Powerplus POWX0761 User Manual

POWX0761 EN
1 APPLICATION ................................................................................ 4
2 DESCRIPTION ................................................................................ 4
3 PACKAGE CONTENT LIST ............................................................ 5
4 SYMBOLS ....................................................................................... 5
5 GENERAL POWER TOOL SAFETY WARNINGS ......................... 6
5.1 Work area ............................................................................................................... 6
5.2 Electrical safety ................................................................ ..................................... 6
5.3 Personal safety ...................................................................................................... 6
5.4 Power tool use and care ........................................................................................ 7
5.5 Service .................................................................................................................... 7
6 ADDITIONAL SAFETY INSTRUCTIONS FOR TABLE SAWS ...... 7
6.1 For both Mitre saw mode and table saw (bench saw) mode: .............................. 7
6.2 When using in Mitre saw mode: ............................................................................ 8
6.3 When using in the table saw (bench saw) mode: ................................................ 9
7 INSTALLATION .............................................................................. 9
7.1 Bench mounting (Fig. 1 & 3) ................................................................................. 9
7.1.1 For the fully-extended feet set up as the high table. ................................................. 9
7.1.2 For the folded feet set up as the low table ................................................................ 9
8 FUNCTIONAL DESCRIPTION ...................................................... 10
8.1 Blade guard (Fig. 4, 5 & 6) ................................................................................... 10
8.2 Maintaining maximum cutting capacity (Fig. 7) ................................................. 11
8.3 Adjusting the Mitre angle (Fig. 9 & 10) ............................................................... 11
8.4 Adjusting the bevel angle (Fig. 11 & 12) ............................................................. 11
8.4.1 In the Mitre saw mode............................................................................................ 11
8.4.2 In the table saw mode (Fig. 13) .............................................................................. 11
8.5 Switch action (Fig. 14) ......................................................................................... 12
8.5.1 Switch for the Mitre saw mode (A) ......................................................................... 12
8.5.2 Switch for the table saw mode (B) .......................................................................... 12
8.6 Adjusting the depth of cut (Fig. 15 - 21) ............................................................. 12
9 ASSEMBLY ................................................................................... 12
9.1 Socket wrench storage (Fig. 17) ......................................................................... 12
Copyright © 2008 VARO P a g e | 1 www.varo.com
9.2 Table height two-way set up ............................................................................... 12
POWX0761 EN
9.2.1 High table set up (Fig. 18) ...................................................................................... 12
9.2.2 Low table set up (Fig. 19) ...................................................................................... 13
9.3 Installing or removing saw blade ........................................................................ 13
9.4 Adjusting riving knife (fig 25,26 & 27) ................................................................ 13
9.5 Installing and adjusting rip fence (Fig. 28) ......................................................... 14
9.6 Installing and adjusting Mitre gauge (Fig. 35) .................................................... 15
9.7 Dust bag (Fig 36, 37 & 38) ................................................................................... 15
9.8 Securing workpiece ............................................................................................. 15
9.9 Setting up the tool in table saw mode ................................................................ 15
9.9.1 Securing the turn table (Fig. 41) ............................................................................. 15
9.9.2 Securing the tool head (Fig. 42) ............................................................................. 16
9.9.3 Releasing the lower limit stopper (Fig. 43) ............................................................. 16
9.9.4 Repositioning the riving knife (Fig. 44) ................................................................... 16
9.9.5 Removing the lower blade guard (Fig. 45) ............................................................. 16
9.9.6 Locking the tool head at fully lowered position (Fig. 46) ......................................... 16
9.9.7 Turning over the tool (Fig. 48) ................................................................................ 16
9.9.8 Installing the top blade guard (Fig. 49) ................................................................... 16
9.10 Setting up the tool in Mitre saw mode (Fig. 50) ................................................. 17
9.10.1 Removing the top blade guard ............................................................................... 17
9.10.2 Installing the lower blade guard C .......................................................................... 17
9.10.3 Turning over the tool .............................................................................................. 17
9.10.4 Releasing the tool head from fully lowered position ................................ ................ 17
9.10.5 Repositioning riving knife (Fig. 51) ......................................................................... 17
9.10.6 Installing or removing the sub fences R and L (Fig. 52) .......................................... 17
10 OPERATION.................................................................................. 18
10.1 Cutting as mitre saw ............................................................................................ 18
10.1.1 Press cutting .......................................................................................................... 18
10.1.2 Mitre cutting ................................ ................................ ........................................... 18
10.1.3 Bevel cut ................................................................................................................ 18
10.1.4 Compound cutting .................................................................................................. 19
10.1.5 Cutting aluminum extrusion (Fig. 56)...................................................................... 19
Copyright © 2008 VARO P a g e | 2 www.varo.com
10.2 Cutting as table saw (bench mode) .................................................................... 19
10.2.1 Work helpers ......................................................................................................... 19
10.2.2 Push block (Fig. 57) ............................................................................................... 19
10.2.3 Auxiliary fence (Fig. 58) ......................................................................................... 19
10.2.4 Ripping .................................................................................................................. 20
10.2.5 Cross cutting (Fig. 63)............................................................................................ 20
10.2.6 Mitre gauge............................................................................................................ 20
10.2.7 Use of Mitre gauge (Fig. 64) .................................................................................. 20
10.2.8 Auxiliary wood facing (Mitre gauge) (Fig. 65) ......................................................... 20
10.2.9 Carrying tool (Fig. 66) ............................................................................................ 21
11 MAINTENANCE ............................................................................ 21
POWX0761 EN
11.1 Adjusting the cutting angle ................................................................................. 21
11.1.1 Mitre angle ............................................................................................................. 21
11.1.2 Bevel angle ............................................................................................................ 21
11.2 Replacing carbon brushes (Fig. 73 & 74) ........................................................... 22
11.3 After use ............................................................................................................... 22
11.4 Service .................................................................................................................. 22
12 TECHNICAL DATA ....................................................................... 22
13 NOISE EMISSION VALUES ......................................................... 23
14 ENVIRONMENT ............................................................................ 23
15 DECLARATION OF CONFORMITY ............................................. 24
Copyright © 2008 VARO P a g e | 3 www.varo.com
POWX0761 EN
FLIP OVER SAW 1400W POWX0761
1 APPLICATION
The tool is intended for accurate straight and Mitre cutting in wood. The tool can be used both in Mitre saw mode and in table saw mode by turning over the table around its axis. It is not designed for commercial use.
WARNING! Read this manual and general safety instructions carefully before using the appliance, for your own safety. Your power tool should only be passed on together with these instructions.
2 DESCRIPTION
1. Adjusting bolt
2. Foot
3. /
4. Hex. bolt
5. U-shaped grooves
6. Lower blade guard A
7. Lower blade guard B
8. Lower blade guard C (used in the Mitre saw mode only)
9. Push button
10. Riving knife
11. Top blade guard (used in the table saw mode)
12. Top surface of turn table
13. Periphery of blade
14. Guide fence
15. Lower limit stopper
16. Nut
17. Clamping screw
18. Handle
19. Turn table
20. Lever
21. Cutting depth adjusting knob
22. Switch in the Mitre saw mode
23. Switch in the table saw mode
24. Lock-off button
25. Switch lever
26. On button
27. Off button
28. Stopper pin
29. Socket wrench
30. Wrench holder
31. Feet
32. /
33. /
34. Shaft lock
35. Lifting lever
36. Saw blade
37. Blade case
38. Arrow
39. Outer flange
40. Inner flange
41. Spindle
42. Ring
43. Clamping nut
44. Blade width
45. Rip fence holder
46. Guide rail
47. Clamping screw (A)
48. Clamping screw (B)
49. Rip fence
50. Line to be aligned with: Line (A)
51. Top table
52. Workpiece
53. Square nut
54. Scale
55. Adjusting screw
56. Top blade guard
57. Mitre gauge fence
58. Mitre gauge
59. Groove
60. Dust nozzle
61. Dust bag
62. Fastener
63. /
64. Vise arm
65. Vise rod
66. Vise knob
67. Saw head locked in the fully lowered position
68. Area of lever for hand/finger to be placed on
69. Hooking parts
70. Sub fence L
71. Sub fence R
72. Pin
73. Vise (accessory)
74. Spacer block
75. Aluminum extrusion
76. Face/edge parallel
77. Wood screw
78. Guide together
79. Push stick
80. Auxiliary fence
81. Push block
82. Cross cutting
83. Mitreing
84. Bevel cutting
85. Compound Mitreing (angles)
86. Knob
87. Tool part to be held carrying
88. Triangular rule
89. 0° adjusting bolt
90. 45° adjusting bolt
91. Arm
92. Bevel scale
93. Pointer
94. Limit mark
95. Brush holder cap
96. Screwdriver
Copyright © 2008 VARO P a g e | 4 www.varo.com
POWX0761 EN
Read manual before usage
For your safety, remove chips, small pieces, etc. from the table top before operation.
Warning / Danger
Unplug the tool before turning it over around the axis
Double insulated
Position hands properly when carrying
To avoid injury from flying debris, keep holding the saw head down, after making cuts, until the blade has come to a complete stop
Do not lift up the top end of the rip fence when installing or removing it.
Do not place hand or fingers close to the blade.
3 PACKAGE CONTENT LIST
Remove all packing materials Remove remaining packaging and transit supports (if existing) Check the completeness of the packing content Check the appliance, the power cord, the power plug and all accessories for transportation
damages.
Keep the packaging materials as far as possible till the end of the warranty period. Dispose
it into your local waste disposal system afterwards.
WARNING Packing materials are no toys! Children must not play with plastic bags! Danger of suffocation!
1 x Flip over saw 1400W 1 x Manual Accessories:
Steel & carbide-tipped saw blades Vertical vise Socket wrench 13-3 Dust bag Triangular rule Push stick
When parts are missing or damaged, please contact your dealer.
Ruler assembly (rip fence) Miter gauge Fix plate Hex bolt Elbow Top cover assy (top blade guard)
4 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Copyright © 2008 VARO P a g e | 5 www.varo.com
POWX0761 EN
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and all instructions. Failure to follow all warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains operated (corded) power tool or battery operated (cordless) power tool.
5.1 Work area
Keep work area clean and well lit. Cluttered and dark areas invite accidents. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used whenever conditions require will reduce personal injuries.
Avoid accidental starting. Ensure the switch is in the off position before plugging in.
Carrying power tools with your finger on the switch or plugging in power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
Copyright © 2008 VARO P a g e | 6 www.varo.com
If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust related hazards.
5.4 Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or sticking of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to stick and are easier to control.
Use the power tool, accessories and tool bits etc., in accordance with these instructions and
in the manner intended for the particular type of power tool, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from intended could lead to a hazardous situation.
5.5 Service
Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
6 ADDITIONAL SAFETY INSTRUCTIONS FOR TABLE SAWS
6.1 For both Mitre saw mode and table saw (bench saw) mode:
Wear eye and hearing protection. Other suitable personal protective equipment should be
worn.
NEVER wear gloves during operation except for replacing saw blades or handling rough
material before operation.
Keep the floor area around the tool level, well maintained and free of loose materials e.g.
chips and cut-offs.
Do not operate saw without guards and riving knife in place. Check blade guards for proper
closing before each use. Do not operate saw if blade guards do not move freely and close instantly. Never clamp or tie the blade guards into the open position. Any irregular operation of the blade guards should be corrected immediately.
Clean and be careful not to damage the spindle, flanges (especially the installing surface)
and hex bolt before or when installing the blade. Damage to these parts could result in blade breakage. Poor installation may cause vibration/ wobbling or slippage of the blade. Use only flanges specified for this tool.
Check the blade carefully for cracks or damage before operation. Do not use saw blade
which are damaged or deformed.
Use only saw blades recommended by the manufacturer and which conform to EN847-1,
and observe that the riving knife must not be thicker than the width of the cut by the saw blade and not thinner than the body of the blade.
Always use accessories recommended in this manual. Use of improper accessories such as
abrasive cut-off wheels may cause an injury.
POWX0761 EN
Copyright © 2008 VARO P a g e | 7 www.varo.com
Select the correct saw blade for the material to be cut.
POWX0761 EN
Do not use saw blades manufactured from high speed steel. To reduce the emitted noise, always be sure that the blade is sharp and clean. Use correctly sharpened saw blades. Observe the maximum speed marked on the saw
blade.
Do not cut metals such as nails and screws. Inspect for and remove all nails, screws and
other foreign matter from the workpiece before operation.
 Knock out any loose knots from workpiece BEFORE beginning to cut.  Don’t use the tool in the presence of flammable liquids or gases.  For your safety, remove the chips, small pieces, etc. from the work area and table top
before plugging the tool and starting operation.
The operator is adequately trained in the use, adjustment and operation of the tool. Keep hands and make your bystander and yourself position out of path of and not in line
with saw blade. Avoid contact with any coasting blade. It can still cause severe injury and never reach around saw blade.
Be alert at all times, especially during repetitive, monotonous operations. Don't be lulled into
(6) false sense of security. Blades are extremely unforgiving.
Make sure the shaft lock is released before the switch is turned on. Before using the tool on an actual workpiece, let it run for (6) while. Watch for vibration or
wobbling that could indicate poor installation or (6) poorly balanced blade.
Wait until the blade attains full speed before cutting. The tool should not be used for slotting, rabbetting or grooving. Retain from removing any cut-offs or other parts of the workpiece from the cutting area
whilst the tool is running and the saw head is not in the rest position.
Stop operation immediately if you notice anything abnormal. Turn off tool and wait for saw blade to stop before moving workpiece or changing settings. Unplug tool before changing blade, servicing or not in use. Some dust created from operation contains chemicals known to cause cancer, birth defects
or other reproductive harm. Some examples of these chemicals are:
lead from lead-based-painted material and, arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in (6) well ventilated area and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles.
Connect the tool to (6) dust collecting device when sawing. Make sure that the table is securely fixed with the lever after turning it over.
6.2 When using in Mitre saw mode:
Do not use the saw to cut other than wood, aluminum or similar materials. Do not perform operation freehand when cutting workpiece in an area close to saw blade.
The workpiece must be secured firmly against the turn table and guide fence during all operations.
Make sure that the turn table is properly secured so it will not move during operation. Make sure that the arm is securely fixed when beveling. Tighten the lever clockwise to fix
the arm.
Make sure the blade does not contact the turn table in the lowest position and is not
contacting the workpiece before the switch is turned on.
Hold the handle firmly. Be aware that the saw moves up or down slightly during start-up and
stopping.
Copyright © 2008 VARO P a g e | 8 www.varo.com
Loading...
+ 16 hidden pages
