Powerplus POWXQ5232 User Manual
POWXQ5232 EN
1 APPLICATION ................................................................................ 3
2 DESCRIPTION (FIG. 1) ................................................................... 3
3 PACKAGE CONTENT LIST ............................................................ 3
4 SYMBOLS ....................................................................................... 3
5 GENERAL POWER TOOL SAFETY WARNINGS ......................... 4
5.1 Working area .......................................................................................................... 4
5.2 Electrical safety ................................................................ ..................................... 4
5.3 Personal safety ...................................................................................................... 4
5.4 Power tool use and care ........................................................................................ 5
5.5 Service .................................................................................................................... 5
6 ADDITIONAL SAFETY INSTRUCTIONS FOR BATTERIES AND
CHARGERS .................................................................................... 5
6.1 Batteries (10) .......................................................................................................... 5
6.2 Chargers (9) ........................................................................................................... 6
7 FEATURES...................................................................................... 6
7.1 Li-ion battery (10) ................................................................................................... 6
7.2 Keyless chuck (1) .................................................................................................. 6
7.3 Torque adjustment ring (2) .................................................................................... 6
7.4 On/off switch (5) ..................................................................................................... 7
7.5 Forward/reverse selector (right/left rotation selector) (4) ................................... 7
7.6 Speed selector (3) .................................................................................................. 7
7.7 LED worklight (6) ................................................................................................... 7
7.8 TPR soft grip .......................................................................................................... 7
8 (PRE)OPERATION .......................................................................... 7
8.1 Battery charging .................................................................................................... 7
8.2 Charging indication ............................................................................................... 7
8.3 To install or remove the battery pack ................................................................... 8
8.3.1 To remove the battery ............................................................................................... 8
8.3.2 To install the battery .................................................................................................. 8
8.4 Installing/removing bits and drills ........................................................................ 8
8.4.1 Installing bits/drills ..................................................................................................... 8
Copyright © 2014 VARO P a g e | 1 www.varo.com
8.4.2 Removing bits/drills ................................................................................................... 8
8.5 General hints for drilling ....................................................................................... 8
8.5.1 Drilling in all materials ............................................................................................... 8
8.5.2 Metal drilling .............................................................................................................. 8
8.5.3 Wood drilling ............................................................................................................. 9
9 MAINTENANCE .............................................................................. 9
POWXQ5232 EN
9.1 General ................................................................................................................... 9
9.2 Service .................................................................................................................... 9
10 STORAGE ....................................................................................... 9
11 TECHNICAL DATA ......................................................................... 9
12 NOISE ............................................................................................ 10
13 TROUBLESHOUTING .................................................................. 10
14 WARRANTY .................................................................................. 10
15 ENVIRONMENT ............................................................................ 11
15.1 Battery pack ......................................................................................................... 11
16 DECLARATION OF CONFORMITY ............................................. 12
Copyright © 2014 VARO P a g e | 2 www.varo.com
POWXQ5232 EN
Denotes risk of personal injury
or damage to the tool.
Read manual before use.
In accordance with essential
safety standards of applicable
European directives.
Class II - The machine is double
insulated; earth wire is therefore
not necessary.
CORDLESS DRILL 14.4V
POWXQ5232
1 APPLICATION
The power tool is intended for driving and drilling through wood, metal, plastics and masonry.
It is not designed for commercial use.
WARNING! For your own safety, read this manual and the general safety
instructions carefully before using the appliance. Your power tool should
only be given to other users together with these instructions.
2 DESCRIPTION (FIG. 1)
1. 10 mm single sleeve keyless chuck
2. Torque adjustment ring
3. Two speed selector
4. Forward/reverse knob
5. ON/OFF switch trigger
6. LED worklight
7. LED battery capacity indicator
3 PACKAGE CONTENT LIST
Remove all packaging materials.
Remove remaining packaging and packing inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for transportation
damage.
Keep the packaging materials as far as possible until the end of the warranty period. Then
take it to your local waste disposal system.
8. Metal belt clip
9. Charger
10. Battery pack
11. Bit holder
12. Drills
13. Screw bits
WARNING Packaging materials are not toys! Children must not play with
plastic bags! There is a danger of suffocation!
1 cordless drill
1 charger
2 battery pack
1 manual
If any parts are missing or damaged, please contact your dealer.
4 SYMBOLS
The following symbols are used in this manual and/or on the machine:
Copyright © 2014 VARO P a g e | 3 www.varo.com
6 screw bit
6 drill bit
1 bit holder 55mm
1 BMC
POWXQ5232 EN
Do not expose charger and
battery pack to water
Risk of fire!
Only use the battery charger
indoors.
Do not expose charger and
battery pack to high temperature
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and follow instructions
may result in electric shock, fire and/or serious injury. Keep safety warnings and instructions
for future reference. The term "power tool" in the safety warnings refers to your mainsoperated (corded) power tool or battery-operated (cordless) power tool.
5.1 Working area
Keep working area clean and well lit. Untidy and dark areas can lead to accidents.
Do not operate power tools in potentially explosive surroundings, for example, in the
presence of inflammable liquids, gases or dust. Power tools create sparks which may
ignite the dust or fumes.
Keep children and bystanders at a distance when operating a power tool. Distractions can
cause you to lose control of it.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the
rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
adapter plugs with earthed power tools. Unmodified plugs and matching outlets will reduce
the risk of a lethal electric shock.
Avoid body contact with earthed surfaces such as pipes, radiators, kitchen ranges and
refrigerators. There is an increased risk of a lethal electric shock if your body is earthed.
Do not expose power tools to rain or wet conditions. If water gets inside a power tool, it will
increase the risk of a lethal electric shock.
Do not damage the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of a lethal electric shock.
When operating a power tool outdoors, use an extension cable suitable for outdoor use.
Using a cord suitable for outdoor use reduces the risk of a lethal electric shock.
If operating a power tool in a damp location is unavoidable, use a power supply protected
by a residual current device (RCD). Using an RCD reduces the risk of a lethal electric
shock.
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool when you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention when operating a power tool may result in serious
personal injury.
Use safety equipment. Always wear eye protection. Using safety equipment such as a
dust mask, non-skid safety shoes, a hard hat, or hearing protection whenever it is needed
will reduce the risk of personal injury.
Copyright © 2014 VARO P a g e | 4 www.varo.com
