HC2003 HANDSFREE TELEPHONE
The HC2003 Hands Free Telephone can be controlled by
all of the Possum Infrared Enviromental Controllers,and
also any infrared unit that can learn Possum Infrared
Telephone codes. For operation of the phone from the
individual controllers please refer to their respective user
guides.
Once the control unit has been programmed it can
access any of the following functions.
1. 0 to 9, *, #. 4. Directory
2. Redial 5. Dial
3. Help 6. Calls
PRIVATE CALLS
An extra function now available is private radio headset
conversations this is achived by plugging an off the shelf
radio headset system into handset port. It is important to
understand that the headset runs on batteries and should
be fully charged over night
Note in order to make a private phone call the user must
first dial the desired number using the hands free mode.
Once the call is answered at the other end the user must
select “private” this will disconnect the hands free speaker
and connect the headset only. If the user is answering a
call only they can go straight to “private” to pick up the call
on the headset. If the user wants to pick up a call in hands
free mode they must select ans phone.
All other user functions are as described in the
InTouch2000 user guide that is supplied with each phone.
TO USE
RESET
SWITCH
REMOTE
SENSOR
INDICATION
LED
FUNCTIONS
INDICATION LED
This flashes to indicate telephone is active via the Headset
RESET SWITCH
The reset switch can be used as a manual override to
deactivate the Headset
The HC2003 Hands Free Telephone is classified as a Class 1
(low risk) medical device, intended for use by physically
disabled persons to control appliances or equipment in a
domestic environment. The unit may also be used within
nursing homes and hospitals, providing adequate care is
taken to ensure the safety of each particular installation.
Possum Controls Limited products are not authorised for use
as critical components in life support devices or systems which
sustain life and whose failure to perform, when properly used in
accordance with the instructions for use provided, can reasonably be expected to result in significant injury or death. A critical
component is any component of a life support device or system
whose failure to perform can reasonably be expected to cause
the failure of the life support device or system or to affect its
safety or effectiveness.
SCOPE OF USE
APPROVALS
The Possum HC2003 Hands Free Telephone is CE marked
under the Medical Devices Directive 93/94/EEC (as an
accessory to a Possum Compact, Companion or Freeway
Controller) and has been tested and approved to the following
standards:
HC2003
This equipment does generate, use and can radiate radio
frequency energy and if not installed correctly, may cause
interference with radio and television receivers or other sensitive
equipment. This equipment may be susceptible to radio
frequency energy or mains conducted interference generated by
other nearby equipment. Interference is unlikely to be a problem
in a typical domestic environment, but if you have any queries
please contact Possum Controls Limited for advice.
POSSUM CONTROLS LIMITED
8, FARMBROUGH CLOSE
STOCKLAKE PARK INDUSTRIAL EST
AYLESBURY
BUCKS
HP20 1DQ
Possum Controls Limited reserves the right to make
improvements to this guide or the products it
describes at any time and without further notice.
This guide is copyright in the U.K. and all rights are
reserved. No part of this guide may be reproduced by
any means or in any form without the prior consent in
writing from Possum Controls Limited.
Notice
HC2003 User Guide - part number: 034-434 Iss:2
Possum Controls Limited, July 2004
TELEPHONE
FAX
email
website
01296 461000
01296 461001
sales@possum.co.uk
http://www.possum.co.uk
There are no user-serviceable parts within the
HC2003. Refer all faults to Possum Controls Limited
or their authorised service agents.
Note that under the Medical Devices Directive, only service
personnel trained and approved by Possum Controls Limited
are permitted to install, maintain and repair this product.
WARNING! Hazardous voltages and exposed live
parts exist within the HC2003 unit when in use. Never
attempt to open the unit or remove the case cover.
PRODUCT CARE
Disconnect the mains power supply & telephone line to the
HC2003 unit before attempting to clean the product.
The Possum HC2003 should be cleaned only with a soft, lintfree cloth slightly moistened with clean water.
Do not use abrasive or solvent-based cleaning products.
Do not allow moisture to enter the HC2003 unit. Ensure that
the product is dry before re-connecting to the mains power
supply & telephone line.
The Possum HC2003 is intended for indoor use only and is
not drip proof, splash proof or waterproof.
The Possum HC2003 is not anaesthetic proof and cannot be
sterilised.
SPECIFICATIONS
POWER REQUIREMENTS
The Possum HC2003 is designed to operate only with
supplied power supply. (Never use a HC501 or any other
power supply)
OPERATING/STORAGE ENVIRONMENT
Storage Temperature Range: 0°C to 40°C
(32°F to 104°F)
Storage Humidity Range: 30% to 75%
(non-condensing)
Storage Altitude Range: 0m to 2,000m
PHYSICAL CHARACTERISTICS
Width: 197mm
Height: 225mm
Depth : 82mm (152MM + base unit)
Weight: 1150 grammes
CONTROLS LIMITED
1.
2.
3.
4.
5.
6.
EN60601-1- 2 (electro-magnetic compatibillity)
If the HC2003 fails to operate, check:
1. That there is a clear line of sight from the controller to the
HC2003 IR window.
2. That the HC2003 IR window is not in direct sunlight.
3. That HC2003 is connected to UK phone socket
If you are still unable to solve the problem, please contact Possum
Controls Ltd. at the address stated for assistance.
IF YOU HAVE A PROBLEM
SERVICING
