Poulan wa15542a Parts List
For Parts Call K&T 606-678-9623 or 606-561-4983
MODEL NO. WA15542A
15.5 HP 42 INCH
LAWN TRACTOR
• Assembly
• Operation
• Maintenance
• Ser vice and Adjustments
• Troubleshooting
• Repair Parts
For Parts and Service, contact our authorized distributor:
call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886
184539 Rev. 4 9.25.03 RH/MH
www.mymowerparts.com
00273
PRINTED IN U.S.A.
For Parts Call K&T 606-678-9623 or 606-561-4983
TABLE OF CONTENTS
Warranty................................................. 2
Safety Rules ...........................................3
Product Specifi cations............................ 6
Assembly/Pre-Operation ........................8
Operation.............................................. 11
Maintenance Schedule......................... 17
Maintenance......................................... 17
Service and Adjustments...................... 21
Storage................................................. 27
Troubleshooting .................................... 28
Repair Parts.......................................... 32
WARRANTY
LIMITED WARRANTY
The Manufacturer warrants to the original consumer purchaser that this product as
manufactured is free from defects in materials and work man ship. For a period of two
(2) years from date of purchase by the original consumer purchaser, we will repair or
replace, at our option, without charge for parts or labor incurred in replacing parts, any
part which we fi nd to be defective due to materials or workmanship. This Warranty is
subject to the following limitations and exclusions.
1. This warranty does not apply to the engine, other than EHP manufactured transaxle/
transmission components, battery (except as noted below) or components parts
thereof. Please refer to the applicable manufacturer's warranty on these items.
2. Transportation charges for the movement of any power equipment unit or attachment
are the responsibility of the pur chaser. Transportation charges for any parts submitted for replacement under this warranty must be paid by the purchaser unless such
return is requested by Electrolux Home Products.
3. Battery Warranty: On products equipped with a Battery, we will replace, without
charge to you, any battery which we fi nd to be defective in manufacture, during the
fi rst ninety (90) days of ownership. After ninety (90) days, we will exchange the Battery, charging you 1/12 of the price of a new Battery for each full month from the date
of the original sale. Battery must be maintained in accordance with the instructions
furnished.
4. The Warranty period for any products used for rental or commercial purposes is
limited to 90 days from the date of original purchase.
5. This Warranty applies only to products which have been properly assembled, adjusted, operated, and main tained in ac cor dance with the instructions furnished. This
Warranty does not apply to any product which has been subjected to alteration, misuse, abuse, improper assembly or installation, delivery damage, or to normal wear of
the product.
6. Exclusions: Excluded from this Warranty are belts, blades, blade adapters, normal
wear, normal adjustments, stan dard hardware and normal maintenance.
7. In the event you have a claim under this Warranty, you must return the product to an
authorized service dealer.
Should you have any unanswered questions concerning this Warranty, please contact:
Electrolux Home Products, Inc.
Outdoor Products Customer Service Dept.
250 Bobby Jones Expressway
Augusta, GA 30909 USA
giving the model number, serial number and date of purchase of your product and the
name and address of the authorized dealer from whom it was purchased.
THIS WARRANTY DOES NOT APPLY TO INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WAR RAN TIES ARE LIMITED TO THE SAME TIME
PERIODS STATED HEREIN FOR OUR EXPRESSED WARRANTIES. Some areas do
not allow the limitation of consequential damages or limitations of how long an implied
Warranty may last, so the above limitations or exclusions may not apply to you. This
Warranty gives you specifi c legal rights, and you may have other rights which vary from
locale to locale.
This is a limited Warranty within the meaning of that term as defi ned in the MagnusonMoss Act of 1975.
In Canada contact:
Electrolux Canada Corp.
7075 Ordan Drive
Mississauga, Ontario
L5T 1K6
2
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
SAFETY RULES
IMPORTANT: This cutting machine is ca pa ble of amputating hands and feet and throw-
ing objects. Failure to observe the fol low ing safety instructions could result in serious
injury or death.
WARNING: In order to prevent accidental starting when setting up, trans port ing, ad just ing or making repairs,
always dis con nect spark plug wire and
place wire where it can not contact spark
plug.
WARNING: Do not coast down a hill in
neutral, you may lose control of the tractor.
WARNING: Tow only the attachments
that are rec om mend ed by and comply with
spec i fi ca tions of the man u fac tur er of your
tractor. Use common sense when towing.
Operate only at the lowest possible speed
when on a slope. Too heavy of a load,
while on a slope, is dan ger ous. Tires can
lose trac tion with the ground and cause
you to lose control of your tractor.
WARNING: Engine exhaust, some
of its constituents, and certain vehicle
com po nents contain or emit chem i cals
known to the State of Cal i for nia to cause
can cer and birth defects or oth er re pro ductive harm.
WARNING: Battery posts, terminals
and related accessories contain lead and
lead compounds, chemicals known to the
State of Cal i for nia to cause can cer and
birth defects or oth er re pro duc tive harm.
Wash hands after handling.
I. GENERAL OPERATION
• Read, understand, and follow all instruc-
tions in the manual and on the machine
before starting.
• Only allow responsible adults, who are
familiar with the in struc tions, to operate
the machine.
• Clear the area of objects such as rocks,
toys, wire, etc., which could be picked
up and thrown by the blade.
• Be sure the area is clear of other people
before mow ing. Stop machine if anyone
enters the area.
• Never carry passengers.
• Do not mow in reverse unless ab so lute ly necessary. Always look down and
behind before and while back ing.
• Be aware of the mower discharge direction and do not point it at anyone. Do
not operate the mower without either
the entire grass catcher or the guard in
place.
• Slow down before turning.
• Never leave a running machine unattended. Always turn off blades, set
parking brake, stop engine, and remove
keys before dismounting.
• Turn off blades when not mowing.
• Stop engine before removing grass
catcher or un clog ging chute.
• Mow only in daylight or good artifi cial
light.
• Do not operate the machine while under
the infl uence of alcohol or drugs.
• Watch for traffi c when operating near or
crossing road ways.
• Use extra care when loading or un load ing the machine into a trailer or
truck.
• Data indicates that operators, age 60
years and above, are involved in a large
percentage of riding mower-related injuries. These operators should evaluate
their ability to operate the riding mower
safely enough to protect them selves and
others from serious injury.
• Keep machine free of grass , leaves or
other debris build-up which can touch
hot exhaust / engine parts and burn . Do
not allow the mower deck to plow leaves
or other debris which can cause buildup to occur. Clean any oil or fuel
spillage before operating or storing the
machine . Allow machine to cool before
storage.
II. SLOPE OPERATION
Slopes are a major factor related to lossof-control and tipover accidents, which can
re sult in severe injury or death. All slopes
require extra caution. If you cannot back
up the slope or if you feel uneasy on it, do
not mow it.
3
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
SAFETY RULES
DO:
• Mow up and down slopes, not across.
• Remove obstacles such as rocks, tree
limbs, etc.
• Watch for holes, ruts, or bumps. Uneven terrain could overturn the machine.
Tall grass can hide ob sta cles.
• Use slow speed. Choose a low gear
so that you will not have to stop or shift
while on the slope.
• Follow the manufacturer’s rec om men da tions for wheel weights or coun ter weights to improve stability.
• Use extra care with grass catchers or
other at tach ments. These can change
the stability of the machine.
slow
• Keep all movement on the slopes
gradual
and
changes in speed or direction.
• Avoid starting or stopping on a slope. If
tires lose traction, disengage the blades
and proceed slowly
slope.
DO NOT:
Do not
•
sary, and then, turn slowly and grad u al ly
downhill, if possible.
Do not
•
or embankments. The mower could
suddenly turn over if a wheel is over
the edge of a cliff or ditch, or if an edge
caves in.
Do not
•
traction could cause sliding.
Do not
•
putting your foot on the ground.
Do not
•
slopes.
. Do not make sudden
straight
turn on slopes unless nec es -
mow near drop-offs, ditches,
mow on wet grass. Reduced
try to stabilize the machine by
use grass catcher on steep
down the
III. CHILDREN
Tragic accidents can occur if the op er a tor
is not alert to the presence of children.
Children are often attracted to the ma-
Never
chine and the mowing activity.
sume that children will remain where you
last saw them.
• Keep children out of the mowing area
and under the watchful care of another
responsible adult.
• Be alert and turn machine off if children
enter the area.
• Before and when backing, look behind
down
and
for small children.
as-
• Never carry children. They may fall off
and be seriously injured or interfere with
safe machine operation.
• Never allow children to operate the
machine.
• Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may obscure vision.
IV. SERVICE
• Use extra care in handling gasoline and
other fuels. They are fl ammable and
vapors are explosive.
- Use only an approved container.
- Never remove gas cap or add fuel
with the engine running. Allow
engine to cool before refueling. Do
not smoke.
- Never refuel the machine indoors.
- Never store the machine or fuel
container inside where there is an
open fl ame, such as a water heater.
• Never run a machine inside a closed
area.
• Keep nuts and bolts, especially blade
attachment bolts, tight and keep equipment in good condition.
• Never tamper with safety devices.
Check their proper op er a tion regularly.
• Keep machine free of grass, leaves, or
other debris build-up. Clean oil or fuel
spillage. Allow machine to cool before
storing.
• Stop and inspect the equipment if you
strike an object. Repair, if necessary,
before restarting.
• Never make adjustments or repairs with
the engine run ning.
• Grass catcher components are subject
to wear, dam age, and deterioration,
which could expose moving parts or
allow objects to be thrown. Frequently
check com po nents and replace with
manufacturer's rec om mend ed parts,
when nec es sary.
• Mower blades are sharp and can cut.
Wrap the blade(s) or wear gloves, and
use extra caution when servicing them.
• Check brake operation frequently. Adjust and service as required.
4
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
SAFETY RULES
• Be sure the area is clear of other people
before mowing. Stop machine if anyone
enters the area.
• Never carry passengers or children
even with the blades off.
• Do not mow in reverse unless ab so lute ly necessary. Al ways look down and
behind before and while backing.
• Never carry children. They may fall off
and be seriously injured or interfere with
safe machine operation.
• Keep children out of the mowing area
and under the watchful care of another
responsible adult.
• Be alert and turn machine off if children
enter the area.
• Before and when backing, look behind
and down for small children.
• Mow up and down slopes (15° Max), not
across.
• Remove obstacles such as rocks, tree
limbs, etc.
• Watch for holes, ruts, or bumps. Uneven
terrain could overturn the machine. Tall
grass can hide obstacles.
• Use slow speed. Choose a low gear
so that you will not have to stop or shift
while on the slope.
• Avoid starting or stopping on a slope. If
tires lose traction, disengage the blades
and proceed slowly straight down the
slope.
• If machine stops while going uphill,
disengage blades, shift into reverse and
back down slowly.
• Do not turn on slopes unless nec es sary,
and then, turn slowly and grad u al ly
downhill, if possible.
5
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
PRODUCT SPECIFICATIONS
Gasoline 1.25
Capacity and Unleaded and
Type: Regular
Oil Type SAE 30
(API-SF-SJ): (above 32°F)
SAE 5W-30
(below 32°F)
Oil Capacity: 3.0 Pints
Spark Plug: Champion RC12YC
(Gap: .030")
Ground Speed (MPH):
Forward: 1st 1.1
2nd 1.4
3rd 2.2
4th 3.3
5th 4.4
6th 4.9
Reverse: 1.4
Tire Pressure: Front: 14 PSI
Rear: 12 PSI
Charging 3 Amps Battery
System: 5 Amps Headlights
Battery: Amp/Hr: 28
Min. CCA: 230
Case Size: U1R
Blade Bolt Torque: 27-35 Ft. Lbs.
CONGRATULATIONS on your purchase
of a new tractor. It has been designed,
engineered and manu fac tured to give
you the best possible dependability and
performance.
Should you experience any problem you
cannot easily remedy, please con tact
your nearest authorized service center/
department. We have com pe tent, welltrained tech ni cians and the proper tools to
ser vice or repair this tractor.
Please read and retain this manual. The
instructions will enable you to assemble
and maintain your tractor prop erly. Always
observe the “SAFETY RULES”.
CUSTOMER RESPONSIBILITIES
• Read and observe the safety rules.
• Follow a regular schedule in main tain ing, caring for and using your tractor.
• Follow the instructions under “Main te nance” and “Stor age” sec tions of this
own er’s manual.
WARNING: This tractor is equipped
with an internal com bus tion engine and
should not be used on or near any un im proved forest-covered, brush-covered or
grass-cov ered land unless the engine’s
exhaust system is equipped with a spark
arrester meeting applicable local or state
laws (if any). If a spark arrester is used, it
should be maintained in effective working
order by the operator.
In the state of California the above is
required by law (Section 4442 of the
California Public Resources Code). Other
states may have similar laws. Federal
laws apply on federal lands. A spark arrester for the muffl er is available through
your nearest authorized service center/department (See REPAIR PARTS section of
this manual).
6
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
UNASSEMBLED PARTS
Steering Wheel
Steering
Wheel Insert
(1) Hex Bolt 1/4-28 x 1-1/4
Steering
Wheel
Adapter
Blade
(1) Hex nut
1/2-20
(1) Large
(1)
Locknut
1/4-28
Steering
Extension
Shaft
Flat Washer
Seat
(1) Washer
17/32 x 1-3/16 x 12 Gauge
Steering
Boot
(2) Mulch Blades
(1) Oil Drain Tube
For Future Use
Keys
(1) Lock Washer 1/2
(1) Bolt
Slope Sheet
(2) Keys
7
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
ASSEMBLY/PRE-OPERATION
Your new tractor has been assembled at the factory with the exception of those parts left
unassembled for shipping purposes. To ensure safe and proper operation of your tractor
all parts and hardware you as sem ble must be tightened securely. Use the correct tools
as nec es sary to in sure proper tightness. Review the video cassette before you begin.
TOOLS REQUIRED FOR
ASSEMBLY
A socket wrench set will make assembly
easier. Stan dard wrench sizes you need
are listed below.
(1) 3/4" wrench (1) Pliers
(2) 7/16" wrench (1) Utility knife
(1) Tire pressure gauge
When right or left hand is mentioned in
this man ual, it means when you are in
the operating po si tion (seated be hind the
steer ing wheel).
TO REMOVE TRACTOR FROM
CARTON
UNPACK CARTON
1. Remove all accessible loose parts and
parts boxes from carton.
2. Cut along dotted lines on all four panels of carton. Remove end panels and
lay side panels fl at.
3. Check for any additional loose parts or
cartons and remove.
Steering
Wheel
Adapter
1/4 Locknut
Lower
Steering
Shaft
Insert
1/2 Hex Nut
Large Flat
Washer
Steering
Boot
Tabs
Extension
Shaft
1/4 Hex Bolt
Ta b
Slots
BEFORE REMOVING TRACTOR
FROM SKID
ATTACH STEERING WHEEL
ASSEMBLE EXTENSION SHAFT AND
BOOT
1. Slide extension shaft onto lower steering shaft. Align mount ing holes in
extension and lower shafts and install
1/4 hex bolt and lock nut. Tighten
securely.
IMPORTANT: Tighten bolt and nut securely to 10-12 ft. lbs torque.
2. Place tabs of steering boot over tab
slots in dash and push down to secure.
INSTALL STEERING WHEEL
3. Position front wheels of the tractor so
they are pointing straight forward.
4. Remove steering wheel adapter from
steering wheel and slide adapter onto
steer ing shaft ex ten sion.
5. Position steering wheel so cross bars
are hor i zon tal (left to right) and slide
inside boot and onto adapt er.
6. Assemble large fl at washer, 1/2 hex
nut and tighten se cure ly.
7. Snap steering wheel insert into center
of steer ing wheel.
8. Remove protective materials from trac tor hood and grill.
IMPORTANT: Check for and remove any
staples in skid that may puncture tires
where tractor is to roll off skid.
INSTALL SEAT
Adjust seat before tightening adjustment
bolt.
1. Remove adjustment bolt, lock washer
and fl at washer se cur ing seat to
cardboard packing and set aside for as sem bly of seat to tractor.
2. Pivot seat upward and remove from
the cardboard packing. Remove the
cardboard packing and discard.
3. Place seat on seat pan so head of
shoulder bolt is positioned over large
slotted hole in pan.
4. Push down on seat to engage shoulder
bolt in slot and pull seat towards rear of
tractor.
5. Pivot seat and pan forward and as sem ble adjustment bolt, lockwasher
and fl at washer loosely. Do not tighten.
6. Lower seat into operating position and
sit in seat.
8
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
7. Slide seat until a comfortable position
is reached which allows you to press
clutch/brake pedal all the way down.
8. Get off seat without moving its adjusted position.
9. Raise seat and tighten adjustment bolt
securely.
Seat
Seat Pan
Shoulder
Bolt
Flat Washer
Lock
Washer
Adjustment Bolt
CHECK BATTERY
1. Lift seat pan to raised position.
NOTE: If this battery is put into service
after month and year indicated on label
(label located between terminals) charge
battery for minimum of one hour at 6-10
amps. (See "BATTERY" in Maintenance
section of this manual for charging instructions).
Seat pan
Label
Terminal
Terminal
NOTE: You may now roll or drive your
tractor off the skid. Follow the ap pro pri ate
instruction below to remove the tractor
from the skid.
TO ROLL TRACTOR OFF SKID (See
Op er a tion section for location and
function of con trols)
1. Press lift lever plunger and raise
at tach ment lift lever to its highest po si tion.
2. Release parking brake by depressing
clutch/brake ped al.
3. Place gearshift lever in neutral (N)
po si tion.
4. Roll tractor forward off skid.
5. Remove banding holding defl ector
shield up against tractor.
TO DRIVE TRACTOR OFF SKID
(See Op er a tion section for location
and func tion of con trols)
WARNING: Before starting, read, un-
der stand and follow all in struc tions in the
Operation section of this manual. Be sure
tractor is in a well-ventilated area. Be sure
the area in front of tractor is clear of other
people and objects.
1. Be sure all the above assembly steps
have been com plet ed.
2. Check engine oil level and fi ll fuel tank
with gasoline.
3. Sit on seat in operating position,
depress clutch/brake pedal and set the
parking brake.
4. Place gear shift lever in neutral (N)
position.
5. Press lift lever plunger and raise
at tach ment lift lever to its highest position.
6. Start the engine. After engine has
started, move throttle control to idle
position.
7. Depress clutch/brake pedal into full
"BRAKE" position and hold. Move
gearshift lever to 1st gear.
8. Slowly release clutch/brake pedal and
slowly drive tractor off skid.
9. Apply brake to stop tractor, set park-
ing brake and place gearshift lever in
neutral position.
10.Turn ignition key to "STOP" position.
Continue with the instructions that follow.
IMPORTANT: For shipping purposes, the
mulcher plate was preattached to your
mower. The mulcher plate must only be
used with the mulching blades that came
packed separately in the carton.
Your mower came factory equipped with
high performance blades, which are the
best blades for bagging and dis charg ing.
To use your mower with the high per for mance blades the mulcher plate must be
removed from the mower.
TO SET UP YOUR MOWER FOR
MULCH ING
• Remove high performance blades and
install mulching blades, (see BLADE
RE MOV AL in the Maintenance sec tion
of this manual).
9
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
INSTALL MULCHER PLATE
NOTE: If you installed the mulching blades
you will need to install the mulcher plate.
1. Raise and hold defl ector shield in
up right po si tion.
2. Place front of mulcher plate over front
of mower deck open ing and slide into
place, as shown.
3. Hook front latch into hole on front of
mower deck.
4. Hook rear latch into hole on back of
mower deck.
CAUTION: Do not remove defl ector
shield from mower.
TO CONVERT TO BAGGING OR
DIS CHARG ING
NOTE: The mulching blades will dis charge
and bag grass, but for best bagging and
discharging install the high per for mance
blades.
1. Remove mulcher plate and mulching
blades and install high performance
blades, (see BLADE REMOVAL in the
Maintenance section of this man u al).
2. Store mulching blades and mulcher
plate in a safe place. Your mower is
now ready for dis charg ing or in stal la tion of optional grass catcher ac ces so ry.
Defl ector
Shield
Mulcher
Plate
Latch
Hooks
CHECK TIRE PRESSURE
The tires on your tractor were over in fl ated at the factory for shipping pur pos es.
Correct tire pressure is important for best
cutting performance.
• Reduce tire pressure to PSI shown in
“PRODUCT SPEC I FI CA TIONS” section
of this manual.
CHECK DECK LEVELNESS
For best cutting results, mower housing should be properly leveled. See “TO
LEVEL MOWER HOUSING” in the Service
and Adjustments section of this manual.
CHECK FOR PROPER POSITION
OF ALL BELTS
See the fi gures that are shown for replacing motion and mower blade drive belts
in the Service and Adjustments sec tion
of this manual. Verify that the belts are
routed correctly.
CHECK BRAKE SYSTEM
After you learn how to operate your tractor, check to see that the brake is properly
adjusted. See “TO ADJUST BRAKE” in
the Service and Adjustments section of
this manual.
✓
CHECKLIST
Before you operate and enjoy your new
trac tor, we wish to assure that you receive
the best per for mance and sat is fac tion
from this Quality Prod uct.
Please review the following checklist:
✓ All assembly instructions have been
completed.
✓ No remaining loose parts in carton.
✓ Battery is properly prepared and
charged. (Minimum 1 hour at 6 amps).
✓ Seat is adjusted comfortably and tight-
ened securely.
✓ All tires are properly infl ated. (For ship-
ping purposes, the tires were overinfl ated at the factory).
✓ Be sure mower deck is properly leveled
side-to-side/front-to-rear for best cutting
results. (Tires must be properly infl ated
for leveling).
✓ Check mower and drive belts. Be sure
they are routed properly around pulleys
and inside all belt keepers.
✓ Check wiring. See that all con nec tions
are still secure and wires are properly
clamped.
While learning how to use your tractor, pay
extra attention to the following important
items:
✓ Engine oil is at proper level.
✓ Fuel tank is fi lled with fresh, clean, regu-
lar unleaded gasoline.
✓ Become familiar with all controls - their
location and function. Operate them
before you start the engine.
✓ Be sure brake system is in safe op er -
at ing condition.
10
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
OPERATION
These symbols may appear on your tractor or in literature supplied with the product.
Learn and understand their meaning.
REVERSE
ENGINE OFF
OVER TEMP
LIGHT
ATTACHMENT
CLUTCH ENGAGED
FREE WHEEL
(Automatic Models only)
NEUTRAL
LIGHTS ON
FUEL
OIL PRESSURE
ATTACHMENT
CLUTCH DISENGAGED
HIGH
ENGINE ON
LOW
ENGINE START
BATTERY
DANGER, KEEP HANDS
AND FEET AWAY
CHOKE
PARKING BRAKE
REVERSE
DANGER indicates a hazard which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazard which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazard which, if not avoided,
might result in minor or moderate injury.
FAST
P
FORWARD
KEEP AREA CLEAR
SLOW
PARKING BRAKE
LOCKED
MOWER HEIGHT
15
SLOPE HAZARDS
(SEE SAFETY RULES SECTION)
IGNITION
PARKING BRAKE
UNLOCKED
MOWER LIFT
15
Failure to follow instructions
could result in serious injury or
death. The safety alert symbol
is used to identify safety information about hazards which can
result in death, serious injury
and/or property damage.
CAUTION when used without the alert symbol,
indicates a situation that could result in damage
to the tractor and/or engine.
HOT SURFACES indicates a hazard which,
if not avoided, could result in death, serious injury
and/or property damage.
FIRE indicates a hazard which, if not avoided,
could result in death, serious injury and/or
property damage.
11
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
KNOW YOUR TRACTOR
READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR
TRACTOR
Compare the illustrations with your tractor to familiarize yourself with the locations of
various controls and ad just ments. Save this manual for future reference.
Attachment
Clutch Lever
Throttle/Choke
Control
Clutch/Brake
Pedal
Ignition Switch
Light Switch Position
Lift Lever
Plunger
Attachment
Lift Lever
Height
Adjustment
Indicator
Gearshift Lever
Our tractors conform to the safety standards of the
American National Stan dards Institute.
ATTACHMENT CLUTCH LEVER - Used
to engage the mower blades, or other attachments mounted to your trac tor.
ATTACHMENT LIFT LEVER - Used to
raise, lower, and adjust the mower deck or
other attachments mounted to your tractor.
CLUTCH/BRAKE PEDAL - Used for
declutching and brak ing the tractor and
starting the engine.
GEARSHIFT LEVER - Selects the speed
and direction of tractor.
Parking Brake Lever
IGNITION SWITCH - Used for starting and
stopping the engine.
LIFT LEVER PLUNGER - Used to re lease
attachment lift lever when chang ing its
position.
LIGHT SWITCH POSITION - Turns the
head lights on and off.
PARKING BRAKE LEVER - Locks clutch/
brake pedal into the brake po si tion.
THROTTLE/CHOKE CONTROL - Used
for starting and controlling engine speed.
12
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
The op er a tion of any trac tor can result in foreign objects thrown into
the eyes, which can result in severe eye dam age. Al ways wear safety
glass es or eye shields while op er at ing your trac tor or per form ing any
ad just ments or repairs. We rec om mend a wide vi sion safe ty mask over
spec ta cles or stan dard safety glass es.
HOW TO USE YOUR TRAC TOR
TO SET PARKING BRAKE
Your tractor is equipped with an operator
presence sens ing switch. When engine
is running, any attempt by the op er a tor
to leave the seat without fi rst setting the
parking brake will shut off the engine.
1. Depress clutch/brake pedal all the
way down and hold.
2. Pull parking brake lever up and
re lease pres sure from clutch/brake
pedal. Pedal should re main in brake
position. Make sure parking brake will
hold tractor secure.
Attachment Clutch Lever
“Engaged” Position
Throttle/Choke
Control
Clutch/
Brake
Pedal
“Disengaged”
Position
Gearshift Lever
STOPPING
MOWER BLADES -
• To stop mower blades, move at tach -
ment clutch lever to “DIS EN GAGED”
po si tion.
GROUND DRIVE -
• To stop ground drive, depress clutch/
brake pedal all the way down.
• Move gearshift lever to neutral (N)
po si tion.
ENGINE -
• Move throttle control to slow po si tion.
NOTE: Failure to move throttle control
to slow position and allowing engine to
idle before stopping may cause engine to
“backfi re”.
• Turn ignition key to “STOP” position and
remove key. Always remove key when
leaving tractor to prevent un au tho rized
use.
• Never use choke to stop engine.
Ignition Key
“Disengaged”
Position
Parking Brake
“Engaged”
Position
“Brake”
Position
IMPORTANT: Leaving the ignition switch
in any position other than "STOP" will
cause the battery to discharge and go
dead.
NOTE: Under certain conditions when
tractor is standing idle with the engine running, hot engine exhaust gases may cause
“browning” of grass. To elim i nate this possibility, always stop engine when stopping
tractor on grass areas.
CAUTION: Always stop tractor com-
plete ly, as de scribed above, before leav ing
the operator's position.
TO USE THROTTLE CON TROL
Always operate engine at full throttle.
• Operating engine at less than full
throttle reduces the battery charg ing
rate.
• Full throttle of fers the best bagging and
mower per for mance.
TO MOVE FORWARD AND BACK WARD
The direction and speed of movement is
controlled by the gearshift lever.
1. Start tractor with clutch/brake pedal
depressed and gearshift lever in neutral
(N) position.
2. Move gearshift lever to desired po-
si tion.
3. Slowly release clutch/brake pedal to
start movement.
IMPORTANT: Bring tractor to a complete
stop before shifting or changing gears.
Failure to do so will shorten the useful life
of your transaxle.
TO ADJUST MOWER CUT TING HEIGHT
The po si tion of the at tach ment lift le ver
de ter mines the cut ting height.
• Grasp lift le ver.
• Press plunger with thumb and move lever
to desired position.
The cutting height range is ap prox i mate ly
1-1/2 to 4". The heights are measured from
the ground to the blade tip with the engine
not running. These heights are approximate
and may vary depending upon soil conditions, height of grass and types of grass
being mowed.
• The average lawn should be cut to approximately 2-1/2 inches during the cool
season and to over 3 inches during hot
months.
13
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
For healthier and better looking lawns,
mow often and after moderate growth.
• For best cutting performance, grass over
6 inches in height should be mowed
twice. Make the fi rst cut relatively high;
the second to de sired height.
TO ADJUST GAUGE WHEELS
Gauge wheels are prop er ly ad just ed
when they are slight ly off the ground when
mower is at the desired cutting height in
operating position. Gauge wheels then
keep the deck in proper position to help
prevent scalping in most terrain conditions.
NOTE: Adjust gauge wheels with tractor
on a fl at level surface.
1. Adjust mower to desired cutting height
(See “TO AD JUST MOWER CUT TING
HEIGHT” in this sec tion of manual).
2. With mower in desired height of cut
po si tion, gauge wheels should be
assembled so they are slightly off the
ground. In stall gauge wheel in ap pro pri ate hole with shoulder bolt, 3/8
washer, and 3/8-16 locknut and tighten
se cure ly.
3. Repeat for opposite side, installing
gauge wheel in same adjustment hole.
Gauge Wheel
Mounting
Bracket
3/8-16
Locknut
3/8 Washer
Gauge Wheel
Shoulder
Bolt
TO OPERATE MOWER
Your tractor is equipped with an operator
presence sensing switch. Any attempt
by the operator to leave the seat with the
engine running and the attachment clutch
engaged will shut off the engine. You must
remain fully and centrally positioned in the
seat to prevent the engine from hesitating
or cutting off when operating your equipment on rough, rolling terrain or hills.
1. Select desired height of cut.
2. Start mower blades by engaging at-
tach ment clutch control.
TO STOP MOWER BLADES disengage at tach ment clutch con trol.
CAUTION: Do not operate the mower
without either the en tire grass catcher,
on mowers so equipped, or the defl ector
shield in place.
Attachemnt Lift
Lever High Position
Attachment
Clutch Lever
“Engaged”
Position
“Disengaged”
Position
Low
Position
Defl ector
Shield
TO OPERATE ON HILLS
WARNING: Do not drive up or down
hills with slopes great er than 15° and do
not drive across any slope. Use the slope
guide at the back of this manual.
• Choose the slowest speed before starting up or down hills.
• Avoid stopping or changing speed on
hills.
• If slowing is necessary, move throt tle
control lever to slower po si tion.
• If stopping is absolutely necessary, push
clutch/brake pedal quickly to brake position and engage parking brake.
• Move gearshift lever to 1st gear. Be
sure you have allowed room for tractor
to roll slightly as you restart movement.
• To restart movement, slowly re lease
parking brake and clutch/brake pedal.
• Make all turns slowly.
TO TRANSPORT
• Raise attachment lift to highest position
with at tach ment lift control.
• When pushing or towing your trac tor,
be sure gearshift lever is in neutral (N)
position.
• Do not push or tow tractor at more than
fi ve (5) MPH.
NOTE: To protect hood from damage
when transporting your tractor on a truck
or a trailer, be sure hood is closed and
secured to tractor. Use an appropriate
means of tying hood to tractor (rope, cord,
etc.).
TOWING CARTS AND OTHER AT TACH MENTS
Tow only the attachments that are rec om mend ed by and comply with spec i fi ca tions
of the manufacturer of your tractor. Use
common sense when tow ing. Too heavy
of a load, while on a slope, is dangerous.
Tires can lose traction with the ground and
cause you to lose control of your tractor.
14
www.mymowerparts.com
For Parts Call K&T 606-678-9623 or 606-561-4983
BEFORE STARTING THE ENGINE
CHECK ENGINE OIL LEVEL
The engine in your tractor has been
shipped, from the factory, already fi lled
with sum mer weight oil.
1. Check engine oil with tractor on level
ground.
2. Remove oil fi ll cap/dipstick and wipe
clean, reinsert the dipstick and screw
cap tight, wait for a few seconds, remove and read oil level. If nec es sary,
add oil until “FULL” mark on dipstick is
reached. Do not overfi ll.
• For cold weather operation you should
change oil for easier starting (See the
oil viscosity chart in the Main te nance
sec tion of this man u al).
• To change engine oil, see the Main te -
nance section in this manual.
ADD GASOLINE
• Fill fuel tank to bottom of fi ller neck. Do
not overfi ll. Use fresh, clean, regular
un lead ed gasoline with a minimum of
87 octane. (Use of leaded gasoline will
increase carbon and lead oxide deposits
and reduce valve life). Do not mix oil
with gasoline. Purchase fuel in quan ti ties that can be used within 30 days to
assure fuel freshness.
CAUTION: Wipe off any spilled oil or
fuel. Do not store, spill or use gasoline
near an open fl ame.
IMPORTANT: When operating in temperatures below32°F(0°C), use fresh, clean
winter grade gas o line to help insure good
cold weather start ing.
CAUTION: Alcohol blended fuels (called
gasohol or using ethanol or methanol) can
attract moisture which leads to separation and for ma tion of acids during storage.
Acidic gas can damage the fuel system
of an engine while in storage. To avoid
engine problems, the fuel system should
be emptied before stor age of 30 days
or longer. Drain the gas tank, start the
engine and let it run until the fuel lines
and carburetor are empty. Use fresh fuel
next season. See Storage In struc tions for
additional information. Never use engine
or carburetor cleaner products in the fuel
tank or permanent damage may occur.
TO START ENGINE
When starting the engine for the fi rst time
or if the engine has run out of fuel, it will
take extra cranking time to move fuel from
the tank to the engine.
1. Sit on seat in operating position,
depress clutch/brake pedal and set
parking brake.
2. Place gear shift lever in neutral (N)
position.
3. Move attachment clutch to dis en gaged
po si tion.
4. Move throttle control to choke po si tion.
NOTE: Before starting, read the warm
and cold starting procedures below.
5. Insert key into ignition and turn key
clockwise to start position and release
key as soon as engine starts. Do
not run starter continuously for more
than fi fteen sec onds per minute. If the
engine does not start after several
attempts, move throt tle control to fast
position, wait a few minutes and try
again. If engine still does not start,
move the throttle control back to the
choke position and retry.
WARM WEATHER STARTING (50° F and
above)
6. When engine starts, move the throt tle
control to the fast position.
• The attachments and ground drive can
now be used. If the engine does not
accept the load, restart the en gine and
allow it to warm up for one minute using
the choke as de scribed above.
COLD WEATHER STARTING ( 50° F and
below)
6. When engine starts, leave throttle
control in choke position until engine
warms up and begins to run roughly.
Once rough running begins, im me di ate ly move the throttle control to the
fast position. Engine warm-up may
take from several seconds to several
minutes (the colder the tem per a ture,
the longer the warm-up).
• The attachments can also be used dur-
ing the engine warm-up period.
NOTE: If at a high altitude (above 3000
feet) or in cold temperatures (below 32 F)
the carburetor fuel mixture may need to
be adjusted for best engine performance
(see “TO ADJUST CARBURETOR” in the
Service and Adjustments section of this
manual).
COLD WEATHER STARTING ( 50° F and
below)
6. When engine starts, leave throttle
control in choke position until engine
warms up and begins to run roughly.
Once rough running begins, im me di ate ly move the throttle control to the
fast position. Engine warm-up may
take from several seconds to several
minutes (the colder the tem per a ture,
the longer the warm-up).
15
www.mymowerparts.com
Loading...
