Coffee Maker
SkyCoffee RСМ-М1509S-А
User manual
A1
45
3
1
6
START/CANCEL
7
8
DELAY BREW
STRENGTH
HOUR
MIN
9
12
10
8
6
4
2
2
10
11
2
A2
1
2
3
4
START/CANCEL
6
DELAY BREW
8
STRENGTH
5
7
9
10
HOUR
11
MIN
3
CONTENTS
IMPORTANT SAFEGUARDS ..........................................................................................................................................................................................5
READ ALL INSTRUCTIONS ...........................................................................................................................................................................................5
SAVE THESE INSTRUCTIONS FOR HOUSEHOLD USE ONLY .....................................................................................................................7
Technical characteristics ........................................................................................................................................................................................................8
Package contents .....................................................................................................................................................................................................................9
Parts of the appliance ...........................................................................................................................................................................................................9
Control panel with display ...................................................................................................................................................................................................9
I. PRIOR TO THE FIRST USE ......................................................................................................................................................................................... 9
II. USING THE APPLIANCE ............................................................................................................................................................................................9
Ready for Sky Technology ...................................................................................................................................................................................................... 9
Bluetooth function ................................................................................................................................................................................................................10
To adjust the current time ...................................................................................................................................................................................................10
Time Delay ...............................................................................................................................................................................................................................10
“Strength” function ................................................................................................................................................................................................................11
Coffee brewing .....................................................................................................................................................................................................................11
III. CLEANING AND MAINTENANCE ......................................................................................................................................................................12
Storage and transportation ................................................................................................................................................................................................12
IV. BEFORE CONTACTING SERVICE CENTRE ....................................................................................................................................................12
SkyCoffee RСМ-М1509S-А5ENG
Carefully read all instructions before operating the unit and
save them for future reference. By carefully following these
instructions you can considerably prolong the service life of your
appliance.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
This device complies with Part 15 of the FCC Rules
and Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the device.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment
and receiver.
•
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV
technician for help.
IMPORTANT SAFEGUARDS
•
When using electrical appliances, basic safety precautions should always be taken including the following:
READ ALL INSTRUCTIONS
•
Do not use the appliance for other than intended
use or specied purposes. Failure to follow product
instructions may result in damage that will not be
covered by the warranty. The manufacturer is not
responsible for the consequences of improper use.
•
Before installing the appliance, ensure that its voltage
corresponds with the supply voltage in your home
(refer to the specications on the appliance rating
plate or technical data). Using a different voltage may
result in re, accident or damage to the appliance.
•
When using the extension cord, ensure that its
voltage is the same as specied on the appliance.
The appliance must be grounded. Ensure that it is
connected to a properly grounded power outlet.
Failing to do so may result in electric shock. Use
only grounded extension cords.
CAUTION!
•
While in use the appliance heats up! Do not touch the
housing while the appliance is operating.
•
Unplug from outlet when not in use and before
cleaning. Allow the appliance to cool before putting
6
on or taking off parts. Never handle the plug with
wet hands. Do not pull power cord to disconnect
from the outlet; instead, grasp the plug and pull
to disconnect.
•
Always attach plug to appliance rst, then plug
cord into the wall outlet. To disconnect, turn any
control to “off”, then remove plug from wall outlet.
•
Do not let cord hang over edge of table or counter,
or touch hot surfaces. Damaged cord may cause a
shock, re, or lead to a failure that will not be covered by the warranty.
•
Do not operate any appliance with a damaged cord
or plug or after the appliance malfunctions or has
been damaged in any manner. Return appliance to
the nearest authorized service facility for examination, repair, or adjustment. Any kinds of modications or adjustments to the product are not allowed.
All the repairs should be carried out by an authorized service repair center.
SkyCoffee RСМ-М1509S-А7ENG
•
Never operate the appliance on soft surfaces.
•
Do not cover the unit with any cloth or material
during operation. Failure to do so may result in
overheating or malfunction.
•
Do not open the lid of the appliance during the
making coffee.
•
Do not use outdoors.
•
Follow cleaning and general maintenance guidelines when cleaning the unit.
•
To protect against electrical shock do not immerse
cord, plugs, or appliance in water or other liquids.
Do not wash the device under running water.
•
Close supervision is necessary when any appliance
is used by or near children.
•
This appliance can be used by children aged 8 years
and older and people with reduced physical, sensory, or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance. Keep
the appliance, its cord, and all packaging materials
out of reach of children aged less than 8 years.
Cleaning and user maintenance shall not be made
by children without supervision.
•
The use of accessory attachments not recommended by the appliance manufacturer may cause
injuries.
•
Do not place the appliance on or near a hot gas,
an electric burner, or in a heated oven.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
CAUTION!
•
If a longer detachable power-supply cord or extension cord is used:
•
The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance. Using different
voltage may result in a re or other accident, causing the device damage or shorting the circuit.
•
The cord should be arranged so that it will not
drape over the countertop or tabletop where it can
be pulled on by children or tripped over unintentionally.
•
If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord.
WARNING!
•
Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
8
Technical characteristics
Model.......................................................... SkyCoffee RСМ-М1509S-А
Power .............................................................................................. 1000 W
Voltage ..................................................................................120 V, 60 Hz
Electrical safety ..............................................................................class I
Type of coffee maker ......................................................................... drip
Type of control ......................................................................... electronic
Remote control ...........................................Ready for Sky technology
Housing material ........................................... plastic / stainless steel
Carafe material .....................................heat-resistant glass / plastic
Filter ..........................................................................................removable
Water tank capacity ..........................................................1.6 Qt (1.5 L)
Carafe capacity...................................................................1.6 Qt (1.5 L)
Use of paper lters ..............................................................................yes
Display................................................................................................... LCD
Continuous operation time ............................................ up to 40 min
Data communication protocol....................................Bluetooth v4.0
Devices enabled:
Supported operating systems ..........................................iOS, Android
Carafe reheating...................................................................................yes
Auto shut-off .........................................................................................yes
Strength adjustment ...........................................................................yes
“Anti-drip” function .............................................................................. yes
Overheat protection ............................................................................yes
Time Delay function ............................................................................yes
Overall dimensions ....8.5 × 8.5 × 13.1 in (215 × 215 × 332 mm)
Net weight ........................................................................ 5.3 lb (2.4 kg)
Power cord length ............................................................2.6 ft (0.8 m)
SkyCoffee RСМ-М1509S-А9ENG
Package contents
Coffee maker ......................................................................................1 pc.
Carafe ................................................................................................... 1 pc.
Cleaning brush...................................................................................1 pc.
User manual ....................................................................................... 1 pc.
Service booklet .................................................................................. 1 pc.
In accordance with the policy of continuous improvement, the
manufacturer reserves the right to make any modications to
design, packaging arrangement, or technical specications of the
product without prior notice.
Parts of the appliance
1. Water tank lid
2. Removable water tank with graduated scale
3. Steaming outlets
4. Filter holder
5. Fixator of lter holder
6. Removable lter with handle
7. Coffee spout with spill protection
8. Metal plate for carafe reheating
9. Coffee carafe
10. Housing with power cord storage compartment
11. Power cord
A1
Control panel with display A2
1. Current time/Time Delay indicator
2. Connection to Ready for Sky application indicator
3. 12-hour time format indicators
4. “Start/Cancel” button
5. Cooking indicator
6. “Delay brew” button
7. Time Delay function indicator
8. “Strength” button
9. Strength adjustment indicator
10. “Hour” button
11. “Min” button
I. PRIOR TO THE FIRST USE
Carefully take the appliance and its detachable parts out of the
package. Remove all wrapping materials and stickers except for
the serial number identication sticker.
The absence of the serial number identication sticker on the appliance automatically disables the user’s right to aftersales service.
After the appliance transportation or storage at low temperature keep
it at room temperature for at least two hours before plugging in.
Wipe the housing with a moist cloth. Rinse the removable parts
with warm water, let dry properly before plugging in.
I I. USING THE APPLIANCE
Ready for Sky Technology
The Ready for Sky technology enables to use the software app of
the same name to control the appliance remotely from a smartphone or tablet.
1.
Enable the Bluetooth function on the electric kettle (see
«Bluetooth function»).
The remote control of the coffeemaker SkyCoffeemaker RCMM1509S-A is only possible when the Bluetooth function is on.
2. Download the software from the App Store or Google Play
(depending on your op erating system) onto your smartphone
or tablet.
For the minimum supported OS version, see the company's ofcial
website www.redmond.company or the application description at
the App Store and Google Play.
3.
Start the Ready for Sky app, create an account, and follow the
prompts appearing on the screen.
4.
To the standby mode press and hold down “Hour” button
until three audible signals are heard. indicator will light
up on display.
After connection is made the indicator will light up constantly.
If within 10 seconds connection won’t be made, the appliance will
switch to the standby mode.
5. To disable remote control press and hold the “Min” button
until the longer sound signal.
To provide a stable connection, your mobile device should be
located no more than 49 ft 15 (meters) away from the appliance.
Bluetooth function
1. Press and hold down the “Strength” button for 3 seconds on
the control panel of the coffeemaker.
2.
The changing symbols and will be displayed during
connection on the coffeemaker display. After the connection
is made an audible signal will be heard and appliance will
switch to the standby mode.
10
To adjust the current time
1. Plug in the appliance. An audible signal will be heard, the
default time value will be displayed (12:00).
2. To change the time value press and hold down the “Delay
brew” button. The hour value on display will start ashing.
3. To set the hour value press HOUR, minute value – press MIN.
Press and hold the corresponding button to scroll through
the digits. The hour value changes irrespective of the minute
value. After the maximum value is reached the adjustment
starts again.
4.
After setting is complete do not press the buttons on the
panel for 5 seconds. Settings will be saved automatically.
The default time value is displayed in 24-hour format. To switch
the clock into 12-hour format in the current time setting mode
simultaneously press and hold “Hour” and “Min” buttons. The
current time value in 12-hour format and АМ or PM indicators
will be displayed.
The REDMOND coffee maker SkyCoffee RCM-М1509S-А does not
have non-volatile memory, that’s why in case of the temporary
disconnection from the power supply it’s necessary to readjust
the clock.
Time Delay
The time delay function allows setting the start time of making
the drink.
1.
To switch to the time delay setting mode to the standby mode,
repress “Delay brew”. indicator will light up solid, the hour
value on display will start ashing.
SkyCoffee RСМ-М1509S-А11ENG
2. To set the hour value press HOUR, minute value – press MIN.
Press and hold the corresponding button to scroll through
the digits. The hour value changes irrespective of the minute
value. After the maximum value is reached the adjustment
starts again.
After 1 minute of idle time, the appliance will switch into the
standby mode.
3. After the end of adjustment press “Start/Cancel”. The Time
Delay function will start its operation.
During the operation of the function the current time value is
displayed. To see the set Time Delay value, press “Hour” or “Min”.
4.
After the end of the function operation the appliance will
make three audible signals, indicator will go out. The
drink-making process will start.
5. To disable the Time Delay function repress “Start/Cancel”. A
long audible signal will be heard, indicator will go out,
the appliance will switch to the standby mode.
“Strength” function
This function allows to increase the intensity of the ready drink.
The hot water is supplied into the lter with coffee by 10 second
periods with 10-second breaks during the function operation.
Thanks to that the avour and aroma of the ready drink become
more intense.
To enable the function in any mode of the appliance operation
press “Strength” button. indicator will light up on the panel.
To disable the function repress the “Strength” button, indicator
will go out.
It is not recommended to use the strength adjustment button
when making more than 10 cups of coffee as it may lead to the
appliance overheating.
Coffee brewing
1. Open the lid of the water tank and remove it by pulling upwards by the handle. Fill the tank with clear water. Fill the
tank with clean cold water not exceeding the maximum mark
and install it to the housing until tight. Close the lid.
2.
Open the lter holder by pulling it by the lock to the left.
Install the removable lter into the lter holder. Add the
ground coffee into the lter so that no less than a half of the
container was empty. Set the lter holder into the working
position, by turning it to the right until it clicks.
It is not recommended to tamp ground coffee in the lter. Use
medium ground coffee, suitable for the drip coffee makers. When
making coffee from beans of different grinding, the lter lling
degree may be slightly different.
3. Set the carafe onto the metal plate for heating. Plug in the
appliance.
4. To brew coffee in the automatic mode press the indicator
will light up.
5. After water tank is empty, the appliance will nish operation
in coffee making mode and switch to the mode of keeping
the ready drink warm.
6.
After the end of operation the appliance will make three
audible signals and switch into the standby mode, the indica-
tion will go out. To turn the appliance into the standby mode
manually, press “Start/Cancel”.
III. CLEANING AND MAINTENANCE
Before cleaning please make sure the appliance is unplugged and
has cooled down.
DO NOT wash the appliance under running water, immerse into
water or wash in dishwasher.
DO NOT use abrasives and chemically aggressive substances,
sponges with hard coating when cleaning the appliance.
Removable parts under running warm water after each use. Soft
detergent can be used. Clean the housing and metal plate for
reheating when required.
During operation, depending on the composition of usable water,
oxide spots and scale can appear on the heating element and
inner walls of the appliance. To remove it use special nonabrasive
cleansers for scale cleaning and removal from kitchen appliances.
Storage and transportation
Before repeated operation or storage completely dry all parts of
the appliance. Store the assembled appliance in a dry, ventilated
place away from heating appliances and direct sunlight. During
transportation and storage, do not expose the device to mechanical stress, that may lead to damage of the device and/or
violation of the package integrity.
Keep the device package away from water and other liquids.
12
I V. BEFORE CONTACTING SERVICE
CENTRE
Problem Possible cause Solution
Pump makes noise Empty water tank Fill the water tank
Water doesn’t ow
through
Water runs too fast
Appliance doesn’t
function
Plastic odour appeared during operation
Synchronization attempt failed
Empty water tank Fill the water tank
The appliance wasn’t properly
cleaned after last use
The appliance is heavily clogged
You use coffee of too ne grin-
ding
Coffee in the lter is too tamped
Coffee is too coarsely ground Try to use ne ground coffee
There isn’t enough ground coffee
in the lter
Appliance is not plugged in
There is no power supply in the
electrical outlet
Appliance is new, the smell
comes out of protective cover
Bluetooth function on the mobile device is disabled
Ready for Sky app on the mobile
device is deactivated
Sync devices are located too far
Check the appliance cleaning
according to recommendations of the section “Cleaning
and maintenance”
We recommend you to use
ground coffee, intended for use
in the coffee-makers of this type
When adding coffee to the
lter do not apply too much
force
Put more ground coffee into
the lter next time
Plug in the appliance to the
working outlet
The smell will disappear after
a few uses
Enable Bluetooth function on
the mobile device
Run the Ready for Sky app on
the mobile device
Ensure devices are located
within 49 ft (15 meters) from
each other
SkyCoffee RСМ-М1509S-А13ENG
Problem Possible cause Solution
The connection with
mobile device is
broken
When removing the lid the coffee-maker power is cut off, that
leads to connection breakdown
with mobile device
To resume the connection set
the lid into place and reselect
the appliance in the mobile
app
The packaging, user manual and the device itself may not be
treated as household waste. Instead, it shall be taken to the applicable collection point for the recycling of electrical and electronic equipment.
Bluetooth is the registered trademark of Bluetooth SIG, Inc.
App Store is the service mark of Apple Inc., registered in the USA
and other countries.
Google Play is the registered trademark of Google Inc.
Manufacturer: GOTECH ELECTRIC APPLIANCE CO., LTD.
Address: No.3, Xinfanan road, Huangpu town, Zhongshan city, Guangdong, 528429, China.
© REDMOND. All rights reserved. 2019.
Reproduction, transfer, distribution, translation or other reworking of this document or any part thereof without prior written permission of the legal
owner is prohibited.
Loading...
