MULTI TOOL POWX134

1 APPLICATION

Your multi tool has been designed for drilling, routing, engraving, polishing, cutting, grinding and sanding of wood, metal, plastics and stone. It is not designed for commercial use.

WARNING! Read this manual and general safety instructions carefully before using the appliance, for your own safety. Your power tool should only be passed on together with these instructions.

2 DESCRIPTION (FIG A)

1. Power cord

2. Hook

3. Switch button

4. Access to carbon brush

5. Locking button

6. LED button

7. LED

3 PACKAGE CONTENT LIST

 Remove all packing materials  Remove remaining packaging and transit supports (if existing)  Check the completeness of the packing content  Check the appliance, the power cord, the power plug and all accessories for transportation

damages.

 Keep the packaging materials as far as possible till the end of the warranty period.

Dispose it into your local waste disposal system afterwards.

8. Lock nut

9. Adjustment button

10. LCD

11. Collet

12. Spanner

13. Flexible drive shaft

WARNING Packing materials are no toys! Children must not play with plastic bags! Danger of suffocation!

1 multi tool + Accessories 1 base 1 telescopic arm

When parts are missing or damaged, please contact your dealer.

4 SYMBOLS

In this manual and/or on the machine the following symbols are used:

1 chainsaw sharpening kit 1 Instruction manual

Page 4

POWX134 EN

5 GENERAL POWER TOOL SAFETY WARNINGS

Read all safety warnings and all instructions. Failure to follow all warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains operated (corded) power tool or battery operated (cordless) power tool.

5.1 Work area

 Keep work area clean and well lit. Cluttered and dark areas invite accidents.  Do not operate power tools in explosive atmospheres, such as in the presence of

flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

 Keep children and bystanders away while operating a power tool. Distractions can cause

you to lose control.

5.2 Electrical safety

Always check that the power supply corresponds to the voltage on the rating plate.

 Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.

 Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges

and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

 Do not expose power tools to rain or wet conditions. Water entering a power tool will

increase the risk of electric shock.

 Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power

tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

 When operating a power tool outdoors, use an extension cord suitable for outdoor use.

Use of a cord suitable for outdoor use reduces the risk of electric shock.

 If operating a power tool in a damp location is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces the risk of electric shock.

5.3 Personal safety

 Stay alert, watch what you are doing and use common sense when operating a power

tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.

 Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,

non-skid safety shoes, hard hat, or hearing protection used whenever conditions require will reduce personal injuries.

 Avoid accidental starting. Ensure the switch is in the off position before plugging in.

Carrying power tools with your finger on the switch or plugging in power tools that have the switch on invites accidents.

 Remove any adjusting key or wrench before turning the power tool on. A wrench or a key

left attached to a rotating part of the power tool may result in personal injury.

 Do not overreach. Keep proper footing and balance at all times. This enables better

control of the power tool in unexpected situations.

 Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and

gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

Page 5

 If devices are provided for the connection of dust extraction and collection facilities, ensure

these are connected and properly used. Use of these devices can reduce dust related hazards.

5.4 Power tool use and care

 Do not force the power tool. Use the correct power tool for your application. The correct

power tool will do the job better and safer at the rate for which it was designed.

 Do not use the power tool if the switch does not turn it on and off. Any power tool that

cannot be controlled with the switch is dangerous and must be repaired.

 Disconnect the plug from the power source before making any adjustments, changing

accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

 Store idle power tools out of the reach of children and do not allow persons unfamiliar with

the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.

 Maintain power tools. Check for misalignment or sticking of moving parts, breakage of

parts and any other condition that may affect the power tool’s operation. If damaged, have

the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

 Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting

edges are less likely to stick and are easier to control.

 Use the power tool, accessories and tool bits etc., in accordance with these instructions

and in the manner intended for the particular type of power tool, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from intended could lead to a hazardous situation.

5.5 Service

 Have your power tool serviced by a qualified repair person using only identical

replacement parts. This will ensure that the safety of the power tool is maintained.

6 SPECIFIC SAFETY WARNINGS

 Check that the maximum speed indicated on the grinding disc corresponds to the

maximum speed of the machine. The speed of the machine must not exceed the value on the grinding disc.

 Make sure that the dimensions of the grinding disc correspond to the specifications of the

machine.

 Make sure that the grinding disc has been mounted and fastened properly. Do not use

reducing rings or adapters to make the grinding disc fit properly.

 Treat and store grinding discs in conformance with the supplier’s instructions.  Do not use the machine for grinding workpieces with a maximum thickness exceeding the

maximum grinding depth of the grinding disc.

 Do not use grinding discs for deburring.  When grinding discs have to be mounted on the thread of the spindle, make sure that the

spindle has sufficient thread. Make sure that the spindle is sufficiently protected and does not touch the grinding surface.

 Before use, inspect the grinding disc for any damage. Do not use grinding discs which are

cracked, ripped or otherwise damaged.

 Before use, let the machine run idle for 30 seconds.  Immediately switch off the machine in case of abnormal vibrations or occurrence of

another defect. Carefully inspect the machine and grinding disc before switching the machine on again.

 Make sure that sparks do not put people into danger or that they contact highly flammable

substances.

POWX134 EN

Page 6

 Make sure that the workpiece is sufficiently supported or clamped. Keep your hands away

POWX134 EN

from the surface to be cut.

 Always wear safety goggles and hearing protection. If desired or required also use another

kind of protection like for example an apron or helmet.

 Ensure that mounted wheels and points are fitted in accordance with the manufacturer’s

instructions.

 Ensure that blotters are used when they are provided with the bonded abrasive product

and when they are required.

 If a guard is supplied with the tool never use the tool without such a guard.  For tools intended to be fitted with threaded hole wheel, ensure that the thread in the

wheel is long enough to accept the spindle length.

 Ensure that ventilation openings are kept clear when working in dusty conditions. If it

should become nessesary to clear dust, first disconnect the tool from the mains supply (use non metallic objects) and avoid damaging internal parts.

 Though poor conditions of the electrical mains, shortly voltage drops can appear when

starting the equipment. This can influence other equipment (eq. blinking of a lamp). If the mains-impedance Zmax <0.348 Ohm, such disturbances are not expected. (In case of need, you may contact your local supply authority for further information.

6.1 Additional safety instructions for powx134

Do not use the tool on light metal with a magnesium content exceeding 80%, as this type of metal is flammable.

 Make sure that the accessories used are suitable for the maximum speed stated in the

technical data.

 Make sure that the accessories are mounted according to the instructions.  Only use accessories and adapters supplied by the manufacturer.  Make sure that sparks cannot hit any persons or set flammable materials alight.  Always wear safety goggles, hearing protection and if necessary other protective means,

such as working gloves, hard hat, etc.

7 OPERATION

Before mounting an accessory, always unplug the tool.

7.1 Changing the attachment tools (see pic 3)

The small accessory attachments such as the grinding stones or cutting discs may be attached directly to the multi tool. If required , these tools may also be attach to the flexible drive shaft.

7.2 Attaching small tools directly to the multi tool. (see pic 4)

- Turn the collet chuck grip slightly while holding down the locking button until the button engages. Never press down on the locking button while the tool is running. If the collet chuck grip can not be loosened by hand, use the small spanner.

- Change the attachment tool. Always tighten attachment tools as much as possible. Shafts which extend out from the collet will cause wobbling.

- Tighten the collet chuck grip. To replace the collet chuck, remove the collet chuck grip and replace the chuck.

Page 7

7.3 Accessories

Pic 5

 Use: sharpening, deburring, rust

removal, shaping.

 Tip: Clean and shape the grinding bits

with the honing stone.

Pic 6

 Use: For fine engraving of various materials.  Tip: Work on metals at a low speed and process

as if it were hardwood.

 Plastics must be processed at low speeds

because of their tendency to melt during processing.

 Operating multi tool at a higher speed will lessen

vibration.

Pic 7

 Use: sanding , smoothing and shaping

wood and fiberglass.

PIC 8

 Use: Cleaning and shaping grinding

stones

Pic 9

 Use: Polishing metals and grinding

stones.

 Attention: Only polish with the sides of

the disc. The head of the stone would will leave scratches on the work piece.

7.3.1 Grinding bits

7.3.2 Grinding points

7.3.3 Sander

POWX134 EN

7.3.4 Grinding stone

7.3.5 Polishing discs

Page 8

7.3.6 Cutting disc

Pic 10

 Use: Cutting or slitting bolts, screws ,

sheet metal, thin wood and plastic.

Pic 11

 Use: Sanding , smoothing and shaping

wood and fiberglass.

Pic 12

 Turning on: Turn the power button to position I  Turning off:Turn the power button to position O

Pic 13

 The multi tool speed is continuously adjustable.

Always start from the lowest speed and then increase the speed to the desired level.

 “+” denotes the higher speed  “-” denotes the lower speed

7.3.7 Orbital sander

7.4 On / off switch

Always check that the power supply corresponds to the voltage on the rating plate.

POWX134 EN

7.5 Setting the speed

Page 9

POWX134 EN

Pic 14

 If you work in dark condition and want

see clearly the work area ,please turn on the LED

 Push the LED button (6),the LED is on

Fig 15

 If the multi tool motor sputters or

completely stops working , this means the carbon brushes have worn down.

 The multi tool has two carbon brushes.

Always replace both carbon brushes at the same time.

 Use a small screwdriver to open the

round cover .Replace the old carbon brushes with new ones, close the cover.

Voltage / frequency

230V / 50Hz

Power input

180W

No load speed

10.000 – 34.000 min-1

Spring chuck

Ф 10 x 15mm

7.6 LED light

8 CLEANING AND MAINTENANCE

Attention !Before performing any work on the equipment, pull the power plug.

8.1 Cleaning

 Keep the ventilation slots of the machine clean to prevent overheating of the engine.  Regularly clean the machine housing with a soft cloth, preferably after each use.  Keep the ventilation slots free from dust and dirt.  If the dirt does not come off use a soft cloth moistened with soapy water.

Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may damage the plastic parts.

8.2 Replacing the carbon brushes

9 TECHNICAL DATA

Page 10

POWX134 EN

Acoustic pressure level LpA

71 dB(A)

Acoustic power level LwA

82 dB(A)

aw (Vibration)

< 2,5 m/s²

K = 1.5 m/s²

10 NOISE

Noise values measured according to relevant standard. (K=3)

ATTENTION! Wear hearing protection when sound pressure is over 85 dB(A)

11 SERVICE DEPARTMENT

 Damaged switches must be replaced by our after-sales service department.  If the connecting cable (or mains plug) is damaged, it must be replaced by a particular

connecting cable which is available from our service department. Replacement of the connecting cable must only be carried out by our service department (see last page) or by a qualified person (qualified electrician).

12 STORAGE

 Thoroughly clean the whole machine and its accessories.  Store it out of the reach of children, in a stable and secure position, in a cool and dry

place, avoid too high and too low temperatures.

 Protect it from exposure to direct sunlight. Keep it in the dark, if possible.  Don’t keep it in plastic bags to avoid humidity build-up.

13 WARRANTY

 This product is warranted for a 36-month period effective from the date of purchase by the

first user.

 This warranty covers all material or production flaws excluding : batteries, chargers,

defective parts subject to normal wear & tear such as bearings, brushes, cables, and plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects resulting from maltreatment, accidents or alterations; nor the cost of transportation.

 Damage and/or defects resulting from inappropriate use also do not fall under the

warranty provisions.

 We also disclaim all liability for any bodily injury resulting from inappropriate use of the

tool.

 Repairs may only be carried out by an authorised customer service centre for Powerplus

tools.

 You can always obtain more information at the number 00 32 3 292 92 90.  Any transportation costs shall always be borne by the customer, unless agreed otherwise

in writing.

 At the same time, no claim can be made on the warranty if the damage of the device is the

result of negligent maintenance or overload.

 Definitely excluded from the warranty is damage resulting from fluid permeation, excessive

dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not following the instructions given in the manual), inexpert assembly, lightning strike, erroneus net voltage. This list is not exhaustive.

 Acceptance of claims under warranty can never lead to the prolongation of the warranty

period nor commencement of a new warranty period in case of a device replacement.

 Devices or parts which are replaced under the warranty therefore remain the property of

Varo NV.

Page 11

 We reserve the right to reject a claim whenever the purchase cannot be verified or when it

POWX134 EN

is clear that the product has not been properly maintained. (Clean ventilation slots, carbon brushes serviced regularly, etc.).

 Your purchase receipt must be kept as proof of date of purchase.  Your appliance must be returned undismantled to your dealer in an acceptably clean state,

(in its original blow-moulded case if applicable to the unit), accompanied by proof of purchase.

14 ENVIRONMENT

Should your appliance need replacement after extended use, do not discard it with the household rubbish but dispose of it in an environmentally safe way. Waste produced by electrical machine items should not be handled like normal household rubbish. Please recycle where recycle facilities exist. Check with your Local Authority or retailer for recycling advice.

15 DECLARATION OF CONFORMITY

VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,

product : Multitool trade mark : POWERplus model : POWX134

is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. Any unauthorized modification of the apparatus voids this declaration.

European Directives (including, if applicable, their amendments up to the date of signature);

2006/42/EC 2004/108/EC

European harmonized standards (including, if applicable, their amendments up to the date of signature);

EN60745-1 : 2009 EN60745-2-3 : 2007 EN55014-1 : 2006 EN55014-2 : 1997 EN61000-3-2 : 2006 EN61000-3-3 : 2008

Keeper of the Technical Documentation : Philippe Vankerkhove, VARO – Vic. Van Rompuy N.V.

The undersigned acts on behalf of the company CEO,

Philippe Vankerkhove Regulatory Affairs – Compliance Manager Date : 08/03/2012

Powerplus POWX134 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
