Place your new PowerBear
iPhone 6+ battery and
follow the steps in reverse
to complete the installation.
You now have a new high
quality battery!
Apply the adhesive on the
new battery.
Remove the iPhone battery
(DO NOT BEND OR
PUNCTURE THE BATTERY).
Do this for both sides of the
battery adhesive strips.
Start to slowly peel the
adhesive away from the
battery making sure to
continue around the sides
as well.
Peel o the adhesive tab
located on the bottom of
the battery.
Disconnect the digitizer
cable located underneath
the display data cable and
you can now take the screen
o to have an easier work
space.
Disconnect the display data
cable located underneath
the front facing camera/
sensor cable.
Disconnect the home button
cable.
STEP 11 STEP 12
STEP 14
STEP 15 STEP 16 STEP 17 STEP 18 STEP 19STEP 13
REPLACING THE iPHONE 6+ BATTERY
REPLACING THE
iPHONE 6+ BATTERY
The Perfect Solution:
PowerBear batteries are engineered to perfectly complement your
iPhone 6+ Battery. When high-performance, quality, and longevity are
your criteria, PowerBear is your answer! Our batteries are designed to
meet and exceed factory specifications so now you can get more out
of your device. Newer means better than New!
Powerful and Responsible:
PowerBear Batteries are made with high capacity grade A+ battery
cells and are environmentally responsible. They feature RoHS certification to be free of lead, mercury, cadmium, PBBs, and PBDE.
24 Month Warranty:
We aim to reach the highest limits of customer service excellence! If
there is ANY REASON why you are unhappy or unsatisfied with ANY of
our products, we guarantee you an exchange or refund within 2years!
If you want to register your warranty, please visit: mypowerbear.com/
warranty to register your product today!
Go Beyond Your Power:
Keep yourself powered with PowerBear Accessories! We oer top
quality products to reliably ensure that you and your phone are always
energized. Products include battery cases, spare batteries, extended
batteries, power cables, and all your power needs. We’re dedicated to
make your life easier by taking the responsibility of keeping your phone
charged away. Using PowerBear products will make life easy again!
Safety and Maintenance Guide:
Your device is a product of superior design and craftsmanship but
should be treated with care. The following suggestions and recommendations will help you prevent any damages or injury:
• This product contains a lithium polymer battery. Most battery issues
arise from improper handling of this product and/or continued use
of damaged batteries. DO NOT put a high degree of pressure on the
battery, or attempt to change the form of the battery; these are the
main cause of overheating. Avoid dropping, knocking or shaking the
device to prevent damage of battery.
• Keep both the device and battery away from liquids and sources of
extreme heat or excessively cold temperatures. The safe operable
temperature range of this product is between -20°C and 60°C (-4°F
and 80°F) for maximum eciency.
• In case of battery liquid leakage, keep away from eyes and skin.
• DO NOT use harsh chemicals, paints or cleaning solvents to paint or
clean the device.
• DO NOT touch the battery with a metal object, this can cause
short-circuiting and can damage the battery.
• If the product begins to overheat, turn o the device and leave it to
cool to a safe temperature and then proceed to remove the product
from the device as well as disconnecting any cables/power sources
from the device until deemed safe.
• DO NOT disassemble battery or any other component of this device.
• If your suspect your PowerBear© device is defective or malfunctioning, especially if the unit becomes excessively hot to the touch,
emitting odor, is deformed, cut or is operating abnormally, DISCONTINUE USE IMMEDIATELY AND CONTACT US.
• PowerBear© does not recommend use of this device by a minor.
However, if this device is intended to be used by a minor, the adult
purchaser agrees to provide detailed instructions and warnings to
minor-user prior to any use. Failure to provide warnings is the sole
responsibility of the adult purchaser, who agrees to indemnify PowerBear© from misuse or unintended use by the minor-user.
• KEEP THIS AND ANY OTHER ELECTRONIC DEVICE AWAY FROM
CHILDREN AND ESPECIALLY INFANTS. The battery in this unit
contains chemicals harmful if ingested or comes in contact with skin
directly. If ingestion or skin contact occurs, contact your local Poison
Control Center or the American Association of Poison Control
Centers at 1-800-222-1222.
Warranty Note:
PowerBear© is not responsible for any damage caused by the consumer. We only provide coverage for manufacturer defects or damage
caused by improper shipping and PowerBear© cannot be liable for
property damage or personal injury from the mishandling, misuse, or
negligence by a consumer or any of their agents.
Disclaimer:
Except as expressly provided herein, provider disclaims all warranties,
express or implied, including without limitation, any warranty or
merchantability or fitness for a particular purpose, with regard to the
US. No commercial or any other than individual use is intended for
PowerBear© products.
Terms & Conditions: FCC Class B Notice
This device complies with Part 15 of the FCC Rules. Operations is
subject to the following two conditions:
1. This device may not cause harmful interface.
2. This device must accept any interference received, including interference that may cause undesired operation.
FCC Note:
This equipment has been tested and found to comply with the limits
for Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician
for help.
• Consult a certified device provider for more help.
Disposal:
Regulations and laws pertaining to the recycling and disposal of lithium
ion batteries vary from country to country as well as by state and local
governments. You will need to check the laws and regulations where
you live to figure out. USA and Canada customers may find a nearby
Drop-O locator by calling Call2Recycle at 1-877-273-2925.
Contact Us:
Any questions, inquiries, concerns, suggestions or even a friendly hello
can be sent to us via the following gateways:
Amazon(US): www.goo.gl/vmiqxe
Email: info@gopowerbear.com
Website: www.gopowerbear.com
Hope to hear from you soon!
Thank you for your purchase!++
@gopowerbear
Disconnect the front facing
camera/sensor cable.
Unscrew and remove the
panel containing the display
connectors.
Unplug the battery connector.Unscrew and remove the
battery connector panel.
Open up the screen to a 90
degree angle and prop it up
against a sturdy object with
a rubber band or tape.
Remove the suction cup
from the screen.
Slowly pull back on the
screen until you create a
small gap between the
screen and the phone and
begin using the prying tool
to separate.
Unscrew the two pentalobe
screws located on the bottom
of the phone next to both
sides of the lighting port.
Take all the tools out of the
box and check to see that
you are not missing any.
Make sure your phone is
turned o.
Firmly apply the suction cup
on the lower portion of the
phone to create a strong
airtight seal.
STEP 5STEP 2STEP 1 STEP 3 STEP 4 STEP 6 STEP 7 STEP 8 STEP 9 STEP 10
REPLACING THE iPHONE 6+ BATTERY
WARNING!
BEFORE STARTING ANY
PROCESS INSTRUCTED IN
THIS MANUAL, PLEASE MAKE
SURE YOUR DEVICE HAS BEEN
POWERED OFF FOR AT LEAST
20 MINUTES PRIOR TO ANY
OPERATION. THIS LOWERS THE
RISK OF BATTERY DAMAGE
WHEN REMOVING IT FROM
YOUR DEVICE. BY PROCEEDING
WITH THE REPLACEMENT
OF YOUR BATTERY YOU ARE
ASSUMING FULL RISK AND
DO NOT HOLD POWERBEAR
LIABLE FOR ANY DAMAGE
TO YOU OR YOUR DEVICE.
PLEASE REFER TO THE BACK
OF THE MANUAL FOR FURTHER
DETAILS.
PLEASE NOTE THAT WHEN
REMOVING THE ORIGINAL
BATTERY THERE MAY BE
LEFTOVER BATTERY ADHESIVE.
DO NOT FORCEFULLY REMOVE
THE BATTERY OR CAUSE ANY
DEFORMATIONS. PLEASE BACK
YOUR PHONE UP AS AN EXTRA
MEASURE OF PRECAUTION.
Product Features & Contents:
The PowerBear iPhone 6+
Replacement Battery Kit arrives
with the following:
• 1 PowerBear iPhone 6+ Battery
• 1 Pentalobe Screwdriver
• 1 Metal Tweezer
• 1 Suction Cup
• 1 Spudger
• 1 Plastic Opening Tool
• 1 Set of Adhesive Strips
• 1 Phillips Head Screwdriver
Battery Usage/Calibrating
Instructions:
Do not allow the battery to drain
completely before charging. Overdischarging the battery causes
damage to the negative electrode
before it is properly calibrated,
which in turn reduces the lifetime
of the battery.
1. Allow the battery to drain
completely.
2. Once the battery has died, let
it charge undisturbed until it
reaches 100%. DO NOT use
your device during this time.
3. Allow the battery to
completely drain again before
the next charge cycle.
4. Repeat steps 1-3 around 3
times. Your battery should now
be properly calibrated with
your phone.
