Pottery Barn Camp Bunk Bed, Camp Bunk System Assembly Instruction

pottery barn kids

CAMP BUNK SYSTEM

WARNING

Failure to follow these warnings and assembly instructions could result in serious
injury or death.

• Read all instructions before assembling bunk bed. KEEP INSTRUCTIONS FOR

FUTURE USE.

• Before each usage or assembly, inspect bunk bed for damaged hardware, loose

joints, missing parts or sharp edges. DO NOT use bunk bed if any parts are missing
or broken. Telephone or write to Pottery Barn Kids for replacement parts and
instructional literature if needed. DO NOT substitute parts.

• Follow the information on the warnings appearing on the upper bunk end structure

and on the carton. DO NOT REMOVE WARNING LABEL FROM THE BED.

• Never allow a child under 6 years on upper bunk.

• Use only mattress which is 74"-75" long and 37.5"-38.5" wide on upper bunk.

• Ensure thickness of mattress does not exceed 9” and mattress is at least 5" below

upper edge of guardrails.

• Always use the recommended size mattress or mattress support, or both, to help

prevent the likelihood of entrapment or falls.

• Surface of mattress must be at least 5 inches (127 mm) below the upper edge of the

guardrails.

• Periodically check and ensure that the guardrail, ladder and other components are

in their proper position, free from damage, and that all connectors are tight.

• Do not allow horseplay on or under the bed and prohibit jumping on the bed.

• Always use the ladder for entering and leaving the upper bunk.

• Use of a night light may provide added safety precautions for a child using the

upper bunk.

• Always use guardrails on both long sides of the upper bunk.

• Prohibit more than one person on the upper bunk.

• If the bunk bed will be placed next to a wall, the guardrail that runs the full length of

the bed should be placed against the wall to prevent entrapment between the bed
and the wall.

• If refinishing, use a non-toxic finish specified for children’s products.

• STRANGULATION HAZARD – Never attach or hang items to any part of the

bunk bed that are not designed for use with the bed; for example, but not limited to,
hooks, belts, and jump ropes.

• The use of water or sleep flotation mattress is prohibited.

Page 1/8

PRE-ASSEMBLY:

• For your safety and ease, assembly by two adults is recommended.

• Please read all instructions before beginning assembly. The illustrations provided allow for easier assembly when used in

conjunction with the assembly instructions.

• Remove all parts and hardware from box and lay out on a carpeted or scratch-free work surface. The shipping box provides
and ideal work surface. Do not dispose of any contents until assembly is completed to avoid accidentally discarding small
parts or hardware.

• Use the parts and hardware lists to identify and separate each of the pieces included prior to starting assembly.

• Note: DO not fully tighten the bolts until all parts are in place. Failure to follow these instructions may cause the bolts to

misalign during assembly.

• The use of power tools for assembly is not recommended. Power tools can damage hardware or split wood.

A.

C.

D.

B.

PARTS INCLUDED:

(A). End Board
(B). Bed Side Rail
(C). Long Guardrail
(D). Short Guardrail
(E). Slat Roll
(F). Desk End
(G). Storage End
(H). Drawer(pre-attached) 5pcs

2pcs
2pcs
1pc
1pc
1pc
1pc
1pc

(I). Removable Shelf
(J). Ladder

1pc
1pc

Page 2/8

HARDWARE INCLUDED:

(K). Allen Key– 1pc

(N) Short Wood Screw

4 x 20mm – 12pcs

(L) Long Bolt 5/16” x 110mm

– 8pcs

(O) Long Wood Screw
4 x 30mm – 32pcs

(M) Barrel Nut – 8pcs

(P) Smooth Metal Dowel –
8pcs

(Q) Pressure Plate – 4pcs

(T) Shelf Support Peg – 4pcs

TOOLS REQUIRED:

Philips Screwdriver (Not included)

(R) Short Bolt 1/4“x 30mm

(S) Spring Washer – 4pcs

– 4pcs

Page 3/8
