PowerBoss Admiral 38C User Manual
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 1
User Manual
Admiral 38C Cylindrical
Sweeper/Scrubber
PowerBoss, Inc.
A Member Of The Hako Group
PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 2
Intended use
The Admiral 38C is a large-area scrubberdrier designed for wet cleaning rough and
structured hard oors inside buildings,
such as in multistorey car parks or logistics
and industrial areas. Any use beyond this
is regarded as improper use. The manufacturer is not considered liable for any
damage resulting from improper use; the
user is solely responsible for all the risks.
The Admiral 38C has not been
approved for use on public paths
and roads.
Intended use also includes maintaining
and observing the operating, maintenance
and repair conditions prescribed by the
manufacturer.
The Admiral 38C may only be operated,
serviced and repaired by personnel who
are familiar with the work involved and are
aware of the risks.
The applicable accident prevention laws
must be observed and any generally accepted health and safety directives must
be maintained.
Introduction
Introduction
Preface
Dear Customer,
Please read this original manual thoroughly before starting the vehicle for the
rst time and keep it in the vicinity of the
vehicle for future reference or subsequent
owners.
We are certain that the excellent qualities
of the vehicle will justify the faith you have
shown in us through your purchase.
Please read the Chapter “Safety Information” prior to starting the vehicle to ensure
it is operated and used safely. Your safety,
and that of others, basically lies in your
ability to control and operate the vehicle.
Therefore, read the operating manual
thoroughly before starting the vehicle up
for the rst time. The operating manual
contains all the most important information regarding operation, maintenance and
service. Throughout this operating manual,
texts which concern safety are indicated
by corresponding symbols.
Should you have any questions in respect
of the vehicle or operating manual, your
authorized PowerBoss dealer is available
to provide help at any time. We would like
to emphasize that no legal claims can
be asserted in respect of any information
provided in this manual. Please pay attention that only original spare parts should
be used for any necessary maintenance
and repair work. Only original spare parts
can guarantee long, reliable equipment
operation. We reserve the right to make
technical improvements.
Valid as of: January 2010
PowerBoss Inc.
175 Anderson Street
NC 28315 U.S.A.
Telephone: (910) 944-2105
Fax: (910) 944-740
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 3
Based on the conception, design and construction of the vehicle introduced onto the
market by us, the vehicle complies with the
applicable basic safety and health requirements stipulated in the EC Directive (refer
to the Declaration of Conformity). This
declaration is no longer considered valid
in the event of modications to the vehicle
not authorized by us. The manufacturer is
not deemed liable for any damage resulting from unauthorized modications to the
vehicle.
Introduction
Notes on warranty
The terms dened in the purchase agreement apply. Claims for compensation
related to damage are excluded from the
terms of warranty when the damage is
the result of failure to observe regulations
concerning service and maintenance.
Maintenance work must be performed at
authorized PowerBoss service centers and
conrmed in the “Maintenance Report”
which serves as a warranty logbook.
The following are excluded from the terms
of warranty: wear and tear through overuse, defective fuses, improper handling or
unauthorized modications. Claims under
the terms of warranty are annulled when
damage occurs to the vehicle resulting
from the use of parts or accessories not
explicitly approved by us or from failure to
observe maintenance regulations.
Acceptance of the vehicle
The vehicle must be inspected directly after delivery for signs of transport damage.
Replacement will be made when conrmation is provided immediately by the
German Federal Railway (Deutsche Bahn
AG) or the freight carrier with regard to the
damage and the damage report is sent to
us together with the consignment note:
PowerBoss Inc.
175 Anderson Street
NC 28315 U.S.A.
Telephone: (910) 944-2105
Fax: (910) 944-740
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 4
Introduction . . . . . . . . . . . . .2
Preface . . . . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . . .2
Notes on warranty . . . . . . . . . . . 3
Acceptance of the vehicle . . . . .3
1 Safety Information. . . . . . . .6
1.1 Safety and warning labels . . . . . 6
1.2 General information . . . . . . . . . . 7
1.3 Operating information. . . . . . . . . 7
1.4 Maintenance information . . . . . .9
1.5 Particular risks . . . . . . . . . . . . . . 10
1.5.1 Electronics . . . . . . . . . . . . . . . . . 10
1.5.2 Batteries . . . . . . . . . . . . . . . . . . . 10
1.6 Environmental protection . . . . . .11
1.7 Labels on the vehicle . . . . . . . . .12
2 Starting Up . . . . . . . . . . . . . .15
2.1 Instruction. . . . . . . . . . . . . . . . . . 15
2.2 Initial battery charge. . . . . . . . . .15
2.3 Prior to starting up for the
rst time . . . . . . . . . . . . . . . . . . . 16
2.3.1 Installing the rotary brushes . . . . 16
2.3.2 Installing and adjusting the
squeegee . . . . . . . . . . . . . . . . . .19
2.3.3 Adjusting the driver’s seat . . . . . 20
2.4 Before starting up daily . . . . . . .20
3 Operation . . . . . . . . . . . . . . .21
3.1 Method of operation . . . . . . . . . .21
3.1.1 Rotary brush head . . . . . . . . . . . 21
3.1.2 Squeegee. . . . . . . . . . . . . . . . . .23
3.1.3 Suction turbines (suction). . . . . . 24
3.1.4 Solution tank . . . . . . . . . . . . . . .24
3.1.5 Recovery tank . . . . . . . . . . . . . .24
3.1.6 Traction drive . . . . . . . . . . . . . . .25
3.1.7 Brakes . . . . . . . . . . . . . . . . . . . . 25
3.1.8 Batteries and charger. . . . . . . . .25
3.1.9 Options . . . . . . . . . . . . . . . . . . . .26
3.2 Operating and indicator
elements. . . . . . . . . . . . . . . . . . . 29
3.2.1 Operating elements in the
driver’s cab. . . . . . . . . . . . . . . . .29
3.2.2 Left-hand operating panel . . . . .32
3.2.3 Right-hand operating panel . . . .36
3.2.4 Operating elements on the
vehicle . . . . . . . . . . . . . . . . . . . . 39
3.3 Operation . . . . . . . . . . . . . . . . . .43
3.3.1 Switching the vehicle on. . . . . . . 43
3.3.2 Accelerating . . . . . . . . . . . . . . . .43
3.3.3 Stopping and parking . . . . . . . . .44
3.3.4 Cleaning . . . . . . . . . . . . . . . . . . . 44
3.3.5 Switching the vehicle off. . . . . . . 46
3.3.6 Loading and transporting
the vehicle . . . . . . . . . . . . . . . . . 46
Table of Contents
3.4 After nishing work. . . . . . . . . . .47
3.5 Function faults . . . . . . . . . . . . . .48
3.5.1 Error code table . . . . . . . . . . . . . 48
3.5.2 Other function faults . . . . . . . . . . 49
4 Technical Data . . . . . . . . . . .50
5 Maintenance and Service . .56
5.1 PowerBoss system
maintenance . . . . . . . . . . . . . . . . 56
5.2 Maintenance report . . . . . . . . . .57
5.3 Maintenance schedule . . . . . . . .58
5.3.1 PowerBoss system
maintenance, customer . . . . . . .58
5.3.2 PowerBoss system
maintenance I. . . . . . . . . . . . . . . 60
5.3.3 PowerBoss system
maintenance II . . . . . . . . . . . . . . 63
5.3.4 PowerBoss system
maintenance III/S
(safety check). . . . . . . . . . . . . . .64
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 5
Table of Contents
5.4 Battery system . . . . . . . . . . . . . .65
5.4.1 Charging batteries . . . . . . . . . . .66
5.4.2 Servicing the driving batteries 67
5.4.3 Disassembling the batteries . . . . 67
5.4.4 Installing the batteries . . . . . . . .67
5.4.5 Disposing of batteries. . . . . . . . . 69
5.4.6 Total discharge signal
transducer (TSG) . . . . . . . . . . . .69
5.5 Solution tank . . . . . . . . . . . . . . .70
5.5.1 Filling the solution tank . . . . . . . . 71
5.5.2 Emptying the solution tank . . . . . 71
5.5.3 Cleaning the draining
hose cap. . . . . . . . . . . . . . . . . . . 71
5.5.4 Cleaning the lter in the
solution feed . . . . . . . . . . . . . . . .71
5.6 Recovery tank . . . . . . . . . . . . . .72
5.6.1 Emptying the recovery tank . . . . 73
5.6.2 Cleaning the recovery tank . . . .73
5.6.3 Cleaning the draining
hose cap. . . . . . . . . . . . . . . . . . . 74
5.6.4 Cleaning the air intake lter . . . . 74
5.6.5 Cleaning the openings to the
solution tank . . . . . . . . . . . . . . . . 74
5.7 Rotary brush head . . . . . . . . . . . 75
5.7.1 Emptying and cleaning the
waste container . . . . . . . . . . . . . 76
5.7.2 Changing the rotary
brushes. . . . . . . . . . . . . . . . . . . .77
5.7.3 Cleaning the contact
surfaces . . . . . . . . . . . . . . . . . . . 78
5.7.4 Adjusting the locking lever
for the brush holder . . . . . . . . . . 78
5.7.5 Installing new rubber
deector strips . . . . . . . . . . . . . .79
5.7.6 Adjusting the rotary
brush head . . . . . . . . . . . . . . . . .79
5.7.7 Direction of rotation of
the rotary brushes . . . . . . . . . . .80
5.8 Squeegee. . . . . . . . . . . . . . . . . .81
5.8.1 Cleaning the squeegee . . . . . . .81
5.8.2 Disassembling the
squeegee . . . . . . . . . . . . . . . . . .81
5.8.3 Installing the squeegee . . . . . . .81
5.8.4 Changing the sealing strips . . . .82
5.9 Wheels . . . . . . . . . . . . . . . . . . . .82
5.9.1 Front wheel. . . . . . . . . . . . . . . . .82
5.9.2 Rear wheels . . . . . . . . . . . . . . . .82
5.10 Electrical installation. . . . . . . . . . 83
5.10.1 Red control lamps . . . . . . . . . . .83
5.10.2 Error codes. . . . . . . . . . . . . . . . .83
5.10.3 Fuses . . . . . . . . . . . . . . . . . . . . . 83
5.10.4 Drive control relay . . . . . . . . . . .83
5.11 Cleaning the vehicle. . . . . . . . . .84
5.12 Transporting and towing
Loading . . . . . . . . . . . . . . . . . . .84
6 WARRANTY . . . . . . . . . . . . .86
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 6
Safety Information
1 Safety Information
1.1 Safety and warning labels
All texts related to personal safety, safety of
the vehicle and environmental protection are
assigned the following symbols throughout
the operating manual:
Symbol Hazardous for ... Denition
Danger persons or property Safety information to prevent the development of hazardous
situations resulting from ignoring or failing to follow instructions or prescribed work procedures.
Note the equipment Important information on handling the equipment in order to
maintain its operability.
Ecological hazard the environment Risk to the environment through using substances which
represent a health or pollution hazard.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 7
Safety Information
1.2 General information
• The Admiral 38C fullls all the applicable safety and health requirements
stipulated in the EU directives with
regard to its planning, constructional
design and nal construction as introduced by us onto the market. In the
case of modications to the vehicle not
approved by us, the EC Declaration of
Conformity enclosed in this operating
manual loses its validity.
• In addition to the information provided
in this operating manual, all legally
applicable health and safety provisions
must be observed.
• Before starting up the vehicle for the
rst time, read the operating manual
supplied with it thoroughly as well as
any separate manuals provided with
additional or attachment devices and
observe all the information during work.
• The vehicle may only be operated,
maintained and repaired by persons
trained by PowerBoss or authorized to
do so by PowerBoss.
• Particular attention should be paid to
the information regarding safety. Technical expertise is the key to preventing
errors when operating the equipment
and ensuring trouble-free operation.
• The operating manual must always be
kept at the operating location of the
vehicle and, as a result, should kept in
a safe place on the vehicle.
• If the equipment is sold or rented out,
these documents should be transferred
to the new owner/operator. The transfer
should be conrmed!
• The warning labels attached to the
equipment provide important information concerning safe operation. Labels
which are illegible or missing must be
replaced.
• Original spare parts must be used to
ensure safety.
• If you want to shut the vehicle down,
render it inoperable. It must not represent a source of danger for children.
1.3 Operating information
• Before starting the vehicle up for
the rst time, the battery to be used
must be fully charged, properly, by
implementing the initial battery charge
routine. Please pay attention to the operating manual provided with the charging unit as well as the manual from
the battery manufacturer. PowerBoss
assumes no liability for damage to the
battery caused by a fault when the battery is charged for the rst time.
• Before starting the vehicle up, always
check it is in a proper condition and
that it is safe to drive and operate.
Clear up any faults and defects immediately! Never operate the vehicle
without functional safety equipment.
• Warning: Do not use the vehicle without
a protective roof structure (refer to “Accessories”, “Cab safety roof”) in areas
where the driver is at risk of being hit
by falling objects (e.g. warehouses).
Contact the trade association respon-
sible for you as to whether obligations exist in this respect.
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 8
Safety Information
• The Admiral 38C must be subjected to
an inspection in respect of its operationally safe condition at least once a
year by an authorized technical expert.
The results of the inspection must be
documented in writing and kept safe at
least until the next inspection.
• Floor cleaning vehicles may only be operated by suitable personnel who have
been trained to operate the equipment,
have proven their capability to operate
the vehicle to the contractor or person appointed by him and have been
explicitly charged by him to operate the
vehicle.
• Before starting work, operating personnel must be fully familiar with all adjustment, operating and control elements
as well as their respective function! It is
too late to do this when the vehicle is
actually in operation!
• The warning labels attached to the
Admiral provide important information
concerning safe operation.
• Wet oors are a potential risk for slipping! Ensure to provide the corresponding information and warning signs.
• If the oor is excessively wet, check the
vehicle for leaks and that the sealing
strips are in a good condition. If the
sealing strips are damaged, change
them immediately.
• Only use cleaning agents suitable for
the vendor (non-foaming) and observe
all the use, disposal and warning information provided by the cleaning agent
manufacturer.
• It is forbidden to use the vehicle in
potentially explosive atmospheres.
• The machine is not suitable for clearing
up health-hazardous, inammable or
explosive uids, dust or substances.
• Ride-on equipment may only be set
into motion from the seat (seat contact
switch).
• The seat contact switch must never be
bypassed or the function immobilized in
any way (e.g. by placing a heavy load
on the seat).
• It is forbidden to transport people on
the vehicle!
• Always wear heavy duty, non-slip footwear when working with the vehicle.
• Start driving immediately after switching on the brush head drive, otherwise
imprints of the brush could be produced
on the oor.
• The machine may only be driven on
and the equipment used on those
surfaces which have been approved
by the contractor or person appointed
by him.
• The manner of driving must be adapted
to the local conditions (oor characteristics, presence of persons in the
vicinity, obstacles, etc.).
• When using the vehicle, it is essential
to pay attention to third parties, especially children.
• Never leave the vehicle unattended
while motors are still running and it has
not been locked against unintended
movement.
• To prevent authorized used of the
vehicle, lock the drive by removing
the key from the key switch.
• When transporting the vehicle, the
motors must be shutdown.
• Only open empty recovery tanks.
• The vehicle may only be driven on
gradients to a maximum of 6% for
a maximum of ve minutes. Do not
drive the vehicle on slopes with a
gradient steeper than the limit gradient indicated on the machine.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 9
Safety Information
1.4 Maintenance information
Properly completed vehicle maintenance
is an important protective measure for
preventing accidents.
• The maintenance work and maintenance intervals prescribed in the operating manual must be adhered to.
• Operating personnel must complete
the necessary daily and weekly
maintenance work. All other maintenance work must be completed at your
nearest authorized PowerBoss service
center.
• Before starting any cleaning and maintenance work or replacing parts, switch
off the engine and motors, remove the
key from the key switch and pull out the
battery plug. This is particularly important in respect of work on the electrical
system!
• Before working on the brushes, switch
off the scrubbing unit, set the key
switch to position 0 and remove the
key.
• The scrubbing unit may only be disassembled and installed by service
personnel.
• Suitable tools must be used for cleaning and maintenance work.
• Spare parts must comply with the minimum technical requirements stipulated
by the manufacturer! This is ensured by
the use of original spare parts.
• When working in the area of the raised
seat console, it must be pivoted up fully
to prevent it accidentally closing or suddenly slamming shut.
• It is not permitted to clean the vehicle
with a pressure washer or steam
blaster.
• Clean the recovery tank regularly to
protect it from the accumulation of dirt,
viruses, bacteria, etc.
• It is not permitted to use aggressive
and corrosive cleaning agents.
• Allow the vehicle to dry after being
cleaned, e.g. over the weekend.
• The vehicle must be checked by a
recognized technical expert in respect
of operational safety at reasonable
intervals (we recommend at least one a
year), particularly with regard to protective equipment and locks and following
modications or repair.
• Only start the vehicle up when all the
safety equipment has been installed, is
functional and brought to its protecting
position.
• The vehicle has been set up for operation using low-maintenance trough
batteries. If other battery types are to
be used, the vehicle must be adjusted
for them at an authorized PowerBoss
service center.
• Observe the information in the operating manual provided by the battery
manufacturer. It must be available to
operating and maintenance personnel
at all times.
• Batteries may only be handled and
changed by properly skilled maintenance personnel.
• When installing the trough battery, use
appropriate lifting gear.
• Only use the batteries prescribed by us
and original chargers to charge them.
The full terms of warranty can only be
accepted when these units are used.
• Pay attention that the insulation on the
charger is not initially damaged and not
damaged during the charging process. The cable must not rub against
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 10
Safety Information
anything. Do not use the charger if the
insulation is damaged.
• Always wear appropriate protective
clothing when handling the battery (e.g.
protective gloves, nger stalls, protective goggles).
• The seat console must be pivoted open
during the battery charging process to
prevent the development of explosive
oxyhydrogen!
• Never leave the batteries in a discharged state but recharge them as
soon as possible.
• Only rell distilled water.
• When the cells are in good condition,
never rell the battery acid.
• Spilled battery acid must never enter
the sewage system in its initial form, it
must be neutralized beforehand.
• Pay attention to legal requirements and
local directives.
• For further safety information, see
supplementary sheet 88-60-2554
“Notes on driving batteries”.
1.5 Particular risks
• The following applies when locating
the cause of faults and clearing them:
Switch the vehicle off, remove the key
and disconnect the battery plug!
• In the case of faults involving the
traction drive, stop the vehicle immediately and remove the key from the key
switch!
1.5.1 Electronics
• Always disconnect the battery plug before starting any work on the electrical
installations.
• Only use original fuses with the prescribed amperage.
• In the case of defects in the electrical
installation, switch the vehicle off immediately and clear the fault.
• Work on the electrical equipment may
only be carried out by electricians who
have received the necessary training
and in accordance with the electrical
engineering regulations.
• The vehicle’s electrical equipment
must be inspected/checked at regular
intervals. Defects, such as loose connections and cable damage, must be
rectied immediately.
1.5.2 Batteries
• Due to a change in the center of gravity, only approved batteries may be
installed at the intended position.
• To prevent creeping currents, always
keep the batteries clean and dry and
protect them from contamination, e.g.
from metal dust.
• Never lay any metallic objects or tools
on batteries. Risk of short circuit and
deagration!
• Ensure sufcient ventilation in the
charging area when charging the
batteries. Otherwise there is a risk of
explosion!
• The seat console must be pivoted open
during the battery charging process to
prevent the development of explosive
oxyhydrogen!
• Only use the original charger! Pay attention that the insulation is not initially
damaged and not damaged during the
charging process. The cable must not
rub against anything. Do not use the
charger if the insulation is damaged.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 11
Safety Information
• Ensure there are no naked ames
nearby when handling batteries, particularly when checking the acidity. Risk
of explosion!
• Do not inhale battery gases.
• Battery acid is very corrosive; keep
away from children.
• Wear protective goggles when controlling the acid level.
• In the event of acid splashing in the
eyes, rinse them with water for approx.
15 minutes and seek medical attention
immediately.
• Also pay attention to the information in
Section 1.4.
1.6 Environmental protection
• A certain factual expertise is required
in order to use substances which could
represent a risk to health and the environment.
• Always observe legal regulations and
local directives when disposing of
cleaning agents.
• Used batteries with the recycling
symbol contain reusable commodities.
The heavy metals contained represent
a major risk both to people’s health
and to the environment. Never open or
damage batteries. Never touch, inhale
or swallow the content of batteries.
Health hazard! Do not allow batteries
to get into the environment. Risk of
contaminating the ground and water!
In accordance with the symbol with
the crossed out garbage bin, these
batteries must not be disposed of in
domestic waste. Return and recycling
of old batteries must be agreed on with
PowerBoss‘ authorized dealers.
• Dispose of the equipment in accordance with local regulations. For further
information on handling and recycling,
please contact the authorized PowerBoss dealer where you purchased the
equipment.
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 12
Safety Information
1.7 Labels on the vehicle
The following safety and warning labels are
attached to the vehicle where easily legible.
Refer to Fig 1 to Fig 3 for item locations.
Missing or illegible labels must be
replaced immediately.
(1) Company logo
Fig 1 Label locations 1
(3) Rating plate, The rating plate is in the
driver’s cab, at the bottom, on the ap of
the left-hand electrical compartment.
(2) Read the operating
manual, maximum gradient
and ban on cleaning using
a high-pressure washer.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 13
Safety Information
(4) Maximum water temperature for solu-
tion to be lled
(5) Drive direction selector:
Forward or reverse
(6) Release parking brake
(7) Apply parking brake
Fig 2 Label locations 2
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 14
Safety Information
(8) Waste water drainage
The waste water is drained via the hose
which hangs to the right of this label.
(9) No waste water drainage
The ap serves exclusively for cleaning and
maintenance of the waste water tank.
(10) Solution drainage
The solution is drained via the hose which
hangs to the left of this label.
Fig 3 Label locations 3
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 15
Starting Up
2 Starting Up
Pay attention to persons in the
vicinity of the vehicle when completing any work.
2.1 Instruction
Instructions to operators are required before
putting the vehicle into service. Only technicians from your local authorized PowerBoss
dealer are allowed to provide initial instruction on the vehicle. The manufacturing plant
will notify the dealer immediately after delivering the vehicle and the dealer will contact
you to arrange a date.
2.2 Initial battery charge
An initial battery charge must be performed
in order for it to provide an optimum performance and service life. A battery charger is
available which is specially adapted to the
batteries.
Only use the batteries and charger
prescribed by us to charge the battery. The full terms of warranty can
only be accepted when these units
are used.
Before starting the vehicle up
for the rst time, the batteries to
be used must be fully charged,
properly, by implementing the
initial battery charge routine.
PowerBoss assumes no liability
for damage to the battery caused
by a fault when the battery is
charged for the rst time.
The seat console must be pivoted
open during the battery charging
process to prevent the development of explosive oxyhydrogen!
Only use the original charger!
Pay attention that the insulation
is not initially damaged and not
damaged during the charging
process. The cable must not rub
against anything. Do not use the
charger if the insulation is damaged.
Do not inhale battery gases.
Please pay attention to the operating
manual provided with the charging unit
as well as the manual from the battery
manufacturer. Powering up the batteries is described in such detail in the
manufacturer’s documents that further
information on the subject is considered
unnecessary for this manual.
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 16
Starting Up
2.3 Prior to starting up for the
rst time
The following work must be completed
before starting the vehicle up for the rst
time:
2.3.1 Installing the rotary brushes
Two rotary brushes must be tted in the
rotary brush head. These rotary brushes
are not part of the scope of delivery supplied with the vehicle. Choose the rotary
brushes separately according to the task
to be completed (refer to Section 4). If you
ordered the rotary brushes together with
the vehicle, the rotary brushes are normally already installed by the authorized
PowerBoss dealer prior to delivery.
Check whether rotary brushes
are tted.
If no rotary brushes are installed, proceed
as follows to install them.
The following applies to all work
on the rotary brushes: Turn the
key switch to position 0, remove
the key and apply the parking
brake (Fig. 14/8).
The front rotary brush is changed
from the right-hand side of the
vehicle, the rear rotary brush from
the left-hand side of the vehicle.
Fig 4
(1) Deector
(2) Deector lock
(3) Grip
1. Open the deector (Fig. 4/1):
take hold of the grip (Fig. 4/3), raise
the deector (Fig. 4/1), pivot open towards the front and set it down (service
position).
Fig 5
(1) Locking lever
(2) Brush holder
(3) Rotary brush
2. Slide the locking lever (Fig. 5/1) for the
brush holder (Fig. 5/2) to the middle of
the device and hold it there.
3. Allow the brush holder (Fig. 5/2) to
lower down and remove it.
4. Release the locking lever (Fig. 5/1).
5. If necessary, remove the existing rotary
brush (Fig. 5/13) from the housing
(Fig. 6/1).
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 17
Starting Up
Fig 6
(1) Housing
(2) Contact surfaces
(3) Rotary brush
(4) Brush holder (removed)
Fig 7
(1) Catch
(2) Housing
(3) Rotary brush
6. Lay one hand under the rotary brush
(Fig. 7/3) and slide it together with the
catches (Fig. 7/1) into the housing (Fig.
7/2).
Fig 8
(1) Pin
(2) Brush support
(3) Catch
(4) Rotary brush
7. To slide the rotary brush (Fig. 8/4) on
the facing brush support (Fig. 8/2),
raise the rotary brush (Fig. 8/4) a little
and turn slightly, if necessary, until the
catches (Fig. 8/3) perceptibly slide
from the rotary brush (Fig. 8/4) onto
the pins (Fig. 8/1) of the brush support
(Fig. 8/2).
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 18
Starting Up
Ensure that the contact surfaces
(Fig. 6/2) are clean. Clean them
thoroughly, if ne essary, before
tting them on the brush holder
(Fig. 6/4).
8. Slide the locking lever (Fig. 5/1) to
the middle of the device and hold
it there.
9. Mount the brush holder (Fig. 6/4)
on the rotary brush (Fig. 6/3), press
against the housing (Fig. 6/1) and
then slide upwards.
10. Pivot the locking lever (Fig. 5/1)
back under the brush holder (Fig.
6/4) to the stop.
11. Close the deector (Fig. 4/1):
Take hold of the grip (Fig. 4/3),
raise the deector (Fig. 4/1), pivot
to the device and lower into the deector lock (Fig. 4/2). The deector (Fig. 4/1) is now in its working
position.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 19
Starting Up
2.3.2 Installing and adjusting the
squeegee
Installing the squeegee
1. Switch on the key switch.
2. Lower the squeegee holding attach-
ment: Press the button for the squeegee and suction turbine so that the
green control lamp lights up.
3. Switch off the key switch and remove
the key.
4. Open the rear doors.
5. Slide the squeegee from the rear under
the lowered holding attachment and x
the squeegee to it with the four wing
nuts (Fig. 9/1).
6. Attach the suction hose to the connec-
tion nozzle (Fig. 9/2) of the squeegee.
7. Insert the key in the key switch and
turn the key switch on.
8. The squeegee is then lifted automati-
cally.
9. Close the rear doors.
Fig 9
Adjusting the squeegee
The squeegee must be set up on a level
oor according to the conditions in which
it is to be used. The squeegee must stand
vertically on the oor (adjusted at the factory). The sealing strip (Fig. 9/3) should
bend slightly to the rear when the vehicle
is in operation. Supporting rollers (Fig.
9/5) limit its movement toward the oor. To
increase the squeegee contact pressure,
the supporting rollers must be adjusted:
• Loosen the counternuts (Fig. 9/4) and
raise the supporting rollers on the left
and right evenly (turn screw counterclockwise and lock again).
The sealing strip now bends a little more
towards the rear. An adjustment of the
supporting rollers is also necessary when
the edge of the sealing strip is worn.
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 20
Starting Up
2.3.3 Adjusting the driver’s seat
The driver’s seat (Fig. 10) must be adjusted so that the driver is seated comfortably
and can reach all the operating elements
with ease.
The vehicle is equipped with a
seat contact switch. The vehicle
can only be operated when the
operating person is seated on the
seat.
The Admiral 38C is equipped with a
driver’s seat which can be adjusted in a
longitudinal direction (forward and back):
1. Force the lever on the right of the seat
outwards slightly.
2. Slide the seat forward or back in steps
of 0.6 in.
Fig 10
2.4 Before starting up daily
Carry out the following checks before starting the vehicle up for its daily operation
(also refer to Section 5.3.2):
1. Check the recovery tank, empty as
necessary. Clean it as necessary. Refer to Sections 5.6.1 and 5.6.2.
2. Check the waste container; empty and
clean it, if necessary; refer to Section
5.7.1.
3. Fill the solution tank and cleaning
agent in accordance with the manufacturer’s mixing directives. Refer to
Section 3.1.4 and Section 5.5.1.
Only use cleaning agents (nonfoaming) suitable for the vehicle’s
vendor. We recommend using our
clean and care products which
are specially balanced for the
vehicles. These products meet
the requirements stipulated in
the washing and cleaning agent
directive (WRMG - Wasch- und
Reinigungsmittelgesetzes).
4. Check the battery charge and recharge
as necessary; refer to Section 5.4.1.
Before starting the vehicle for its
rst working operation, carry out
an initial battery charging routine;
refer to Section 2.2.
5. Check the area where the vehicle was
parked for signs of leaks. Hoses, lines
and tanks must show no signs of leaks
or damage. If necessary, clear up any
defects before putting the vehicle
into operation.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 21
Operation
3 Operation
Operating personnel must read
the operating manual through
carefully. Operating personnel
should complete their initial test
drive on open ground or a test
track until they are familiar with
the individual operating elements
and the respective functions.
3.1 Method of operation
The Admiral 38C is a scrubber-drier
designed for wet cleaning rough and structured hard oors inside buildings, such as
multi-storey car parks or in logistics and
industrial areas (refer to Fig. 11). It cleans
oors by means of intensive scrubbing
with the aid of a water and cleaning agent
solution. The squeegee at the rear of the
vehicle vacuums up the waste water into
the recovery tank in the same working
process. The Admiral 38C is a ride-on
machine designed for the economic cleaning of large oor areas in buildings. A seat
contact ensures that the vehicle can only
be operated when an operator is seated
on the driver’s seat.
Fig 11
The most important vehicle elements are
described below:
3.1.1 Rotary brush head
(Fig. 12/2)
The two rotary brushes, which can be
changed without the need for any tools,
in the rotary brush head provide a high
cleaning performance. The solution supply starts automatically when the rotary
brush head is lowered. The solution is
sprayed onto the oor to be cleaned by
means of three nozzles. At the same time,
the contra-rotating rotary brushes start to
rotate. They then scrub the oor in such a
way that even dirt which has penetrated
more deeply is removed. The two rotary
brushes are each driven by a splashproof
electric motor. The contra-rotating motion
of the rotary brushes also picks up coarse
dirt and throws it into the downstream
waste container (sweeping function). In
addition to the cleaning effect, this also
ensures that coarse dirt, such as cable
ties, cigarette ends etc., does not slide
under the sealing strip of the squeegee
and, thus, impair the vacuuming results.
The waste water left over is then removed
by the squeegee which follows on.
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 22
Operation
Fig 12
Deectors (Fig. 12/2)
To the right and left of the rotary brush
head, near the oor, are two deectors
which, when in their working position,
prevent water splashing to the sides and
guide the waste water to the center of the
vehicle so that it can be vacuumed up
better.
The deectors can be raised, if necessary. This is the case for basic cleaning,
for example, where the oor only needs to
be scrubbed when wet and the solution is
not vacuumed up but allowed to soak in
instead. To raise the deector, take hold of
the grip (Fig. 12/6), raise it and hook the
locking hooks (Fig. 12/4) in the recesses in
the grip above it (Fig. 12/5). Proceed in the
same way on the other side of the side of
the vehicle.
Side brush unit (Fig. 12/1)
In order to be able to sweep up coarse dirt
close to walls and beyond the width of the
squeegee, a side brush unit, consisting of
two side brushes (right and left) can be
installed as an option at the front, refer to
Section 3.1.9.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 23
Operation
3.1.2 Squeegee
(Fig. 12/3)
The squeegee, which projects at the sides,
is xed to the Admiral 38C so that it can
pivot and swing. This enables it to evade
obstacles in the current cleaning track
and pivot back. Its strong suction capacity
ensures the waste water is vacuumed up
fully even on uneven oors and in bends,
leaving the oor dry enough to be walked
on. The squeegee must be checked prior
to starting work, when disposing of waste
water and/or lling the solution tank and
cleared of any foreign bodies which have
been vacuumed up. Check that the sealing
strips are in perfect condition. The rollers
serve to support the squeegee to prevent
excessive bending of the sealing strips.
The squeegee is automatically raised
when reversing.
Fig 13
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 24
Operation
3.1.3 Suction turbines (suction)
(Fig. 13/3)
The two suction turbines are located on
the rear panel of the solution tank and can
be accessed after opening the rear doors.
The suction turbines are switched on
and off automatically when lowering and
raising the squeegee, respectively. A oat
switch in the recovery tank switches the
suction turbine off automatically on reaching the maximum ll height.
3.1.4 Solution tank
(Fig. 13/2)
The solution tank is located behind the
driver’s seat, on the right-hand side (when
facing the front). It has a capacity of approx. 174 liters. Pivot the gray tank cap
open and lock to ll. Fill water, max. 50 °C,
and add the cleaning agent in accordance
with the manufacturer’s instructions. Pivot
the tank cap back down.
Only use cleaning agents (nonfoaming) suitable for the vehicle’s
vendor.
We recommend using our clean and care
products which are specially balanced for
the Admiral 38C. These products meet the
requirements stipulated in the washing and
cleaning agent directive (WRMG - Waschund Reinigungsmittelgesetzes). Observe
the correct dosage of the cleaning agent.
The correct dosage helps to reduce costs
and protect the environment. The development of excessive foam impairs the
machine’s function. It indicates overdosage of the cleaning agent; components of
the cleaning agent which are fed back to
the waste water cause foaming. Information on dosage is provided on the cleaning
agent container. Use the manufacturer’s
information as an initial guideline. Practical experience will ensure that you quickly
nd out which is the right cleaning agent
and the optimum dosage to suit your
needs. The solution feed to the brushes
is automatically opened when the scrubbing program is activated. If necessary, the
feed can be stopped manually by means
of the ball cock.
Operating times with one tankful:
•at 2 l/min. approx. 87 minutes
•at 4 l/min. approx. 43 minutes
•at 7 l/min. approx. 24 minutes
3.1.5 Recovery tank
(Fig. 13/1)
The recovery tank is located behind the
driver’s seat, on the left-hand side (when
facing the front). It has a capacity of approx. 174 liters. The waste water is fed
to the recovery tank via the squeegee
by means of a vacuum. A oat switch at
the top of the recovery tank switches the
suction turbine off automatically as soon
as the maximum tank ll level is reached.
In this case, the control lamp (Fig. 15/2)
on the left operating panel lights up. An
acoustic signal is also issued. A vacuuming tool (refer to Section 4), which can
be connected to the vehicle, is optionally
available with which to clean and vacuum
up water from areas difcult to access.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 25
Operation
3.1.6 Traction drive
The traction drive is provided by a drive
motor on the steerable front wheel. The
driving speed can be continuously regulated via the accelerator by means of the
electronic drive control (pulse contact control). The axle gear is a low maintenance
gear train which runs in an oil bath: The
gear oil need not be changed.
In the case of faults involving the
traction drive, stop the vehicle
immediately and remove the key
from the key switch!
3.1.7 Brakes
The Admiral 38C is equipped with a service brake and a parking brake. The service brake relates to a drum brake which
acts hydraulically on the rear wheels. It
is actuated by a foot pedal. The parking
brake is actuated mechanically via brake
cables. It is applied by means of the foot
pedal to the left of the steering column
and released using the safety catch in the
steering column.
3.1.8 Batteries and charger
The vehicle is equipped with low-maintenance batteries. The batteries concern
6 individual cells with an output of 36
Volt/320 Ah5. They are located under the
seat console.
To ensure protection against total discharge, the Admiral 38C is equipped with
a total discharge signal transducer (TSG).
It is integrated in the electronic system and
set up at the factory.
If other batteries are used, the
total discharge signal transducer must be adjusted. This
adjustment work should only be
performed at an authorized PowerBoss service center.
The battery is provided with a connection
cable with battery plug (Fig. 14/1). When
the battery plug is plugged into the vehicle
socket (Fig. 14/2), the vehicle is ready to
operate. To charge the battery, insert the
battery plug in the charger. The vehicle
includes a battery charger. Pay attention
to the safety information of the producer of
battery and battery charger.
PowerBoss, Inc. Copyright 2010
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
Page 26
Operation
Fig 14
3.1.9 Options
The basic vehicle can be supplemented by
further components. The order and spare
parts numbers of these components are in
brackets.
• Cab safety roof
(7582) (Fig. 15/2)
Purpose: To protect the driver,
e.g. from objects falling from
warehouse shelving. Ensure that
assembly of a cab safety roof
is made compulsory when the
vehicle is operated in such risk
areas.
• Flashing beacon
(7585.02 Assembly on the cab safety roof)
(7585.10 Assembly on a pole / without cab
safety roof) (Fig. 15/3)
Purpose: To recognize the vehicle more
clearly when in use, even in the dark.
• Working lights
(7584.02) (Fig. 15/1)
Purpose: To be able to use the vehicle in
dark lighting conditions.
Admiral 38C Scrubber PB# 4100055UM Rev.* 08/10
PowerBoss, Inc. Copyright 2010
Page 27
Operation
• Side brush unit
(7586.10) (Fig. 15/5)
Comprised of two side brushes, one for
the right and one for the left side of the
vehicle, which can be pivoted out.
Purpose: To enable effective cleaning
along borders and sweep coarse dirt to the
center of the vehicle.
• Set of non-slip wheels
Purpose: For safe, reliable operation of the
vehicle on particularly slippery oors.
• Spraying-vacuuming tool
(Fig. 15/4)
Purpose: For the manual cleaning of areas
difcult to access using scrubbing and
vacuuming tools. A holder can be installed
on the left- hand side of the vehicle to x
the vacuuming tool. Two holes are already
drilled in the left-hand side of the vehicle
for this. The corresponding switch is provided on the right-hand operating panel to
operate the vacuuming tool.
The following belong to the spraying-vacuuming tool:
- Floor scrubbing and vacuuming tool
(7009)
- Suction and spraying hose (7766)
- Tool holder and attachment parts
(7311.10)
• Hand-held vacuum cleaner
(Fig. 15/4)
Purpose: To vacuum up water manually in
areas difcult to access using the vacuuming tool. The hand-held vacuum cleaner
can be xed to the tool holder (refer to
spraying-vacuuming tool). The hand-held
vacuum cleaner contains:
- Adapter to connect the following
tools (7893)
- Flexible plastic extension hose,
length: 3 m (7880)
- Suction pipe (for connection to the
plastic extension hose), length: 1.3 m
(7881)
- Suction nozzle with rubber lips
(7883)
With regard to accessories such
as rotary brushes, suction lips
etc., (Fig. 15/4) please refer to
our spare parts catalog in the
Internet at
www.powerboss.com.
Loading...
