Powerplus POWLI120 User Manual
ENERGY SAVING FLOODLIGHT 32W
Read the manual before using the machine
In accordance with essential applicable safety standards of European
directives
POWLI120 EN
POWLI120
1 DOMAIN OF USAGE
Outdoor or indoor usage such as jobsite, garden, studio and workshop.
WARNING! Read this manual and general safety instructions
carefully before using the appliance, for your own safety. Your
power tool should only be passed on together with these
instructions.
2 SYMBOLS
In this manual and/or on the machine the following symbols are used:
3 WARNING
The floodlight may not be attached against a mast (pole). Best installed onto a fence
or a wall, in a warehouse, shop or a similar place.
Replace the protection glass immediately if damaged.
4 ASSEMBLYING THE FLOODLIGHT
Before mounting the energy-saving floodlight ensure that the mains voltage is
switched off.
The floodlight can not be adjusted to point downwards.
To fix the floodlight onto normal inflammable surfaces follow the instructions as
shown in (Fig. 2 - 3).
Do not mount the projector onto the ceiling.
5 WIRING DIAGRAM (FIG. 1)
Fix the wiring in the connection block according to the included diagram (Fig. 1):
a=brown conductor of the network cable (L)
b=blue conductor power cable (N)
c=yellow/green: grounding cable
6 USING THE FLOODLIGHT
Simply plug in the cable of the floodlight to the socket.
7 FIXING AND CHANGING AN ENERGY-SAVING LAMP (FIG 4)
When the energy-saving lamp needs changing, switch off the lamp at the mains
before opening the lid.
Copyright © 2014 VARO P a g e | 1 www.varo.com
Insert the energy-saving lamp into the lamp holder gently.
Type
POWLI120
Power
32W
Voltage/frequency
220-240V~50Hz
Bulb type
PL 3U
Bulb holder
P4G01
Bulb life-span
>8000
Floodlight facade material
Tempered glass
Waterproof protection grade
IP44
POWLI120 EN
8 SPECIFICATION
9 ENVIRONMENT
Copyright © 2014 VARO P a g e | 2 www.varo.com
Should your appliance need replacement after extended use, do not
discard it with the household rubbish but dispose of it in an
environmentally safe way.
Waste produced by electrical machine items should not be handled like
normal household rubbish. Please recycle where recycle facilities exist.
Check with your Local Authority or retailer for recycling advice.
