Power Supply S06A Assembly Instruction
Digital power supply case (S06A) assembly instruction
This case is suitable for RD6006
Date:2019.9.16
Dear users, thank you for purchasing the digital power supply accessory-metal case
produced by Hangzhou Ruideng Technology Co., Ltd. In order to let you know more about
the full function of this product, get a better experience and avoid misuse. Please read this
instruction carefully before assembly. Keep it for future reference.
ATTENTION: Since the assembly process involves voltage that exceeds the human body's
safety, non-professionals should not operate, you must do insulation and protective
measures during the assembly process, and check the wiring several times for safety, please
place the product at a place that children and old people cannot get.
Please use the switch power supply we recommend, and if you use other power source,
check if the positions of fixing holes are suitable or not.
CONTENT
1.Notes:
2.Product Dimension
3.Accessory List
4.Accessory Picture
5.Assembly Procedure
...............................................................................................................................................
...........................................................................................................................
...................................................................................................................................
.............................................................................................................................
5.1 Assembly Preparation
5.2 Assembly step
...........................................................................................................................
........................................................................................................................
...............................................................................................................
1
1
1
3
4
4
4
1
1.Notes
NAME
SPECIFICATION
QUANTITY
Upper Board
S06A upper board
1
Lower Board
S06A lower board
1
Fan
50mm*15mm
1
● Read this instruction carefully before assembly, if you still have question, please contact
us.
Since the assembly process involves voltage that exceeds the human body's safety,
non-professionals should not operate, you must do insulation and protective measures during
the assembly process, don’t forget to check the wiring several times for safety, and place the
product at a place which children and old people can not get.
● This case is made of cold-rolled steel plate and the surface is sprayed. When assembling
and using, prevent it from scratching by sharp objects, and avoid direct sunlight and humid
environment.
● Avoid short circuit when assembling, connect the electrode correctly.
● NEVER connect the cables with the power ON.
● Try to avoid vibration and fall.
