Desk Top Power Supplies
PSE60C Series
60 Watt Switch Mode
Universal AC Input
The PSE60C series of AC/DC switching power
supplies offer 60 watts of continuous output power.
All models meet CISPR class B and FCC class B
emission limits, and are designed to comply with UL,
cUL and EN60950 r
Features
• Optional output connectors
• 100% burn-in
• Wide input voltage 90 to 264 VAC
• Input surge current protection
• Overvoltage protection
• Overcurrent protection
equirements.
www.powersolve.co.uk
Electrical Specification
INPUT
Input voltage 90 to 264 VAC
Input Frequency 47 to 63 Hz
Input current 1.6A max at low line
Safety ground leakage current 0.75mA max @ 240 VAC 50Hz
OUTPUT
Output voltage See Rating Chart
Output current See Rating Chart
Output power range 0-60 watts
Ripple
Overvoltage protection set at 112-132% of its nominal output voltage
Overcurrent protection All outputs protected to short circuit conditions
ficient
emperatur
T
ENVIRONMENTAL
Operation temperature 0°C to +70°C
Derating
Storage temperature -40°C to +85°C
Relative Humidity 5% to 95% non-condensing
GENERAL
Efficiency 83% typical
Hold-up time 16 m/s low line
Line r
ush cur
Inr
Withstand voltage 4242V DC from input to output, 2121DC from input to ground,
Insulation r
Mean time between failure 100,000 hours minimum at full load at 25°C ambient
EMI r
Safety approvals ul, cUL60950-1, ITS/GS(EN60950)
e coef
egulation
ent
r
esistance
ements Meets conduction limits of (a) FCC 20780 CLASS B
equir
1% peak to peak maximum
All outputs ±0.04%/°C maximum
C linearly to 50% at +70°C
Derated fr
0.5% maximum at full load
±
15 amps @ 115 V
500V DC fr
50 Mohm minimum fr
(b) CISPR CLASS B
om 100% at +40
AC, or 30 amps @ 230 V
om output to gr
°
ound
om output to gr
ound
AC at 25
°C cold start
Powersolve Electronics Ltd. Units 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: [email protected]
Page 2
5
.0
0.1–5.23
0.1–0.8
1
1
52.0–1.0
0
.
4
R
-
4
SWITCHING
POWER
NOTE:
1. Dimensions are shown in mm.
2. Weight: 350 - 400gs approx.
MECHANICAL DIMENSIONS
MM
Desk Top Power Supplies
www.powersolve.co.uk
Output Voltage/Current Rating Chart - PSE60C Series
MODEL NO OUTPUT VOLTAGE OUTPUT CURRENT MAXIMUM OUTPUT
POWER
PSE60C-05 5VDC 4.00A 20W
PSE60C-09 9VDC 4.44A 40W
PSE60C-12 12VDC 4.17A 50W
PSE60C-15 15VDC 3.67A 55W
PSE60C-18 18VDC 3.33A 60W
PSE60C-19 19VDC 3.16A 60W
PSE60C-24 24VDC 2.5A 60W
PSE60C-48 48VDC 1.25A 60W
Standard models have 1.8 metre lead fitted with 2.5x5.5x11 female barrel connector, wired centre positive.
Options: Alternative output connectors available, consult sales office with your requirements.
Any output voltage available within the range of 3V to 50V DC.
Some options subject to minimum order quantities.
