LED TORCH 3W
Read the manual before using the machine
POWLI422 EN
POWLI422
WARNING! For your own safety, read this manual and the general
safety instructions carefully before using the spotlight. Your
spotlight should only be given to other users together with these
instructions.
1 DESCRIPTION (FIG. A)
1. On/Off switch top light
2. On/Off switch side light
3. Charger base
4. Charging indicator
5. AC/DC adapter
6. 12V car adapter
7. Magnet
8. Rubberized housing
2 CONTENTS
Remove all packaging materials.
Remove remaining packaging and packing inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for
transportation damage.
Keep the packaging materials as far as possible until the end of the warranty period.
Then take it to your local waste disposal system.
WARNING Packaging materials are not toys! Children must not play
with plastic bags! There is a danger of suffocation!
1 x spotlight
1 x charger
1 x 12V car adapter
1 x AC/DC adapter
1 x manual
If any parts are missing or damaged, please contact your dealer.
3 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Copyright © 2014 VARO P a g e | 1 www.varo.com
Page 2
POWLI422 EN
In accordance with essential applicable safety standards of European
directives
4 WARNINGS
Do not use if any parts are broken, bent, cracked or damaged. Any work light that
appears damaged in any way or operates abnormally must be removed from service
immediately. Inspect before each use.
This work light is not to be used by children. Keep out of reach of children.
Do not leave work light on and unattended.
Do not expose to fire or high temperatures; the battery may explode.
Do not charge or use near open flames or glowing embers.
Do not shine directly into eyes.
Never block lens and reflector during operation.
Do not store the work light for an extended period of time. Charge the battery every
three months during storage.
Do not charge the battery for an extended period of time. Overcharging will greatly
shorten battery life.
You must give the work light battery a top-up charge at the time of purchase.
Avoid charging at temperatures below 4℃.
The DC charging plug may very warm when in use. Unplug from receptacle with
caution.
5 OPERATION
5.1 Magnetic base
The work light features a magnetic base on the bottom, allowing the light to be
magnetically attached to a vehicle or other metal objects.
NOTE Do not place the light on or near computer equipment,
computer disks or other types of magnetic storage equipment as
strong magnetic fields can erase or corrupt data.
5.2 Different modes
On the back of the light, there are 2 ON/OFF switches to control the light.
Press the top switch to turn 3W LED torch head on and press again to turn off.
Press the bottom switch to turn the 12LED floodlight on in low light mode. Press
again to turn into high light mode. Press a tird time to switch back off.
NOTE: This work-light has a charge and discharge protection, so in
order to better protection for battery life, it suggests that don't make
the product into a state of charge for a long time or discharge
completely exhausted.
Copyright © 2014 VARO P a g e | 2 www.varo.com
Page 3
6 CHARGING THE BATTERY
Model
POWLI422
Nominal lifetime
100,000 Hours
Battery
Battery type
Li-ion
Battery pack
3.7V-2200mAh
Charging time
1 hour
Top light
Bulb type
3W Cree LED
Working time
3 hours
Side light
Bulb type
12 * 0.5W LED
POWLI422 EN
The work light is using fast charge technology. This light must be
fully charged before being used for the first time. It is recommended
that the battery be re-charged every 3 months to ensure maximum
performance in an emergency.
This will ensure that the battery gives its best performance now and on future re-charging
cycles. The charging base and AC and DC charging adapters are for re-charging the
battery only. They can not be used to directly power the light.
6.1 Using the ac/dc charging adapter
First put the work light into the charging base, the charging position as above picture.
This quick charge work light have magnet on bottom, it can stick the charging base
easily. Then you plug the charging jack into the socket of the charging base next to
the LED charging indicator and make sure it is firmly seated.
Plug the adapter into a 230V socket and switch the socket on (if applicable).
The charging indicator lamp will glow RED while charging is in progress.
The battery will be fully charged after approximately 60 minutes, and the RED
charging indicator will turn to GREEN when the unit is fully charged. Disconnect the
jack plug from the charging base, remove the adapter from the wall socket or switch
off.
6.2 Using 12v dc adapter to charge
First put the work light into the charging base, the charging position as above picture.
This quick charge work light have magnet on bottom, it can stick the charging base
easily. Then plug the charging jack into the socket of the charging base next to the
LED charging indicator and make sure it is firmly seated.
Plug the adapter into the vehicles 12V DC cigarette lighter or accessory power
socket.
The charging indicator lamp will glow RED while charging is in progress.
The battery will be fully charged after approximately 60 minutes, and the RED
charging indicator will turn to GREEN when the unit is fully charged. Disconnect the
jack plug from the charging base; remove the adapter from the 12V socket.
7 TECHNICAL DATA
Copyright © 2014 VARO P a g e | 3 www.varo.com
Page 4
POWLI422 EN
Working time low mode
3 hours
Working time high mode
1.5 hours
8 ENVIRONMENT
IMPORTANT: BATTERY DISPOSAL:
This product contains Li-ion. To preserve natural resources, please recycle or dispose of
batteries properly. Local, state or federal laws may prohibit disposal of Li-ion batteries in
ordinary trash. Consult you local waste authority for information regarding available
recycling and/or disposal options.
Should your spotlight need replacement after extended use, do not put it
in the domestic waste but dispose of it in an environmentally safe way.
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice.
