PowerAcoustik Silver Edition, sports a clean new look with cool blue reactor light bars hidden
under stylish black mesh grills and chrome end caps. Our proprietary mosfet power supply
delivers deep tight bass with rapid decay 18db. subwoofer slopes. We also include dash mounted
subwoofer controls on our 1000 watt and up 2-channel class A/B amplifiers.
Check out our new monster class “D” 5500 watt behemoth, this should loosen the welds on your
car.

Common Features For Class D:

Hi Speed Digital Circuitry
Fully Regulated PWM Power Supply
Four Way Protection Circuit
1 Ohm Stable
Bridging Synchronization
Variable Low Pass 50Hz-150Hz
Variable Subsonic Filter 15Hz-40hz
Variable Subwoofer EQ @ 45Hz
Phase Switch 0-180
Remote Dash Mount Low Level Gain Control With
Cable

Frequency Response: 15Hz to 150hz
S/N Ratio: 100 db
THD: 0.5%
System Distress Indicator
Inputs Sensativity: 200mv-8v
Dual Mono Speaker Output Connectors
Platinum Plated Heavy Duty Power & Speaker Terminals

Silver edition pg3

Blue Reactor Light Bars

Chrome End Caps

New Hyper Bass

Common Features For Class A/B:

Full Mosfet Power Supply
PWM Circuitry
Full Selectable Crossover Hi/Full/Low
Three Way Protection Circuit
Tri-Mode Capable
Variable Low Pass 40Hz-120Hz
Variable Hi Pass 150Hz-1.5Khz
18dB Bass Boost @ 40Hz.
Frequency Response: 10Hz to 30Khz
S/N Ratio:97 db

Remote Dash Mount Bass

THD: 0.02%

Knob Control

2 ohm Stable Stereo
System Distress Indicator

High/Low Level inputs With Floating Ground
4 Gauge Power/Ground Connection
Platinum plated RCA Connectors
Line output
V-Angled Transparent Terminals

Class A/B Series

Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimension W”xH”xD” Bass Knob

Sl2-340 2 80x2 95x2 190 340 8.4x2.3x11.7 No

SL2-460 2 95x2 120x2 240 460 9.7x2.3x11.7 No

SL2-620 2 150x2 180x2 360 620 12.4x2.3x11.7 No

Sl2-1000 2 220x2 280x2 560 1000 15.2x2.3x11.7 Yes

Sl2-1500 2 300x2 380x2 760 1500 19.6x2.3x11.7 Yes

Sl2-2000 2 370x2 450x2 900 2000 20.7x2.3x11.7 Yes

Sl4-680 4 80x4 95x4 190x2 680 11.25x2.3x11.7 No

SL4-1000 4 100x4 125x4 250x2 1000 13.2x2.3x11.7 No

Class D Digital Series

Model Ch 4 Ohm Rms 2 Ohm Rms 1 Ohm Rms Max Dimensions (LxWxH) Bass Knob

SL-2000D 1 800 1300 1600 2000 12.7” x 11.7” x 2.3” Ye s

SL-2600D 1 1100 1600 2000 2600 15” x 11.7” x 2.3” Yes

SL-3400D 1 1400 2100 2600 3400 16.7” x 11.7” x 2.3” Yes

SL-5500D 1 2100 3600 4200 5500 21” x 11” x 2.3” Yes

http://www.poweracoustik.com

Silver edition pg4

Silver Edition

Our collection of Silver Edition woofers and component systems are
the new technological innovations of our engineers designed both
for high power handling accurate bass reproductions, as well as
sound quality to quench the thirst of the most crtitic audio-files.

Common Features:

Wide UV Coated Foam Surround
Black Chrome Coated PP Cone
Stiff Poly Cotton Spider
Dual 4 ohm 2” KSV Voice Coil
Reinforced Aluminum Voice Coil Former
Integrated Tinsel Leads
Stamped Steel Basket
Steel Gasket
Black Chrome Finish
Chrome Push Terminals
Vented Pole Piece

SL-10W

• 800 Watts power handling

• 400 Watts RMS

• 70 oz. magnet

• 2” BASV/Kapton Hybrid 18 AWG Voice Coil

• SPL 89 dB

• Fs: 42 Hz

• Vas: 1.06 cu.ft.

• Qms: 4.057 • Qes: 0.667 • Qts: 0.573

• Xmax: 0.32"

• Sealed box: .95 cu..Ft.

• Ported box: 1.25 cu..Ft.

• Tuning: 38 Hz

• Port size: 3”(dia)x8”(length)

• # of ports: 1
”

Silver edition pg5

SL-12W

• 1000 Watts power handling

• 500 Watts RMS

• 80 oz. magnet

• 2” BASV/Kapton Hybrid 18 AWG Voice Coil

• SPL 89 dB

• Fs: 39 Hz

• Vas: 1.20 cu.ft.

• Qms: 2.019 • Qes: 0.674 • Qts: 0.506

• Xmax: 0.32"

• Sealed box: 1.25 cu..Ft.

• Ported box: 2 cu..Ft.

• Tuning: 38 Hz

• Port size: 4”(dia)x8.25”(length)

• # of ports: 1
”

Common Features:

Wide Foam Surround
One Piece Cone/Dust Cap Assembly
Large Diameter Poly-Cotton Spider
Integrated Tinsel Leads
Dual 4 ohm BASV Voice Coils
Reinforced Aluminum Voice Coil Former
Die Cast Aluminum Basket
1-Piece Rubber Gasket
Black Chrome Finish
Chrome Push Terminals
Vented Pole Piece

STW-10W

Shallow Mount

STW-12W

• 800 Watts power handling

• 400 Watts RMS

• 100 oz. magnet

• 2” BASV/Kapton Hybrid 18 AWG Voice Coil

• SPL 88 dB

• Fs: 35 Hz

• Vas: 0.08 cu.ft.

• Qms: 8.133 • Qes: 0.4778 • Qts: 0.458

• Xmax: 0.3"

• Sealed box: .7 cu..Ft.

• Ported box: 1 cu..Ft.

• Tuning: 38 Hz

• Port size: 3”(dia)x10”(length)

• # of ports: 1”

SL-6C

• 6.5” Component system

• 3” high power handling kapton voice coil

• 250 Watts max

• High performance Neodymium magnet

• P P cone mid-bass

• Butyl rubber surround

• Chrome magnet cover

• Shallow mount 2.25”

• 2-way die-cast passive crossover

• 12db/Octave roll off

• Impedance balancing network

• Impedance: 4 ohm

• Frequency response: 45Hz-30KHz

• Sensitivity: 90dB

• 1” silk dome tweeter

• NDFEB magnet

• 80Hz/6KHz

• Flush, angle, and surface mount tweeter

• Ferro fluid cooled

• 1000 Watts power handling

• 500 Watts RMS

• 120 oz. magnet

• 2.5” BASV/Kapton Hybrid 18 AW G Voice Coil

• SPL 89 dB

• Fs: 32.8 Hz

• Vas: 1.7 cu.ft.

• Qms: 4.49 • Qes: 0.737 • Qts: 0.683

• Xmax: 0.3"

• Sealed box: 1 cu..Ft.

• Ported box: 1.5 cu..Ft.

• Tuning: 35 Hz

• Port size: 3”(dia)x7.75”(length)

• # of ports: 1”

http://www.poweracoustik.com

3” Voice Coil & Massive Neo Mganet
For Extrem Power Handling

Silver edition pg6

AMPLIFIERS

CLASS A/B Series

Common Features For Class A/B:

Full Mosfet Power Supply
PWM Circuitry
Full Selectable Crossover Hi/Full/Low
Three Way Protection Circuit
Tri-Mode Capable
Variable Low Pass 40Hz-120Hz
Variable Hi Pass 150Hz-1.5Khz
18dB Bass Boost @ 40Hz.
Frequency Response: 10Hz to 30Khz
S/N Ratio:97 db
THD: 0.02%
2 ohm Stable Stereo
System Distress Indicator

High/Low Level inputs With Floating Ground
4 Gauge Power/Ground Connection
Gold plated RCA Connectors
Line output

Dash Mount Bass Knob

Amplifiers pg7

CLASS D Series

High Speed Digital Circuitry

Common Features For Class D:

Hi Speed Digital Circuitry
Fully Regulated PWM Power Supply
Four Way Protection Circuit
1 Ohm Stable
Bridging Synchronization
Variable Low Pass 50Hz-150Hz
Variable Subsonic Filter 15Hz-40hz
Variable Subwoofer EQ @ 45Hz
Phase Switch 0-180
Remote Dash Mount Low Level Gain Control With Cable
Frequency Response: 15Hz to 150hz
S/N Ratio: 100 db
THD: 0.5%
System Distress Indicator
Inputs Sensativity: 200mv-8v
Dual Mono Speaker Output Connectors
Gold Plated Heavy Duty Power & Speaker Terminals

Class D Digital Series

Model Ch 4 Ohm Rms 2 Ohm Rms 1 Ohm Rms Max Dimensions (LxWxH) Bass Knob

A1000DB 1 450 800 N/A 1000 10.5” x 11” x 2.3” Yes

A1800DB 1 600 1100 1400 1800 12.6” x 11” x 2.3” Yes

A2400DB 1 900 1400 1800 2400 15” x 11” x 2.3” Yes

A3000DB 1 1100 1800 2300 3000 16.8” x 11” x 2.3” Yes

Class A/B Series

Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimension W”xH”xD”

A520-2HP 2 125x2 150x2 300 520 11.25x11x2.3

A600-4HP 4 70x4 85x4 170x2 600 11.25x11x2.3

http://www.poweracoustik.com

Amplifiers pg8

AMPLIFIERS

PLASMA SPHERE

Remote Dash Mount Bass
Knob Control

Common Features:

Synchronized Lightning Pulse Dish
Full Mosfet Power Supply
PWM Circuitry
Full Selectable Crossover Hi/Full/Low
Remote Dash Mount Bass Knob Control
Three Way Protection Circuit
2 Ohm Stable Stereo
Tri-Mode Capable
Variable Low Pass 40Hz-250Hz
Variable Hi Pass 40Hz-250Hz

Amplifiers pg9

Variable 18dB Bass Boost @ 40Hz.
Frequency Response: 10Hz to 30KHz
S/N Ratio: 98 dB
THD: 0.02%
System Distress Indicator
4 Guage Power/Ground Connection
Platinum Plated RCA Connectors
Line Output
High/Low Level Inputs with Floating Ground

Reach the lightning sensation with the new Power Acoustik
Plasma Sphere amps

New Proprietary Power Supply Design

New Hyper Bass

Synchronized
Lightning Pulses

Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimensions W”xH”xD” Bass knob

TS620-2 2 150x2 180x2 360 620 11.25x2.25x11 Yes

TS980-2 2 220x2 280x2 560 980 13x2.25x11 Yes

TS1440-2 2 300x2 360x2 720 1440 18.5x2.25x11 Yes

TS1920-2 2 370x2 440x2 880 1920 20.5x2.25x11 Yes

TS960-4 4 100x4 125x4 250x2 960 13x2.25x11 No

http://www.poweracoustik.com

Amplifiers pg10

AMPLIFIERS

GOTHIC Series

Common Features:

Super Cool Blue LED
Chrome Top Plate Panel
Full Mosfet Power Supply
PWM Circuitry
Full Selectable Crossover Hi/Full/Low
Three Way Protection Circuit
Tri-Mode Capable
Variable Low Pass 40Hz-120Hz
Variable Hi Pass 150Hz-1.5Khz
18dB Bass Boost @ 40Hz.
Frequency Response: 10Hz to 30Khz
S/N Ratio:97 db
THD: 0.02%

2ohm Stable Stereo

System Distress Indicator
High/Low Level inputs With Floating Ground
4 Gauge Power/Ground Connection
Platinum RCA Connectors
Line output

Amplifiers pg11

Chrome Top Plate Panel

Deliver Huge Power Capabilities

Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimension W”xH”xD”

OV2-300 2 70x2 85x2 170 300 7.25x11.25x2.25

OV2-400 2 85x2 105x2 210 400 8.5x11.25x2.25

OV2-520 2 125x2 150x2 300 520 11.25x11.25x2.25

OV2-820 2 180x2 230x2 460 820 14x11.25x2.25

OV2-1200 2 250x2 300x2 600 1200 20.5x11.25x2.25

OV2-1600 2 310x2 370x2 740 1600 22x11.25x2.25

OV4-600 4 70x4 85x4 170x2 600 11.25x11.25x2.25

OV4-800 4 85x4 105x4 210x2 800 14x11.25x2.25

http://www.poweracoustik.com

Amplifiers pg12

AMPLIFIERS

POWER Series

Common Features:

Full Mosfet Power Supply
PWM Circuitry
Full Selectable Crossover Hi/Full/Low
Three Way Protection Circuit

2ohm Stable Stereo

Tri-Mode Capable
Variable Low Pass 40Hz-120Hz
Variable Hi Pass 150Hz-1.5Khz
18dB Bass Boost @ 40Hz.
Frequency Response: 10Hz to 30Khz
S/N Ratio:97 db
THD: 0.02%
System Distress Indicator
High/Low Level inputs With Floating Ground
Spade Terminals
Top Chrome Plate
Platinum RCA Connectors
Line output

Amplifiers pg13

Deliver Huge Power Capabilities

Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimension W”xH”xD”

PS2-120 2 35x2 45x2 NO NO 5x9x2

PS2-300 2 70x2 85x2 170 300 7.25x11.25x2.25

PS2-400 2 85x2 105x2 210 400 8.25x11.25x2.25

PS2-520 2 125x2 150x2 300 520 11.25x11.25x2.25

PS2-820 2 180x2 230x2 460 820 14x11.25x2.25

PS2-1200 2 250x2 300x2 600 1200 20.5x11.25x2.25

PS2-1600 2 310x2 370x2 740 1600 22x11.25x2.25

PS4-240 4 35x4 45x4 NO NO 7x9x2

PS4-600 4 70x4 85x4 170x2 600 11.25x11.25x2.25

PS4-800 4 85x4 105x4 210x2 800 14x11.25x2.25

http://www.poweracoustik.com

Amplifiers pg14

AMPLIFIERS

LT Series

Common Features:

Full Mosfet Power Supply
PWM Circuitry
Full Selectable Crossover Hi/Full/Low
Three Way Protection Circuit

2 Ohm Stable Stereo

Tri-Mode Capable
Variable Low Pass 30Hz-500Hz
Variable Hi Pass 50Hz-500Hz
Variable 24 dB Bass Boost
Variable Subsonic Filter 60Hz-200Hz
Frequency Response: 10Hz to 30KHz
S/N Ratio: 98 dB
THD: 0.02%
System Distress Indicator
4 Guage Power/Ground Connection
Diamond Cut Heat Sink
Gold Plated RCA Connectors
Line Output
Top Control Panel

Amplifiers pg15

For Extreme Bass Reproduction

New Proprietary Power Supply Design

New Hyper Bass

Built-In Blue
Lights In Side
Panels

Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimensions W”xH”xD”

LT480/2 2 100x2 125x2 250 480 8.5x2.25x11

LT620/2 2 150x2 180x2 360 620 11.25x2.25x11

LT980/2 2 220x2 280x2 560 980 14x2.25x11

LT1440/2 2 300x2 360x2 720 1440 20.5x2.25x11

LT1920/2 2 370x2 440x2 880 1920 22x2.25x11

LT720/4 4 85x4 100x4 200x2 720 11.25x2.25x11

LT960/4 4 100x4 125x4 250x2 960 14x2.25x11

http://www.poweracoustik.com

Amplifiers pg16

New///////////

Meter & Plasma

METER-4

• Universal amplifier status and distress monitoring
system Voltage meter

• Temperature meter

• Twin VU meters

• Cool blue back-lit meters

• Three-way mounting (Under dash L-bracket,

Console

or A-pillar mount, ISO din mounting system)

• Separate easy mount control box and cabling

PLASMA-1

• Three color rectangular lightning dish (Red, White and Blue)

• Responds to music (Signal Inputs)

• Voice recognition by microphone

• Pre-programmed auto pulse

• Cut-in mounting shroud

• Butterfly stand mounting system

Meter pg17
