Pottery Barn Universal Trundle Assembly Instruction

pottery barn kids

UNIVERAL TRUNDLE BED

PRE-ASSEMBLY:

• Remove all parts and hardware from the box and lay out on a clean, carpeted, or scratch-free work surface, as this will
avoid damaging any parts during assembly. The shipping box provides an ideal work surface. Do not dispose of any
contents until assembly is completed to avoid accidentally discarding small parts or hardware.

• Two adults recommended for ease of assembly.

• Use the parts and hardware lists to identify and separate each of the pieces included prior to starting assembly.

• The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions.

• Note: Do not fully tighten all bolts until all parts are in place. Failure to follow these instructions may cause the bolts to

misalign during assembly.

• If using power tools to aid in assembly please use caution. Power tools can damage hardware or split wood.

PARTS INCLUDED:

(A) Long Side Rails – 2pcs

(B) Short Side Rails – 2pcs

(C) Bottom board with predrilled holes – 2pcs

(D) Bottom board – 1pc

(E) Cross bar – 2pcs

HARDWARE INCLUDED:

(F) 1/4” x 2-1/2” Bolt – 8pcs (G) Barrel nut – 8pcs

(H) #8 x 1-1/4” Screws – 22 pcs (I) 4mm Allen key –1pc

(J) #7 x 12mm Screw – 24pcs (K) Caster – 6pcs

TOOLS NEEDED:

Phillips screwdriver (not included)

ASSEMBLY INSTRUCTIONS:

1. Lay the (2) Bottom boards (C, D) on your work surface with the side of the pre-drilled holes facing up. Evenly
align the Bottom boards with each other. Attach both of the Cross bars (E) by inserting the #8 x 1-1/4” Screw
(H) into the pre-drilled holes of each cross bar, tightening with the Phillips screwdriver where the Cross bars
join the Bottom boards. Finally, insert the Casters (F) into the pre-drilled holes on the Bottom boards by using
#7 x 12mm screw (J). (Fig. 1)

(Fig. 1)

2. Position the Long side rail (A), exactly as shown in illustration below with the wood dowels of the Cross bar (E)
into the pre-drilled holes of the Long side rail (A). Insert the #8 x 1-1/4” Screws (H) into the pre-drilled holes
located in the support rail of the Long side rail, tightening with Phillips screwdriver. Repeat the same process
for the other Long side rail. (Fig. 2)

(Fig. 2)
