software and Hardware Compatibility Nexus FT

Software and Hardware Compatibility

There are different versions of CU PCBA software which can be combined with PCBAs of various revisions. These have unique part numbers and revision information. Table 2-8 lists the software currently available in combination with CU PCBA revisions.

Table 2-8 Hardware / Software Compatibility

CU PCBA part number CU Software part number

500-13817-001 (previously K103/3) D631-18072-001

D631-18072-003 D631-18072-004 D631-18072-005

This information is accurate as of 10/16/2009. As new versions of hardware and software are released without prior notice, contact your Powerwave sales re pr e sentative for information on the latest revision.

For detailed information, refer to the release notes for the CU software to be downloaded (normally found in the readme.txt file

provided with the program files).

2-8 044-05251 Rev C

Chapter 3

Installation

Introduction

This chapter contains unpacking, inspection and installation instructions for installing and powering up the WRH.

Site Survey

Powerwave recommends that a site survey be performed prior to equipment ordering or installation. Performing a detailed site survey reduces or eliminates installation and turn-up delays. Pay particular attention to power plant capacity, cooling needs, floor space, and RF/DC cabling/breaker requirements. Cabinet dimensions and weights are listed in Chapter 5.

Unpacking and Inspection

This equipment has been operated, tested, and calibrate d at the factory. Carefully open con tainers to re move equipment. Retain all packing material that can be reassembled in th e event unit must be returned to the factory. Perform the following steps:

❑ Visua ❑ Check for evidence of water damage, bent or warped chassis, loose screws or nuts, or extraneous

If equipment is damaged, file a claim with the carrier once If equipment must be returned to factory, please contact factory for a R

see Chapter 4.

lly inspect equipment for damage that may have occurred

presence of the delivery person. packing material in connectors.

the extent of any damage is assessed.

during shipment. If possible, in the

eturn Material Authorization (RMA),

WRH Location

The WRH is designed with a weather proof outdoor cabinet that can be mounted without any kind of shelter from rain, snow or hail. The same unit can be installed indoors. A preferable site fo r the WRH is a location free of obstructions, easily accessible and allows for proper air-flow and ventilation.

If a WRH is installed outdoors and can be exposed to direct the WRH with no obstacles. The operating temperature must not exceed 131°F (55°C) . A shelter can be used to shade the WRH from direct sunshine.

Never open a WRH when rain, snow, hail, high humidity temporary shelter can be erected.

sunshin

igh winds are present unless some kind of

or h

e, it is essential that air circulates around

Mounting

The WRH is easy to mount using the provided mounting bracket, which has 9/16-inch (14mm) holes for 3/8inch (10mm) or 1/2-inch (12mm) fixing screws. Clamps with C-C measurements of 3.5-inch (90mm), 5.3-inch (135mm), 5.7-inch (144mm), 8.1-inch (205mm), 9.8-inch (250mm), and 11.8-inch (300mm) can be used as well. The vertical C-C measurement for these is 16.2-inch (411mm). There is a 9/16-inch (14mm) single hole in the middle of the mounting bracket, marked ‘A’ in the figure, which is intended for a locking screw to lock the bracket into place.

044-05251 Rev C 3-1

Mounting Nexus FT

90 135 144 205 250 300

Ø14

411

Figure 3-1 Mounting Bracket

Normally, the WRH is mounted on a wall, pole, or mast. Figure 3-2 illust bracket on a wall using four fixing screws and a locking screw.

rates the installation of the mounting

Figure 3-2 Mounting Bracket Installation on Wall

3-2 044-05251 Rev C

Nexus FT Mounting

Figure 3-3 illustrates the installation of the mounting bracket on a pole using two 5.7-inch (144mm) U-shaped clamps and a locking screw.

Figure 3-3 Attaching the Bracket to a Pole

Figure 3-4 illustrates a mast installation using two 11.8-inch (300mm) bar-shaped clamps screw.

Figure 3-4 Attaching the Bracket to a Mast

and no locking

044-05251 Rev C 3-3

Connections Nexus FT

After installing the mounting bracket, hang the WRH on the upper supports, as illustrated in Figure 3-5. Tighten the upper and lower mounting screws to secure it into place using the 6mm hex socket wrench. Locking cylinders, used to prevent unauthorized removal of the repeater, can be inserted and locked with a key after the lower screws have been tightened. Make sure the donor antenna, directed towards the BTS antenna, and the service antenna, directed towards the area to be covered by the WRH, are mounted and installed properly.

Figure 3-5 Attaching the WRH to the Bracket

Connections

This section describes general examples of how to connect the input and output ports on the WRH.

Main Power and Grounding

Local regulations need to be followed for the main power connection. WRHs are approved in accordan ce with EN and UL/cUL regulations. This is, however, only valid if a classified power cord is used. For the Nexus FTto meet th

For outdoor use, the power cord should meet at least IP65 enca power on until you are ready to commission the WRH.

Fiber Optic and RF Connections

Fiber optic and RF cable connections should be verified both internally and exte rnally before po wering up the equipment. This section illustrates the general internal connections of the WRH. Verify these connections with the as-built drawings and documents for your specific system configuration. Table 3-1 lists the steps to add the external connections to the WRH.

ese regulations you must select one of the following classified and approved cord types:

❑ EN – H 05 W5 - F HMR ❑ UL – AWM ❑ CSA– AWM 1 A/B 11 A/B

WARNING: For WRHs supplied from the main power source, the main outlet must be grounded.

Style 2587

psulation requirements. Do not turn the main

3-4 044-05251 Rev C

Nexus FT Connections

1550

1310

Power connection

Fiber Optic

Connection

Service Antenna Connection

Ground Points

Table 3-1 Cable Connection Procedure

Step Action

1 Connect service antenna coaxial cable to left-outside DIN conn 2 Connect fiber optic cable from OCM or BMU to fiber optic cabl 3 Connect station ground to appropriate ground point in cabinet 4 Mount main power plug to main power cord and insert into PSU

WRH

Figure 3-6 illustrates the cables and

ection on cabinet

e demark on FOU

connections for the WRH.

044-05251 Rev C 3-5

re 3-6 WRH Cable Connections

Figu

Connections Nexus FT

Fiber Optic

Connection

Service Antenna Connection

Ground Points

Power connection

3-6 044-05251 Rev C

Figure 3-7 WRH Cable Connections for 700 MHz unit

Nexus FT Optional Connections

DPX

ANT

TEST

-30 dB

-20 dB

DPX

ANT

TEST

-30 dB

-20 dB

POWER SUPPLY UNIT

ALLGON INNOVATION SWEDEN M105 R6

PARKING FOR W5

P27

W6B 10

P33

ALARM

P23 LNA

UP-LINK

P32

MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

P6 c b a

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31 PC

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

P28 P33

Optional Connections

Alarms

Alarm signals from external sensors are received by an ALI or RCI which forwards them to the CU. The RCI is used if the WRH has an RCU, otherwise the ALI is used. The software on the CU can activate acoustic or visual alarms or direct the alarm to the P33 alarm port for forwarding via an RCU through OM-Online. Alarms can also be handled by the FON. Alarms are configured through OM-Online.

External Alarm

Burglary, fire or other external alarms can be handled by the WRH. External alarm sensors and alarm signals are connected to the P33 alarm port located to the left in the cabinet, as illustrated in Figure 3-7. The P33 alarm port is described in Chapter 2. The cable for this installation is taken through a strain relief bushing at the bottom of the WRH cabinet.

Door Open Alarm

A door open alarm can be configured and installed in the WRH. Th is is arranged with a do or switch connected to pin 8 (AI4) on P28, as described in chapter 2. The location of P28 is shown in Figure 3-7.

Figure 3-8 External Alarm Connection

Main Power Breakdown Relay

To be able to distinguish PSU faults from power failures, a main power breakdown relay can be used. This relay is not included in the WRH. It has to be mounted outside the WRH cabinet. The relay intended for this purpose must fulfil the following specifications:

Closing time: Max. 30 milliseconds Insulation coil/contact: Min. 4KV

A main power connected relay must also be in compliance with breakdown relay connection, follow the steps listed in Table 3-2.

044-05251 Rev C 3-7

valid local regulations. To inst

all a main power

Commissioning Nexus FT

DPX

ANT

TEST

-30 dB

-20 dB

POWER SUPPLY UNIT

ALLGON INNOVATION SWEDEN M105 R6

PARKING FOR W5

P27

W6B 10

P33

ALARM

P23 LNA

UP-LINK

P32

MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31 PC

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

P33:AICP33:AI1

Table 3-2 Main Power Breakdown Relay Connection

Step Action

1 Connect a currentless closed relay contact to pin AI1 and AIC on

Figure 3-8. Alarm is initiated when pins AI1 and AIC are shorted 2 Connect relay coil. Coil must be supplied from same fuse as WRH 3 After commissioning, select Mains

Breakdown

in alarm configuration window in OM-Online. For

details on setting alarm configuration see OM-Online User Manual.

P33 alarm connector, as shown in

Figure 3-9 Main Power Breakdown Relay Connection

21-60 Volt DC PSU Installation

See the Field Replaceable Units, PSU section in Chapter 4 for details on replacing a 115/230 VAC PSU with a 21 to 60 Volt DC PSU.

Commissioning

Before proceeding, carefully read the Safety section and check all connections made during the installation. To fulfill the IP65 weather protective requirements, ensure cable strain relief bushings are properly tightened. Also, ensure gaskets at cable inlets and on the cabinet are properly fitted and not damaged.

3-8 044-05251 Rev C

Nexus FT Commissioning

DPX

ANT

TEST

-30 dB

-20 dB

POWER SUPPLY UNIT

ALLGON INNOVATION SWEDEN M105 R6

PARKING FOR W5

P27

W6B 10

P33

ALARM

P23 LNA

UP-LINK

P32

MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31 PC

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

P31

A WRH can be configured locally with OM-Online by connecting a standard seria l cable from the COM port on the PC to the P31 PC port (RS-232) located to the right in the cabinet as shown in Figure 3-9. The P31 PC port is described in Chapter 2. Details on using OM-Online are described in the OM-Online User Manual.

Initial Startup

To complete the inital start-up of the WRH, follow the steps listed in Table 3-3.

Step Action

1 Turn main power on

Figure 3-10 Connecting a PC for Local Access

Table 3-3 Initial Statup Procedure

2 Check Yellow LED on power supply unit. Steadily lit = functioning correctly 3 Check the four CU PCBA LEDs. Refer to CU PCBA

section in Chapter 2 for correct power up

indications

4 Check the three ALI PCBA LEDs or corresponding LEDs on RCI PCBA. Refer to ALI or RCI PCBA

section in Chapter 2 for correct

power up indications

NOTE When optimizing WRHs, offset the UL gain 20dB less than the DL gain as a starting point.

Always monitor the UL pass bands for noise levels and/or IMDs when optimizing

and commissioning. For CDMA carriers, ensure that the UL pass band is well above the noise floor.

044-05251 Rev C 3-9

Commissioning Nexus FT

(

Passive Intermodulation (PIM) Testing

PIM is the non-linear effect of passive RF components in a desired RF transmission ba nd. As higher percarrier transmit power levels are applied to duplexed passive RF networks, PIM becomes an increasingly significant factor in potential receiver desensitization. A PIM tester may be used on the RF network prior to turn-on and commissioning of the unit, but if a PIM tester is not available, the following may be used:

The following equipment is required to test for PIM:

❑ Anr ❑ Agilent ESG443 ❑ Guarateed/calibrated PIM load capable of handling 20W composite power ❑ Low-PIM RF cable adaptors such as N-N female, Din male to N femaile, DIN-DIN, SMA-SMA

❑ Installed and operational WRH unit ❑ Installed passive RF network under test ❑ Torque wrenches for DIN and N connectors

Two different types of setup are av Figure 3-10 shows PIM testing with two carriers over one WRH, an carrier over each of two WRHs.

itsu Site eMaster or equivilent RF Spectrum Analyzer

2B or equivilent Multi-Signal Generator (or commissioned BTS)

female, and N male to SMA female

ailable, depeding on equipment availability and testing methods

d Figure 3-11 shows PIM testing with one

E4432B

SIG Gen

or BTS)

E4432B SIG Gen (or BTS)

OCM

E4402B

Spec. An.

WRH-V

Load /

DAS

Figure 3-11 PIM testing two carriers and one WRH

E4432B

Sig Gen /

BTS 1

E4432B

Sig Gen /

BTS 2

OCM

WRH-V

Under Test

E4402B

Spec. An.

Hybrid

Load /

DAS

Figure 3-12 PIM testing one carrier over each of two WRHs

The following PIM test uses the receive sensitivity an

d gain of the WRH under test to verify that the receive path is free of PIM noise. For PIM to be a problem at a particular site, TX signals must exist such that their products fall into the RX band using the formulae:

order product = (2 * f1) - f

and

order product = (2 * f2) - f

3-10 044-05251 Rev C

Nexus FT Commissioning

Where f1 and f2 are two TX signals entering a WRH. The specification for the maximum allowed PIM is -115 dBm per 100 kHz resolution bandwidth at rated output power. To test for PIM follow the steps listed in Table 3-4.

Table 3-4 PIM Testing Procedure

Step Action

1 If BTS signals are present, continue with step 2. Otherwise, connect two signal generators to OCM

and set frequencies such that products are in relevent receive band (see equations above)

2 Set WRH UL gain to 60 dB and DL gain such that desired per carrier power is presented at output

port

3 Set Spectrum Analyzer to 100 kHz resolution bandwidth and view RX band at 3

frequency calculated in step 1 4 Loosen fastening screw in each corner on front cover of WRH under test, and open cover 5 Verify the noise floor specification for the Spectrum Analyzer. If the noise floor is higher than or equal

to -85 dBm/100 kHz, locate FON, disconnect UL cable from port P101 and connect

SpectrumAnalyzer to the cable using an SMA female - female connector (noise limit becomes -115

dBm + 60 dB = -55 dBm). Continue with step 7. 6 If noise floor is lower than -85 dBm/100 kHz, locate the FON card and connect the Spectrum Analyzer

to P117 (noise limit becomes -115 dBm + 60 dB - 30 dB = -85 dBm). If the FON only has three RF

ports on the left side, port P117 will not be available, so follow instructions listed in step 5.

order product

7 Enable WRH TX signal. For details on using OM-Online, see OM-Online user manual 8 Using Spectrum Analyzer, measure noise level. If no noise exists above calculated limit in step 5

(-55 dBm) or step 6 (-85 dBm) above, as appropriate, then test is passed and no other action is

necessary 9 If a higher level of noise exists, disable the WRH TX signal and disconnect cable to DAS at bottom-

left outside corner

10 Connect low PIM load onto WRH Service antenna connector at bottom-left outside corner. Tighten

connectors securely

11 Remeasure noise level. If no noise exists above calculated limit in step 5 (-55 dBm) or step 6 (-85

dBm) as appropriate, then DAS has a PIM issue. Tighen all connections in DAS with torque

wrenches, replace any cripmed or severely bent cables, and retest. Repeat until all issues are solved

12 Otherwise, if noise is higher than limit, WRH is defective and must be replaced. See Chapter 4 for

Replacement procedures

044-05251 Rev C 3-11

Commissioning Nexus FT

3-12 044-05251 Rev C

Chapter 4

Maintenance

Introduction

This chapter contains periodic maintenance and performance test procedures for the WRH.

Periodic Maintenance

Periodic maintenance requirements are listed in Table 4-1, as well as the intervals at which the tasks should be performed.

Table 4-1 Recommended Periodic Maintenance

Task Interval Action

Inspection of cables and connectors

Clean equipment Clean as required depending on operating environment

nths Inspect power, RF and Fiber cables for signs of damage or wear

12 mo

(frayed insulation, cracks, punctures, etc.) Check connections to be sure they are tight

Optional Perform cable sweeps

Troubleshooting

The sections that follow contain a list of problems that could occur and a few suggested actions that might correct each problem. If the suggested corrective action does not eliminate the problem, please contact your Powerwave field representative or help line for further instruction.

Clearing Alarm Faults

Table 4-2 lists the alarms that can be generated in the WRH. Critical, Error and Warning alarms are sent automatically from a WRH to OM-Online, stored and then viewed in the Alarm window.

Table 4-2 Alarm Troubleshooting

ID Alarm Text Alarm Unit Alarm Description

1 Power PSU Critical PSU1 in the cabinet does not work properly. A sum signal from

the PSU1 indicates that no mains breakdown relay is used, then the alarm will also be sent at mains breakdown

Ceasing PSU1 in the cabinet works properly again. Ceasing is sent i

PSU1 works at start-up, and there is a corresponding critical PSU1 alarm logged in the Events log. The WRH will restart when the power is back and this alarm will be sent

at least one voltage output has dropped. If

f the

PSU Critical PSU2 in the cover does not work properly. A sum signal from the

PSU2 indicates tha mains breakdown relay is used, then the alarm will also be sent at mains breakdown

044-05251 Rev C 4-1

t at least one voltage output has dropped. If no

Troubleshooting Nexus FT

Table 4-2 Alarm Troubleshooting (Continued)

ID Alarm Text Alarm Unit Alarm Description

Ceasing PSU2 in the cover works properly again. Ceasing is sent if the

PSU2 works at start-up, and there is a corresponding critical PSU2 alarm logged in the Events Log. The WRH will restart when the power is back and this alarm will be sent

Power FON Error The FON 10 Volt charger voltage is below limit. Suggested

remedy: Replace the F

Ceasing The cause of the alarm has ceased

2 WRH restart CU None Power on start, or user ordered reboot. Logged to indicate a

normal power up, or a restart ordered by the operator

Warning Software error restart, 1st – 7th time. Restart 1st to 7th time during

14 day period. The counter is reset every 14th day, counted

a from power up

Error Software error restart 8th – 10th time. Resta rt 8th to 10th time

during the blocked and not used anymore until a user ordered reset is performed, or power is switched off/on

14 day period. At the 11th time, the SW bank will be

3 Mains

breakdown

4 Alarm reset CU None Alarm reset by the user. All alarms are reset. The cause of the

5 Local bus

error

6 Ma in bkd w

backup

7 Err in AD-

converter

8 New un

detected

9 Inst. unit lost Error Compared to the last power on, the CU lacks at least one

External Crit

WBA #, MCPA#

External Error Used to indicate that the mains is no longer available. WRH is

ical The mains power is gone. Used with an external relay indicating

mains breakdown. The external relay should be connected to External Alarm 1 and the WRH configured to indicate this alarm. If no relay is used, a mains breakdown will be reported as a PSU fault

re is a

Ceasing The mains power is back. Sent if the

mains breakdown alarm logged in the Events Log. The WRH will restart when the power is back

alarm will be re-evaluated and reported, if still active

Error Error when communicating on the bus. The CU has no contact

with the WBA, or M

powered b

Check the mains power Ceasing The cause of the alarm has ceased Warning The analog-to-digital converter on the CU PCBA does not give

reliable values None Compared to the last power on, the CU has recognized at least

one additional hardw

hardware unit

y external battery backup unit. Suggested remedy:

CPA PCBA, which is taken out of service

are unit

corresponding critical

10 EEPROM

error

11 Log memory

fault

CU Error EEP read or write fail. Data cannot be written or read from the

EEPROM on the CU PCBA. User parameters are

EEPROM Error Log me

is faulty. The WRH will not work. Not available in all CU software

versions

mory fault. Indicates that the log memory on the CU PCBA

stored in the

4-2 044-05251 Rev C

Nexus FT Troubleshooting

Table 4-2 Alarm Troubleshooting (Continued)

ID Alarm Text Alarm Unit Alarm Description

12 High temp CU Warning The CU PCBA temperature is higher than 90°C

Ceasing The CU PCBA temperature has fallen below 90°C 13 REFO error Error Significant REFO drift or error detected by CU 14 Ext REFO

error

15 CU battery

fault

16 SW load error CU Error Software load error. An error has occurred during a software lo ad

17 Log cleared CU None Lo g memory has been cleared. The check sum in the Events Log

18 RTC restarted CU None The time is changed by the operator (logged to keep track of

19 RTC error Error RTC does not operate. The CU has detected an error in the RTC

CU Warning CU RAM battery fault. The battery for the RAM on the CU PCBA

Warning Sug

Ceasing The cause of the alarm has ceased

Warning Time reset to 1994-01-01. The RTC was unable to keep track of

gested remedy: Check the reference source and the cables

has a voltage outside the normal 2.7 to 3.5 Volt. An alarm may be initiated at start-up if the WRH has been stored out of power for a long time. Suggested remedy: Ensure jumper P3 on the CU PCBA is mounted to charge the battery

ss. The fla

proce Suggested remedy: Check the CU software using the OM-Online SW Manager. Do NOT restart the WRH

memory is faulty. The battery backup or low voltage to the RAM

changes made to the RTC)

the time and di the CU PCBA is mounted to charge the battery

operation which makes the time unreliable. Suggested remedy: Replace the CU PCBA

sh memory does not contain a proper software.

log is cleared. Can be caused of a bad RAM

d a reset. Suggested remedy: Ensure jumper P3 on

20 Door open

alarm

21 External

alarm 1

22 External

alarm 2

23 External

alarm 3

24 External

alarm 4

rnal Config The door has been open 30 seconds without disabling the alarm

Exte

Ceasing The door has been closed 30 seconds, or the alarm is disabled

External Config External alarm input EA1 active more than 1 second

Ceasing External alarm input EA1 no longer active

External Config External alarm input EA2 active more than 1 second

Ceasing External alarm input EA2 no longer active

External Config External alarm input EA3 active more than 1 second

Ceasing External alarm input EA3 no longer active

External Config External alarm input EA4 active more than 1 second

Ceasing External alarm input EA4 no longer active

044-05251 Rev C 4-3

Troubleshooting Nexus FT

Table 4-2 Alarm Troubleshooting (Continued)

ID Alarm Text Alarm Unit Alarm Description

30 No modem

found

33 No

connection

34 Login failed None Invalid WRH password 35 Remote

connection

36 Modem init

failed

37 Remote

timeout

38 PIN code

failed

Remote ctrl None No modem found, that is no answer is returned on a poll string to

the modem

mote ctrl None No connection at callback. The WRH has tried to call as many

times as stated in the alarm call settings. No connection was established.

Warning No connection at alarm call. The WRH has tried to call as many

times as stated in established. This alarm does not generate a new attempt to report alarm by alarm call.

mote ctrl None Modem connection to OM-Online opened. Not logged on CU2.

Remote

Remo

Remote ctrl Warning The PIN code sent to MS is incorrect. To unlock the MS/SIM card,

ctrl None Initia tion string to modem not OK. The initiation string sent to the

modem is not OK. The string may contain commands not recognized by the modem. An alarm might be sent anyway. Suggested remedy: Check the modem using the OM-Online or OMS modem debugger

te ctrl Warning The time limit of 20 minutes is exceeded without extendin g the

timer. The modem connection is terminated by the WRH

the PUK code will probably be needed

the alarm call settings. No connection was

39 No phone

detected

40 Battery fault RCU, FON

42 Antenna

isolation

48 Battery

backup fa

Remote ctrl Warning When using a PC-card together with the MS, the alarm indicates

charger

WBA #, Channel #, UL/DL

External Error If a battery backup unit alarm is connected to external alarm 2,

ult

Ceasing The cause of the alarm has ceased

contact Note: A Nokia MS does not power-up after power failure.

Suggested remedy: Ensure the cellular phone is connected Ceasing The cause of the alarm has ceased Error The

properly. Suggested remedy: Check cables or replace battery Ceasing The cause of the alarm has ceased Warning Low antenna isolation. The antenna isolation is lower than the

gain set. Gain is reduced by 10dB – 13dB below the oscillation

point. Suggested remedy: Decrease gain or increase antenna

isolation Error L ow antenna isolation at lowest gain. The gain has been reduced

as much as po

is turned off. Suggested remedy: Decrease gain or increase

antenna isolation Ceasing Normal operation again, that is no oscillation can be detected

13dB above the

then the operator can configure the WRH to display this alarm

when the battery backup unit indicates alarm

with the PC-card, but MS is not present or turned off.

backup battery on the RCU or the FON PCBA does not work

ssible but the oscillation still remains. The amplifier

gain set

4-4 044-05251 Rev C

Nexus FT Troubleshooting

Table 4-2 Alarm Troubleshooting (Continued)

ID Alarm Text Alarm Unit Alarm Description

Ceasing The cause of the alarm has ceased

50 Fiberoptical

error

70 Bad table

alarm

71 Table not

found

72 Table

database error

80 Antenna

SWR alarm

90 FON power

alarm

91 FON

TxStable alarm

FOT

fiber

optics

CU Error Req

CU Error Requested table not found in the datab ase (SW or calibration

CU Error Table database not found (calibration error)

Donor

tenna

an service antenna

FON RF Error A DC voltag

FON RF Error Laser transmitter control loop voltage out of range. Suggested

Configur able

Ceasing The cause of the alarm has ceased

Error Too low antenna return loss, caused either by cables, connectors,

Ceasing The cause of the alarm has ceased

If a fiber unit alarm is connected to external alarm 3, then the operator can configure the WRH to display this alarm when the fiber optical unit indicates alarm

uested table contains incorrect information (SW error)

error)

or antenna problems. Suggested remedy: Check antenna and cables

e on a FON PCBA is out of range. Suggested remedy:

Replace the FON PCBA.

remedy: Replace the FON PCBA

Ceasing The cause of the alarm has ceased

92 FON RxLevel

alarm

93 FON SPI

alarm

245 Not In

Allowed Area

N Warning Received optical level is below any of the two limits (one for

Warning and one for Error). Suggested remedy: Check optical cables

Error Rece ived optical level is below any of the two limits (one for

Warning a cables

Ceasing The cause of the alarm has ceased

FON F2F Error The SPI bus connection to the RF modem does not work properly.

Suggested remedy: Replace the FON PCBA

CU Non

e WRH is moved from the operating area and the RF HW is

switched on or off

nd one for Error). Suggested remedy: Check optical

Remarks: The Door Open alarm requires an optional door switch described

in the Door Open Alarm section of

Chapter 3. The Main power breakdown alarm requires an optional relay described in the Main Power Breakdown Relay

section of Chapter 3.

044-05251 Rev C 4-5

Field Replaceable Units Nexus FT

Field Replaceable Units

The following units can be replaced in the field on-site by a qualified technician with experience maintaining RF equipment:

❑ FON ❑ PSU ❑ WRH

FON

To replace a FON PCBA, follow the steps listed in Table 4-3. For details on cables and connectors, see Chapter 2.

CAUTION: Do not look into the end of any fiber optic cable. Be sure to cap fiber optic cables to protect the connecting end from damage

CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure"

NOTE

Verify ‘Fiberoptical’ classmark in the FON Status window is checked, otherwise FON will not be operational. Classmarks are described in the OM-Online User Manual. Verify that the keyed angle polished connectors are aligned pr can result in high signal loss and/or no connectivity with that node.

operly before tightening. Improper alignment

Table 4-3 FON Replacement Procedure

Step Action

1 Loosen all four locking screws on front of cabinet 2 Open WRH door and secure 3 Locate power connector on FON and remove connector from PCBA 4 Verify all cables on FON are labeled before disconnecting, then disconnect all cables. 5 Remove screws securing FON PCBA to FOU and remove PCBA 6 Replace FON PCBA in reverse order and apply power 7 Connect PC to OM Online port, login to FON and verify configuration and IP address. 8 Close WRH door and secure

NOTE

After replacing the FON, if measurements taken at the fiber connector are correct but the OM Online measurement indicates a loss several dB higher, the likely causes are:

1) Dirty fiber.

2) The DIN to FC bulkhead adapter is bad.

3) Loose fiber connection on the FON board.

4) Bad WDM.

4-6 044-05251 Rev C

Nexus FT Field Replaceable Units

PSU

To replace a PSU, follow the steps listed in Table 4-4. For details on cables and connectors, see Chapter 2.

Figure 4-1 PSU Cable, Switch and Lable locations

Table 4-4 PSU Replacement Procedure

Step Action

1 Loosen all four locking screws on front of cabinet 2 Open WRH door and secure 3 Disconnect main power plug from PSU(Location 1 shown in Figure 4-1) 4 Disconnect power cable bundle from PSU(Location 2 shown in Figure 4-1) 5 Loosen but do not remove screws securing PSU using a 5mm Allen key and remove PSU (Location 3

shown

in Figure 4-1)

6 On new AC power supply, if used, set input voltage switch on PSU to correct input voltage -- 115 VAC

or 230 VAC (Location

7 On new DC power supply, if used, verify that the supply volt

label on PSU (Location 5 shown in Figure 4-1)

8 Set new PSU to correct output supply voltage (27 VDC) by moving

on label on PSU (Location 6 shown in Figure 4-1)

9 Mount new PSU with all four fixing screws (Location 3

10 Connect PSU to DIA PCBA (Location 2 shown in Figure 4-9) with cable

cable must be used in all situations. If only one connection is available on DIA PCBA, the second connector may be tied out of the way with a cable tie

11 Insert power cord (AC power suppl y) or connect DC power cable brown wire (Europe) or black wire

(US) to positive (+) pole and supply)

4 shown in Figure 4-1)

age is 24 VDC or 48 VDC as stated on

wire connection plug as illustrated

shown in Figure 4-1)

marked VE007 98/1. This

blue wire (Europe) or white wire (US) to negative (-) pole (DC power

12 Close WRH door and secure with four locking screws on front of cabinet

044-05251 Rev C 4-7

Remote Control Unit (RCU) Nexus FT

DPX

ANT

TEST

-30 dB

-20 dB

DPX

ANT

TEST

-30 dB

-20 dB

ALLGON INNOVA TION SWEDEN M105 R6

PARKING FOR W5

P27

W6B 10

P33

ALARM

P23 LNA

UP-LINK

P32

MODEM

P28 DOOR

P11

P34

P26

15 16

X0A

X0B

P12 P13

P6 c b a

c b a

1P232

b a

16P3

P14

P35

P21 PSU

P31

P29

P24

P25

GND

6V6

LNA

DOWN-LINK

LED P22

POWER SUPPLY UNIT

RCU

WRH

To replace a WRH, follow the steps listed in the Table 4-5.

WARNING: A fully loaded WRH can weigh 96lbs. Lifting of the WRH should be done by two people. Do not attempt to carry the WRH up a ladder.

Table 4-5 WRH Replacement Procedure

Step Action

1 Loosen all four locking screws on front of cabinet 2 Open WRH door and secure 3 Disconnect main power plug from PSU 4 Verify all external cables connected to WRH are

labeled

before disconnecting, then disconnect all

external cables

5 Remove mounting screws from bottom legs of WRH and loo

sen mounting screws in top legs 6 Close and secure door 7 Lift the WRH off of mount hinges 8 Replace WRH in reverse order 9 Connect PC to OM Online port and verify configurati

r Fiber Optic installations, verify IP

on. Fo

address

10 Close WRH door and secure

Remote Control Unit (RCU)

The RCU provides remote control of Powerwave WRHs. It contains an integrated mobile phone, modem and power supply backup. The RCU is installed in the bottom front of the cabinet, on top of the PSU as illustrated in Figure 4-2.

The RCU is connected to P130 on either an RCI or FON. A jumper is required between pins 1 and 2 on RCI if the P130 cable connector is disconnected. If a main power failure occurs, the unit has a battery with enough capacity for sending a number of alarms.

the

Figure 4-2 RCU in the WRH cabinet

4-8 044-05251 Rev C

Nexus FT Return For Service Procedures

RCU for Radio Communication

The RCU antenna for a radio modem is connected to the BS antenna via the uplink DC, provided the RCU and the WRH operate in the same cell system. Otherwise, the modem must have a separate antenna. Data is transferred between the WRH and the RCU via the P130 modem port on the RCI or FON. The RCU is also powered via the same port and has a battery with enough capacity to send a number of alarms if a main power failure occurs.

RCU for Telephone Line Communication

The land line version uses a telephone line connected to a terminal block on the RCU. A free strain relief bushing at the bottom of the WRH is used for the external telephone line cable.

Return For Service Procedures

When returning products to Powerwave, the following procedures will ensure optimum response.

Obtaining an RMA

A Return Material Authorization (RMA) number must be obtained prior to returning equipment to the factory for service. Pease contact our Repair Department at +1-714-466-1000 to obtain this number, or FAX your request to +1-714-466-5800. Failure to obtain this RMA number may result in delays in receiving repair service.

Repackaging for Shipment

To ensure safe shipment of the unit, it is recommended that the original package designed for shipping the unit be reused. If it is not available, contact Powerwave’s Customer Service Department at 1-800-797-9283, +1-714-466-100 or by e-mail at support@pwav.com for packing material.

044-05251 Rev C 4-9

Return For Service Procedures Nexus FT

This page intentionally left blank

4-10 044-05251 Rev C

Introduction

This chapter provides specifications for the WRH.

Table 5-1: WRH Specifications

Electrical

Frequency band UL 788 to 805 MHz (CS, PS)

824 to 849 MHz (Cellular) 806 to 824 MHz (800 iDEN) 880 to 915 MHz (GSM 900) 896 to 901 MHz (900 iDEN) 1710 to 1785 MHz (GSM 1800) 1850 to 1910 MHz (PCS) 1850 to 1915 MHz (PCS+G) 1920 to 1980 MHz (UMTS) 1710 to 1755 MHz (AWS 2100)

Frequency band DL 758 to 775 MHZ (CS, PS)

869 to 894 MHz (Cellular) 851 to 869 MHz (800 iDEN) 935 to 940 MHz (GSM 900) 925 to 960 MHz (900 iDEN) 1805 to 1880 MHz (GSM 1800) 1930 to 1990 MHz (PCS) 1930 to 1995 MHz (PCS+G) 2110to 2170 MHz (UMTS) 2110 to 2155 MHz (AWS 2100)

Chapter 5

Specifications

Max absolute delay <300 ns Gain adjustment range (in 1 dB steps) 30 dB

Gain

Uplink Downlink Variation

Instantaneous bandwidth 17 MHz (CS, PS)

35 to 60 dB typical - Excluding fiber link 45 to 70 dB typical - Excluding fiber link ± 1.5 dB versus temperature including fiber link ± 1.5 dB versus DL frequency including fiber link ± 0.5 dB versus DL output power including fiber link ± 0.5 dB versus input voltage including fiber link ± 2.0 dB versus UL frequency including fiber link

25 MHz (Cellular) 18 MHz (800 iDEN) 35 MHz (GSM 900) 5 MHz (900 iDEN) 75 MHz (GSM 1800 60 MHz (PCS) 65 MHz (PCS+G) 60 MHz (UMTS) 45 MHz (AWS)

044-05251 Rev C 5-1

Introduction Nexus FT

Table 5-1: WRH Specifications (Continued)

Uplink AGC limit 0 dBm at FON input Downlink AGC limit 43 dBm at antenna port Return Loss 11 dB Downlink, Spurious and Emissions level -13 dBm/1 MHz (FCC)

-36 dBm (below 1 GHz, per ETSI EN 300 609-4)

-30 dBm (above 1 GHz, per ETSI EN 300 609-4)

Downlink power +43 dBm RMS (20 Watts) (for FCC - UMTS)

+40 dBm RMS (10 Watts) (for ETSI - GMS/EDGE) Noise figure excluding fiber optic link 4 dB Fiber-Optic Link Budget 10 dBo Receiver input port return loss 14 dB Power supply voltage 115/230 VAC

21-60 VDC Maximum Current Draw (Single Band) 6 A @ 115 VAC

3 A @ 230 VAC

15A @ 21-60 VDC Maximum Current Draw (Dual Band) 6 A @ 115 VAC

3 A @ 230 VAC

15A @ 21-60 VDC Recommended Fuse size

Single Band

Dual Band

Power consumption 210 W typical, 300 W max (Single band)

Impedance

Input Output

Mechanical

Dimensions (W x H x D in inches) 465 x 530 x 195 mm (18.3 x 20.9 x 8.3 in) incl. hinges (low cover)

Weight <25 kg (55 lbs) low cover

Service Antenna port connector 7/16 DIN Female Donor Optical port connector FC/APC

10 A for AC voltage

20 A for DC voltage

20 A for AC voltage

40 A for DC voltage

420 W typical, 600 W max (Dual band)

Not Applicable - Optical input

50 Ω

465 x 530 x 310 mm (18.3 x 20.9 x 12.3 in) incl hinges (high cover)

<44 kg (96 lbs) high cover

Environmental

Operating Temperature Range -25 °C to Altitude -142 m to 4000 m (-466 ft. to 13100 ft. Casing class NEMA4/IP65

+55 °C (-13°F to

+131°F)

5-2 044-05251 Rev C

Nexus FT Introduction

Table 5-1: WRH Specifications (Continued)

Fiber Optic Node (FON)

Bandwidth @ 3dB 800 – 2200 MHz Power Consumption, total <5 W Wavelength TX: DFB 1310 or 1550 nm

RX: 1250 – 1600 nm

Transmit

Max continuous RF input Optical output power, two levels RF attenuation settable by SW in 1dB steps

Receive

Max optic power input RF attenuation settable by SW in 1dB steps Alarm threshold level, settable warning Alarm threshold level, settable error

+36dBm +3 or 0dBm 0-20dB

+5dBm 4-24dB 0-40dBm 0-40dBm

044-05251 Rev C 5-3

Introduction Nexus FT

This page intentionally left blank

5-4 044-05251 Rev C

Appendix A

WDM

FOU

DPX

WBA

LNA

MCPA

To/From

OCM or

BMU

RCU

RCI

PSU

FON

ALI

External

alarms

850 MHz

TX0/RX0

1900 MHz

TX0/RX0

Block Diagrams

Introduction

This appendix describes the main signals paths for the WRH.

Non-Diversity

Figure A-1 shows the non-diversity block diagram configuration of the WRH. The WRH is always fed b y a BTS via either a BMU or an OCM. The TX signal from the BTS is converted to an optical signal in a BMU or OCM and fed to the WRH via a fiber optic cable. The o ptical signal is then receive d by the FON and converted to an RF signal. The FON supervises the signaling and reports errors via the RCU connected to the CU.

The RF signal enters the WBA, is amplified, and further amplified in amplifier sta attenuators. The signal exits the WBA and enters the MCPA where it is amplified and fed to the DPX. The amplified output signal passes the DPX before it is fed to the service antenna.

The uplink signal path is located on the same WBA but goes thro

ugh an LNA before entering the WBA.

ges followed by controllable

Figure A-1 WRH Block Diagram - Non-Diversity

044-05251 Rev C A-1

Diversity Nexus FT

WDM

DPX

WBA

LNA

MCPA

To/From

OCM or

BMU

RCU

RCI

PSU

FON

ALI

External

alarms

FOU

LNA

DPX

WBA

LNA

MCPA

LNA

DPX

FON

1900 MHz

TX0/RX0

850 MHz TX0/RX0

850 MHz

RX1

1900 MHz

RX1

Diversity

Figure A-2 illustrates the diversity block diagram configuration of the WRH. With diversity installed, there are two paths on the UL instead of one. This require s an add itional FON fo r the a dded receive path signa l. Signal flow is identical to the non-diversity version with the MCPA on the DL and LNAs on the UL providing the additional amplification out of and into the WBA.

Figure A-2 WRH Block Diagram - Diversity

A-2 044-05251 Rev C

Nexus FT Diversity

044-05251 Rev C A-3

Powerwave Technologies 5JS0115, 5JS0114 Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual
