pottery barn kids
OLIVIA CHIFFONIER
PRE-ASSEMBLY:
• Read all instructions before beginning assembly. The illustrations provided allow for easier assembly when used in
conjunction with the assembly instructions.
• For your safety and ease, assembly by tw o adults is reco mmended .
• Remove all parts and hardware from the box and lay out on a clean, carpeted, or scratch-free work surface. Use care
as some parts or hardware may ha ve sharp poin ts or edges.
• Do not dispose of any contents until assembly is completed to avoid accidentally discarding small parts or hardware.
• Use the parts and hardware lists to identify and separate each of the pieces included.
• Note: Do not fully tighten all bolts until all parts are in place. Failure to follow these instructions may cause the
bolts to misalign during assembly.
• If using power tools to aid in assembly please use caution. Power tools can damage hardware or split wood.
P ARTS INCLUDED:
(A) Chiffonier - 1pc
(B) Leg - 4pcs
(C) Adjustable shelf - 2pcs
(D) Hanging rod - 1pc
HARDWARE ENCLOSED:
(E) Knobs - 3pcs
(F) #4x15mm Screw -3pcs
(G) Shelf Supports - 8pcs
TOOLS REQUIRED:
Phillips head screwdriver (not included)
B
C
D
C
A
B
B
Page 1/3
ASSEMBLY INSTRUCTIONS:
1. Lay Chiffonier (A) down on a soft surface such as a carpet. Attach the Legs (B) to the Chiffonier (A) (see Fig. 1).
Turn the Chiffonier (A) upright.
(Fig. 1)
2. Fasten Knobs (E) to door and drawer using Screws (F). Tighten with Phillips head screwdriver. Place the Hanging
rod (D) onto the block mounted inside the Chiffonnier (A) as shown. (See Fig.2)
(Fig. 2)
A
D
A
B
D
F
B
B
A
E
Page 2/3
3. To install Adjustable Shelves (C), insert (4) Shelf Supports (G) into the pre-drilled holes on the inner side panels of
Chiffonier (A) at the desired height. Carefully place the Adjustable shelf (C) onto the Shelf Supports (G). Repeat
with second Adjustable Shelf (C). Make sure each Adjustable Shelf (C) is properly supported by all (4) Shelf
Supports (G). (See Fig.3)
(Fig. 3)
4. If your floor is not perfectly even, the furniture may not sit level. To ensure piece is level, determine which leg does
not touch the ground. With two people follow these steps:
• Carefully elevate the item slightly to provide access to the leveler attached to the bottom of the elevated leg.
• Turn the levelers in a counter-clock wise directi on.
• Gently set down the piece and check stability.
• Repeat steps until the furniture sits firmly on the ground.
5. As a safety precaution, please follow the instructions enclosed to secure the Chiffonier to the wall using
the tipping-restraint kit included.
CARE INSTRUCTIONS:
• Dust often using a clean, soft, dry lint-free cloth.
• Blot spills immediately, and wipe with a clean, damp, cloth.
• We do not recommend the use of chemical cleansers, abrasives, or furniture polish on our lacquered finish.
C
C
Thank you for your purchase
stores | catalog | www.potterybarnkids.com
USA 1.800.290.8181
G
Page 3/3
