Pottery Barn Sandbox Assembly Instruction

pottery barn kids

SANDBOX

PRE-ASSEMBLY:

• Read all instructions before beginning assembly. The illustrations provided allow for easier
assembly when used in conjunction with the assembly instructions.

• For your safety and ease, assembly by two adults is recommended.

• Remove all part and hardware from the box and lay out on a clean, carpeted, or scratch- free

work surface. Use care as some parts or hardware may have sharp points or edges.

• Do not dispose of any contents until assembly is completed to avoid accidentally discarding small
parts and hardware.

• Use the parts and hardware lists to identify and separate each of the pieces included.

• Note: Do not fully tighten all bolts until all parts are in place. Failure to follow these instructions

may cause the bolts misalign during assembly.

• The use of power tools for assembly is not recommended. Power tools can damage hardware or
split wood.

PARTS INCLUDED:

(A1/A2) Front / Back Panel (2)
(B1/B2) Side panel (2)
(C1/C2/C3/C4) Awning Poles (4)
(D) Plastic Tarp (1)
(E) Front/back horizontal Bars (2)
(F) Side horizontal Bars (2)
(G) Triangle Supports (8)

HARDWARE INCLUDED:

(H) 4mm Allen Key (1)

(I) Short Bolt 20mm (24)

(J) Medium Bolt 40mm (8)

(K) Long Bolt 50mm (4)

(L) Extra Long Bolt 60mm (16)

C1

B

1

E

A1

G

C2

C4

F

G

B2

C3

A2

Page 1/5

ASSEMBLY INSTRUCTIONS:

1. Align and assemble Awning poles (C1/C2/C3/C4) to the wood posts on each corner of the

side panels (A1/A2) as shown. Secure them with the (2) Extra Long bolts (L) on each side
using Allen key h. Repeat same procedure for back awning poles (D).

(Fig.1)

2. Assemble the side horizontal bar (F) as shown to connect the awning poles.

C1

L

H

(Fig.2)

C2

A1

F

C4

C3

H

L

A2

Page 2/5
