Powerplus POWXG9427 User Manual

Download

Page 1

POWXG9427 EN

1 APPLICATION .................................................................................. 2

2 DESCRIPTION (FIG A) .................................................................... 2

3 PACKAGE CONTENT LIST ............................................................. 2

4 SYMBOLS ........................................................................................ 2

5 GENERAL POWER TOOL SAFETY WARNINGS .......................... 3

6 BEFORE START-UP, NOTE THE FOLLOWING! ........................... 3

7 INSTALLATION ................................................................................ 3

8 SETTING TO WORK ........................................................................ 4

8.1 Setting the ON/OFF operating point....................................................................... 4

9 CLEANING AND MAINTENANCE ................................................... 4

9.1 Maintenance guidelines .......................................................................................... 4

9.2 Cleaning the impeller .............................................................................................. 5

10 TECHNICAL DATA .......................................................................... 5

11 SERVICE DEPARTMENT ................................................................ 5

12 TROUBLESHOOTING ..................................................................... 6

13 STORAGE ........................................................................................ 6

14 WARRANTY ..................................................................................... 6

15 ENVIRONMENT ............................................................................... 7

16 DECLARATION OF CONFORMITY ................................................ 7

Page 2

POWXG9427 EN

Denotes risk of personal injury or damage to the tool.

Read manual before use

In accordance with essential requirements of the European directive(s)

SUBMERSIBLE PUMP POWXG9427

1 APPLICATION

This pump is used primarily as cellar pump. When installed in a shaft, the pump provides protection from flooding. It is also used wherever water has to be moved from one place to another, e.g. in the home, agriculture, horticulture, plumbing and many other applications. It is not designed for commercial use.

WARNING! Read this manual and general safety instructions carefully before using the appliance, for your own safety. Your power tool should only be passed on together with these instructions.

2 DESCRIPTION (FIG A)

1. Motor housing

2. Water inlet

3. Water outlet

4. Cable & plug

5. Floating switch

6. Carrying handle

3 PACKAGE CONTENT LIST

 Remove all packing materials  Remove remaining packaging and transit supports (if existing)  Check the completeness of the packing content  Check the appliance, the power cord, the power plug and all accessories for transportation

damages.

 Keep the packaging materials as far as possible till the end of the warranty period.

Dispose it into your local waste disposal system afterwards.

WARNING Packing materials are no toys! Children must not play with plastic bags! Danger of suffocation!

Submersible pump with 10m electric cable (RNF) with earthed plug Outlet connection. manual

When parts are missing or damaged, please contact your dealer.

4 SYMBOLS

In this manual and/or on the machine the following symbols are used:

Page 3

POWXG9427 EN

5 GENERAL POWER TOOL SAFETY WARNINGS

Read all safety warnings and all instructions. Failure to follow all warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains operated (corded) power tool or battery operated (cordless) power tool.

6 BEFORE START-UP, NOTE THE FOLLOWING!

 The pump can be connected to any shock-proof plug which has been installed according

to regulations. The plug must have a supply voltage of 230V ~ 50Hz. Fuse min. 6 Amp.

Caution!

When the pump is to be used near swimming pools or garden ponds and in their area of protection, it must be equipped with a PRCD (residual current circuit breaker) with a nominal trip current of max. 30 mA (according to VDE 0100, part 702 and 738). The pump must not be operated while people are in the swimming pool or in the garden pond! Please contact your electrician!

Caution! This pump is not suitable for continuous use!

Attention!

(Important for your own security) Before starting to run your new submersible pump, please have the following items checked by an expert:

 Ground connection  Zero conductor  Fault current breaker switch must correspond the safety regulations of the power plants

and they must work faultlessly.

 The electrical connections must be protected from moisture.  If there is danger of flooding, the electrical connections must be taken to higher ground.  Circulation of aggressive fluids, as well as the circulation of abrasive materials must be

avoided at all costs.

 The submersible motor-driven pump must be protected from frost.  The pump must be protected from running dry.  Access on the part of children should also be prevented with appropriate measures.

Consistency

Your submersible pump is designed for the circulation of water with a maximum temperature of 35° C. This pump may not be used for other fluids, especially motor fuels, cleaning fluids, and other chemical products!

7 INSTALLATION

The submersible motor pumps is installed as follows:  In a stationary position with fixed pipeline or  in a stationary position with a flexible hose pipe.

Please note!

You should never install the pump by suspending it unsupported from its delivery pipe or power cable. The submersible motor pump must be suspended from the specially provided handle or be placed on the bottom of the shaft. To guarantee that the pump works properly, the bottom of the shaft must be kept free of sludge and dirt of all kinds. If the level of water sinks too far, any sludge in the shaft will dry out quickly and stop the pump from starting up. ,Therefore it is necessary to check the submersible motor pump regularly (by carrying out start-up tests). The floater is adjusted in a way that the pump can immediately be started

Page 4

Note!

The pump shaft should have minimum dimensions of 40 x 40 x 50 cm, so that the floating switch can move freely.

Mains supply

Your new submersible pump is equipped with a shock-proof plug according to regulations. The pump is designed to be connected to a 230V - 50 Hz earthed socket. Make sure that the socket is sufficiently secured (min. 6 Amp.) and is in excellent condition. Introduce the plug into the socket and the pump is ready to go.

Important Note!

If the mains cable or plug suffers any damage from external action, repairs to the cable are prohibited.

8 SETTING TO WORK

After having read these instructions carefully, you can set your pump to work, reconsidering the following:

 Check if the pump rests on the ground of the shaft.  Check of pressure cord has been attached properly.  Check if electrical connection is 230 V - 50 Hz.  Check if socket is in good condition.  Make sure that water and humidity can never come to the mains supply.  Avoid pump running dry.

8.1 Setting the ON/OFF operating point

The ON and OFF operating point of the float switch can be set by adjusting the float switch in its latching holder. Before you put the pump into operation, please check the following:  The float switch must be installed so that the level of the ON operating point and the level

of the OFF operating point can be reached easily and with little force. To check this, place the pump in a vessel filled with water, raise the float switch carefully by hand and then lower it again. As you do so, note whether the pump switches on and off.

 Make sure that the distance between the float switch head and the latching holder is not

too small. Proper operation is not guaranteed if the gap is too small.

 When you set the float switch, make sure that it does not touch the base before the pump

switches off. Caution! Risk of dry-running.

This appliance cannot be used by children or people who are physically, mentally or developmentally impaired, or people who lack experience or knowledge, except in case these people receive instruction from a person responsible for their safety, a supervisor, or by studying the preceding instructions concerning use of this appliance.

POWXG9427 EN

9 CLEANING AND MAINTENANCE

Attention !Before performing any work on the equipment, pull the power plug.

Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may damage the plastic parts.

9.1 Maintenance guidelines

This submersible pump is an approved, maintenance-free high quality product, which is subject to severe final controls. We recommend regular inspection and maintenance to ensure long equipment life and uninterrupted operation.

Page 5

Important ! Note!

type

POWXG9427

Voltage / frequency

230V / 50Hz

Power input

1100W

Delivery rate max..

20000 l/h

Delivery height max

8 m

Immersion depth max.

max. 7 m

Water temperature max.

35° C

Hose connection

5/4"

Foreign bodies up to

35 mm

Switching point high: ON

ca. 55 cm

Switching point high: OFF

ca. 5 cm

For clean/dirty water:

Dirty

Housing (plastic(P) / Stainless Steel (SS) )

Water inlet (plastic / Stainless Steel (SS) )

Weight

7 kg

Remove the mains plug before all maintenance work.

 When the pump is often transported in the course of operation, it should be cleaned out

with clear water after every use.

 In case of stationary installation, the function of the bating switch should be checked every

3 months.

 All fibrous particles which may have built-up inside the pump housing should be removed

with a water jet.

 Every 3 months the shaft ground and as should be cleaned from mud.  Remove deposits on the floater with clear water.

9.2 Cleaning the impeller

If excessive deposits collect in the pump case you must dismantle the bottom part of the pump as follows:

1. Remove the intake cage from the pump case.

2. Clean the impeller with clear water.

Important! Do not put down or rest the pump on the impeller!

3. Re-assemble in reverse order

10 TECHNICAL DATA

POWXG9427 EN

11 SERVICE DEPARTMENT

 Damaged switches must be replaced by our after-sales service department.  If the connecting cable (or mains plug) is damaged, it must be replaced by a particular

connecting cable which is available from our service department. Replacement of the connecting cable must only be carried out by our service department (see last page) or by a qualified person (qualified electrician).

Page 6

POWXG9427 EN

INCIDENTS

CAUSES

REMEDIES

Pump does not start

- No mains supply

- Floater does not switch

- Check mains supply

- Bring floater in a higher position

No flow

- Inlet sieve is clogged

- Pressure hose in bent

- Clean inlet sieve water jet

- Reset hose

Pump does not switch off

- Floater cannot sink down

- Place pump properly on shaft ground

Insufficient flow

- Inlet sieve is clogged

- Reduced pumping capacity by dirty and abrasive water

- Clean inlet sieve

- Clean pump and replace worn-out

parts

Pump switches of after short operating period

- Thermal cutout stops pumps due to dirty water

- Water too hot. Thermalcutout stops pump

- Remove mains plug. Clean pump

and shaft

- Make sure that a water temperature

of max. 35°C is not exceed

12 TROUBLESHOOTING

13 STORAGE

 Thoroughly clean the whole machine and its accessories.  Store it out of the reach of children, in a stable and secure position, in a cool and dry

place, avoid too high and too low temperatures.

 Protect it from exposure to direct sunlight. Keep it in the dark, if possible.  Don’t keep it in plastic bags to avoid humidity build-up.

14 WARRANTY

 This product is warranted for a 36-month period effective from the date of purchase by the

first user.

 This warranty covers all material or production flaws excluding : batteries, chargers,

defective parts subject to normal wear & tear such as bearings, brushes, cables, and plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects resulting from maltreatment, accidents or alterations; nor the cost of transportation.

 Damage and/or defects resulting from inappropriate use also do not fall under the

warranty provisions.

 We also disclaim all liability for any bodily injury resulting from inappropriate use of the

tool.

 Repairs may only be carried out by an authorized customer service center for Powerplus

tools.

 You can always obtain more information at the number 00 32 3 292 92 90.  Any transportation costs shall always be borne by the customer, unless agreed otherwise

in writing.

 At the same time, no claim can be made on the warranty if the damage of the device is the

result of negligent maintenance or overload.

 Definitely excluded from the warranty is damage resulting from fluid permeation, excessive

dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not following the instructions given in the manual), inexpert assembly, lightning strike, erroneus net voltage. This list is not exhaustive.

 Acceptance of claims under warranty can never lead to the prolongation of the warranty

period nor commencement of a new warranty period in case of a device replacement.

 Devices or parts which are replaced under the warranty therefore remain the property of

Varo NV.

Page 7

 We reserve the right to reject a claim whenever the purchase cannot be verified or when it

POWXG9427 EN

is clear that the product has not been properly maintained. (Clean ventilation slots, carbon brushes serviced regularly, etc.).

 Your purchase receipt must be kept as proof of date of purchase.  Your appliance must be returned undismantled to your dealer in an acceptably clean state,

(in its original blow-moulded case if applicable to the unit), accompanied by proof of purchase.

15 ENVIRONMENT

Should your appliance need replacement after extended use, do not discard it with the household rubbish but dispose of it in an environmentally safe way. Waste produced by electrical machine items should not be handled like normal household rubbish. Please recycle where recycle facilities exist. Check with your Local Authority or retailer for recycling advice.

16 DECLARATION OF CONFORMITY

VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,

product: Submersible pump trade mark: POWERplus model: POWXG9427

is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. Any unauthorized modification of the apparatus voids this declaration.

European Directives (including, if applicable, their amendments up to the date of signature);):

2011/65/EU 2006/95/EC 2004/108/EC

European harmonized standards (including, if applicable, their amendments up to the date of signature);

EN60335-1 : 2012 EN60335-2-41 : 2003 EN55014-1 : 2006 EN55014-2 : 1997 EN61000-3-2 : 2006 EN61000-3-3 : 2008

Keeper of the Technical Documentation : Philippe Vankerkhove, VARO – Vic. Van Rompuy N.V.

The undersigned acts on behalf of the company CEO,

Hugo Cuypers Regulatory Affairs – Compliance Manager Date: 18/12/2013
