EN 900W SPRAY STATION POWX357

1 APPLICATION

1.1 Coating Materials Suitable for Use

Water- and solvent-based paints, finishes, primers, 2-component paints, clear finishes, automotive finishes, staining sealers and wood sealer-preservatives.

1.2 Coating Materials Not Suitable for Use

Wall paints (emulsion paints) etc., alkali and acidic paints.

WARNING! Read this manual and general safety instructions carefully before using the appliance, for your own safety. Your power tool should only be passed on together with these instructions.

2 DESCRIPTION (FIG A)

1. Spray station

2. Volume regulator

3. On-/Off switch

4. Handle

5. Paint container

3 PACKAGE CONTENT LIST

 Remove all packaging materials.  Remove remaining packing and package inserts (if included).  Check that the package contents are complete.  Check the appliance, the power cord, the power plug and all accessories for

transportation damage.

 Keep the packing materials as far as possible till the end of the warranty period. Dispose

it into your local waste disposal system afterwards.

6. Spray pistol

7. Trigger

8. Hook

9. Air hose

10. Nozzle

WARNING: Packaging materials are not toys! Children must not play with plastic bags! Danger of suffocation!

1x 900W spray station 1 x 3m air hose 1 x viscosity cup

If any parts are missing or damaged, please contact your dealer.

1 x spray pistol 1 x Instruction manual

4 SYMBOLS

In this manual and/or on the machine the following symbols are used:

Denotes risk of personal injury or damage to the tool.

In accordance with essential requirements of the European directive(s)

Page 4

POWX357

"Class II

double insulated; Earthing

wire is therefore not

necessary

Wear a mask In dusty

conditions

Wear ear guards and

goggles

Read all safety warnings and instructions. Failure to heed warnings and follow instructions

may result in electric shock, fire and/or serious injury. Keep safety warnings and instructions

gs refers to your mains

Keep working area clean and well lit. Untidy and dark areas can lead to accidents.

gs, for example, in the

presence of inflammable liquids, gases or dust. Power tools create sparks which may

Keep children and bystanders at a distance when operating a power tool. Distractions can

Always check that the power supply corresponds to the voltage on the rating plate.

Power tool plugs must match the outlet. Never modify the plug in any way. Do not use

adapter plugs with earthed power tools. Unmodified plugs and matchin

Avoid body contact with earthed surfaces such as pipes, radiators, kitchen ranges and

refrigerators. There is an increased risk of an electric shock if your body is earthed.

rain or wet conditions. If water gets inside a power tool, it

Do not damage the cord. Never use the cord for carrying, pulling or unplugging the power

ng parts. Damaged or

When operating a power tool outdoors, use an extension cable suitable for outdoor use.

Using a cord suitable for outdoor use reduces the risk of an electric shock.

power tool in a damp location is unavoidable, use a power supply protected

by a residual current device (RCD). Using an RCD reduces the risk of an electric shock.

Stay alert, watch what you are doing and use common sense when operating a po

tool. Do not use a power tool when you are tired or under the influence of drugs, alcohol

or medication. A moment of inattention when operating a power tool may result in serious

safety equipment such as a

skid safety shoes, a hard hat, or hearing protection whenever it is needed

Read manual before use

- The machine is

Wear gloves

Wearing of protective shoes advised

5 GENERAL POWER TOOL SAFETY WARNINGS

for future reference. The term "power tool" in the safety warnin operated (corded) power tool or battery- operated (cordless) power tool.

5.1 Working area

  Do not operate power tools in potentially explosive surroundin

ignite the dust or fumes.



cause you to lose control of it.

5.2 Electrical safety

 

reduce the risk of an electric shock.

  Do not expose power tools to

will increase the risk of an electric shock.



tool. Keep the cord away from heat, oil, sharp edges or movi entangled cords increase the risk of an electric shock.

  If operating a

5.3 Personal safety



g outlets will

wer

personal injury.

 Use safety equipment. Always wear eye protection. Using

dust mask, nonwill reduce the risk of personal injury.

www.varo.com

Page 5

POWX357

 Avoid accidental starts. Ensure the switch is in the off position before inserting the plug.

Carrying power tools with your finger on the switch or plugging in power tools when the switch is in the on position makes accidents more likely.

 Remove any adjusting keys or spanners before turning on the power tool. A spanner or

key left attached to a rotating part of the power tool may result in personal injury.

 Do not reach out too far. Keep your feet firmly on the ground at all times. This will enable

you retain control over the power tool in unexpected situations.

 Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and

gloves away from the power tool. Loose clothes, jewellery or long hair can become entangled in the moving parts.

 If there are devices for connecting dust extraction and collection facilities, please ensure

that they are attached and used correctly. Using such devices can reduce dust-related hazards.

5.4 Power tool use and care

 Do not expect the power tool to do more than it can. Use the correct power tool for what

you want to do. A power tool will achieve better results and be safer if used in the context for which it was designed.

 Do not use the power tool if the switch cannot turn it on and off. A power tool with a

broken switch is dangerous and must be repaired.

 Disconnect the plug from the power source before making adjustments, changing

accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

 Store power tools, when not in use, out of the reach of children and do not allow people

who are not familiar with the power tool or these instructions to operate it. Power tools are potentially dangerous in the hands of untrained users.

 Maintain power tools. Check for misalignment or jammed moving parts, breakages or any

other feature that might affect the operation of the power tool. If it is damaged, the power tool must be repaired. Many accidents are caused by using poorly maintained power tools.

 Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting

edges are less likely to jam and are easier to control.

 Use the power tool, accessories and cutting tools, etc., in accordance with these

instructions and in the manner intended for the particular type of power tool, taking into account the working conditions and the work which needs to be done. Using a power tool in ways for which it was not intended can lead to potentially hazardous situations.

5.5 Service

 Your power tool should be serviced by a qualified specialist using only standard spare

parts. This will ensure that it meets the required safety standards.

6 SAFETY WARNINGS FOR FINE-SPRAY SYSTEMS

 Keep area clean well lit and free of paint or solvent containers, rags, and other flammable

materials. Spontaneous combustion may occur. Fire extinguisher equipment shall be present and working at all times.

 Provide for good ventilation in the spraying area and for sufficient fresh air in the complete

room. Evaporating inflammable solvents create an explosive environment.

 Do not use materials with a flashpoint below 21 °C for spraying and cleaning. Use water-

based materials, non-volatile hydrocarbons or similar materials. Fast evaporating solvents create an explosive environment.

 Do not spray in the vicininty of ignition sources, such as static electricity sparks, open

flames, pilot lights, hot objects, engines/ motors, cigarettes and sparks from plugging in or unplugging power cords or operating switches. Such spark sources can ignite the spraying vicinity/environment.

Page 6

POWX357

 Do not spray any liquid of unknown hazard potential. Unknown materials can create

hazardous conditions.

 Wear additional protective equipment such as appropriate protective gloves and protective

masks or respirators when spraying or handling chemicals. Wearing protective equipment for the appropriate conditions reduces the exposure to hazardous substances.

 Never point the spray jet against yourself, towards other persons or animals. Keep your

hands and other body parts away from the spray jet. If the spray jet should penetrate the skin, seek medical attention immediately from a doctor. The material being sprayed can even penetrate the skin through a glove and be injected into your body.

 Do not treat injection as a simple cut. Highpressure spray is able to inject toxins into the

body and cause serious bodily injury. In the event that injection occurs, seek medical attention immediately.

 Be aware of possible hazards from the spray material. Observe the information on

drums/tanks/tins as well as manufacturer information of the spray material, including the request to wear personal protective equipment. The manufacturer's instructions are to be observed in order to reduce the risk of fire as well as injuries caused through toxins, carcinogens, etc.

 Use only nozzles/nozzle inserts specified by the manufacturer. Never spray without the

nozzle protection mounted. Use of a special nozzle insert with the corresponding nozzle protection reduces the probability that a high-pressure jet penetrates the skin and injects toxins into the body.

 Exercise caution when cleaning and changing nozzle inserts. If the nozzle insert should

become clogged during spraying, follow the manufacturer's instructions for switching off the system and relieving the pressure before removing the nozzle. Fluids under high pressure can penetrate the skin, inject toxins into the body and lead to serious injury.

 Keep the plug of the mains cord and the trigger switch of the spray gun clear of paint and

other fluids. Never hold the cord by its connectors to support it. Failure to follow the instruction can lead to electric shock.

We accept no responsibility for damage caused by the use of unsuitable substances, or paints that have not been thinned correctly, and any health hazards that arise from lack of adequate ventilation

6.1 Immediately switch off the spray gun when :

 Interruption in the mains plug, mains lead or mains lead damage.  Defect switch.  Smoke or stench of scorched isolation.

7 ASSEMBLY

7.1 Preparation (fig 1.)

Do not use textured wall paints or coatings as this will block the nozzle.

To obtain the best results, it is important that you prepare the surface to be sprayed and thin the paint to the correct viscosity, before you operate your spray gun. Always ensure that the surfaces to be sprayed are free from dust, dirt and grease. Make sure that you have masked the areas that should not be sprayed, using a good quality masking tape. The paint or fluid to be sprayed should be thoroughly mixed and free from lumps or other particles. Many substances can be sprayed with your spray gun, but always check the manufacturers recommendations before purchasing your paint.

Page 7

POWX357

Viscosity Table

Spray material

Runout Time in Seconds

7.2 Thinning

Always remember to disconnect from the mains supply before filling the paint container with sprayable material.

Most paints are supplied ready for brush application and will need to be thinned before they are suitable to be sprayed. Follow the manufacturer’s advice on thinning. The paint when used with a spray gun. The viscosity cup will help you to determine the correct viscosity of paint to be used. To determine the correct viscosity, fill the cup to the brim with the paint. Measure the amount of time it takes for the cup to empty back into the can. The table below shows recommended times for different types of material.

Plastic & latex paint 24 - 28 seconds Water based paint 20 - 25 seconds Primers 24- 28 seconds Varnishes 20 - 25 seconds Oil based paints 18 - 22 seconds Enamel paints 18 - 22 seconds Aluminum paints 22 - 25 Seconds Car under sealing 25 - 35 seconds Wood sealers 28 - 35 seconds Wood preservatives No thinning required Wood stains No thinning required

If the paint takes longer than the recommended time to empty, then further thinning is required. Mix in a small quantity of the appropriate thinner and use the viscosity test until the correct thickness is achieved. Some sprayable materials contain particles and lumps. These materials should be strained before filling the paint container.

8 OPERATION

8.1 Start up

1. Mounting air hose. Insert the air hose tightly in the connections on the machine and the

spray gun (a + b). The connections can be positioned as desired. (Fig. 2, fig. 3)

2. Unscrew the container from the spray gun.

3. Aligning suction tube .The container contents are to be sprayed out almost completely.

When spraying horizontal surfaces, turn suction tube forward (A). When spraying objects overhead, turn suction tube back (B). (Fig. 4)

4. Set the container on a sheet of paper, pour in the prepared coating material and screw

the container tightly onto the spray gun.

5. Place the spray gun in the gun holder on the machine (Fig. 5)

6. Put the machine down only on a level, clean surface. Otherwise the machine could suck

in dust, etc.

7. Take the spray gun out of the spray gun holder and point it at the target object.

Before connecting to the mains supply, be sure that the supply voltage is identical with the value given on the rating plate.

Page 8

POWX357

8.2 Adjust the spray setting on the spray gun.

Three different spray jet settings can be chosen on the spray gun, depending on the application and target object.

8.2.1 Selecting the Spray Setting Fig. 6 = vertical flat jet ➟ for vertical surfaces

Fig. 7 = horizontal flat jet ➟ for horizontal surfaces Fig. 8 = circular jet ➟ for corners, edges and hard-to-reach surface. Fig. 9 = Wrong settings.

WARNING! Danger of injury! Never pull the trigger guard while adjusting the air cap.

Attention: Only one direction is applicable when changing setting. Do not force or will cause damage!

 Change horizontal flat jet to Vertical. Counter clockwise rotate the changing button 90°.

(Fig. 10)

 Change Vertical flat jet to horizontal. Clockwise rotate the changing button 90°. (Fig. 10)

8.3 Adjusting the Material Volume (Fig. 11)

Set the material volume by turning the regulator on the rear part of the spray gun. A scale on the regulator serves as a guide: + turn to the right ➟ higher material volume

- turn to the left ➟ lower material volume

8.3.1 Spray Technique  The spray result depends heavily on the smoothness and cleanliness of the surface to be

sprayed. Therefore the surface should be carefully prepared and kept free of dust.

 Cover all surfaces not to be sprayed.  Cover screw threads or similar parts of the target object.  It is advisable to test the spray gun on cardboard or a similar surface to find the correct

setting. Important: Begin spraying outside of the target area and avoid interruptions inside the target area.

 Correct (Fig. 12 a) Be sure to hold the spray gun at an even distance of approx. 2.5- 30

cm to the target object.

 Incorrect (Fig. 12 b) Heavy spray fog build-up, uneven surface quality.  An even movement of the spray gun results in an even surface quality.  When coating material builds up on the nozzle (A) and air cap (B) (Fig. 13), clean both

parts with a solvent or water.

8.3.2 Interruption of Work

 Turn the machine off.  Put the spray gun in the spray gun holder.

9 CLEANING AND MAINTENANCE

Make sure that the machine is not live when carrying out maintenance work on the motor.

Page 9

POWX357

Model nr

. POWX357

Our machines have been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper machine care and regular cleaning.

9.1.1 Taking Out of Operation and Cleaning (Fig. 14) a: Air cap

b: Union nut c: Nozzle  Turn the machine off. Activate the trigger guard so that the coating material in the spray

gun flows back into the container.

 Unscrew the container. Empty any remaining coating material back into the material tin.  Pre-clean the container and feed tube with a brush.  Pour solvent or water into the container. Screw the container back on.  Use only solvents with a flashpoint over 21°C  Turn on the machine and spray the solvent or water into a container or a cloth.  Repeat the above procedure until the solvent or water emerging from the nozzle is clear.  Turn the machine off.  Then empty the container completely. Always keep the container seal free of coating

material residue and check for damage.

 Clean the outside of the spray gun and container with a cloth soaked in solvent or water.  Unscrew the union nut and remove the air cap and nozzle. Clean the air cap and nozzle

with a brush and solvent or water.

Caution! Never clean nozzle or air holes in the spray gun with sharp metal objects.

9.1.2 Re-assembling the nozzle (Fig. 15) a: rib

b: groove Put the nozzle onto the gun body and find the correct position by turning it. The rib on the enclosure should fit into the groove on the nozzle. Put the air cap onto the nozzle and tighten it using the union nut.

9.2 Entretien (Fig 16)

Change the air filter if it is soiled. Release the cover fastening from the machine place the air filter (1) in the cover. Push the cover back onto the machine.

WARNING! Never operate the machine without the air filter; dirt could be sucked in and interfere with the function of the machine.

10 TECHNICAL DETAILS

Voltage 220-240V Frequency 50Hz Power input 900W Maximum nozzle flow rate 800gr/min Container capacity 700ml Nozzle diameter 2.6mm Max viscosity 90 DIN/s

Page 10

POWX357

PROBLEM

CAUSE

SOLUTION

11 NOISE

Noise values measured according to relevant standard. (K=3) Acoustic pressure level LpA 83 dB(A)

Acoustic power level LwA 96 dB(A)

ATTENTION! The sound power level may exceed 85 dB(A), in this case individual hearing protection shall be worn.

aw (Vibration) 0,1 m/s² K = 1,5 m/s²

12 TROUBLE SHOOTING

Motor hums but does not spray or irregular spraying.

Atomization is not good.

Over painting. Spray gun not clean, or not

Motor louder than normal.

No spray, no sound.

Operating sound not right.

“Orange Skin” excessive fogging.

Worn swirl head Pick up pipe not in the right position Blocked pick up pipe Blocked nozzle Blocked filter Control knob needs adjustment

Volume adjustment is not correct. Paint too thick

lubricated resulting in piston being stuck in cylinder Too much paint

Viscosity too low Spray gun not clean, or not

lubricated, resulting in piston being stuck in cylinder

No electricity Check power supply

Poor output adjustment Not enough paint in the container resulting in air being sucked in. Not diluting properly or not passing pick up pipe completely.

Incorrect solvent is used Spray gun too far from the surface. Paint too thick

Replace swirl head. Re-adjust pick up pipe.

Clean with thinner. Clean nozzle. Clean with thinner. Adjust.

Adjust. Check viscosity of the paint.

Disassemble spray gun and clean with thinner.

Adjust the volume clockwise to reduce spraying. Two thin coats are better then one Check viscosity

Disassemble spray gun and clean with thinner.

Re-adjust Refill with paint.

Check pick up pipe and viscosity level.

Use correct solvent. Hold spray gun closer to the object. Thin the paint

Page 11

POWX357

13 WARRANTY

 This product is warranted for a 36-month period effective from the date of purchase by the

first user.

 This warranty covers all material or production flaws. It does not include defective parts

subject to normal wear & tear such as bearings, brushes, cables, and plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects resulting from maltreatment, accidents or alterations; nor the cost of transportation.

 This warranty covers all material or production flaws, excluding batteries, chargers,

defective parts subject to normal wear and tear such as, in particular, bearings, brushes, cables, plugs… Accessories such as drills, drill bits, saw blades etc. also do not fall under this warranty.

 Damage and/or defects resulting from inappropriate use also do not fall under the

warranty provisions.

 We also disclaim all liability for any bodily injury resulting from inappropriate use of the

tool.

 Repairs may only be carried out by an authorised customer service centre for Powerplus

tools.

 You can always obtain more information at the number 00 32 3 292 92 90.  Any transportation costs shall always be borne by the customer, unless agreed otherwise

in writing.

 At the same time, no claim can be made on the warranty if the damage of the device is the

result of negligent maintenance or overload.

 Definitely excluded from the warranty is damage resulting from fluid permeation, excessive

dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not following the instructions given in the manual), inexpert assembly, lightning strike, erroneus net voltage. This list is not exhaustive.

 Acceptance of claims under warranty can never lead to the prolongation of the warranty

period nor commencement of a new warranty period in case of a device replacement.

 Devices or parts which are replaced under the warranty therefore remain the property of

Varo NV.

 We reserve the right to reject a claim whenever the purchase cannot be verified or when it

is clear that the product has not been properly maintained. (Clean ventilation slots, carbon brushes serviced regularly, etc.).

 Your purchase receipt must be kept as proof of date of purchase.  Your appliance must be returned undismantled to your dealer in an acceptably clean state,

(in its original blow-moulded case if applicable to the unit), accompanied by proof of purchase.

14 ENVIRONMENT

Should your appliance need replacement after extended use, do not dispose of it with the household refuse, but in an environmentally safe way. Waste produced by electrical machine items should not be handled like normal household rubbish. Please recycle where recycle facilities exist. Check with your Local Authority or retailer for recycling advice.

Page 12

POWX357

BELGIUM, declares that,

ovisions of the applicable

European Directives as they relate to European harmonized standards. Any unauthorized

European harmonized standards (including, if applicable, their amendments):

The undersigned acts on behalf of and under the power of attorney granted by the company

15 DECLARATION OF CONFORMITY

VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier -

Product: Spray station Trade mark: POWERplus Model: POWX357

is in conformity with the essential requirements and other relevant pr modification of the apparatus voids this declaration.

European Directives (including, if applicable, their amending directives):

2006/42/EC 2004/108/EC

EN50144-1 : 1998 EN50144-2-7 : 2000 EN55014-1 : 2006 EN55014-2 : 1997 EN61000-3-2 : 2006 EN61000-3-3 : 2008

management,

Philippe Vankerkhove Certification Manager Date: 18/06/2012

www.varo.com

Powerplus POWX357 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
