Powerplus POWLI020 User Manual

HALOGEN FLOODLIGHT 500W

Read the manual before using the machine

In accordance with essential applicable safety standards of European
directives

POWLI020 EN

POWLI020

1 DOMAIN OF USAGE

Outdoor or indoor usage such as jobsite, garden, studio and workshop.

WARNING! Read this manual and general safety instructions
carefully before using the appliance, for your own safety. Your
power tool should only be passed on together with these
instructions.

2 SYMBOLS

In this manual and/or on the machine the following symbols are used:

3 WARNING

 The floodlight may not be put against a mast (pole). Best installed onto a fence or a

wall, in a warehouse, shop or a similar place.

 Replace the protection glass immediately if damaged.

4 ASSEMBLYING THE FLOODLIGHT

 Before mounting the Halogen floodlight ensure that the mains voltage is switched off.
 The floodlight must be placed at least one meter away from the area that you wish to

be lit. (as shown in Fig.3)

 The floodlight can not be adjusted to point downwards.
 To fix the floodlight onto normal inflammable surfaces follow the instructions as

shown in (Fig.2.)

 Do not mount the projector onto the ceiling.
 The fitting should be levelly mounted so that the head of the fitting is no more than 4º

from the horizontal plane. (Fig 4)

5 WIRING DIAGRAM (FIG. 1)

Fix the wiring in the connection block according to the included diagram (Fig. 1):
a=brown conductor of the network cable (L)
b=blue conductor power cable (N)
c=yellow/green: grounding cable

Copyright © 2014 VARO P a g e | 1 www.varo.com

6 USING THE FLOODLIGHT

Type

POWLI020

Power

500W

Voltage/frequency

220V-240V~50Hz

Bulb type

Tungsten halogen tube

Bulb holder

R7s

Bulb life-span

1000

Floodlight facade material

tempered glass

Waterproof protection grade

IP44

 Simply plug in the cable of the floodlight to the socket.

7 FIXING AND CHANGING A HALOGEN TUBE

 When the halogen tube needs changing, switch off the lamp at the mains before

opening the lid.

 Insert the halogen lamp into the lamp holder gently.
 Do not touch the halogen lamp with your bare hands (Fig.5.)

POWLI020 EN

8 SPECIFICATION

9 ENVIRONMENT

Copyright © 2014 VARO P a g e | 2 www.varo.com

Should your appliance need replacement after extended use, do not
discard it with the household rubbish but dispose of it in an
environmentally safe way.
Waste produced by electrical machine items should not be handled like
normal household rubbish. Please recycle where recycle facilities exist.
Check with your Local Authority or retailer for recycling advice.
