Powerwave Technologies 5JS0072 Users manual

869-894 MHz

Installation and

Operation Manual

Power Amplifier Radio Module (PARM),

869-894 MHz, 40/30-Watt

January 2005
Installation & Service Manual
r
© 2005 Powerwave Technologies Incorporated. All rights reserved. Powerwave Technologies, and the Powerwave logo are registered trademarks. Powerwave Technologies, Inc. reserves the right to make changes to the documentation and
equipment, including but not limited to component substitution and circuitry changes. Changes that impact this manual may subsequently be incorporated in a later revision of this manual.
This Powerwave product is designed to operate within the Normal Operating (typical operating) ranges or conditions specified in this document. Operation of this equipment beyond the specified ranges in this document may cause (1) spurious emissions that violate regulatory requirements; (2) the equipment to be automatically removed from service when maximum thresholds are exceeded; or (3) the equipment to not perform in accordance with its specifications. It is the Operator's responsibility to ensure this equipment is properly installed and operated within Powerwave operating specifications to obtain prope performance from the
equipment and to comply with regulatory requirements.

January 2005

Powerwave Technologies, Inc. Tel: (714) 466-1000 1801 E. St. Andrew Place (888) 797-9283 Santa Ana, CA 92705 Fax: (714) 466-5800 Web Site: www.powerwave.com
© Copyright Powerwave Technologies, Inc., January 2005. All rights reserved
ii January 2005
Installation & Service Manual
Chapter 1 General Description
1-1 Introduction
This manual contains general information, installation procedures, and specifications for the op­eration and use of the Power Amplifier Radio Module (PARM). The manual is organized as fol­lows:
Chapter 1 Chapter 2 Installation and Operation
1-2 General Description
The PARM is designed as an integrated subassembly unit mounted in a Radio Module (RM) closed metal housing fitted with a heat sink and connected by RF coaxial and DC connectors. The PARM use a common DC/DC converter for operating power. Up to three PARM can be mounted in one RM.
The PARM’s basic function is amplifying 25 MHz band modulated RF input signals (869-894 MHz) from the TX driver subassembly, up to the level of the whole transmitter, as defined in GSM
05.05, class 1 (20 watts minimum and 40 watts maximum). The main characteristics of the PARM are:
General Description with Specifications
GMSK compliant
8-PSK compliant
The PARM is rated for an average output power of 40/30 watts with an EDGE signal and 40/30 watts with a GMSK signal. The electrical specifications are also designed to be in compliance with the requirements of GSM 05.05.
1-3 Specifications
Specifications for the PARM are listed and described in table 1-1.
Table 1-1 PARM Operating Specifications
Frequency Range 869 - 894 MHz (25 MHz Bandwidth) Total Typical / Maximum Input Power -15.7 - +4.8 / +5.8 dBm Average Output Power 40/30 Watts (46.02/44.8 dBm) RF Gain 39 - 48 dB Duty Cycle Continuous DC Operating Voltage DC Operating Voltage Range 25 to 29.5 VDC Operating Temperature -5 ºC to +60 ºC Storage Temperature -40 ºC to +85 ºC Operating Humidity 5 % to 95 % Relative Humidity (noncondensing) Storage Humidity 0 % to 100 % Relative Humidity (noncondensing) Alarms See Chapter 2 RF Input Connector MCX female, gold plated body and core RF Output Connector QN-type female (50 Ohm Nominal Impendence) DC Input Connector Samtec FHP-04-01-T-S, 8-pin (50 Ohm Nominal Impedence) Power Consumption 94.5 Watts Dimensions 3.75” High, .75” Wide, 6.75” Deep
27 ±2% VDC (26.46 to 27.54 VDC)
© Copyright Powerwave Technologies, Inc., January 2005. All rights reserved
1-1 January 2005
Installation & Service Manual
Chapter 2 Installation and Operation
2-1 Introduction
This section contains operating instructions for the Power Amplifier Radio Module (PARM).
2-2 Installation
The PARM module is designed to be directly installed into the radio module.
2-2.1 Alarms Interface Connector
Pin Number Signal Comment
1 PA_VER_RADO From PARM TO LRM 2 PA_VER_RAD1 From PARM TO LRM 3 PA_VER_RAD2 From PARM TO LRM 4 PA_VER_RAD3 From PARM TO LRM 5 PA_VER_RAD4 From PARM TO LRM 6 GND 7 GND 8 PA_ID_LDMOS0 From PARM TO LRM
9 PA_VG_LDMOS0 From LRM TO PARM 10 GND 11 GND 12 PA_ID_DRIVER From PARM TO LRM 13 PA_ALA_TPTR_OUT From PARM TO LRM 14 GND 15 GND 16 PA_OFF From LRM TO PARM 17 PA_VG_LDMOS1 From LRM TO PARM 18 GND 19 PA_ID_LDMOS1 From PARM TO LRM 20 PA_P_OUT From PARM TO LRM
2-2.2 Alarm Descriptions
High Temperature – A temperature monitor located inside the PARM indicates the alarm status if the temperature exceeds the defined threshold.
High Current - This alarm indicates when a high current is pending that could dam- age the PARM if the system continues to operate.
© Copyright Powerwave Technologies, Inc., January 2005. All rights reserved
2-1 January 2005
