MAP55 SERIES

Power-One's MAP55 series of power supplies provides reliable, tightly
regulated DC power for commercial and industrial systems. Wide­range AC input and full international safety, EMI, and ESD
compliance ensure world-wide acceptance. All units bear the CE
Mark.

The MAP55 utilizes a thermally efficient U-channel chassis design,
which allows full power operation in convection cooled applications.

Other mechanical design innovations include metric and SAE
mounting inserts on each mounting surface to provide integration
flexibility. Dual-mode connectors provide traditional terminal block
connections or popular single row Molex connector mating.

Single output models feature wide-range output adjustability to meet a
wide variety of standard and user specific output voltage requirements.

FEATURES

• Wide Range Input for 110/220 VAC Applications

• Meets EN55022, Conducted Class B Limits

• Compact Footprint: 6.00" x 3.27" x 1.60"
(152.4mm x 83.1mm x 40.6mm)

• Greater than 225,000 Hours MTBF

• Metric and SAE Mounting Inserts

SINGLE OUTPUT MODEL SELECTION CHART

MODEL

OUTPUT ADJUSTMENT MAXIMUM OUTPUT PEAK OUTPUT LINE LOAD RIPPLE & NOISE INITIAL SETTING

VOLTAGE RANGE CURRENT CURRENT (NOTE 3) REGULATION REGULATION %p-p (NOTE 1) ACCURACY

MAP40-1005 5V 4.7V to 5.50V 8A 11A 0.2% ±1.5% 1% 5.0V to 5.2V
MAP55-1012 12V/15V 11.4V to 15.75V 5.0/4.0A (Note 2) 5.8/4.7A (Note 2) 0.2% ±1% 1% 12.0V to 12.2V
MAP55-1024 24V/28V 23.5V to 28.5V 2.5/2.2A (Note 2) 2.9/2.5A (Note 2) 0.2% 1% 1% 23.8V to 24.2V

NOTES: 1) Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth.

2) MAP55-1012 output currents are expressed as 12V/15V operation. MAP55-1024 output currents are expressed as 24V/28V operation.

3) Peak load for 60 seconds or less are acceptable, 10% duty cycle, maximum.

MULTIPLE OUTPUT MODEL SELECTION CHART – 55W CONTINUOUS OUTPUT POWER

MODEL

OUTPUT ADJUSTMENT OUTPUT PEAK OUTPUT LINE LOAD RIPPLE & NOISE INITIAL SETTING

VOLTAGE RANGE CURRENT CURRENT (NOTE 1) REGULATION REGULATION %p-p (NOTE 2) ACCURACY

+5V 4.7V to 5.6V 6A 8A 0.2% 2% 1% 5.0V to 5.2V

MAP55-4000

+12V Fixed 3A 5A 0.2% 2% 1% 11.6V to 12.4V

-5V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% -4.8V to -5.2V

-12V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% -11.6V to -12.4V
+5V 4.7V to 5.6V 6A 8A 0.2% 2% 1% 5.0V to 5.2V

MAP55-4001

+24V Fixed 1.5A 2.5A 0.2% 2% 1% 23.0V to 24.9V

-12V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% -11.6V to -12.4V

+12V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% 11.6V to 12.4V

+5V 4.7V to 5.6V 6A 8A 0.2% 2% 1% 5.0V to 5.2V

MAP55-4002

+12V Fixed 3A 5A 0.2% 2% 1% 11.6V to 12.4V

-12V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% -11.6V to -12.4V

+12V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% 11.6V to 12.4V

+5V 4.7V to 5.6V 6A 8A 0.2% 2% 1% 5.0V to 5.2V

MAP55-4003

+15V Fixed 2.5A 3.5A 0.2% 2% 1% 14.6V to 15.4V

-5V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% -4.8V to -5.2V

-15V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% -14.4V to -15.6V
+5V 4.7V to 5.6V 6A 8A 0.2% 2% 1% 5.0V to 5.2V

MAP55-4004

+24V Fixed 1.5A 2.5A 0.2% 2% 1% 23.0V to 24.9V

-15V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% -14.5V to -15.5V

+15V Fixed 0.5A 1A (Note 3) 0.5% 2% 1% 14.5V to 15.5V

NOTES: 1) Peak loads up to 65 watts for 60 seconds or less are acceptable, (10% duty cycle max.). Peak power must not exceed 65 watts.

2) Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth.

3) Maximum load on V3 or V4 could be 1 amp continuous if output V4 or V3 is unloaded.

REV. 09/01

2

INPUT SPECIFICATIONS

PARAMETER CONDITIONS/DESCRIPTION MIN NOM MAX UNITS

Input Voltage - AC Continuous input range. 90 132 VAC

175 264
Input Frequency AC input. 47 63 Hz
Brown Out Protection Lowest AC input voltage that regulation is maintained with full rated loads. 90 VAC
Hold-up Time Nominal AC Input Voltage (115VAC), full rated load. 20 ms
Input Current 90 VAC (55W load). 1.6 ARMS
Input Protection Non-user serviceable internally located AC input line fuse.
Inrush Surge Current Internally limited by thermistor. Vin = 264VAC (one cycle). 25° C. 38 A

PK

Operating Frequency Switching frequency of power supply (varies with load). 22 180 kHz

OUTPUT SPECIFICATIONS

PARAMETER CONDITIONS/DESCRIPTION MIN NOM MAX UNITS

Efficiency Full load, 115VAC. Varies with distribution of loads among outputs. 73 %
Minimum Loads MAP55-1012 0.21

MAP55-1024 0.11 Amps

MAP40-1005 and all multiple output models, main channel only. 0.50
Ripple and Noise Full load, 20MHz bandwidth. See Model Selection Chart.
Output Power Continuous output power, all multiple output models. 55 Watts

Peak output power (60s maximum, 10% duty cycle), all multiple output models. 65 Watts
Overshoot / Undershoot Output voltage overshoot/undershoot at turn-on, V1, V2. 1 %
Regulation Varies by output. Total regulation includes: line changes from 90-132 VAC or 175-264 VAC, See Model Selection Chart.

changes in load starting at 20% load and changing to 100% load.
Transient Response Recovery time, to within 1% of initial set point due to a 50-100% 500 µs

load change, 4% max. deviation. (Main output of multiple output units).
Turn-on Delay Time required for initial output voltage stabilization. 1 4 Sec
Turn-on Rise Time Time required for output voltage to rise from 10% to 90% (Note 1). 7 ms

NOTES: 1) Nominal rise time for MAP55-1024 is 36 msec.

INTERFACE SIGNALS AND INTERNAL PROTECTION

PARAMETER CONDITIONS/DESCRIPTION MIN NOM MAX UNITS

Overvoltage Protection MAP40-1005 5.5 6.8

MAP55-1012 17.5 19.7 V
MAP55-1024 32.0 36.0

Main output only of multiple output units. 5.6 6.8

Overload Protection Fully protected against output overload and short circuit. Automatic recovery upon removal of overload condition.

SAFETY, REGULATORY, AND EMI SPECIFICATIONS

PARAMETER CONDITIONS/DESCRIPTION MIN NOM MAX UNITS

Agency Approvals UL1950.

CSA 22.2 No. 234/950. Approved.

EN60950 (TUV).
Dielectric Withstand Input to output. 2600 VDC

Voltage
Electromagnetic FCC CFR title 47 Part 15 Sub-Part B - conducted & radiated. B

Interference, EN55022 / CISPR 22 conducted. B Class
Conducted EN55022 / CISPR 22 radiated. A

Insulation Resistance Input to output. 7 MΩ
Leakage Current Per EN60950, 264VAC. 500 µA

MAP55 SERIES

3

ENVIRONMENTAL SPECIFICATIONS

PARAMETER CONDITIONS/DESCRIPTION MIN NOM MAX UNITS

Altitude Operating. 10k Feet

Non-operating. 40k

Operating Temperature Derate linearly above 50°C by 2.5% per °C At 100% load: 0 50 °C

to a maximum temperature of 70°C. At 50% load: 0 70 °C
Storage Temperature -40 85 °C
Temperature Coefficient 0°C to 70°C (after 15 minute warm-up). ±0.02 ±0.03 %/°C
Relative Humidity Non-condensing. 5 95 %RH
Shock Operating, peak acceleration. 20 G
Vibration Random vibration, 10 Hz to 2 kHz, 3 axis. 6 GRMS

OPTIONS

DESCRIPTION NOTES DIMENSIONS

Cover Add ‘C’ suffix to model number or order part number 412-59584 separately. 6.00" x 3.27" x 1.85"

For convection cooled applications, derate output power to 45 watts on multiple (152.4mm x 83.1mm x 47.0mm)
output units, 50 watts on MAP55-1012 and MAP55-1024,and 40 watts on MAP40-1005.

MAP55 SERIES

OVERALL SIZE: 6.00" x 3.27" x 1.60" (152.4mm x 83.1mm x 40.6mm)

WEIGHT: 1.1 LBS (0.55 kg)

INPUT & OUTPUT CONNECTIONS: 6-32 SCREW WIRE CLAMPS ON 0.312" (7.9mm) CENTERS, 0.045" (1.1mm)

SQUARE PINS ON 0.156" (3.4mm) CENTERS, MATES WITH MOLEX SERIES 2139, 6442, OR 41695

CHASSIS: 0.090" (2.3mm) ALUMINUM ALLOY, WITH CLEAR FINISH
