1.1 Physical and Electrical Specifications
Dimensions: 103mm *53mm *18.65mm
Weight: 54.5 g (with optional battery)
Input Voltage: 8-30VDC
Power consumption:
- Active mode: 200mA ＠12VDC
- Sleep mode: <8mA ＠12VDC
Operating temperature: -30℃ to 80℃
Storage temperature: -40℃to 85℃
1.2 Input/Output
Digital Inputs: 1
FJ1000L
Relay driver Outputs: 1
Function LEDs: 2
GPS Status GREEN
Cellular Status AMBER
1.3 GPS and Bluetooth
GPS and bluetooth has been closed by software
1.4 Cellular Communication
Operation Mode: FDD_LTE (Cat1)
Operation Band： Lte_B2, Lte_B4, Lte_B12
Modulation : Uplink: QPSK/16QAM
Downlink: QPSK/16QAM/64QAM
1.5 Harnesses
There are1 harnesses that may be used with the FJ1000LT:
1. 4 wire power and I/O harness
The picture above shows the 4 wire power and I/O harness. The wiring details are:
Power and I/O Harness 4 wires
1. Blackor Red V+ is connected to Positive , +12VDC or +24VDC
Page 3
FJ1000L
Positioning Universal, Inc. - Confidential & Proprietary
3
Message
#
Message Type
Description
0
Interval
Auto Report (auto report when moving)
1
Vibration
Vibration alarm(report when GPS is OFF and vibration detected)
2
Power
Disconnect
Power cut alarm (report when external power is cut off)
3
Power Connect
Power connected alarm (external power has been connected)
4
Ignition ON
Hardwired or Virtual Ignition ON detected
5
Ignition OFF
Hardwired or Virtual Ignition OFF detected
6
Input 2 High
Input2 high alarm
7
Input 2 Low
Input2 low alarm
8
Stop
Device has stopped moving
9
Heartbeat
Heartbeat periodic report
13
Input 1 High
Input1 high alarm
14
Input 1 Low
Input 1 Low alarm
19
Crash Alarm
Crash Detected
24
Heading
Change
Heading change detected
25
Tow Alert
Device is moving but being pulled
35
Starter Disabled
An output has been set by SMS command
36
Starter Enabled
An output has been cleared by SMS command
41
Harsh Accel
Harsh acceleration has been detected
42
Harsh Brake
Harsh Braking has been detected
43
Swerve Left
A left swerve has been detected
44
Swerve Right
A right swerve has been detected
2. GreyV- is connected to Negative or Ground
3. GreenInput 0 is an input biased high, negative trigger.
4. BlueOutput 0 is an output, open collector, may be used for Starter Disable.
1.6 Event Codes
The table below relates the Event codes in the message to the reason the message was
generated:
Page 4
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interferen ce recei ved,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
