N1F-GT-250/350-B
OPERATING INSTRUCTIONS
Electric Grass Trimmer
1. Read the instruction carefully. Be familiar
with the controls and the proper use of the
appliance. Read and understand the operator’s
manual and observe the warnings and
instruction labels affixed to the appliance.
2. Users. Never allow children or people
unfamiliar with these instructions to use the
appliance. Local regulations may restrict the
age of operator. Never operate the tool under
the influence of alcohol, medication or drugs.
3. Use appropriate tool. This device is only
intended for cutting grass and soft vegetation
outdoors and only designated for use on
private property. Do not force small tools or
attachments to do the job of a heavy duty tool.
4. Keep work areas clean. Cluttered areas
can cause accidents.
5. Consider work area environment. Do not
expose your tool to high humidity or rain. Do
not use your tool in damp and wet conditions.
Keep the work area well lit. Do not use your
tool where there is a risk of causing fire or
explosion, e.g. in the presence of flammable
liquids and gases.
6. Keep all bystanders, children, and pets
away. The operator or user is responsible for
accidents or hazards occurring to other people
or the property.
7. Dress appropriately. Do not wear loose
clothing or jewelry, as these can be caught in
moving parts. Preferably wear non-slip footwear
when working outdoors. Wear protective hair
covering to keep long hair out of the way.
8. Head protection. Always use safety glasses
and gloves. Use a face or dust mask whenever
the operations may produce dust or flying
particles. Wear ear protection whenever the
sound level seems uncomfortable.
9. Do not overreach. Keep proper footing and
balance at all times.
10. Stay alert, watch what you are doing.
Use common sense when operating the
appliance. Do not operate the tool when you
are tired.
11. Grip the tool securely. Operator should
one hand on the main handle, the other on the
front handle. Keep finger off trigger until ready
to use.
12. Remove adjusting keys and wrenches.
Always check that adjusting keys and
wrenches are removed from the tool before
operating the tool.
13. Risk of cut. Do not touch or try to stop the
cutting lines when they are moving.
14. Disconnect the plug. Disconnect plug
from the tool when not in use or when servicing
or cleaning.
15. Check for damaged parts. Before further
use, carefully check the tool for damage.
Check for alignment of moving parts, binding
of moving parts, breakage of parts, mounting
and any other condition that may affect its
operation.
Do not use the tool if any parts are damaged
or defective. Have any damaged or defective
parts repaired or replaced by an authorized
service agent. Never attempt any repairs
yourself.
16. Avoid unintentional starting. Do not carry
the tool without disconnect the plug and be
sure the tool is switched off.
17. Use an extension cord suitable for
outdoor use when operating a power tool
outdoors. Use a cord suitable for outdoor use
reduces the risk of electric shocks.
18. If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply. Use
of an RCD reduces the risk of electric shock.
19. Store idle tools. When not in use, tools
should be stored in a dry, locked-up place out
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
WARNING!
Read all instructions. Failure to follow all
instructions listed below may result in electric
shock, fire and/or serious injury. The term
“power tool” in all warnings listed below refers
to your mains operated power tool.
GENERAL POWER TOOL
SAFETY WARNINGS
Thank you for purchasing an POWERBASE
grass trimmer.
We would you like to be completely satisfied
with your new product and hope you will enjoy
using this tool for many years.
Your N1F-GT-250/350-B grass trimmer has
been designed for cutting grass and similar
soft vegetation and for trimming grass edges
in private and hobby garden areas which are
not accessible with a lawn mower.
The device is not allowed to be used in public
gardens, parks, sports centres or at roadsides
as well as agriculture and forestry.
INTRODUCTION
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
WARNING!
Do not use any attachments or accessories not
recommended by the manufacturer of this tool.
The use of attachments or accessories not
recommended can result in serious personal
injury.
WARNING!
Read these safety instructions thoroughly before
connecting this product to the mains supply.
Before switching on, make sure that the voltage
of your electricity supply is the same as that
indicated on the rating plate. This product is
designed to operate on 230-240VAC 50Hz.
Connecting it to any other power source may
cause damage.
This product may be fitted with a non-rewireable
plug. If it is necessary to change the fuse in the
plug,
the fuse cover must be refitted. If the fuse
cover becomes lost or damaged, the plug must
not be used until a suitable replacement is
obtained.
If the plug has to be changed because it is not
suitable for your socket, or due to damage, it
should be cut off and a replacement fitted,
following the wiring instructions shown below.
The old plug must be disposed of safely, as
insertion into a 13 amp socket could cause an
electrical
hazard.
ADDITIONAL SAFETY
WARNINGS FOR YOUR
GRASS TRIMMER
ELECTRICAL SAFETY
of reach of children.
20. Maintain tools with care. Keep tools clean
and in good condition for better and safer
performance. Follow the instructions for
maintenance and changing accessories. Keep
handles and switches dry, clean and free from
oil and grease.
21. Have your tool repaired by an authorized
service agent. This tool is manufactured in
accordance with the relevant safety regulations.
To avoid danger, electrical appliances must
only be repaired by qualified technicians.
a) Wear protective glasses or goggles;
b) Never allow children or people unfamiliar
with the instructions to use the machine;
c) Stop using the machine while people,
especially children, or pets are nearby;
d) Only use the machine in daylight or good
artificial light;
e) Before using the machine and after any
impact, check for signs of wear or damage and
repair as necessary;
f) Never operate the machine with damaged
guards or without the guards in place;
g) Keep hands and feet away from the cutting
means at all times and especially;
h) Take care against injury form any device
fitted for trimming the filament line length. After
extending new cutter line always return the
machine to its normal operating position before
switching on;
i) Never fit metal cutting elements;
j) Never use replacement parts or accessories
not provided or recommended by the
manufacturer;
k
) Always ensure that ventilation openings are
kept clear of debris;
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
Symbols are used in this manual to attract
your attention to possible risks. The safety
symbols and the explications which
accompany them must be perfectly
understood. The warning themselves do not
prevent the risks and can not be a substitute
for proper methods of avoiding accidents.
DESCRIPTION OF
SYMBOLS
Before any use, refer to the
corresponding paragraph in the
present manual.
This symbol, before a safety
comment, indicates a precaution, a
warning or a danger. Ignoring this
warning can lead to an accident for
yourself or for others. To limit the risk
of injury, fire, or electrocution always
apply the recommendations indicated.
Warning!
Wear ear protection.
Wear eye protection.
Wear dust mark.
Do not expose and operate the tool
in rain.
Keep all other people,including
children, pet and bystanders outside
the 10 meters hazard zone, stop the
trimmer immediately if you are
approached.
Remove the plug from the mains
supply immediately if the cable is
damaged or cut.
Double insulation.
Recycle unwanted materials instead
of disposing of them as waste. All
tools, hoses and packaging should
be sorted, taken to the local recycling
centre and disposed of in an
environmentally safe way.
1
2
3
4
5
6
7
8
9
10
11
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
1. grass trimmer
2. safety guard
3. assembly screw for safety guard
4. flower guard
5. front handle
PACK CONTENTS
EXTENSION CABLES
ASSEMBLY:
Use only extension cords suitable for outdoor
use, preferably with a high visibility cable colour.
Always unwind all extension cables fully,
coiled cables can overheat and reduce the
efficiency of your product.
For extension cables up to 15metres , use a
wire cross section of 1.5mm
2
.For extension
cables over 15 meters but less than 40 meters
,
use a wire cross section of 2.5 mm
2
If the insulation on a power cable or extension
lead is found to be cut or damaged, do not
touch it! Disconnect the power supply
immediately and have the damaged cable
replaced.
Do not repair damaged cables.
Always follow the manufacture’s instructions.
INSTALLATION OF THE
GUARD AND FLOWER
GUARD (See Fig. B)
1 Insert the flower guard into the slot on the
motor housing.
2
Insert the safety guard into the slot on the
motor housing.
3
Screw tight the Guard.
1. Place unit on a flat surface.
2. Push the front handle onto the shaft,
and move to a comfortable position.(See Fig.A1)
3. Place the bolt into the fix hole, and tighten
bolt securely.(See Fig.A2,3)
Installation of the adjustable handle
WARNING!
Do not use two-core extension cords or reels
on power tools with an earth path.
WARNING!
Fig.B
The guard must be properly installed. The
guard provides partial protection from the risk
of thrown objects to the operator and others.
WARNING!
Do not use the product without fitting the
guard.
NOTE: If guard is not properly installed,
damage to unit (including motor failure) will
result.
flower guard
Motor housing
Guard
1. Safety guard
2. Motor house
3. Edging switch
4. Extension tube
5. Knob
6. Handle
7. Front handle
8. Locking switch
9. Cable
11. On/off switch
10. Flower guard
Fig.A1
Fig.A3
Fig.A2
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
WARNING!
Fig.D1 Fig.D2
Fig.C2
Always wear eye protection. Never lean over
the trimmer head. Rocks or debris can ricochet
or be thrown into eyes and face and cause
blindness or other serious injury.
When operating unit, check for the following:
Wear eye protection and heavy clothing.
Hold front handle with one hand and auxiliary
handles with the other hand.
Keep unit below waist levels. Work only from
your right to your left to ensure debris is thrown
away from you.
Without bending over, keep line near and
parallel to the ground(perpendicular when
edging). Do not switch the machine on with the
cutting head on or near material to be cut.
Ensure the cutting line is at full speed before
contacting material to be cut.
1．To prevent excessive strain on the cable
connections, the trimmer is fitted with a cable
restraint.
2．Before switching on, push a loop of cable
through the space in the handle and secure it
over the cable restraint.
First press the locking button in then press the
on/off switch, your switch is now on.
To switch off, simply release the on/off switch.
Locking
button
On/off
switch
MAINS SUPPLY CABLE
STRAIN RELIEF
(See Fig.C1)
OPERATING THE ON/OFF
SWITCH
(See Fig.C2)
Pull the Edging switch away from the motor
house as indicated by “1”, then rotate 180
degrees as indicated by”2” to the edge cutting
mode.
Correct use error use
OPERATING THE EDGING
SWITCH
(See Fig.E1 E2)
OPERATION
Tube length adjusting
(See Fig.D1 D2)
WARNING!
The cutting head continues to rotate after the
trimmer has been switched off, wait until it has
stopped then lay down the tool.
Loose the knob in the direction indicated by the
unlock sign – adjust the tube length to your
desire- secure the knob.
TO REMOVE THE
CUTTING HEAD COVER
(See Fig.I)
WHEN REFITTING THE
SPOOL CAP
(See Fig.J)
Make sure that line is fed out before operation.
Make sure motor is up to full speed before
trimming.
1. Let the trimmer run for a few seconds
without touching the working area, and allow
the trimmer to cut the line.
2. Use the trimmer at an angle of
approximately 15 degree to the working area.
3. Swing the trimmer head from side to side.
(See Fig.F)
Fig.F
Fig.G
Fig.C1
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
4 If the grass is very long cut in stages rather
than trying to cut in one ago. Do not overload
your trimmer. Take small cuts this will keep
machine operating at high speed and will
greatly improve cutting efficiency.
(See Fig.G)
If required, line can be fed out manually. To
operate, press and release manual line feed
button, while gently pulling out the lines until
the lines reach the line cutter.
When the required amount of line is fed out,
gently pull on the second line (there is no need
TO MANUALLY FEED
THE LINE
(See Fig.H)
If too much line is fed out, remove the spool
cap and turn spool counter-clockwise until the
line is at the desired length.
Press the release latch on the spool head
cover and remove cover, pulling it straight off
the cutting head assembly.
Pull the cutting head cover away from the
spool holder.
Keep all areas of the cutting head cover and
spool holder clean.
Replace the spool head cover, pressing firmly
down towards the spool holder to ensure the
cover is fully located.
Check that the cap is correctly fitted by trying
to remove it without depressing the two latches.
to press the manual line feed button again), If
the line extends past the line cutter, too much
line has been fed out.
WARNING!
Fig.E1 Fig.E2
Fig.H
Cutting line
blade
Cutting line
feed button
Fig.I1
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
1. Never use water or chemical cleaners to
clean your power tool. Wipe clean with a dry
cloth.
2. Always check the cutting head and guard
before each use.
3. Always store your power tool in a dry place.
4. Keep the motor ventilation slots clean.
5. Have the unit professionally repaired should
any damage parts.
Although your new grass trimmer is really
easy to operate. If you do experience
problems, check the following:
Your trimmer is designed to use only line with
a maximum diameter of 1.2 mm.
IMPROTANT: Leave approximately 100 mm of
line unwound and place into cleat.
Care should be taken to ensure that the line is
neatly coiled on the spool. Failure to do so will
impair the efficiency of the automatic line feed.
(See Fig. L1, L2, L3)
Then fit spool as described in “To fit spool
and line complete”.
MAINTENANCE AND
STORAGE
TROUBLE SHOOTING
TO REPLACE CUT LINE
TO FIT SPOOL AND LINE
COMPLETE
TO FIT NYLON LINE
ONLY
Take approximately 4m of line. Insert line into
the spool holes and wind line in the direction
of the arrows on the top of spool. (See Fig.K)
For your convenience it is recommended you
buy spool and line complete.
Remove old spool.
Place new spool into cutting head with cut out
areas of the spool in line with eyelets.
Release line from cleat and feed line through
eyelet.
Refit the spool head cover.
WARNING!
Before proceeding, unplug the tool.
Fig.L1 Fig.L2
Fig.L3
Fig.K
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
● Check that the spool housing can rotate
freely. Carefully clean it if necessary.
● Check that the cutting line does not protrude
more than 9 cm from the spool housing. If it
does, cut it off so that it just reaches the line
trimming blade.
Check the condition of the cutting head, if the
cutting line is too short or cutting head damaged.
Note: Do not use damaged cutting head.
If a fault is suspected return the trimmer to
an authorized dealer for repair.
Tool runs slowly
If the trimmer is not cutting properly
Model No.
Rated voltage
Input power
No load speed
Cutting Width
SPECIFICATIONS
NOISE AND VIBRATION DATA
N1F-GT-250/350-B
230-240V AC 50Hz
350W
12000rpm
250MM
Cutting line Diameter
Protection class
Machine Weight
Sound pressure level(LpA)
Power sound level(LwA)
Vibrations
1.2mm
II
2kg
83, 8 dB(A)KPA: 1,0 dB(A)
96 dB(A)
3,88 m/s
2
K=1,5 m/s
2
Fig.J
Electric Grass Trimmer
ORIGINAL INSTRUCTIONS
WARNING!
The vibration emission value during actual use of the power tool can differ form the declared value
depending on the ways in which the tool is used dependant on the following examples and other
variations on how the tool is used:
How the tool is used and the materials is cut or drilled.
The tool being in good condition and well maintained.
The use the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles and any anti vibration accessories are used.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand vibration syndrome if tie use is not adequately managed.
HOME RETAIL GROUP
EC DECLARATION OF CONFORMITY
We
Home Retail Group
Avebury, Milton Keynes,
MK9 2 NW
declare that the product
N1F-GT-250/350-B Electric grass trimmer
Complies with the requirements of the following directives:
Function: Cutting grass and similar soft vegetation and for trimming grass edges
2004/108 EC - EMC Directive.
2006/95 EC - Low Voltage Directive.
93/68 EC - CE Marking Directive
2006/42 EC - Machinery Directive
2000/14/EC - Noise emission in the environment by equipment for use outdoor
s
Directive.
- Conformity assessment procedure as per ANNEX VI.
- Measured Sound Power Level = 93dB(A)
- Declared Guaranteed Sound Power Level = 96dB(A)
Technical documentation holder: Home Retail Group, MK9 2NW
Standards and technical specifications referred to:
EN 60335-1:2002+A11: 2004+A1: 2004+A12:2006+A2:2006+ A13 :2008+A14:2010;
EN 60335-2-91:2003;
PrEN60335-2-91:2007/FprAA:2009
Notified body name: Intertek Testing & Certification ltd
Notified body address: davy Avenue, knowlhill, Milton keynes, Mk5 8Nl
Notified body number: 0359
Authorised Signatory
Date: 30.10.2010
Signature:
Name: Roger Panton-Kent
(EC conformity mark)
Head of Quality Assurance
EN 786: 1996+A2:2009; EN 62233:2008; EN61000-3-3:2008;
EN61000-3-2:2006; EN55014-1:2006; EN55014-2:1997+A1:2001+A2:2008;
EN ISO 3744:1994, ISO 11904:1991
PLUG REPLACEMENT
Your grass trimmer is fitted with a moulded plug. However if you need to replace a fitted plug then
follow the instructions below.
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Blue - Neutral Brown – Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows.
The wire which is coloured blue must be connected to the terminal which is marked with N
The wire which is coloured brown must be connected to the terminal which is marked with the letter L
If a 13AMP (BS1363/A) plug is used, a 13A fuse must be fitted, or if any other type of plug is used a
13AMP fuse must be fitted, either in the plug or adapter, or on the distribution board.
Note: If a moulded plug is fitted and has to be removed take great care in disposing of the plug and
severed cable, it must be destroyed to prevent engaging into a socket.If the supply cord is damaged
it must be replaced by a service agent or a similarly qualified person in order to avoid hazard.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your local authority or retailer for recycling advices.
Connect
Blue to N
(neutral )
Outer sl eeve
firmly c lamped
Cable gr ip
Brown L (live)
13 Amp fuse app roved
to BS13 62
GUARANTEE
This product is selected for DOMESTIC USE ONLY and not for business use. This product is
guaranteed against manufacturing defects for a period of 12 months. This does not cover the
product where the fault is due to misuse, abuse, use in contravention of the instructions, or
where the product has been the subject of unauthorised modifications or alterations, or has been
the subject of commercial use. In the event of a problem with the product within the guarantee
period please return it to your nearest Homebase store. If the item is shown to have an inherent
defect present at the time of sale, the store will provide you with a replacement. Your statutory rights
remain unaffected.
Guarantor: Homebase, MK9 2NW
Issue2 05/2011
Loading...
